www.cpt-international.com<br />
WITH SUPPLIERS GUIDE<br />
Juni<br />
2<strong>02</strong>1<br />
CASTING<br />
PLANT AND TECHNOLOGY<br />
INTERNATIONAL<br />
2<br />
Setting The Standards For Highest<br />
Efficiency In Thermal Processing<br />
Soluons for:<br />
-the steel industry<br />
-the aluminum industry<br />
-foundries and for hot dip galvanizing<br />
www.jasper-gmbh.de<br />
WK Know-How<br />
by Jasper GmbH
Thenew technical journal<br />
WE ACCOMPANY THE FUTURE OF<br />
THEINTERNATIONAL STEEL INDUSTRY<br />
steel production<br />
application technology<br />
innovation +management<br />
processing<br />
READ STEEL + TECHNOLOGY REGULARLY.<br />
SUBSCRIBE NOW AT WWW.DVS-MEDIA.EU/STAHL
EDITORIAL<br />
Innovative spirit and digitalization<br />
shape the future!<br />
The vaccination rate is rising worldwide –asisthe hope that, as the<br />
time of social distancing comes to an end, we will soon beattending<br />
meetings and conferences again. It will be seen that the pandemic has<br />
not been lost time in technological terms. What matters now is to<br />
look to the future, which will be characterized by asustained innovative<br />
spirit and continuing digitalization.<br />
state-of-the-art and will come out of<br />
the pandemic strengthened (read our<br />
interview from P. 6)<br />
There was also no loss of innovative<br />
spirit during the crisis: at the <strong>International</strong><br />
Foundry Conference in Portoroz<br />
(Slovenia) last September, Ashley Stone<br />
presented his plant design for casting<br />
semi-solid magnesium. Now CP+T offers<br />
him the opportunity to present his casting<br />
technology for the “green 21st century”,<br />
that can also be used for drive<br />
forward digitalization (from P. 16).<br />
Robert Piterek<br />
e-mail: robert.piterek@bdguss.de<br />
While the pandemic is gradually<br />
going to come to an end,<br />
some casters are looking<br />
back at this time with satisfaction.<br />
Because various foundries have used<br />
the crisis to expand their value-creation<br />
chains and have, for example, built up<br />
their mechanical processing capabilities.<br />
Such is the case at the die-casting<br />
foundry Industria Metalli in Bedizzole<br />
(Italy) which will in future offer their<br />
customers tangible added value and<br />
will thus be able to become more competitive<br />
(see P. 10).<br />
The clock has also continued to tick at<br />
other places in the sector, where the<br />
next generation of managers start to<br />
work. Anew man will take the place of<br />
Heinz Nelissen, GIFA President 2019 and<br />
Foseco’s Head ofNorthern Europe.<br />
According to Hannes Erger, German<br />
foundries represent the technological<br />
Digitalization in the foundry industry<br />
has been arepeated topic in recent<br />
issues. At the same time, many foundries<br />
around the world still operate as<br />
they did in the old days. How far has<br />
the foundry industry come on its transformation<br />
process towards the foundry<br />
of the future? The sector is put to the<br />
test using Germany as an example. Is<br />
the digital foundry merely wishful<br />
thinking or amodel for the future? Find<br />
out more from Page 32.<br />
This issue offers an expanded news<br />
review. New faces are presented, as are<br />
important partnerships, innovative processes<br />
and new plants. Whereby the<br />
trend continues to ever-larger die-casting<br />
plants for large light-metal castings<br />
with integrated functions, e.g. from<br />
Italpresse Gauss or the Bühler Group.<br />
Have agood read!<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 3
CONTENTS<br />
FEATURES<br />
6 INTERVIEW<br />
“The foundry industry will emerge stronger<br />
from the pandemic!“<br />
At Foseco, Hannes Erger succeeds Heinz Nelissen.<br />
Interview with the two experts about Foseco‘s<br />
future challenges and the state of the German<br />
foundry industry. Robert Piterek, Martin Vogt<br />
10 MACHINING<br />
Expanding value creation in the lockdown<br />
Atraditional foundry in the Italian region of Lombardy<br />
used the involuntary break in production to<br />
establish amechanical manufacturing facility.<br />
Nikolaus Fecht<br />
16 CASTING TECHNOLOGY<br />
MAXImolding -Magnesium alloy injection<br />
molding in the digital foundry<br />
Inventor Ashley Stone combined the advantages of<br />
Thixomolding and hot- and cold-chamber high-pressure<br />
casting machines into the MAXImolding<br />
machine and process. Ashley Stone, Edo Meyer<br />
DIGITALIZATION<br />
Charging via Joystick<br />
at Düker in Laufach.<br />
New technologies<br />
bring long term competitive<br />
advantages.<br />
MACHINING<br />
Industria Metalli used<br />
the lockdown to build<br />
up a mechanical<br />
manufacturing facility.<br />
24 SIMULATION<br />
Optimizing service life of die casting tools<br />
Tool life is one of the main cost factors in high<br />
pressure die casting. The Italian foundry Mazzucconi<br />
used Magmasoft to increse the die life of a<br />
steering housing, Andreas Heitmann, Mechele<br />
Zanni, Daniele Bianchi.<br />
GRINDING<br />
New grinding wheels<br />
for more productivity<br />
and quality.<br />
Cover-Photo:<br />
JASPER Gesellschaft für Energiewirtschaft<br />
und Kybernetik mbH<br />
Bönninghauser Strasse 10<br />
59590 Geseke (Germany)<br />
info@jasper-gmbh.de<br />
www.jasper-gmbh.de<br />
4
CONTENTS<br />
INTERVIEW<br />
Hannes Erger succeeds<br />
Heinz Nelissen<br />
at Foseco.<br />
27 AUTOMATION<br />
From casting to cleaning in 60 seconds<br />
A60second cycle is made possible by aproduction<br />
line from August Mössner, Dietmar Schmid, Christian<br />
Kunz<br />
30 GRINDING<br />
Cool grinding for more parts per wheel<br />
Anew elctroplated single-layer grinding wheel<br />
increases productivity and product quality, Andreas<br />
Eckhard<br />
32 DIGITALIZATION<br />
The digital foundry –wishful thinking or a<br />
model for the future?<br />
To what extent have digital production technologies<br />
so far taken over the work halls of German<br />
and Swiss foundries? Alook at the foundries<br />
reveals it, Robert Piterek<br />
36 MOLD AND COREMAKING<br />
Efficient curing process of the core making<br />
machine<br />
The article features the development method,<br />
value, and performance of the core heater with an<br />
integrated design concept, Yang Linlong, Xu Leilei<br />
COLUMNS<br />
3 EDITORIAL<br />
41 NEWS<br />
51 SUPPLIER GUIDE<br />
58 FAIRS AND KONGRESSES/AD INDEX<br />
59 PREVIEW/IMPRINT<br />
NEWS<br />
The trend to ever-larger<br />
die casting plants<br />
for large light-metal<br />
castings continues.<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 5
INTERVIEW<br />
Photos: BDG/Vogt; Foseco<br />
Interview situation in times of the pandemic. Heinz Nelissen and Hannes Erger answer questions from the GIESSEREI editorial team.<br />
„The foundry industry will emerge<br />
stronger from the pandemic!“<br />
With Heinz Nelissen, President of GIFA 2019 and Managing Director at Foseco/Vesuvius,<br />
one ofthe best-known movers and shakers in the foundry industry is retiring. With Hannes<br />
Erger, the group isfilling the succession inthe management from its own ranks. In<br />
the interview, the two experts explain what challenges Foseco will face in the future and<br />
where Germany‘s foundry industry currently stands.<br />
Mr. Nelissen, aclassic question to start<br />
with: What will you do in the future?<br />
Ihave arranged with my wife that we<br />
will go on certain trips together. Of<br />
course, Ihave been afrequent traveller<br />
in the past years -onbusiness, of<br />
course. Family holidays have long taken<br />
aback seat to that. We will change<br />
that, for example to catch up with New<br />
York, where we actually already wanted<br />
to go in 2<strong>02</strong>0. South Africa is also one<br />
of our goals.<br />
In addition, Iwill do more<br />
endurance sports and would like to hike<br />
regularly around Unterbacher See in<br />
Düsseldorf. But still, Iwon‘t leave the<br />
industry completely in my mind. Iwill<br />
certainly continue to follow its magazines<br />
GIESSEREI and CP+T <strong>International</strong>.<br />
And Ialso plan to attend the one or<br />
other foundry event.<br />
Youhave been working in the Foseco<br />
Group since the end of the 1980s. What<br />
has changed during this time?<br />
Nelissen: Youcould write abook about<br />
that. Yesterday and today are worlds<br />
apart. First, German unification brought<br />
with it the large newly accessible<br />
foundry market in the five East German<br />
states. By visiting the big foundries,<br />
making contacts and presenting the<br />
products, this was avery big change<br />
that continues to this day, because a<br />
large part of the German foundry<br />
industry is in the East. Then in the 1990s<br />
there was too much foundry capacity in<br />
Germany, which led toastrong consolidation.<br />
Nevertheless, casting tonnage in<br />
Germany remained stable, but spread<br />
over fewer locations. However, other<br />
large European markets such as the UK<br />
and France lost large amounts of casting<br />
capacity to Eastern Europe and Turkey.<br />
Then there has been heavy investment<br />
in automation -atrend that<br />
continues today. Ifyou look at today‘s<br />
molding lines, they have become much<br />
faster compared to the past. Today, significantly<br />
more castings are produced<br />
per employee hour than in the past. At<br />
6
the same time, we see agrowth in<br />
non-ferrous foundries and ashift<br />
towards processes that can be automated.<br />
The challenges of globalization created<br />
new market access, but also new<br />
competitors, for foundries as well as<br />
foundry suppliers. Foundries today are<br />
much cleaner, interms of emissions and<br />
overall appearance, and some can be<br />
considered high-tech operations.<br />
Where does the German foundry industry<br />
stand today?<br />
Compared to the rest of Europe, Germany<br />
has been and remains the number<br />
one country for cast tonnage, albeit<br />
now with completely different segments,<br />
alloys and processes. But Germany<br />
is still in avery good position, also<br />
because of its philosophy of investing<br />
and modernizing processes. That is not<br />
necessarily the case in other countries.<br />
Now, the use of energy is being optimized<br />
in this country, for example in furnaces.<br />
Because the non-ferrous sector is<br />
growing very strongly, wealso see large<br />
investments in the die-casting sector.<br />
The willingness to spend money on<br />
modernization is astrength that Germany<br />
has and that also ensures that we<br />
remain aleader.<br />
Heinz Nelissen has been successfully involved with Foseco for 31 years. He has already resigned<br />
from his position as Managing Director at Vesuvius GmbH. He will remain Foseco Area<br />
Director Northern Europe until the end of June. In 2019, he was president of GIFA.<br />
Mr. Nelissen, in 2019 you were appointed<br />
President of GIFA, which was very<br />
successful that year. What do you think<br />
will become of the GIFA trade fair format<br />
under the impression of 2<strong>02</strong>0 and<br />
increasing digitalization?<br />
Trade fairs are currently struggling to<br />
show how important they are for the<br />
trade. GIFA 2019 was different, as it was<br />
very successful and took place at just<br />
the right moment. We already saw a<br />
downturn in car manufacturing at the<br />
end of2019, then the Corona crisis<br />
came just afew months later. Since<br />
then, digitalization has been advancing<br />
in leaps and bounds, even our interview<br />
would probably have been conducted<br />
in person rather than via Microsoft<br />
Teams if it hadn‘t been for Corona. In<br />
the meantime, we at Foseco also conduct<br />
alot of customer meetings online.<br />
This digitalization push will continue<br />
and lead to further process automation<br />
in the foundries and to more advanced<br />
robot technology. This will certainly be<br />
afocus at the next GIFA in2<strong>02</strong>3. The<br />
next GIFA will probably also be able to<br />
take place as aface-to-face event again.<br />
This is necessary to stimulate the dialogue<br />
ofthe international foundry world.<br />
By 2<strong>02</strong>3 the foundry market will have<br />
stabilized again and 2<strong>02</strong>3 could therefore,<br />
from today‘s point of view, be<br />
exactly the right date for the next successful<br />
GIFA.<br />
Mr. Nelissen, you resigned from the<br />
management of Foseco’ sparent company<br />
Vesuvius at the beginning of the<br />
year. You will relinquish your post as<br />
Area Director Northern Europe in the<br />
summer. Hannes Erger will become a<br />
member of the management of Vesuvius<br />
in Borken. What would you like to<br />
pass on to him?<br />
Hannes Erger is already very experienced<br />
inhis previous job, he knows the<br />
customer structure and the core contact<br />
persons. He is already very well positioned.<br />
Otherwise: Focus on customers<br />
and employees. This is the only way we<br />
can learn about challenges in the market<br />
atanearly stage, develop targeted<br />
solutions and then establish them with<br />
the customers through our employees.<br />
This is the only way to create value for<br />
the customer and to make the business<br />
sustainable. There will be many challenges,<br />
but ifyou ever must weigh up between<br />
an internal meeting and acustomer<br />
meeting, choose: Customer first!<br />
That has always been my priority.<br />
Mr. Erger, you have been working at<br />
Foseco for 21 years, currently as Business<br />
Unit Manager Iron and Steel<br />
Foundries. With what feelings are you<br />
taking over from Mr. Nelissen?<br />
Erger: Ihave been working with Mr.<br />
Nelissen for more than 20 years and I<br />
am full of enthusiasm to take over<br />
from him, but at the same time Iknow<br />
that this will be agreat challenge for<br />
me, as Heinz Nelissen has made aname<br />
for himself in the foundry world as a<br />
very competent and respected partner<br />
for customers, employees and foundry<br />
experts over decades. However, Iam<br />
happy to take on this challenge and<br />
am confident that Iwill be able to continue<br />
the cooperative relationship with<br />
the foundrymen that Mr. Nelissen has<br />
shaped.<br />
What would you like to achieve for<br />
your company as Mr. Nelissen’ ssuccessor<br />
at Foseco?<br />
Erger: Foseco stands for Foundry Service<br />
Company. The basic idea is to be at the<br />
service of the customer and together<br />
with the customer we will continue to<br />
apply our proven Foseco business<br />
model. In the cooperation between the<br />
management personnel in the foundries<br />
and our sales engineers, topics such<br />
as changes in processes or minimizing<br />
the use of resources are important<br />
aspects. With innovative Foseco product<br />
applications, we want to continue to<br />
achieve productivity increases and quality<br />
improvements. We also have many<br />
new product ideas ‘in the pipeline’,<br />
developed in our development centre in<br />
the Dutch city of Enschede according to<br />
the requirements of our global foundry<br />
customers. Wewill present these to our<br />
customers inatimely manner. Foseco<br />
wants to contribute to making foundry<br />
products ‘Made in Germany’ even more<br />
efficient and attractive. In this way we<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 7
INTERVIEW<br />
can help to secure Germany as an<br />
important foundry location in the long<br />
term.<br />
Mr. Nelissen, Mr. Erger. The foundry<br />
industry is affected by the pandemic.<br />
The trend towards electromobility continues.<br />
In which direction is the industry<br />
developing?<br />
Nelissen: Casting tonnage in Germany<br />
