EDITORIAL<br />
Taking chances in multidimensional<br />
fields of tension<br />
The new vaccines are gradually illuminating the light at the end of<br />
the tunnel in this coronavirus pandemic. Reason enough to think about<br />
what will come after it, as Johannes Messer does in our Interview. He<br />
believes that European foundries are currently experiencing a period<br />
of historical significance, characterized by multidimensional fields of<br />
tension – some of which are discussed in this issue.<br />
Robert Piterek<br />
e-mail: robert.piterek@bdguss.de<br />
Artificial intelligence (AI) has<br />
become a magical phrase that<br />
mostly brings to mind self-driving<br />
vehicles, and many carmakers are<br />
currently working on its breakthrough.<br />
Smart houses, apartments and devices,<br />
as well as virtual assistants such as Apple’s<br />
Siri and Amazon’s Alexa, however,<br />
are already part of the modern everyday<br />
life of many people in large parts of<br />
the world. Artificial intelligence is now<br />
also unstoppable in the foundry sector<br />
– in the form of ‘intelligent’ automation.<br />
Whether in automated casting<br />
control (more from P. 24), or even for<br />
the substantial reduction in the number<br />
of rejects (from P. 34): the combination<br />
of algorithms that simulate intelligent<br />
behavior with modern foundry technology<br />
will be reflected in many more<br />
applications during the coming years<br />
and decades, contributing towards<br />
more efficient, more economical, and<br />
higher-quality production.<br />
Light construction and e-mobility<br />
already characterize modern foundry<br />
development – as is increasingly the<br />
case for AI. e-mobility contributes<br />
towards those tensions mentioned by<br />
Messer. There is currently a trend in<br />
die-casting towards using ever larger<br />
machines to cast structural components<br />
that integrate functional aspects. This<br />
has advanced so far that carmaker Tesla<br />
wants to cast the complete tailpiece of<br />
its Model Y as a single part with a giant<br />
casting cell. Also large are the two<br />
structural casting cells from German<br />
plant manufacturer Oskar Frech, which<br />
are now going into operation in the<br />
USA (from p. 38). While the trend<br />
towards structural casting requires new<br />
machines, new testing methods are also<br />
necessary for e-mobility components,<br />
such as the cast rotors in the new Audi<br />
e-tron (more on this from P. 31).<br />
Efficiency measures in foundries<br />
mostly involve the melting operation.<br />
This is because most of the energy is<br />
used here. Whereby the second-largest<br />
energy consumer is often overlooked:<br />
sand preparation – where a reduction<br />
of energy input of a good ten percent is<br />
already possible at a reasonable cost, as<br />
our author Wolfgang Ernst points out.<br />
Ernst is an acknowledged expert when<br />
it comes to foundry sand and sand preparation<br />
technology (from P. 10).<br />
Have a good read!<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 3
CONTENTS<br />
FEATURES<br />
6 INTERVIEW<br />
Transformation in the multidimensional<br />
field of tension<br />
Interview with Foundry Consultant Johannes Messer<br />
on chances for aluminium foundries in times of<br />
the pandemic and ongoing changes of the branch.<br />
10 SAND PREPARATION<br />
It‘s about time to switch off...<br />
In most foundries the sand preparation is the<br />
second most energy-intensive area. 10 per cent can<br />
be saved with reasonable effort. Wolfgang Ernst<br />
18 MOLDMAKING<br />
With simulation to substitution as cast part<br />
Agricultural machinery producer Amazone used<br />
simulation by Altair and 3-D print ing from voxeljet<br />
to optimize a chassis. Frederick von Saldern<br />
SAND PREPARATION<br />
Exploiting new<br />
energy savings<br />
potentials.<br />
AUTOMATIC<br />
POURING<br />
Fully automated pouring<br />
control is possible<br />
with the help of lasers<br />
and cameras.<br />
21 CORE COATING<br />
Ensuring quality by utilizing efficient<br />
process technology<br />
New dip tanks at German foundry group SLR have<br />
optimized the core coating process. Gianni Segreto<br />
24 AUTOMATIC POURING<br />
Once a vision, now reality<br />
Swedish Pour-Tech AB has imple mented Artificial<br />
Intelligence in the pouring process, Michael Colditz<br />
TRACEABILITY<br />
DGS Druckguss labels<br />
its die castings with<br />
a new software<br />
solution.<br />
Cover-Photo:<br />
Andreas Bednareck Photography<br />
The photo shows giant casting molds in a foundry hall<br />
at Gontermann-Peipers roll foundry in Siegen, Germany,<br />
which CP+T <strong>International</strong> reported on in issue 3, 2<strong>01</strong>9.<br />
Please also read our report on the Walzen Irle roll<br />
foundry on page 48 in this issue.<br />
4
CONTENTS<br />
MOLDMAKING<br />
A bogey chassis was<br />
optimized with simulation<br />
and 3-D-printing.<br />
31 CASTING INSPECTION<br />
Cast rotors in electric asynchronous motors<br />
A joint project has succeeded for the first time in<br />
taking a look into the inside of cast rotors with a<br />
new computed tomography system.<br />
Christoph Pille, Gabriele Mäurer<br />
34 DIGITALIZATION<br />
Reducing rejects with Artificial Intelligence<br />
With the digital solution of molding machine<br />
manufacturer Disa Spanish foundry group Condals<br />
significantly improved the casting process.<br />
Kasper Paw Madsen<br />
38 DIE CASTING<br />
Producing structural parts with the new<br />
GDK model series<br />
To produce structural castings and castings for<br />
e-mobility two extralarge die casting cells by<br />
Oskar Frech were sold to a US light metal foundry.<br />
Philip Wiederhold<br />
44 TRACEABILITY<br />
“We can uniquely identify every casting<br />
we produce”<br />
DGS Druckguss Systeme AG has optimized its<br />
production with a efficent new software solution<br />
Tino Böhler<br />
48 COMPANY<br />
Pouring off melt for industrialization<br />
Walzen Irle has been casting rolls for more than<br />
200 years and has thus decisively driven industrialization<br />
forward. Robert Piterek<br />
COMPANY<br />
Casting rolls is a<br />
profession that<br />
Walzen Irle masters<br />
since 200 years.<br />
COLUMNS<br />
3 EDITORIAL<br />
54 NEWS IN BRIEF<br />
61 SUPPLIERS GUIDE<br />
78 FAIRS AND KONGRESSES/AD INDEX<br />
79 PREVIEW/IMPRINT<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 5
Lightweight construction<br />
is a trend in the automotive industry that continues<br />
unabated. This opens enormous opportunities<br />
for aluminium foundries Europe wide – says<br />
Johannes Messer.<br />
6
INTERVIEW<br />
Aluminium Casting<br />
Transformation in the multidimensional<br />
field of tension<br />
In the context of the multidimensional challenges and the corona pandemic, the<br />
foundry industry is currently in a situation of historic significance. Regardless of all the<br />
changes, the trend towards lightweight construction in the automotive industry continues<br />
unabated. Even in competition with other applications/processes and materials, this<br />
opens enormous opportunities for aluminium foundries. The concept paper „Aluminium<br />
casting: Success story part 2“ by foundry consultant Johannes Messer describes the past,<br />
comments on the present and motivates for the future. We spoke to the author about<br />
the content, findings, and recommendations of the concept paper.<br />
Photo: Andreas Bednareck<br />
When I read your study, I have the feeling<br />
that the foundry industry, more<br />
than other automotive suppliers, has<br />
been affected by the transformation in<br />
the automotive industry and the effects<br />
of the current pandemic. Or do the<br />
foundries like to complain at a high<br />
level?<br />
Most of the foundries in Germany<br />
already had a „previous illness“. Despite<br />
know-how and productivity advantages<br />
in international comparison, the foundries<br />
have not been able to keep up economically<br />
in the international<br />
benchmark for several years. The foundries,<br />
with their high personnel and<br />
energy requirements, are not able to<br />
compensate for the disadvantages of<br />
the location (taxes, energy, and wage<br />
costs) here in Germany, despite their<br />
technological lead and highest productivity.<br />
Transformation and Corona have<br />
made the overall situation even worse.<br />
You have been talking about the situation<br />
for German foundries. How do you<br />
see the impact of the transforming<br />
automotive industry and the pandemic<br />
on a European scale? Which countries<br />
are affected, which less?<br />
In Spain, France, Italy, Austria, and Sweden<br />
the overall situation is very similar<br />
to the situation in Germany. In Eastern<br />
Europe, the general conditions (taxes,<br />
energy, and wage costs) for foundries<br />
are significantly better. This has a direct<br />
influence on the company‘s results,<br />
which are better than e.g., in Germany,<br />
although there are some productivity<br />
disadvantages there. Regarding the<br />
upcoming transformation in the automotive<br />
industry, foundries with technological<br />
know-how (development of new<br />
parts) have a clear advantage.<br />
In the interview, Johannes Messer, Business<br />
Owner of Johannes Messer Consulting, talks<br />
about the effects of the COVID-19 pandemic<br />
and the transformation of the automotive<br />
industry on foundries in Europe.<br />
In comparison to other automotive suppliers,<br />
the foundries are currently particularly<br />
affected by insolvencies. Doesn‘t<br />
it make sense then that a “market shakeout”<br />
should take place now?<br />
The foundry industry has been fighting<br />
for years against unequal conditions of<br />
Photo: Johannes Messer Consulting<br />
competition because of the aforementioned<br />
locational disadvantages. The conditions<br />
of competition are not the only<br />
reason for the financial imbalances, but<br />
they are the most important. However,<br />
the possibilities of companies to compensate<br />
for these disadvantages are<br />
limited. Many foundries have therefore<br />
moved parts of their production to<br />
neighbouring European countries in<br />
recent years. The main motivation was<br />
and is to participate from the low-cost<br />
advantages. Proximity to customer markets,<br />
which is often used as an argument<br />
in such relocations, is often of<br />
minor importance.<br />
If you say that the location disadvantages<br />
are not the only reason for the current<br />
problems, what are the others?<br />
To answer the question in detail at this<br />
point will certainly lead too far. You can<br />
find detailed answers to this in the<br />
study. In principle, however, it can be<br />
said that foundries in Germany have<br />
developed more slowly in terms of technology<br />
and economy in recent years<br />
than in the past.<br />
I currently see the main need for action<br />
in the following areas:<br />
> Alignment of the product portfolio<br />
> Economically focused technology<br />
orientation<br />
> Managing investments<br />
> Merging the value chain<br />
> „Preserving and shaping“ liquidity<br />
> Find partners<br />
> Understand CIP as a lever for success<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 7
INTERVIEW<br />
> Accept and implement the new normality<br />
> Changes in line with the key success<br />
criteria’s<br />
> Look beyond the box<br />
To be successful again in the short term<br />
and to remain successful in the long<br />
term, these issues must be dealt with<br />
now. The complexity of the topics and<br />
their importance for the company‘s success<br />
require individual a detailed revision<br />
of the corporate strategy.<br />
Basically, you assume that the German<br />
foundries are competitive. Will there<br />
still be the necessary market for this in<br />
a few years? In the long term, the<br />
transformation will make today‘s<br />
power train “superfluous”.<br />
Foundries will inevitably lose volume<br />
with today‘s bread and butter parts. The<br />
foundries will lose cash flow due to the<br />
volume losses from the powertrain.<br />
These losses can only be compensated<br />
for with new parts after a time delay<br />
due to corresponding start-up costs. The<br />
resulting risk is to be assessed as particularly<br />
high in view of the current liquidity<br />
situation and the upcoming investments<br />
in connection with the transformation.<br />
The transformation will open opportunities<br />
for foundries. The trend towards<br />
lightweight construction, as one of the<br />
essential levers for increasing the range<br />
of the Battery Electric Vehicle (BEV), will<br />
continue to increase. Casting as a process<br />
and aluminium as a material are the<br />
guarantees of success at this point. There<br />
are opportunities for new cast parts in<br />
the field of e-mobility, autonomous driving<br />
and chassis and structural parts.<br />
You consider the foundries competitive<br />
and see the necessary market in the<br />
long term. These are the essential<br />
requirements for all companies to operate<br />
successfully. In your opinion, what<br />
needs to be done to take advantage of<br />
the opportunities available and to<br />
make the foundries more successful<br />
again?<br />
Yes, I think that foundries in Germany<br />
are largely competitive. However, I also<br />
say that the foundries must work harder<br />
on the success levers of technology<br />
and productivity in order to at least partially<br />
compensate for location disadvantages<br />
and to secure their competitiveness<br />
in the long term.<br />
Politicians, trade unions and foundry<br />
associations must also contribute their<br />
part and bringing taxes, energy and<br />
labour costs close to the international<br />
level of competition, so that the foundries<br />
can return to the economic track of<br />
success.<br />
As far as the market volume is concerned,<br />
there are opportunities to<br />
generate further growth. The extraordinary<br />
foundry network (metal suppliers,<br />
tool makers, foundries, machine manufacturers,<br />
research workers, ...) in Germany/Europe<br />
can exploit these opportunities.<br />
Together we can and will<br />
succeed in making lightweight construction<br />
technologically and economically<br />
possible “everywhere” in the automobile<br />
through aluminium casting.<br />
In my opinion, success depends on<br />
the foundries doing their homework<br />
successfully on an individual basis and<br />
all those involved working together on<br />
the following topics:<br />
> Reduction of the location disadvantages<br />
(taxes, energy and wage costs)<br />
> 100 % lightweight automobile construction<br />
= 100 % cast aluminium<br />
Can your recipes for becoming more<br />
successful again and taking chances be<br />
applied also on the European foundry<br />
industry as a whole? Are there regional<br />
differences?<br />
Yes, the “recipes” apply to the entire<br />
European foundry industry. The most<br />
important point is that in competition<br />
with other materials and processes we<br />
offer our customers the technologically<br />
and economically best solutions. To be<br />
successful, the entire value-added network<br />
in Europe must work together.<br />
Last but not least - now that Brexit is<br />
accomplished. Does the new reality of a<br />
EU without Britain affect the European<br />
foundries? After all some automaker<br />
produce on the British isles who need<br />
light metal castings.<br />
I cannot see any significant changes at<br />
the moment. I expect that British car<br />
manufacturers will continue to source<br />
most of their castings in the EU. I rule<br />
out a relocation of production to British<br />
foundries. For new products, the British<br />
car manufacturers will use the development<br />
know-how in the EU. The German<br />
foundries are very well positioned here.<br />
Naturally in cooperation with the outstanding<br />
foundry network in Europe.<br />
The interview with Johannes Messer<br />
was conducted by Nicole Kareta from<br />
spotlightmetal.com<br />
Read the concept paper at<br />
https://t1p.de/dx8t<br />
REMONDIS PRODUCTION GMBH –<br />
Business Unit LEGRAN<br />
Choose REMONDIS as your professional service partner and benefit<br />
from our:<br />
exceptional wet process technology – efficiency and quality are unique<br />
in Europe<br />
reliable waste management, no matter how much material you generate<br />
recovery of elementary metals out of your slags in the highest possible<br />
quality<br />
extensive network – as a part of the REMONDIS Group, we can offer you<br />
a wide range of recycling and waste management solutions<br />
Address:<br />
Brunnenstraße 138, 44536 Lünen<br />
National:<br />
raphael.adamski@remondis.de / +49 2306 106 8237<br />
<strong>International</strong>:<br />
yannik.droste@remondis.de / +49 2306 106 8831<br />
Website: www.LEGRAN.de<br />
Service range: Reutilization of refractories and metallurgical slags,<br />
recovery of elementary metals<br />
CONTACT US!<br />
Concentrate on your core business and REMONDIS manages your by-products and waste!<br />
8
The new technical journal<br />
WE ACCOMPANY THE FUTURE OF<br />
THE INTERNATIONAL STEEL INDUSTRY<br />
steel production<br />
application technology<br />
innovation + management<br />
processing<br />
READ STEEL + TECHNOLOGY REGULARLY.<br />
SUBSCRIBE NOW AT WWW.DVS-MEDIA.EU/STAHL
SAND PREPARATION<br />
Exploiting new energy savings potentials<br />
Aerator for loosening the prepared sand. The sum of<br />
energy consumed by the various machines and equipment<br />
in a sand preparation facility makes sand preparation the<br />
number 2 energy-intensive area in a foundry – after the<br />
melting shop<br />
It’s about time to switch off …<br />
In foundries, the meltshop is the most energy-intensive area, immediately followed by<br />
sand preparation in most cases. With a reasonable effort up to 10 percent of energy can<br />
be saved in the sand preparation area.<br />
by Wolfgang Ernst, Braunschweig, Germany<br />
Photos: Eirich<br />
There are several reasons for<br />
foundries to implement energy-saving<br />
measures. They may<br />
want to improve their image by reducing<br />
their ecological footprint, or they<br />
may have committed themselves to continuous<br />
optimization as part of a certification<br />
to an ISO 50000 standard. But<br />
ultimately, the most important drivers<br />
for reducing energy consumption are<br />
cost reasons. Numerous foundries have<br />
already achieved significant savings in<br />
their meltshop, have replaced old air<br />
compressors and have changed all<br />
lamps to LED. With all this done, other<br />
areas of the foundry are now moving<br />
into the focus. In many green-sand<br />
foundries, the meltshop is the most<br />
energy-intensive area, immediately followed<br />
by sand preparation. Exemplary<br />
studies have identified an energy<br />
savings potential of up to 10 % in this<br />
area, achievable with a reasonable<br />
effort.<br />
There are two areas of interest that<br />
avail themselves as a starting point for<br />
the reduction of power consumption in<br />
sand preparation: on the one hand,<br />
the electric equipment, i.e. the motors<br />
and their power consumption at full<br />
load operation, and, on the other<br />
hand, the mode of operation, especially<br />
the idle mode, i.e. when all motors<br />
are on but no sand is being transported<br />
or processed. Below, we take a<br />
look at both areas. While we will only<br />
briefly explain the option of replacing<br />
existing motors with new-generation<br />
energy-saving motors, we will go more<br />
into detail describing the strategy of<br />
saving energy by temporarily switching<br />
off equipment when in idle mode,<br />
including the example of two foundries<br />
that have implemented this concept<br />
in practice.<br />
10
emergency stop – the machine can<br />
immediately resume full-load operation,<br />
minimizing the need for<br />
time-consuming manual emptying and<br />
the downtimes associated with it. This is<br />
a situation where the intention to save<br />
energy by using a smaller motor collides<br />
with the wish to be up and running as<br />
fast as possible after a failure.<br />
Figure 1: Intensive-mixing<br />
unit with energy-saving torque motors<br />
Use of energy-saving motors<br />
Typically, in the sand preparation area<br />
there are but a few energy-intensive<br />
systems: mixers (Figure 1), used-sand<br />
coolers (Figure 2), bucket conveyors and<br />
fans, for example. At full load, they use<br />
between 50 and 500 kW. Other systems,<br />
such as conveyor belts, worm conveyors<br />
and vibrators, operate with much less<br />
energy - starting at 1 kW and usually<br />
not exceeding a wattage rating of 5<br />
kW. Therefore, with a view to energy<br />
saving, they are only of little relevance:<br />
one mixer, for example, uses about the<br />
same energy as 20 belt conveyors. The<br />
technological fields of dedusting, compressed-air<br />
generation and hydraulics<br />
are not covered in this article.<br />
The last few years have seen intensive<br />
and successful efforts to make<br />
motors generally more energy-efficient.<br />
Meanwhile, there are already motors of<br />
Class 4 efficiency rating. The selection<br />
of the right motor deserves special<br />
attention. It is not as simple as replacing<br />
a 100-kW motor of the old design with<br />
a new-generation 100-kW motor. When<br />
selecting a new motor, an important<br />
aspect is efficiency. In order to achieve<br />
high efficiency, the electric power input<br />
should only be slightly higher than the<br />
mechanical power output. Efficiency<br />
(eta or ƞ) is defined as useful power<br />
output divided by the total electrical<br />
power consumed. The closer this quotient<br />
is to 1, the better (Figure 3).<br />
Getting the motor size right<br />
While the above in itself is not an easy<br />
task – because it is difficult to determine<br />
what amount of mechanical<br />
energy is actually needed –, there is<br />
another issue to be taken into account.<br />
This task is of a more conceptual<br />
nature, but not less challenging. Especially<br />
for production-critical high-power<br />
assets, such as mixers or coolers, there<br />
has always been a trend to use motors<br />
with a much higher power rating than<br />
