Maintworld Magazine 1/2021

1/2021 www.maintworld.com

maintenance & asset management

Five Key Benefits of Improving

Operations with Modern p 6

Wireless Vibration Monitoring

THE DAY AFTER TOMORROW IN ASSET PERFORMANCE PG 10 PRECISION BELT ALIGNMENT AND WHAT IT ENTAILS PG 22 MONETIZING DATA IN MAINTENANCE PG 48

Mobius Institute wants to help you

ACHIEVE

YOUR GOALS

Accredited Certification

Course and accredited certification options for

condition monitoring and reliability practitioners.

Mobius Institute helps condition monitoring, maintenance,

and asset reliability practitioners, business leaders, and

strategic partners achieve the next level of success through

leading-edge training, ISO/IEC 17024 and ISO 18436-1

accredited certification, engaging conferences, and

educational websites.

Course Delivery Options

Training courses where and when you

need them.

Mobius Institute courses are available in the format that best

fits your needs, including instructor-led virtual courses via

GoToWebinar, instructor-led classroom courses, web-based

video courses, private virtual instructor-led courses via

GoToWebinar, or private onsite courses.

Books by Mobius Institute

Achieving optimal performance and

dependability without safety and environmental

incidents are within reach.

Read about Asset Reliability Transformation® [ART] a

step-by-step guide to delivering a value-driven reliability and

performance improvement initiative.

Solve + Learn + Share

MOBIUS CONNECT® knowledge sites,

community, and conferences.

MOBIUS CONNECT is the gateway to knowledge, solutions,

and friendship. Join a community of reliability, maintenance,

and CBM leaders and practitioners to keep on learning, solve

tough problems, and share your knowledge. Or attend a LIVE

training conference.

CREATE YOUR PROFILE TODAY! MobiusConnect.com

Training Courses & Accredited Certification

mobiusinstitute.com

and only at Mobius Institute...

ANIMATIONS

SIMULATIONS

ILLUSTRATIONS

LEARNING ZONE

QUIZZES

SURVEYS

Mobius Institute courses feature animations,

interactive simulations, and detailed graphics to

ensure that students enjoy the learning process and

understand the course content.

START HERE: mobiusinstitute.com

FOR MORE INFORMATION:

learn@mobiusinstitute.com

North America: +1 (239) 600-6828

Australia: (+61) (0)3-5977-4606

Follow us on social:

© Copyright 2021. Mobius Institute. REV:0321

Mobius Institute Board of Certification (MIBoC) is ISO/IEC 17024 and ISO 18436-1 accredited

EDITORIAL

Release the

power of data

AFTER OVER 20 YEARS working

with customers within maintenance,

I still do not see much focus

on the output of the CMMS:s. I see

two actions all companies should

take here. First, set the analysis

tools free for all users and bring on

the creativity!

Put effort in providing a userfriendly,

neat, and really attractive

tool for users. Let them be amazed

and baffled by the nice charts and

turning tables of data. Let them

twist the filters like there is no tomorrow.

Throwing the figures around

gets creativity going. Finding new

insights and possibilities you never knew of. More results and more good decisions

will come. New intrapreneurs will step forward.

I am a big fan of securing good data and having valid models of analysis. Users

not used to this will fall into easy traps and might present bad data charts…

there is always a learning curve.

When we within maintenance talk about KPIs and the importance to measure

and benchmark, we absolutely need secured data and valid models. Often

the data tools are built around that, with terrible static reports, printable, for

a few users. I have also seen some pretty good intentions – but very little in 20

years.

So, the second action needed is to set a good maintenance strategy with

defined goals and find needed data-points to measure. The more defined, the

easier to find out your measures. Here you set a few important KPI:s (Key Performance

Indexes) controlling your process. For the every-day running of business

there needs to be another bunch of measures. In order to know what to do

now, how to prioritise the day and week.

We call it to be Data-Driven. Knowing where to put effort, by fact. No estimates,

no fiction, but real data from all that hard work we have put into our

CMMS:s 24-seven for years. All those years... is the data at all in good quality? –

you will not know until you start looking.

At Trivalo we talk about Data-Driven Maintenance in the means of making

both strategic and operational decisions based on good data. No matter

on what level and how manual or automated. It is important that both the

long-term KPI:s and the operational measures are defined, communicated and

visual for all to act upon.

But, I am just saying. While setting your business goals and creating your

dashboards. Do not forget to release the data for all to play with. Analysis is a

free-form art of insights, fuelled by your creativity, and only limited by the tools

provided. Start playing with your data and learn how to move forward.

With love,

4 maintworld 1/2021

Mia Ilkko

Senior Consultant Data-Driven Maintenance at Trivalo AB,

B.Sc.; Cert. European Expert in Maintenance Management

24

The auto lubricant devices

have evolved to become

smarter. Many of them not

only dispense the lubricant

but can also set alarms based

on excessive feedback and

low lubricant.

IN THIS ISSUE 1/2021

32

Digitalisation

in the field

of capital goods cannot be

viewed as an isolated trend,

but must be embedded in

key current trends.

=

38

Keeping

the Lights On

and Preventing Failures.

SPI Inspections provides

customers with topnotch

utility system and

infrastructure inspections.

6

Five Key Benefits of Improving

Operations with Modern Wireless

Vibration Monitoring

10

14

18

The Day After Tomorrow in Asset

Performance

Next Level Energy and Alarm

Management in ICONICS’ Latest Release

We Succeeded, what is Next?

22

Precision Belt Alignment and what it

Entails / Easy

24

Bearing Lubrication Reimagined:

Remote and Real Time Friction

Monitoring and Lubrication

26

Safe Operation of Software-

Controlled Lifts

30

OPC UA including Ethernet TSN

and Ethernet APL for the field: An

intermediate goal has been achieved

32

Digitalisation of Production Systems:

getting smart while keeping out of

harm’s way?

38

42

46

Keeping the Lights On and Preventing

Failures

Cui Solution for Aging Plants.

Maintaining Production During Critical

Maintenance

Creativity Was – and Still Is – Needed in

Teaching and R&D Projects during the

Pandemic Time

48

Monetizing Data in Maintenance: Datadriven

Spare Parts Management –

Part 2

Issued by Promaint (Finnish Maintenance Society), Messuaukio 1, 00520 Helsinki, Finland tel. +358 29 007 4570 Publisher Omnipress Oy,

Väritehtaankatu 8, 4. kerros, 01300 Vantaa, tel. +358 20 6100, www.omnipress.fi Editor-in-chief Nina Garlo-Melkas tel. +358 50 36 46 491,

nina.garlo@media.fi, Advertisements Kai Portman, Sales Director, tel. +358 358 44 763 2573, ads@maintworld.com Layout Menu Meedia,

www.menuk.ee Subscriptions and Change of Address members toimisto@kunnossapito.fi, non-members tilaajapalvelu@media.fi

Printed by Reusner, www.reusner.ee Frequency 4 issues per year, ISSN L 1798-7024, ISSN 1798-7024 (print), ISSN 1799-8670 (online).

1/2021 maintworld 5

ASSET MANAGEMENT

Five key benefits of improving

operations with modern

wireless vibration monitoring

BY JOSE VERDUGO, vibration portables and wireless product manager, Emerson

As many manufacturing

organisations today move

toward wireless monitoring

technology, they

have more choices than

ever before. Users have

found tremendous savings

through monitoring technology

and yet have had

to guard against drowning

in data or merely looking

at the big picture rather

than details. Either condition

has meant potentially

overlooking issues that can

cause shutdowns.

RECENT EVOLUTIONS IN VIBRATION

MONITORING technology will bring users

beyond their previous successes

and assist with data digestion through

organised and understandable views

of conditions. With new technology in

hand, users can now more easily find

and address the root causes of machinery

issues.

It is important to bear in mind clear

guidelines while matching personnel

abilities and available time to the newly

evolved wireless monitoring technologies.

Manufacturers around the globe

who are choosing wireless monitoring

technology have found success by focusing

on key elements such as improved

safety, cost of implementation, decisionmaking

support, intuitive operation, and

overall return on investment.

6 maintworld 1/2021


Improved Safety

Monitoring for vibration in field equipment

is critical because it can signal bearing wear,

poor lubrication, and more – precursors to

hazardous conditions. But because safety is

the number-one priority in manufacturing

facilities, it is out of the question to send

personnel for route-based monitoring into

areas where a potential safety situation may

arise. However, monitoring must continue.

Recently at a UK processing plant, vibration

on an asset indicated impending failure.

Rather than expose personnel to risk

by performing manual vibration readings,

the facility chose to implement a wireless

vibration monitoring solution. Not only did

the technology enable technicians to make

fewer visits to a potentially hazardous site,

the monitor increased visibility to the condition

before it posed additional risks. Data

was delivered remotely away from the risk

to personnel and the facility team obtained

enough data to trend and find solutions.

Evolving with the technology, this company

could continue to improve their solution

by shifting to a technology that enables

them to move the vibration monitor to

different assets for temporary monitoring.

In addition, they could install a wireless device

– such as Emerson’s AMS Asset Monitor

– that could monitor up to 12 assets

simultaneously. When fewer devices are

required to monitor more assets, the team

needs fewer trips to the field and gains better

visibility.

Cost of Implementation

Cabling and equipment costs can prohibit

continuous, hard-wired online vibration

monitoring. In these cases, organisations

have typically substituted manual measurements

taken via handheld units. But

quite often, manual readings do not enable

the organisation to attain adequate

analysis and trending because the manual

readings require time and expertise. In addition,

to achieve the most accurate picture

of conditions, a facility might need a greater

variety of sensor input options such as

accelerometer placements.

One power producer moved to a wireless

solution that was versatile enough in

its configuration and installation to deliver

savings during implementation. The

organisation needed to monitor a motor

housed in a gas turbine auxiliary compartment

where a cabled monitor would not be

cost effective. Because the compartment

acted as a Faraday cage, they needed easy,

robust wireless connectivity. In addition,

they wanted to measure other rotating

equipment as required without overextending

maintenance personnel.

The solution they found included wireless

transmission and no need for expensive

cabling. It also included a wireless

vibration transmitter that instantly connected

to their network with no additional

wireless infrastructure, such as a repeater.

The transmitter and connected sensors

could be moved as needed and the accelerometer

configuration was flexible enough

to be easily adapted to the situation.

By embracing the next generation of

wireless vibration monitoring – for example

Emerson’s AMS Wireless Vibration

Monitor – the ease and speed in which

the power producer could implement

monitoring of additional equipment could

be increased greatly. With a standalone

device, which includes both transmitter

and sensor, installation and configuration

becomes extremely easy. These devices,

which can be preconfigured or configured

onsite using a wireless gateway or handheld

device, enable the company to place

at any location in the facility immediately

without needing to install and connect

separate sensors to the transmitter. This

gives almost instant access to readings

and complete visibility of the health of that

equipment.In addition, a longer battery

life and field-replaceable batteries means



the user can plan for less maintenance and

fewer trips to the asset being monitored. All

these capabilities mean faster deployment,

less engineering, and quicker return on

investment.

Decision-Making Support

Effective decision making relies on many

factors. For example, if operators receive

unfocused alerts or alerts presented in a

confusing format, they can become distracted.

To remain focused on the correct

problems and find ways to solve them, personnel

should have effective tools such as

online vibration monitoring.

Online vibration monitoring can help

predict when a failure will occur and alert

maintenance to prevent unexpected shutdown.

When personnel receive alerts via

wireless, they can more simply make the

right decisions because they have the information

at their fingertips.

In addition, wireless technology is an

enabler to help focus personnel’s attention

on the most important tasks to enable efficiency.

Solutions have offered alerts delivered

as intuitive health values that many

plant personnel can quickly interpret.

As users evolve with the wireless vibration

monitoring technology, they will be

able to receive alerts and interpret great

amounts of data from a variety of platforms.

In fact, the latest monitoring advances

make it possible for users, through Emerson’s

PeakVue Plus analytics, to immediately

determine the root cause of the defect

on a given machine. This power can provide

them a more sophisticated look at asset

health, including overall values, analysis parameter

trends, spectrums, and waveforms.

Intuitive Operation

Without intuitive operation, vibration

monitors might provide data without

follow-up from the facility team – ease of

use is key for follow-up action. Recently, another

UK end user needed their operators

to have information available easily and

quickly, so they chose to implement a solution

where vibration data was transmitted

directly from equipment to the control

system.

More than simply data, their solution

involved an intuitive health score through

Emerson’s PeakVue technology. The data

could be trended to determine when the

equipment was going to fail. This solution

enabled improvement of maintenance

scheduling while avoided taking equipment

offline when failure was not imminent. And

because the information was continuous

EVOLUTIONS IN VIBRATION

MONITORING HAVE PROVIDED

AN ALTERNATIVE TO ROUTE-

BASED AND CONTINUOUS

MONITORING USING HARD-

WIRED DEVICES.

and always available, personnel did not

need to wait for collection or its subsequent

analysis.

As wireless vibration monitoring

evolves, the users of PeakVue technology

can choose monitoring devices that are

supported through embedded prescriptive

analytics powered by technology such as

PeakVue Plus. The embedded intelligence

enables teams quickly and easily to differentiate

between mechanical problems

– such as rolling element bearing defects

– and root-cause issues such as insufficient

lubrication.