fell by around 35 %in2<strong>02</strong>0 due to the<br />
pandemic-related reduction in the<br />
market. Incidentally, the magnitude is<br />
reminiscent of the effects of the 2009<br />
financial crisis. The global trends<br />
remain essentially unaffected by the<br />
pandemic. Today, weassume that cast<br />
tonnage will stabilize again over the<br />
course of two years and return to the<br />
level of 2019. E-mobility is, of course, a<br />
trend that is strongly influencing the<br />
market, especially for passenger cars. If<br />
hybrid vehicles are produced, the cast<br />
share is stable. With all-electric<br />
vehicles, more non-ferrous metal castings<br />
are used, but important iron castings,<br />
especially in the engine and<br />
drive area, are eliminated. The corresponding<br />
foundries must look for replacements<br />
in time.<br />
Erger: This is adifficult question to answer<br />
because the world continues to be<br />
during aglobal health crisis and aworld<br />
economic crisis whose effects are still<br />
uncertain. Ithink, like Mr. Nelissen, that<br />
the German foundry industry and thus<br />
also Foseco will have to deal with the<br />
consequences of the Corona pandemic<br />
in the medium term. But in the end, I<br />
am convinced that we will emerge<br />
stronger from the pandemic. It is<br />
important to make the right business<br />
decisions now toposition ourselves for<br />
the future. Ofcourse, this also includes<br />
the orientation of the companies, especially<br />
the automotive foundries, to face<br />
the changing demands ofthe electromobility<br />
market and to break new<br />
ground. Brake discs and various chassis<br />
parts will probably remain, but engine<br />
blocks will certainly disappear. However,<br />
it will certainly be several years before<br />
electromobility can establish itself. For<br />
that, fundamental changes in the infrastructure<br />
are still necessary, which first<br />
have to be created.<br />
And what challenges do you both see<br />
for Foseco?<br />
Nelissen: Foseco is part of the Vesuvius<br />
Group, which has come through the crisis<br />
in astable manner so far. Ingeneral,<br />
however, Foseco, the foundry business<br />
Hannes Erger has been appointed to the management team in Borken. He has been working<br />
for Foseco for more than 20 years, currently Business Unit Manager for the iron and<br />
steel foundry sector. Infuture, he will also represent this sector in public relations and<br />
association work.<br />
of Vesuvius, is globally positioned. We<br />
can therefore compensate for geographical<br />
shifts in demand. Now we see a<br />
lot of demand in Eastern Europe and<br />
Mexico. Market proximity is always in<br />
demand. That‘s why we always must<br />
have local forces on site, because we<br />
can‘t necessarily serve the Chinese market<br />
with product managers from Germany<br />
or England, for example. We<br />
must support the growth of the<br />
non-ferrous foundries by building up<br />
appropriate resources. We are continuing<br />
to strengthen this business, but we<br />
already have avery strong presence<br />
there.<br />
Erger: Foseco’ sstrength is its market<br />
presence and proximity to our foundry<br />
customers. It is important that we face<br />
the changing market requirements and<br />
globalization together with our customers<br />
and develop aunique selling proposition<br />
with innovative and individual<br />
casting applications in the different segments<br />
of the foundry industry.<br />
In which direction are you developing<br />
your products for Germany in particular?<br />
Erger: We are facing all the challenges<br />
that foundries must master. These are,<br />
for example, the many environmental<br />
regulations. With our products we are<br />
therefore trying to contribute to the<br />
reduction of CO2 emissions. The<br />
environment and efficiency are key<br />
issues for the future that we must continue<br />
to address.<br />
The German foundry industry will<br />
emerge stronger from the crisis, you<br />
say Mr. Erger. Isthe reason for your<br />
optimism that German foundries are<br />
more solidly positioned than other<br />
countries by investing in modernization<br />
and sustainability?<br />
Erger: Yes, most foundries have earned<br />
money in the past, which they are now<br />
investing in modernization to become<br />
more efficient. This keeps German<br />
foundries at the cutting edge of technology.<br />
Sustainability will certainly also<br />
be acrucial issue. We have many enquiries<br />
from foundries about how our products<br />
can contribute to reducing CO2<br />
emissions. Overall, we have been focusing<br />
on sustainability for along time. At<br />
the last GIFA, it was our main topic.<br />
Nelissen: Sustainability is becoming<br />
more and more important. Customers<br />
from the Scandinavian region also<br />
already attach importance to acommitment<br />
to sustainability. This trend is set<br />
to increase.<br />
The interview with Heinz Nelissen and<br />
Hannes Erger was conducted by Robert<br />
Piterek and Martin Vogt –editorial<br />
team of GIESSEREI magazine. It<br />
is published by the German Foundry<br />
Association BDG as well as CP+T <strong>International</strong>,<br />
which is the English language<br />
sister magazine of GIESSEREI.<br />
8
Iron Melting<br />
Conference&<br />
Exhibition2<strong>02</strong>1<br />
Saarbrücken, Germany<br />
September 28 and 29, 2<strong>02</strong>1<br />
CCS Congress-Centrum Saar<br />
Topics of the conference:<br />
Foto: Darius Soschinski/BDG<br />
Contact and further information:<br />
VDG Verein Deutscher Giessereifachleute e.V.<br />
VDG-Akademie<br />
Christopher Neu<br />
christopher.neu@vdg-akademie.de<br />
BDG Bundesverband der Deutschen Gießerei-Industrie<br />
Dr. Ingo Steller<br />
ingo.steller@bdguss.de<br />
E-Mail Registration:<br />
christopher.neu@vdg-akademie.de<br />
corinna.knoepken@vdg-akademie.de<br />
ironmelting.com<br />
>Efficient Cupola Operation<br />
>Efficient Induction Furnace Operation<br />
>Charge Materials (conventional, alternatives)<br />
>Measures toEnhance Energy Efficiency and Flexibility<br />
>Decarbonization, Hydrogen<br />
>Circular Economy<br />
>Digitalisation<br />
Early bird discount until June, 30, 2<strong>02</strong>1<br />
Official registration deadline: August, 30, 2<strong>02</strong>1.
MACHINING<br />
An electronically controlled<br />
coolant supply ensures the<br />
temperature stabilisation of<br />
the workpiece and the tool<br />
and takes care ofswarf<br />
removal.<br />
Die casting foundry invests in machining<br />
Expanding value creation<br />
in the lockdown<br />
While the lockdown in Italy saw many companies struggle, atraditional foundry in the<br />
Italian region of Lombardy used the involuntary break in production to establish a<br />
mechanical manufacturing facility. Infuture, the rough cast parts will no longer need<br />
to leave the factory to be finished —instead, they will be finished on-site using two<br />
Heckert machining centres.<br />
By Nikolaus Fecht, Gelsenkirchen<br />
Photos: STARRAG/RALF BAUMGARTEN<br />
Acompany‘s choice of pictures can<br />
often tell you something about<br />
the company itself –and this is<br />
also the case in Bedizzole, not far from<br />
Lake Garda. In the conference room of<br />
Industria Metalli, there is apicture titled<br />
„Obiettivi“ (goals). The picture<br />
shows ahiker standing on amountain<br />
top, gazing at afar-off mountain range.<br />
The caption also sounds exciting: “Look<br />
to the future and then look even<br />
further ahead.”<br />
While hikers can simply enjoy the<br />
view, looking ahead is vital for companies<br />
such as Industria Metalli as its customers<br />
come from the automotive sector<br />
–one of the most demanding industries.<br />
The company specializes in vehicle components,<br />
from supports and brackets<br />
through toall manner of housings. With<br />
ahigh level of vertical integration, each<br />
year the factory produces more than<br />
five million cast aluminium parts for 160<br />
customers around the world using 8,000<br />
tons of secondary aluminium. The medium-sized<br />
company from Lombardy<br />
generates 40 %ofits turnover from the<br />
automotive industry, around 30 %from<br />
commercial vehicle manufacturers and<br />
around another 30 %from agricultural<br />
technology companies.<br />
Learning from the automotive<br />
industry<br />
During the tour of the large factory<br />
premises, Fausto Becchetti, Managing<br />
10
Director and co-owner, explains to us<br />
that he learned alot from his previous<br />
work on the automotive sector<br />
management team at ABB and the process-oriented<br />
thinking that this required:<br />
The factory is divided into three<br />
production cells and follows similar<br />
principles. All of the production areas<br />
are connected digitally via amanufacturing<br />
execution system which controls<br />
the entire manufacturing process in real<br />
time. Every production step is carried<br />
out inaccordance with Toyota‘s Poka-<br />
Yoke principle, which detects and prevents<br />
faults. It is supported by aproduction-oriented<br />
and seamless quality<br />
assurance system, which is based on the<br />
strict requirements of IATF 16949 (<strong>International</strong><br />
Automotive Task Force).<br />
In the factory, the former ABB manager<br />
proudly points to one of the four<br />
gas-operated furnaces in the first production<br />
cell. „The aluminium immediately<br />
reaches the ideal processing temperature<br />
of 700 °C, at which point it<br />
becomes fluid“, explains Becchetti. „The<br />
next steps are degassing and transport“.<br />
In the meantime, the manufacturing<br />
execution system fully automatically<br />
organizes just-in-time transport<br />
and assigns adriver via the digital network.<br />
The forklift truck is located<br />
nearby and features atablet that<br />
informs the driver which furnace to collect<br />
the crucible from and which of the<br />
16 robot-assisted high-pressure die-casting<br />
presses in the second production<br />
cell is waiting for the liquid aluminium.<br />
Not far from Brescia, the second largest city in Lombardy, Industria Metalli has used the involuntary<br />
break in production caused by the COVID-19 pandemic to establish amechanical manufacturing<br />
facility.<br />
The first step is the<br />
melting process,<br />
which heats the<br />
secondary aluminium<br />
up to the ideal<br />
processing temperature<br />
of700 °C, ready<br />
for the die-casting<br />
presses.<br />
Outsourcing slows down<br />
the flow of materials<br />
Like most firms in the industry, the company<br />
has so far relied on outsourcing:<br />
After the die casting process, the components<br />
have anear-net shape and therefore<br />
have to be taken to anearby<br />
workshop to be finished. Outsourcing<br />
INDUSTRIA METALLI SRL, BASED IN BEDIZZOLE<br />
The foundry has around 100 employees and manufactures components<br />
weighing between 0.5 and 30.0 kg using the aluminium high-pressure die-casting<br />
process, all on aproduction area covering approximately the equivalent<br />
of eight football fields. The product range includes housings for steering systems,<br />
gears and oil filters, supports, brackets, lighting fixtures and much<br />
more. The second-generation family-owned company oversees the entire production<br />
process, from the melting of the secondary aluminium (around 8,000<br />
tons per year), degassing, high-pressure die-casting, heat treatment, shot-blasting,<br />
deburring, mechanical processing and assembly, all with ahigh level of<br />
vertical integration. The quality control process spans the entire company,<br />
from the incoming goods department with aquality control laboratory that<br />
analyses aluminium alloys using aspectrometer, to the X-ray machine for<br />
detecting blowholes and the expensive 3D coordinate measuring machine.<br />
This „cultura di qualità“ is the result of quality management certificates received<br />
for compliance with IATF 16949 (<strong>International</strong> Automotive Task Force)<br />
and ISO 9001. Due to its sustainable, low-emission production, the company<br />
has also received ISO 14001 certification. www.industriametalli.it<br />
leads to an increase inlogistical considerations<br />
and cost, while quality<br />
decreases. For example, small air<br />
pockets known as blowholes can occur<br />
in cast parts, but these are often not<br />
detected during X-rays and are only<br />
picked up during final machining. The<br />
late detection of these blowholes by<br />
external companies results in significant<br />
delays to the production process and<br />
increases the cost enormously: There is<br />
no immediate quality check after<br />
high-pressure die-casting on the<br />
machine tool. The result: The process<br />
chain becomes slower and the part has<br />
to be melted down and poured again.<br />
These bottlenecks were athorn in the<br />
former manager‘s side.<br />
The turning point came with the<br />
arrival of anew project manager, who<br />
had worked as amachining specialist in<br />
the automotive industry and who<br />
recommended purchasing afive-axis<br />
Heckert X40 and afour-axis Heckert<br />
H40 to assist the establishment of a<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 11
MACHINING<br />
Industri Metalli is using two Heckert<br />
machining centres to machine simple<br />
housings for oil filters. The company is<br />
already machining one in ten of its components<br />
in its new production cell.<br />
Short distances,<br />
lean structures and strict process orientation<br />
characterise the production process of the cast<br />
parts producer<br />
Industria Metalli has closed asignificant<br />
gap in its production<br />
process by establishing amechanical<br />
manufacturing facility with<br />
afive-axle Heckert X40 (front)<br />
and afour-axle Heckert H40.<br />
mechanical manufacturing facility. „We<br />
ordered the two mashining centres in<br />
autumn 2019“, explains Becchetti. „Despite<br />
the lockdown, we decided to go<br />
through with setting up amechanical<br />
manufacturing facility as it is an investment<br />
in the future —even though<br />
there was no market for our products in<br />
the spring“.<br />
Support from Chemnitz<br />
Thomas Kässner was involved in the process<br />
right from the start: The Heckert<br />
Sales Manager speaks fluent Italian and<br />
also helped with commissioning during<br />
the lockdown period, which took place<br />
almost without any delays thanks to<br />
direct contact with the Starrag plant in<br />
Chemnitz. The company decided in<br />
favour of the two machining centres<br />
because of their robust design, greater<br />
swarf removal, continuous precision and<br />
the technological performance buffer.<br />
All the frame assemblies are deliberately<br />
rigid, from the machine bed, column and<br />
table to the rotary swivelling unit. „I am<br />
particularly pleased about the high and<br />
consistent machine rigidity as we use<br />
diamond tools to finish the die-cast<br />
parts“, says the project manager, clearly<br />
satisfied with the machining centres.<br />
„Even at20,000 revolutions per minute,<br />
the diamond doesn‘t break when it hits<br />
ablowhole“.<br />
Diamond tools and<br />
wet machining<br />
Minimal-volume lubrication or dry<br />
machining isgenerally not anoption<br />
when machining aluminium components.<br />
The Italian company uses an<br />
electronically controlled coolant supply,<br />
which ensures the temperature<br />
stabilization ofthe workpiece and the<br />
tool, amongst much more. „Without<br />
effective wet machining, it would be<br />
impossible to achieve optimum swarf<br />
removal“, adds the project manager.<br />
The removal of the swarf is the linchpin<br />
ofaclean and rapid process, as<br />