needed for regular operation. The idea<br />
behind this is to ensure that – after an<br />
Figure 2: Intensive cooler with high-efficiency cooling system<br />
Purchase costs are almost negligible<br />
The idea of having to replace all motors<br />
in a sand preparation facility may scare<br />
foundry owners off due to the costs<br />
involved. Nevertheless, it may be<br />
worthwhile taking a closer look at the<br />
figures. Although the actual consumption<br />
of a motor depends on its age and<br />
design, manufacturers of energy-efficient<br />
motors see savings potentials of<br />
up to 40 %. If in doubt, have an electrician<br />
measure the consumption values<br />
for the various load cases for all three<br />
phases. Based on these measurements,<br />
you should discuss with a trustful motor<br />
supplier what savings may be realistically<br />
achievable. Also worthy of note is<br />
a cost analysis that breaks down the<br />
actual costs arising during the entire<br />
motor life. Figure 4 clearly shows that,<br />
when looking at the complete lifetime<br />
of a motor, the purchase price becomes<br />
virtually negligible, as it accounts for<br />
just about 1% of the total costs. The<br />
bulk of the expenses is accounted for by<br />
operational costs, in other words by the<br />
power input.<br />
Prioritizing the replacement<br />
of the motors<br />
Still, the capital investment involved<br />
may be deterring. However, if distribu-<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 11
SAND PREPARATION<br />
Figure 3: Motor efficiency<br />
Figure 4: Cost breakdown of a motor life<br />
ted over a longer period, the investment<br />
is easier to bear. The question is<br />
where to start. A suitable strategy for<br />
prioritization is to categorize the<br />
motors into four groups according to<br />
their age and their annual electricity<br />
consumption. Figure 5 illustrates this<br />
strategy: as an example, each one of<br />
the motors under discussion has been<br />
assigned to a position within one of the<br />
four quadrants of a coordinate system<br />
for better visualization. It is recommended<br />
to start with the older, high-power<br />
motors because their replacement will<br />
achieve the biggest individual savings.<br />
The most counter-productive<br />
cost drivers<br />
However, we do not want to leave<br />
unmentioned that the installation of an<br />
energy-efficient motor is not everything<br />
you need. A number of other investments<br />
may result, as for the frequency<br />
converter, for example. This instrument<br />
is needed to reduce the mechanical<br />
power output by reducing the electric<br />
power input via frequency variations.<br />
Quite often, grant and funding programs<br />
will only be approved if a frequency<br />
converter is installed. In literature,<br />
supply pumps are frequently<br />
mentioned as an example in this context.<br />
In the course of the day, these<br />
pumps supply varying flow rates and a<br />
frequency converter can continuously<br />
adjust the power of the pump to the<br />
capacity needed. However, this example<br />
is not generally transferrable to other<br />
machines and components. Conveyor<br />
belts and feeding screws, for example,<br />
have basically only two operating<br />
modes: “filled” or “empty”. Frequency-converter<br />
controlled operation does<br />
not really make sense here, especially,<br />
with a view to the follow-up costs. Frequency<br />
converters are quite big instruments,<br />
usually too big to be accommodated<br />
in existing control cabinets.<br />
Investments in new cabinets and major<br />
rebuilding efforts will be unavoidable.<br />
All motors of the conveying systems are<br />
equipped with an external cooling fan<br />
that is mechanically coupled with the<br />
drive shaft. This means that as soon as<br />
the rpm of the motor is reduced the fan<br />
will also run at lower power. To avoid<br />
this effect, the fan will have to be<br />
equipped with an additional, separate<br />
motor, requiring quite some installation<br />
effort. And, last but not least, the cabling<br />
will have to be renewed. As a result<br />
of the varying frequency, the power<br />
input of frequency-converter controlled<br />
motors causes the unwanted effect of<br />
electromagnetic interference (EMI) with<br />
the highly sensitive electronics. Usually,<br />
the only remedy against this is the installation<br />
of shielded cables. One last<br />
aspect shall be considered now: frequency<br />
converters, especially larger<br />
ones, release considerable heat. This<br />
may raise the temperature in the control<br />
cabinet to such an extent that the<br />
cabinets have to be fitted with cooling<br />
systems. These additional costs also<br />
need to be taken into account when<br />
considering the replacement of the<br />
motors. Therefore it is doubtful<br />
whether the sum of all these measures<br />
can still be considered energy-efficient.<br />
Reducing power input<br />
during idle runs<br />
While in the above described approach<br />
the idea is to install energy-efficient<br />
motors in order to achieve - with a<br />
smaller energy input - the same conveying<br />
and preparation rates, we are<br />
now going to explain an approach<br />
intended to avoid, wherever possible,<br />
power input during idle runs. A sand<br />
preparation plant will always be dimensioned<br />
allowing for extra capacity. In<br />
other words, it will be laid out to be<br />
able to process more sand than speci-<br />
12
fied to avoid downtimes in the foundry<br />
due to a lack of sand. Consequently<br />
there will be idle run phases in the sand<br />
preparation shop, particularly, in jobbing<br />
foundries where the sand requirements<br />
and the cycle times vary from casting<br />
to casting. However, this is not<br />
necessarily the biggest potential source<br />
for wasted energy. A central area of<br />
interest is the power consumption while<br />
the sand preparation equipment is<br />
being idled, during stoppages or other<br />
interruptions of production, for<br />
example. It may be a misconception,<br />
but the common practice in foundries is<br />
obviously to not switch the equipment<br />
off in such situations. Here, clarity can<br />
only be achieved by evaluating the<br />
savings potential based on the batch<br />
protocols. Given fixed cycle times, the<br />
distribution of idle times can be derived<br />
from the starting times of production<br />
for the individual batches (down to<br />
seconds). Figure 6 shows the results of<br />
an analysis covering almost a complete<br />
year. 72,182 charges were analyzed<br />
during that time – during 268 work<br />
days and 5,487 hours of operation. As<br />
the consumption of electric power per<br />
cycle was not documented, average<br />
values were assumed for the power<br />
Figure 5: Modernization strategy: upgrade to state-of-the-art high-efficiency<br />
motors<br />
consumed per cycle and during idle run<br />
phases. The chart shows the shares of<br />
energy consumption for idle times longer<br />
than five minutes and idle times<br />
longer than ten minutes. Just as remarkable<br />
is the relationship between<br />
energy consumption at full load and<br />
that during idle mode. Almost one third<br />
of the energy is consumed during<br />
idling. This analysis considers only the<br />
mixer, not the other sand preparation<br />
equipment.<br />
Power off saves energy<br />
The most obvious and simple measure<br />
therefore is: switch off whenever no<br />
sand is being conveyed or processed.<br />
But what about the justified concern<br />
that motors may suffer damage when<br />
being switched on and off too often.<br />
your Partner<br />
for turnKey Projects<br />
in no-bake moulding shops for:<br />
• moulding lines<br />
• continuous mixers<br />
• mechanical and thermal reclamations<br />
• chromite separations<br />
Smooth pneumatic conveying system for:<br />
• sand • bentonite • carbon • filter dust<br />
QuAliTY<br />
maDe In germany<br />
FAT Förder- und Anlagentechnik GmbH · D-57572 Niederfischbach · Tel. +49 (0) 27 34/5 09-0 · fat.info@f-a-t.de · www.f-a-t.de
SAND PREPARATION<br />
Company Mixer No. of batches 72,182<br />
Data from to Average batch weight 2,200 kg<br />
02.<strong>01</strong>.2<strong>01</strong>8 14.12.2<strong>01</strong>8 Working days 268<br />
Filter: nicht > 07:00 hh:mm Operating hours 5,465<br />
kWh per year<br />
750,000 kWh<br />
725,000 kWh<br />
700,000 kWh<br />
675,000 kWh<br />
650,000 kWh<br />
625,000 kWh<br />
600,000 kWh<br />
575,000 kWh<br />
550,000 kWh<br />
525,000 kWh<br />
500,000 kWh<br />
475,000 kWh<br />
450.000 kWh<br />
Figure 6: Total energy consumption<br />
Unfortunately, there are no reliable and<br />
comprehensive empirical values available<br />
to verify this. However, there is no<br />
arguing about the fact that when a frequency<br />
converter or soft starter is used<br />
the frequency of switching on and off is<br />
hardly an issue. On the other hand,<br />
even when switching a motor on and<br />
off via circuit breakers in the classical<br />
mode, the mechanical parts of the<br />
motor and the unit it propels are also<br />
subjected to stresses and wear. Therefore<br />
we have limited our examination<br />
to the two power-off periods compared<br />
in Figure 7: five minutes and more, and<br />
ten minutes and more. Not switching<br />
off the equipment during idle runs that<br />
are longer than five minutes would<br />
mean that 11.8 % - corresponding to an<br />
assumed 84,557 kWh – are wasted. For<br />
idle runs of ten minutes and more these<br />
Potential reduction in kWh per year by<br />
power-off of mixer<br />
> 1:00 and < 7:00 h:mm; 71.866<br />
> 0:30 and < 1:00 h:mm; 13.105<br />
> 20 and < 30 min. ; 5.527<br />
> 10 and < 20 min. ; 13.952<br />
> 08 and < 10 min.; 7.520<br />
> 06 and < 08 min. ; 14.173<br />
> 05 and < 06 min. ; 13.344<br />
> 04 and < 05 min. ; 14.251<br />
> 03 and < 04 min.; 14.199<br />
> 02 and < 03 min.; 10.197<br />
> 00 and < 02 min.; 45.906<br />
figures would even increase to 16.7 %,<br />
or 119,591 kWh. The essential results<br />
from this analysis are summarized in<br />
Figure 8. The most salient result is the<br />
potential savings of 15 % of the total<br />
energy consumption. Other key information<br />
can be derived from the parameter<br />
kWh per t of molding sand. This<br />
ratio should stay – given an intelligently<br />
programmed sand preparation process<br />
- more or less the same independent of<br />
the throughput rate. Two foundries<br />
have already implemented this concept<br />
of switching equipment off when in<br />
idle mode, while achieving the same<br />
throughput. In one case, the concept<br />
was practiced in a larger-scale sand preparation<br />
shop using two mixers. The bar<br />
chart in Figure 9 represents as an<br />
example a 24-hour period. The facility is<br />
operated for 18 hours, the mixer can<br />
handle a maximum batch size of 2,200<br />
kg. Over the period shown, the hourly<br />
sand rate varied between 42.6 and<br />
97.3 t. The black curve plotted over the<br />
blue “sand columns” represents the –<br />
naturally varying – electric power<br />
consumed by the complete dosing and<br />
mixing line. The turquoise straight line<br />
represents the parameter kWh/t, which<br />
is slightly below 5.5 kWh in this case.<br />
This parameter is a simple means to<br />
visually verify the efficiency of operation.<br />
The actual energy consumption in<br />
kWh per tonne of molding sand is plotted<br />
as the dark green curve. Even in the<br />
case of a smaller aluminium foundry<br />
with a mixer capacity of only 250 kg this<br />
parameter is at approx. 3.5 kWh per<br />
tonne of sand.<br />
Implementation strategy<br />
Unlike the strategy of installing new<br />
energy-efficient motors, the strategy<br />
“power off during idle runs” requires<br />
minimum hardware. It is rather a new<br />
approach to control. This involves the<br />
development of algorithms that avoid<br />
constant switching of the motors. The<br />
aim is to be able to anticipate when the<br />
mixer is going to discharge a batch,<br />
whether it is going to need additional<br />
sand or whether there may be a waiting<br />
period of a few minutes. This requires<br />
very close communication with the molding<br />
line, which determines how much<br />
sand is actually needed. For the sand<br />
preparation shop it is essential to receive<br />
as soon as possible all relevant information<br />
about a stop or failure of the molding<br />
line, whether it is running smoothly<br />
and when it may be needing new sand.<br />
As a further area of modification, the<br />
filling control of the sand hoppers was<br />
adapted. Conventional control systems<br />
work on the principle that new sand is<br />
immediately supplied as the filling level<br />
comes below a defined “full” limit. It<br />
often turns out that sand is being supplied<br />
sooner than actually necessary. This<br />
can be avoided by a hysteretic control, in<br />
other words a delayed effect based on<br />
variable full-level signals. Therefore, the<br />
existing limit-value controllers were<br />
replaced with analogue fill-level signals<br />
(0 – 100 %). They enable fine-tuned setting<br />
of the switching thresholds via a<br />
menu with the aim to achieve longer<br />
non-active times and longer, cohering<br />
filling times. In the case of the aluminium<br />
foundry with a total of seven sand<br />
hoppers, an even more sophisticated filling<br />
scheme was implemented by designing<br />
a hysteretic control that provides<br />
even more flexibility. There are situa-<br />
14
Your Key to<br />
Deciders<br />
CASTING<br />
PLANT AND TECHNOLOGY<br />
INTERNATIONAL<br />
THE KEY TO CASTING INDUSTRY SUPPLIERS GUIDE<br />
Your advantages:<br />
4 x in CASTING PLANT AND<br />
TECHNOLOGY INTERNATIONAL<br />
1 year online<br />
Complete company address including<br />
e-mail and homepage<br />
Your entry on www.keytocasting.com<br />
with a link to your homepage<br />
Your company logo on<br />
www.keytocasting.com as well as<br />
in the magazines<br />
Fast & easy search function on<br />
www.keytocasting.com<br />
NOW ONLINE<br />
Circulation: 5,000 copies<br />
Frequency: 4 per annum<br />
Language: English<br />
Your contact persons:<br />
DVS Media GmbH • Aachener Straße 172 • 40223 Düsseldorf<br />
P +49 2 11 15 91-152 • P +49 2 11 15 91-155 • F +49 211 15 91-150<br />
vanessa.wollstein@dvs-media.info • britta.wingartz@dvs-media.info • www.giesserei.eu
SAND PREPARATION<br />
No. of power-offs: 5792 No. of power-offs: 1543<br />
Power-offs/shi:<br />
8,5 Power-offs/shi:<br />
2,3<br />
kWh per year<br />
750,000 kWh<br />
725,000 kWh<br />
Potenal reducon in kWh per year by power-off<br />
of mixer 1 during all idle runs > 5 minutes,<br />
based on an idle-me predicon model<br />
kWh per year<br />
750,000 kWh<br />
725,000 kWh<br />
Potenal reducon in kWh per year by power-off<br />
of mixer 1 during all idle runs > 10 minutes,<br />
based on an idle-me predicon model<br />
700,000 kWh<br />
700,000 kWh<br />
675,000 kWh<br />
650,000 kWh<br />
625,000 kWh<br />
Idle mes > 5 min<br />
139.488 kWh<br />
19,5%<br />
675,000 kWh<br />
650,000 kWh<br />
625,000 kWh<br />
Idle mes > 10 min<br />
104.450 kWh<br />
14,6%<br />
600,000 kWh<br />
600,000 kWh<br />
575,000 kWh<br />
575,000 kWh<br />
550,000 kWh<br />
525,000 kWh<br />
Sum of other idle mes<br />
84.554 kWh<br />
11,8%<br />
550,000 kWh<br />
525,000 kWh<br />
Sum of other idle mes<br />
119.591 kWh<br />
16,8%<br />
500,000 kWh<br />
500,000 kWh<br />
475,000 kWh<br />
475,000 kWh<br />
Figure 7: Decrease in kWh/year achieved by power-off times of 5 minutes and more versus power-off times of 10 minutes and more<br />
tions in the foundry where a hopper is<br />
being filled and the mixer is stopped<br />
immediately after completion of the<br />
batch, just to be switched on again a<br />
few seconds later when the next hopper<br />
signals that it needs sand. To avoid this<br />
constant switching, the following control<br />
scheme has been implemented:<br />
When a new batch is started, the system<br />
triggers a response from all the hoppers<br />
as to their sand requirements. The trigger<br />
level of all hoppers has been raised<br />
in order to know not only the current<br />
but also the imminent sand requirements.<br />
Thus the mixer will not be switched<br />
off immediately as the current<br />
demand has been fulfilled but will continue<br />
producing in advance for the other<br />
hoppers. The next step towards an even<br />
more sophisticated control will be to<br />
derive the switching thresholds from the<br />
order data. This would enable the control<br />
system to adjust even more precisely<br />
to varying cycle times and sand requirements<br />
of the molding boxes. This will<br />
make it possible to plan the sand requirements<br />
and the mixer throughput in<br />
such a way that power-off times are<br />
maximized. Thus, control algorithms that<br />
would hold the complete sand preparation<br />
facilities in stand-by, waiting to<br />
immediately restart when the filling<br />
level drops below the “full” limit, have<br />
become a thing of the past.<br />
Company<br />
Date<br />
Date<br />
Working days<br />
Weeks<br />
1st batch<br />
last batch<br />
(actual)<br />
(period)<br />
Summary<br />
We have introduced two strategies to<br />
achieve energy-efficient sand preparation:<br />
on the one hand, a hardware<br />
upgrade by replacing older motors with<br />
02.<strong>01</strong>.2<strong>01</strong>8 Batches total 72,183<br />
14.12.2<strong>01</strong>8 Shi 06:00 - 14:00 31,632<br />
268 Shi 14:00 - 22:00 29,<strong>01</strong>7<br />
49 Shi 22:00 - 06:00 11,534<br />
Moulding sand producon<br />
Average batch size 2,200 Kg per day per year<br />
During period considered 158,803 t 593 t 158,803 t<br />
Energy consumpon<br />
Per year<br />
715,469 kWh<br />
Thereof for producon 489,782 kWh<br />
Thereof for idle mode<br />
225,688 kWh<br />
Idle mes not longer than: > 08:00 hh:mm resulng power-offs<br />
Savings potenal 2 106,097 kWh Total number No./shi<br />
(all idle mes > 10 minutes) 14.8% 1,546 2.3<br />
Savings potenal 1<br />
141.134 kWh<br />
(all idle mes > 5 minutes) 19.7% 5,795 8.4<br />
Parameters<br />
kWh per tonne of sand<br />
Mixer 1<br />
4.51 kWh/t Current situaon<br />
kWh per tonne of sand 3.84 kWh/t for savings potenal 2<br />
Savings potenal (per year)<br />
106,097 kWh<br />
Savings pot. (with 0.14 € per kWh) 14,854 €<br />
Figure 8: Summary of analysis of potentials<br />
new energy-efficient motors and, on<br />
the other hand, modification of the<br />
motor control with the aim to switch<br />
the sand preparation equipment as<br />
often as possible into power-off during<br />
16
Figure 9: Implementation of an energy-efficiency enhancing strategy in a larger-scale sand preparation facility using two mixers<br />
idle runs. The parameter kWh/t can<br />
serve as a measure of the consistency of<br />
operation. Ideally, this value will not<br />
change even if the hourly throughput<br />
rate varies. Whether in full-load operation<br />
or in slow “stop-and-go” operation<br />
– the energy consumption for one<br />
tonne of sand remains the same<br />
because during idle run the sand preparation<br />
equipment will be in power-off<br />
mode. The main objective – and the<br />
main challenge – here is to coordinate<br />
and adjust the operation of the mixer<br />
to the hopper filling requirements,<br />
taking into consideration not just the<br />
immediate demand but also the next<br />
following molding jobs. To achieve this,<br />
it is essential that the operating status<br />
of the molding line be signalled to the<br />
mixers without delay and that the sand<br />
hoppers be equipped with analogue<br />
fill-level measuring devices. The latter<br />
are needed to be able to implement a<br />
flexible hysteresis-based sand requesting<br />
scheme. While some experience<br />
gained during practical operation may<br />
help in the set-up, there is yet no standard<br />
solution available that would fit<br />
every sand preparation scenario. It is<br />
recommended to determine the to be<br />
expected savings by means of an analysis<br />
of potentials prior to the implementation.<br />
However, care should be taken<br />
when financial jugglers try to create the<br />
illusionary prospects of ROI-periods of<br />
less than one year. Such short pay-back<br />
periods are only feasible in situations<br />
where no investments have been made<br />
for many years and the machines would<br />
be good for exhibits in a museum.<br />
www.datecgmbh.de<br />
Wolfgang Ernst, Managing Director of<br />
datec GmbH, Braunschweig, Germany<br />
ONLINE AUCTION<br />
HIGH QUALITY CASTING PARTS FOUNDRY MACHINERY - STADE (DE)<br />
including induction furnace equipment, molding sand mixers, casting ladles, compressor and filter equipment, transformers, metalworking<br />
machines such as milling machines and lathes, bridge cranes, molding boxes, substations and much more.<br />
WWW.TROOSTWIJKAUCTIONS.COM<br />
CLOSING: Tuesday 30 March - VIEWING: Wednesday 24 March by appointment<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 17
MOLDMAKING<br />
Photos: Voxeljet<br />
3-D-printing<br />
With simulation to<br />
substitution as cast part<br />
During mechanical reworking<br />
the optimized bogey chassis<br />
slowly takes on its final shape<br />
Agricultural machinery manufacturer Amazone uses simulation software<br />
by Altair and 3-D printing from voxeljet to optimize a bogey chassis.<br />
By Frederick von Saldern, Friedberg<br />
The German agricultural machinery<br />
manufacturer Amazone was able<br />
to save 18 percent in weight<br />
when producing a prototype for a new<br />
bogey chassis. This was possible because<br />
the family business from Hasbergen,<br />
near Osnabrück in Germany, was able<br />
to print the sand-casting molds and<br />
cores for the casting without special<br />
tools and using just a CAD file. The<br />
company used the world’s largest industrial<br />
3-D printer for sand-casting molds,<br />
the VX4000 by voxeljet from Augsburg,<br />
Germany.<br />
There is unrelenting progress in the<br />
evolution of harrows, which farmers<br />
drag along the ground with a tractor to<br />
break up the soil and prepare it for<br />
sowing seeds. Manufacturers are constantly<br />
striving to make the equipment<br />
more stable, durable and also lighter in<br />
order to, for example, adhere to the<br />
permitted axle loads when driving on<br />
