ioplastics magazine Vol. 8 ISSN 1862-5258<br />
Basics<br />
Succinic acid | 60<br />
Cover-Story<br />
Toy blocks | 20<br />
May / June<br />
Highlights<br />
03 | 2013<br />
Injection Moulding | 16<br />
PLA Recycling | 40<br />
... is read in 91 countries
Packaging Film provided by Oerlemans Plastics B.V.<br />
1 ton of Braskem´s Green Polyethylene<br />
captures more than 2 tons * of CO 2<br />
Green Polyethylene offers unique opportunities,<br />
thus helping you to meet your sustainability goals.<br />
Braskem´s Code of Conduct underlines the<br />
company´s commitment to operating in accordance<br />
with sustainable development principles.<br />
Sugarcane sourced in South Brazil does not disturb<br />
the Amazon Rain Forest.<br />
Green PE provides you with the perfect solution<br />
for your biobased packaging application:<br />
• High content of renewable ressources<br />
• Outstanding CO 2 capturing<br />
• Properties as fossil based PE<br />
• Identical processability: Drop-In Solutions<br />
• 100% recyclable in existing polyethylene streams<br />
* Carbon Footprint calculated from cradle to polymer factory gate (t CO2 eq./t polymer), Preliminary Ecoefficiency Analysis by Espaço Eco Foundation.<br />
For more information, please visit<br />
www.fkur.com • www.fkur-biobased.com
Editorial<br />
dear<br />
readers<br />
Michael and Jenny (Covergirl 05/2011)<br />
bioplastics MAGAZINE has already reported a couple of times about the PLA beverage cups<br />
that are collected and recycled at large festivals, sport events or rock concerts. “So why not<br />
do it myself?” I thought earlier this year. During a rather small local festival in my home<br />
town of Mönchengladbach in Germany I succeeded in convincing the organizers to sell<br />
beer in PLA cups (Ingeo cups supplied by Huhtamaki). And just like at the other festivals<br />
or concerts, the guests were offered a free drink for each ten returned cups.<br />
The collected cups will be sent to Purac to be recycled during one of the next uses of the<br />
Perpetual Plastic Project’s recycling machine (see p. 54).<br />
The festival is a typical German Schützenfest (see http://bit.ly/Y1SmVP for an explanation),<br />
and this year I was one of the two Ministers to the King of Marksmen, wearing<br />
a traditional red hussar’s uniform.<br />
Now… after combining job and leisure… back to business: And back to recycling of<br />
PLA, which is one of the highlights in this issue, even though we could not obtain the<br />
latest news about the future of the chemical recycling system LOOPLA in time to<br />
include it. The project will be continued by Futerro after Galactic decided to orient<br />
its development towards more specific solutions for the food and pharmaceutical<br />
sectors, and we still offer our readers a lot of other articles and news around the<br />
recycling of PLA. We will certainly keep you updated on the future of LOOPLA…<br />
The other editorial focus is on injection moulding of components for use in<br />
durable applications. Because durable applications have become an increased<br />
focus of attention in the bioplastics world, we also decided to dedicate the third<br />
day of our Bioplastics Business Breakfast, during the upcoming K’2013 trade<br />
fair, to durable applications.<br />
Finally this issue is once again rounded off by another of our basics articles,<br />
this time on succinic acid, and lots of industry and applications news. As usual, our<br />
events calendar provides an overview about forthcoming conferences and trade shows. I’m<br />
looking forward to seeing one or more of you at one of these events.<br />
Until then, we hope you enjoy reading bioplastics MAGAZINE<br />
Sincerely yours<br />
Michael Thielen<br />
Follow us on twitter!<br />
www.twitter.com/bioplasticsmag<br />
Be our friend on Facebook!<br />
www.facebook.com/bioplasticsmagazine<br />
bioplastics MAGAZINE [03/13] Vol. 8<br />
3
Content<br />
03|2013<br />
May/June<br />
Editorial ...................................3<br />
News ...................................5 - 8<br />
