A p p e n d i x A : U s e f u l M a t h 717 The other important point to take away from Eq. (A.3.6) is that the higher the frequency f of the sinusoidal driving force, the larger the coefficient of the acceleration terms in front of the sin or cos term. As we discuss in Chap. 3, electromagnetic radiation is caused by accelerated charges; it is clear from this equation that the propensity for EM radiation increases with increasing frequency f. A.4 Triangles In plane geometry we find three kinds of triangles, as shown in Fig. A.4.1: • Equilateral (where all three sides are of equal length) • Isosceles (where two sides are of equal length) • Scalene (where no two sides are the same length) All three types share a common trait: The sum of their three interior angles (a, b, and g) is always 180 degrees. We can also categorize triangles by their interior angles: • Acute (where no interior angle is 90 degrees or greater) • Right (where one interior angle is exactly 90 degrees) • Obtuse (where one interior angle is greater than 90 degrees) Right Triangles In a right triangle, one angle is always 90 degrees, so the sum of the other two angles must also be 90 degrees. The side opposite the right angle is perpendicular to neither of the other two sides, and it is always the longest side of the three; it is called the hypotenuse. If we place a right triangle on an x-y grid so that the two perpendicular sides are on the x and y axes as shown in Fig. A.4.2, the relative lengths of the sides and the three interior angles are related as shown in the figure. For a right triangle—and only for a right triangle—the square of the hypotenuse is equal to the sum of the squares of the other two sides: 2 2 2 h = a + b (A.4.1) a a a a a c Figure A.4.1 Types of plane triangles. a (A) Equilateral b (B) Isosceles b (C) Scalene
718 A p p e n d i x A : U s e f u l M a t h y hypotenuse h b Symbol indicating a right triangle a h 2 = a 2 + b 2 a = h sin b = h sin x Figure A.4.2 Right triangle relationships. so it follows that h = a 2 + b 2 and a = h 2 − b 2 and b = h 2 − a 2 (A.4.2) Sometimes it is helpful to think of the sides a and b as the projections of h onto the x and y axes, respectively. For instance, if the sun is directly overhead, a is the shadow projected by a stick having the length and orientation of h onto the ground directly beneath it. The sides and interior angles of a right triangle are related by the following equations: sin α = a h or a = h sin α (A.4.3a) sinβ = b h or b = h sin β (A.4.3b) For completeness, we list the following additional relationships in a right triangle: cosα = b h or b = h cosα (A.4.3c) cosβ = a h or a = h cosβ (A.4.3d)
- Page 688 and 689: C h a p t e r 2 9 : T o w e r s 667
- Page 690 and 691: C h a p t e r 2 9 : T o w e r s 669
- Page 692 and 693: C h a p t e r 2 9 : T o w e r s 671
- Page 694 and 695: C h a p t e r 2 9 : T o w e r s 673
- Page 696 and 697: C h a p t e r 2 9 : T o w e r s 675
- Page 698 and 699: C h a p t e r 2 9 : T o w e r s 677
- Page 700 and 701: C h a p t e r 2 9 : T o w e r s 679
- Page 702 and 703: C h a p t e r 2 9 : T o w e r s 681
- Page 704 and 705: CHAPTER 30 Grounding for Safety and
- Page 706 and 707: C h a p t e r 3 0 : G r o u n d i n
- Page 708 and 709: C h a p t e r 3 0 : G r o u n d i n
- Page 710 and 711: C h a p t e r 3 0 : G r o u n d i n
- Page 712 and 713: C h a p t e r 3 0 : G r o u n d i n
- Page 714 and 715: C h a p t e r 3 0 : G r o u n d i n
- Page 716 and 717: C h a p t e r 3 0 : G r o u n d i n
- Page 718 and 719: C h a p t e r 3 0 : G r o u n d i n
- Page 720 and 721: CHAPTER 31 Zoning, Restrictive Cove
- Page 722 and 723: C h a p t e r 3 1 : Z o n i n g , R
- Page 724 and 725: C h a p t e r 3 1 : Z o n i n g , R
- Page 726 and 727: Appendices
- Page 728 and 729: APPENDIX A Useful Math The material
- Page 730 and 731: A p p e n d i x A : U s e f u l M a
- Page 732 and 733: A p p e n d i x A : U s e f u l M a
- Page 734 and 735: A p p e n d i x A : U s e f u l M a
- Page 736 and 737: A p p e n d i x A : U s e f u l M a
- Page 740 and 741: A p p e n d i x A : U s e f u l M a
- Page 742 and 743: A p p e n d i x A : U s e f u l M a
- Page 744 and 745: A p p e n d i x A : U s e f u l M a
- Page 746 and 747: A p p e n d i x A : U s e f u l M a
- Page 748 and 749: Appendix B Suppliers and Other Reso
- Page 750 and 751: A p p e n d i x B : S u p p l i e r
- Page 752 and 753: A p p e n d i x B : S u p p l i e r
- Page 754 and 755: A p p e n d i x B : S u p p l i e r
- Page 756 and 757: A p p e n d i x B : S u p p l i e r
- Page 758 and 759: A p p e n d i x B : S u p p l i e r
- Page 760 and 761: B.1.6 Rotators and Controllers Alfa
- Page 762 and 763: A p p e n d i x B : S u p p l i e r
- Page 764 and 765: A p p e n d i x B : S u p p l i e r
- Page 766 and 767: Index Note: Boldface numbers denote
- Page 768 and 769: I n d e x 747 Binns, Jack, first ma
- Page 770 and 771: I n d e x 749 dipole (Cont.): slopi
- Page 772 and 773: I n d e x 751 grounding and ground
- Page 774 and 775: I n d e x 753 ionospheric propagati
- Page 776 and 777: I n d e x 755 maximum effective len
- Page 778 and 779: I n d e x 757 noise (Cont.): sky no
- Page 780 and 781: I n d e x 759 reactance: cancellati
- Page 782 and 783: I n d e x 761 standing waves: on an
- Page 784 and 785: I n d e x 763 transmission lines, 1
- Page 786 and 787: I n d e x 765 vertically polarized
718 A p p e n d i x A : U s e f u l M a t h<br />
y<br />
hypotenuse<br />
<br />
h<br />
b<br />
Symbol indicating a<br />
right triangle<br />
<br />
a<br />
h 2 = a 2 + b 2<br />
a = h sin <br />
b = h sin <br />
x<br />
Figure A.4.2 Right triangle relationships.<br />
so it follows that<br />
h = a 2 + b 2 and a = h 2 − b 2 and b = h 2 − a<br />
2<br />
(A.4.2)<br />
Sometimes it is helpful to think of the sides a and b as the projections of h onto the x<br />
and y axes, respectively. For instance, if the sun is directly overhead, a is the shadow<br />
projected by a stick having the length and orientation of h onto the ground directly beneath<br />
it.<br />
The sides and interior angles of a right triangle are related by the following equations:<br />
sin α = a h or a = h sin α<br />
(A.4.3a)<br />
sinβ = b h<br />
or b = h sin β (A.4.3b)<br />
For completeness, we list the following additional relationships in a right triangle:<br />
cosα = b h<br />
or b = h cosα (A.4.3c)<br />
cosβ = a h<br />
or a = h cosβ (A.4.3d)