Return on Investment

Assets that are monitored using wireless

vibration can significantly impact the plant.

Facilities find that they incur reduced impact

when make repairs are made during

scheduled rather than unscheduled downtime.

Return on investment is often found

by avoiding total asset failure, which can often

cause irreparable damage and requires

costly replacements of entire assets.

A recent case proved the point at a power

company that relied on a primary motor

for continued operation. A shut down for a

total overhaul would have reduced output

capacity by 200MW and cost as much as

£50,000 in lost revenue. Using a wireless

vibration transmitter, the facility optimised

their time and fixed the motor when market

conditions minimised financial impact,

and ran throughout the interim with

wireless vibration monitoring continuing

through the overhaul. The data that was

sent to the control system in that interval

freed up maintenance to do other jobs and

keep their maintenance schedule.

The next step for the company could be

to choose a wireless monitor that can be

immediately placed on the equipment to be

monitored without the need for any wiring.

This less complicated and less costly solution

helps to speeds the return on investment

for the user.

Conclusion

In general, evolutions in vibration monitoring

have provided a true alternative to

route-based and continuous monitoring

using hard-wired devices. Users now can

choose a solution that provides the raw

data for deep-diving in tandem with the

prescriptive analytics and tools to diagnose

the underlying problems. Wireless has built

a foundation for strong benefits discussed

here and has expanded so much in recent

years that users can take those benefits to

new heights by updating and expanding

their wireless technology.


ASSET MANAGEMENT & TECHNOLOGY

The Day After Tomorrow

in Asset Performance

Peter Hinssen is an entrepreneur, focused on start-ups for almost 20 years. He is a

technologist at heart. About eight years ago, he decided to spend more time on telling

the story about technology. He started teaching at MIT in Boston and London Business

School (UK), and wrote a few books on how technology is changing the world.

PETER HINSSEN BIOGRAPHY

Peter Hissen is a serial entrepreneur, advisor,

keynote speaker and author, Peter lectures

at various business schools such as

the London Business School (UK) and MIT

in Boston. Peter has founded nexxworks to

help organizations become fluid, innovate

and thrive in 'The Day After Tomorrow'.



Peter will be talking at the Asset Performance

Awards about how companies

and technical services can prepare for

the future. How can you help your company

in staying relevant The Day After

Tomorrow?

Peter, you will be present as a

keynote speaker at the Asset

Performance Awards. Can you

explain where your interest in the

industry comes from?

It is a little bit personal because my father

worked in the oil and gas industry

his entire life, specifically Maintenance

and everything that deals with process

control. So, when I was a kid, it was all I

heard from my dad coming home. And I

think the evolution that you see in this

industry is fascinating. New technologies

are changing, in my opinion, tremendously:

dealing with assets, managing

performance, and thinking about prediction

is going to change tremendously. So,

I'm very excited to be part of this.

Can you give some examples of

technologies that will impact our

world?

Big Data. I mean, this is an industry that

has always been interested in information.

But now Big Data is becoming

abundant. We have technologies to deal

with that. We have machine learning,

artificial intelligence, all these mechanisms

of connectivity. I think if you put

it all together, it's piling up technology

after technology that is fundamentally

changing how we think about how to

deal with data. And I think it will have a

tremendous impact on this industry.

What do you think the main

challenge of the industry today is?

We're currently in a disruptive era. I

use this word carefully, but it indicates

a constant acceleration and the need to

follow that speed. Lots of companies see

a huge conflict between possibilities and

reality. So this gap and tension between

what is possible and what you do day to

day is a big challenge. We need to take a

huge leap in skills and technology. This

is also an opportunity to become more

critical of your company. Performance

plays an important rule. And the reason

why your company exists is absolutely

core. But be careful what you wish for.

Because once you enter the spotlight,

you've got to deliver. Take up your role

and realise it.

What makes it so difficult to take up

this role?

Being able to tell the story and carry it

out. Storytelling is key. IT people should

be rock stars, but most of the time

they're not so communicative. That's

because they don't have the skills to tell

their story. If you go from predictive

maintenance to Asset Performance in a

connected world, then you have so many

touchpoints, that you have to broaden

your gaze. You need more skills and

competences. Your suppliers change.

Your partners change. And everything

becomes more fluid.

In your book ‘The Day After

Tomorrow’, you're talking about

what is going wrong in companies

today. What is your vision?

Well, I have a very simple idea of how

much time companies spend on today,

tomorrow, the day after tomorrow. Most

companies are very busy with today.

And when they look at the future, they

often extrapolate today, they think that

tomorrow is approximately the same.

But we're now facing so many different

changes that there might be changes in

business models or in technologies or

new players coming onto the market.

We have to think about this disruption,

'this is the day after tomorrow', and how

you deal with that. When I talk about

today, tomorrow, the after tomorrow,

many people say they dedicate 70-20-10

percent of their time on it. The reality

is we spend 93 percent of our time today,

maybe 7 percent thinking about

tomorrow and virtually none in the day

after tomorrow. And I think in many

industries, this was okay and in the 20th

century. But we're now fully in the 21st

century. That doesn't work anymore. We

have to be much more flexible and agile.

And that's why the day after tomorrow is

more important than ever before.

You will also talk about two

interesting concepts: staying

essential and staying relevant. How

can we achieve that?

Of course, you want to be essential. You

want to do something that makes sense.

If you do predictive maintenance, that

is essential. If you work for customers,

you're hoping that you are vital for

that customer. But the other question



is, how relevant are you? And I think

there's a very clear difference between

essential and relevant. And I think an

exampleis the telecoms industry. If you

look at telecoms 10 years ago, a telecom

operator was essential. You needed a

SIM card, and they were relevant, they

gave you added value. In today’s world,

they are still essential, because you still

need that SIM card. But the relevance

has dropped. And therefore, if whatever

capacity you have in an organization,

whatever position you have in dealing

with the outside world, that is the core

question, are you essential? I hope you

are. But how can you make sure that

your relevance doesn't go down?

And that brings us to the maintenance

and quality department. They

don't add value directly to the product.

The customer doesn't pay for

maintenance that was necessary to

produce his product. But it is essential.

So, what would your tip be to

staying relevant?

Well, I think it's because we're in an age

where everything is interconnected. So,

if you look at an organization, they are

not silos anymore. We're in this network

age, everything is connected to everything.

So, when you say that your customer

doesn't pay for the maintenance

directly, that's true, but your customer

will feel, see, and understand whether

this is something which is integral in

terms of quality thinking or performance

management. And in the end, if

your company wants to be flexible and

fast and agile, you have to incorporate

that into every part of the organization.

Every fibre, every node, every element

has to understand that you are part of a

bigger picture, and you have to keep reinventing

itself to be both essential and

relevant for the outside world.

On the other hand, in our industry,

there are a lot of service providers.

They are companies that perform

maintenance activities and make

services. How is this new and how

will they need to evolve?

We're more and more in this age of networks,

thinking about ecosystems, the

role that they play is different. We're

beginning to see the old "I supply a

product and that's it" is over. It's more

and more a service type of activity. And

what you see is, instead of the traditional

boundaries, we get fluidity, we have

more and more of that network and ecosystem

type thinking. And that means

that you're going to have new players

entering the market very, very quickly.

You're going to have traditional players

who must reinvent themselves. And you

have different types of partnerships and

agreements that we need to figure out.

And I think figuring out what your role

is, as an external provider in this sea of

fluidity in a connected world is going to

be very fascinating.

This connectivity is entering a lot of

factories. They are experimenting,

but we see some reluctance and

difficulties to scale up. How can you

solve that?

Well, I think we're in a phase where a lot

of the technologies are emerging. Take

something like AI or machine learning

that's relatively new. Most people don't

understand it very well, there is a huge

skill gap that we need to fill, because

we need to train and prepare people for

that. But a lot of things are just trying

out, companies are experimenting and

figuring out how to apply this, but it's a

very early game.

If you compare that to the PC industry,

this was the time where we had

Commodores and Ataris, and not the

established industry like we have today.

We're going through that phase. And if

you're too early, you're going to burn a

lot of money and not get a lot of results.

But if you wait too long, you probably

run the risk of becoming completely

obsolete. I think it's making sure that

you're constantly in tune that you're

constantly alert that you follow this as

closely as possible and make the right

move at the right time. But you can only

do that if you are prepared.

How can people prepare for this skill

challenge?

I think they have to make time for it.

Time is the biggest issue. To put your

day-to-day work at the side is difficult,

but you really must invest in these skills.

Experiment at first, like tinkering with a

fuse until something blows up. There are

so many possibilities, also online, to test

and try out different stuff. Everybody

talks about life- long learning, but most

managers don't do it themselves.

Why should people attend your

keynote at the Asset Performance

4.0 Conference?

I think this is one of the most fascinating

industries that for a long time, has

already worked with data. But it's now

making a quantum leap. I'd love to talk

about how I see that evolving, I hope to

inspire you to maybe even do more than

what you're doing today. But above all,

to prepare us for, I think, a very disruptive

wave that is going to affect everyone.

And I think if we understand this,

we can all actually come out even better

as a result.

INFORMATION

CHECK OUT more information

on the Asset Performance 4.0 Hybrid

Conference & Exhibition 2021 via

www.assetperformance.eu/2021


Scan me

Hybrid Conference & Exhibition

October 26-28, 2021

Antwerp, Belgium

The 4th Industrial revolution, IoT and predictive

analytics are bringing unseen possibilities in

maintenance, reliability and condition monitoring.

The Asset Performance 4.0 Conference & Exhibition offers a

unique opportunity to learn how new 4.0 technologies and

fundamentals in operations, maintenance and asset

management reinforce each other in order to achieve higher

equipment reliability and cost performance in asset intensive

industries.

DIAMOND SPONSORS

GOLD SPONSORS

√

3 day conference with workshops & in-depth expert

presentations.

SILVER SPONSORS

√

Exhibition with +50 exhibitors.

√

+100 presentations to watch live or online when you want.

√

Extensive networking opportunities with peers & experts.

√

Keynote by Peter Hinssen (entrepreneur & MIT lecturer).

√

Register now & get access to an extensive database of

+100 recordings of the conference sessions of Asset

Performance 4.0 2020.

BRONZE SPONSORS

EARLY BIRD REGISTRATION NOW OPEN

Powered by

www.assetperformance.eu/2021

PARTNER ARTICLE

Next Level Energy and

Alarm Management in

ICONICS’ Latest Release

ICONICS is a global automation software provider of advanced industry 4.0 Webenabled

OPC UA and BACnet certified visualization, analytics, and mobile software

solutions for any energy, manufacturing, industrial, or building automation application.

This year marks a few milestones. Within 2021, ICONICS will mark its 35th year of

operations, doing so within its first full year as a group company of Mitsubishi Electric

Corporation, itself celebrating the 100th anniversary of its establishment.

THIS YEAR also marks the release of

the latest version of ICONICS Suite:

version 10.97. With this latest release,

ICONICS has addressed a wide variety

of customer challenges through innovative

technological solutions and

enhancements across its automation

MELISSA TOPP,

Senior Director of

Global Marketing,

ICONICS,

melissa@iconics.com

software lineup of data visualization,

archiving/rapid retrieval, analytics,

mobile apps, and edge to cloud connectivity.

Some of the new additions

include ICONICS’ connected field service

software, CFSWorX’, integration

with Maximo, ServiceNow, and Azure



ICONICS SUITE VERSION 10.97 CONTAINS MULTIPLE DATA VISUALIZATION,

ANALYTICS, HISTORIAN, MOBILITY, AND CLOUD CONNECTIVITY SOLUTIONS.

Active Directory and support for load

balancing. The Data Exporter within

ICONICS’ high-speed data historian,

Hyper Historian, now supports Azure

Data Lake Generation 2 and other scalable

cloud storage services. Also newly

added are Sankey Diagram controls,

available for use across any of ICON-

ICS’ visualization environments on any

desktop, laptop, web browser, or smart

device.

This issue of Maintworld highlights

energy management and condition

monitoring in maintenance applications.

Solutions for both of these requirements

are included within version

10.97 of ICONICS Suite, as well.

Energy AnalytiX® for Energy

Management

Energy management systems help to

deliver rich platform and browserindependent

real-time visualization

of energy use. Such software can address

any size application, from a single

building to an entire campus or multisite

enterprise. Energy management

system software also involves monitoring,

analyzing, and improving organizational

assets. It helps to optimize en-

ergy usage of buildings and equipment

and can help identify energy-related efficiency

issues in production processes.

It also helps to simplify workflow for

maintenance personnel and field operatives.

With such software tools, users

can create IT firewall-friendly, secure

custom energy dashboards and kiosks

to view reports for analysis of energy

consumption patterns, resource usage,

and progress on sustainability efforts.

Maintenance personnel, site managers,

and building engineers can quickly

and intuitively navigate energy-related

data and discover opportunities for improvement.

ICONICS’ energy management system

software, Energy AnalytiX®, provides

open universal data connectivity

and enterprise integration to a wide variety

of building management systems

(BMS), SCADA, enterprise resource

planning (ERP), and control systems.

Managers of commercial or government

buildings, university campuses,

and industrial plants can use this revolutionary

smart energy software solution

to configure, customize, operate,

and improve. Energy AnalytiX includes



built-in calculations, KPIs, analytics,

data historian, reporting, and the rich

visualization needed to take decisive

action to reduce and manage utility

costs and consumption.