the road. Among them is the family<br />
business Amazone, which produces the<br />
Catros compact disc harrow with a<br />
bogey chassis. This is a towed device<br />
which is fixed to a tractor and can be<br />
used in different configurations. The<br />
compact disc harrow is used for shallow<br />
and intensive soil cultivation for a working<br />
depth of up to 15 centimeters.<br />
The CAD software creates a cast<br />
design according to a lightweight<br />
construction<br />
The bogey chassis connects the device<br />
to the axle to enable the device to be<br />
transported from the farm to the field.<br />
The original welded construction had a<br />
weight of 245 kilograms and a welding<br />
seam length of 16.5 metres, making it<br />
18
A part of the<br />
3-D-printed casting<br />
mold made of<br />
quartz sand, is cleaned<br />
and inspected<br />
after printing.<br />
RESOURCE-FRIENDLY INTO<br />
THE FUTURE –<br />
HWS systems for sand reclamation.<br />
• Highly efficient, flexible process<br />
• Customized concepts<br />
• Automated solutions<br />
• No environmental requirements for the<br />
reclamation unit<br />
• Own reclamation test center available<br />
very complex and production-intensive. In order to reduce<br />
costs and make the component more stable and lighter,<br />
Amazone decided to replace the bogey chassis with a cast<br />
component. Using the topology optimisation software<br />
“Inspire” by Altair, the Amazone development team was<br />
able to create a design that was suitable for the load and<br />
could also be cast.<br />
Considerably lighter, more<br />
stable and more durable<br />
Due to the materials being distributed in a manner suitable<br />
for the amount of force, the cast bogey chassis is over<br />
45 kilograms lighter than the welded component. With<br />
this saving in weight, the shape is reminiscent of tree<br />
structure or bird bones. At the same time, the new design<br />
ensures a 272 percent longer service life, because the<br />
design avoids the variations in rigidity in the cast component<br />
compared to the welding component. In order to<br />
guarantee the material quality, the ex-perts at Altair have<br />
also simulated the flow of metal during the casting process<br />
with the Inspire software. In this way, they were able<br />
to reduce the risk of internal defects caused by trapped<br />
gases before the actual casting process, and therefore<br />
optimize the quality of cast parts. Sebastian Kluge from<br />
Amazone says: “Thanks to the optimized design of the<br />
cast construction which is suitable for the load, for the<br />
third evolution stage of the rear swing arm, it was possible<br />
to increase the service life by 2.5 times whilst also<br />
reducing the weight by approx. 18 % compared to the<br />
welding component. The creation of the sand-casting<br />
mold using 3-D printing makes it possible to quickly<br />
source prototype components and therefore significantly<br />
reduce development times.<br />
Saving time with 3-D printing<br />
Before sand reclamation<br />
After sand reclamation<br />
www.sinto.com<br />
Manufacturing casting molds for such a complex component<br />
is generally time-consuming – partly because complex<br />
specialist tools are required. For this reason, Altair<br />
re-thought the options and decided to use the VX4000 by<br />
voxeljet – a 3-D printing system with an installation space<br />
of 4000 x 2000 x 1000 millimetres. “This is the largest<br />
HEINRICH WAGNER SINTO<br />
Maschinenfabrik GmbH<br />
SINTOKOGIO GROUP<br />
Bahnhofstr.1<strong>01</strong> · 57334 Bad Laasphe, Germany<br />
Phone +49 2752 / 907 0 · Fax +49 2752 / 907 280<br />
www.wagner-sinto.de<br />
HWS Anz 85x260 USR-II GB_<strong>2021</strong>_RZ.indd 1 <strong>01</strong>.03.<strong>2021</strong> 17:31:35<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 19
MOLDMAKING<br />
industrial 3-D printer in the world for<br />
sand-casting molds”, says Tobias King,<br />
Director Marketing & Application at<br />
voxeljet. “Because the complexity of the<br />
component does not affect the cost of<br />
the 3-D printing, even difficult geometric<br />
shapes can be created at a low cost.”<br />
For complex structures: Design<br />
freedom and 300 dpi resolution<br />
with the 3-D printer<br />
First of all, voxeljet converted the CAD<br />
file of the component into a negative<br />
CAD file to digitally represent the fourpart<br />
casting mold. The workers then fed<br />
this data into the 3-D system. Then the<br />
printing began. Here, a so-called coater<br />
spreads the printing material (quartz<br />
sand) onto the construction platform.<br />
Then the print head moves over the<br />
platform and binds the grains of sand<br />
together with a binding agent – depending<br />
on the geometry of the object in<br />
the CAD file. For this, the print head<br />
works with a resolution of 300 dpi.<br />
While the construction platform itself<br />
remains static, the coater and print<br />
head move their working height gradually<br />
upwards by 300 micrometres until<br />
the casting mold is complete.<br />
Once the printing procedure has<br />
finished, the workers remove the side<br />
walls of the construction platform that<br />
were printed with the component and<br />
remove any misprinted quartz sand. This<br />
leaves the casting mold, which can be<br />
used straight away. The foundry (Pro<br />
The completed casting mold made from<br />
quartz sand appears at Pro Cast Guss.<br />
The foundry in Gütersloh is responsible<br />
for casting the bogey chassis.<br />
After the workers have removed the<br />
casting mold, the bogey chassis emerges,<br />
including risers.<br />
Cast Guss from Gütersloh) gives the casting<br />
mold just one coating – the barrier<br />
layer between sand and metal, which<br />
protects the casting mold from thermal<br />
stress. Despite all of this, the shape is lost<br />
after the casting – just as with traditional<br />
casting molds (sand-casting molds). It<br />
is destroyed after the core of the cast<br />
bogey chassis is removed. Thanks to the<br />
previous Click2Cast computer simulation<br />
for casting, the cast material flows perfectly<br />
into the original size the first time.<br />
Frederick von Saldern,<br />
voxeljet AG, Friedberg<br />
www.voxeljet.de<br />
20
CORE COATING<br />
Quality Assurance<br />
Coating a core at SLR in one of the new<br />
modernized coating dip tanks.<br />
Ensuring quality by utilizing<br />
efficient process technology<br />
The SLR Group is investing with the aim to optimize its cold box core coating process.<br />
Utilizing the „Arena All-in-One“ dip tanks from the Italian company Proservice s.r.l.,<br />
repeatability, cleanliness, safety, maintenance frequency and power consumption have<br />
all been improved. Thereby, contributing to improving the core quality within a reasonable<br />
payback period for the investment.<br />
by Gianni Segreto, Borgoricco, Italiy<br />
Photo: SLR Group<br />
The SLR Group in Germany produces<br />
over 130,000 tons of<br />
machine parts from high-quality<br />
nodular cast iron (GJS). The foundry in<br />
St. Leon-Rot (parent plant and<br />
headquarters of the SLR group) was<br />
founded in 1981. One production site is<br />
located at St. Leon-Rot near Heidelberg.<br />
Another foundry location is Elsterheide<br />
near Dresden. There is a machining/<br />
assembly shop in Hungary, while the<br />
pattern shop is located at the company<br />
site Eging near Passau.<br />
Process optimization, costs reduction<br />
and research for innovative solutions<br />
have always been the basis of the philosophy<br />
for the SLR group. The two<br />
foundries in the group have therefore<br />
invested in equipment for the control<br />
of coating filtration as well as the control<br />
and application of alcohol-based<br />
coating of cold box cores.<br />
As with many other foundries, this<br />
part of the foundry process has not<br />
been automated.<br />
The application of core coating is a<br />
delicate part of the process and has<br />
been associated with defects in the<br />
final castings which create hidden<br />
costs.<br />
The cores are finished by immersion<br />
with lifting gear or manually by the<br />
operator working at each core shooter,<br />
where the cores from 0.5 to 80 kg (for<br />
Leon Rot) and from 0.5 to 300 kg (for<br />
Elsterheide) are produced.<br />
Very ambitious goals were set from<br />
the beginning of the project. On the<br />
one hand, it was a matter of controlling<br />
the varying wet layer thickness of the<br />
core coating, as well as controlling the<br />
problems associated with the core dipping<br />
duration. In addition, the cleaning<br />
and filtration costs of the core coating<br />
were to be reduced, as well as reducing<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 21
Dense coating and<br />
alcohol storage area,<br />
separated from the<br />
work area.<br />
the alcohol emissions into the environment.<br />
The design and installation was to<br />
be a turnkey supply, performed by a<br />
single supplier, with a storage area for<br />
the undiluted coating and the alcohol<br />
supply to be separated from the actual<br />
work area, as per instructions from Martin<br />
Scherz, the managing director of SLR<br />
foundry St. Leon-Rot.<br />
From the goals to the solutions<br />
ProserviceTech of Borgoricco Italy, had<br />
taken on this challenge. The company<br />
analyzed the process in every single<br />
step to understand how to punctually<br />
achieve the targets set by the customer.<br />
Thus, together with the customer it<br />
identified some safe areas where to<br />
install a plant for the storage of the<br />
dense coating and alcohol containers,<br />
this plant was to feed to each individual<br />
core coating tank. In this phase every<br />
detail was considered, from the safety<br />
(being an Atex area) to the automatic<br />
pre-mixing and pre-dilution of the<br />
dense core coating. The reason was to<br />
make it easier mixing and pumping<br />
through the piping (including the supply<br />
pipe), and to manage the mixers for<br />
the containers of dense core coating as<br />
well as the control of the alcohol and<br />
dense core coating levels.<br />
The following pictures show the storage<br />
area, the pipelines where the alcohol<br />
and the dense coating intermittently<br />
circulate safely, and the various coating<br />
tanks positioned in the foundry on two<br />
floors in St. Leon Rot and on only on<br />
one floor for the Elsterheide line.<br />
Goal: constant quality advance<br />
Once that the storage and the supply of<br />
the dense coating and the alcohol were<br />
Vibro-filter, which<br />
filters the coating<br />
through a sieve<br />
which removes sand<br />
particles.<br />
stabilized and optimized, the focus was<br />
placed on each individual coating dipping<br />
tank. Means of choice in this case<br />
and at this time was the Arena All-in-<br />
One series advanced dipping tanks,<br />
which collect from a centralized unit,<br />
the automatically controlled mixed and<br />
prepared coating and kept the coating<br />
at a constant level. In fact, each coating<br />
tank is equipped with a storage tank,<br />
where the coating is continuously controlled<br />
by means of the Density Sentinel.<br />
The automatic supply of dense coating<br />
and alcohol, as well as the ability to set<br />
fixed density targets for each unit in<br />
which the coating density needs to be<br />
maintained. Each coating tank is interconnected<br />
through its own network<br />
with the other units, but also with the<br />
storage area. The advantages of the<br />
Arena All-in-One solution is that the<br />
coating does not settle and the power<br />
consumption is thereby optimized.<br />
Mr. Christian Zouplna, Foundry<br />
manager: “After approximately a year<br />
of use, we already are able to measure<br />
the achieved benefits. Before installing<br />
Arena All-in-One, even if we manually<br />
controlled the coating up to 10 times<br />
per day, for each coating tank with the<br />
related corrections, the wet layer thickness<br />
of the coating before drying still<br />
had a deviation of +/- 25 µm almost<br />
daily. With the “Arena All-in-One” we<br />
were able to reduce the deviation by<br />
approx. 70 %, even if there was still a<br />
residual deviation, which is mainly due<br />
to the manual operation of core dipping.<br />
The current tolerance range is<br />
from -10 µm to + 5 µm. The resulted in<br />
more consistent repeatability and a considerable<br />
reduction in quality control<br />
problems of the cores in the<br />
downstream processing area with the<br />
associated rejects or corrective measures<br />
on the cores.<br />
22
CORE COATING<br />
Another coating dip<br />
tank. In St. Leon-Rot<br />
the dip tanks are<br />
located on two floors,<br />
while in Elsterheide<br />
on one floor.<br />
Minimized maintenance.<br />
Where the coatings are used, usually<br />
there are three words: cleanliness, manpower<br />
and spare parts. The cleanliness<br />
seems to be a condition accepted as a<br />
divine punishment universally associated<br />
with the use of refractory core coatings.<br />
For example, every week SLR had to<br />
drain all the coating tanks and manually<br />
removal the residual coating sediment<br />
and core sand. These operations required<br />
a lot of manpower (up to one hour<br />
for each coating tank every week) and a<br />
consequential waste of coating and solvent<br />
due to the inefficient mixing. (to<br />
reject sedimented coating means to pay<br />
the coating twice: once when purchased<br />
and again for the special disposal as a<br />
dangerous material).<br />
In all the coating tanks at SLR, ProserviceTech<br />
has introduced solutions<br />
that have almost canceled all of these<br />
costs. Thanks to the use of a system<br />
with static filters on each tank and of<br />
the innovative Arena Vibro-filter, a portable<br />
vibrating unit which allows for<br />
the filtration of the sand from the coating<br />
in few minutes without interrupting<br />
the production. The operations of<br />
the weekly process of emptying and cleaning<br />
are something of the past. They<br />
are now performed in the two annual<br />
stoppages. Arena Vibro-filter is moved<br />
from one tank to the other only as and<br />
when required, almost completely eliminating<br />
the presence of sand and<br />
dried coating pieces in the core coating.<br />
Consequently, eliminating the common<br />
defects of sand inclusions and coating<br />
lumps in the castings.<br />
A diaphragm pump is usually required<br />
to achieve a constant level within<br />
the dipping tank. The installation of a<br />
diaphragm pump is usually fraught with<br />
many problems: noise, considerable<br />
consumption of spare parts, energy<br />
usage (compressed air) and manpower<br />
for its maintenance.<br />
The Arena E-pump has consistently<br />
maintained a constant coating level for<br />
more than two years, (the original<br />
pump is still working) with an operational<br />
life that has already exceeded 8,200<br />
hours. Without requiring any maintenance<br />
or any spare parts. With a noise<br />
level of 55 dB while the pump is working,<br />
is like a quiet conversation and<br />
with huge energy savings. Therefore, it<br />
is not a surprise that in similar conditions<br />
and when only considering the<br />
energy costs, the E-pump allows a payback<br />
period of less than a year, when<br />
compared to a traditional diaphragm<br />
pump.<br />
Safety first.<br />
The use of alcohol based coatings imposes<br />
some very strict safety procedures,<br />
related to and governed by the relevant<br />
ATEX certification. To design and to certify<br />
with ATEX is not simple, especially<br />
in foundries with existing equipment.<br />
After the implementation of the system,<br />
the alcohol consumption has been<br />
reduced by up to 3 %. This is thanks to<br />
the system‘s new circulation/mixing<br />
technology.<br />
Moreover, by eliminating the cleaning<br />
operations (the removal of the<br />
coating sediment and the sand), the<br />
new system of coating mixing and circulation,<br />
as well as the installation of alcohol<br />
fume detection, has resulted to a<br />
remarkable reduction of the alcohol dispersion<br />
within the work environment.<br />
Which has considerably improved the<br />
MAK (Maximum Workplace Concentration)<br />
index.<br />
Now, operators who came into contact<br />
with the coating are no longer<br />
required for the manual dipping, including<br />
the cleaning as well as the dilution<br />
and control of the coating. Regarding<br />
this, Mr. Zouplna (Foundry manager,<br />
SLR St. Leon-Rot) has commented: “The<br />
preparation, the density control, the<br />
dense coating dilution with alcohol and<br />
the transportation of the alcohol and<br />
coating containers to each individual<br />
tank introduced some safety problems<br />
(which were related to the logistics and<br />
contact with the coating that is no longer<br />
required for the coating operation)<br />
and also a manpower cost saving. We<br />
had one person dedicated for 3 to 4<br />
hours/day for these operations, who can<br />
now be employed for other activities”.<br />
Mr. Scherz ends: “The low payback<br />
time allowed us to purchase two additional<br />
All-in-One units. Installation was<br />
done in July 2020 for a different area in<br />
the core shop, with the aim to replace<br />
all the other existing coating tanks in<br />
the group’s two foundries, in the next<br />
few years”.<br />
www.slr-gruppe.de<br />
Eng. Gianni Segreto, Proservice Technology,<br />
Borgoricco, Italy, assisted by Birgit<br />
Wagner, James Durrans GmbH, Willich<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 23
AUTOMATIC POURING<br />
24
Unheated pouring ladle<br />
„The new application improves working<br />
conditions, reduces production costs and<br />
paves the way for further AI applications“<br />
AI-operator in foundries<br />
Once a vision, now reality<br />
In the past years many articles have been published about “The Internet of Things” (IoT),<br />
Foundry 4.0, Artificial Intelligence (AI) and the potential of its use in foundries. Interesting<br />
R&D strategies have been explained but results about the implementation in foundries<br />
have seldom been presented. The article describes the development and experiences<br />
with Artificial Intelligence at pour-tech AB, a specialist in automatic pouring and software<br />
solutions. The company develops new integrated systems with fully automated<br />
pouring controls based on a combination of laser and camera technology.<br />
By Michael Colditz, Sävedalen, Sweden<br />
Every day, foundries are faced with<br />
loss of knowledge due to the<br />
retirement of experienced operators<br />
and the difficulty of replacing them<br />
with new talent, An automated pouring<br />
system – requiring very little operator<br />
intervention – is needed now more than<br />
ever.<br />
Based on the experiences with automation<br />
and the active use of the collected<br />
information in its data base Pourtech<br />
AB, Sävedalen, Sweden, has<br />
created a solution for artificial intelligence<br />
called EASYpour.<br />
Photo: Pour-tech AB<br />
At first a number of challenges were<br />
identified by the development team, as<br />
the process conditions are continuously<br />
changing due to, among other things:<br />
> Imperfect molds<br />
> Slag in the liquid iron<br />
> Bath level variations<br />
> Temperature changes.<br />
While aiming for minimal operator<br />
interference, the team was also focusing<br />
on improving the casting quality<br />
and increasing the line productivity. In<br />
this context it had the values for its customers<br />
in focus, so for example:<br />
> Less manual work<br />
Figure 1: Bottom stopper laser pouring at a vertical molding line<br />
> Allowing the operator to focus more<br />
on quality checks, preparation of<br />
further batches, taking samples etc.<br />
> Increased product quality due to<br />
continuous improvements by the<br />
developed algorithm<br />
> Shorter line cycle times<br />
> Less production costs<br />
> Continuous logging of the pouring<br />
quality, evaluated in real time and<br />
associated with each individual castings<br />
in order to ensure traceability.<br />
The development of the algorithm was<br />
one part of the task, the other part was<br />
finding the right selection of processes<br />
needed for the reliable operation of<br />
EASYpour (Figure 1).<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 25
AUTOMATIC POURING<br />
Figure 2: Channel type furnace<br />
Figure 3: Coreless press pour furnace<br />
Suitable foundry systems<br />
The following vessels and devices, in<br />
combination with stopper and nozzles<br />
are state of the art pouring units:<br />
> Unheated pouring ladles (see page<br />
24) are, because of their flexibility and<br />
many other advantages, used in a great<br />
number of foundries worldwide.<br />
> Channel type furnaces (Figure 2) for<br />
the production with single grades of<br />
iron – with only small chemistry variations.<br />
A complete change of iron grade<br />
is of course possible, but laborious and<br />
time consuming. If covered with inert<br />
gas, fading of Magnesia will be reduced.<br />
> Coreless press pour systems (Figure 3)<br />
known for high flexibility and less<br />
time-consuming iron grade changes,<br />
exact control of pouring temperature<br />
and the resistance to thermal shocks. If<br />
covered with inert gas, fading of Magnesia<br />
will be reduced.<br />
> Foundry specific pouring units<br />
designed in-house using stopper rods<br />
and nozzles (Figure 4).<br />
Unheated pouring vessels<br />
Compared to pouring furnaces,<br />
unheated pouring systems (Figure 5) are<br />
lower in weight and can therefore be<br />
equipped with pancake load cells to<br />
monitor the liquid iron content inside<br />
the ladle. Unheated bottom pour solutions<br />
are common for continuous and<br />
steady production where stable refilling<br />
of the vessel is possible.<br />
A constant flow rate of iron is provided<br />
thanks to a special software,<br />
which compensates for the changing<br />
ferrostatic pressure by adjusting the<br />
pouring parameters, also in the case of<br />
a fast-ris ing iron level during refill.<br />
A slag dam in the center of the<br />
pouring vessel is separating the filling<br />
from the pouring section. Because of its<br />