aluminium swarf will otherwise easily<br />
12
One of the 16 high-pressure<br />
die-casting presses that work in<br />
close collaboration with robots.<br />
With ahigh level of vertical integration,<br />
more than five million<br />
cast aluminium parts are produced<br />
for 160 customers around<br />
the world using 8,000 tons of<br />
secondary aluminium.<br />
stick to the diamond and scratch or<br />
impair the cast component. The<br />
machining expert isparticularly pleased<br />
with the quality and the very fast<br />
processing time. „Although many<br />
components have hard-to-reach areas<br />
such as holes orpockets, the processing<br />
time has been reduced by several<br />
seconds per clamping surface compared<br />
tothat offered by our service provider,<br />
as we can run at significantly<br />
higher cutting speeds“, Becchetti<br />
reports. „At the same time, wecan<br />
also achieve top quality“. The two<br />
Heckert machines are able to achieve<br />
asurface roughness (Ra) of20µm,<br />
meaning that nofurther processing is<br />
required.<br />
The effort was worthwhile: Industria<br />
Metalli has begun processing simple<br />
housings for oil filters. The company is<br />
already machining one in ten of its components<br />
in its new production cell. „I am<br />
optimistic that we will soon be able to<br />
finish more products using the Heckert<br />
machining centres and that, thanks to<br />
the in-house mechanical manufacturing<br />
facility, wewill also receive orders for<br />
completely new components“, states<br />
Becchetti optimistically. „Automation is<br />
now the next step“. However, the benefits<br />
are obvious, even without this integration:<br />
Industria Metalli has considerably<br />
increased the proportion of value<br />
added for its components –and with<br />
better margins too.<br />
The boss is already looking to<br />
future, but what are his long-term strategic<br />
plans? „By establishing amechanical<br />
manufacturing facility and incorporating<br />
it into our production system,<br />
our opportunities to progress to tier<br />
one, tobecome asystem supplier, have<br />
increased significantly“, explains the<br />
Managing Director. “Our products are<br />
now significantly more competitive in<br />
comparison to those from many of our<br />
competitors, who do not have in-house<br />
machining. The two Heckert machining<br />
centres represent the first milestone in<br />
our journey“.<br />
www.industriametalli.it<br />
www.starrag.com<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 13
REACH TOP DECISION-MAKERS +<br />
FOUNDRY TRADE VISITORS<br />
WORLDWIDE<br />
ON SITE<br />
DIRECTLY<br />
SPOT ON
The leading English-language trade journal for the foundry industry with<br />
worldwide distribution:<br />
CASTING PLANT AND TECHNOLOGY INTERNATIONAL<br />
Issue #3|2<strong>02</strong>1<br />
Core Production<br />
Molding Material<br />
Die-Casting<br />
Foundry Plants<br />
Sand Preparation &<br />
Regeneration<br />
FENAF 2<strong>02</strong>1 in Sao Paulo (Brazil),<br />
14.-17.09.2<strong>02</strong>1<br />
61th IFC Portoroz in Portoroz (Slovenia),<br />
15.-17.09.2<strong>02</strong>1<br />
Formnext in Frankfurt (Germany),<br />
16.-19.11.2<strong>02</strong>1<br />
Advertising Deadline:<br />
August 13, 2<strong>02</strong>1<br />
Issue #4|2<strong>02</strong>1<br />
Die-Casting<br />
Die-Casting Process<br />
3-D-Printing &Digitalization<br />
Environment &Energy<br />
including<br />
YEARLY CALENDAR 2<strong>02</strong>2<br />
EUROGUSS in Nuremberg (Germany),<br />
18.-20.01.2<strong>02</strong>2<br />
Advertising Deadline:<br />
November 19, 2<strong>02</strong>1<br />
Media<br />
Information
CASTING TECHNOLOGY<br />
Photo: ANDREAS BEDNARECK<br />
Magnesium castings in aGerman die casting foundry. Does the new MAXImolding process offer new perspectives and qualitative advantages<br />
for the light metal alloys parts?<br />
Casting with semi-solid melt<br />
MAXImolding –Magnesium<br />
alloy injection molding inthe<br />
digital foundry ofthe future<br />
By inventing anew metal molding process, anew light metal injection molding machine<br />
and anew self-learning foundry, Ashley Stone’s vision is to make this industry fit for the<br />
“green” 21st century. Since 1999, Jacobsen Real-Time X-Ray Machinery of Canada has<br />
been working to eliminate defects in castings and to do so Ashley Stone combined the<br />
advantages of Thixomolding and hot and cold chamber high-pressure casting machines<br />
into the MAXImolding machine and process.<br />
By Ashley Stone, Toronto, Canada, and Edo Meyer, Siegsdorf, Germany<br />
The MAXImolding machine is invented<br />
from scratch and can produce<br />
light alloy components with less<br />
than 0.5 %ofporosity. The next step is<br />
to implement afully automated, self-learning<br />
light alloy forming cells in which<br />
the MAXImolding machine works in tandem<br />
with Automatic Image Recognition<br />
(ADR) X-ray inspection. The real time<br />
X-ray feedback via two independent<br />
loops allows the process to be optimized<br />
in real time cycle to cycle.<br />
Thixomolding<br />
Casting has been carried out according<br />
to the same principle for more than<br />
5,000 years. The metal is heated in a<br />
pot so that it becomes aliquid. It is<br />
then metered into the mold with a<br />
16
Figure 1: Illustration of the energy input and shot weight for a430-g motor support block as<br />
afunction of the process (Dr. Lohmüller, NMF GmbH).<br />
ladle, where it solidifies. To overcome<br />
many issues with molten material<br />
handling anew process was implemented.<br />
Introduced back in the 1990s, the<br />
Thixomolding process from Thixomat<br />
Inc. USA (an offshoot of Dow Chemical<br />
Company) licensed over 600 machine<br />
installations worldwide to date. The<br />
process was based on plastic injection<br />
molding machines intended to process<br />
plastic polymers. Since the 1990s,<br />
machine manufacturers such as HPM<br />
USA, JSW Japan, and Husky Injection<br />
Molding Systems, Canada, have been<br />
producing Thixomolding machines.<br />
While these Thixomolding machines<br />
have many process advantages, they<br />
proved to be very complex and relatively<br />
expensive to build and maintain.<br />
At the same time, new and demanding<br />
tasks and quality requirements regarding<br />
cast lightweight components have<br />
been requested from engineers and<br />
designers over the past decade.<br />
Anew, vertically oriented, environmentally<br />
friendly magnesium alloy<br />
injection molding machine for semi-solid<br />
melt is invented and is suitable to<br />
fulfill these tasks.<br />
The goal is to solve two problems:<br />
producing lightweight metal alloy parts<br />
with high integrity and reducing CO 2<br />
and Green House Gases (GHG) emission<br />
of hazardous gases to mitigate climate<br />
change effects in the diecasting industry.<br />
Thus, the current unsustainable<br />
approach of casting, inspecting, separating<br />
good from bad, and finally remelting<br />
bad parts must change and, therefore,<br />
significant effect on carbon<br />
footprint shall be made.<br />
In order to meet the requirements in<br />
the area of sustainability, the MAXImolding<br />
process and machine has been<br />
developed for magnesium, which is the<br />
most suitable metal of the future.<br />
Why magnesium?<br />
Due tothe continuous quest for weight<br />
reduction, magnesium alloys offer<br />
themselves as the most promising materials<br />
for technological developments.<br />
Magnesium is the eighth most abundant<br />
element in the earth‘s crust and<br />
the fourth most abundant element on<br />
earth. Magnesium is the lightest of all<br />
structural metals. Aunique blend of<br />
> low density,<br />
> high specific strength,<br />
> stiffness,<br />
> high electrical conductivity,<br />
> high heat dissipation<br />
Graphics: Dr. Lohmüller, NMF GmbH<br />
Figure 2: Thixomolding machine (NMF GmbH).<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 17
CASTING TECHNOLOGY<br />
asafe and rewarding activity promising<br />
minimal climate impact and great<br />
growth opportunity.<br />
Figure 3: MAXImolding operates in the semi-solid temperature range for the AZ91 alloy, which<br />
is between 480 and 580 °C. The microstructure ofthe alloy has spherical, non-dendritic features<br />
with 50 %solid content (Dr. Frank Czerwinski). This prevents the formation of defects.<br />
Casting -Molding -Forging<br />
Abasic distinction is made between two<br />
processes for melting light alloy metals:<br />
> Ingots are processed in amelting<br />
furnace and then filled into the casting<br />
chamber as aliquid melt: hot and cold<br />
chamber die-casting machines dominate<br />
this ecosystem.<br />
> Processing and heating of the material<br />
to asemi-solid mushy melt directly<br />
in the machine, (cold to cold processing)<br />
and without an external melting furnace:<br />
rheo (Rheomolding) and thixo<br />
(Thixomolding) processes dominate<br />
here.<br />
Die-casting is an industrial casting process<br />
for series or mass production of<br />
structural parts. Metallic materials or<br />
light metal alloys with alow melting<br />
point are generally used for this purpose.<br />
Among the casting processes for<br />
magnesium alloy parts, the die-casting<br />
processes currently dominate.<br />
Figure 4: Levitation preprocessor using argon to preheat and clean the chips. The use of argon<br />
reduces costs by up to 80 %.<br />
> and absorption of vibrations<br />
makes magnesium an excellent candidate<br />
to support human activities in<br />
almost all aspects.<br />
Combined with ease of processing<br />
and very easy recycling, magnesium<br />
alloys may be the material of the<br />
future. And even unrecycled, MgO<br />
becomes part of nature over time<br />
without emitting pollutants. Compared<br />
to plastics, which have seen tremendous<br />
growth over the last 50 years, magnesium<br />
has many qualities to offer. Magnesium<br />
does not harm humans or animals<br />
and is readily available. It can be<br />
recyclable with only 4%ofthe original<br />
energy of creation, thus contributing to<br />
the achievement of climate goals.<br />
If the materials are recycled at the<br />
end oftheir life cycle, a„credit“ can be<br />
issued for primary production avoided.<br />
The credits are particularly high for aluminum<br />
and magnesium in an assumed<br />
closed recycling loop. As aresult, net<br />
emissions change considerably, compared<br />
with other materials. Magnesium<br />
now has the lowest emissions over its<br />
entire life cycle. Polyamide and polypropylene<br />
have little credit potential, as<br />
plastics are assumed to be thermally<br />
recycled with relatively few credits.<br />
However, inorder to take advantage of<br />
the many benefits of magnesium, some<br />
fundamental things in the foundry<br />
industry need to be reconsidered. For a<br />
long time, magnesium was regarded by<br />
Foundrymen as being difficult to<br />
handle, and the appropriate technology<br />
for better utilization of magnesium was<br />
lacking. Today, processing magnesium is<br />
Cold and hot chamber die-casting<br />
Cold chamber die-casting is frequently<br />
used for components with large casting<br />
weights. Machines with aclamping<br />
force of between 2000 and 4000 tonns<br />
are usually used for the production of<br />
gearboxes or crankcases. The magnesium<br />
is strongly superheated (> 680 °C)<br />
in large crucibles (> 500 kg magnesium)<br />
and supplied with alarge amount of<br />
energy to melt and maintain temperature.<br />
When the melt is injected into the<br />
cold casting chamber, injection rate<br />
must be very fast due to high thermal<br />
conductivity of alloy. The turbulence of<br />
the melt creates gas inclusions. The<br />
inclusions are detrimental for structural<br />
integrity of the part. Many discarded<br />
parts are due to unacceptable inclusions.<br />
Constant temperature variations<br />
and long heat history casing formation<br />
and growth of the dendritic structures<br />
which can lead to premature casting<br />
defects. The temperature loss between<br />
melt in the crucible furnace and the<br />
metal in the casting chamber can be up<br />
to 150°C. For highly thermally conductive<br />
alloy alot can happen in this temperature<br />
range.<br />
In hot-chamber die-casting, the casting<br />
chamber is located directly in the<br />
crucible and isthus more or less temperature-controlled.<br />
Pre-solidification<br />
occurs to amuch lesser extent in the<br />
area of the nozzle and the gooseneck.<br />
18
As aresult, the melt does not have to<br />
be overheated as much (> 630 °C) and it<br />
is possible to manufacture components<br />
with smaller wall thicknesses. However,<br />
due tothe temperature to which the<br />
casting chamber is permanently subjected,<br />
the maximum possible casting pressure<br />
is limited and is only at amaximum<br />
of 350 bar, which severely restricts the<br />
component size. In die-casting, the<br />
gating system and the overflows must<br />
be adapted to the respective component<br />
geometry. This leads to relatively<br />
high material consumption. For<br />
example, in cold-chamber die-casting,<br />
the component‘s share of the shot<br />
weight is often in the range of 40 to<br />
60 %for compact, thick-walled components.<br />
In the case of flat, thin-walled<br />
components, as little as 30 % is<br />
sometimes achieved. Figure 1shows a<br />
comparison of the casting processes in<br />
terms of shot weight and energy<br />
consumption.<br />
Both cold and hot chamber processes<br />
have high-energy losses due to the<br />
necessary overheating of the melt and<br />
require environmentally harmful reactive<br />
gases (mainly R134a: 1300 times the<br />
global warming potential of CO 2<br />
or SO 2<br />
:<br />
toxic, corrosive) to prevent the melt surface<br />
from oxidizing.<br />
Thixomolding<br />
Another manufacturing technology for<br />
magnesium castings is Thixomolding.<br />
Semi-solid metal molding is amolding<br />
process inwhich amold isfilled with<br />
partially molten metal in which solid<br />
particles are homogeneously dispersed<br />
in the melt. The thixotropic properties<br />
(e.g. gel liquefies when stirred, thickens<br />
when at rest) of metal alloys in the<br />
semi-solid state and semi-solid casting<br />
were invented by Prof. Merton C. Flemings<br />
and his colleagues in the 1970s at<br />
MIT (Massachusetts Institute of Technology)<br />
in the USA. The machine technology<br />
is comparable to plastics injection<br />
molding.<br />
The process is characterized by good<br />
control of the melt temperature, alow<br />
melt volume, short residence times and<br />
intensive shearing of the melt. The melt<br />
can be processed in the semi-solid<br />
range. At the Bavarian State Research<br />
Institute Neue Materialien Fürth GmbH,<br />
Dr. Andreas Lohmüller and his team<br />
were able to demonstrate advantages<br />
over conventional die casting processes,<br />
such as better mechanical properties of<br />
the castings with lower porosity. Sofar,<br />
however, the maximum possible solid<br />
phase content has been limited to<br />
Figure 5: Processing temperature ofthe MAXImolding process compared to common series<br />
processes for the alloy AZ91 (Dr. Lohmüller, NMF GmbH).<br />
about 30 to 40 %. The shot weights are<br />
limited (maximum 3to4kg), so that<br />
large thick-walled components could<br />
not be produced so far. Simple upscaling<br />
does not seem to be possible at<br />
present. For material savings, it can be<br />
assumed that optimized gating systems<br />
similar to today‘s hot sprue systems,<br />
Thixomolding with direct injection as<br />
well as compact components are possible.<br />
The low temperature favors hot<br />