Energy AnalytiX can be deployed

quickly in order to more swiftly

achieve return on investment. Integration

with a wide variety of existing

meters, coupled with preconfigured

charts, helps to reduce the engineering

time involved. It can also help

realize cost savings through informed

decision-making, as organizations

frequently seek ways to reduce consumption,

monitor conditions, lower

energy costs, and minimize carbon

emissions. Energy AnalytiX provides

in-depth comparison and visualization

of energy costs.


ENERGY ANALYTIX NOW

UTILIZES INFORMATIVE SANKEY

DIAGRAMS TO HIGHLIGHT

INFORMATION FLOW.

ICONICS energy management software

comes with the ability to provide

standard cost, consumption, and carbon

reports. Charts can include consumption

(electric, wind, solar, steam, gas,

water, and/or cogen), costs (electricity,

steam, water, and/or gas), conditions

(occupants, equipment runtime, sun, air

handling unit, zone footage, outside air

temperature [OAT], and/or component

count), and carbon (carbon dioxide and/

or methane). Energy AnalytiX can also

integrate with a wide array of meter

types, featuring compatibility with manufacturers

in multiple energy-related

categories (electric, wind, solar, steam,

gas, water, and/or cogen), which helps

toward quicker configuration and ROI.

With Energy AnalytiX, users are able

to drill down into the causes of abnormal

energy use. Asset-based management

provides setup and configuration

to any level of aggregation. Users can

drill down to specific sources of energy

efficiencies and locate suspected consumption

offenders. The software is also

widely scalable, from a single building

to a large campus to a global enterprise

location portfolio to even an entire city.

In the latest version 10.97 release,


FREE TRIAL DOWN-

LOAD OF ICONICS SUITE

VERSION 10.97

Visit https://iconics.com/Downloads/

Download-ICONICS-Suite to download

a trial copy of the latest version

of ICONICS Suite, including both

Energy AnalytiX and the new Hyper

Alarm Server.

Energy AnalytiX’ data model and sample

dashboards have been updated to

utilize the previously mentioned Sankey

Diagram control. Sankey diagrams help

illustrate information flow between

different sources and destinations.

The Sankey diagram expects a dataset

with three columns: a source, a destination,

and a weight. In runtime, the diagram

intelligently draws the correctly

weighted lines between each source and

destination. Optionally, gains and losses

can also be visualized, while the colors

and shapes of the nodes and links can be

extensively customized, if desired.

Condition Monitoring and

Improved Alarm Management

ICONICS provides multiple software

tools capable of condition monitoring,

VERSION 10.97 INTRODUCES

HYPER ALARM SERVER, THE

NEXT GENERATION OF ALARM

MANAGEMENT.

as well as remote systems management.

One aspect of condition monitoring that

ICONICS has advanced, specifically for

its version 10.97 release, is alarm management,

with the result being its new

Hyper Alarm Server product. Hyper

Alarm Server offers ISA 18.2-compliant

and redundant alarming using all new

technology, allowing for better performance,

more control, native integration

with ICONICS product communications,

and easy, intuitive configuration

via ICONICS’ asset-based management

system, AssetWorX.

ICONICS Suite version 10.97 still

includes the existing AlarmWorX64

Server solution, but users are encouraged

to experience the added benefits of

Hyper Alarm Server. One such feature

enables access to historical data for each

tag, making it even easier to configure

rate-of-change or similar alarm types.

Another allows for unlimited related

values, empowering users to analyze

alarm information from a creative array

of new angles. ICONICS believes Hyper

Alarm Server represents the future of

advanced SCADA systems for its unparalleled

performance and extensive

functionality.

Also new in the Hyper Alarm

Server, users are able to define alarm

types, which act as a template or class

for alarm tags. The type defines the

core logic behind an alarm, its states

or conditions, when it is evaluated,

and more. The sample Hyper Alarm

Server configuration includes several

of the most common alarm types. In

comparison, AlarmWorX64 Server

had a set of hard-coded alarm types –

such as digital or limit – that worked

in very specific ways. Users with specific

needs could not always get the

alarm behavior they needed. Hyper

Alarm Server alarm types give users

the freedom to customize the way

alarms work without having to implement

counterintuitive workarounds

or request product enhancements.

Hyper Alarm Server is also available

for edge devices running ICONICS’

Internet of Things compatibility software,

IoTWorX.



We succeeded,

what is next?

Back in the fourth quarter of 2019, SDT

team assisted LUBExpert implementation

(parallel to Condition Monitoring

implementation) in wastewater facility

in SE Europe, with the primary target of

improving lubrication practice on 180

assets (more or less 700 bearings).

THIS TASK MIGHT sound simple and straightforward, still it

highly depended on many real condition facts. A relatively

small team was working on several improvements at the same

time: Condition Monitoring (CM) and Lubrication. A small

team, in this case, means: two technicians engaged in CM activities,

one grease technician and the maintenance manager

playing the role of reliability engineer, lube manager, CM engineer

as well as many others. Certainly, it was not an easy task

for the team, and certainly it was not as it should have been, but

that was the reality and what was approved by decision makers.

Obviously, that was one of those situations when management

gives you less than you need to succeed, promising to give

you more once you succeed. Catch-22, but it is something we

face often, making the process more challenging and rewarding.

To make it happen, our grease technician was trained to the

level of LUBExpert Strategist, understanding Why job needs

to be done, What needs to be done and How, and being able to

perform entire setup, execution and reporting. Proper selection

of lubricants, controlled purchase process, proper storage,

cleanliness… all was included in the process, of course. Once

started, the gained experience resulted in growing confidence,

increased work efficiency, well organized work orders and

smooth execution. Once grease guy, now LUBExpert Strategist.

However, there was another aspect of implementation that

was highly important for the success of the entire program. Do

more than required with less than needed.

Critical point of implementation was the proper positioning

of each department (CM and Lube) and interdepartmental cooperation,

considering available resources. The approach applied

(knowing LUBExpert’s capabilities) was to erase departmental

fences and silos and set it more like an army formation:

• first line of defence – grease bearings right and eliminate

mayor cause of failures;

• scouting – frequent data collection and trending, share data

and locate anomalies;

• light calvary – collect dynamic (TWF, FFT) data for analytic

purposes;

• heavy artillery – deeper analysis, problem definition, root

cause definition (and elimination).

Lots of work and lots of tasks

for a small team.

As usual, Pareto’s 80:20, fits in from all angles. 80 percent of

problems come from 20 percent of activities, 20 percent of

problems require 80 percent of available time to be analysed …

and so on.

Although it may sound ambitious, we assigned first two tasks

to our Lube team/technician:

• First line of defence – Lubrication department job, for sure

• Scouting – CM job, normally

Some call it a burden too big, some think it is impossible, we

consider it an integral part of LUBExpert strategy. Whoever

is taking care of Lubrication, has his hands-on assets more


frequently than anyone else in the Reliability team, and has

the most interactive relationship with the asset. LUBExpert

Specialist (in this case also Strategist) is collecting data for

Lubrication purposes, has an opportunity to monitor and

trend data before and after replenishment condition, possess

the data collected and analysed during replenishment.

Knowing that, LUBExpert Strategy easily takes care of

the first two tasks, bringing huge benefits to the CM team by

giving them the most valuable data, and consequently time!

More available time for deeper analysis, problem definition,

root cause search.

At the end of the first year of the LUBExpert program implementation:

• Lube technician took care of 35 – 40 bearings per day (per shift)

• That includes work task preparation, data collection,

on-site analysis based on triggered alarms, LUBExpert

guided grease replenishment, data overview and possible

strategy corrections, and reporting.

• All bearings showed an excellent response (as one in

the picture 1 below), operating at minimum friction and

wear level:

• Process statistics (as shown in picture 2 below) showed

high level of performance, correct lubrication practice and

strategy settings, as well as additional observations and condition

assessments:

• Q4 2020 compared to Q4 2019 shows significant decrease

of bearings related failures in rotating assets;

• Q4 2020 shows no Lubrication related failures, except

ones inherited from previous period;

• Full traceability and detailed data about each process

achieved;

• Data shows that most of the previously used interval and

quantity plans were incorrect;


• LUBExpert Strategy was successfully implemented.

In addition:

• Lube technician delivered 12.500 Ultrasound readings to

CM team, including static trend graphs, triggered alarms, before

and after grease replenishment values, all relevant events, all

taken actions;

• Lube technician delivered 18 “Suspected bearing failure”

warnings to CM team;

• Lube technician delivered 10 “Safety risk” warnings to everyone’s

attention.

First year of the implemented program can now be safely declared

as successful. As usual, once you succeed, there comes the question:

“What’s next?”

For the Lube team, “next” equals expanding the program to the

entire plant and sustaining top performance.

For the CM team, “next” equals covering more assets, covering

more failure modes, digging deeper into analysis to define a root

cause, suggesting corrections to remove root cause, and suggesting

improvements.

So, first, we need to look at the accomplished results and assigned

tasks, once again emphasising the necessity to remove departmental

division and silos mindset and conclude that both tasks

are actually one. The question that we really needed to answer was:

“How can the Lube team further assist the CM team to accomplish

more with less or the same resources?”

Again, more work on Lube tech shoulders?

Not really, the answer is: LUBExpert Dynamic.

LUBExpert Dynamic is equipped with an additional feature:

collects Dynamic data (TWF, FFT) while performing usual LUBExpert

work. No additional time needed, no additional training

needed, no additional efforts, only additional benefits. Those benefits

are exactly what the CM team needs to accomplish.

Now, out of four army style operating segments, we can add

one more to Lube team without creating any additional stress on

our Lube tech, but freeing huge amount of time for our CM team:

• First line of defence – Lubrication department job, for sure

• Scouting – CM job, normally

• Light calvary – collect dynamic (TWF, FFT) data for analytic

purposes

What does it mean for Lube tech during his daily work? Absolutely

nothing.

• Dynamic data is collected in the background.

• Remember this from above?

• Lube technician delivered 12.500 Ultrasound readings to

the CM team, including static trend graphs, triggered alarms,

before and after grease replenishment values, all relevant

events, all actions taken.

Now add the same amount of Time Waveform and Spectra, that

normally requires the work of an additional technician.

One more task off the shoulders of the CM team and a huge

opportunity for them to increase coverage, dig deeper and have

more time for analysis and problem solving.

Each Condition Monitoring team knows exactly how big this

benefit is and how it improves CM efficiency.

Here is how it looks like in the first week of implementation.

Bearing successfully greased with declared condition as “Suspected

bearing failure”, TWF and Spectra collected before and

after grease replenishment (picture 3):

Before grease replenishment

After grease replenishment

Lubrication as part of Condition Monitoring? Well, shouldn’t it be that way? The first line of defence has just become a Maginot line.


LUBExpert

Grease Bearings Right

DOUBLE DATA COLLECTION

NO ADDITIONAL ATTENTION

NO ADDITIONAL RESOURCES

NO ADDITIONAL TIME

The LUBExpert Dynamic Option delivers advanced analysis of bearing condition.

During grease replenishment, dynamic data is captured in the background.

These outcomes are fed to the condition monitoring team

to help assess real-time bearing condition.

sdtultrasound.com


Precision belt alignment

and what it entails.

JOHN LAMBERT, Benchmark PDM.

John has a lifetime of experience measuring and

aligning machines. He is also a contributor to the ANSI/

ASA standard for rotating machinery. BENCHMARK

PDM Inc. provides the industry with instruments for

reliable machinery installation and maintenance.

The term Precision Maintenance is

popular in today's maintenance world.

What it means in a simplistic way, is

to work to a known set of tolerances.

FOR EXAMPLE, when we overhaul a machine

– say a gearbox or pump – precision

maintenance promotes that we measure

the bearing bores not only for the diameter

but also the ovality, how round it is.

This is to ensure good bearing fits and

there is a known tolerance for this work.

Unfortunately, many may take that care

during an overhaul but then they install

that machine back onto a base that is not

flat and now the machine's casing that

they have measured precisely is distorted

because of the base. There is also a known

standard for base flatness however, many

do not know this or have the capability of

measuring it. The point about precision

maintenance is that the precision needs

to be all inclusive from start to finish.

Precision Maintenance includes the

overhaul and the installation, and it is the


key factor in machine (asset) reliability.

Fortunately, we have known standards

that we can use for shaft-to-shaft

driven machines (ANSI standard) but

not belt driven machines. Have you

ever conceded how imprecise belt

driven machines are installed? And

that it is a fact that the maintenance

industry spends millions each year

replacing sheaves, pulleys, and belts?

Most of these installations are done

well before their full life expectancy is

reached.

A major reason for this is that we do

not install these drives to a standard

tolerance as there does not appear to

be any for belt alignment – one published

from a recognized organisation

like ISO or ANSI. If you search the internet

you will find Guidelines such as

the one below which comes from Ludeca

who’s a known expert company in

the field of alignment and this is one of

the only ones we currently use.


Surprisingly, we do not see too much information from

the belt manufacturers and what we do see is not particularly

good. From one large North American manufacturer, in their

Technical Information Library, they provide a paper showing

the right and wrong way to use a string to align two sheaves.