lower specific density, the slag will float<br />
up and the dam keeps it in the filling<br />
section, while the clean melt flows<br />
under the dam into the pouring section,<br />
reducing filling turbulence.<br />
Compared to pouring with a hand<br />
ladle, which is still very common, the<br />
risk of slag entering the mold is very<br />
much reduced. At the same time, the<br />
yield can be improved, since the<br />
required pour cup is only 2.5 times the<br />
size of the pouring nozzle and all metal<br />
that is transferred to the vessel can be<br />
poured (no remaining heel as in a hand<br />
ladle).<br />
The system is designed for a short<br />
residence time of the liquid iron in the<br />
vessel. This has a very beneficial effect<br />
on iron alloy changes and the production<br />
of nodular iron castings.<br />
The pouring vessel is designed so<br />
that 70 % of the content is poured off<br />
within seven to ten minutes. Conversely,<br />
the tub is refilled six to eight times an<br />
hour. This allows the temperature loss<br />
and the Mg fading to be controlled in a<br />
targeted manner.<br />
The pouring vessel can be refilled<br />
manually or automatically with a<br />
skip-system (Figure 6).<br />
An order is currently being processed<br />
on an automatic tight flask line.<br />
A transport ladle hangs on an automatic<br />
crane and transports the ladle,<br />
filled at the melt shop, to the treatment<br />
and later to the de-slagging station.<br />
The transfer ladle is then placed on such<br />
a skip and locked in. One operator per<br />
shift is expected for the entire process,<br />
including pouring.<br />
FORCEpour system<br />
Especially with vertically parted molding<br />
lines, the cycle time is mainly determined<br />
by the pour time, even with<br />
moderate pour weights. In order to<br />
fully utilize the stoppage time of the<br />
mold string for the pouring process, the<br />
26
Figure 4: Tailormade system<br />
optimization by FORCEpour was developed.<br />
With FORCEpour, the stopper starts<br />
to open while the mold string is still in<br />
motion, as soon as the pouring cup<br />
reaches the pouring zone and the outermost<br />
edge of the cup is recognized by<br />
the upstream positioning laser. The<br />
pour is therefore started before the end<br />
of the index, and timed such that the<br />
first iron just hits the pour cup.<br />
This allows a few tenths of a second<br />
to be saved with every single cycle. For<br />
a molding line operating at 500 molds<br />
per hour, each 0.1 second of pre-start<br />
generates 7 more molds per hour. A<br />
vertical molding line at a French<br />
foundry is currently producing 580<br />
molds per hour with a laser based pouring<br />
system featuring FORCEpour.<br />
FORCEpour is an addition tool for<br />
optimizing the process, especially in<br />
connection with artificial intelligence.<br />
Pouring temperature<br />
The verifiable pouring temperature for<br />
each individual mold is important for<br />
quality control. This is why the temperature<br />
is measured with a pyrometer as it<br />
Figure 5: Unheated pouring vessel<br />
exits the pouring nozzle and is recorded<br />
in the data base.<br />
To calibrate the pyrometer, it is necessary<br />
to measure the iron temperature in<br />
the furnace spout or ladle from time to<br />
time with a dip lance. With the dip<br />
lance reading directly integrated into<br />
the database, the pyrometer can be<br />
automatically calibrated. If the dip<br />
lance is not integrated into the system,<br />
the measured temperature can be<br />
Usable capacity<br />
Nutzvolumen<br />
Remaining heel<br />
Sumpf<br />
entered into the system via the Operator’s<br />
Panel.<br />
InoTECH inoculation system<br />
For EASYpour the in-stream inoculation<br />
is not primary necessary, but for the<br />
cast ing quality it is a significant requirement.<br />
Like the pouring process, the<br />
in-stream inoculation is part of the<br />
quality control measures. Therefore, all<br />
relevant inoculation information for<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 27
AUTOMATIC POURING<br />
Figure 6: Automatic refilling by a skip-system<br />
Figure 7: HMI screen for inoTECH inoculation<br />
each mold is stored in the data base.<br />
The inoTECH inoculation unit is known<br />
for:<br />
> High Uptime<br />
> Multiple sensors for reliable operation<br />
> Easy installation<br />
> Easy and fast calibration<br />
> The possibility to operate with<br />
double feeder systems<br />
The InoTECH inoculation unit is working<br />
with removable hoppers for capacities<br />
of 25 or 50 kg, a powder grain size of<br />
up to 0.8 mm and a density of approx.<br />
1.7 kg/dm 3 . Feeding rates between 1-60<br />
gram/sec are available. The amount of<br />
inoculant delivered is recorded in the<br />
database. But does this amount really<br />
correspond to the amount that hits the<br />
iron stream - considering that often,<br />
there is a significant layer of inoculant<br />
in the surface of the mold?<br />
This material is wasted, as it doesn‘t<br />
enter the casting, and if this inoculant is<br />
not removed from the mold, it will also<br />
compromize the quality of the green<br />
sand and the surface finish of the casting.<br />
The newly developed system uses a<br />
laser to provide a light curtain between<br />
the inoculation feed tube and the iron<br />
stream and enables a camera to detect<br />
the individual inoculant grains that hits<br />
vs. misses the iron stream counting<br />
them in real time to determine a hit<br />
rate. The hit rate of the inoculation is<br />
further optimized by the feed tube<br />
which automatically corrects its aim, in<br />
the event of a fluctuating iron stream.<br />
The HMI screen (Figure 7) shows all<br />
the significant information, including<br />
the distribution curve of the inoculant<br />
vs. the pouring stream. In addition, the<br />
inoculation hit rate is shown. These values<br />
are also documented in the database<br />
and made available for the quality<br />
management.<br />
At this point a few words about the<br />
iron stream exiting the nozzle: This<br />
stream is not always compact and sometimes<br />
breaks up into several streams,<br />
which makes it difficult to control the<br />
level in the pouring cup pure vision and<br />
single point observations. The line laser<br />
used as standard for measuring the<br />
level of iron in the pouring cup consists<br />
of the equivalent of one million laser<br />
points, which are viewed by a pouring<br />
camera. However, only one thousand<br />
“laser points“ are sufficient for a stable<br />
pouring process. There is no doubt that<br />
the 0.1% of all laser points required for<br />
the process will capture the filling level<br />
in the cup.<br />
Artificial Intelligence<br />
Data base<br />
Ever since pour-tech was founded back<br />
in 2<strong>01</strong>1, the databases have been an<br />
important part of the companys knowhow.<br />
As mentioned in a previous chapter,<br />
one of the necessary accessories for<br />
a powerful artificial intelligence was<br />
the integration with a powerful database.<br />
The pourTECH Data Base (PTDB)<br />
has the following functions:<br />
> Storage of all available pouring and<br />
production data in a secure database<br />
> Dual raided HD<br />
> SQL data base<br />
> Basic report tool via a standard web<br />
browser such as Google Chrome<br />
> No extra programs are needed<br />
> PTDB keeps data for >5 years of production<br />
> Possibility to import data from other<br />
foundry equipment - to be stored in the<br />
PTDB<br />
A selection of standard production<br />
reports are available, and reports tailored<br />
to specific customer needs are<br />
easy to create. The data presented are<br />
certainly not new and have been part<br />
of the applications of IoT for a long<br />
time, but all this data also forms the<br />
basis for the next logical steps to<br />
develop the next level – to create artificial<br />
intelligence.<br />
28
System modules<br />
Figure 8 shows the summary of all tools<br />
and devices described so far, these are:<br />
(1) spot laser for positioning and line<br />
laser for constant filling process<br />
(2) inoTECH inoculation device with<br />
self-adjustable feeding tube<br />
(3) inoTECH-camera and light-curtain<br />
laser for counting inoculation grains<br />
(4) spout level laser, providing level<br />
feedback to the furnace pressure system<br />
(5) pyrometer to provide pouring temperature<br />
for each pour<br />
(6) final level laser for optimizing the<br />
final iron level, checked at a position<br />
down-stream from the pouring station<br />
(7) safety electrodes for emergency<br />
depressurization<br />
(8) optimized pouring spout; the distance<br />
to upper edge of the mold is<br />
approx. 165 mm<br />
The complete integrated package is<br />
available for both heated and unheated<br />
pouring systems. EASYpour can be<br />
retro fitted to existing systems from<br />
pour-tech by installing a final level laser<br />
and the PTDB.<br />
Production with EASYpour<br />
The internet of things collects the data<br />
and the artificial intelligence evaluates<br />
the context and gives recommendations<br />
for actions with EASYpour. At an<br />
advanced level, the AI executes its calculated<br />
recommendations autonomously.<br />
Figure 9 shows the line laser that<br />
monitors the filling of the mold.<br />
Together with the spot laser for positioning,<br />
this laser combination has been<br />
in use in this foundry for over a decade.<br />
A final level laser monitors the poured<br />
level of iron two molds downstream<br />
from the pouring. The final level laser<br />
(features blue light) represents the next<br />
generation in laser technology and was<br />
installed together with the EASYpour<br />
solution. The blue laser technology is<br />
less sensitive to high temperature and<br />
has a longer lifetime than older (green)<br />
lasers.<br />
In the upper area of figure 9 the<br />
spout level laser in the siphon of the<br />
furnace is seen. To the left of it is the<br />
plunger system used to clean the stopper<br />
and nozzle from slag during the<br />
production of CGI and Nodular iron.<br />
4<br />
7<br />
6<br />
8<br />
Figure 8: Summary of basic devices to create an AI system<br />
1<br />
2<br />
5<br />
3<br />
If pouring must take place automatically<br />
with the laser control, but without<br />
EASYpour, thirteen numerical parameters<br />
must be entered and saved in the<br />
PLC for each new set of patterns.<br />
Figure 9: Fully equipped stopper pouring system<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 29
AUTOMATIC POURING<br />
direct use as an advanced level of AI.<br />
The concept was started to list all<br />
the challenges. Work such as de-slagging,<br />
preparation for refilling, changing<br />
stoppers, taking samples, etc. must still<br />
be carried out by the operator, but no<br />
longer the time-consuming monitoring<br />
of the pouring process itself.<br />
Figure 10: HMI screen for EASYpour<br />
Figure 10 shows the HMI screen for the<br />
EASYpour-solution. Only three numerical<br />
parameters need to be entered at<br />
the beginning of the first production<br />
cycle of a new pattern. These parameters<br />
are shown in the centre of the<br />
image:<br />
> Stopper offset<br />
> TT( Total Time / Pouring time)<br />
> Desired metal level in the cup<br />
Every time the system learns independently<br />
of the operator in order to<br />
optimize itself, the green Learning bar<br />
in the top right of the picture moves<br />
up. After the first pouring cycle of a<br />
new pattern has been completed, the<br />
Stopper offset and TT are included in<br />
the optimization together with the<br />
other parameters.<br />
The green bars above and below the<br />
two parameters light up during optimization<br />
and show the direction and<br />
intensity of the action. Two graphs are<br />
placed on the left of the screen. The<br />
upper graph shows the (green) calculated<br />
iron level, which is necessary for a<br />
clean filling of the pouring cup. The<br />
actual filling level, which results from<br />
the reaction of the stopper, is shown by<br />
the yellow line. The two thicker red<br />
lines at 66 and 100 represent the lower<br />
and upper boundaries of the pouring<br />
cup. The “Level” parameter was set 96.<br />
This means the desired fill level is 4 mm<br />
below the top of the mold (as the top<br />
of mold is defined as 100).<br />
The opening of the stopper is shown<br />
in the lower graph. In this case, the<br />
stopper opens up to the selected maximum<br />
distance of 12 mm between the<br />
nozzle and the tip of the stopper. At<br />
the beginning the pouring, the stopper<br />
is opened up at maximum speed up to<br />
the limit, for the fastest possible filling<br />
of the pouring cup. This is intended to<br />
prevent ambient air from being sucked<br />
into the gating system, causing oxide<br />
formation.<br />
The maximum speed of the stopper<br />
movement is about 100 mm per second.<br />
The maximum flow rate of iron is<br />
reached when the stopper is lifted<br />
about 30 millimeters from the nozzle.<br />
Thus, the stopper reacts very quickly,<br />
opening in a few tenths of a second.<br />
The pouring time and the flow rate<br />
are adapted to provide a smooth and<br />
repeatable mold filling thanks to the<br />
precise laser measurement. Videos<br />
showing the filling process can be<br />
accessed via internet link at the end of<br />
the article.<br />
Summary<br />
Experiences gained over several decades<br />
of pouring ferrous materials, automation<br />
and the intensive development and<br />
use of the components of IoT laid the<br />
foundation for taking the next automation<br />
step.<br />
Algorithms for artificial intelligence<br />
were developed, necessary accessories<br />
were put together and intensively<br />
tested together with interested foundries.<br />
With each phase of this development<br />
it has become clear that this special<br />
application has the potential for<br />
At the beginning of the development<br />
the challenges were compiled. The<br />
focus was on the benefits for the<br />
foundries, such as:<br />
> Less workload for employees<br />
> The operators should be able to<br />
spend more time on quality controls,<br />
preparing the next batches, taking samples<br />
etc.<br />
> Quality of the production should be<br />
increased through the continuous<br />
improvement of the processes through<br />
developed algorithm<br />
> The cycle times of the molding systems<br />
should be reduced by optimizing<br />
the pouring time<br />
> The production costs are to be<br />
reduced<br />
> All process data are to be continuous<br />
logged, evaluated and assigned to<br />
each individual casting so that traceability<br />
is guaranteed<br />
After completion of the development<br />
and intensive tests in several foundries,<br />
these partners are convinced: A new<br />
application has been created that further<br />
improves the working conditions<br />
for the employees in the foundries,<br />
reduces production costs and represents<br />
a good basis, paving the way for further<br />
applications of artificial intelligence in<br />
the foundry industry.<br />
Michael Colditz, Sales, pour-tech AB,<br />
Sävedalen, Sweden<br />
<br />
www.pour-tech.com<br />
Videos showing EASYpour in use:<br />
https://bit.ly/3nnNM3S<br />
https://bit.ly/34kSN5K<br />
https://bit.ly/3p0CaEn<br />
30
CASTING INSPECTION<br />
Graphics: Fraunhofer IFAM/Yxlon<br />
Full component inspection<br />
promises an enormous<br />
increase in performance<br />
for electric motors<br />
Computed Tomography<br />
Cast rotors in electric<br />
asynchronous motors<br />
Electromobility confronts the automotive industry with many new challenges. New<br />
components sometimes require new test methods to ensure functionality and safety.<br />
Research and development are running at full blast and partnerships find solutions that<br />
clearly push the current boundaries of what is possible. A joint project has succeeded<br />
for the first time in taking a look into the inside of cast rotors.<br />
by Christoph Pille, Bremen, and Gabriele Mäurer, Hamburg<br />
The knowledge that cast rotors for<br />
electric asynchronous motors<br />
often suffer from casting defects<br />
like cavities and porosity is as old as the<br />
technology for casting rotors itself. In a<br />
so-called asynchronous machine<br />
(Figure 1), such as the one used in the<br />
AUDI e-tron, the rotor is powered by<br />
the electromagnetic field of the coils<br />
and transmits the power generated in<br />
the electric motor via the shaft to the<br />
wheels.<br />
Assured material- and product quality<br />
is important for the electric car’s<br />
maximum performance and thus, the<br />
driving pleasure. In the field of industrial<br />
drives, knowledge of casting defects<br />
in rotors was accepted for decades and<br />
minor losses in performance could be<br />
neglected. But since the rapid growth in<br />
electromobility, the automotive sector<br />
has been placing significantly higher<br />
demands on quality and ensured performance.<br />
Manufacturing process of cast<br />
rotors for asynchronous motors<br />
Cast rotors are preferably manufactured<br />
by aluminum high-pressure die-casting.<br />
A cylindrical laminated steel sheet<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 31
CASTING INSPECTION<br />
Graphics: Audi AG<br />
Figure 1: Schematic representation<br />
of an electric motor with<br />
cast rotor<br />
package with axially continuous recesses<br />
(the electrical conductor slots) is stacked<br />
from single, usually 0.3 - 0.8 mm<br />
thick punched electrical sheets. This<br />
stack is placed into the casting mold<br />
and during the casting process, a<br />
short-circuit ring is firstly cast onto the<br />
front side of the lamination stack.<br />
Almost simultaneously, all the conductor<br />
slots get flowed and filled with melt<br />
coming from this front ring. Finally, the<br />
second short-circuit ring on the opposite<br />
side is filled with the melt running<br />
out of the conductor slots.<br />
Due to their high wall thickness,<br />
these short-circuit rings tend to a lot of<br />
cavities caused by solidification - especially<br />
the short-circuit ring opposite the<br />
sprue, which can hardly become re-densified<br />
via the gating system. Due to the<br />
high thermal losses when flowing<br />
through the comparatively thin conductor<br />
slots, the molten aluminum quickly<br />
loses temperature and pre-solidifications<br />
can affect in the conductor slot<br />
area within the lamination stack.<br />
Moreover, casting with ultrapure „rotor<br />
aluminum“ in the 99.5-99.7 quality prevents<br />
a generous solidification interval,<br />
which can usually be used for re-densification<br />
and the avoidance of cavities<br />
caused by solidification.<br />
Figure 2: High-resolution line detector array Yxlon CTScan 3<br />
Quality inspection of cast rotors<br />
So far, non-destructive quality testing<br />
of rotors has been limited to two<br />
methods: the experimental test stand<br />
and radioscopy. Although electrical performance<br />
testing on special test stands<br />
provides information about the effective<br />
performance, it does not provide<br />
any direct conclusions to be drawn<br />
about casting quality and casting<br />
defects. The relevant imaging inspection<br />
method of computed tomography<br />
(CT) however was limited to the externally<br />
exposed short-circuit rings made<br />
of cast aluminum, whose material density<br />
of 2.7 g/cm³ is comparatively low<br />
compared to the thick-walled steel<br />
sheet package (density ~ 7.6 g/cm³).<br />
However, these short-circuit rings are of<br />
secondary interest from an electrical<br />
point of view.<br />
Much more important and more critical<br />
is the detection of casting defects<br />
in the rotor conductor bars made of<br />
cast aluminum. These are “hidden”<br />
inside the lamination stack and electrically<br />
connect the two outer short-circuit<br />
rings with each other. Casting defects in<br />
these areas would lead to a reduction<br />
of the effective conductor cross-section<br />
or even interrupted rotor conductor<br />
bars due to cold runs or enclosed flow<br />
front oxide layers. Consequently, the<br />
electrical performance of the entire<br />
motor, including thermal problems, suffers<br />
directly. This means that casting<br />
defects and inhomogeneities in these<br />
areas lead to performance losses as well<br />
as one-sided magnetic pull and thus can<br />
take effect to an uneven rotation of the<br />
rotor, which can result in increased bearing<br />
loads and damage to the electrical<br />
machine, especially at high speeds.<br />
A complete CT scan of a rotor is therefore<br />
desirable but was previously not<br />
feasible due to the unfavorable material<br />
pairing of a high-density steel-based<br />
lamination stack and low-density cast<br />
aluminum rotor conductor bars.<br />
Computed tomography system<br />
Yxlon-FF85-CT<br />
The Fraunhofer Institute for Manufacturing<br />
Technology and Advanced Materials<br />
IFAM has been engaged in the cas-<br />
Photo: Yxlon<br />
32
ting processes and quality improvement<br />
of rotors for many years. In cooperation<br />
with Yxlon <strong>International</strong>, for the first<br />
time, rotors of the size of electric car<br />
traction drives were successfully<br />
scanned in the new Yxlon FF85 CT computed<br />
tomography system at 600 kV<br />
and the high-resolution Yxlon CTScan 3<br />
line detector, providing insights into the<br />
internal details of a high-pressure diecast<br />
rotor which were previously not<br />
possible.<br />
The line detector CTScan 3 (Figure<br />
2) developed and manufactured by<br />
Yxlon <strong>International</strong> was introduced in<br />
2<strong>01</strong>8 and used for the first time in the<br />
computed tomography system CT<br />
Compact. Thanks to machine-supported<br />
cutting of the crystals, their uniformity<br />
has been improved by a factor of<br />
5. This leads to reduced ring artifacts,<br />
and the high repeatability of the signal<br />
allows optimal calibration. Due to<br />
the higher dynamic range and better<br />
signal stability, greater material thicknesses<br />
can be tested with the same<br />
x-ray energy. The solid housing is particularly<br />