runner systems.<br />
Currently, there are only afew<br />
manufacturers of Thixomolding injection<br />
molding machines and the machines<br />
are very complex. They require<br />
intensive and very expensive servicing,<br />
as many complex and moving parts<br />
come into direct contact with molten<br />
magnesium (Figure 2).<br />
Dr. Frank Czerwinski, author of the<br />
book „Magnesium Injection Molding“<br />
published by Springer Verlag, wrote<br />
that the production of non-dendritic<br />
structures in the melt is also possible<br />
under precise heat addition and precise<br />
temperature control. This is done<br />
without shearing the melt, which is<br />
done in an extruder of aThixomolding<br />
machine. This extruder is also the most<br />
expensive machine part, as it is made<br />
of aspecial steel alloy suitable for operation<br />
at high temperature and pressure.<br />
However, the screw with the<br />
non-return valve installed at the front<br />
is notoriously prone to leakage and<br />
inconsistent operation. Maintenance of<br />
these units, which is required after<br />
only 500,000 cycles, requires the use of<br />
special removal tools and acleaning<br />
process that uses an environmentally<br />
harmful hydrochloric or phosphoric<br />
acid. This process, while an advance in<br />
the production of high quality parts, is<br />
definitely complex and costly to maintain.<br />
Disadvantages of the extruder in a<br />
Thixomolding machine:<br />
> The technology was adopted from<br />
plastic injection molding and thus is not<br />
robust enough for metal alloy injection<br />
molding at high operating temperatures,<br />
> requires exotic materials to withstand<br />
magnesium (bushings of Stellite<br />
12 or special steel No. 1.2888),<br />
> the cylinder wall thickness cannot be<br />
increased arbitrarily because external<br />
heat from heating zones does not penetrate<br />
into the interior,<br />
> has acomplex heating and conveying<br />
distance of over 2.5 m,<br />
> uses ascrew that has not been heated<br />
to advance material along the melt<br />
path,<br />
> inorder to stop, the screw has to be<br />
removed for acid cleaning (two additional<br />
installations necessary to maintain<br />
the main machine),<br />
> replacing the screw is very expensive.<br />
More than 100,000 US-Dollar can<br />
be expected,<br />
> maintenance intensive,<br />
> operation requires alot of training<br />
and experience.<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 19
CASTING TECHNOLOGY<br />
The idea<br />
Let‘s start with the feeding material<br />
and preparation. For the MAXImolding<br />
molding process, metal chips are fed to<br />
alevitation pre-processor for cleaning,<br />
where they are heated up to 200 °C<br />
under argon with precise temperature<br />
control. Oxidation is avoided by flooding<br />
with argon. The chips are then<br />
continuously metered into the vertical<br />
processing cylinders and slowly heated<br />
from top to bottom. The recirculated<br />
heat from the mold is used to preheat<br />
the starting material (chips). The preheated<br />
Mg chips coming from the pre-processor<br />
are now further heated in the<br />
thermal reactor in the form of arevolver<br />
cylinder. This is done by several heating<br />
zones placed over the outer wall of<br />
the cylinder. The semi-solid slurry can<br />
then be collected in achamber and<br />
metered under afast acting piston. The<br />
viscous slurry is then precisely injected<br />
into the mold via aco-axially located<br />
injection piston at high pressure (1,000<br />
bar) and high speed (up to 12 m/s). The<br />
whole process requires avertical path<br />
of only 1.5 m, thus reducing the size of<br />
the entire 50 mlong casting line. This in<br />
turn makes the process more controllable<br />
(Figure 4and Figure 6) and totally<br />
enclosed.<br />
Figure 6: MAXImolding with chip preparation processor, main reactor and mold with heat<br />
recovery.<br />
Can this process be improved even<br />
further? To find out, one has to look at<br />
Thixomolding shortcomings.<br />
MAXImolding<br />
The question ishow to build anew, simple<br />
and robust hybrid machine that produces<br />
virtually defect-free, high-integrity<br />
parts with minimum energy and<br />
materials, very quickly and without<br />
polluting gas emissions.<br />
The first apparent improvement is<br />
the vertical orientation of the hybrid<br />
machine. Gravity makes it easier for<br />
chips and semi-solid melt to flow from<br />
top to bottom without changing direction.<br />
By designing amain reactor with a<br />
large thermal mass and high-precision<br />
temperature control in the form of a<br />
revolver cylinder, the complex and<br />
high-maintenance parts such as the barrel<br />
and screw in aThixomolding<br />
machine are eliminated. On closer<br />
inspection, the changes are even more<br />
far-reaching (Figure 3).<br />
The advantages of MAXImolding<br />
The first obvious advantage of all<br />
semi-solid processes is the lower energy<br />
consumption. When using aMAXImolding<br />
machine, the gate temperature is<br />
540 °C, the shot weight is 500 gfor a<br />
net part of 430 g, and the energy<br />
consumption is 340 kJ. These are conservative<br />
assumptions, since energy<br />
consumption will drop again if ahot<br />
runner and direct injection are used. In<br />
comparison, the casting cold chamber<br />
temperature is 680 °C. Asimilar gating<br />
system was assumed for hot-chamber<br />
die casting as for Thixomolding<br />
(without hot sprue) (~ 30 %). For MAXImolding,<br />
ahot sprue system (~16 %)<br />
can beassumed due to the low casting<br />
temperature (Figures 1, 3 and 5).<br />
MAXImolding does not require ascrew<br />
or its rotation. It is not necessary to<br />
shear the chips to produce asemi-solid<br />
melt (slurry) containing spherical solid<br />
particles in the melt. The generation of<br />
athixotropic slurry can be accomplished<br />
in athermal mass reactor under the sole<br />
influence of precisely controlled heat.<br />
Eliminating the screw for shearing is a<br />
major simplification of the process<br />
(Figure 6).<br />
The process is „solid-to-solid“ molding<br />
because it starts with solid chips,<br />
then asemi-solid slurry is produced, and<br />
it is finally completed with solid nearnet-shape<br />
parts from the mold. The process<br />
is completely enclosed. Very little<br />
argon is used to prevent oxidation of<br />
chips. The revolver cylinder provides<br />
plenty of surface area in the material<br />
contact with cylinders to heat the chips<br />
quickly. Precise temperature control of<br />
the outside surface of the processing<br />
cylinder allows the inside of the co-axially<br />
placed cylinders, including the injection<br />
piston (in the center), to be heated<br />
at the same time with temperature precision<br />
of a+/- 1°C. Precise temperature<br />
control of the piston and the cylinder<br />
allows for accurate piston and cylinder<br />
20
Table 1: MAXImolding has many advantages over die-casting and Thixomolding.<br />
Item Die-Casting Thixomolding MAXImolding<br />
Hot-Chamber Cold -chamber<br />
Molding temp.(°C) 630~650 590~610 590~610 480~580<br />
Injection speed (m/s) 1~4 1~4 1~4 1~12<br />
Injection pressure(kgf/cm²) 250~350 500~1200 500~1200 500~1200<br />
Material<br />
Ingot directinmachine<br />
at 650°C<br />
Ingot in melting pot at<br />
ca. 700°C<br />
Chip directinmachine Pre-processor takes<br />
feedstock chips and<br />
de-contaminate,<br />
degrease,dry andpreheat<br />
them uniformly to<br />
max. 200°C and doses<br />
them in machine<br />
Projectareaatsame clamping<br />
force<br />
Large Medium Medium Larger because of<br />
directinjection<br />
Max. machine size 900t 1000t 1000t 5.000t +, limited by<br />
press tonnage only;<br />
multi-injectorusage<br />
Blowhole Small Few Few Few<br />
Surfacedefect Small Few Few Few+<br />
Shrinkage crack Small Few Few Few+<br />
Fluidity Good Excellent Excellent Excellent++<br />
Surfaceroughness Good Excellent Excellent Excellent<br />
Flash Few Small Small Small+<br />
Shrinkage Small Few Few Few+<br />
Mold shrinkage Dimension accuracy<br />
5~5.5/1000<br />
Good<br />
3.8~4.5/1000 Excellent 3.8~4.5/1000 Excellent 3.8~4.5/1000 Excellent<br />
Warp Small Few Few Few<br />
Mechanical properties Good Excellent Excellent Excellent++<br />
Shot cycle 0.8 0.9 1(Standard) 0.8<br />
Material cost 0.85 0.9 1(Standard) 1<br />
Material shot weightfor same net 1.1 1.6 1(Standard) 0.8<br />
partweight<br />
Die‘slife 0.9 0.8 1(Standard) 1.2<br />
Safe operation Good Poor Excellent Excellent+<br />
Protection gas SF6, SO2 SF6,SO2 Ar Ar<br />
Dross/Sludge Much Much Nothing Nothing<br />
tolerance being maintained over processing<br />
time. This is all possible due to<br />
ingenious symmetrical and co-axial<br />
nature of the processing cylinders.<br />
The maintenance of the MAXImolding<br />
system is simple. This is because no<br />
material can settle on the smooth inner<br />
cylinder sacrificial surface, and the<br />
semi-solid slurry is completely contained<br />
within the MAXImolding machine. A<br />
major advantage over other die casting<br />
processes isachieved by eliminating the<br />
need for aseparate furnace and pot to<br />
generate and hold the melt. Everything<br />
is done in the same machine within a<br />
fast cycle of 14 to 60 seconds. Mold cooling<br />
is accomplished by an enclosed<br />
water mist system (80 %air, 20%<br />
water) circulating at very high cooling<br />
rates directly under the mold surface.<br />
The water air generation in enclosed<br />
cooling channels absorbs alarge<br />
amount of the heat. Evaporative heat<br />
absorbed from the solidifying part is in<br />
turn used to preheat the incoming magnesium<br />
chips. This leads to further considerable<br />
process energy savings.<br />
The development of the Maximolding<br />
machine opens up completely new<br />
possibilities for the production of lightweight<br />
components without dangerous<br />
gas emissions. First from magnesium<br />
and later also from aluminum. As a<br />
result, climate targets are met and users<br />
of the machine can trade CO 2<br />
certificates.<br />
No other machine can produce<br />
large, thin-walled parts with athickness<br />
of 1mmfrom standard or special alloys.<br />
The same applies to large thick-walled<br />
parts of up to 10 or even 20 kg in very<br />
good quality. Table 1 summarizes the<br />
main differences between the processes.<br />
The next step: smart factory<br />
Optimizing the semi-solid molding/casting<br />
process is only one step of the system<br />
innovation. The goal is aholistic<br />
solution. The smart factory is at the<br />
heart of Industry 4.0. The term smart<br />
factory essentially refers to networked<br />
adaptive production systems connected<br />
to value-adding networks. Operators of<br />
the machine benefit primarily from the<br />
rapid dissemination and use of data. In<br />
this context, both real-time capable networks<br />
and scalability are important fac-<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 21
CASTING TECHNOLOGY<br />
Figure 7: Schematic of light<br />
alloy wheels self-learning<br />
smart factory incorporating<br />
MAXImolding machine with<br />
feed back x-ray control loop<br />
incl. ADR software and<br />
knowledge system for data<br />
analyzing and prediction of<br />
process parameters<br />
tors to ensure the exchange of information<br />
between the participating devices.<br />
Any user can operate aMAXImolding<br />
process anywhere in the world and realize<br />
best parts possible. The objective is<br />
to apply these aspects to the casting cell<br />
and thus create safe and autonomous<br />
production. Figure 7shows the approach<br />
ofanintelligent production chain<br />
for discrete production. Foundries are<br />
being transformed into part production<br />
cells with unique supply chain and process<br />
optimization network.<br />
The entire production process for a<br />
light alloy wheel could look something<br />
like this: the operator selects the part to<br />
be molded from a3-D database and<br />
supplies power to the MAXImolding<br />
injection molding machine. Achecklist<br />
is followed with regard to material supply<br />
and safety checks, and then the<br />
machine isstarted. The MAXImolding<br />
machine suggests the startup process<br />
parameters and sets them. The machine<br />
operator confirms proposed parameters<br />
or set owns. Casting of the first wheel<br />
begins. After completion, the wheel is<br />
immediately inspected on the X-ray<br />
inspection system with Automatic<br />
Defect Recognition (ADR). This determines<br />
the quality of the wheel and generates<br />
adigital identifier that can be<br />
used to identify the part. If the part<br />
produced is found to be good, the associated<br />
process parameters are stored in<br />
adatabase and marked as „good.“<br />
Parameters of the defective products<br />
are also stored so that faster iterative<br />
adjustments to process parameters can<br />
be made from them. For example,<br />
inspection might show that the wheel<br />
was not fully formed, indicating insufficient<br />
starting material and commonly<br />
referred to as ashort shot. The system<br />
recognizes that alonger injection time<br />
is needed and iteratively instructs the<br />
parameter generator to delay closing<br />
the nozzle. The next machine cycle is<br />
22
executed, serialized and passed to the<br />
inspection system.<br />
By continuously cycling data from an<br />
inspection system and accelerating the<br />
convergence of good and bad data sets,<br />
the cast wheel can be progressively<br />
improved over the digital 3-D model.<br />
Production with integrated X-ray feedback<br />
control loop and machine learning<br />
algorithm enables fully automated production<br />
of wheels with high integrity<br />
and minimal scrap.<br />
The global cloud<br />
As many of today‘s products are developing<br />
at an ever-faster pace, production<br />
must be continuously adapted accordingly.<br />
Topermanently shorten innovations<br />
and product cycles, companies<br />
must be able to act flexibly. One promising<br />
step along this path could be to<br />
identify the respective network production<br />
capacities across companies globally.<br />
By networking production facilities<br />
across companies, it is possible to respond<br />
flexibly to fluctuating market conditions<br />
or order situations. Such smart<br />
factories integrated into an ecosystem<br />
also ensure particularly efficient utilization,<br />
which can reduce costs and promote<br />
more resource-efficient production.<br />
Company Ashares its own spare<br />
capacity with Company B, which is operating<br />
at full capacity. IfCompany B<br />
takes advantage of the offer, itwill not<br />
only temporarily expand its own production<br />
facilities, but also allow Company<br />
Atobetter utilize its capacity. This<br />
allows both companies tokeep order<br />
fluctuations to aminimum. In addition,<br />
maintenance procedures based on the<br />
evaluation of process and machine data<br />
can also be carried out proactively.<br />
The MAXImolding factory ensures<br />
fast piece production of good parts and<br />
provides stable and automatic process<br />
control. The factory consists only of proprietary<br />
machines such as robotics and<br />
vision systems based on unified factory<br />
software from COPA-DATA. COPA-DATA<br />
is an independent software manufacturer<br />
that combines in-depth experience<br />
in automation with the new possibilities<br />
of digital transformation. Via acloud,<br />
process data is collected for the same or<br />
similar parts worldwide. And anyone<br />
can use it to improve their magnesium<br />
molding processes.<br />
Conclusion<br />
The product features, and freedom<br />