This is a major reason why we have premature belt failure. By

promoting the use of string or even a straightedge, prompts

the belief that close enough is good enough.

The company also says that a general rule of thumb is to get

the alignment within 0.5 degrees for V-belts. Can you imagine

a tradesman using string and trying to get a tolerance of 0.5

degrees? You would think the days of using a string or for that

matter a straightedge are in the past, but they are not unfortunately.

At a minimum you should be using a visual Laser based

alignment system or better still, a digital laser belt alignment

system.

Belt drives systems have changed. It is rare to see a single

(strand) belt drive system, most are multiple (strand) belts. We

also have flatback (banded) V belts (as on the main picture) as

well as timing belts which are much more common. This means

these belt drives are much more susceptible to misalignment. To

align these belts requires a great degree of accuracy. Rather 0.1

degree than 0.5. We still need to measure the same parameters

which are explained in the picture below.

Angular misalignment in

vertical plane

Angular misalignment in the

horizontal plane (aka Toe-out

and toe-in)

Parallel / Offset misalignment

in the axial plane

A combination of misalignments

is probably most common

Notice that in the graphic above, in each form of misalignment

the belt runs against the wall of the sheave groove. Obviously,

this is the cause of the belts drying out becoming hard

and then brittle due to the increased friction. It is the reason

why the hardened belt wears out the sheave. It is also the reason

why sheave grooves do not wear evenly, and therefore we do not

recommend that you use them to align the sheave. Just a small

amount of sheave wear might cause an angular deviation when

aligning. For example, 0.1° equals almost 70 thou (1.8 mm) offset

at 40 inches (1 meter). If you are using a laser system, we recommend

that you use the walls of the sheaves and align them.

The reason why is that it is a large flat (machined) surface area

that we can attach to and have the laser beam be parallel to this

surface, it is the reference point from which we measure. Your

target or detector is mounted on the other sheave wall surface.

Now let me tell you what the most ignored issue in belt

alignment is. It is the fact that many sheave walls (faces) are

mismatched, meaning not the same width. When we used string,

straightedges and even some models of visual laser system, we

never aligned them correctly because we never compensated

for this variable offset. And just like belt drives have changed, so

have the tools we can use to align them. If you are using a digital

laser system you can quite easily input the sheave wall dimensions

and the laser system will automatically compensate for

you. If you want precision alignment you will need a digital laser

alignment system for this reason alone.

Different sheave wall (face)

width will cause problem if

not taken into consideration.

Left picture, As Found. Right picture, As Left. With a digital tool this can be documented.

Another reason is that if you are trying to use Precision

Maintenance Techniques you will want documentation. And

a digital laser can give a quantifiable, measurable result, a

numeric value. If we are using string, straightedge or even

visual lasers, there is no quantifiable result. But more than

this, it will give you a documented result including an As

Found and an As Left result. It will also tell you whether the

sheave wall has been compensated for. This is important

because along precision maintenance, asset reliability goes

hand in hand and if you did have to do breakdown analysis

on this machine without documentation, you would only be

guessing as to what happened during the installation.



Bearing Lubrication Reimagined:

Remote and Real Time Friction

Monitoring and Lubrication

What if we could lubricate our bearings remotely, from any device, making sure

that the right amount and right lubricant are always used – and even better, based

on bearing condition? Then we would address the 3 main lubrication issues which

cause most of early bearing failures. Today this is already possible. Using ultrasonic

sensors and single point lubrication devices, all connected to a central system, we

can now bring lubrication practices to a whole new level!

Prevention in place of

monitoring

We have a serious problem with bearing

condition monitoring! Technology is

making it easier and more cost-effective

to monitor our bearings in real-time and

as a result, we are seeing sensors and

systems being installed on equipment at

an exponential rate.

There is a race from these monitoring

systems to detect the onset of failure

(Point P on the P-F curve) at the earliest

possible point. And this race to detect

a failure is a serious problem. We are

spending more money and extra TIME

to detect a failure when we should be

preventing that failure in the first place.

Addressing lubrication

issues – the root of most

bearing failures

It is no secret that over 80% of

premature bearings failures can be

traced back to lubrication related

issues. These issues can be put into

three general categories: inadequate

lubrication (over or under lubricated),

wrong lubricant, and contamination.

When it comes to addressing

premature bearing failure, reducing

the impact on just one of these issues

can have a large impact on the bearing

life. But when we start to address

all three, then we can reach excellence

in our lubrication programs.

It’s all about the friction levels

A lot of expertise needs to be designed into

the bearing selection and lubrication requirements,

no technology will likely ever

replace the need for trained and experienced

lubrication experts. But when it boils

down to it, it is all about friction - that’s why

they are called anti-friction bearings.

Once the correct bearing is installed

properly and the right lubricant is chosen,

it comes down to managing that friction in

the bearing by using the correct regreasing

volume and frequency. Simple to understand

but often difficult to put into practice.



Time based lubrication

vs condition-based: using

ultrasound to avoid under and

over-lubrication

One technique is to use time-based lubrication.

In this case, regreasing is done based

on time, with a predetermined amount of

grease. This method is often based on an

ideal calculation that is not reflective of the

real-life condition that influences the friction

in the bearing. This often leads to under

greasing or over greasing the bearing.

A step-change in lubrication practices

came with condition-based lubrication.

Using ultrasound to measure the friction

in real-time to determine exactly when

lubrication (and how much) is required to

bring the friction back to or near the ideal

level. Moving to ultrasound-assisted lubrication

will ensure we do not over or under

lubricate but has still not addressed the two

other lubrication related issues: using the

correct lubricant, and contamination.

What about automatic

lubricators?

To address these two other lubrication

issues many have turned to automatic lubrication

devices or auto lubers. Automatic

WHAT IF WE WERE ABLE

TO COMBINE THE PROVEN

PRECISION AND BEST

PRACTICE OF CONDITION-

BASED LUBRICATION USING

ULTRASOUND WITH THE

CONVENIENCE, SAFETY, AND

ACCURACY OF AUTOMATIC

LUBRICATION DEVICES?

lubrication provides a safer and more convenient

method of supplying the precise

amount of lubricant into the bearings on a

more frequent basis.

These devices ensure we always use the

correct grease stored in the device but also

reduce or eliminate the possibility of contamination

caused by the operational environment.

These devices are time-based and

set to dispense lubricant on a set frequency

or run time.

The auto lubricant devices have evolved

to become smarter. Many of them not only

dispense the lubricant but can also set

alarms based on excessive feedback and low

lubricant.

The best of two worlds:

SmartLube – single point

lubricator, remotely operated,

based on friction levels

We have two solutions addressing the different

aspects of the common lubrication

issues. On one side we have ultrasoundassisted

lubrication, using friction to determine

when and how much lubrication is

required. Combined with good lubrication

practices, it will provide benefits but still

requires an investment in time and training

to ensure the proper lubricant is used to reduce

the potential of contamination.

On the other side, we have automatic lubrication

devices ensuring the correct, contaminant-free

lubricant but still based on

time or running hours versus the condition

or friction in the bearing, often still leading

to not optimizing lubrication frequency.

What if we were able to combine the

proven precision and best practice of condition-based

lubrication using ultrasound

with the convenience, safety, and accuracy

of automatic lubrication devices? We would

then have a solution that allows us to lubricate

our bearings only when required by

measuring friction and ensuring we always

use the correct, contaminant-free lubricant

every time. That’s exactly what the Smart-

Lube from UE Systems does.

Lubricate based on friction,

from any device, anywhere

When we use technology to make all this

remotely operated, we can now monitor

the real-time friction of our bearings and,

when needed, remotely dispense the correct

lubricant. All this with the confidence

that the lubricant is getting to the bearing

with real-time alerts and notifications from

any internet-connected device, anywhere

in the world!

The OnTrak SmartLube by UE Systems

has the power of real-time bearing

friction monitoring and the convenience,

safety, and accuracy of single-point bearing

lubricators. Lubrication experts can now

lubricate remotely with confidence from

anywhere, anytime, on any device.

How does it work?

This disruptive device works with a simple

concept: ultrasonic sensors are permanently

mounted on the bearings to monitor

friction levels. All this data is sent to a

central processing unit – the OnTrak – and

can be viewed in dashboards using any internet-connected

device. The OnTrak then

is also connected to single point lubrication

devices. Based on the friction levels and on

setup alarms, we now have the possibility to

tell the OnTrak that a certain bearing needs

lubricant. The OnTrak will then instruct

the SmartLube – single point lubricator – to

dispense lubricant, just the right amount.

And the best part: all can be done remotely,

anywhere, anytime.


LIFT SAFETY

Safe operation

of softwarecontrolled

lifts

Is this lift safe to use until its next periodic inspection?

Lift experts and maintenance personnel are expected

to answer this question clearly and unambiguously –

potentially challenging in practice, as safety functions

in modern lifts are software-monitored and digitally

controlled. The solution is based on effective and

continuous verification of the firmware’s product

safety and its safety in use.

TEXT and PHOTOS: DR. ROLF ZÖLLNER, TÜV SÜD Industrie Service GmbH

TO ENSURE LIFT SAFETY even in the

presence of faults, demands on lift safety

components such as safety gears have

always been subject to high demands.

In Germany the same as in the rest of

Europe, lifts may only use safety components

that have passed type examination

(assessing design, construction, material,

workmanship, load limits, etc.) and

proved that they always fulfil their safety

functions reliably.

Type examined for safety

functions

As technological change leaps forward,

many safety functions that used to be

mechanical are now embedded systems,

monitored and controlled by hardware

and software (HW/SW) systems. Modern

lifts contain safety circuits, with a

typical architecture including sensors,

logic units and actuators (hardware),

that digitally generate, process, evaluate

data (software) and trigger actuators.

Lift shaft information systems, for

example, identify safety-relevant faults

in the dynamic behaviour of the lift and

reliably place the lift in a safe operational

state. In regular operation they monitor

the lift’s position whilst travelling as well

as its levelling accuracy, and allow the

precise measurement of other dynamic

parameters such as acceleration and

speed.

The qualified data provided by these

systems can be used to identify safetyrelevant

faults and initiate effective

countermeasures. In this context the

HW/SW system must reliably identify

all hazardous operational states and

process them correctly, the detection of

overspeed travelling being one example.

On the other hand, however, the system

shall also minimise “false positives”,

such as triggering the safety gear unnecessary

in regular safe operation.

Stickers raise questions

Inspectors often find control units

bearing only a sticker with the version

number of the installed software version

(SW) but no indication of when the


LIFT SAFETY

SW TESTING AND

QUALIFICATION ARE ESSENTIAL

PARTS OF TYPE EXAMINATION.

sticker was affixed or whether the information

is still up-to-date and correct.

Has the SW been updated meanwhile,

or perhaps even a new version installed?

If so, is the update qualified and suitable

for the HW-setup, who performed the

update or installation and why, and does

it impact on the safety functions? When

the lift is connected to the Internet, is

manipulation by unauthorised parties

excluded? Can the company rule out unauthorised

or unintentional manipulation

by, say, a service technician?

In periodic inspections, these questions

are often hard to answer. The

inspectors must search for evidence,

review documentation and access authorisations

and, in particular, check test

results and information from the original

type examination, which informs

about the system configuration and the

SW installed in the examined type that

was approved for use in a safety function

… and of course qualified SW-updates. If

the experts cannot determine without

doubt that the control unit SW is still the

same as in type examination, they cannot

confirm that its use will be safe.

Working together:

Hard- and software

SW testing and qualification are thus

clearly essential parts of type examination

as they ensure the functional safety

of the lift system in case of a fault.

While SW updates may be executed

and new versions developed and installed,

the important principles of the

safety life cycle of SW development must

be complied with in the same way as it is

done with HW. Yet, this is not always sufficiently

guaranteed.

The methods and qualities for ensuring

the reliability and effectiveness of

safety-related functions required in SW

development differ from those required

for hardware components. That is because

SW is subject to systematic and

IEC 61508 “Functional Safety of Electrical/

Electronic/Programmable Electronic

Safety-related Systems (E/E/PE)”


LIFT SAFETY

Directive 2014/33/EC of

the European Parliament

and of the Council of 26

February 2014 on the

approximation of the laws

of the Member States

relating to lifts and safety

components for lifts

DIN EN ISO 9001 “Quality Management Systems – Requirements”

intended errors only – failure rates and

reliability data cannot be calculated as

it is common practice in HW qualifications.

All professional methods are characterised

by typical quality assurance

activities as clear goals, instructions,

responsibilities, and authorities. Feedback,

meetings, test environments and

simulations keep developers informed of

important findings about shortcomings,

incompatibilities, programming errors

or malfunctions, while milestones in

important project phases ensure sourcecode

verification and SW validation. In

this context, experts rely on traceability,

the four-eye principle (two-man rule)

and other proven and tested quality assurance

measures to prevent systematic

faults.

Unlike HW, SW is not subject to wear

and tear, i.e. there are no random faults.

Causes of systematic faults include inadequate

implementation of the requirements

in SW specifications, unsystematic

use of anchor links and variables or

insufficient test coverage. These faults

must be excluded through efficient quality

assurance.