resistant to temperature fluctuations,<br />
ensuring optimized cooling of<br />
the electronics. At the same time, this<br />
material combination leads to very<br />
little scatter within the detector, resulting<br />
in sharper images, cleaner edges<br />
and an improved detail detectability<br />
(Figure 3).<br />
a<br />
b<br />
Figure 3: a) Conventional CT scan of a cast rotor with insufficient resolution of the rotor conductor<br />
bars; b) CT scan with Yxlon FF85 CT system, 600 kV and CTScan 3, showing axially continuous<br />
cavities in the rotor conductor bars.<br />
a<br />
b<br />
Figure 4: a) Three-dimensional representation of the casting defects and defect distribution<br />
from the high-resolution CT; b) photo of the cast rotor which externally appears free from<br />
defects.<br />
Photos: Yxlon<br />
Quality prediction and<br />
adjustment<br />
This new success in imaging quality<br />
inspection with the high-resolution<br />
Yxlon CTScan 3 opens up new paths in<br />
the development and series production<br />
of cast rotors, and also first scans at 450<br />
kV brought excellent results. Until now,<br />
the design of casting tools has been<br />
limited to classical simulations of mold<br />
filling and solidification. In the future,<br />
samples cast in the early prototype<br />
phase can already provide information<br />
on whether casting concepts are leading<br />
to the desired goal and whether changed<br />
process parameters influence the<br />
reduction of casting defects (Figure 4).<br />
Likewise, trapped gas porosity can be<br />
detected, which has arisen due to burnoff<br />
or thermal outgassing of the electrical<br />
sheet insulation coating during casting.<br />
Accompanying the series<br />
production, it is possible to control the<br />
quality by random sampling and to<br />
detect changes due to tool wear or<br />
changes in the delivered quality of the<br />
electrical lamination sheets at an early<br />
stage.<br />
The three-dimensional display of<br />
casting defects now allows the next<br />
step for rotor inspection. The Fraunhofer<br />
IFAM is working on the computer-based<br />
prediction of the real performance<br />
of rotors in consideration of<br />
casting defects. For this purpose, the<br />
previously scanned porosity model of<br />
the rotor is imported into special software<br />
which examines the effects of the<br />
reduced electrical conductor cross-sections<br />
in the rotor conductor bars due to<br />
cavities, entrapped air or other casting<br />
defects in a simulation model. The calculated<br />
reduced performance values are<br />
compared with those of an ideal rotor.<br />
This way, the determination of a „scrap<br />
factor“ should be possible specifying<br />
the degree of casting defects possible<br />
for the rotor to still provide the required<br />
performance values.<br />
Differences in defect distribution<br />
(„homogeneous fine distribution“ vs.<br />
„locally inhomogeneous accumulation“)<br />
do not only affect the electrical performance,<br />
torque, and heat dissipation.<br />
The so-called magnetic eccentricity is a<br />
result of unequally distributed porosity<br />
in the rotor, too. From a mechanical<br />
point of view, these resulting imbalances<br />
are currently eliminated in a simple<br />
way by individually measuring and<br />
balancing the rotors analogous to<br />
„wheel balancing“. From an electrical<br />
point of view, however, the problem<br />
has not yet been solved because inhomogeneous<br />
rotor conductor bars lead<br />
to a one-sided „magnetic pull“ and the<br />
rotor rotates unevenly during operation.<br />
Waviness in torque, uneven and<br />
acoustically noticeable running, especially<br />
at high speeds, and increased bearing<br />
load on the rotor shaft are the<br />
result.<br />
Christoph Pille, Head of “casting technology”,<br />
Group manager “castings for<br />
e-drives”, Fraunhofer Institute for<br />
Manufacturing Technology and Advanced<br />
Materials IFAM, Bremen, Germany,<br />
and Gabriele Mäurer, Regional Sales<br />
Manager & Key Accounts, Yxlon <strong>International</strong>,<br />
Hamburg, Germany<br />
www.ifam.fraunhofer.de/casting<br />
www.yxlon.com<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 33
Foundry workers<br />
in the control room of Foneria Condals<br />
in Spain. Access to data now is easy and<br />
instant. Monitizer Global f. i. automatically<br />
calculates and displays the derived variables<br />
of important metrics like cumulative<br />
totals of iron poured in real time.<br />
Scrap cut by 45%<br />
Reducing rejects with<br />
Artificial Intelligence<br />
Spanish foundry group Condals transformed its access to – and application of – foundry<br />
data with Disa’s Monitizer digital solutions. Customized dashboards deliver a unified,<br />
real-time view of process information while Artificial Intelligence-driven recommendations<br />
have posted initial results for scrap reduction.<br />
by Kasper Paw Madsen, Taastrup, Denmark.<br />
Photo: Norican<br />
At its Spanish and Slovakian locations,<br />
Condals Group’s three<br />
molding lines produce over<br />
43,000 tons of iron castings each year.<br />
Constantly seeking to improve casting<br />
quality, efficiency and productivity, the<br />
company employs traditional good<br />
foundry practice like modifying patterns<br />
or varying mold density.<br />
But these days, much of its insight<br />
arrives through collecting, visualizing,<br />
and analyzing process data. Condals has<br />
already invested in numerous digital<br />
aids so, when long-term supplier Disa,<br />
Taastrup, Denmark, added an Artificial<br />
Intelligence (AI) product to its Monitizer<br />
suite of Industry 4.0 solutions, it was<br />
naturally curious.<br />
“Our goal is to be a data-driven<br />
company,” says David de la Cruz, CIO at<br />
Condals Group. “In 2020, we were interested<br />
in finding an AI solution that<br />
would help us lower our scrap rate as<br />
much as possible. Which is why we<br />
spoke to Disa.”<br />
The Monitizer Suite supports any<br />
foundry at any stage of its digital journey,<br />
whether they are novices or<br />
experts. Using Monitizer CIM with Disa<br />
machines, individual foundries can collect<br />
data, implement automatic process<br />
control and perfectly synchronize their<br />
Disa equipment – cutting out the need<br />
for manual intervention.<br />
Monitizer Global collects data from<br />
any vendor’s equipment across multiple<br />
foundries, lines or sites, and presents it<br />
in real time to users who can monitor<br />
and analyze it, then use the learnings to<br />
inform improvements. Monitizer Prescribe,<br />
powered by AI partner DataProphet,<br />
a South African IT company, speci-<br />
34
DIGITALIZATION<br />
alized in industrial AI solultions, takes<br />
an even bigger leap forward, with automated<br />
AI-driven analytics that deliver<br />
dynamic, real-time process analysis<br />
across an entire production line to significantly<br />
reduce scrap and improve profitability.<br />
“We had initially only focused on AI<br />
but Disa offered a complete solution<br />
with Monitizer,” explains de la Cruz.<br />
“We already had Monitizer CIM installed<br />
and that had worked well for us.<br />
Our business case was based on reducing<br />
the scrap rate; Monitizer Global is<br />
a really powerful tool for putting all<br />
our data in one central place and<br />
making it easily available, but reducing<br />
scrap was always the main goal.”<br />
In November 2<strong>01</strong>9, Condals decided<br />
to implement the entire Monitizer<br />
Suite. It was time to create a next-generation<br />
digital foundry.<br />
Building on a long-term<br />
relationship<br />
Condals has two Disamatic molding<br />
lines at its main Spanish plant: one<br />
installed over a decade ago and another<br />
with a state-of-the-art Disamatic<br />
D3 vertical molding machine. There’s a<br />
Disamix S100 sand mixer and another<br />
D3 in the single line in the company’s<br />
Slovakia foundry which opened in<br />
2<strong>01</strong>6. Condals has invested in Disa’s<br />
accessories too, such as the Mold<br />
Accuracy Controller (MAC) which arrived<br />
in 2020.<br />
“We have been working with Disa<br />
since the beginning of our company<br />
and their equipment has helped us to<br />
be successful,” says de la Cruz. “We<br />
already have a lot of data and we wanted<br />
to get more value out of it and for<br />
our people to have one single source of<br />
information.”<br />
The project team’s first action was to<br />
upgrade Condals’ existing Monitizer<br />
CIM installation. CIM already supported<br />
tasks like recipe management, in-mold<br />
Automatic casting on the molding line.<br />
cooling time control, automatic pouring<br />
and automatic casting sorting. The<br />
latest version would make reliable<br />
time-stamped, structured data available<br />
from all the Disa equipment, improve<br />
machine automation and recipe<br />
management, and support modern<br />
communication standards plus a wider<br />
range of languages.<br />
Monitizer Global came next, bringing<br />
all Condals’ data together in a<br />
unified cloud-based database. The company<br />
previously had to dig into each<br />
system separately, then merge data sets<br />
and calculate derived variables<br />
manually; Global’s automated variable<br />
calculations and data integration<br />
would make most of this processing<br />
unnecessary.<br />
“Because we have multiple different<br />
systems with different databases, our<br />
data was split into silos,” explains de la<br />
Cruz. “Though there was some automatic<br />
processing for our data<br />
warehouse, we mostly had to aggregate<br />
and integrate it manually. Merging<br />
data sources this way was a problem. To<br />
gain a view of the whole process, we<br />
would have to spend days combining<br />
and analysing data sets.”<br />
Information is power<br />
Condals wanted access to real-time<br />
foundry data so it could respond immediately<br />
to any line issues and it also<br />
wanted that data stored in its data<br />
warehouse. “Monitizer Global will give<br />
us both solutions,” says de la Cruz.<br />
“Real-time data to work with right now<br />
that is also stored so we can work with<br />
it afterwards. We also wanted a single<br />
standard source that everyone could<br />
trust and access. Before, the same analysis<br />
could give different answers<br />
Aerial view of Fonderia Conals near<br />
Barcelona. Two molding lines are installed<br />
here.<br />
depending on how the data set was<br />
brought together and the time period<br />
under consideration.”<br />
The Disa team first audited all the<br />
available data, identifying sources and<br />
running workshops, then worked out<br />
how to extract and push the data to the<br />
central Monitizer database. Next came<br />
the installation of NoriGate hardware<br />
to securely collect and transport data to<br />
the Cloud database from both Spanish<br />
lines as well as sand mixing and molding<br />
data from Slovakia.<br />
Seamless remote access – one of the<br />
Monitizer Suite’s main strengths – was<br />
even more vital than usual because all<br />
deployment, configuration and testing<br />
took place during the Covid pandemic.<br />
“We were only able to meet face to<br />
face with Disa and DataProphet twice,”<br />
explains de la Cruz. “We consulted<br />
remotely with Disa’s engineers who<br />
were able to configure the system and<br />
we fitted the NoriGates in Slovakia ourselves<br />
which was very easy. Considering<br />
the global situation, the whole installation<br />
went amazingly smoothly.”<br />
Making sense of complexity<br />
Previously, Condals had to tap into each<br />
machine’s control system to gather<br />
data. Now access is easy and instant.<br />
Instead of struggling in Excel to compute<br />
important metrics like cumulative<br />
totals of iron poured, Monitizer Global<br />
automatically calculates and displays<br />
these derived variables in real time.<br />
As of November 2020, Condals had<br />
12 systems connected to Monitizer Global<br />
in Spain, with almost 2000 different<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 35
DIGITALIZATION<br />
One of the two molding lines in Spain. Spanish foundry group Condals produces 43,000<br />
tons of iron castings per year with three molding lines in Spain and Slovakia.<br />
data points available through over 40<br />
different dashboards. In Slovakia, there’s<br />
currently two systems connected<br />
supplying over 500 data points to six<br />
dashboards.<br />
Dashboards and their real-time metrics<br />
can be customized for each user. For<br />
example, line speed is an important KPI<br />
for measuring productivity. But while a<br />
machine operator is mainly concerned<br />
with the current value, managers want<br />
to know how their lines functioned<br />
during the last hour, the last shift or the<br />
previous day to find ways to improve<br />
performance.<br />
“Now anyone can connect and see<br />
the data from anywhere,” enthuses de<br />
la Cruz. “Managers, supervisors and<br />
operators, many now have their own<br />
personalized, role-based dashboard<br />
view and can find all the information<br />
they need in the same place. We can<br />
collect and combine the data much faster<br />
than before and that makes historical<br />
analysis faster too.”<br />
Data access and visualization work<br />
continues to evolve, with new data<br />
sources and new or revised dashboards.<br />
One popular dashboard option combines<br />
diverse machine data to display all<br />
the important process data related to<br />
castings created from a single pattern,<br />
with an “end of batch” report summarizing<br />
each run.<br />
“We’re now asking everyone how<br />
we can support them with a unified<br />
view of their data,” de la Cruz says.<br />
“We can configure dashboards and KPIs<br />
on our own most of the time, with Disa<br />
ready to support us remotely if we need<br />
them.”<br />
One of the two molding lines in Spain<br />
is a state-of-the-art Disamatic D3 vertical<br />
molding machine.<br />
Towards zero scrap<br />
With Monitizer CIM and Global up and<br />
running by Spring 2020, it was time for<br />
the AI phase of the project. Testing<br />
started with a single Spanish line and<br />
one main objective: to reduce Condals’<br />
scrap rate.<br />
“Monitizer Prescribe relates all the<br />
process parameters from the entire production<br />
line to one output – casting<br />
quality – and we found it was a very<br />
easy solution to understand and use,”<br />
says de la Cruz. “Other competing solutions<br />
only look at parts of the process in<br />
detail and only optimize certain parameters<br />
– mold alignment, temperature,<br />
porosity – whereas Monitizer Prescribe<br />
optimizes the entire process to reduce<br />
scrap. That was exactly what we were<br />
looking for.”<br />
Jointly supported by Disa and data<br />
science partner DataProphet, Monitizer<br />
Prescribe employs automated AI-driven<br />
analytics and cloud computing’s horsepower<br />
to tackle large sets of data and<br />
extremely complex analyses head on.<br />
Where traditional manual statistical<br />
methods struggle with the volume and<br />
complexity of foundry data, the AI<br />
automatically examines historical data<br />
to learn how parameters like sand grain<br />
size and moisture content, melt pouring<br />
speed or inoculation rate influence each<br />
other – and affect final casting quality.<br />
Based on this model, it calculates<br />
which combination of machine and<br />
material settings will produce the best<br />
results for each individual pattern.<br />
During production, instead of simply<br />
reacting – too late – to quality issues,<br />
Prescribe functions as an Expert Execution<br />
System (EES), looking into the<br />
future and updating its recommendations<br />
for the control plan every 30<br />
minutes based on real-time data from<br />
the line. That’s how it keeps the<br />
foundry in the optimized “sweet spot”<br />
of maximum quality production, even<br />
as factors like air temperature or sand<br />
moisture content vary.<br />
Operators and managers receive<br />
advice through a user-friendly, web-based<br />
front end. Because Prescribe is, like<br />
Global, a cloud-hosted, Software-as-a-<br />
Service application that integrates easily<br />
with existing infrastructure, there is no<br />
need for any new IT investment.<br />
“Disa were able to show us an<br />
example of another foundry where Prescribe<br />
had been used successfully,”<br />
notes de la Cruz. “The data from that<br />
reference site proved they had been<br />
able to find optimum operating parameters<br />
that gave stable, high quality<br />
production.”<br />
Need AI? Just plug it in and<br />
put it to work<br />
The Prescribe project team made its<br />
only site visit in March 2020, running<br />
workshops and helping to set up the<br />
data feeds. All subsequent work was<br />
carried out remotely due to Covid but<br />
close, constant discussions between all<br />
three implementation partners – Condals,<br />
DataProphet and Disa – continued.<br />
Initial work involved extracting,<br />
transforming and then loading Condals’<br />
abundant historical production data<br />
into the Monitizer Prescribe platform.<br />
Over 700 parameters were collected to<br />
describe the processes for the initial five<br />
test patterns. DataProphet easily extracted<br />
process data from the Global database<br />
as well as pulling casting quality<br />
and metallurgy data directly from the<br />
source systems.<br />
36
Time-synchronizing the different<br />
data feeds is often challenging, with<br />
multiple methods employed to track<br />
molten metal and individual molds and<br />
castings, such as mold numbers and pattern<br />
keys. Where no tracking method<br />
exists, DataProphet introduces software<br />
tracing techniques that can detect process<br />
events like molten metal leaving<br />
the holding furnace and being poured,<br />
then calculate the time taken to move<br />
between them. For example, a spike in<br />
pouring ladle temperature and weight<br />
would mark exactly when the ladle was<br />
filled with metal.<br />
“The standardized, reliable data<br />
from Monitizer CIM and Global made it<br />
much easier for us to align the sensor<br />
data,” notes Leonard. “We moved<br />
quickly to sense checking results with<br />
Disa’s Application consultant and<br />
educating the Condals team in what we<br />
were doing with their data.”<br />
By mid-May, a unified, time-synchronized<br />
data set was ready to support<br />
model creation and training. Through<br />
advanced, unsupervised machine learning,<br />
the AI’s neural network model calculated<br />
and established the correlation<br />
and interaction between the hundreds<br />
of input process and machine variables,<br />
and final casting quality data.<br />
This procedure produced two initial<br />
models that would automatically specify<br />
the optimal operating regime for<br />
two of the five patterns under test.<br />
Each pattern has its own dedicated<br />
model that generates custom prescriptions<br />
to optimize each pattern’s process.<br />
After rigorous checking with test data<br />
to confirm the models’ predictive<br />
accuracy, real-life commissioning started<br />
in October 2020.<br />
Inspiring improvements<br />
in casting quality<br />
As the prescriptions went into operation,<br />
improvements arrived quickly. One<br />
test pattern already had very low scrap<br />
rates but that was reduced by a further<br />
39 %. The other pattern had a high<br />
existing scrap rate which the prescriptions<br />
helped cut by 45 %.<br />
“These initial commissioning results<br />
are very encouraging,” states de la<br />
Cruz. “Though we are still at an early<br />
stage with results for only two patterns,<br />
I think this is the right approach and we<br />
are going in the right direction. We<br />
definitely expect further improvements<br />
in future.”<br />
Not only did Condals see impressive<br />
results rapidly but the improvement has<br />
since been maintained. “The scrap rate<br />
is staying at the lower level and actually<br />
still dropping slowly, so we have seen a<br />
reduction and then a stabilization –<br />
which is good but it’s still early days,”<br />
explains de la Cruz. “The prescriptions<br />
are pointing us in the right direction,<br />
for example, in showing us which variables<br />
have the most influence on our<br />
process and so what our priorities<br />
should be.”<br />
The focus is now on fine-tuning<br />
model performance and implementing<br />
the advice in the prescriptions to move<br />
the process parameters into the desired<br />
optimum operating range. Sometimes<br />
that simply means turning a dial but<br />
other adjustments are more challenging.<br />
One example is controlling the<br />
cooling rate of poured molds; this cannot<br />
be changed directly but has to be<br />
influenced by adjusting numerous other<br />
parameters.<br />
These include holding furnace temperature,<br />
the percentage of scrap and<br />
other metals like copper initially added<br />
to the iron mix, and how much of the<br />
previous batch of iron remains in the<br />
melting furnace. To help with fine<br />
adjustments, Monitizer Prescribe gives<br />
Condals an “ideal” iron recipe to aim<br />
for while a real-time model predicts<br />
how changing the metal composition<br />
will produce the desired adjustment in<br />
the metal cooling curve.<br />
Prescriptions are currently delivered,<br />
reviewed and implemented weekly by a<br />
dedicated in-house team, but the aim is<br />
to move to real-time working as soon as<br />
possible. When that happens, machine<br />
operators will see recommended<br />
machine settings pop up in their dashboards.<br />
“One of the goals is to bring the prescriptions<br />
from Prescribe back onto the<br />
factory floor so operators can use them<br />
immediately,” explains de la Cruz. “We<br />
don’t want to change everything we<br />
have been doing for the last 20 years<br />
immediately but will gradually make the<br />
prescriptions part of our process.”<br />
Monitizer Global’s recipe settings<br />
tracker feature will help foundry<br />
managers monitor and report on<br />
actual machine settings as operated<br />
and compare them to those specified<br />
by Monitizer CIM’s recipe management<br />
tool. This gives additional insight –<br />