from deficiencies are two feature that<br />
make money. MAXImolding and its<br />
integration into aholistic solution is a<br />
pioneering process in the field of production<br />
defect prevention. The ambition<br />
is to resolve core problem of the<br />
customer. The production process is to<br />
be optimized and the generation of<br />
errors is to be avoided.<br />
The focus is not on the output itself,<br />
but on the process that achieves the<br />
output. The production of almost<br />
defect-free parts is made possible by<br />
combining amolding/casting machine<br />
with anX-ray system.<br />
Knowledge from the field of X-ray<br />
technology combined with high-pressure<br />
die-casting and metal alloy injection<br />
molding will result in anew generation<br />
of metal alloy injection molding<br />
machines. It is possible to mass-produce<br />
moldings/castings that are virtually free<br />
of defects, and the path from the<br />
virtual 3-D part to the finished casting<br />
with matching alloy is short. There is no<br />
comparable holistic system on the market<br />
yet. The magnesium-molding factory<br />
is safe, energy efficient and<br />
environmentally friendly with no emission<br />
of gases outside the factory parameters.<br />
All injection molding machines<br />
and X-ray inspection machines, as well<br />
as proprietary linear robotics and vision<br />
systems integrated into this semi-solid<br />
molding process, ensure the fast production<br />
of good parts and provide stable<br />
closed-loop automatic process control.<br />
For further progress, the mindset<br />
should be changed. Not only machines<br />
and products can be exported, but holistic<br />
and intelligent factories integrated<br />
into aglobal ecosystem. An ecosystem<br />
that continuously improves itself, thereby<br />
reducing surplus and emissions and<br />
leading to more profit for all stakeholders<br />
-amodern digital business model<br />
that is attractive and pays off for all stakeholders.<br />
www.maxi-molding.com<br />
Ashley Stone of Toronto is an inventor<br />
working inthe field of industrial X-ray<br />
inspection and mechanical engineering<br />
for over 40 years. Edo Meyer is an<br />
industrial psychologist doing doctoral<br />
research at the University of Vienna. He<br />
has been cooperating with Jacobsen<br />
X-Ray inCanada for more than 15 years<br />
to create environmentally friendly casting<br />
factories and is Managing Director<br />
of MAXImolding! Technology GmbH in<br />
Siegsdorf, Germany.<br />
Accurate.<br />
Pyrometers. IR Cameras. Accessories. Software.<br />
We measure temperature non-contact from<br />
–50 °C to +3000°C. Visit: www.optris.gobal<br />
Extremely high targeting accuracy<br />
is guaranteed with our CTlaser with<br />
its unique dual-laser sighting.<br />
from<br />
£ 440<br />
when temperature matters
SIMULATION<br />
Virtual Design of Experiments<br />
Fonderie Mario Mazzucconi S.p.A. in<br />
Ponte San Pietro.<br />
Optimizing the service life<br />
of die casting tools<br />
Tool life is one of the main cost factors in high pressure die casting. The Italian foundry<br />
Mazzucconi used the capabilities of virtual Design of Experiments inMagmasoft to substantially<br />
increase the die life for asteering housing.<br />
By Andreas Heitmann, Aachen, Germany, and Mechele Zanni and Daniele Bianchi, Ponte San Pietro, Italy<br />
Photo: mazzucchoni<br />
Unfortunately, the die of acast<br />
part that had been produced for<br />
along time fell short of the<br />
expected tool life. Changes to the casting<br />
geometry were not an option due<br />
to the existing design freeze. Therefore,<br />
the aim of the project was to identify<br />
the main influencing factors on tool life<br />
in the process and adjust the casting<br />
process accordingly. One of the major<br />
influencing factors on tool life are thermo-mechanical<br />
stresses in the die surface<br />
and the associated die erosion.<br />
These stresses are caused by temperature<br />
changes during the casting cycle.<br />
Mazzucconi decided to investigate the<br />
following parameters:<br />
> Distance between temperature control<br />
channels and die surface<br />
> Diameters of the temperature control<br />
channels<br />
> Temperature of the temperature<br />
control medium<br />
> Casting temperature<br />
> Spraying process<br />
For each of the five parameters, aseparate<br />
systematic set-up using the in-build<br />
Design of Experiment (DoE) was done.<br />
The foundry used Magmasoft and Magmadielife<br />
to estimate the die life for<br />
their process. To minimize the simulation<br />
effort, asubstitute geometry was<br />
used that had characteristics similar to<br />
the original casting (Figure 1).<br />
First, the status quo of the existing<br />
process was simulated and then compared<br />
to the real damage in the die.<br />
Figure 2shows the tool cracks already<br />
visible on the casting and the result of<br />
the lifetime estimation.<br />
For the DoE used to analyze the distance<br />
between temperature control<br />
channel and die surface, in addition to<br />
the initial situation, three variations<br />
with the distances 3d, 5d and 7d were<br />
defined. In addition, avariant with<br />
deactivated die temperature control<br />
was simulated.<br />
The results reveal that the tool life<br />
decreases with increasing distance between<br />
cooling channel and die surface<br />
24
a<br />
b<br />
Figure 1: Real casting and substitute model for the<br />
designs of experiments.<br />
(Figure 3). For the investigated variants,<br />
Figure 4shows the temperature history<br />
at one point of the die surface. With<br />
increasing distance between cooling<br />
channel and die surface, the temperature<br />
of the surface increases at the<br />
beginning of the spraying process. Due<br />
to the higher die temperature, the<br />
spraying process generates ahigher<br />
temperature gradient, which results in<br />
higher residual tensile stresses in the die<br />
surface.<br />
However, the compressive stress at<br />
the beginning of solidification hardly<br />
changes. In contrast, the stress amplitude<br />
between the tensile stresses<br />
(during spraying) and the compressive<br />
stresses (during filling/solidification)<br />
increases with increasing distance between<br />
cooling line and die surface. This<br />
results in an increased load and a<br />
decrease of the tool life.<br />
For the other process variables, corresponding<br />
virtual Designs of Experiments<br />
were conducted, too. These led<br />
to the following fundamental insights:<br />
In the area analyzed, the diameter<br />
of the cooling channels has no influence<br />
on the tool life. Explanation: The<br />
average die temperature does not<br />
change, resulting in the maximum stresses<br />
both during spraying and during filling/solidification<br />
not changing either.<br />
The temperature of the cooling<br />
medium has aconsiderable influence on<br />
the tool life. This effect can be explained<br />
by the fact that the die is on<br />
average colder with colder cooling<br />
a<br />
b<br />
Figure 2: Visible tool cracks on the casting (left) compared to the simulation result ‚<br />
Die Lifetime‘ (right).<br />
Figure 3: Influence of the distance between cooling channel and die surface on the die life.<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 25
SIMULATION<br />
Figure 4: Temperature history at point 6for different cooling channel distances to the<br />
die surface.<br />
agents. This, in turn, leads to areduced<br />
thermal shock during spraying and,<br />
thus, to lower tensile stresses. The temperature<br />
increase of the die surface<br />
during filling/solidification, however,<br />
remains approximately the same, which<br />
means that the level of compressive<br />
stresses is also almost identical. Overall,<br />
the stress range decreases with lower<br />
cooling agent temperature (Figure 5).<br />
Reducing the pouring temperature<br />
minimizes both the tensile stresses<br />
during spraying and the compressive<br />
stresses during filling/solidification, thus<br />
increasing the tool life. This can be explained<br />
as follows: Reducing the casting<br />
temperature leads to areduction of the<br />
average die temperature. This results in<br />
asmaller thermal shock during spraying.<br />
Likewise, the temperature gradient<br />
during filling/solidification is also<br />
reduced due to the colder melt.<br />
The variation of spraying, in turn has<br />
shown that intermittent spraying of<br />
smaller amounts causes smaller tensile<br />
stresses in the die surface than one<br />
single, intense spray stroke.<br />
Figure 5: Stress curves for point 6when varying the cooling channel temperature.<br />
a<br />
b<br />
The different investigations show that<br />
the layout of the spraying process has<br />
the greatest influence on the die<br />
lifetime. The aim must therefore be to<br />
keep the thermal shock during spraying<br />
as small as possible. On this basis, new<br />
process parameters were defined for<br />
the series part:<br />
> Wherever possible, cooling channels<br />
are placed closer to the surface to<br />
thus minimize the surface temperature<br />
before spraying.<br />
> The cooling channel temperature is<br />
reduced.<br />
> The pouring temperature is reduced<br />
as far aspossible.<br />
> The spraying process is changed to<br />
intermittent spraying (with several<br />
smaller spray strokes).<br />
> Atthe same time, the process was<br />
switched to water-free spraying.<br />
Figure 6: Lifetime estimation for original and optimized production parameters (left and right<br />
respectively).<br />
FONDERIE MAZZUCONI<br />
The Italian foundry produces aluminum alloy components, casted in gravity,<br />
low-pressure or high-pressure die casting, as well as fully machined and assembled<br />
components. For over more than acentury, Mazzucconi has been active in the<br />
field of metal castings and machining. The foundry is located in Ponte San Pietro<br />
(Bergamo) and has seven production facilities located in Italy plus alocal office in<br />
Munich, Germany.<br />
In the simulation with Magmasoft, the<br />
verification of the new process conditions<br />
revealed aconsiderably higher die<br />
lifetime (Figure 6). This was confirmed<br />
in the series production with new tools.<br />
www.magmasoft.de<br />
www.mazzucconi.com<br />
Andreas Heitmann, Application Technology,<br />
Magma Gießereitechnologie<br />
GmbH, Aachen, Germany, Mechele<br />
Zanni und Daniele Bianchi, Process<br />
Simulation, Fonderie Mario Mazzucconi<br />
S.p.A., Ponte San Pietro, Italy.<br />
26
AUTOMATION<br />
PHOTOS AND GRAPHICS: AUGUST MÖSSNER<br />
Parts handling when cutting casting systems with aband saw machine.<br />
Pre-Machining<br />
From casting tocleaning<br />
in 60 seconds<br />
A60second cycle is made possible byacompact production line from August Mössner<br />
GmbH +CoKG, which isused to turn raw castings into pre-machined and cleaned workpieces.<br />
Arobot processing cell makes it possible.<br />
by Dietmar Schmid and Christian Kunz, Eschach<br />
Chassis are complex multi-part constructions.<br />
Fully automated casting<br />
finishing is achallenge in<br />
terms of cycle time, flexibility and<br />
robustness. The most important machines<br />
are ten heavy-duty robots, four<br />
decoring machines, four band saw<br />
machines and eight tool spindles.<br />
Coming from the casting plant, the<br />
cast blanks are fed into the machine via<br />
rotary tables. Loading can be carried<br />
out manually or with arobot. The finished<br />
and partially processed workpieces<br />
are discharged by two belt conveyors.<br />
The processing cell is divided into cell<br />
areas for<br />
> Decoring,<br />
> Separation of the steel filters and<br />
casting systems<br />
> Removal of dividing burrs and<br />
machining of internal feeders<br />
(Figure 1).<br />
The subdivision into cell areas with<br />
transfer points and turntables enables<br />
specific supply of operating materials,<br />
such as lubricants and cutting materials,<br />
sorted disposal and separation of recycling<br />
material, sand, chips and process-specific<br />
exhaust air.<br />
In addition, the subdivision into partial<br />
cells and the complete enclosure<br />
with sound insulation walls ensures low<br />
noise pollution. In the decoring area,<br />
the additional enclosure reduces sand<br />
emission into the environment.<br />
The ten robots are used on the one<br />
hand to transport parts and on the<br />
other hand for workpiece processing in<br />
the machining stations. The system is<br />
controlled by several, locally distributed<br />
control systems. In chaotic throughput,<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 27
AUTOMATION<br />
Figure 1: Layout of atwin processing cell.<br />
four types of „nodes“ and four types of<br />
„cross members“ can beprocessed.<br />
For part identification, DataMatrix<br />
codes on the castings are recorded by<br />
camera systems. Depending on this, the<br />
part and task-specific machining and<br />
handling processes are activated.<br />
The transfer of parts from one cell<br />
to the next takes place at transfer<br />
rotary tables: The robot in one cell<br />
deposits the casting on one half of the<br />
turntable. After the turntable has<br />
turned 180 degrees, the robot of the<br />
next cell takes over the workpiece. For<br />
machining on all sides, the workpieces<br />
are oriented by the 5th and 6th robot<br />
axis. Furthermore, the parts can be gripped<br />
byrotating workpiece supports.<br />
With the help of cameras, the production<br />
progress is monitored, and<br />
errors are detected. Alarge number of<br />
individual sensors record –among other<br />
things –the presence and positions of<br />
the parts in the grippers and holding<br />
fixtures. Process temperatures on workpieces<br />
and tools as well as clamping<br />
forces and vibrations are controlled.<br />
The aluminium chassis parts (Figure 2)<br />
with afinal weight of approx. 17 kg<br />
come from the casting machine into the<br />
plant with atemperature of 80 °C and a<br />
weight of 40 kg. They are decored in<br />
the cell and release about 10 kg sand<br />
per part. The casting system to be separated<br />
with feeders and steel filters<br />
weighs about 12 kg per part. Sand, casting<br />
system parts, steel filters and chips<br />
are automatically conveyed out of the<br />
cell (Figure 3). Underfloor vibratory conveyors<br />
are used for the sands and chips,<br />
while chutes and belt conveyors are<br />
used for the casting systems.<br />
Decoring<br />
The parts, which come from the casting<br />
process, initially still have solid cores.<br />
During decoring, the sand cores are<br />
emptied from the cavities of the castings.<br />
Pneumatic hammers (Figure 4)<br />
break the sand cores by impact energy.<br />
The broken sand cores are then crushed<br />
Figure 2: Example Crossmember.<br />
by high-frequency vibration. This is<br />
done by crushing and breaking up the<br />
sand lumps on the casting walls. The<br />
removal of the molding sand is achieved<br />
by vibrating and rotating the castings.<br />
The rotation unit brings the casting<br />
into an ideal position for emptying.<br />
The optional blowing out of the casting<br />
with compressed air keeps any sand<br />
residues low. All this is achieved by the<br />
Mössner 3-in-1 decoring unit. It combines<br />
the process steps of hammering,<br />
vibrating and turning in one machine.<br />
Sand therefore only accumulates at one<br />
point. Sand carry-over is avoided. All<br />
three process steps require only one<br />
loading and unloading process.<br />
The design ofthe 3in1decoring<br />
unit is deliberately without elaborate<br />
gears for turning and vibrating. This<br />
solution makes the machine extremely<br />
