DYNEMECH ANTI VIBRATION TECHNOLOGY<br />
ENHANCING INDUSTRIAL STABILITY<br />
A DEEP DIVE INTO DYNEMECH'S VIBRATION INSULATION PLATES<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
VIBRATION<br />
INSULATION PLATES<br />
INNOVATIVE SOLUTIONS FOR VIBRANT<br />
INDUSTRIES<br />
<strong>Vibration</strong> management is crucial for optimal performance<br />
in the dynamic world of industrial machinery. <strong>Dynemech</strong><br />
<strong>Vibration</strong> Insulation Plates are a reliable solution to this<br />
issue, offering numerous benefits for diverse industries.<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
STRATEGIC ADVANTAGES OF<br />
VIBRATION MANAGEMENT<br />
WHY IT'S A GREAT INVESTMENT OPTION<br />
Fast , Easy and<br />
Inexpensive<br />
Machinery<br />
Installation<br />
Enhanced<br />
Component Finish,<br />
Accuracy and Part<br />
Tolerance<br />
<strong>Vibration</strong> Reduction<br />
for Prolonged<br />
Machinery<br />
Lifespan<br />
Safeguarding<br />
Machinery and<br />
Surrounding<br />
Structures<br />
Unique cell design ;<br />
high coefficient of<br />
friction - prevents<br />
“machine walking”.<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
VIBRATION DAMPING<br />
SHEETS<br />
MATERIAL COMPOSITION<br />
Made from a high-grade synthetic elastomeric composite material of<br />
Nitrile <strong>Rubber</strong>, Cork, Synthetic Fibre.<br />
LOAD CAPACITIES:<br />
Manufactured in different load capacities, allowing them to support<br />
machines of various weights.<br />
NATURAL FREQUENCIES<br />
Engineered for different natural frequencies, for providing vibration<br />
damping to almost all machine tool.<br />
RESISTANCE<br />
Resistant to water, oils, lubricating oils, fuels, etc., making them suitable<br />
for use in industrial environments.<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
VIBRATION DAMPING<br />
SHEETS<br />
STRESS VALUES<br />
Each sheet has defined stress values, and they can be placed directly under<br />
the machine based on the weight of the machine and the number of<br />
mounting positions.<br />
DEFORMATION RESISTANCE<br />
The plates are designed not to deform plastically, provided the weight of<br />
the machine does not exceed the maximum load value specified for the<br />
insulation plates.<br />
THICKNESS OPTIONS<br />
The plates are available in various thicknesses, including 2mm, 8mm,<br />
15mm, 20mm, 25mm, and 65mm.<br />
SIZES<br />
The maximum available size for Dp1, Dp3 is 600x600mm. For others, it is<br />
500x500mm. These sheets can be cut & supplied as per specific<br />
requirements.<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Du<br />
Applications :<br />
Tool Room Machines, Plastic Injection Moulding Machines,<br />
Pressure Die Casting Machines, Printing and Textile<br />
Machines (For Machines having high axial forces.)<br />
Load Capacity (Kg./sq. cm) : 3-9<br />
Thickness (mm) : 15<br />
Coefficient of Friction : 0.9<br />
Natural Frequency Range : 35 Hz-18 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Du-10<br />
Applications :<br />
Tool Room Machines, Plastic Injection Moulding Machines,<br />
Pressure Die Casting Machines, Printing and Textile<br />
Machines (For Machines having high axial forces.)<br />
Load Capacity (Kg./sq. cm) : 3-9<br />
Thickness (mm) : 10<br />
Coefficient of Friction : 0.9<br />
Natural Frequency Range : 35 Hz-18 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Du-12<br />
Applications :<br />
Tool Room Machines, Plastic Injection Moulding Machines,<br />
Pressure Die Casting Machines, Printing and Textile<br />
Machines (For Machines having high axial forces.)<br />
Load Capacity (Kg./sq. cm) : 3-9<br />
Thickness (mm) : 12<br />
Coefficient of Friction : 0.9<br />
Natural Frequency Range : 35 Hz-18 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dm<br />
Applications :<br />
Lathe Machines, Milling Machines, Grinding Machines,<br />
Machining Centres, Turning Centres etc.<br />
Load Capacity (Kg./sq. cm) : 5-10<br />
Thickness (mm) : 15<br />
Coefficient of Friction : 0.7<br />
Natural Frequency Range : 50 Hz-30 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Di<br />
Applications :<br />
For machines with high vertical dynamic forces such as<br />
Power Presses, Punching Machines, Stamping Machines,<br />
Shearing Machines etc.<br />
Load Capacity (Kg./sq. cm) : 5-14<br />