“why did they change this setting and<br />
what did it influence?” – and will be<br />
vital in ensuring that operators follow<br />
advice rather than constantly<br />
modifying settings on their own initiative,<br />
which would make a data-driven<br />
approach impossible.<br />
Accelerating into a digital future<br />
Condals has already seen major improvements<br />
in its digital capabilities. Critical<br />
information is now instantly available<br />
and the AI-driven prescriptions are<br />
teaching staff which parameters have<br />
the most influence on each part of their<br />
process.<br />
“We can now access data and KPIs<br />
much faster and it’s a real-time view<br />
that’s easily accessible through a browser,”<br />
says de la Cruz. “Though we are<br />
still learning how to implement the prescriptions,<br />
we have certainly been able<br />
to find things that make us more profitable<br />
and our process more understandable.”<br />
“The links between data points are<br />
not obvious and the great thing about<br />
Prescribe is that it brings everything<br />
together to predict its influence on<br />
scrap and gives you a clearer picture of<br />
what is really happening – that is one of<br />
its biggest attractions. So it’s not just<br />
been about looking for a great final<br />
result, the journey is really important<br />
too – what we learn along the way to<br />
gain greater understanding of what<br />
affects scrap.”<br />
The models that have been successfully<br />
tested are now in live production<br />
and the next phase of testing has<br />
already begun. Data is now being collected<br />
for 38 patterns and model creation<br />
is underway, so the next set of<br />
improvements should make a serious<br />
dent in the foundry’s overall scrap rate.<br />
Condals will also add further data<br />
sources to make the predictive modelling<br />
and prescriptions more accurate<br />
and present an even richer real-time<br />
view of the entire line. Once Prescribe is<br />
fully proven on the first test line, Condals<br />
will extend it to its other Spanish<br />
line.<br />
“We have still not added the sand<br />
data to the model and that could a<br />
make a major difference,” explains de<br />
la Cruz. “We know we can gain a lot of<br />
benefit from Prescribe – our team has<br />
no doubts that this is how we will do<br />
things in future – but we still have to<br />
put things in place to make it happen in<br />
normal production. We will know we<br />
have succeeded when we permanently<br />
reduce our overall scrap rate.”<br />
Kasper Paw Madsen is the Global Product<br />
Manager for Digital Solutions at<br />
Disa<br />
www.disagroup.com<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 37
DIE CASTING<br />
38
Tank area of the machine, which is<br />
particularly suitable for the production<br />
of structural cast parts.<br />
„The collaboration between Spartan Light<br />
Metal Products and Oskar Frech traces its<br />
roots to the 1970s“<br />
XXL Casting Machines<br />
Producing structural parts with<br />
the new GDK model series<br />
The US light metal foundry Spartan Light Metal Products produces cast parts for the<br />
automotive and consumer goods industries in Missouri and Illinois and has been using<br />
Oskar Frech die casting machines for this purpose since the 1970s. In a new plant in<br />
Missouri, a new machine with a clamping force of more than 4000 tons went into operation<br />
last autumn, and another identical system is currently being installed. Goal: The<br />
production of structural castings and castings for e-mobility. What can the new GDK<br />
model series do?<br />
By Philip Wiederhold, Schorndorf, Germany<br />
Photo: Oskar Frech<br />
Spartan Light Metal Products,<br />
headquartered in St. Louis, Missouri,<br />
USA is one of the world‘s<br />
leading manufacturers of aluminum<br />
and magnesium components for diecasting.<br />
The company‘s three production<br />
plants in the USA (Hannibal, Mexico in<br />
Missouri, and Sparta in Illinois) demonstrate<br />
exceptional expertise when it<br />
comes to conventional diecasting and<br />
mechanical processing lines, assembly<br />
and dies for producing products for the<br />
automobile industry and consumer<br />
goods. Some of the company‘s<br />
renowned customers from the automobile<br />
industry include Toyota, GM, Ford<br />
and Honda.<br />
The collaboration between Spartan<br />
Light Metal Products and Oskar Frech<br />
traces its roots to the 1970‘s. A number<br />
of hot chamber machines for magnesium<br />
components was delivered in 1979.<br />
In recent years, Spartan has been equipped<br />
with various products and technologies<br />
from the Frech Group, such as<br />
temperature control technology from<br />
the Austrian Oskar Frech subsidiary<br />
Robamat.<br />
Spartan‘s expansion into<br />
structural parts<br />
In order to ensure future competitiveness<br />
and the further strategic development<br />
of the company‘s product/application<br />
portfolio, investment in structural<br />
Function test of a GDK4100S die casting<br />
machine at Oskar Frech in Germany.<br />
A total of two of these systems will go<br />
to Spartan Light Metal Products<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 39
DIE CASTING<br />
part production was seen as having<br />
great potential for growth.<br />
Construction of the 4th plant in<br />
Mexico, Missouri, USA was officially<br />
announced in January of 2<strong>01</strong>8.<br />
Ground-breaking for a new 135,000<br />
square meter building with its own production<br />
facilities for multiple, fully-automated<br />
diecasting cells, including processing<br />
and logistics, for the production<br />
of ready-to-install structural cast components<br />
followed in August of 2<strong>01</strong>8.<br />
This new, highly modern infrastructure<br />
will help to fulfill the requirements<br />
of OEMs for CO 2<br />
reduction through<br />
lightweight construction using diecasting<br />
applications in Al/Mg structural<br />
parts. The goal is to actively engage in<br />
the growing market for new components<br />
of electric drives.<br />
In the first expansion stage, complex<br />
aluminum structural parts will be produced<br />
for the vehicle manufacturers.<br />
The first GDK4100S diecasting cell<br />
with 44,000 kN locking force was successfully<br />
commissioned in October of<br />
2020, following a construction period of<br />
only 8 weeks to start of production in<br />
the plant. Challenges and travel restrictions<br />
due to the corona virus had no<br />
effect on the construction time. Integrated<br />
worldwide with highly qualified<br />
on-site personnel and online remote<br />
support for global assistance, Frech USA<br />
Service enabled smooth construction of<br />
the GDK4100S.<br />
The second GDK4100S diecasting cell<br />
is currently being delivered; SOP is scheduled<br />
for early <strong>2021</strong>.<br />
Convincing Frech performance<br />
The casting unit was given high priority<br />
in the machine selection process. The<br />
performance of the 2100 kN, real-time<br />
controlled casting unit from Oskar Frech<br />
provides maximum flexibility for structural,<br />
chassis and engine components.<br />
Its properties make it particularly well<br />
suited for thin-walled and thick-walled<br />
components. Chief among these convincing<br />
dynamic properties are the acceleration<br />
of ≥650 m/s² for magnesium and<br />
a maximum velocity (V2) without metal<br />
of up to 11 m/s.<br />
Low accelerated masses allow hardly<br />
any pressure peaks as well as short pressure<br />
rise times of 20 ms at maximum<br />
specific die pressure, as a result of the<br />
interior intensifier through which flow<br />
occurs. These technical properties,<br />
among others, were crucial decision-making<br />
criteria in favor of Frech.<br />
A patented and optimized hydraulics<br />
concept, which reduces the number<br />
of<br />
40
The first model GDK4100S diecasting machine was commissioned<br />
At the top: Successful machine<br />
acceptance on site<br />
Above: New productionhall in<br />
Mexico, Missouri, USA<br />
Left: Fully automated casting cell<br />
valves in the new machine generation<br />
of the GDK series by up to 30 % and<br />
also has a very quiet FC drive, enables<br />
easy maintenance with the best possible<br />
accessibility and energy savings of<br />
up to 50 % compared to the previous<br />
series.<br />
The combination of a high-resolution<br />
position sensor system and rapid<br />
processing of the high-end real-time<br />
control with the fastest runtimes enables<br />
the GDK machine to have unparalleled<br />
and high repetition accuracy as<br />
well as process stability at a machine<br />
capability of cm k<br />
≥1.33.<br />
The locking unit of the 3-plate GDK<br />
series, known around the world as especially<br />
robust and reliable, also ensures<br />
low Total Costs of Ownership (TCO)<br />
over the long term.<br />
Efficiency with high system<br />
availability<br />
In addition to quality and process stability,<br />
powerful productivity of every system<br />
component with a high degree of<br />
availability in continuous operation is<br />
required for economic success. This prerequisite<br />
is particularly fulfilled by the<br />
robust heart of the system. The optimized<br />
kinetics/kinematics of the locking<br />
unit‘s 3-plate design allows for shorter<br />
overall lengths than in the case of<br />
2-plate machines already on the market,<br />
despite the knee joint. Among<br />
other things, the tank volume required<br />
for operating resources could be halved<br />
as a result of innovations in hydraulics.<br />
Opening and closing times of less than<br />
13 sec as well as permanently high availability<br />
are achieved, even in machines<br />
used over many years.<br />
Variables influencing casting parameters<br />
are compensated with repeatable<br />
accuracy via the controlled casting<br />
unit. The tolerances of the casting process<br />
and all quality-related process parameters<br />
are permanently monitored.<br />
With state-of-the-art equipment, the<br />
installed systems fulfill the necessary<br />
prerequisites for the future successful<br />
growth of Spartan Light Metal Products<br />
with challenging new applications from<br />
the fields of e-mobility and structural<br />
casting.<br />
As a result of the close collaboration<br />
by Spartan with its partners, the customer‘s<br />
requirements for the complex casting<br />
cell concept were able to be met in<br />
nearly turnkey fashion. Open communication<br />
combined with trust and a high<br />
level of engineering expertise were the<br />
success factors here.<br />
Wirtsch.-Ing. (M.Eng.) Philip Wiederhold,<br />
Oskar Frech GmbH + Co. KG,<br />
Schorndorf<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 41
REACH TOP DECISION-MAKERS +<br />
FOUNDRY TRADE VISITORS<br />
WORLDWIDE<br />
ON SITE<br />
DIRECTLY<br />
SPOT ON
The leading English-language trade journal for the foundry industry with<br />
worldwide distribution:<br />
CASTING PLANT AND TECHNOLOGY INTERNATIONAL<br />
Issue # 2|<strong>2021</strong><br />
Materials<br />
Casting Technology<br />
Simulation<br />
Cleaning & Finishing<br />
Advertising Deadline:<br />
May 14, <strong>2021</strong><br />
CastForge <strong>2021</strong> in Stuttgart (Germany),<br />
08.-10.06.<strong>2021</strong><br />
metef in Bologna (Italy),<br />
10.-12.06.<strong>2021</strong><br />
ANKIROS in Istanbul (Turkey),<br />
10.-12.06.<strong>2021</strong><br />
CHINA DIECASTING in Shanghai (PR China),<br />
07.-09.07.<strong>2021</strong><br />
Issue # 3|<strong>2021</strong><br />
Core Production<br />
Molding Material<br />
Die-Casting<br />
Foundry Plants<br />
Sand Preparation &<br />
Regeneration<br />
Advertising Deadline:<br />
August 13, <strong>2021</strong><br />
FOND-EX in Brno (Czech Republic),<br />
13.-17.09.<strong>2021</strong><br />
FENAF <strong>2021</strong> in Sao Paulo (Brazil),<br />
14.-17.09.<strong>2021</strong><br />
61th IFC Portoroz in Portoroz (Slovenia),<br />
15.-17.09.<strong>2021</strong><br />
Formnext in Frankfurt (Germany),<br />
16.-19.11.<strong>2021</strong><br />
Issue # 4|<strong>2021</strong><br />
Die-Casting<br />
Die-Casting Process<br />
3-D-Printing & Digitalization<br />
Environment & Energy<br />
including<br />
YEARLY CALENDAR 2022<br />
EUROGUSS in Nuremberg (Germany),<br />
18.-20.<strong>01</strong>.2022<br />
Advertising Deadline:<br />
November 19, <strong>2021</strong><br />
Media<br />
Information
TRACEABILITY<br />
In a first step, Schmid Engineering connected DGS’s casting cells so that data<br />
and information from a variety of sources were combined and transferred to<br />
the MES. The production path of each casting is thus traceable<br />
Product Labeling<br />
“We can uniquely identify<br />
every casting we produce”<br />
The Swiss automotive supplier DGS Druckguss Systeme AG has further optimized<br />
its production with a software solution from service provider Schmid Engineering<br />
for tracing individual parts.<br />
by Tino Böhler, Dresden<br />
Photo: DGS Druckguss Systeme<br />
DGS Druckguss Systeme AG (DGS)<br />
is a developer and producer of<br />
complex light-metal cast components<br />
active worldwide, with more<br />
than 1,240 employees at its sites in St.<br />
Gallen (Switzerland), Liberec (Czech<br />
Republic) and Nansha (China). With<br />
automated plants and processes for<br />
medium to high volumes, DGS serves<br />
companies wherever light-metal components<br />
with maximum demands<br />
regarding dimensional accuracy, surface<br />
quality and special physical properties<br />
are required. The Swiss automotive<br />
supplier decided on<br />
engineering service provider Schmid<br />
Engineering (Freudenstadt, Germany)<br />
to further optimize its production. The<br />
requirements of DGS focused on the<br />
tracing of individual parts. “DGS had<br />
no OPC UA server and was looking for<br />
a product that could fulfil all requirements<br />
regarding machine networking<br />
for tracing purposes,” Olivier Bloch,<br />
Corporate Development Manager at<br />
DGS, describes the initial situation.<br />
The specific reason was an automotive<br />
customer’s demand for the introduction<br />
of component-specific traceability<br />
by means of DataMatrix codes,<br />
including logging of all relevant process<br />
data. This was also to involve a central<br />
and standardized solution for all existing<br />
and future plants. “Thanks to<br />
Schmid Engineering we now have a<br />
standardized connection to all cells and<br />
44
DGS is a developer and producer of complex light-metal cast components<br />
active worldwide with more than 1,240 employees<br />
CNC plants with a single type of software,” according to<br />
Bloch. Schmid Engineering’s close interaction with the cronetwork<br />
Manufacturing Execution System (MES) from<br />
Austrian software provider Industrie Informatik was also<br />
decisive in selecting this specialist for production data<br />
management, connection to MES systems, and automation<br />
plants. “This interaction was an ideal basis for smooth<br />
introduction with as few interfaces as possible. No previous<br />
systems were being used at St. Gallen, and our sister<br />
works in Liberec only uses freeware products,” Olivier<br />
Bloch describes the implementation phase.<br />
Traceability, evaluations<br />
and dashboards possible<br />
Following a two-phase project, the automotive supplier<br />
and casting producer can now “uniquely identify every<br />
casting we produce” (Bloch) in interaction with Schmid<br />
Engineering’s DataSErver and on the basis of the data<br />
from the cronetwork MES. DGS thus meets the automotive<br />
sector’s high demands regarding the quality and traceability<br />
of products. Implementation, however, continues<br />
unabated because new machines and new sites are constantly<br />
being added. More than 80 percent of machines are<br />
now connected. “In addition to the customer’s demand<br />
for component-specific traceability, we now also generate<br />
evaluations and dashboards based on the machine data,”<br />
reports the Corporate Development Manager.<br />
The modern casting cells, regulated in real-time, are<br />
fully automatic and enable high unit numbers in the production<br />
of complex thin-walled castings for light construction.<br />
In a first step, Schmid Engineering connected these<br />
casting cells to the DataSErver, which reliably combines the<br />
data and information from a variety of sources at DGS and<br />
transfers them to the MES. Thus each casting produced is<br />
uniquely identifiable within the framework of single-part<br />
tracing. All process and machine data are also stored.<br />
Interactions between MES,<br />
DataSErver and AGVs<br />
In a second step, Schmid Engineering connected the AGV<br />
system from EK Automation (Rosengarten) to the Data-<br />
SErver. Whereby the DataSErver communicates with the<br />
AGV system, the productive machinery, and the cronetwork<br />
MES.<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 45
TRACEABILITY<br />
The car<br />
manufacturers<br />
are the main customers of<br />
DGS castings. The company<br />
has specialized in the body,<br />
interior, steering, front and<br />
rear end, engine and transmission<br />
parts, and electromobility<br />
segments.<br />
46
A DGS employee at<br />
the melting furnace.<br />
The aggregate supplies<br />
liquid metal to<br />
the numerous casting<br />
cells at the St.<br />
Gallen works<br />
The plant places the produced and<br />
fully processed castings in a rack, and<br />
transmits a signal to the Data-SErver<br />
when the rack is full. This sends a query<br />
to the MES in order to obtain a rack<br />
number. All racks are administrated in<br />
the cronetwork MES. These racks are<br />
prepared at a set-up station and are<br />
given an inlet that must match the<br />
material produced. Whereby differing<br />
inlets can be mounted on any particular<br />
rack. The rack is thus reused with differing<br />
setups. Only the cronetwork<br />
‘knows’ how the rack is currently set up,<br />
i.e. the MES reports a free rack with a<br />
suitable inlet for the material currently<br />
being produced on the plant.<br />
The DataSErver from Schmid<br />
Engineering then transmits a transport<br />
order to an AGV based on the data<br />
from the MES, and the AGV immediately<br />
drives to where the rack is parked<br />
and picks it up. The destination is the<br />
particular production plant. The rack is<br />
exchanged when it arrives: the full one<br />
out and the empty one in. The AGV<br />
receives its next order from the Data-<br />
SErver so that the full rack is transported<br />
for further treatment.<br />
Continuous and future-oriented<br />
solution development<br />
“Interactions between the cronetwork,<br />
DataSErver and AGV system work well<br />
because we can now carry out most of<br />
the parameterization in the MES and<br />
DataSErver ourselves, ensuring rapid<br />
assistance and problem-solving,” points<br />
out Olivier Bloch. The AGV interface is<br />
just at the beginning at present but will<br />
be further expanded in the coming<br />
months. “An expansion for an additional<br />
fleet of AGVs with five vehicles and<br />
a variety of plant interfaces for a fully<br />
automated production area for large<br />
parts is already in the planning phase,”<br />
adds Bloch.<br />
DGS can now cover all the original<br />
requirements of the solution with the<br />
DataSErver. Olivier Bloch sees the greatest<br />
benefit of the DataSErver for DGS<br />
in that “we thus have a standardized<br />
and central instrument which we can<br />
adapt and with which we can implement<br />
new actions ourselves.”<br />
http://schmid-engineering.com<br />
Tool production is decisive in a diecasting<br />
foundry. Here, casting molds<br />
are being produced and optimized<br />
INTERFACES<br />
The DataSErver sends the orders to<br />
the AGV and provides the appropriate<br />
feedback from the individual<br />
transport to the cronetwork MES. A<br />
variety of interfaces was used for this<br />
purpose:<br />
> Communication with the plant via<br />
Profinet (Siemens 840D controller)<br />
> Communication with the transport<br />
system via TCP/IP<br />
> Communication with the MES via<br />
OPC-UA, web services and ASCII files<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 47
COMPANY<br />
Foundry Manager<br />
Torsten Locker<br />
has already been at Walzen Irle<br />
for 30 years. Here he is standing<br />
in a 12-meter-deep casting pit in<br />
front of a 10-meter roll, to which<br />
the runners are still attached.<br />
48
“125 years ago, the omnibus with enormous<br />
spoked wheels, that appeared to be moving<br />
as if by magic, was a symbol of innovative<br />
and progressive Siegerland.”<br />
200 years of Walzen Irle<br />
Pouring off melt for<br />
industrialization<br />
In the western German region of Siegerland, casting rolls has a tradition lasting hundreds<br />
of years. This is also the case at Walzen Irle, which has been casting these essential<br />
industrial tools (which go back to the time of Leonardo da Vinci) for more than 200<br />
years and has thus decisively driven industrialization forward. In the coronavirus-influenced<br />
year of 2020, this family-run company did relatively well with its diversified range of<br />
products – and is building upon its progress-orientation and high-end production as a<br />
recipe for success.<br />
By Robert Piterek, Düsseldorf<br />
Photo: Warren Richardson<br />
In 1895, progress and casting were<br />
already indivisibly connected with one<br />
another for Walzen Irle. This is when<br />
the company brought the world’s first<br />
internal combustion omnibus to Siegerland.<br />
With six indoor and two outdoor<br />
spaces, the new-fangled vehicle transported<br />
passengers from Siegen to Netphen-Deuz,<br />
located 15 kilometers away.<br />
Instead of riding to work on a horse or<br />
taking the coach, foundry workers also<br />
used the strange vehicle that looked like<br />
a stagecoach but was powered by an<br />
early Mercedes engine. Thus, 125 years<br />
ago, the omnibus with enormous spoked<br />
wheels, that appeared to be moving<br />
as if by magic, was a symbol of innovative<br />
and progressive Siegerland – with<br />
its industrial core in the iron and steel<br />
industry, mining, smelting, and iron ore<br />
production.<br />
Innovative family clan<br />
At the time, Walzen Irle was also<br />
already a cornerstone of progress and<br />