LIFT SAFETY

Functional safety

requirements

Safety-related electrical, electronic and

programmable electronic systems (E/E/

PE systems) are considered to achieve

the intended risk reduction if they fulfil

the requirements of the IEC 61508 series

of standards [1]. Part 3 of this series

specifies the requirements regarding

safety-related software. This part defines

safety life cycle, tools to be used and

the documentation quality. It is thus

particularly relevant for software and

applies to all PESSRAL (=Programmable

Electronic Systems in Safety-Related

Applications for Lifts) in the scope of Directive

2014/33/EU [2] in the EU.

In addition to special software-related

requirements, IEC 61508 also addresses

general requirements for safety

functions realised as HW/SW systems

which ensure reliable achievement of

the necessary Safety Integrity Level

(SIL) which indicates the expected risk

reduction to be achieved through the

specific PESSRAL.

A functional safety management system

according to IEC 61508 is critical in

this context. Like the ISO 9001 standard

FEEDBACK, MEETINGS, TEST EN-

VIRONMENTS AND SIMULATIONS

KEEP DEVELOPERS INFORMED OF

IMPORTANT FINDINGS ABOUT

SHORTCOMINGS, INCOMPATIBILI-

TIES, PROGRAMMING ERRORS OR

MALFUNCTIONS.

[3], it establishes quality assurance along

the supply chain, demanding that HW

and SW suppliers, but also inspection

organisations establish functional safety

and apply it correctly.

Furnishing proof of

safe lift use

The existing system configuration must

thus be documented in an equally thorough

and traceable manner as every

safety-related change to the lift system

(e.g. sensor replacement, firmware

update). Compliance with this requirement

is generally ensured in the form

of a suitable configuration management

system.

In periodic inspection, a sticker or note

with a QR code is often found in the lift

documentation. By scanning the code and

entering the correct password, the expert

can access the entire documentation of

the lift. The digital file includes all relevant

information at a glance. In case of remote

software updates, the expert verifies the

integrity of data transmission.

Further evidence and certificates by

accredited bodies then prove that cybersecurity

measures correspond to the state

of the art and that the lift control unit is

protected against software manipulation

and malware. Information on these aspects

can be found in the IEC 62443 series of

standards [4].

This type of documentation answers all

questions on IT security and functional

safety, enabling experts to confirm that use

of the lift will be safe until the next periodic

inspection. This “futuristic” form of verification

has already become reality as all

stakeholders have realised that it supports

easy and continuous verification of lift

safety, which benefits everybody – and lift

users in particular.

Reveal Your Potential

Get a Reliability and Maintenance Assessment

Call us +1 919-847-8764


OPC UA including Ethernet TSN

and Ethernet APL for the field:

AN INTERMEDIATE GOAL

HAS BEEN ACHIEVED!

At SPS 2018, in Nuremberg, Germany the FLC initiative was founded

under the umbrella of the OPC Foundation. A total of 27 companies,

including the largest automation manufacturers in the world, have joined the

initiative's Steering Committee, supporting it financially as well as with man-power

and technical know-how.

PETER LUTZ, OPC Foundation, peter.lutz@opcfoundation.org

THE COMMON GOAL is to expand the scope

of OPC UA down to the field level and to

establish OPC UA as a uniform and consistent

communication standard in factory

and process automation. In the technical

working groups, which are open to all

members of the OPC Foundation, a total of

over 320 experts from more than 65 companies

are currently working to develop

appropriate concepts and specifications.

OPC UA at the field level - the

system architecture

The extensions specified by the FLC Initiative

are based on the OPC UA Framework

(IEC 62541), which enables a secure and

reliable, manufacturer and platformindependent

information exchange. Controllers

and field devices support both, the

connection-oriented client/server communication

model and the publish/subscribe

extensions, which are indispensable for

communication at the field level due to the

corresponding requirements for flexibility,

efficiency and determinism. The security

mechanisms specified in OPC UA are also

used, which, among other things, support

authentication, signing and encryption of

the data to be transported and can be used

for both client/server and publish/subscribe

communication relationships.

The initial release candidate of the FLC


Initiative, completed in November 2020,

consists of four specification parts (OPC

UA Parts 80-83) and focuses on C2C communication

(controller-to-controller) for

the exchange of process and configuration

data by means of peer-to peer-connections

and a basic diagnosis.

Work on the safety solution for OPC UA

(OPC UA Safety) is also very advanced. A

first OPC UA Safety specification, which is

based on client-server mechanisms which

arose from a Joint Working Group with

Profibus & Profinet International (PI), was

already adopted in November 2019 (Part

15, OPC 10000-15). A revision of the OPC

UA Safety specification will be available

shortly, which describes the extensions for

OPC UA publish / subscribe and the parameterization

of safety participants. The

special thing about the safety concept for

OPC UA is, among other things, that safe

participants can be dynamically integrated

into the communication, with a unique

identification, even while a machine or system

is in operation.

Progress can also be reported with

regard to motion. A working group has

been developing an OPC UA-based motion

solution since mid-2020. OPC UA Motion

comprises the specification of motion control

functions for various types of motion

devices such as controllers, standard drives,

frequency converters and servo drives. The

FLC Steering Committee has agreed to

base the work on the CIP Motion and Sercos

specifications and to adapt them to the

OPC UA information modeling and system

architecture, taking into account the relevant

Industry 4.0 use cases. The fact that, as

with safety, existing concepts and specifications

are being used, the specification work

can be significantly accelerated.

The combination with TSN, APL

and 5G

The OPC UA Framework is fundamentally

transport-agnostic and can therefore be

flexibly used with various underlying communication

protocols and transmission

physics. Ethernet Time-Sensitive Networking

(Ethernet TSN) and the Ethernet Advanced

Physical Layer (Ethernet APL) are

considered by the OPC Foundation as important

elements of the strategy to expand

OPC UA to all use cases and requirements

in factory and process automation and the

vision to create a completely scalable, industrial

interoperability solution.

The combination with TSN

By using Ethernet TSN, deterministic

data transmission via OPC UA is facilitated,

which is particularly indispensable for

demanding automation applications. In

addition, TSN allows different applications


the supply of energy and data via a common,

twisted 2-wire cable, and protective measures

for safe use in hazardous areas. This makes

Ethernet APL the enabling technology for

the use of OPC UA and other Ethernet-based

protocols in the process industry. Due to the

special importance of this technology, the

OPC Foundation joined the Advanced Physical

Layer (APL) project group in June 2020

to develop and promote APL together with

other non-profit organizations and various

industrial partners.

The combination with 5G

Data exchange via OPC UA is not limited to

wired or wireless Ethernet communication.

Support for the 5G mobile communications

standard is also on the OPC Foundation's

development horizon. The mapping to 5G

will be seamlessly integrated into the existing

OPC UA architecture, so that all protocol and

profile extensions of the FLC initiative can be

used, not only via Ethernet and Ethernet TSN,

but also via 5G in the future.

and protocols to be operated using standardized

hardware and a common network

infrastructure. This enables convergent

industrial automation networks to be

implemented in which various IT and OT

protocols can coexist. A Working Group of

the FLC Initiative is currently working out

which TSN sub-standards shall be mandatory

for OPC UA-based end devices and

infrastructure components to meet the

specified requirements for performance,

flexibility and ease-of-use. The OPC Foundation

has given a clear commitment to the

TSN-IA (Industrial Automation) profile,

which is being developed by the IEC/IEEE

60802 working group. For this reason, the

OPC Foundation has entered into liaison

agreements with the standardization bodies

IEC SC65C and IEEE 802.1.

The combination with APL

Ethernet APL describes a physical layer

for Ethernet that was specially developed

for the requirements of the process industry.

Ethernet APL enables data transmission

at high speeds over long distances,

Figure: Semantic interoperability with OPC UA from the sensor to the cloud

Summary

The OPC UA (IEC 62541) framework, with

extensions for the field level, specified by the

FLC Initiative, in combination with underlying

communication standards such as APL,

TSN, and, in the future, 5G, offers a complete,

open, standardized and interoperable solution.

It not only fulfills the requirements of

industrial communication, but, at the same

time, enables consistency and semantic interoperability

from the field level to the cloud

and vice versa (Fig. 5). With this approach - in

combination with the various companion

specifications - information is made available

with a standardized semantics directly at the

data source.

Use cases to consider: A flow meter offers

directly standardized "OPC UA flow

measuring data" the moment the APL cable

is plugged in. And analogously, servo drives

directly process standardized "OPC UA

drive setpoints” and provide standardized

“OPC UA actual drive values” as soon as

they are integrated into a machine network

with Ethernet TSN.

FURTHER INFORMATION

AND DOWNLOADS:

• FLC Initiative Technical Paper

• APL White Paper

• FLC webinar presentations /

recordings

WWW.OPCFOUNDATION.ORG/FLC


DIGITALISATION

Figure 1: Digitalisation of production systems

Digitalisation of production

systems: getting smart while

keeping out of harm’s way?

When embarking on their digitalisation / IIot course, machine and plant manufacturers

are often unsure how to approach things, which steps come first, which can wait

and which may be entirely superfluous. This article sums up the current experiences

of mechanical engineering customers of the HARTING Technology Group and shows

how this important but also tremendously multifaceted topic can be mastered.

THE TOPICS OF DIGITALISATION / IIOT of

production systems are omnipresent

in the general reporting media, as well

as featuring heavily in the specialist

media. More and more new keywords

are emerging in the process. Companies

such as Amazon, Uber & Co. are often

cited as examples, demonstrating to the

whole world how digitalisation strategies

can be used to achieve economic success

through the consistent digitalisation of

JAKOB DÜCK,

DIPL.-ING.

Global Industry

Segment Manager

online trade and logistics (Amazon) or

through the digitally mediated use of

existing resources (Uber). Consequently,

OEMs of capital goods are also asking

themselves: Can we achieve similarly

rapid success with digitalisation, and if

so, how?

First of all, the topics of digitalisation

/ IIoT (Industrial Internet of Things)

for production systems need to be further

narrowed down. We will consider

possible digitalisation steps along the

typical machine lifecycle (VDMA [1]),

or more precisely: only those measures



that relate to products, services or other

performances that can be offered to an

end user. We will not consider entirely

new technologies and business models

which are technically conceivable, but

currently have no legal framework (such

as "Machine-to-Machine Order & Payment",

for example).

One fundamental aspect should be

mentioned in advance. Some experts

question whether digitalisation and IIoT

technologies in mechanical and plant

engineering have any potential at all to

bring about fundamental or even disruptive

changes in existing business models.

As the author, business angel and former

CTO of IBM, Dr. Gunter Dueck, comments

in this context [2]: "When the

Deluge comes, build ships, not dikes ... Are

we building ships to set sail to the digital

future continent? That would mean that

we are looking for digital innovations that

would shape our new age”. The study

"Digitalisation in Mechanical Engineering"

by the Hans Böckler Foundation in

2018 [3] sizes things up in more concrete

terms and quotes an expert from a German

company: "We will definitely remain

mechanical engineers and not become a

software house. But we need software and

networking to sell our machines better

and make sure that they remain attractive.

Based on digitalisation, we want to

help customers to solve their problems better.

Above all, we want to leverage the digital

potentials to ensure that no one comes

between us and our customers. This is a

forward strategy, coupled with a hedging

strategy, so that no disruptor - Amazon,

Google, Microsoft or similar players - ends

up alienating us from our customers". In

the final instance, competitive pressure

leaves OEMs for capital goods no other

option: they must face up to the emerging

digitalisation!

So it is not a question of whether, but

how. The current state of digitalisation

and the necessary priorities in mechanical

and plant engineering, however, are

assessed quite differently by the parties

involved. The IMPULS Foundation of

the VDMA, for example, summarised

the state of affairs in the foreword to a

2016 study [4] as follows: "Industry 4.0

has arrived in German mechanical and

plant engineering. Companies are taking

a leading role, especially as providers of

digitally networked technologies and services

... For customers around the world,

additional added value is being created”.

Gunther Kegel, Chairman of the

Board of Pepperl+Fuchs and current

ZVEI President commented as follows

in an interview in June 2018 [5]: "However,

I do think that ... our pace moving

forward is rather slow. The possibilities

are so diverse that we have to choose very

consciously for which of the many promises

resources are used, degrees of freedom

are allowed and perhaps something new

will be established. It has to be weighed up

what has to be implemented and what not

yet, because it still seems too far away."

The statements show how differently

the situation in mechanical engineering

is assessed by the actors themselves. At

the end of 2019 [6], Commerzbank AG

attempted a quantitative assessment of

Figure 2: Modularity and scalability

as exemplified by HARTING Ethernet

interfaces.



digitalisation in the German mechanical

engineering industry: "A decisive development

towards the digital company is the

integration of platform solutions, both at

the process and service levels as well as at

the sales level. In the meantime, three out

of four companies in the sector state that

such IIoT platforms are important for

them, and almost 30 percent are already

using corresponding solutions". This

means that more than half of the German

machine and plant manufacturers

had not yet taken any action on the topic

of digitalisation / IIoT. The situation is

similar in other countries with a comparable

mechanical engineering industry.

But what success patterns can be observed

among mechanical engineering

customers of the HARTING Technology

Group and what concrete steps can be

recommended?