robust and reduces the susceptibility to<br />
errors. Gearbox solutions are expensive<br />
when it comes to the procurement of<br />
spare parts and, in the event of failure,<br />
lead to longer plant downtimes.<br />
Parts handling is carried out with<br />
heavy-duty robots and special gripping<br />
systems. The decoring machines are<br />
mounted on air dampers to reduce<br />
noise and vibration. In addition, various<br />
noise and vibration damping measures<br />
are taken. During the decoring process,<br />
28
Figure 3: Separate discharge of core sand, chips and casting system parts .<br />
Figure 4: View into the decoring machine.<br />
the soundproof cabin is closed with a<br />
soundproof dust protection door. After<br />
decoring, the castings are transferred to<br />
the processing areas by arobot.<br />
Processing<br />
All machining processes are carried out<br />
by handling the workpieces or tools<br />
with heavy-duty robots. The work processes<br />
include:<br />
> Separating the steel filters,<br />
> Sawing off the casting systems,<br />
> Machining of internal feeders,<br />
> Deburring.<br />
Figure 5: General layout<br />
finishing line for crossmember and nodes.<br />
The steel filters are separated with circular<br />
saw cuts. The casting systems,<br />
including the feeders, are separated<br />
with band saw machines. Steel filters<br />
and pouring systems fall onto conveyor<br />
belts for disposal via chutes. Vibratory<br />
conveyors transport the chips under the<br />
floor to the outside. For cleaning, the<br />
castings are rotated and turned over on<br />
air nozzles by robots in cleaning chambers.<br />
Removal of dividing burrs is performed<br />
bythe tool-guided processing cells.<br />
The robots handle the machining spindles<br />
and remove the burrs on the mold<br />
parting. Compared to hydraulic deburring<br />
presses, this solution offers advantages<br />
interms of flexibility and reduced<br />
tool costs. If changes to castings are<br />
pending, only the programmed machining<br />
paths of the robots need to be corrected.<br />
The costs for this are significantly<br />
lower than, for example, changes<br />
to apress tool.<br />
Internal feeders and casting systems<br />
that cannot be removed by sawing are<br />
machined within the production line.<br />
For this purpose, the robot moves the<br />
workpiece along fixed milling spindles.<br />
Compared to sawing, milling causes<br />
arelatively high metal removal volume<br />
and requires correspondingly high<br />
metal removal rates. Compared to<br />
machining in amachining centre, robot<br />
machining is the cheaper and more flexible<br />
alternative. It does not require<br />
additional transport, loading and clamping<br />
operations.<br />
Finally, the robots place the nodes<br />
and crossmembers on the outfeed belts<br />
for transport.<br />
Summary<br />
This production line (Figure 5) eliminates<br />
the heavy and very stressful manual<br />
work of fettling castings. The chassis<br />
parts are processed fully automatically<br />
with short cycle times in achaotic<br />
sequence of parts. The division of the<br />
production line into cell areas ensures<br />
that the recycled materials and exhaust<br />
air are separated accordingly. Atthe<br />
same time, this structure -with cell<br />
areas replacing each other -enables an<br />
emergency operation with reduced output<br />
in the event of acell failure. Dividing<br />
the processing cell into cell areas<br />
allows the entire system to be implemented<br />
in individual expansion stages.<br />
In six phases, for example, the described<br />
cell may be expanded from abasic configuration.<br />
It is flexible and thus suitable<br />
for avariety of different workpieces<br />
and production capacities.<br />
Flexibility of production systems is<br />
more important than ever, especially in<br />
times of unclear quantity forecasts.<br />
Mössner meets this requirement with its<br />
modular system concepts. Foundries are<br />
thus able to make the necessary investments<br />
in line with the respective quantity<br />
phase.<br />
www.moessner-kg.de<br />
Prof. Dr.-Ing. Dietmar Schmid und M.<br />
Eng. Christian Kunz, August Mössner<br />
GmbH +Co. KG, Eschach.<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 29
GRINDING<br />
Superabrasives for the foundry industry<br />
Cool grinding for more<br />
parts per wheel<br />
How can foundries increase their productivity and product quality aswell as the safety<br />
of their employees? Asuitable tool isthe new Foundry Xelectroplated single-layer<br />
grinding wheel from Norton Winter, the premium brand from Saint-Gobain Abrasives.<br />
by Andreas Eckhard, Norderstedt<br />
Photos: SAINT-GOBAIN ABRASIVES<br />
Compared with existing electroplated<br />
tools on the market, Foundry<br />
Xsteps things up agear in terms<br />
of performance, durability and safety<br />
during cast product machining thanks<br />
to aspecial new electroplated bond<br />
technology which allows foundries to<br />
cut costs per approved part considerably.<br />
Futhermore, Foundry Xalso offers a<br />
reason for foundries to switch from<br />
standard electroplated tools and particularly<br />
from conventionally bonded<br />
abrasives to diamond and CBN grinding<br />
tools.<br />
Increasing productivity –reducing<br />
dust exposure<br />
Modernization is akey trend inthe<br />
foundry segment. New CNC- and<br />
robot-assisted systems, which appeal to<br />
foundries of all sizes, come with the<br />
promise of extra production output<br />
and arapid ROI. At the same time,<br />
demand for higher-quality cast and<br />
ductile iron is growing. “In light of this,<br />
foundries are focusing partly on<br />
making their production systems more<br />
environmentally friendly and improving<br />
their efficiency in the process. With<br />
Foundry Xattheir disposal, these two<br />
objectives are not mutually exclusive.<br />
For example, switching from conventio-<br />
30
nally bonded wheels to Foundry Xdiamond<br />
and CBN abrasives not only<br />
increases productivity and quality but<br />
also cuts down on dust by as much as<br />
90 %”, says Andreas Eckhardt, product<br />
manager at Norton Winter.<br />
Service life, quality and<br />
consistency<br />
An electroplated grinding wheel consists<br />
of asteel body with asingle layer of diamond<br />
or CBN. The grains are embedded<br />
in aspecial nickel bond. This gives users<br />
agrinding wheel with astable diameter<br />
and profile. That means that there is no<br />
need to make diameter adjustments in<br />
the machine software during series production.<br />
The main body can be re-used<br />
many times, provided that it is not<br />
damaged. The wheel can then be used<br />
until there is no protruding grain left.<br />
The new line of Norton Winter<br />
Foundry Xelectroplated single-layer<br />
grinding wheels, featuring an extremely<br />
hard and yet ductile nickel bond coupled<br />
with high-quality special diamond<br />
and CBN grains, have been developed to<br />
prevent heat and load problems from<br />
being factors limiting productivity and<br />
quality in grinding and cutting work.<br />
For that purpose, Norton Winter has<br />
equipped Foundry Xwith high-quality<br />
special diamond and CBN grains arranged<br />
inhigh concentrations bonded to<br />
the high-grade steel main body by the<br />
nickel electroplating. This enables the<br />
grain toprotrude more than on wheels<br />
with multiple layers. The special new<br />
electroplating technology also ensures<br />
excellent grain retention, which leads<br />
to anoticeable reduction in wear in<br />
applications on CNC-controlled machining<br />
equipment as well as in robot guided<br />
applications and manual processes.<br />
Automated cell grinding is one<br />
example. Foundry Xtruly shines in this<br />
department, with along service life,<br />
reduced wheel changes and minimized<br />
downtime, with consistent wheel<br />
dimensions and minimal wear. Its precise<br />
geometry reduces vibrations, while the<br />
unchanging wheel dimensions allow for<br />
faster and easier programming.<br />
As Eckhardt explains, “Foundry X<br />
combines unique grain quality and<br />
maximum grain concentration in the<br />
wear zone and offers better homogeneity<br />
in comparison with other coated<br />
wheels. Grain quality is selected depending<br />
on component material. The grain<br />
size can also be adjusted to suit the<br />
application. Foundry Xcan maintain the<br />
expected tolerances depending on the<br />
grain size and offers excellent diameter<br />
and profile stability as well as profile<br />
tolerances of 0.05 mm to 0.15 mm.”<br />
Thanks to the design benefits and<br />
the ability to make minute adjustments<br />
to the tool in line with the specific<br />
application, manufacturers can cut and<br />
grind at lower temperatures and<br />
improve their material removal rates.<br />
Foundry Xsuperabrasives last for longer<br />
thanks to their wear resistance. According<br />
to Andreas Eckhardt, “they offer<br />
the longest service life per wheel on the<br />
market compared with directly coated<br />
standard wheels. That means more grinding<br />
between wheel changes and also<br />
Foundry Xoffers<br />
impressive performance,<br />
durability<br />
and safety during<br />
cast product machining<br />
thanks to a<br />
special new electroplated<br />
bond technology.<br />
The grinding wheels<br />
are available in a<br />
range of sizes and<br />
profile shapes to<br />
meet specific<br />
requirements for<br />
grinding various<br />
cast materials.<br />
reduced downtime. Consequently,<br />
depending on the application, using a<br />
Foundry Xwheel can allow you to<br />
machine up to 50 %more parts”.<br />
This is underlined by aNorton Winter<br />
case study entitled “Rough machining<br />
grey cast iron: Foundry Xvsstandard<br />
electroplated wheel with agrain<br />
size of D851”. With parameters of a<br />
hardness of 67 HRC, material removal of<br />
3mm, wheel speed of 50 m/s and feed<br />
rate of3mm/s, the Foundry Xtool<br />
manufactured 40 %more workpieces<br />
per wheel.<br />
In cutting processes for machining a<br />
brake calliper from tempered grey cast<br />
iron (67 HRC) in aMaus robotic cell,<br />
Foundry Xachieved aservice life 30 %<br />
longer than aconventional superabrasive<br />
available on the market. Furthermore,<br />
it did so with better chip clearance,<br />
astraight cut and fewer rejects.<br />
Safety for employees<br />
The switch from conventional grinding<br />
wheels to diamond and CBN wheels in<br />
foundries offers significant potential for<br />
improvements in safety and environmental<br />
aspects. The steel bodies of the<br />
diamond and CBN grinding wheels prevent<br />
the risk of the wheels breaking<br />
during use. Much less dust is produced<br />
than with conventional abrasives and<br />
the odour that is typically emitted<br />
during grinding in foundries is almost<br />
entirely eliminated.<br />
All Foundry Xwheels are manufactured<br />
to suit user requirements. They<br />
are available in arange of sizes and<br />
profile shapes to meet specific requirements<br />
for grinding various cast materials.<br />
Arange of special shapes can also<br />
be created.<br />
www.nortonabrasives.com/de-de<br />
Andreas Eckhardt, Product Manager<br />
Direct Plated Products, Superabrasives<br />
EMEA, Saint-Gobain Diamantwerkzeuge<br />
GmbH, Norderstedt, Germany<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 31
DIGITALIZATION<br />
Site Analysis<br />
The digital foundry –<br />
wishful thinking or amodel<br />
for the future?<br />
Networking in foundries increases.<br />
But autonomous production is not the<br />
aim of application-related science.<br />
“Humans should always decide<br />
whether to adjust ascrew or not.“<br />
The foundry industry is abuzz about the digital transformation. New technical solutions<br />
promise to optimize foundry processes and bring long-term competitive advantages. But<br />
to what extent have digital production technologies so far taken over the works halls of<br />
German and Swiss foundries, and what potentials do scientists think they will bring?<br />
Some practical evaluation follows.<br />
BY Robert Piterek, Düsseldorf<br />
Photo: Fotolia<br />
The interest that the word ‘digitalization’<br />
awakens in the foundry<br />
industry is greater than ever<br />
before. The networking of plant technology<br />
and the acquisition of data –with<br />
the opportunities they provide –have<br />
been exciting ever-greater circles in the<br />
industry for more than adecade now.<br />
Whereby the digital transformation is<br />
seen as amagic formula for enhancing<br />
competitiveness through optimized lean<br />
processes, the costs of which –for<br />
example, energy and resources, CO 2<br />
emissions, maintenance, procurement<br />
and quality assurance –can be massively<br />
reduced using digital methods.<br />
So much for the theory. But to what<br />
extent has this future project progressed<br />
in the foundry industry? Let’s take a<br />
look at the figures first, before we examine<br />
the everyday operations of German<br />
foundries.<br />
SMEs are taking their first steps<br />
At aworkshop organized by Germany’s<br />
Federal Ministry for Economic Affairs<br />
and Energy on the future technologies<br />
of suppliers, Dr. Kai Kerber (Manager of<br />
Smart Foundry Solutions at Oskar Frech)<br />
recently showed that, based on data<br />
obtained from asurvey of SMEs, companies<br />
are still at the start of along journey.<br />
Onascale of 1to6(where Step 1 is<br />
computerization, 2isconnectivity, 3is<br />
visualization, 4istransparency, 5is predictive<br />
capability, and 6isadaptability),<br />
almost two-thirds of companies are still<br />
struggling with the first two digitization<br />
steps.<br />
32
Digitalization actually only becomes interesting from Step<br />
3onwards, when production processes obtain visualization<br />
capability via data analyzes –and, to be fair, every fifth SME<br />
is already at this level. Digitalization adds aholistic process<br />
understanding at Step 4. Companies can then capture a<br />
wealth of data at Step 5, when faults can be predicted and<br />
prevented before they occur. Step 6involves self-optimizing<br />
systems that could ultimately enable autonomous production<br />
in foundries.<br />
‘Unmanned’ autonomous processes appear attractive for<br />
reasons of cost but also creates unease: “The aim is to make<br />
better decisions quicker, and not establish autonomous production<br />
in the foundry,” stresses Prof. Dierk Hartmann from<br />
Kempten University of Applied Sciences in southern Germany,<br />
apioneer in research on digitalization in foundries. It<br />
is his clear opinion that ultimately aperson should always<br />
decide “whether to adjust ascrew or not”. An opinion that<br />
he voiced in an interview onthe state of digitalization-related<br />
research and development which appeared in May 2<strong>02</strong>1.<br />
All the same, initial applications of this type have been in<br />
operation in the industry for some time now, for example in<br />
the form of autonomous transport systems at the Smart<br />
Foundry in Hasloch; or avirtual assistant in the latest die-casting<br />
plants from Oskar Frech –which makes autonomous corrections<br />
of tolerance deviations during production or a<br />
warehouse whose ERP system enables ‘chaotic’ organization.<br />
These, however, are only individual aspects. There is not (yet)<br />
an algorithm that can autonomously carry out production as<br />
awhole. What do exist are noteworthy developments in the<br />
sector, and they show that the foundry industry is on the<br />
path towards digitalization and is already profiting from it.<br />
NEW<br />
Emission-Free<br />
Casting with<br />
Inorganic Cores<br />