Events .....................................9<br />
Cover Story ................................20<br />
Application News .......................34 - 35<br />
Suppliers Guide ........................66 - 68<br />
Event Calendar .............................69<br />
Companies in this issue .....................70<br />
Did you know<br />
10 Did you know…? …about meat<br />
Report<br />
11 New data on land-use<br />
12 Valorisation of by-products<br />
14 Greenhouse gas-based PHA<br />
58 Bioplastics for food packaging<br />
Injection Moulding<br />
16 Not only for film making<br />
18 Watch bracelets made in Austria<br />
20 Toys and more... (Cover Story)<br />
21 Pitcher with separate bamboo handle<br />
22 Liquid wood and more …<br />
From Science & Research<br />
24 Lacquer from tomato for metal cans<br />
28 Bioplastic products from citrus wastes<br />
36 Advances in PLA chemistry<br />
Chinaplas Review<br />
31 Chinaplas<br />
Materials<br />
39 Innovative biopolymer blend<br />
PLA Recycling<br />
40 Bioplastics want to be recycled as well<br />
42 PLA recycling via thermal depolymerization<br />
45 Solvent based PLA recycling<br />
46 PLA recycling with degassing<br />
48 Mechanical PLA recycling<br />
49 Supporting ecological advantages<br />
50 Better-than-virgin recycled PLA<br />
52 Chemically recycling post-consumer PLA<br />
54 Recycling ‘hands on‘<br />
55 Pelletizing and crystallizing of PLA<br />
Portrait<br />
56 10 years FKuR<br />
Opinion<br />
57 Biobased: Lose the hyphen<br />
63 Market studies<br />
64 Reliable and transparent<br />
Basics<br />
60 Succinic acid<br />
Imprint<br />
Publisher / Editorial<br />
Dr. Michael Thielen (MT)<br />
Samuel Brangenberg (SB)<br />
Contributing editor: Karen Laird<br />
Layout/Production<br />
Julia Hunold, Christos Stavrou<br />
Mark Speckenbach<br />
Head Office<br />
Polymedia Publisher GmbH<br />
Dammer Str. 112<br />
41066 Mönchengladbach, Germany<br />
phone: +49 (0)2161 6884469<br />
fax: +49 (0)2161 6884468<br />
info@bioplasticsmagazine.com<br />
www.bioplasticsmagazine.com<br />
Media Adviser<br />
Elke Hoffmann, Caroline Motyka<br />
phone: +49(0)2161-6884467<br />
fax: +49(0)2161 6884468<br />
eh@bioplasticsmagazine.com<br />
Print<br />
Tölkes Druck + Medien GmbH<br />
47807 Krefeld, Germany<br />
Total Print run:3,800 copies<br />
bioplastics magazine<br />
ISSN 1862-5258<br />
bM is published 6 times a year.<br />
This publication is sent to qualified<br />
subscribers (149 Euro for 6 issues).<br />
bioplastics MAGAZINE is printed on<br />
chlorine-free FSC certified paper.<br />
bioplastics MAGAZINE is read<br />
in 91 countries.<br />
Not to be reproduced in any form<br />
without permission from the publisher.<br />
The fact that product names may not be<br />
identified in our editorial as trade marks is<br />
not an indication that such names are not<br />
registered trade marks.<br />
bioplastics MAGAZINE tries to use British<br />
spelling. However, in articles based on<br />
information from the USA, American<br />
spelling may also be used.<br />
Editorial contributions are always welcome.<br />
Please contact the editorial office via<br />
mt@bioplasticsmagazine.com.<br />
Envelopes<br />
A part of this print run is mailed to the readers<br />
wrapped in Green PE envelopes sponsored by<br />
FKuR Kunststoff GmbH and Oerlemans<br />
Plastics B.V.<br />
Cover<br />
Coverphoto: Philipp Thielen<br />
Photo page 3: Sven Keitlinghaus<br />
Follow us on twitter:<br />
http://twitter.com/bioplasticsmag<br />
Like us on Facebook:<br />
http://www.facebook.com/pages/bioplastics-MAGAZINE/103745406344904
News<br />
Green materials in<br />
rapid prototyping<br />
In early April of this year, Merseburg University of<br />
Applied Sciences joined the Research for the Future<br />
stand, run by the Central German Universities at the<br />
Hanover Trade Fair, and presented the latest FABIO<br />
project results.<br />
FABIO stands for the FAbrication of parts with<br />
BIOplastics and simply means that, in the framework of<br />
this project, processes and devices are developed which<br />