As an OEM for production systems, it is

important to identify the most important

players in the field of digitalisation /

IIoT in the industry - and consider their

role, capabilities and interests (see also

VDI/VDE Status Report [9]):

• OEMs - providers of individual machine

modules or complex machines

/ systems - have the know-how to

offer machine users the key functions

as the most important differentiating

feature in an economically

successful manner, and to expand

these functions to include digital

IIoT components and services;

• Suppliers of automation components

- suppliers of PLC, CNC,

Figure 3: HARTING T1 Ethernet

connector for SPE technology in

Ethernet interfaces.

DIGITALISATION IN

THE FIELD OF CAPITAL GOODS

CANNOT BE VIEWED AS

AN ISOLATED TREND.

industrial PC, HMI, drive systems,

measurement technology, sensors

etc. - have been mainly producing

digital controller-based systems;

these use digital signals and information

for the direct control of machines

and processes and can also

easily aggregate these further;

• Software providers for production

control at the factory/enterprise

level - providers of ERP, MES

and similar management software

systems - command an extremely

high level of expertise in the control

of business processes and handling

of large data volumes; however, they

rarely have direct access to machine-

and process-related data;

• Platform providers for new

business models - still poorly represented

in the capital goods sector

- are well-known names in the B2C

sector, e.g. Amazon & Co. But there

is also activity in B2B, as the growing

demand for subscription models

("Pay per Use", "Pay per Month",

"Pay per Unit" etc.) is raising hopes

among these providers of being able

to establish themselves in the mar-

ket with benefit and service-oriented

models;

• Associations and co-operations

for digitalisation and IIoT - strategic

alliances between mechanical

engineering and software companies

– are frequently pursuing the goal

of creating an open, manufacturerneutral

IIoT environment and corresponding

standards based on leading

software and communication

technologies (e.g. Open Industry 4.0

Alliance: Endress + Hauser, KUKA,

MULTIVAC, Pepperl + Fuchs, SAP,

SVA, Voith et al.; Open Manufacturing

Platform: BMW and Microsoft,

umati: machine tools, etc.).

• Users/operators of machines

and plants - on the one hand hold

the greatest expert knowledge in

the everyday use of machines and

plants and the associated technologies;

they also know the most about

the problems in the background;

on the other hand, they are also the

strongest "beneficiaries" of ongoing

technical development, including

digitalisation in all its facets.

Moreover, digitalisation in the field of

capital goods cannot be viewed as an

isolated trend, but must be embedded in

key current trends. The most important

ones are:

• "Industry 4.0 / industrial production

of individual products" - End users

expect an increasingly high variability

of manufacturing systems: it

must be possible to manufacture the

widest possible range of products in

small to medium quantities harnessing

the same system;

• Production plants must be scalable

and offer options for cost-effective

subsequent expansion of existing

systems in terms of capacity and

output;

• Declining OEM margins on new installations

combined with high end

user expectations for maintenance

and service make the expansion of

LCC-based business models (LCC

= Life Cycle Costs [1]) with new

business concepts (including maintenance,

service, retrofit services,

e.g. "Predictive Maintenance") more

and more economical for OEMs as

well, and therefore more meaningful;

• Users' expectations of the interoperability

of machine modules and

sub-systems are constantly on the


YOUR PARTNER IN

ULTRASOUND

INSTRUMENTS

Leak Detection

Bearing Condition Monitoring

Bearing Lubrication

Steam Traps & Valves

Electrical Inspection

TRAINING

CAT & CAT II Ultrasound Training

Onsite Implementation Training

Application Specific Training

CONTINUOUS SUPPORT

Free support & license-free software

Online Courses

Free access to our Learning Center

(webinars, articles, tutorials)

UE SYSTEMS

www.uesystems.com

info@uesystems.com

CONTACT US FOR AN

ONSITE DEMONSTRATION


rise; machines and machine modules

from different suppliers should be

as easy as possible to combine in a

single production line. This results

in greater comparability and tougher

competition for OEMs.

All these requirements can only be reconciled

very efficiently in machine and

plant construction, both in technical and

economical terms, if production systems

are consistently modularised, scalable in

various stages of expansion and, in the final

instance, also networkable. Only with

modular networked machines will

one be economically successful in the

long term - more details are described in

the HARTING article on modularisation

"How granular can production technology

be?" [8]. So it is precisely the modularity

and the possibilities of scalability and

expandability of existing systems - a "state

of the art" of "hardware" in modern mechanical

engineering - which from today's

point of view is the key to the success of

digitalisation (IIoT)!

This is also illustrated by two examples

from "related" areas:

• The modularisation of today's

industrial PLC, CNC and HMI systems

is proverbial. The respective

hardware and the development environment

involved here is designed for

each concrete application according

to the principle of "only as much as

necessary"; but if necessary, these can

also be designed for subsequent upgrades,

which applies in particular to

the data interfaces; in this case, subsequent

expansion, the "growth" of

control software in delivered systems

is in principle no problem - and only

limited by the know-how of the given

OEM supplier;

• The scalability of high-performance

drive systems consisting of a

servo-inverter and a servo-motor is

nowadays very often not realised by

the manufacturer via the hardware,

but only through the software (similar

to the "chip tuning" of combustion

engines). Consequently, the hardware

is identical for simple and "high-end"

products, and only the software determines

the functionality and performance

of a concrete system at the

customer's site.

Since the economic success of digitalisation

in the mechanical engineering industry

can vary greatly from segment to segment,

and depends among other things on

company focus and business models, we

Figures 4 and 5: HARTING PushPull RJ45 and M12 X-coded - typical high-performance

data interface in mechanical and plant engineering.

will not make any recommendations here.

In answering these questions, you

should refer to current studies: e.g. "Industrie

4.0 Barometer / Summary 2019"

by MHP [9], the "Market study industrial

communication / Industry 4.0” (“Marktstudie

Industrielle Kommunikation /

Industrie 4.0") by VDMA / M. Rothhöft

[10] or the very recent study “Customer

centricity as opportunity for the digital

breakthrough" (“Kundenzentrierung als

Chance für den digitalen Durchbruch") by

VDMA / McKinsey & Company [11].

How can digitalisation

be shaped and designed

successfully for an OEM?

Evaluating the experience of HARTING

customers in different sub-segments of

the mechanical engineering industry and in

different countries, three aspects must first

be considered:

1. The functions and existing software elements

of the basic, initial system must be

prioritised:

• Key functions that reflect the core competence

of the OEM;

• Basic functions that apply across the

entire system, but do not impact on the

core know-how;

• Add-on or auxiliary functions that are

secondary for the OEM and the end

user, and are usually purchased as

sub-systems;

2. In the next step, collect the expert

knowledge of the end users (customers)

and own experts relevant to possible digitalisation

projects and give preference to



Figure 6: Han-Modular:

established hybrid power and

data interface for sophisticated

and demanding industrial

applications.

high-priority functions and software elements.

Possibly compare with the knowhow

of competitors and develop a list of

requirements. This list must be modular

throughout and as specific as possible in

terms of prioritised functions and software

elements;

3. Now it is necessary to assess the feasibility

of digitalisation for individual

functional modules; in this step it is advisable

to involve all in-house OEM experts

along the performance and service

provision chain - development & design,

project planning & sales, production &

assembly, documentation, service & aftersales

services. Moreover, assessments

can be obtained from external specialists

and any specifications or standards that

have already been drawn up can serve as

a template (e.g. by umati). Remember the

sentence: "We will definitely remain mechanical

engineers and will not become a

software house".

The biggest challenges for OEMs in

these steps are:

• The contradiction between the diverse

individual requirements of the

customers on the machines and the

economic necessity to keep the number

of modules / processes required

for this (especially for key functions)

small. OEMs are already solving

this problem today by consistently

"breaking down" their systems into

logical units and pursuing modularisation

- in order to act economically

when digitalising here, the following

should be considered.

AS MUCH EXISTING technological and

machine-related data as possible should

be used and aggregated at the "lowest"

modular level for future digitalisation

INTERFACES PLAY AN

IMPORTANT ROLE IN MODULAR

NETWORKED PRODUCTION

SYSTEMS.

projects, i.e. utilising existing sources, data

and machine and process models that are

already in place. Particular attention should

be paid to the previously unused or little

used "intelligence" of the automation components,

such as drives, sensors for machine

or process states, etc.

AT ALL HIGHER levels (edge and above) the

most open, future-oriented standards possible

for physical interfaces should be relied

on, as well as the latest software and communication

protocols.

• Too broadly designed and not very

concretely elaborated targets in combination

with unduly high expectations

regarding the economic effects of

digitalisation will result in frustration.

On the one hand, relevant projects are

often overloaded with expectations

on the part of the OEM management,

while on the other hand, they are also

insufficiently equipped with resources.

For the development, implementation

and ongoing support of digitalisation

projects, it is therefore advisable not

to want to achieve everything right

away. Rather, the following should be

considered:

SUB-PROJECTS should be defined in terms

of modules and focus on high-priority key

functions;

THE DESIGN of the interfaces on the

physical level as well as on the data level

should always correspond to the latest

state of the art and be open for subsequent

software updates and extensions

(especially for end users);

THE PARTICIPANTS should be divided

into interdisciplinary project groups, so

that on the one hand a constant dynamic

exchange of information can take place,

while on the other hand, access to the

management level of the OEM is possible

at any time at short notice for the purpose

of correcting objectives and targets;

Consequently, the overriding rule is

as follows: If the modularity of digitalisation

projects (the "software") follows

the modularity of machines and systems

(the "hardware") and features the latest

physical and data interfaces, as an OEM,

you will then be providing an economically

and technically optimal system for

the current customer requirements.

Such systems are also best equipped

to cope with the constantly growing and

partly still unknown future requirements!

Interfaces play an important role

in modular networked production

systems: they are the "lifelines, nerve

pathways and synapses" and create the

necessary infrastructure for the module

and machine transitions, the edge area,

the factory and other superordinate levels.

The HARTING Technology Group

provides solutions for all interfaces

that are essential in modern and future

control, drive, HMI and communication

technology for production systems, in

order to implement and advance digitalisation

in this area without functional

restrictions.



Keeping the Lights On and Preventing

Failures with the FLIR Si124

SPI Inspections provides their customers with top-notch utility system and

infrastructure inspections, relying on their extensive experience in the field and

advanced inspection technology. The team uses UAVs, FLIR thermal cameras, and

other high-tech equipment to deliver qualified inspection services and independent

verification of construction standards and monitoring of power systems.

RECENTLY, the team at SPI Inspections

test-ran the new FLIR Si124 acoustic

imaging camera. Built with 124 microphones,

the Si124 produces a precise

acoustic image that visually displays

ultrasonic information in real time on

top of a digital camera picture. This allows

the user to visually pinpoint the

source of the sound.

The founders of SPI Inspections

have more than 100 years of combined

experience working with utility systems,

from building power lines to

inspecting substations. “We’ve been

around the block a few times,” says Elton

Hunter, Field Manager at SPI. “Our

background is basically power, from

where it's made in the generating facility

to where the meter is—either the

The FLIR Si124 is a lightweight, one-handed

solution that can identify issues up to 10

times faster than with traditional methods.

meter on your home or the meter on

your business.”

“We've really assisted our customers,”

says Hunter. “Our goal is to make their

systems work better, safer, and be more

reliable.” The team at SPI Inspections

found the FLIR Si124 to be an invaluable

asset in detecting partial discharge, a

sign of approaching or imminent failure

in power infrastructure.

The Tools of Inspection

The journey of electricity from power

plant to lightbulb in your home presents

plenty of opportunities for failure if infrastructure

isn’t properly maintained.

SPI uses their extensive experience to

recognize when an element needs maintenance,

aided by advanced technology.



The FLIR GF77 offers both radiometric temperature measurement and the ability to

detect a wide range of gases by simply changing lenses.

SPI Inspections that their tools are ready

for the job. “It's very user friendly,” says

Hunter about the Si124. “Within a halfdozen

hours, we were very confident

working with it.”

“The camera has wonderful clarity

for us in the field,” Hunter continues.

He said his team appreciated the quality

of the images, ease of download to a

laptop or the cloud, and the functionality

of the user interface. “We're guys that

have been in construction for 40-plus

years—we've got arthritis and big swollen

fat hands hitting hammers and stuff.

The user interfaces—the keys, the touch

boards—are very user friendly. We found

them very easy to work with.”

IT IS IMPORTANT TO THE TEAM

AT SPI INSPECTIONS THAT THEIR

TOOLS ARE READY FOR THE JOB.

“We bring a lot of technological tools to

the trade,” says Hunter. Among the tools

in their arsenal is the FLIR GF77 gas

detection camera, which allows them to

spot sulfur hexafluoride (SF6) leaks in

electrical installations as well as detect

hot spots. The GF77 is a multi-use camera

that can detect a range of gases just

by changing out the lens. When equipped

with an HR Lens, the camera can visualize

sulfur hexafluoride, while an LR

Lens allows the camera to see methane,

ethylene, ammonia, and other gas emissions.

The camera is also calibrated for

temperature, so it functions as a standard

thermography camera use to reveal a

wide range of utility issues.

Having relied on FLIR gas detection

cameras for previous inspections, the

SPI team was excited to get their hands

on the Si124 and see what it could do.

Though acoustic imaging cameras are

often used to locate pressurized leaks in

compressed air systems, the Si124 is also

a very effective tool for detecting partial

discharge from high-voltage systems.