Automatedinorganic sand 3D printing<br />
nowavailable<br />
The digital administration<br />
Thus, for example, automated administration is an early digitalization<br />
step with major effects. Christen Guss in Bergdietikon<br />
(in the Baden district of Aargau canton in Switzerland)<br />
already took this step several years ago: invoices are scanned,<br />
compared with customer data, and automatically booked.<br />
Accounting costs quickly halved, while balance sheets and<br />
income statements are now updated in real-time, massively<br />
improving the overview of business activities –regularly<br />
consulted by Elon Musk fan, Florian Christen, for advice. “We<br />
want to act, not react,” says the businessman. Christen therefore<br />
rates digitalization highly (CP+T reported on this in Issue<br />
4/2017, from p. 30). Automated administration is active all<br />
the way down to procurement.<br />
The use of probes at Karl Casper Guss in Remchingen<br />
makes the consumption of resin and sand so transparent that<br />
the ordering of auxiliary and operating materials is now largely<br />
automated. Customers also profit from minute-by-minute<br />
transparency regarding their orders. Customers sending<br />
regular delivery forecasts can obtain their castings just one<br />
day after making the actual order. Online presentations, e.g.<br />
by Florian Christen, are also being worked on –one day he<br />
wants to automatically offer potential customers an expected<br />
price when they upload their CAD data. Acloud-based<br />
raw materials platform developed by Profs. Hartmann and<br />
Gottschling (with Lohmann Guss, among others) already<br />
works somewhat similarly: the most reasonably priced offer<br />
is displayed on the basis of aso-called simplex algorithm.<br />
Profs. Gottschling and Hartmann have significantly shaped<br />
research into digitalization in the foundry industry. Prof.<br />
Gottschling teaches mathematics for engineers at the University<br />
of Duisburg-Essen.<br />
• Series production through integrated automation and future<br />
robotic expansionpossibilities<br />
• Fast production of precise,complex,and consolidatedcores<br />
• Zero emissions during printing and pouring<br />
• Higher yields with lowerrejection ratesfromgas-related<br />
defects during casting<br />
• Environmentally friendly processing and storage<br />
• Easy finishing thanks to reduced sand adhesion<br />
AUTOMATED<br />
DESANDING STATIO ON<br />
reduces unpacking<br />
time by up to 95%<br />
LEARN MORE:<br />
exone.com/inorganicbinder
DIGITALIZATION<br />
Administrative optimizations have<br />
meanwhile taken place at well over<br />
two-thirds of SMEs, according to Kerber’s<br />
figures.<br />
Optimizing the charging process<br />
The optimization of production processes<br />
using digital methods can take place<br />
in many forms and affect processes<br />
throughout the entire production cycle.<br />
In 2018, fittings caster Düker in Laufach<br />
introduced new process control technology<br />
that uses the JOKS-Gatt system,<br />
enormously simplifying charging –and<br />
leading to savings in energy and<br />
resource consumption. The technology<br />
is monitored from the control center of<br />
the magnetic crane. First, arecipe is<br />
input. Then the magnetic crane drives<br />
from metal bay to metal bay picking up<br />
the defined amount of scrap or ingots<br />
and dropping them into the vibrating<br />
chute, whereby the required charging<br />
quantity is counted down –asifina<br />
video game. The crane operator therefore<br />
has the charging process under<br />
control atall times. Quality assurance<br />
takes place using aspark emission spectrometer<br />
connected to the JOKS-Gatt<br />
system. The company’s technical<br />
management carried out the 100,000<br />
euro investment not only to optimize<br />
charging but, with numerous linked<br />
process parameters, also considered it<br />
an important step towards digitalization.<br />
This is in harmony with modern research:<br />
“For every need in foundries or<br />
the process industry we want to control<br />
optimized processes on the basis of<br />
data to obtain more information on<br />
how toachieve optimizations,” Prof.<br />
Johannes Gottschling defines the aims<br />
of application-oriented science.<br />
Optimizing sand preparation<br />
Another example of adigitally optimized<br />
process is the Qualimaster AT1from<br />
Eirich, which optimizes sand preparation<br />
and is used as part of the new HWS<br />
III Hybrid molding plant at Ohm &<br />
Häner in Olpe. After mixing, the device<br />
measures the gas permeability, springback,<br />
and plasticity of the sand chargeby-charge.<br />
The continuous provision of<br />
data enables improvement of sand quality<br />
while increasing the precision of<br />
molding and casting. This helps meet<br />
tighter tolerances, and considerably<br />
reduces subsequent work on the castings.<br />
The sand circulatory system is also<br />
included in the digitally monitored process<br />
chain, and thus assists in the traceability<br />
of castings, among other things.<br />
Photos: Andreas Bednareck<br />
Sacher Kast, an<br />
employee at Karl Casper<br />
Guss, obtains data<br />
on acasting from the<br />
feedback monitor in<br />
the foundry hall.<br />
Information on the<br />
unit number, model<br />
and designation is<br />
provided after the<br />
casting’s bar code has<br />
been scanned.<br />
Predictive maintenance<br />
Aprocess optimization that precisely<br />
coordinates maintenance work with<br />
the wear that has taken place can also<br />
be seen at Düker in Laufach. Its use,<br />
however, isnow common practice in<br />
the melting plants of many foundries.<br />
The furnace’s numerous sensors in the<br />
OCP system (Optical Coil Protection)<br />
from Otto Junker constantly monitor<br />
the filling state and weight in the aggregate.<br />
At the same time, afiber-optic<br />
cable measures the temperature on the<br />
inside of the induction coil, thus monitoring<br />
wear of the furnace lining.<br />
Visual translation on the screen provides<br />
agood indication of the state of<br />
the refractory material. Relining then<br />
takes place when necessary, cutting<br />
costs and increasing safety in the melting<br />
plant.<br />
Maintenance on the basis of digital<br />
methods is now also carried out by ABP<br />
Induction Systems regardless of location,<br />
which is particularly helpful during<br />
this coronavirus pandemic. Service personnel<br />
can provide virtual support to<br />
technicians on site with the help of a<br />
headset with asmall video screen and<br />
camera. Circuit diagrams can be fed-in<br />
during maintenance, and instructions<br />
provided. The technology has therefore<br />
taken astep towards augmented reality,<br />
with which ultimately every hand<br />
movement during maintenance work<br />
can be supported technically, and<br />
valuable supplementary information<br />
can be provided.<br />
Traceability and fault prevention<br />
Foundries have been working on the<br />
traceability of castings for some time<br />
34
now. While it was initially ademand<br />
from carmakers, intended to ensure<br />
reproducible production steps and<br />
high quality, for many casters traceability<br />
(e.g. via RFID chips) now includes<br />
the almost complete penetration of<br />
individual process steps, and thus also<br />
the reduced potential for faults. “The<br />
casting knows best what has happened<br />
to it –wejust have to make it talk,”<br />
sums up Prof. Hartmann. While it is<br />
relatively easy to mark acasting during<br />
the die-casting process, it is definitely<br />
more difficult in the case of core shooting<br />
and sand casting. Hartmann is<br />
working with Franken Guss Kitzingen<br />
on the Castcode project, involving the<br />
marking of components via the mold,<br />
whereby amark isembedded in the<br />
pattern plate. This would enable the<br />
calling up of current data on the melt,<br />
Christof Amend, Melting Operations<br />
Manager at Düker in<br />
Laufach, demonstrates charging<br />
via joystick. The chutes<br />
for input materials can be<br />
seen on the left.<br />
Fully automatic core production<br />
at Inacore inErgoldsbach:<br />
industrial robots carry<br />
out most of the work steps<br />
here. They place the cores in<br />
racks marked with RFID<br />
codes.<br />
Photo: Inacore<br />
mold material data including machine<br />
data (mold plant, core-shooting<br />
machine) and, for example, cooling<br />
data. The hand molding shop Karl Kasper<br />
Guss introduced RFID chips for<br />
administrating mold boxes some time<br />
ago. In the Inacore core shop in Ergoldsbach<br />
in Bavaria, which supplies the<br />
BMW light-metal foundry in Landshut<br />
with inorganic cores, the RFID chips are<br />
attached tothe racks. This enables them<br />
to assign production parameters to<br />
batches. The production cycles and their<br />
associated data can be called up in realtime<br />
via aPC, and can be compared<br />
with older data. Inacore cooperates<br />
with the University of Passau so that<br />
one day –with the help of this wealth<br />
of data –nomore faults will be possible.<br />
Data quality counts<br />
It cannot, however, beassumed that a<br />
wealth of production data automatically<br />
provides good forecasts on quality.<br />
“I could have amountain of data with<br />
little information, or just 120 lines of<br />
data with really important information,”<br />
Gottschling knows, and Hartmann<br />
adds: “Getting agood data structure<br />
in the company isthe very first<br />
thing that must be done before optimizations<br />
are possible.”<br />
The two professors recently proved<br />
this with aparticularly creative project<br />
on data gathering: the state of sand is<br />
acoustically determined using their<br />
so-called ‘chafing generator’ and the<br />
forecasting data is used to calculate an<br />
optimum time window for sand regeneration.<br />
The consequence: aprocess with<br />
improved energy and resource conservation.<br />
Safeguarding the future<br />
by reducing rejects<br />
Afoundry can save alot of money by<br />
reducing the number of rejects. The<br />
Danish Norican Group working with the<br />
South African IT company DataProphet<br />
offers the latest system for foundries,<br />
intended to reduce the number of<br />
rejects in serial production by up to 45<br />
percent. Such systems are already in operation<br />
in aSpanish foundry group and at<br />
the South African Atlantis foundry.<br />
The system from Swedish company<br />
pour-tech, recently presented in CP+T<br />
1/2<strong>02</strong>1 from page 24, also promises to<br />
reduce the number of rejects. Foundries<br />
where defective casting is particularly<br />
expensive, e.g. roller foundries, have<br />
already used IT systems for the early<br />
prevention of defects for some time<br />
now. At Walze Irle in Netphen, for<br />
example, probes provide data that computer<br />
algorithms use to determine melting<br />
point and melting range values, as<br />
well as tapping and casting temperatures,<br />
to prepare for casting.<br />
The race for the future of the sector<br />
in the digital age –with minimal rejects<br />
and maximum process reliability –has<br />
therefore started. “If weknow all the<br />
data, all the starting conditions and the<br />
laws of nature we can provide atotally<br />
accurate forecast,” Prof. Gottschling<br />
replies to the question of how exact the<br />
forecasting function could be. This may<br />
well prove difficult. But Prof. Hartmann<br />
is certain that foundries could become<br />
“more flexible, more agile, more reliable<br />
and more robust,” –anadvantage<br />
as afoundry location, that should definitely<br />
be exploited.<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 35
MOLD AND COREMAKING<br />
Photos and Graphik: Mingzhi Technologie Leipzig<br />
Core Shooting<br />
High-efficiency heater integrated into acore shooter. Usually, it is<br />
installed separately from the machine.<br />
Efficient curing process of the<br />
core making machine<br />
An integrated high-efficiency heater for acore making machine’s newest generation<br />
improves the curing efficiency of the core making machine, reducing energy consumption<br />
and creating catalyst material savings. The article features the development<br />
method, value, and performance results, as well as afinite element analysis method to<br />
improve the performance of the heater with an integrated design concept. The results<br />
show that significant results have been achieved.<br />
By Yang Linlong and Xu Leilei, Suzhou, China<br />
Introduction<br />
The gas generator (including gas heater,<br />
abbreviated as heater) of the traditional<br />
core making machine, widely used<br />
in the foundry industry, isusually installed<br />
separately from the equipment. Its<br />
main function is to send high-temperature<br />
gas or catalytic gas into the blowing<br />
plate through hoses, joints, the<br />
connecting plate, and into the core box,<br />
resulting in the hardening of the sand<br />
core.<br />
Based upon research into the inorganic<br />
and organic core curing process,<br />
improving the heater‘s ability to continuously<br />
provide high-temperature gas<br />
is aknown challenge. Considering the<br />
status quo and associated problems, the<br />
development of high-performance heaters<br />
can provide high-level efficiency<br />
and energy savings.<br />
With the current technology, the<br />
high-temperature gas has alengthy<br />
transport distance, great temperature<br />
loss (up to 60% or more), high energy<br />
consumption, and poor stability. Especially<br />
among the conditions of the inorganic<br />
curing process, the temperature<br />
cannot be guaranteed, resulting in low<br />
curing efficiency and high energy<br />
consumption.<br />
Status analysis<br />
The schematic diagram of the traditional<br />
generator scheme is revealed in<br />
Figure 1, which shows the combination<br />
36
of the upper moving mechanism of the<br />
core making machine. Since the upper<br />
part of the core making process repeats<br />
once every cycle, the heater is fixed on<br />
the upper frame, and the hot air or the<br />
catalytic gas is delivered to the gassing<br />
bell under aspecific pressure which<br />
results in the hardening of the sand<br />
core.<br />
For analysis of the distribution<br />
power composition of the main functions<br />
of the core making machine, we<br />
use the 40 l-core making machine as an<br />
example, see Figure 2:Thereby T1 is the<br />
sum of auxiliary actions for the equipment<br />
to achieve core making, T2 the<br />
time period of sand shooting and<br />
discharge of high-pressure gas after the<br />
mold closing equipment is locked and<br />
T3 the time period for core sand solidification<br />
after filling the cavity.<br />
The core-making cycle time is<br />
T=T1+T2+T3, and the hardening of the<br />
sand core accounts for about 50%-60%<br />
of the core-making cycle. The traditional<br />
core-making efficiency is about<br />
50-60 type/H (cold core process), 40-50<br />
type/H (Inorganic technology).<br />
The main functional power distribution<br />
of the core making machine is divided<br />
across the hydraulic station (pressure),<br />
operating units, and heaters<br />
(Figure 3). Among these, heaters<br />
account for about 25%~40%. Combined<br />
with the previous evaluation<br />
data, the curing energy consumption of<br />
the traditional core making machine<br />
(Cold core process) is about 0.009Kwh/<br />
kg<br />
(Calculated based on the ratio of the<br />
measured curing energy consumption<br />
to the weight of the sand core during a<br />
specific blowing period)<br />
Compressed air<br />
(1) Sand shooting barrel assembly, (2) Gassing bell assembly, (3) Heater<br />