enable the use of biobased polymers in Rapid Prototyping.<br />
The research team and project leader, Dietmar Glatz,<br />
presented a rapid prototyping system based on fused<br />
layer modelling (FLM). For the very first time, thermo<br />
plastic, biobased polymers are processed in granular<br />
form using this method. The development of this rapid<br />
prototyping system provides a new basis for construction<br />
materials and has enormous developmental potential.<br />
Since November 2011, functional prototypes have<br />
been produced from bioplastics, opening up new fields<br />
of application. In the framework of the FABIO project,<br />
Merseburg University of Applied Sciences co-operates<br />
with four partners from industry, 30 designers and<br />
Magdeburg-Stendal University of Applied Sciences. The<br />
manufactured prototype is living proof of the usability of<br />
bioplastics in technical fields.<br />
The Hanover Trade Fair, which took place from April 8 th .<br />
- April 12 th . is the world’s biggest investment goods trade<br />
fair and an important platform for scientific institutions,<br />
universities and business developers from all branches<br />
of industry.<br />
www.hs-merseburg.de<br />
(Photo: HS Merseburg)<br />
Cardia and University<br />
of Sydney explore<br />
PPC applications<br />
Cardia Bioplastics Limited (Mulgrave, Victoria,<br />
Australia) recently announced a collaboration of the<br />
University of Sydney with CO2 Starch Pty Ltd (100%<br />
owned subsidiary of Cardia).<br />
Cardia launched the world’s first CO 2<br />
+Starch<br />
biodegradable carrier bag in 2010. This patented<br />
breakthrough opened up the potential for<br />
biodegradable polymers and polymeric blends for<br />
packaging applications to mitigate environmental<br />
problems caused by non-degradable polymeric and<br />
plastic materials.<br />
Cardia advanced its patented CO 2<br />
+Starch<br />
development one step further and produced a<br />
biodegradable CO 2<br />
+ Starch bag with good mechanical<br />
properties.<br />
CO2 Starch Pty Ltd’s ground breaking work allows<br />
polypropylene carbonate (PPC) resins to be blended<br />
with starch with the potential to be cost-effectively<br />
transformed into a wide variety of industrial products<br />
that includes packaging, medical and coatings and<br />
engineering polymers. The research agreement also<br />
allows for the PPC resin to be used for bio-medical<br />
applications such as tissue scaffolds and drug<br />
delivery agents.<br />
CO2 Starch Pty Ltd Chairman Pat Volpe said: “In<br />
collaboration with the University of Sydney, CO2<br />
Starch Pty Ltd is looking to expand its patented<br />
PPC+starch blending technology into application<br />
within the packaging industry before addressing<br />
potential applications in other industries including<br />
but not limited to the medical industry.”<br />
Volpe said they are working with the University<br />
of Sydney to develop and adopt their new unique<br />
technique that aims to produce PPC, a biodegradable<br />
aliphatic polyester which is synthesized from<br />
copolymerization of carbon dioxide (CO 2<br />
) and<br />
propylene oxide (PO). The technique is a one-step<br />
manufacturing process (rather than two) that<br />
also lowers the levels of residual zinc catalyst and<br />
potentially lowers the costs of PPC.”<br />
The aim is to apply the technology to many<br />
applications and produce alternative renewable<br />
biodegradable plastics at an economical price point<br />
whilst maintaining good mechanical properties that<br />
meet international compostability standards. MT<br />
www.cardiabioplastics.com<br />
www.sydney.edu.au<br />
bioplastics MAGAZINE [03/13] Vol. 8 5
News<br />
Sulzer to build high PLA<br />
production plant in Asia<br />
Sulzer (Winterthur, Switzerland) has been awarded<br />
a contract for the delivery of a production plant based<br />
on Sulzer’s proprietary polylactic acid (PLA) technology.<br />
The facility with a capacity of more than 10,000 tonnes<br />
per year will produce high performance PLA for a broad<br />