Partial discharge—caused by a breakdown

in electrical insulation—can be

detected when the air around the breakdown

becomes ionized, creating a phenomenon

called “corona.” Corona can

be quickly detected by acoustic imaging,

identified by a “meatball” of sound in the

image. “For us, that's invaluable,” says

Hunter.

Almost invisible electrical utility issues are quickly detected with the Si124.

The team had previously been using

ultraviolet technology to detect corona

and were pleased to find that the Si124

achieved about the same result for a fifth

of the price. “The Si124 basically does

the same job and it's very easy to use,”

explains Brett Fleming, Corporate Manager

at SPI Inspections.

Intuitive and Accessible

Features

Because so much of their work is done

in the field, it’s important to the team at

The Si124 made it much easier to

spot failures from the ground. During

their test run of the camera, they found

a failure on a power line 220 feet up in

the air, a difficult issue to detect. “With

our drones we could, but we would have

known where to look,” says Hunter. “Because

of our field experience we were

able to pick it out and zoom in on it,

then we knew that there was a bit of a

problem up there.”

“That's a 25-million-dollar failure

on a line that's only five years old,” he



The Si124 can detect issues up to 100

m (328 ft) away, keeping inspectors

on the ground and out of danger.

remarks. With the Si124 they were able

to catch the problem early, before the

cost to fix it became nearly that high.

Safely Accessing

Dangerous Areas

Electrical substations and other utility

infrastructure present numerous

hazards for workers and inspectors.

When the team confronted a particularly

dangerous area inside the substation

where a capacitor bank had come

down, they were required to stay outside

the chain-link fence enclosing the

area. They were pleased to find that

the Si124 could look through the fence

to assess the situation.

“We were able to walk right up, and

we could look right through the chainlink

fence. Because there's 124 microphones

on the front of the camera and

then one little tiny camera,” Hunter

explains, “that camera was able to

look right through that two by two

inch square and keep our people safe,

which is a huge advantage for us being

in the field.”

Catching Problems Before

They Become Catastrophes

SPI’s goal during inspections is to catch

issues before they’re allowed to escalate

too far. Spotting partial discharge and corona

early with tools like the Si124 helps

them anticipate failures and keep the

lights on for their clients. “It allows us to

preemptively prognosticate what's happening

in our power line,” says Hunter.

“So instead of there being a catastrophic

failure and then an outage and a repair,

we can go in ahead of time and we can tell

them, ‘hey, you're going to have a problem

with this if you don't fix it’.”

Unplanned outages can be prevented

with regular inspection and maintenance.

“If we do our jobs right, nobody

ever knows we're out there. The customer

doesn't know we're there; we go

do our job, we make recommendations,

and then through planned outages or

regular maintenance they can repair

something.”

SPI Inspections operates in Canada

and China—learn more about the services

they offer here: www.spiinspections.

com/, and learn more about the FLIR

Si124: www.flir.com/products/si124/

ABOUT FLIR SYSTEMS, INC.

FOUNDED IN 1978, FLIR SYSTEMS

is a world-leading industrial technology

company focused on intelligent

sensing solutions for defense,

industrial, and commercial applications.

FLIR Systems’ vision is to be

“The World’s Sixth Sense, creating

technologies to help professionals

make more informed decisions that

save lives and livelihoods. For more

information, please visit www.flir.

com and follow @flir.



IGS Technician Applying

HVTS (High Velocity Thermal

Spray) Alloy Cladding

Cui Solution for Aging Plants

Maintaining Production During

Critical Maintenance

BO ANDERSEN,

bo.andersen@integratedglobal.com

TSA (Thermal Sprayed

Aluminium) provides lasting

(>20 years) protection

of carbon steel equipment.

It acts as a barrier

coating, passivating the

surface and galvanically

protecting it against atmospheric

and immersion

corrosion mechanisms,

such as CUI (corrosion

under insulation).

IN THE PAST, TSA applications were

performed during turnarounds, disrupting

schedules and other activities due to

noise, possible TSA fumes, and abrasive

blasting. Plant operators were forced to

make tradeoffs between turnaround duration

and asset integrity as the amount

and location of surfaces protected by

TSA in turnarounds are limited.

Aging Plants Require Work

between Turnarounds

There has been a higher demand for

prolonged TSA application outside

of the turnarounds in the past years.

Equipment within many refineries, petrochemical

plants, and other facilities

is now a lot older. Pipes, vessels, and other

process equipment face rapid deterioration

of their original non-optimal corrosion

protection.

How to Increase the Speed of

Maintenance and Maintain Production

Capacity?

Maintenance and Operations Managers

are under pressure to increase the maintenance

speed not to lose many production

facilities or at least the production capacity.

Thus, they look at doing the critical maintenance

while the plant is online – in other

words, without shutting it down. That way,

they will be able to reach their maintenance

goal and maintain uptime simultaneously.



What about Safety?

There are concerns about “hot-work”

such as welding, abrasive blasting, and

the open flame of TSA application in

many locations around the world. Temperature

and humidity also need to be

controlled to reach the optimal environment

for the TSA application. These

concerns apply to both colder areas,

such as Canada, Alaska, The North Sea,

Northern Russia, and high temperature/

humidity areas like the Middle East, Singapore,

and West Africa.

Hot-work that may produce sparks

or open flames can be dangerous due

to the risk of explosion, fire, and the

release of poisonous gasses. It can be

hazardous for personnel, equipment,

and the entire plant.

Developing IGS TUFFss

Online TSA Solution

Large national and international petrochemical

companies have been actively

looking for a safer TSA solution, which

can be applied while the plant is in operation.

Royal Dutch Shell, a British-Dutch

multinational oil and gas company, has

initiated a project with TUFFss to develop

a safer online TSA solution.

TUFFss has since been acquired

by Integrated Global Services (IGS), a

global turnkey thermal spray cladding

provider. IGS was chosen to join this

project due to their lasting experience in

the field of thermal spray. IGS is the sole

provider of a proprietary HVTS (High

Velocity Thermal Spray) alloy cladding

technology, specifically designed

for the protection of mission-critical

equipment, including pressure vessels

and boilers. Furthermore, IGS HVTS is

applied in situ, whereas the majority of

thermal spray applications take place in

CUI on Piping is Common

in Aging Facilities

IGS TUFFss Online TSA Meets

Highest Industry Standards

workshops. To enable the HVTS application

in the field, IGS have successfully

optimized their materials, conveyancing

technology, and application procedures.

Could the same be done for TSA?

IGS TUFFss Online TSA Meets

Highest Industry Standards

For TSA to be safely applied online, several

issues would need to be resolved,

including process-specific safety procedures,

temperature, and humidity.

Following two years of intensive R&D

work, a safer online TSA solution was

introduced. –

– The solution included enhanced

TSA application processes and procedures,

sealed safety enclosures, humidity

and temperature control, (negative) environmental

pressure control, and a fully

automated safety shutdown system for

the TSA and abrasive blasting processes.

Everything was custom-made and combined

in ways unheard of, meeting the

highest standards in the industry, Bo

Andersen, who has been instrumental in

the development of this new technology,

said.

Safety! Safety! Safety First!

The IGS IGS TUFFSS ONLINE TSA

solution is a safe way to handle online

maintenance with blasting, TSA, or other

coatings. This is made possible with a

proprietary Automatic Shutdown System.

This emergency shutdown system

continuously monitors the entire work

area and surroundings. The system will

give digital, audible, and visual warnings

in case of leak of gasses, pressure loss, or

any other parameter deviation.

This, in turn, enables almost instantaneously

automatic termination of any

work and equipment inside or outside

the habitat, including, but not limited to,

welding, grinding, power, grit/sandblasting,

TSA, HVAC, dust collection, etc. All

equipment is controlled through the

use of electrical connections, solenoid

valves, and pneumatic connections.

Pilot Project at a Liquefied

Natural Gas-Producing Plant

Established in 1989, NLNG, an LNG facility

in Nigeria, currently has 6 Trains.

The plant has a total production capacity

of 22 Million Tons Per Annum (mtpa) of

LNG and 5mtpa of Natural Gas Liquids

(NGLs), which equals 6% of the global

market.



Hot and Humid

Located in a hot, humid, and very salty

environment, piping at this facility is

prone to corrosion. Various kinds of

paint and insulation have initially been

used for corrosion protection. After 20

years in service, Corrosion Under Insulation

(CUI) has turned into a significant

problem with many pipes about to burst.

Ignoring the problem or an insufficient

solution could result in fire, explosion,

environmental damage, loss of life, loss

of profit, or production loss.

CUI Problem: Evaluating

Alternatives

One option was to repaint the piping

with the same or similar paints and coatings

that have already failed once. Some

new technology paints and coatings

were also being considered. These paints

would still need to be inspected and usually

reapplied every 5-10 years. Thermal

Spray Aluminium (TSA) was an optimum

solution due to its long inspection

cycle, >20 years, and proven reliability.

IGS TUFFss Online TSA Pilot

Application

TSA coatings applied in traditional ways

without environmental controls would

not be practical in this case. The scale of

the work in total exceeded 360,000m2.

Applied during turnarounds, it would

have taken over 30 years to protect all corroded

piping. The plant would not have

lasted 30 years in its present condition!

The plant needed a solution that could be

applied while the plant is live. The application

would need to be climate-controlled

during surface preparation and TSA application,

with all grit and dust contained.

The IGS TUFFSS ONLINE TSA pilot

project was first completed on train 1.

The scope included a 50-meter (160 foot)

column and a two-level platform with two

heat exchangers/reboilers. IGS TUFFSS

ONLINE TSA was applied to a total area

of 700m2 on cold and hot surfaces.

This onsite project began on October 1st

2016, and concluded in January 2018.

The project was carried out in adverse

weather conditions, including heavy

rain, thunder, sandstorms, high temperature,

and high humidity.

One Train Done, Six to Go

This project succeeded in meeting and

exceeding objectives by rigidly following

all safety guidelines. The project utilized

specially designed Habitats to enable

IGS IGS TUFFSS ONLINE TSA Project at a Liquefied Natural Gas-Producing Plant

CUI Problem Area on Piping

weather protection, climate, humidity, and

pressure control. It was now confirmed

without a doubt that it is possible to do the

encapsulated TSA maintenance in a live

environment, which will be of great importance

to NLNG in the future as the work

continues on the remaining six trains.

IGS TUFFSS ONLINE TSA –

In Summary

As equipment within refineries, petrochemical

plants, and other facilities

continues to age, the demand for maintenance

solutions that can be applied all

year round is growing. Plant operators

are looking to companies like IGS to

utilize their global footprint and experience

to deliver innovative solutions

safely and efficiently. Preventing shutdowns

and providing the work outside of

turnarounds eases the pressure off the

maintenance and operations teams, who

can continue production while crucial

maintenance work is being simultaneously

carried out. Further IGS TUFFSS

ONLINE TSA projects are now being

commissioned within refineries and

petrochemical sites, paving the way for

more uptime in aging facilities.

GOOD TO KNOW

INTEGRATED GLOBAL SERVICES, Inc.

(IGS) is an international provider of

surface protection solutions headquartered

in Virginia, USA. IGS operates

operational hubs, subsidiaries, and

sales offices around the world to service

global asset owners and operators.

The company has 40 years of experience

helping customers solve metal

wastage and reliability problems in

mission critical equipment and is an

industry leader in the development

and application of solutions to corrosion

and erosion problems in challenging

operating environments.


Registration:

https://opcfoundation.org/opcday

OPC DAY

INTERNATIONAL

IT meets Automation

JUN 08 – 10, 2021

3 HOURS A DAY

EACH DAY: 2H CONFERENCE – 1H Q&A

DIGITAL EVENT

Join this digital event free of charge

“OPC Day – International”

Agenda:

W Day: Keynotes Level

Target Group: Management, Product Managers & Architects

W Day 2: Technology Update Level

Target group: Implementers, Developers, Product Managers, Program Managers

W Day 3: Adaption & Solutions

Target Group: End-Users

Listen to infl uencers on technology, security and solutions:

https://opcfoundation.org/podcast/

©royyimzy – stock.adobe.com

TRAINING & EDUCATION

Creativity Was

– and Still Is –

Needed in Teaching and R&D Projects

during the Pandemic Time

The Corona virus outbreak shut

down all of Häme University

of applied sciences (HAMK)

campuses, just as it did in other

Universities. Teaching was

transferred to the internet. But

how were research activities

continued with the tight

movement restriction in place?

LEA MUSTONEN, Senior Lecturer (Communications), School of Technology, Häme University of Applied Sciences (HAMK),

SUSAN HEIKKILÄ, Senior Lecturer, Electrical and Automation Engineering study programme, Häme University of Applied Sciences (HAMK)

THE SHIFT TO REMOTE TEACHING happened

in a few hours. On Friday 13.3.2020

regular classroom teaching was being

implemented as usual, but with the

recent corona outbreak on everyone’s’

minds. But at the same day all the contact

lessons were cancelled to the end of the

semester. Classrooms became deserted.

The jump to pure virtual-based teaching

was not painless, but the staff had strong

experience of teaching diverse students

who studied and worked at that time.