an important link in the industry of the<br />
region. Ultimately, rolls were and are a<br />
fundamental tool for producing sheet<br />
metals, profiles of all sorts, and paper,<br />
among other things – basic components<br />
for automotive and machine construction,<br />
railways, education and administration<br />
in an industrialized society. At<br />
Siegen and Netphen-Deuz were already connected with one another in 1895 via the world’s<br />
first internal combustion omnibus<br />
the end of the 19th century, the company<br />
had already been producing rolls<br />
for three-quarters of a century – initially<br />
for the steel industry, and later for the<br />
paper and plastics sectors. The name Irle<br />
was not only connected with iron in Siegerland.<br />
The local art of beer brewing<br />
can also be traced back to an offshoot<br />
of the entrepreneurial family whose<br />
family tree goes back at least as far as<br />
the 15th century – with its origin in ‘Hof<br />
von den Erlen’ (The Alder Estate) a bit<br />
further north of Netphen. The Irles have<br />
been producing iron castings since the<br />
end of the 17th century. First attempts<br />
to cast rolls from iron were then performed<br />
200 years ago by Hermann and his<br />
son Johannes Irle.<br />
Photo: SIEGENER ZEITUNG<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 49
COMPANY<br />
Celebrations canceled<br />
due to Covid-19<br />
A welcome occasion for today’s sons<br />
and heirs – Managing Partner Dr.<br />
Petrico von Schweinichen and Commercial<br />
Director Thomas Fink – to prepare<br />
for a jubilee originally intended to be<br />
celebrated in the summer of 2020. But<br />
the coronavirus pandemic forced the<br />
managers to put an end to it. “We cancelled<br />
the jubilee with a heavy heart.<br />
The pandemic doesn’t simply come to a<br />
stop for celebrations,” Fink recalls. Roll<br />
production, however, was not cancelled,<br />
and continued with little impairment<br />
– instead of the sales results of 55 million<br />
euros achieved in 2<strong>01</strong>9, the company<br />
will probably still earn more than<br />
50 million euros in 2020. Some customers<br />
have temporarily cancelled orders<br />
so the casters are only working in threeshift<br />
operation on four days of the<br />
week in Works I and II – in Netphen and<br />
in the Deuz suburb one-and-a-half kilometers<br />
away. The company, however,<br />
does not have any financial loss due to<br />
short-time work. The fewer hours worked<br />
now will be compensated for via<br />
working time accounts.<br />
Enormous energy consumption<br />
“24 new coronavirus cases in Netphen.”<br />
This was the news when the working<br />
day started in early October 2020 at the<br />
foundry in Works II. It was mainly<br />
schoolchildren who had got ill, the<br />
report continued. Someone swears<br />
about the schools, although nobody<br />
here wants to imagine a new lockdown<br />
and another period of school closure.<br />
Worries about the coronavirus evaporate<br />
in the works itself, though, with its<br />
skylights a good ten meters above the<br />
floor, the brick walls, and the hall of<br />
heavy machinery in the distance. Rolls<br />
up to 17 meters in length and with 1.7<br />
meter bale diameters are cast here<br />
using centrifugal casting or statically.<br />
Deep casting pits for static casting, as<br />
well as horizontal and vertical spin-casting<br />
plants, are ready and waiting in<br />
several halls.<br />
A lot of energy is required to complete<br />
production of such enormous<br />
rolls, from their casting to their finishing.<br />
Every year, about 60 GWh of<br />
energy flows through the electricity<br />
cables and gas pipes of the melting furnaces,<br />
lathes, honing machines, grinders,<br />
centrifugal casting plants, roll<br />
saws, heating systems, annealing furnaces,<br />
and much else besides – equivalent<br />
to the energy required by about 15,000<br />
family households. “We can prepare 90<br />
A well-aimed throw into the<br />
casting mold. The powder in the<br />
plastic bag inserts seeds into the<br />
melt to influence the structural<br />
formation of the hardening roll.<br />
Below: As if in a firestorm, this<br />
caster is standing on a gallery<br />
from which he keeps an eye on<br />
the melt’s state in the mold. A<br />
profile roll for a Spanish steelworks<br />
is being cast here.<br />
tonnes of liquid iron ad hoc. In order to<br />
cast our heaviest 130-tonne rolls we<br />
prepare the melt with appropriate storage<br />
technology,” explains Torsten<br />
Locker, Foundry Manager and a graduate<br />
of TU Bergakademie Freiberg in<br />
Saxony, who can already look back on<br />
30 years of professional experience. His<br />
team of masters and specialists is well<br />
organized and work well together.<br />
Many are like him, have been here<br />
more than 30 years and are accordingly<br />
well-practiced in their profession whilst<br />
being well aware of the everyday risks<br />
involved.<br />
The best of tradition<br />
and the modern<br />
“You can start the algorithms,” Locker<br />
tells the melt foreman Wagener. The<br />
melting and casting technology, based<br />
on experience gathered over two hundred<br />
years, is now coupled with modern<br />
technology. With the instruction, Locker<br />
sets a mechanism going which, right<br />
from the start, should ensure that<br />
today’s casting successfully results in a<br />
section roller for a Spanish steelworks.<br />
It will roll tracks for the railways and is<br />
made of a steel-like iron with just 1.3<br />
percent carbon. First there is an evaluation<br />
of a sample of the melt using computer<br />
algorithms. This determines its<br />
liquidus and solidus values, the tapping<br />
and casting temperatures, and its quality<br />
values. The reason for the analysis is<br />
simple: if the casting process fails, rolls<br />
worth between 25,000 and 850,000<br />
euros (depending on their size and<br />
complexity) could be ruined. In order to<br />
50
Mold elements of a wide<br />
variety of sizes are stored<br />
in the halls.<br />
90-tonne melting capacity and distribute<br />
it in all directions in the works.<br />
Finally, two 20-tonne ladles hover along<br />
one after the other on the hall crane,<br />
accompanied by a worker in a silvery<br />
protective suit, who controls the crane<br />
remotely by radio. A little later, an<br />
orange-yellow flow of melt gushes into<br />
the ladle, spraying sparks. The flow<br />
dries up when the furnace has been tilted<br />
all the way to the end stop. Ladle 2<br />
follows, while the heat-protected worker<br />
deslags the first melting vessel.<br />
Small color-coded piles of chips lie on<br />
the floor between the ladles, ready to<br />
be added to the melt according to the<br />
alloy composition.<br />
prevent this, or at least to limit the costs<br />
and effort involved, a comprehensive<br />
quality management system is used<br />
both before and after casting, e.g. with<br />
ultrasonic measurements.<br />
The analysis is being carried out as<br />
the group of visitors surrounding Works<br />
Above: Hardening centrifugal<br />
casting rolls in<br />
a casting pit. While<br />
Walzen Irle produces<br />
the molds for static casting<br />
itself, the company<br />
buys centrifugal casting<br />
molds made of forged<br />
steel from elsewhere.<br />
left: The casters use a<br />
demolition robot to<br />
secure a riser before<br />
the 100-tonne roll is<br />
lifted out of the pit.<br />
Manager Locker climbs a metal ladder<br />
onto the stage of the melting operation<br />
and finally arrives above the five melting<br />
furnaces. A gap opens and the tilting<br />
furnaces, arranged in a row next to<br />
one another, release searing light and<br />
heat. They can prepare 66 of the<br />
Countdown to the casting<br />
When the extremely heavy roll melt is<br />
ready for casting, workers use a crane<br />
to lift the two-meter-tall ladles onto railed<br />
vehicles and transport them into the<br />
adjacent hall. Smoky orange auras radiate<br />
the melt energy away from the top<br />
of the crucibles and are reflected in the<br />
workers’ heat protection visors. Their<br />
expressions also reflect focused attention,<br />
because time is of the essence. The<br />
time window with the necessary casting<br />
temperature of about 1,480°C is only<br />
about 20 minutes long.<br />
Today’s casting is static. A mold<br />
stands ready in a deep casting pit protected<br />
by railings. The mold has two<br />
long vertical casting inlets. The ladles<br />
are now brought into position above<br />
the inlets, on the left and right. The air<br />
crackles with tension in the hall, the<br />
size of a football pitch, where giant<br />
upright molds beside the casting pit<br />
reflect the enormous effort of the task,<br />
as well as its dimensions, in the flaring<br />
light of the blazing melt. Then the time<br />
comes, and from both sides the melt<br />
flows into the inlets with the wide funnels<br />
and falls to the lowest end of the<br />
casting pit through the drag box made<br />
of sand, rotating back up to the top<br />
through the mold. A technology intended<br />
to prevent impurities and the formation<br />
of cavities. Meanwhile, a caster<br />
monitors the state of the melt from the<br />
gallery. It soon seems as if he is standing<br />
at the center of a roaring sea of fire<br />
between the ladles that are descending<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 51
COMPANY<br />
farther and farther. The flow diminishes<br />
after about one-and-a-half minutes –<br />
the spectacle is at an end. The roll<br />
enclosed in the mold will now need<br />
seven days to solidify fully.<br />
Diversification brings economic<br />
stability<br />
The idea of rolling as a transmission of<br />
power originates from the universal<br />
genius Leonardo da Vinci in the 15th<br />
century. Its industrial application started<br />
in the 19th century. Now rolling is used<br />
to produce numerous products, such as<br />
metal sheets, profiles, foils and paper.<br />
The customer spectrum and product<br />
range of Walzen Irle is just as varied,<br />
ranging from the steel, flat and profile<br />
industries, through the food industry, to<br />
the paper and foil industries. A small<br />
proportion of the roll foundry’s sales<br />
also involves abrasive wear castings<br />
such as grinding bowls for mills, or extremely<br />
wear-resistant pump rotors used<br />
in machines with which, for example,<br />
artificial islands in Dubai are heaped up.<br />
“Our varied product range is a blessing<br />
in times such as these, when the steel<br />
industry is faltering,” explains Commercial<br />
Director Fink. Then booming industrial<br />
sectors can compensate for collapsing<br />
sales elsewhere. The packaging<br />
sector is currently thriving as a result of<br />
the coronavirus pandemic, which can be<br />
seen, for example, from the orders for<br />
foil rolls. The paper sector is also strong<br />
at the moment, as observed by von<br />
Schweinichen and Fink. During the<br />
good times, on the other hand, the Netphen-based<br />
company considers diversification<br />
to be a curse, because then they<br />
have to measure themselves against<br />
specialists from all over the world,<br />
whose business strategy is frequently<br />
only based on a single rolling group.<br />
And Foundry Manager Locker is aware<br />
that “the operating costs of such specialists<br />
are lower, and we also have the<br />
costs of our rail operation between<br />
Works II and Works I.”<br />
Works railway connects the<br />
foundry with the processing<br />
works<br />
The railway line between the foundry<br />
and the processing works is a curiosity<br />
that goes back to the start of the 20th<br />
century. Netphen-Deuz obtained its rail<br />
link in 1906 and Walzen Irle in turn laid<br />
down its own feeder tracks in both<br />
works. Regular rail operation has meanwhile<br />
stopped. Only the rail section between<br />
the two works remains – and is<br />
used under the company’s own control<br />
for the daily transports of extremely<br />
heavy rolls from the foundry in Works II<br />
Managing Directors Dr. Petrico von<br />
Schweinichen (right) and Thomas Fink in<br />
a roll processing hall. Here, the anniversary<br />
celebration was to take place in the<br />
summer of 2020. It has now been postponed<br />
until June of this year.<br />
for processing in Works I. In the other<br />
direction, the chips arising from processing<br />
are returned to the foundry, where<br />
they are re-used in the melt.<br />
A 100-tonne calender roller, still in<br />
its twelve-meter-deep casting pit, will<br />
also soon take the familiar path along<br />
the rails between the two works. The<br />
Netphen casters must attach a bracket<br />
for the riser that is still in the roll before<br />
The enormous roll slowly rises from the pit.<br />
Numerous extensive processing steps follow<br />
that can take a whole week to complete.<br />
52
emoving the colossus from the pit.<br />
They use a demolition robot for this – it<br />
is a bit like a Mars Rover. The machine<br />
carefully mounts a long rod to the<br />
upper end of the pipe. Whereby the<br />
robot arm slowly crosses the gaping gap<br />
of the casting pit. Then the job is completed<br />
and the second part of the complicated<br />
removal process can begin. Creaking<br />
loudly, the elbow-thick steel cable<br />
takes hold as the crane lifts the roll and<br />
raises it in the vastness of the hall. As<br />
was the case for the casting process,<br />
molds again hem the casting pit like<br />
enormous visitors. The men with their<br />
blue helmets, on the other hand, look<br />
like children with a toy.<br />
The term ‘calender roll’ comes from<br />
paper production. Calender describes a<br />
system of several heated and polished<br />
rolls that are arranged upon one another.<br />
After delivery to Works I, numerous<br />
holes are therefore drilled into the<br />
calender rolls, through which a fluid<br />
will eventually flow to heat the surface<br />
of the roll to more than 200°C, making<br />
it into a huge iron for paper.<br />
“Anyone can do the easy things”<br />
Walzen Irle’s competitors are mainly<br />
located in Asia. The recipe for not losing<br />
any market share to them is to produce<br />
high-alloy, geometrically demanding<br />
rolls of extremely high quality. “Anyone<br />
can do the easy things,” is the motto at<br />
Netphen. ‘Together we are stronger’ –<br />
the principle of the European Union –<br />
seems to have become a template for<br />
the roll casters from Siegerland for their<br />
own collaborations. Because, since mid-<br />
2020, Walzen Irle has been cooperating<br />
with their competitor Gontermann Peipers<br />
from Siegen, which also has a minority<br />
holding in the Netphen company.<br />
The aim is to ensure the survival of the<br />
area as a foundry location. The two<br />
companies are now collaborating on<br />
four joint projects. Ultimately, both<br />
firms are highly dependent on exports<br />
and will thus continue to contribute<br />
towards industrialization worldwide.<br />
After all, ploughing the same field twice<br />
does not make much sense.<br />
The progress that has characterized<br />
the company right from the start is still<br />
important for it to remain a technology<br />
leader. Irle works with the Fraunhofer<br />
Institutes, with universities in Siegen<br />
and Bochum, and with RWTH Aachen to<br />
ensure continuous improvement. Trials<br />
are underway, for example, to see<br />
whether wear layers can be applied to<br />
the roll surface using additive manufacturing<br />
techniques. Digitalization<br />
Roll processing in Works I. About 70 rolls for numerous industrial sectors are processed<br />
here every month and transported worldwide.<br />
methods and artificial intelligence are<br />
also in use or being tested. The company<br />
has also been using its own cogeneration<br />
plant for some time now in<br />
order to reduce its operating costs in<br />
the long term. “After all, we use it to<br />
generate one GWh of electricity per<br />
year. And a home for senior citizens in<br />
Netphen is being heated with the waste<br />
process heat from the works,” adds Dr.<br />
Petrico von Schweinichen. At the same<br />
time, the management team is keeping<br />
close eye on developments in the use of<br />
hydrogen as a fuel of the future.<br />
This mix of progress-orientation and<br />
social responsibility, which can also be<br />
seen from the good mood and high<br />
motivation among the casters at the<br />
works, is still the key for Walzen Irle’s<br />
successful continued existence – and is,<br />
at the same time, an unmistakable feature<br />
of SMEs as the backbone of Germany’s<br />
economy.<br />
www.walzenirle.com<br />
WALZEN IRLE<br />
Employees: 300, 103 in the foundry.<br />
Alloys: 600 alloys on offer, including those with vanadium, molybdenum, niobium,<br />
tungsten, nickel and chromium.<br />
Carbon content in iron: 0.8 - 3.9 percent.<br />
Annealing furnace for heat treatment: 17 units in Works II.<br />
Processes: static roll casting and, since the turn of the millennium, vertical and<br />
horizontal centrifugal casting. Two different iron layers can be combined here<br />
by means of composite casting – a hard outer layer and a ductile inner one.<br />
There are centrifugal casting plants for 80- and 100-tonne rolls that rotate at<br />
about 600 rpm. Centrifugal casting and static casting are each responsible for<br />
50% of production.<br />
Proportion exported: about 70%, with buyers from North America and Russia,<br />
through Asia and South America, to Europe and North Africa.<br />
Customers (selected): Salzgitter, Tata, thyssenkrupp, Saarstahl and ArcelorMittal<br />
in the steel industry. Valmet, Voith and Exalt in mechanical engineering.<br />
Roll service life: some calender rolls that are now being replaced were produced<br />
in 1969. The service life of a highly abrasive roll for steelworks sheet is<br />
only 6 - 12 months.<br />
Annual capacity: 14,000 tonnes. Finished weight: 12,000 tonnes.<br />
Roll dispatch per month: about 4 - 6 plate rolls, 45 - 50 hot-strip rolls, as well<br />
as 2 paper and 8 - 10 plastic calender rolls.<br />
Energy: Walzen Irle is partially exempt from the Renewable Energy Sources<br />
Act (EEG) due to energy costs representing more than 17% of total costs.<br />
Energy management takes place, for example, via a load management system<br />
for the flexible billing of electricity.<br />
Refractory technology: Safeway System to monitor the refractory state of the<br />
furnaces.<br />
Special aspects: inductive hardening, production of hydraulically loaded rolls<br />
for the aluminum industry, restoration of worn rolls.<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 53
NEWS<br />
BUSH-HUNGARIA<br />
Investments instead of crisis mood<br />
Despite the challenges of 2020,<br />
Busch-Hungária Kft. in Győr, Hungary,<br />
sister foundry of M.Busch in Bestwig,<br />
Germany, is investing millions in improving<br />
productivity, optimizing the value<br />
chain and other measures.<br />
“With investments of 5 million<br />
euros to raise productivity in 2020,<br />
combined with a comprehensive package<br />
of measures, the foundry has prepared<br />
itself for the challenges of the<br />
future,” says Managing Director István<br />
Kaiser. The lean management<br />
approach was used to optimize processes<br />
along the entire value chain,<br />
resulting in cost-optimized production,<br />
improved organizational structures<br />
and increased transparency in internal<br />
processes.<br />
Extensive investments will also be<br />
arranged at Busch-Hungária in the<br />
coming years. Already in the coming<br />
months, further investments will be<br />
made in the areas of melting operations<br />
and infrastructure to expand<br />
capacities with the aim of increasing<br />
casting capacity to 26 tons/hour.<br />
Busch-Hungária Kft. employs<br />
around 315 people. German and Hungarian<br />
specialists make up the management<br />
team. So far, there has been no<br />
production downtime in the Corona<br />
pandemic. Thus, the company proved<br />
to be a reliable supplier, which further<br />
increased customer satisfaction.<br />
www.busch-hungaria.hu<br />
Busch-Hungária Kft. has developed into<br />
one of the technologically leading foundries<br />
of components for the commercial<br />
vehicle industry, which, in addition to<br />
production for the trailer sector, now also<br />
counts major OEMs from the truck sector<br />
among its customers.<br />
Photo: BUSCH-HUNGARIA<br />
FOSECO<br />
Solution to rapid changes of nozzle<br />
size in bottom pour applications<br />
Photo: FOSECO<br />
The Vapex Fosflow concept employs specific<br />
stopper and nozzle technologies for bottom<br />
pouring applications.<br />
Foseco Vapex Fosflow is a new system<br />
that allows for changes in nozzle diameter,<br />
even in a full ladle. Vapex Fosflow<br />
alumina graphite nozzles use both<br />
carbon and ceramic bond technology.<br />
The combination of the two bonding<br />
systems provides unique beneficial properties<br />
for steel foundry ladle applications.<br />
When using stopper and nozzle<br />
technologies for bottom pouring applications<br />
it may be desirable to change<br />
nozzle diameters between fills of the<br />
ladle or even between castings. In normal<br />
circumstances this would not be<br />
possible as it would require removing<br />
and replacing the nozzle and stopper.<br />
The system contains a base nozzle<br />
which remains in the refractory bottom<br />
of the ladle and an interchangeable<br />
pouring nozzle with possible different<br />
inner diameters. This pouring nozzle<br />
can be replaced quickly even within a<br />
ladle cycle. Foseco provides 4 different<br />
Vapex Fosflow series: 45, 65, 100 and<br />
100 extended for large ladles.<br />
The Vapex Fosflow nozzle should be<br />
used in conjunction with Viso monobloc<br />
stopper technology that also allows<br />
multiple uses of the stopper.<br />
Benefits are mostly found in steel<br />
foundry applications:<br />
> The pouring nozzle can be changed<br />
quickly<br />
> Multiple use of the stopper & nozzle<br />
system resulting in labour cost<br />
reduction<br />
> No cooldown of the ladle resulting<br />
in energy savings and increased<br />
ladle lining performance<br />
Application for use of the Vapex Fosflow<br />
concept, the nozzle needs to have<br />