range of applications. Commercial production is planned<br />
to start in the second half of 2014.<br />
Both parties have agreed to leverage Sulzer’s<br />
technology and pilot facilities to support the customer<br />
in the development of innovative solutions for the Asian<br />
polymer market.<br />
Sulzer’s proprietary technology allows the continuous<br />
production of high-performance PLA grades with very low<br />
residual monomer levels and a wide possible viscosity<br />
range. The new PLA produced with Sulzer technology<br />
exhibits an excellent crystallinity and withstands<br />
temperatures up to 180°C (HDT-B for stereocomplex<br />
PLA). Applications in the automotive, electronics and the<br />
textile industry based on this new type of material are<br />
currently under development and will see their market<br />
appearance in the near future.<br />
In order to further facilitate the PLA market<br />
development and to emphasize its commitment to<br />
the biopolymer industry, Sulzer has recently startedup<br />
its own PLA pilot plant for 1,000 tonnes per year in<br />
Switzerland. MT<br />
www.sulzer.com<br />
Renewable farnesene<br />
Amyris, Inc. (Emeryville, California, USA), a leading<br />
renewable chemicals and fuels company, recently announced<br />
the first commercial shipment from its new plant in Brazil.<br />
Amyris’s first purpose-built industrial fermentation facility<br />
produces Biofene ® , Amyris’s brand of renewable farnesene,<br />
a chemical building block to be used in a range of specialty<br />
chemical, fuel and polymer applications.<br />
With its unique chemical structure, Biofene is ideally<br />
suited for various polymer applications. Amyris is currently<br />
collaborating with two of its partners to incorporate Biofene<br />
in breakthrough applications.<br />
Amyris is working with Japan’s Kuraray to use Biofene<br />
to replace petroleum-derived feedstock in the production<br />
of specified classes of high-performing polymers for the<br />
tire industry. Initial testing indicates that Biofene provides<br />
differentiated performance for rubber tires by reducing<br />
rolling resistance, which improves fuel economy, without<br />
reduction in tire wear.<br />
Amyris has partnered with Italy’s Gruppo M&G to<br />
incorporate Biofene as an ingredient in PET (polyethylene<br />
terephthalate) resins for packaging applications. While<br />
lightweight, shatterproof and recyclable, plastic bottles are<br />
not very good at keeping air from reaching its contents,<br />
particularly food products. When processed, Biofene helps<br />
form an oxygen barrier for plastic bottles and jars.<br />
Amyris’s Biofene plant in Brotas, in the state of São Paulo,<br />
Brazil, sources its sugarcane feedstock locally from the<br />
Paraíso mill. Prior to the start-up of this facility, Amyris relied<br />
solely on contract manufacturing for commercial production.<br />
www.amyris.com<br />
Significantly enhanced heat and impact resistance<br />
Teijin Limited Tokyo, Japan, recently announced that it<br />
has developed technology to significantly enhance the heat<br />
and impact resistance of PLANEXT, the company’s highperformance<br />
bio-polycarbonate.<br />
The technology modifies the molecular design of Planext<br />
to achieve greatly improved heat resistance with a glasstransition<br />
temperature of 120°C, as well as superior<br />
resistance to impact. In addition, a separate proprietary<br />
flame-retardant technology enables Planext to achieve toplevel<br />
flame retardancy of UL94V-0 at 1.6mm.<br />
Teijin will develop markets for Planext as a strategic bio- and<br />
next-generation transparent material with new applications<br />
in the electronics, architecture and exterior fields, starting<br />
with the Japanese market. Annual production capacity at the<br />
company’s Matsuyama Factory in Ehime Prefecture, Japan is<br />
expected to expand to 3,000 tons within a few years.<br />
Planext is an eco-friendly bio-polycarbonate made with<br />
bio-content based on isosorbide from corn-starch and other<br />