Thickness (mm) : 25<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 25 Hz-7 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dp1<br />
Applications :<br />
Tuned to low natural frequency, suitable for passive<br />
vibration control of Measuring & Testing Machines,<br />
Grinders etc.<br />
Load Capacity (Kg./sq. cm) : 1-4<br />
Thickness (mm) : 15<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 20 Hz-7 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dp2<br />
Applications :<br />
Suitable for passive vibration control of measuring &<br />
testing machines maintains machines stability along with<br />
vibration reduction.<br />
Load Capacity (Kg./sq. cm) : 1-5<br />
Thickness (mm) : 20<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 30 Hz-12 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dp3<br />
Applications :<br />
Tuned to low natural frequency, suitable for both active &<br />
passive vibration isolation of metrology and production<br />
machines.<br />
Load Capacity (Kg./sq. cm) : 2-6<br />
Thickness (mm) : 24<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 15 Hz-7 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Ds1<br />
Applications :<br />
Light Weight Presses, Tool Room Machines, Compressors<br />
etc. on Ground Floor as well as upper Floors.<br />
Load Capacity (Kg./sq. cm) : 2-5<br />
Thickness (mm) : 20<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 35 Hz-15 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Ds1<br />
Applications :<br />
Light Weight Presses, Tool Room Machines, Compressors<br />
etc. on Ground Floor as well as upper Floors.<br />
Load Capacity (Kg./sq. cm) : 2-5<br />
Thickness (mm) : 20<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 35 Hz-15 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Ds2<br />
Applications :<br />
High <strong>Vibration</strong> Insulation for both active and passive range,<br />
Medium Presses, Stamping Machines, also well suited for<br />
high speed rotating machines on upper floors.<br />
Load Capacity (Kg./sq. cm) : 2-8<br />
Thickness (mm) : 25<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 35 Hz-8 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dhs1<br />
Applications :<br />
Forging Hammers, Heavy Gen Sets, Heavy Industrial<br />
Machines, Test Rigs, Heavy Presses etc.<br />
Load Capacity (Kg./sq. cm) : 5-20<br />
Thickness (mm) : 65<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 12 Hz-6 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dhs2<br />
Applications :<br />
Forging Hammers, Heavy Gen Sets, Heavy Industrial<br />
Machines, Test Rigs, Heavy Presses, Crushers etc.<br />
Load Capacity (Kg./sq. cm) : 2-8<br />
Thickness (mm) : 65<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 8 Hz-4 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dhs3<br />
Applications :<br />
Forging Hammers, Heavy Gen Sets, Heavy Industrial<br />
Machines, Test Rigs, Heavy Presses, etc.<br />
Load Capacity (Kg./sq. cm) : 4-28<br />
Thickness (mm) : 50<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 15 Hz-7 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dhs4<br />
Applications :<br />
Forging Hammers, Heavy Gen Sets, Heavy Industrial<br />
Machines, Test Rigs, Heavy Presses, Crushers,etc.<br />
Load Capacity (Kg./sq. cm) : 3-12<br />
Thickness (mm) : 50<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 8 Hz-5 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dhs5<br />
Applications :<br />
Forging Hammers, Heavy Gen Sets, Heavy Industrial<br />
Machines, Test Rigs, Heavy Presses, etc.<br />
Load Capacity (Kg./sq. cm) : 4-28<br />
Thickness (mm) : 80<br />
Coefficient of Friction : 0.8<br />
Natural Frequency Range : 12 Hz-5 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> Insulation Plate , Dh<br />
Applications :<br />
Very Heavy and Long Bed Machines, Long Machining<br />
centres, Planners etc.<br />
Load Capacity (Kg./sq. cm) : 10-35<br />
Thickness (mm) : 15<br />
Coefficient of Friction : 0.6<br />
Natural Frequency Range : 70 Hz-45 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> <strong>Anti</strong> Skid Plate , Da1<br />
Load Capacity (Kg./sq. cm) : 2-18<br />
Thickness (mm) : 2<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> <strong>Anti</strong> Skid Plate , Da2<br />
Load Capacity (Kg./sq. cm) : 2-10<br />
Thickness (mm) : 8<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