assembly, (4) Connecting hose assembly, (5) Connecting trolley assembly<br />
Figure 1: Sketch of the traditional solution.<br />
Integrated solution<br />
According to the above analysis of the<br />
operating cycle, the heater accounts for<br />
60% of the total core-making cycle, and<br />
the energy consumption accounts for<br />
40%. The question of how to integrate<br />
the design will be the starting point in a<br />
addressing the efficiency and consumption<br />
problem. The heater integration<br />
task includes primarily structural integration<br />
and functional integration:<br />
> Structural integration: the heater is<br />
MADE IN ITALY<br />
Decoring foundrysolutions for30years<br />
Pneumatic decoring hammer<br />
for gravity, low pressure<br />
and lost wax process<br />
PATENTED<br />
• Different models<br />
• Easy to install<br />
• After-sales and repair service<br />
Decoring bench<br />
• Designed and manufactured<br />
according to<br />
customer’s needs<br />
• Suitable for small batch<br />
castings<br />
• Pneumatic decoring<br />
hammers fastened<br />
in a fixed position<br />
PNEUMATIC DECORING HAMMER AF1470<br />
MONITORING<br />
SYSTEM THOR V4.0<br />
to check the hammer’s<br />
performance<br />
during operation<br />
DECORING MACHINE DCB18<br />
EXTERNAL VIEW<br />
DECORING MACHINE DCB18 - INTERNAL VIEW<br />
EXAMPLE<br />
OF A DECORING<br />
BENCH<br />
Decoring machine DCB18<br />
• Rotation movement<br />
up to 360° in both rotation<br />
directions<br />
• Simultaneous decoring<br />
of several castings<br />
• Suitable for big batch<br />
castings<br />
• Custom-made housings<br />
• PATENT PENDING<br />
Contact us for further information about our products.<br />
When contacting, please give following code <strong>CPT</strong>_ 22<strong>02</strong>1.<br />
O.M.LER SRL Via Don Orione 198/E, 198/F -12042 Bandito -Bra (CN) -Italy<br />
Phone +39 0172 457256 -Fax +39 0172 491180<br />
omler@omlersrl.com -www.omlersrl.com
MOLD AND COREMAKING<br />
Energy consumption<br />
Effectiveness<br />
27%~34% 33%~41% 25%~40%<br />
~25 kW<br />
<br />
<br />
Dry cycle time<br />
~30 kW<br />
<br />
<br />
Sand shooting<br />
exhaust<br />
Curing time<br />
18 kWCold core process<br />
36 kWInorganic technology<br />
<br />
Figure 3: The relationship between power distribution and energy consumption of the main<br />
functions of the traditional core machine<br />
(1) The heater body is integrated with the gassing channel<br />
and electric heating element, (2) Blowing air duct (3) Air inlet<br />
(4) Air outlet (5) Electric heating element (6) Amine injection port<br />
(7) Heat insulation (8) Gassing bell (9) Core box (10) Sand core<br />
Figure 4: Schematic diagram of the functional integration.<br />
2030sCold core process 80%<br />
3050sInorganic technology 80%<br />
Figure 2: The relationship between core-making cycle time and efficiency using the<br />
traditional method.<br />
P<br />
integrated with the blowing hood of<br />
the core making machine.<br />
> Functional integration: heater and<br />
cold core process catalyst atomization<br />
accomplish afunctional integration.<br />
The schematic diagram of the functional<br />
integration is shown in Figure 4,<br />
whereas the schematic diagram of the<br />
integrated solution is shown in Figure 5.<br />
Compared to the traditional scheme,<br />
the other mechanisms are the same, but<br />
the heater is integrated on the blowing<br />
hood, eliminating the traditional<br />
connecting hose assembly.<br />
According tothe current structure of<br />
the key functional component of the<br />
heater, its physical shape and the geometric<br />
model of the fluid channel area<br />
are preprocessed, and the flow and<br />
heat exchange process of the heater are<br />
simulated and analyzed according to<br />
the operating conditions of the heater<br />
(Figure 6):<br />
> The three-dimensional flow trajectory<br />
diagram of the gas in the heater<br />
channel and the core area diagram of<br />
the air flow vortex are obtained<br />
through simulation, and the air inlet<br />
Reynolds number, obtained through<br />
simulation, is within the “strong turbulence”<br />
stage.<br />
> The heater is designed to simultaneously<br />
introduce gas into both sets of<br />
flow channels. Since the channel geometric<br />
structure is symmetrically similar,<br />
the gas flow in the two sets of flow<br />
channels also exhibits asymmetrically<br />
distributed flow pattern.<br />
> Itcan be seen from the schematic<br />
diagram that within the heater flow<br />
channels, the gas flow state in most<br />
areas is aturbulent vortex flow, sothe<br />
heating and heat exchange efficiency of<br />
the heater is relatively high.<br />
Table 1: Verification results of the integration scheme (with a40l-core making machine as an example).<br />
Performance Traditional solution Integrated solution Trend Parameter<br />
Heatloss in % 50-60 10-20 reduce 30-50<br />
Curing energy<br />
0.009 0.0045 reduce 50%<br />
consumption in Kwh/kg (Cold<br />
core process only)<br />
Catalyst consumption<br />
1-1.5ml/kg 0.5-0.7 reduce 30-50%<br />
(Catalystdosage/sand core<br />
Weightinml/kg,cold core process<br />
only)<br />
Curing efficiency<br />
Curing time in s<br />
reduce 30-50%<br />
Exhaust system processing<br />
airvolumeinm 3 /h<br />
20-30 (Cold core<br />
process)<br />
30-50 ((Inorganic<br />
-technology)<br />
10-20 (Cold core<br />
process)<br />
15-25 (Inorganic<br />
technology)<br />
50 %<br />
About 8000 About 3500 reduce 40-50%<br />
38
The serpentine curved flow channels<br />
in the different layers of the heater are<br />
connected through the vertical tube.<br />
Due tothe small size of the round tube,<br />
the acceleration of the gas flow is<br />
achieved by the constant scaling of the<br />
pipe size in the heater, which enhances<br />
the heat exchange effect to some<br />
extent.<br />
> From the top inlet of the heater to<br />
the bottom outlet, the temperature rise<br />
of the gas is relatively stable and continuous.<br />
This indicates that when the<br />
heating rod is working, the heater shell<br />
and the gas near the boundary layer<br />
near the wall of the flow channel are<br />
effectively heated, and the vortex in the<br />
elbow area makes the gas heat exchange<br />
stronger. The temperature rise of<br />
the mainstream in the smooth straight<br />
channel depends primarily upon the<br />
heat status of the molecules.<br />
Production test and verification<br />
results<br />
Through the application of the integrated<br />
solution, due to the increase of blowing<br />
temperature and continuous<br />
improvement, the blowing curing time<br />
is significantly shortened, thereby reducing<br />
the amount of sand core curing<br />
time and improving the core making<br />
efficiency. (See Figure 7): The percentage<br />
of sand core hardening in the<br />
core-making cycle is reduced from<br />
50-60 %toabout 37-44 %, and the<br />
core-making efficiency of the integrated<br />
solution is increased to approximately<br />
90-100 type/H (cold core process)<br />
and 80-90 type/H (inorganic process).<br />
Due to the cancellation of the<br />
high-temperature gas delivery pipeline,<br />
the blowing temperature heat<br />
loss is greatly reduced, and the same<br />
inlet temperature of the blowing hood<br />
is obtained. The set temperature of the<br />
heater integration scheme is lower, the<br />
response time is shorter, and the proportion<br />
ofheater power is also<br />
reduced from 25%~40% to 18%~30%.<br />
In addition, the curing energy<br />
consumption is estimated to be<br />
reduced by more than 50%. (See<br />
Figure 8): In addition, for the cold core<br />
process, as the heater and the catalyst<br />
atomization are functionally integrated,<br />
the catalyst can be blown and<br />
injected after the initial atomization,<br />
and the catalyst gasification efficiency<br />
and utilization rate are improved, thereby<br />
reducing the catalyst. In the case<br />
of consumption, ahigher catalytic<br />
effect is obtained, and the curing efficiency<br />
is improved.<br />
Energy consumption<br />
Effectiveness<br />
44%50% 12%13% 37%44%<br />
Dry cycle time<br />
Sand shooting<br />
exhaust<br />
32%37% 38%45% 18%30%<br />
~25 kW<br />
<br />
<br />
~30 kW<br />
<br />
<br />
Curing time<br />
1<strong>02</strong>0Cold core process 80%<br />
1525Inorganic technology 80%<br />
<br />
<br />
<br />
Compressedair<br />
Amine-<br />
inlet<br />
(1) Sand shooting barrel assembly (2) Blow hood assembly<br />
(3) Integrated heater assembly (4) Connecting trolley assembly<br />
Figure 5: Schematic diagram of the integration solution.<br />
Figure 6: Heater geometry model.<br />
Figure 7: The relationship between cycle time and efficiency of an integrated solution for<br />
manufacturing sand cores.<br />
Figure 8: The relationship between power distribution and energy consumption of the main<br />
processes of the integrated core making machine.<br />
P<br />
CASTING PLANT &TECHNOLOGY 2/2<strong>02</strong>1 39
MOLD AND COREMAKING<br />
Table 1 clearly shows: in the case of<br />
reducing the heat loss by 50 %, the<br />
energy consumption can be effectively<br />
reduced by 50 %, the curing efficiency<br />
increased by 30 to 50 %, the amount of<br />
catalyst reduced by 30 %, and the costs<br />
of exhaust gas purification treatment<br />
will decrease accordingly (the exhaust<br />
system processing air volume is reduced<br />
by 40 to 50%).<br />
Figure 9: Completed finalization plan of the integrated heater.<br />
Blow inlet temperature<br />
Conclusion<br />
This paper studies the high-efficiency<br />
blowing and curing technology of the<br />
core-making machine. It integrates heat<br />
exchange principles, curing process<br />
principles, and advanced integrated<br />
design concepts. Afinite element digital<br />
analysis model of the heater is established.<br />
Through multi-dimensional analysis,<br />
the finalized heater is also<br />
established. Design parameters, and<br />
likewise, test quantification and production<br />
verification of the finalized<br />
heater yield the following results:<br />
> Reduced energy consumption by<br />
more than 30 %<br />
> Reduction in the amount of catalyst<br />
by more than 30 %under the organic<br />
process<br />
> Curing efficiency increase by about<br />
50 %<br />
> Exhaust gas treatment air volume<br />
reduction by more than 50 %under the<br />
organic process conditions<br />
www.mingzhi-tech.eu<br />
Yang Linlong, Xu Leilei, Suzhou Mingzhi<br />
Technology Co. Ltd. Suzhou, China<br />
Blowing times<br />
Organic process<br />
Inorganic technology<br />
Figure 10: Blowing inlet temperature curve of the integrated solution.<br />
Figure 9represents the finalized<br />
plan of the integrated heater, which has<br />
been applied to the production test<br />
verification of the Mingzhi MiCC300<br />
integrated intelligent core-making unit.<br />
Almost 200,000 molds of sand core have<br />
been manufactured with no process failures.<br />
The blowing inlet temperature of<br />
the organic process can be above 150 ℃.<br />
Inorganic process blowing inlet temperature<br />
is above 200℃ (blowing pressure<br />
is 3bar, blowing flow isabout 1200 l/<br />
min);<br />
Figure 10 shows the blowing inlet<br />
temperature curve of the integrated<br />
solution. During the entire high-efficiency<br />
curing period (within 30 s), the<br />
blowing inlet temperature of the integrated<br />
heater shows improved capability<br />
to remain constant. The blowing inlet<br />
temperature over 30 sshows adownward<br />
trend, with adecrease of about 5<br />
%, which reflects that the heater‘s heat<br />
capacity, heating power and other parameters<br />
are well designed and result in<br />
good performance.<br />
Verification results<br />
The data obtained through the production<br />
test verification and summarized in<br />
40
NEWS<br />
ASK CHEMICALS<br />
Hubert Windegger is new Chief Financial Officer<br />
Hubert Windegger (50) joins the<br />
management of ASK Chemicals, Hilden,<br />
Germany, asGroup Chief Financial<br />
Officer (CFO). In this role, he is responsible<br />
for the areas Finance, Controlling,<br />
Digitalization &IT.<br />
Windegger succeeds Anders Wester,<br />
who left the company at the end of<br />
February. Wester served as CFO of the<br />
ASK Chemicals Group since 2018 and<br />
made important contributions to the<br />
company‘s sustainable financial<br />
development inrecent years.<br />
With the Swiss Hubert Windegger,<br />
the global foundry supplier ASK Chemicals<br />
gains an experienced financial<br />
expert as Group CFO. Windegger has<br />
held various management positions at<br />
Dow Chemical in Europe, including a<br />
recent stint at Trinseo Europe, where he<br />
Photo: ASK Chemicals<br />
New CFO: Hubert Windegger succeeds<br />
Anders Wester at ASK Chemicals Group.<br />
contributed his financial expertise as<br />
Division CFO.<br />
„Hubert is aseasoned manager<br />
who, alongside traditional CFO responsibilities,<br />
will set new emphasis in the<br />
digitalization strategy of ASK Chemicals.<br />
Iamvery pleased that we were<br />
able to win hin for our company,“ says<br />
Frank Coenen, CEO of ASK Chemicals<br />
Group.<br />
ASK Chemicals is one of the world’s<br />
largest suppliers of foundry chemicals<br />
and consumables, with acomprehensive<br />
product and service portfolio of binders,<br />
coatings, feeders, filters, and<br />
release agents, as well as metallurgical<br />
products including inoculants, Mg-treatment,<br />
and inoculation wires and master<br />
alloys for iron casting.<br />
www.ask-chemicals.com<br />
NORICAN GROUP AMERICAS<br />
Mike Lewis becomes new head of sales and service<br />
Norican Group, parent company to<br />
leading industrial equipment brands<br />
Disa, Italpresse Gauss, StrikoWestofen<br />
and Wheelabrator, has appointed Mike<br />
Lewis as its new Vice President for<br />
Sales and Service in North and South<br />
America. In this position, he will be responsible<br />
for sales and service for all<br />
four Norican Group brands.<br />
With atotal of 36 years of Norican<br />
experience under his belt, Mike’s deep<br />
knowledge of the metalworking industry<br />
makes him the right person to<br />
understand what customers really need.<br />
Mike started as aservice technician with<br />
Disa, then worked his way up to service<br />
manager before becoming Disa President<br />
for North America in 2004. Most<br />
recently VP Commercial Operations for<br />
Norican Group Americas, he gained a<br />
degree in Business Management from<br />
Aurora University in 1999.<br />
“I’m very excited to take over this<br />
role,” said Mike. “Our industry is more<br />
competitive than ever and, as we come<br />
out of the pandemic, our customers are<br />
looking to us to help them improve performance.<br />
I’m looking forward to continuing<br />
to broaden and deepen our<br />
Will promote sales<br />
and services in the<br />
Americas: Mike<br />
Lewis, who has<br />
been Americas-President<br />
of Norican<br />
brand Disa and VP<br />
Commercial Operations<br />
for Norican<br />
Group Americas<br />
before.<br />
customer support, becoming even more<br />
responsive to customer requests and<br />
making it as simple as possible for them<br />
to access the incredible combined<br />
expertise of the four Norican Group<br />
brands.”<br />
Norican Group has spent the last<br />
two years upgrading its infrastructure<br />
to better serve its customers and transform<br />
the way it delivers equipment,<br />
parts and services. In 2<strong>02</strong>0, it moved all<br />
manufacturing and operations for the<br />
four brands into its LaGrange Technology<br />
Hub in Georgia where anew operations<br />
and assembly facility opens in<br />
2<strong>02</strong>2. “To build world class support and<br />
customer service, we are investing heavily<br />