plants. In addition to excellent moldability and durability, it<br />
is superior to oil-derived polycarbonates in terms of surface<br />
hardness (pencil hardness rank: H), weather and chemical<br />
resistance, and light transmission of 92%. With its newly<br />
enhanced heat and impact resistance, Planext is now a<br />
material suited for a much wider range of applications than<br />
ever before. MT<br />
www.teijin.com<br />
6 bioplastics MAGAZINE [03/13] Vol. 8
News<br />
Purac and Rotec<br />
cooperate in Russia<br />
In early April CJSC Rotec (Moscow, Russia, a<br />
subsidiary of the Renova Group of companies) and<br />
Purac (Gorinchem, The Netherlands), a subsidiary<br />
of CSM), signed an agreement on the development<br />
of a project to create a unique in the world high-tech<br />
biopolymer production facility in Russia.<br />
The agreement envisages analysis of opportunities<br />
to set in Russia a 100,000 tonnes/annum facility that<br />
will produce PLA polymers for subsequent production<br />
of biodegradable plastics.<br />
A facility of this scale operating on the basis of<br />
Purac’ technology of industrial PLA and lactides<br />
production from renewable resources from locally<br />
available biomass, and their polymerization knowhow,<br />
will be the first production chain of its kind in<br />
Europe.<br />
In the study, Rotec will focus on a location analysis<br />
related to the availability of optimal agricultural land<br />
and feedstocks and potential production locations,<br />
as well as research of the Russian market. Purac,<br />
leading player in natural food preservation and biobased<br />
building blocks & chemicals, will focus on the<br />
analysis of the optimal available feedstock-to-PLA<br />
technologies and defining the business case.<br />
In the event of positive project feasibility testing,<br />
the new facility will allow for industrial production of<br />
a revolutionary generation of polymers that will be<br />
unique for Russia and globally. According to Renova’s<br />
estimate, project investments will exceed rubles<br />
(RUB) 16bn (€ 400mio).<br />
As Renova Group’s High-Tech Asset Development<br />
Director Mikhail Lifschitz says, ”the prospect of<br />
creating a production facility of this kind will not only<br />
contribute to improvement of overall environmental<br />
situation in our country and the development of<br />
agricultural sector as the core supplier of raw<br />
materials for production of biopolymers, but will<br />
also improve the image of Russian economy as the<br />
user of environmentally friendly newest-generation<br />
materials”.<br />
Million-invest in<br />
bioplastic production<br />
The Russian company PoliKompleks plans to build a<br />
complex for rectification of lactic acid and for the production<br />
of bioplastics in the Kaliningrad region.<br />
The administration of the Kaliningrad region informed in<br />
a press release that an agreement was signed at the recent<br />
Hanover Fair (Hanover, Germany). According to that press<br />
release, the plants will produce about 50,000 tonnes/annum<br />
of bioplastics as well as about 12,000 tonnes/annum of<br />
biodegradable thawing agents on the basis of lactic acid or<br />
of polylactides (PLA) with a targeted turnover of 1.4 billion<br />
rubles (RUB) (€ 35 million) per year.<br />
The completion of the complex is scheduled for 2016, work<br />
to be started this year. The investment volume amounts to<br />
approximately RUB 1.2 bn (€ 30 million). A precise location of<br />
the facilities was not disclosed in the press release.<br />
The project will be the basis of a biochemical cluster.<br />
Together with similar industrial projects, e.g. for the<br />
automotive and shipbuilding industries, it will become a<br />
focus for future economic growth in the region. The whole<br />
project is part of a development plan of the bio-economy in<br />
Russia, known as Bio-2030. The strategic goal is to increase<br />
the bio-economy to 1% of the GDP by 2020 and 3% by 2030.<br />