a different fixing system (see illustration).<br />
Foseco can provide all the necessary<br />
metal parts which makes it easy to<br />
modify the nozzle ladle mechanism.<br />
www.vesuvius.com<br />
Video about the use of<br />
Vapex Fosflow<br />
https://bit.ly/3uTwzUa<br />
54
AZTERLAN METALLURGY RESEARCH CENTER<br />
New technology could stabilize<br />
CGI component manufacturing<br />
Photo: AZTERLAN<br />
Thermolan thermal analysis system takes into account the metallurgical properties from<br />
liquid metal by the control of its solidification curve and the geometric characteristics of the<br />
part, to extrapolate the results.<br />
A new development from Azterlan<br />
Metallurgy Research Center, Durango,<br />
Spain, correlates the various factors<br />
involved in the formation of compact<br />
graphite iron (CGI) and could provide a<br />
significant boost to the industrial production<br />
of CGI components. The<br />
methodology allows to predict in real<br />
time the index of nodularity and the<br />
proper formation of compact graphite.<br />
This could enable new applications<br />
and developments with the material.<br />
Compact graphite iron (CGI), also<br />
known as vermicular graphite iron, displays<br />
outstanding mechanical properties<br />
such as high thermal conductivity<br />
and vibration damping, comprised between<br />
those of lamellar and spheroidal<br />
cast iron. These qualities make this<br />
material notably attractive for applications<br />
that require high thermal conductivity,<br />
which are currently manufactured<br />
in grey cast iron. Due to its higher<br />
mechanical properties, the use of CGI<br />
allows to implement design optimization<br />
and weight reduction strategies,<br />
which are a key factor for diverse applications,<br />
like in the automotive sector.<br />
Nevertheless, despite of the great<br />
features and performance of this material,<br />
the complicated and not quite stable<br />
production process impedes CGI to<br />
jump into industrial manufacturing.<br />
With the aim of building a robust process,<br />
researchers from Azterlan Metallurgy<br />
Research Centre have developed<br />
a methodology that, based on thermal<br />
analysis, allows to predict in real time<br />
the index of nodularity and the proper<br />
formation of compact graphite. This<br />
new method makes it possible to<br />
ensure in less than 3 minutes that the<br />
graphite formed owns the desired<br />
shape. To achieve that, the Thermolan<br />
thermal analysis system is necessary.<br />
The system takes into account the<br />
metallurgical properties from liquid<br />
metal by the control of its solidification<br />
curve and the geometric characteristics<br />
of the part, to extrapolate the<br />
results according to the specific reference<br />
being manufactured at the<br />
moment. With the new and affordable<br />
control system a stable manufacturing<br />
process assuring the required characteristics<br />
for a proper solidification<br />
scheme can be assured. If not, the<br />
foundry has the capacity to react at<br />
the right time during the manufacturing<br />
process. According to Azterlan the<br />
doors now are wide open “for this promising<br />
material to reach new applications<br />
and developments”.<br />
www.azterlan.es<br />
Pneumatic conveying<br />
technology<br />
For dry, free-flowing, abrasive and<br />
abrasion-sensitive material<br />
Core sand preparation<br />
technology<br />
For organic and inorganic processes,<br />
turn-key systems including sand,<br />
binder and additive dosing and<br />
core sand distribution<br />
Reclamation technology<br />
Reclamation systems for<br />
no-bake sand and core sand,<br />
CLUSTREG® for inorganically<br />
bonded core sands<br />
Shock wave technology<br />
CERABITE ®<br />
clean castings<br />
The reliable solution for the<br />
removal of residual sand<br />
and coatings of<br />
demanding castings<br />
KLEIN Anlagenbau AG<br />
KLEIN Stoßwellentechnik GmbH<br />
a subsidiary of KLEIN Anlagenbau AG<br />
Obere Hommeswiese 53-57<br />
57258 Freudenberg | Germany<br />
Phone +49 27 34 | 5<strong>01</strong> 3<strong>01</strong><br />
info@klein-group.eu<br />
www.klein-ag.de<br />
www.stosswellentechnik.de<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 55
NEWS<br />
Photo: AVM SOLUTIONS<br />
AMV SOLUTIONS<br />
New digital platform for efficient<br />
melting management<br />
BeyondAlea should be able to<br />
fully manage the melting and<br />
alloying process in foundries.<br />
AMV Solutions, Vigo, GHI Smart Furnaces,<br />
Galdakao, and GECSA, Loiu, (all<br />
Spain) take a step forward to bring 4.0<br />
technology closer to foundries, creating<br />
an innovative product that fully manages<br />
the melting and alloying process in<br />
steelworks, aluminium recycling plants<br />
as well as in casting plants for iron and<br />
other metals.<br />
The alliance of these three firms, with<br />
extensive experience in the 4.0 industry<br />
and in the metal sector, results in a new<br />
digital platform for the foundry industry.<br />
The so called BeyondAlea platform<br />
applies Machine Learning and Artificial<br />
Intelligence techniques in order to<br />
achieve a Digital Twin of any melting<br />
plant.<br />
BeyondAlea is a modular platform<br />
that covers the entire production cycle<br />
of any type of foundry. The platform<br />
covers and monitors the entire process,<br />
from the raw materials purchasing and<br />
equipment management up to the final<br />
product quality control.<br />
It allows to achieve complete traceability<br />
and reduce the risk of defects,<br />
since it can correct anomalies in real<br />
time.<br />
The Beyond Alea platform allows the<br />
companies to have:<br />
> Advanced sensorization: Specifically<br />
designed sensors along the whole<br />
process that automatically report<br />
data to the information systems.<br />
> Monitoring: Monitoring of the production<br />
process and detection and<br />
correction of anomalies in real time.<br />
> Charges optimization: Lower cost<br />
charges, considering the variability<br />
(composition, availability, cost) of<br />
the raw material and the final specification<br />
of the alloy.<br />
> Scheduling: Process planning adapted<br />
to the plant’s workflow.<br />
Accurate control of capacities,<br />
equipment availability and operation<br />
times.<br />
> Quality improvement: Reduction of<br />
faults, real time corrections and consistent<br />
final product thanks to the<br />
continuous improvement of the chemical<br />
precision and complete traceability.<br />
> Machine learning: Beyond Alea<br />
learns from production data to predict<br />
the behavior of raw materials<br />
and power profile to reach the full<br />
potential of the plant.<br />
Beyond Alea, applies 4.0 technologies in<br />
sensoring, capturing and analyzing data<br />
in real time to maximize metal yield,<br />
minimize costs and process times on a<br />
single platform.<br />
The use of data analysis and<br />
machine learning techniques allows the<br />
users in the metal sector, to ease the<br />
decision making as the system can automatically<br />
learn and correct itself with<br />
the generated data of the casting process.<br />
This continuous improvement allows<br />
to have a total process control, thus<br />
obtaining a more consistent and homogeneous<br />
final product with a stable chemistry<br />
and an evident reduction in the<br />
use of raw materials, energy and melting<br />
times, resulting in a significant economic<br />
savings for the customers.<br />
Beyond Alea, the new 4.0 platform<br />
for the foundry industry is the result of<br />
experience and research work carried<br />
out by the three companies, with the<br />
objective to achieve an intelligent and<br />
efficient foundry that aligns and anticipates<br />
market demands with available<br />
technology.<br />
www.beyondalea.com<br />
56
NORICAN GROUP<br />
New Americas headquarters in 2022<br />
Norican Group, parent company to<br />
industry leading brands DISA, Wheelabrator,<br />
StrikoWestofen and Italpresse<br />
Gauss, announced plans to build and<br />
move to new facilities for its Americas<br />
headquarters in 2022.<br />
The move follows the consolidation<br />
in 2020 of all manufacturing and operations<br />
for the four brands into the<br />
LaGrange Technology hub, to fully leverage<br />
the strengths of the group, standardize<br />
business processes and optimize<br />
service levels to all customers. The existing<br />
LaGrange facility has been home to<br />
Norican brands for 33 years and the<br />
group remains committed to the local<br />
area, choosing a local greenfield site in<br />
LaGrange, Georgia, USA, for its new state-of-the-art<br />
operations and assembly<br />
facility, to be built and completed in<br />
2022.<br />
The new development will give the<br />
group a platform for accelerated<br />
growth and enable it to further ramp<br />
up technology development, assembly<br />
and testing.<br />
Current facility of<br />
Norican Group in<br />
LaGrange, Georgia.<br />
The company keeps<br />
its headquarters,<br />
which will open in<br />
2022, in the local<br />
area.<br />
Kim Tjerrild, General Manager at<br />
Norican Group Americas, explained the<br />
move: “(…) The new facility allows us to<br />
truly transform the way we deliver<br />
equipment, parts and services for our<br />
customers. We will develop new technology<br />
faster, get it to our customers<br />
more quickly and better respond to<br />
their fast-evolving needs.” Norican<br />
Group serves a wide range of industries,<br />
including the global automotive,<br />
aerospace, foundry and aluminium sectors,<br />
through a global network of<br />
engineering expertise, manufacturing<br />
capacity and local service support.<br />
www.noricangroup.com<br />
Photo: NORICAN GROUP<br />
Media Kit <strong>2021</strong><br />
Give your marketing<br />
the significant boost!<br />
+49 211 1591 142<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 57
NEWS<br />
FOSECO<br />
Change in management and leadership<br />
On 30 June <strong>2021</strong>, Heinz Nelissen will<br />
retire after 31 years of successful service<br />
to the Foseco and Vesuvius group<br />
of companies. His successor as managing<br />
director of Vesuvius GmbH for the<br />
foundry division is Rafael Carbonell,<br />
who is European Vice President EMEA<br />
Foundry and will now also become<br />
Managing Director. Furthermore, Hannes<br />
Erger, Business Unit Manager for<br />
the iron and steel foundry business, has<br />
been appointed to the management<br />
team in Borken. Erger remains the contact<br />
person for all matters concerning<br />
customers and sales and will support<br />
the management in sales decisions.<br />
Heinz Nelissen held his position as<br />
Managing Director of Vesuvius GmbH<br />
for 18 years, additionally he was appointed<br />
Managing Director of Foseco GmbH<br />
in 2003. His successor as managing director<br />
of Vesuvius GmbH for the foundry<br />
division is Rafael Carbonell. Rafael Carbonell<br />
holds a master’s degree in<br />
Mathematics and Theoretical Physics<br />
from Cambridge University and an MBA<br />
from London Business School. After graduating,<br />
he spent 10 years in various<br />
management positions in the aluminum<br />
industry. For more than two years, he<br />
has been responsible for the strategic<br />
growth of the European foundry business<br />
at the Vesuvius Group as European<br />
Vice President EMEA Foundry.<br />
In Hannes Erger, Foseco has found a<br />
committed and competent successor for<br />
the management. Hannes Erger has<br />
been with Foseco for over 21 years and<br />
can look back on many years of experience<br />
in various areas of activity in the<br />
foundry industry. He is very familiar<br />
with the special requirements that<br />
customers place on foundry solutions<br />
and has been with the company since<br />
1999. 2003 he was appointed Sales<br />
Manager for iron and steel foundries.<br />
Since 2<strong>01</strong>4, he has had overall responsibility<br />
for the iron and steel foundries<br />
business unit as Business Unit Manager.<br />
In recent years, Vesuvius has invested<br />
Heinz Nelissen (left), Managing Director<br />
of Vesuvius GmbH, goes into well-deserved<br />
retirement after 31 years, while Hannes<br />
Erger takes over responsibility for all<br />
matters relating to customers and sales<br />
for iron and steel foundries as well as<br />
public relations and association work.<br />
heavily in the development of new product<br />
ideas for its foundry customers.<br />
Hannes Erger sees the successful marketing<br />
of these products as a focal point<br />
and opportunities to further expand the<br />
business.<br />
www.vesuvius.com<br />
Photo: Foseco<br />
GRIEVE<br />
Jumbo walk-in oven<br />
Photo: Grieve<br />
No. 1<strong>01</strong>9 is a 260 ºC electrically heated walk-in batch oven from<br />
Grieve, Round Lake, USA, currently used for curing coatings onto<br />
large discs at the customer’s facility. 260 kW are installed in<br />
Incoloy-sheathed tubular elements to heat the oven chamber, while<br />
a total of 1,869 m 3 per min generated by two 30-HP recirculating<br />
blow ers provides combination airflow to the workload.<br />
This Grieve walk-in oven features insulated walls, aluminized<br />
steel exterior and interior, thick insulated flooring with built-in oven<br />
truck wheel guide tracks and motorized dampers on the intake and<br />
exhaust for accelerated cooling of the oven chamber. The oven was<br />
sectioned into four pieces for shipping convenience.<br />
All safety equipment required for handling flammable solvents,<br />
including explosion-venting door hardware, is provided on No. 1<strong>01</strong>9.<br />
Controls on this jumbo walk-in oven include an SCR power controller.<br />
<br />
www.grievecorp.com<br />
58
EFFICIENT CUPOLAS<br />
Waupaca foundry wins<br />
Better Project Award<br />
The U.S. Department of Energy has<br />
recognized the Waupaca Foundry in<br />
Waupaca, Wisconsin, with the Better<br />
Project Award for 2020. The Waupaca<br />
plant in Tell City, Indiana, designed and<br />
installed a system to remove moisture<br />
from the air around the foundry‘s<br />
cupola furnace.<br />
The award is part of the Better<br />
Plants program, which recognizes<br />
manufacturers for developing and<br />
implementing industrial energy and<br />
water efficiency projects, as well as<br />
renewable energy and energy resilience<br />
projects. Tell City plant engineers installed<br />
a drying system that removes water<br />
vapor from the ambient air of the<br />
cupola furnace before it is preheated.<br />
Removing moisture from the air stabilizes<br />
operations and reduces energy<br />
consumption by using less coke and<br />
improving melting efficiency. This is<br />
intended to offset rising material costs.<br />
www.waupacafoundry.com<br />
A worker at the Waupaca<br />
plant in Tell City,<br />
Indiana, USA,<br />
inspects the new<br />
drying system that<br />
removes water vapor<br />
from the air around<br />
the cupola.<br />
Photo: Michael Schultz<br />
TRIMET<br />
New alloy for crash-loaded components<br />
Trimet Aluminium, Essen, Germany, has<br />
developed trimal-53, a new alloy for<br />
crash applications. According to the<br />
supplier, the wrought alloy is suitable<br />
for structural parts with high strength<br />
and excellent deformation capacity and<br />
meets the requirements of all wellknown<br />
automotive manufacturers for<br />
light metal materials for corresponding<br />
safety-relevant vehicle components.<br />
According to the company, the<br />
wrought alloy trimal-53 (AlMgSi) achieves<br />
strengths in the range of more than<br />
270 MPa. With an elongation at break<br />
of 10 % and more, the new material<br />
also meets the high requirements for<br />
compression behavior at this level. In<br />
this way, the new material is said to<br />
achieve higher component strengths<br />
with the same wall thickness compared<br />
with conventional alloys. In addition,<br />
the wall thickness can be reduced while<br />
maintaining the strength. This allows<br />
the weight of the component to be<br />
reduced without compromising safety<br />
standards. The alloy can thus be used<br />
Left: Intact structural casting; right: Structural<br />
casting after crash test.<br />
for different dimensioning targets and<br />
enables the cost-effective production of<br />
structural components. Components<br />
made from the material can also be<br />
joined thermally or mechanically with<br />
other materials such as cast nodes in a<br />
production-safe manner. If necessary,<br />
Photo: Trimet<br />
Trimet adapts the alloy to the specific<br />
requirements of the application.<br />
The Research & Development<br />
department of the family-owned company<br />
developed the new alloy from the<br />
so-called 6xxx series. Wrought aluminum<br />
alloys of this series are established<br />
materials in automotive engineering.<br />
They have good strength and<br />
formability and are also corrosion<br />
resistant. The alloy group is used in<br />
many areas and promises problem-free<br />
recycling. In the new material, too, the<br />
main alloying elements magnesium and<br />
silicon provide the basic strength. Other<br />
elements make the material finegrained<br />
and resistant to quenching.<br />
Homogenization produces a microstructure<br />
with predominantly round structured<br />
phases. This has a positive effect on<br />
the subsequent forming process. According<br />
to the supplier, the new wrought<br />
alloy is particularly suitable for extruded<br />
profiles according to BMW‘s delivery<br />
specification as well as for other<br />
applications.<br />
www.trimet.eu<br />
CASTING PLANT & TECHNOLOGY 1/<strong>2021</strong> 59
NEWS<br />
Mohammed Bin<br />
Rashid Al Maktoum<br />
Solar Park outside<br />
of Dubai, UAE.<br />
Photo: Dubai Electricity and Water Authority.<br />
BMW GROUP<br />
Carmaker relies on aluminum production<br />
from solar power<br />
The BMW Group will begin sourcing<br />
aluminium produced using solar electricity<br />
with immediate effect. This marks<br />
an important milestone of lowering<br />
CO 2<br />
emissions in BMW’s supplier network<br />
by 20 %, enabling it to avoid<br />
approx. 2.5 million tonnes of CO2 emissions<br />
until 2030. The aluminium is processed<br />
in the light metal foundry at<br />
BMW Group Plant Landshut. Sourcing<br />
43,000 tonnes of solar aluminium<br />
valued in the three-digit million euros<br />
will supply nearly half the annual<br />
requirements of the Landshut plant.<br />
Since producing aluminium is highly<br />
energy-intensive, the use of green<br />
power – such as solar electricity – offers<br />
considerable potential for reducing CO 2<br />
emissions. That is why the BMW Group<br />
also plans to source aluminium produced<br />
with green power in the long<br />
term. This is equivalent to about three<br />
percent of the CO 2<br />
targets the company<br />
has set for its supplier network. The aluminium<br />
produced using solar power is<br />
processed in the light metal foundry at<br />
BMW Group Plant Landshut to manufacture<br />
body and drive train components,<br />
including those needed for electric<br />
drive trains, for instance.<br />
The trend towards e-mobility means<br />
that without corrective measures, CO 2<br />
emissions per vehicle in the BMW Group<br />
supply chain would increase by more<br />
than a third by 2030. The company not<br />
only wants to stop this trend, but also<br />
reverse it – and even lower CO 2<br />
emissions<br />
per vehicle by 20 % from 2<strong>01</strong>9<br />
levels.<br />
The BMW Group has therefore<br />
already agreed with suppliers for its<br />
current fifth-generation battery cells<br />
that they will only use green power for<br />
producing battery cells. The BMW<br />
Group is now taking the next logical<br />
step by sourcing aluminium produced<br />
with green power. Because, as e-mobility<br />
takes off, aluminium will become<br />
increasingly important as a lightweight<br />
material that can partially offset the<br />
heavy weight of the batteries in electrified<br />
vehicles. However, producing aluminium<br />
is extremely energy-intensive.<br />
The BMW Group already has a<br />
long-standing supply relationship for<br />
primary aluminium with Emirates Global<br />
Aluminium (EGA). EGA has now<br />
become the first company in the world<br />
to also use solar electricity for commercial<br />
production of aluminium, which it<br />
will initially supply exclusively to the<br />
BMW Group. EGA sources the electricity<br />
used to produce the aluminium destined<br />
for the BMW Group from the<br />
Mohammed Bin Rashid Al Maktoum<br />
Solar Park in the desert outside of<br />
Dubai, which, in the final stage of<br />
development, is set to become the world’s<br />
largest solar park. It is operated by<br />
the Dubai Electricity and Water Authority,<br />
which has the electricity it produces<br />
sustainably certified by third parties,<br />
ensuring that it can supply EGA with<br />
power that is traceable and transparent.<br />
Abdulnasser Bin Kalban, Chief Executive<br />
Officer of EGA, said: “(…) Solar<br />
aluminium is a step in the right direction<br />
– it uses a natural and abundant<br />
source of energy in our desert environment<br />
to produce a metal that is vital to<br />
the future of our planet.”<br />
The light metal foundry is the largest<br />
production unit at BMW Group<br />
Plant Landshut and the company’s only<br />
European manufacturing facility for<br />
light metal casting. Last year, the more<br />
than 1,600 employees at the light metal<br />
foundry at BMW Group Plant Landshut<br />
produced a total of 2.9 million cast<br />
components. The scope of production<br />
includes engine components such as<br />
cylinder heads and crankcases, components<br />
for electric drive trains and large-scale<br />
structural components for<br />
vehicle bodies. The foundry also works<br />
with shaping sand cores, among other<br />
methods, to manufacture cast parts.<br />
The sand cores are produced using inorganic<br />
binders – making the casting process<br />
virtually emission-free. Five different<br />
casting methods are used for<br />
standard production of cast components.<br />
The most suitable casting<br />
method is selected, depending on the<br />
component concept, technological<br />
requirements and production volume.<br />