DyneStarke Shock & <strong>Vibration</strong> Isolation<br />
<strong>Pads</strong> , DHS6-ML<br />
High Strength , Exceptional Shock Absorption, High<br />
<strong>Vibration</strong> <strong>Damping</strong><br />
Applications: HVAC Equipements, Gensets, AHUs,<br />
Transformers, Compressors, Pumps etc.<br />
Load Capacity (Kg./sq. cm) : 527<br />
Thickness (mm) : 15,25<br />
Coefficient of Friction : 0.7<br />
Natural Frequency Range : 15 Hz-20 Hz<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Dynemech</strong> Rituresilire <strong>Vibration</strong><br />
Isolation <strong>Pads</strong> , DU-10-NP<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
Customised<br />
VIBRATION DAMPING PADS<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
Customised<br />
VIBRATION DAMPING PADS<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
VIBRATION ISULATION PLATE<br />
UNDER DISPATCH<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> <strong>Damping</strong> <strong>Pads</strong> In Action<br />
Dp Insulation Plates<br />
installed under the<br />
Table and Microscope<br />
in IVF Laboratory<br />
AFTER ANTI<br />
VIBRATION PLATES<br />
Dp <strong>Vibration</strong> Isolation<br />
Sheet<br />
BEFORE ANTI<br />
VIBRATION PLATES<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> <strong>Damping</strong> <strong>Pads</strong> In Action<br />
MickroVicker<br />
Hardness Tester<br />
Machine on <strong>Vibration</strong><br />
Isolation <strong>Pads</strong> Dp<br />
Belt Grinder installed<br />
on <strong>Vibration</strong><br />
Insulation <strong>Sheets</strong><br />
Weighing Balance<br />
installed on <strong>Vibration</strong><br />
Insulation <strong>Sheets</strong><br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> <strong>Damping</strong> <strong>Pads</strong> In Action<br />
Hammer anvil on Dhs<br />
Shock Isolation Plate<br />
DNM Insulation Plates<br />
for Foundation<br />
Isolation For 50 T<br />
DOOSAN VMC<br />
ISOLATED<br />
FOUNDATION For<br />
Zeiss CMM<br />
Spectrum: 10/12/6<br />
on Dp Insulation<br />
Plate Stack<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
<strong>Vibration</strong> <strong>Damping</strong> <strong>Pads</strong> In Action<br />
<strong>Anti</strong> <strong>Vibration</strong> Tables with Elastomeric Isolation use<br />
<strong>Vibration</strong> <strong>Damping</strong> <strong>Sheets</strong><br />
<strong>Vibration</strong> Isolated<br />
Table with<br />
<strong>Dynemech</strong><br />
vibration Isolation<br />
<strong>Sheets</strong><br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
HEADING1-A<br />
APPLICATIONS<br />
Plastic Injection Moulding Machines<br />
★CNC Turning/ Machining Centers<br />
★Pressure Die Casting Machines<br />
★<br />
★Coal Crushers, Turbines, ID/FD Fans<br />
★Printing and Packaging Machines<br />
★Food and Pharmaceutical Machines<br />
★CMM and EDM Machines<br />
★Press Brakes and Turret Punch Presses<br />
Surface Roughness Tester<br />
★<br />
★Power Presses<br />
★Tool Room Machines<br />
★Textile Machines<br />
★ Forging Hammers<br />
CNC Milling<br />
Lathes, Broachers<br />
★HMC/VMC<br />
★<br />
★Gear Profile Tester<br />
★<br />
★Deep Drilling Machines<br />
★Generators, Compressors &<br />
HVAC Installations<br />
★Punching, Stamping & Shearing<br />
Machines<br />
★Measuring and Testing Machines &<br />
Equipements (Surface Plates,<br />
Hardness Testers)<br />
★<strong>Anti</strong>-<strong>Vibration</strong> Tables and Isolation<br />
Platforms<br />
★ Precision Machine Tools (Turning<br />
Centers, Machining Centers,<br />
Grinding Machines)<br />
★Centrifugal Pumps and Fans<br />
★ Contour Measuring Machines<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
MEET US :<br />
Unit II: Plot No.: 44, HSIIDC,<br />
Rai Industrial Area, Sonepat,<br />
Haryana-131029<br />
Unit I: Plot No.:136, HSIIDC,<br />
Rai Industrial Area, Sonepat,<br />
Haryana-131029<br />
RU-395, Near Power<br />
House, Main Outer<br />
Ring Road, Pitam<br />
Pura, Delhi-110034<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
LET'S TALK!<br />
HOW TO GET IN TOUCH<br />
PHONE NUMBER<br />
+91-9911145131,<br />
+91-9810760131<br />
EMAIL ADDRESS<br />
sales@dynemech.com<br />
WEBSITE<br />
www.vibrationmountsindia.com<br />
www.vibrationdampingpads.com<br />
sales@dynemech.com | +91-9810760131 | vibrationmountsindia.com
Change language