For the Russian government bio-economy is an important<br />
part of the modernization of the economy, creating social<br />
benefits and new jobs, and working against depopulation in<br />
the rural areas.<br />
The company PoliKompleks has been active in the field of<br />
industrial biotechnology in several Russian regions as well as<br />
in Kazakhstan and Venezuela since 2009.<br />
According to the information from the Kaliningrad<br />
administration PoliKompleks cooperates (among others)<br />
with the Dresden, Germany based company Sarad. MT<br />
Source: www.nov-ost.info<br />
Renova is also the major shareholder of the Swiss<br />
corporations Sulzer and Oerlikon. MT<br />
www.purac.com<br />
www.renova.ru<br />
bioplastics MAGAZINE [03/13] Vol. 8 7
News<br />
15% annual growth for biodegradable plastics<br />
According to a new IHS Chemical global market research<br />
report, mounting consumer pressure and legislation such as<br />
plastic bag bans and global warming initiatives will increase<br />
demand for biodegradable plastics. In North America, Europe<br />
and Asia demand will rise to nearly 525,000 tonnes in 2017 (from<br />
269,000 tonnes in 2012). This represents an average annual<br />
growth rate of nearly 15% during his period.<br />
The IHS Chemical CEH Biodegradable Polymers Marketing<br />
Research Report focuses on biodegradable polymers, including<br />
compostable materials, but not necessarily including all biobased<br />
products.<br />
In terms of biodegradable polymer end-uses, IHS estimate<br />
that the food packaging (including fast-food and beverage<br />
containers), dishes and cutlery markets are the largest enduses<br />
and the major growth drivers. In both North America and<br />
Europe, these markets account for the largest uses and strong,<br />
double-digit growth is expected in the next several years.<br />
Foam packaging once dominated the market and continues to<br />
represent significant market share for biodegradable polymers,<br />
behind food packaging, dishes and cutlery. Compostable bags,<br />
as well as single-use carrier plastic bags, follow foam packaging<br />
in terms of volume.<br />
“The biodegradable polymers market is still young and very<br />
small, but the numbers are off the charts in terms of expected<br />
demand growth and potential for these materials in the coming<br />
years,” said Michael Malveda, principal analyst of specialty<br />
chemicals at IHS Chemical and the report’s lead author. “Food<br />
packaging, dishes and cutlery constitute a major market for the<br />
product because these materials can be composted with the<br />
food waste without sorting, which is a huge benefit to the waste<br />
management effort and to reducing food waste and packaging<br />
disposal in landfills. Increasing legislation and consumer<br />
pressures are also encouraging retailers and manufacturers to<br />
seek out these biodegradable products and materials.”<br />
In 2012, Europe was the dominant market for biodegradable<br />
polymers consuming 147,000 tonnes or about 55% of world<br />
consumption; North America accounted for 29% and Asia<br />
approximately 16%. Landfill waste disposal and stringent<br />
legislation are key market drivers in Europe and include a<br />
packaging waste directive to set recovering and recycling<br />
targets, a number of plastic bag bans, and other collection and<br />
waste disposal laws to avoid landfill.<br />
The most acceptable disposal method for biodegradable<br />
polymers - according to IHS - is composting. However,<br />
composting requires an infrastructure, including collection<br />
systems and composting facilities. Composting has been a<br />
growing component of most European countries’ municipal solid<br />
waste management strategies for some time, and the continent<br />
has an established and growing network of facilities, while the<br />
U.S. network of composting facilities is smaller, but expanding.<br />
In 2012, the two most important commercial, biodegradable<br />
polymers were polylactic acid (PLA) and starch-based polymers,<br />