Some students used to traditional

classroom teaching and university facilities

had problems with software and

internet connections. Luckily many of

the software developers had a “We are all

in the same boat” -mentality. At the start,

teachers often had to think what software

would likely work for teaching virtually,

but a lot of the software used got quick updates

within the first few weeks. In addition

to students, the teaching staff moved

to a virtual environment with no major

problems. So, there were some problems

with teaching, but the goal was in sight.

Digital twin as a solution

Staff of universities does not only include

teaching staff. The radical change also

meant rethinking the means of success

for research activities. To further

research during these restrictions, the

digital twin was taken in use in our project,

Low Carbon Energy Efficiency with

Micro-CHP-technology (later called as

VEneCT).

The term “digital twin” tells it’s meaning

quite well: a digital copy is made of a

physical thing. The copy is made to simulate

the parameters and components

essential for its functionality as close as

possible in the development environment.

Digital twin is a simulation that

makes it possible to test how a change

to an existing one or a new functionality

would affect the original.

The goal of the VEneCT-project is low

carbon usage, as it is a goal in all of the research

projects conducted by HAMK that

involve energy efficiency. The basis of the

research is that its results benefit companies

and teaching in the future.

The purpose of the project is to resolve

how electricity can be produced on a small

scale with waste energy including the possibility

of utilizing the waste energy produced

by burning process. The research

is conducted using a physical construct

that utilizes a “hybrid module” of generating

and storing energy. Different types of

energy-generating possibilities are tested.

The construct has been installed with a

control system that determines what energy

source is the most cost efficient. The

possible energy sources are solar heating,

solar panels and heating bio-boiler. Different

storage methods of heat energy are

also being explored. Testing is being done

on different phase change materials in addition

to water to enable larger amounts

of heat energy storage. In addition to the

hybrid module creating data, the construct

itself could be an energy source.

Corona virus sped up the

development process

When teaching moved to a virtual environment

with a fast pace, the research


TRAINING & EDUCATION

Picture 1. The digital twin’s interface

It is also possible to delve deeper into the data, for example, if some sudden

change or outcome draws attention. Picture 2 shows an example of a report.

Picture 2. Boiler water temperature

The advantage is that different data can be combined and later we can

return to a certain time period to inspect it. It is also beneficial to be able to

monitor individual status changes in real time, allowing for a quick response

to the situation. “The novelty is that the reporting view and process control

are combined”, sums up the project engineer Ari Lindgren.

personnel also started working from

home as much as possible. The continuation

of the VEneCT-research project

with a great start became a challenge.

The hybrid module is controlled with

touch-screen control panel, which is

situated inside the building. Remote

access to collected data has been a goal

from the very start, but remote control

of the system was not part of the written

down objectives of the project. The idea

had been brought up at the start of the

year before the pandemic, but there had

not been any active development on it.

Closing of the campus changed the situation

totally.

The size of the hybrid module building

is 18 square meters. Tight pandemic

security measures allow for only one

person to enter the building. Because

of the complicity of its interior design,

even careful cleaning practices cannot

guarantee the safety off the staff. Staff

access was limited so that there had to

be a three-day gap between access of different

staff members. So, the research

activities could not be continued in a

realistic way.

Special attention to data

security

When designing the remote control,

special attention had to be paid to data

security, emphasizes research assistant

Duong Truong. Control cannot be performed

from home computers or home

network connections; it can only take

place in a secure network of HAMK.

Thus, the researchers had to physically

come to campus, but since there was no

contact teaching, there was plenty of

room on campus to operate without any

kind of close contact.

A digital twin was built for the control

system of the hybrid module. It is now

possible to both monitor and control activities

remotely. A key part of the digital

twin’s operations is reporting. The digital

twin’s interface (picture 1) provides realtime

information on process status and,

for example, temperature changes, water

flows, and electricity production.

Digital twin came to stay

The digital twin changed the way to operate

and came to stay. It will be used in the

future, when physical presence requiring

burn tests are not being performed. Everything

else can be done virtually.

At the moment, virtual learning and

work will continue. Changing circumstances

forced – and will force - us to

search new solutions in teaching and research;

the digital twin is a good example

of this. Ending research and development

cannot be afforded.

PROJECT INFORMATION:

VEneCT i.e. Low Carbon Energy Efficiency

using Micro-CHP-technology.

An EU project funded by the Pirkanmaa

Association integrates electricity

generation using waste heat from the

combustion process. (CHP, combined

heat and power)



Monetizing Data

in Maintenance:

Data-driven Spare Parts

Management – Part 2

TOMÁŠ HLADÍK,

Principal Consultant,

Logio S.R.O.

Today, digitization, Industry 4.0 and Maintenance

4.0 bring about vast volumes of data. Technologies

such as IoT or IIoT allow large sets of devices to

connect to data networks and send complex data

continuously.

Organizations today maintain huge amounts of data, structured

or unstructured. However, from research of renowned

organizations like Gartner, we know that industrial firms today

are not able to use 70—90 percent of data that are collected

and stored. This paradox is described in the paper, and various

generic models of big data monetization are proposed. Some of

these models are shown in examples from spare parts management.

Spare parts inventory can lock in significant amounts of

working capital. This article summarizes recommendations

for effective spare parts inventory management and spare

parts optimization using various sets of data and statistical

analytical methods.

The management of spare parts and other materials needed

for realization of maintenance processes is one of the key functions

in physical asset management. Especially in power generation,

oil and gas and heavy chemical industries, spare parts

inventories can easily add up to tens of thousands of various

items, at a value of hundreds of millions of euros.

It is obvious that efficient spare parts inventory management

can have significant impact on the financial performance

of the company. Better spare parts management can lead to

improvement of financial performance of the company.

In previous research we discussed several recommendations

for spare parts inventory management. Using these

recommendations, companies can achieve better financial

performance in different parts of the spare parts lifecycle.

In some of these recommended practices, various data can

be employed and analysed – especially in areas like portfolio

segmentation, criticality assessment, forecasting, improving

spare parts naming and identification, or cleaning and rectifying

master data.

Eight Rules of Good Spare Parts Management

In our previous research, we refined the following eight rules –

best practices – for good spare parts management:

• Focus on preventative maintenance – for preventative

maintenance no inventories of spare parts need to be

held.

• Solve problems in spare parts processes.

• Segment your spare parts portfolio.

• Analyse spare part’s criticality.

• Use suitable forecasting methods and verify their accuracy

and reliability.

• Use special methods for intermittent demand items.

• Consider the whole lifecycle of your assets while mak-



ing decisions related to spare parts.

• Implement a good information system for spare parts

management so all above stated rules are supported

and/or automated.

In this issue of Maintworld we will describe in more detail the

importance of analysing spare parts critically and the need to

use suitable forecasting methods and verify their accuracy and

reliability.

Analyse Spare Part’s Criticality

In large organizations operating large production systems, the

size of spares portfolio amounts to tens or hundreds of thousands

of items. It is therefore essential to be able to distinguish

the important ones from the others. Criticality of spare parts is

after all the ultimate measure of spare parts’ importance.

The level of a spare part’s criticality is inevitably related to

the criticality of the production equipment it is used for (so

having an RCM analysis done will certainly help in assessing

the criticality of spares). However, we need to keep in mind

that criticality of spare parts is not equal to criticality of the

device the spares are used for.

When analysing criticality, we need to collect and look at

various areas of data linked with the item: cost of inventory

holding, failure probability, impacts of spare part unavailability,

lead-time and other parameters – as shown in Fig. 4.

Based on the level of item’s criticality, appropriate service level

targets should be set.

In practice, costs of inventory holding, and costs of spare

parts unavailability should be carefully balanced. Costs can be

compared using the following equation:

Cinv=Cun*LT*f (1)

Figure 4: Spare parts criticality analysis areas

Where Cinv are costs of inventory holding per one year and

Cun are costs of unavailability of spare part in case of need

calculated per one day. LT is lead time calculated in days and

f is frequency or probability of failure (need for spare part) as

occurrences per year.

If all data for the equation is available, criticality can be

calculated directly – and easily. But in practice typically some

the variables in the equation are not known at all or are uncertain,

blurred and inaccurate. This is where advanced analysis

Figure 5: Equation of criticality calculation – example



of available data comes to question. From our experience, in

industrial organizations a number of interesting sets of data can

be utilized to evaluate (or support evaluation) of spare parts’

importance (criticalness or criticality).

In the following diagram (Figure 6), a 2-level evaluation of

criticality (or identification of critical items – materials or spare

parts) is described. This 2-level approach allows for the “clever”,

efficient process of evaluation of large numbers of items. Using

various data sources like spare parts master data, history of

spare parts transactions, RCM data, data from previous assessments

of critical items, bills of materials etc., a preliminary separation

of clearly non-critical items vs. suspicious (potentially

critical) items can be done by means of data analysis without

human interaction. After this preliminary evaluation, we can

spot the relatively small group of potentially critical items and

focus further evaluation on them. In this way the preliminary

evaluation can save a lot of work and time otherwise required

from maintenance technicians to assess each item individually.

In the second step, potentially critical items are scrutinized

thoroughly to find out their level (score) of criticalness. This can

be done either in a quantitative way (if required data is available)

or qualitative way (data must be collected by means of questionnaires

filled-in by maintenance technicians or engineers).

If it is less than 0 we should not – this spare part is not critical.

Weights should be tested on selected parts with known (or

agreed) criticality. A pilot mix of spare parts should include

some parts which are critical for sure, some which are not, and

some which are in between.

It is essential to include maintenance engineers in both

selecting questions for the questionnaire and in selecting

weights for answers. This helps to create a better understanding

of the questions and the whole purpose of the criticality

assessment. A maintenance engineer should be able to fill the

questionnaire in an average time of 2-10 minutes, so that the

criticality assessment will not consume much of working time.

Although assessment can be done on paper or in Excel, today

it makes more sense to use available services like Google

Forms or SurveyMonkey or others, that can be used to collect

needed data and minimize the work with collecting, processing

and analysing the data.

Spare Parts Management Starts with Good

Forecasting

The next step in the specification of optimum spare parts

inventory management regime is the prediction of future

demand (consumption) for the items in stock. The forecast is

always based on transactional data from information systems

GOOD FORECASTING IS ALWAYS A BALANCED

COMBINATION OF QUANTITATIVE METHODS

AND HUMAN INTELLIGENCE. MATHEMATICS

AND AI CAN WORK FOR US AUTOMATICALLY,

BUT STILL WE NEED TO ENSURE QUICK AND

EFFICIENT INPUT FROM PEOPLE.

Figure 6: 2-level evaluation of spare parts criticality.

If data for quantitative calculation is not available, we need to

rely on information from maintenance engineers or technicians. To

objectivize their subjective view on spare parts (maintenance engineers

are often strongly biased towards keeping excessive inventory,

“just to be safe”), we have proposed a structured questionnaire.

Questions about spare parts realisability, probability of failure,

and impact of unavailability, lead time, etc. should be designed

to fit specific conditions of the organization (industry, technology/production

equipment used etc.). The equation (1) should

be taken into logarithm, so we can change variables for indices

which can be added and subtracted instead of multiplicated. Answers

should be given weights, and the questionnaire should be

balanced so that we can have sums for each area (index) as shown

in the following equation:

IP-Iun-ILT-If=0 (2)

This allows for summing weights for answers in each area

into a single index. If the left side of the equation is greater

than 0, we should keep at least one item of spare part in stock.

– history of spare parts consumptions, which must be representative

(meaning sufficiently long). In the case of spare parts,

we usually work with a history of three to ten years (depending

on industry). Three years of recorded history seems to be the

minimum for intermittent items. A general rule here applies:

the longer the history, the better and more reliable the forecast.

When analysing historical consumption, we need to carefully

distinguish between material consumed for planned

maintenance (planned shutdowns, turnarounds, preventive

maintenance) and spare parts issued for unplanned (corrective)

maintenance – repairs. In forecasting, we must adjust the

history for planned maintenance.

In the forecasting process, items should be treated individually,

according to the character of their consumption. Items

with common demand patterns (high runners – fast moving

items like fasteners, etc.) can be forecast using a number of

standard statistical methods normally used in inventory management

(moving average, exponential smoothing, Holt’s exponential

smoothing, trends, seasonal indexes, Winter’s method,

etc.). Items with intermittent demand require a special

suitable method to be applied. The use of standard methods of

prediction and inventory management in case of intermittent

items results often in a substantial overestimate of future consumption

and therefore excessive inventory level.


VIBRATION ANALYSIS

THERMAL IMAGING

ULTRASOUND

MEASUREMENT

EYESIGHT – HEARING – SENSITIVITY

WE HAVE IN COMMON

MASTER THE LANGUAGE OF YOUR MACHINERY

WWW.ADASH.COM

Turn Your Remote Workers

Into Remote Experts

Automatically Detect Faults

ROI Typically Within 12 to 18 Months

Rich Visualization and Reporting

Predict, Reduce and Eliminate Downtime

productive, and safe to

stay ahead inthis current climate. With CFSWorX and its Remote Expert technology, companies

with a highly mobile workforce are able to do just that. Learn

solutions enable organizations to keep more accurate records of where their workforce are,

and at what times, and allow them to more intelligently schedule worker tasks. Learn more

about this and other groundbreaking solutions by checking out ICONICS 10.97 webcast series.

iconics.com/1097-webcasts

Maintworld Magazine 1/2021

You also want an ePaper? Increase the reach of your titles

Delete template?

Save as template?