accounting for about 47% and 41%, respectively, of total<br />
biodegradable polymers consumption. MT<br />
www.ihs.com<br />
Biome Bioplastics to investigate lignin<br />
The UK’s innovation agency, the Technology Strategy Board,<br />
has awarded a £150,000 (€ 176,000) grant to a consortium led<br />
by Biome Technologies, to investigate a biobased alternative<br />
for the oil derived organic chemicals used in the manufacturer<br />
of bioplastics.<br />
The research will be undertaken by the group’s bioplastic<br />
division Biome Bioplastics (Southampton, UK) in conjunction<br />
with the University of Warwick’s Centre for Biotechnology<br />
and Biorefining. The project is scheduled to last nine<br />
months and is about scaling up laboratory results to test<br />
their technical feasibility for commercial use, as reported by<br />
packagingeurope.com.<br />
One of the most interesting sources of biobased chemicals<br />
is lignin, a waste product of the pulp and paper industry, thus<br />
being a potentially abundant feedstock that could provide the<br />
foundation for a new generation of bioplastics.<br />
Biome has partnered with the University of Warwick’s<br />
Centre for Biotechnology and Biorefining that is pioneering<br />
academic research into lignin degrading bacteria. Together<br />
they want to develop methods to control the lignin breakdown<br />
process to determine whether aromatic chemicals can<br />
be isolated from the lignin in significant quantities. These<br />
aromatic chemicals are to replace the oil-derived equivalent<br />
currently used in the production of a polyester that conveys<br />
strength and flexibility in some of BIOME’s bioplastics.<br />
“The environmental and social concerns surrounding the<br />
use of fossil fuels make lignin a compelling target as a source<br />
of chemicals”, explains Professor Tim Bugg, Director of the<br />
Centre. “Often considered a waste product, it may provide a<br />
sustainable source of building blocks for aromatic chemicals<br />
that can be used in bioplastics”.<br />
“The bioplastics market remains small compared to that<br />
of fossil-based polymers”, comments Biome Bioplastics CEO<br />
Paul Mines. “Growth is restricted by the price of bioplastic resins<br />
being 2-4 times that of their petrochemical counterparts. We<br />
anticipate that the availability of a high performance polymer,<br />
manufactured economically from renewable sources would<br />
considerably increase the market”. MT<br />
www.biomebioplastics.com<br />
8 bioplastics MAGAZINE [03/13] Vol. 8
Events<br />
International conference<br />
in Cologne<br />
With 180 participants (60% up on 2012) from 23 countries<br />
(up 50%), this year’s International Conference on Industrial<br />
Biotechnology and Bio-based Plastics & Composites<br />
organized by the nova-Institute (Hürth, Germany) further<br />
established itself as a major industry meeting-place and<br />
visitors both grew in number and became more international.<br />
Lengthening the conference to three days to provide<br />
comprehensive coverage of political, industrial and scientific<br />
issues proved a success.<br />
The focus of this year’s conference was on the United States<br />
and Germany. The large number of American speakers and<br />
participants contributed to a thrilling dialogue between the<br />
world’s two leading industrial biotechnology countries.<br />
Policy<br />
The first day was largely devoted to discussing the political<br />
framework that could drive the development of the biobased<br />
economy and, above all, biobased materials and products.<br />
Industry<br />
During the industry sessions on the first and second<br />
day, companies such as Clariant Produkte (Germany),<br />
BASF (Germany), DuPont (USA), Bayer MaterialScience<br />
(Germany), NatureWorks (USA), Johann Borgers (Germany)<br />
and FlexForm Technologies (USA) presented their plans for<br />
biorefineries, new biobased polymers and natural-fibrereinforced<br />
composites.<br />
Science<br />
This was the first time that the conference had been<br />
extended to a third, scientific day, which nova-Institute<br />
organised with the collaboration of Professor Dr Jörg<br />
Müssig from Bremen University of Applied Science’s Bionics<br />
Innovation Centre. The organisers had succeeded in bringing<br />
together 13 renowned speakers from the USA and Germany.<br />
Biomaterial of the Year 2013<br />
There was great interest<br />
in the awards ceremony<br />
for the Innovation Prize<br />
for Biomaterial of the Year<br />
2013, which, as in previous<br />
years, was sponsored by<br />
Coperion GmbH and, for<br />
the fifth time, conference<br />
participants voted for<br />
the winners. This prize is<br />
awarded to new practical<br />
applications of biobased materials. Around 20 companies<br />
from the USA and Germany entered the competition.<br />
The First prize, Biomaterial of the Year 2013, was awarded<br />
to Newlight Technologies, LLC for its Airflex (AirCarbon)<br />
resins. CEO Mark Herrema presented a new kind of highyield<br />
technology chain to produce thermoplastics (PHAs)<br />
from greenhouse gases (such as CO 2<br />
and methane). See<br />
page 14 for a more comprehensive article on this technology<br />
The 2 nd prize went to fischerwerke GmbH & Co. KG<br />
(Germany) for their bio-PA universal UX green plug<br />
and the 3 rd prize was awarded to 4e solutions GmbH &<br />
TECNARO GmbH (Germany) - ajaa! For their product line<br />
of sustainable household articles from bioplastics - made<br />
in Germany. Both were already introduced in earlier issues<br />
of bioplastics MAGZINE. MT<br />
www.biowerkstoff-kongress.de<br />
www.nova-institut.eu<br />
left to right: Uta Kühnen (Coperion,<br />
Mark Herrema, Newlight, Michael Carus, nova-Institute)<br />
bioplastics MAGAZINE [03/13] Vol. 8 9
Did you know<br />
Did you know…?<br />
…about meat<br />
by Stephan Piotrowski<br />
nova-Institute<br />
Huerth, Germany<br />
kg meat per capita and year<br />
140.0<br />
120.0<br />
100.0<br />
80.0<br />
60.0<br />
40.0<br />
20.0<br />
0.0<br />
2000 2003 2006 2009 2012 2015 2018 2021 2024<br />
USA China Indiana<br />
Fig. 1: Per capita meat consumption in the USA, India and China<br />
(Source [1])<br />
m 2 /kg<br />
60<br />
50<br />
40<br />
30<br />
20<br />
10<br />
0<br />
Beef 34,5 (28-50) Pork 11 (9-13) Chicken 9 (8-10) Wheat 1,5<br />
Fig. 2: Land use for livestock products (in m 2 /kg of product)<br />
(Source [2, 3])<br />
The per capita meat consumption in the USA amounted<br />
to about 108 kg per year in 2012 [1]. The projection of<br />
FAPRI [1] until 2025 is that this level of consumption<br />
will rise only slightly to about 109 kg/year. This meat consumption<br />
level, one of the highest in the world, can be regarded<br />
as a kind of saturation level.<br />
If this consumption level would prevail in the whole world,<br />
this would equate to about 720 million tonnes of meat per year<br />
today (6.7 billion people) or about 1 billion tonnes in 2050 (given<br />
the UN population projection of 9.3 billion people by 2050).<br />
Currently, global meat consumption amounts to about 270<br />
million tonnes, so that consumption would rise by almost<br />
3 times today or almost 4 times by 2050. The current meat<br />
consumption demands about 60% of harvested agricultural<br />
biomass worldwide as feed. Assuming that this level of<br />
feed use is already the limit today, taking into account the<br />
already high competition for other biomass uses, mankind<br />
would therefore need today almost 2 more planets to satisfy<br />
the world’s appetite for meat. In addition to the total meat<br />
consumption, the kind of meat also plays an important role<br />
on the required land. Beef for example requires about twice<br />
as much land as pork or chicken.<br />
Looking out into 2050, approximately 40% yield increases<br />
are projected by the FAO for most arable crops. Ignoring all<br />
other influencing factors, two more planets may therefore<br />
still suffice to provide enough meat to the world. However,<br />
this calculation disregards, among many more, one<br />
important aspect: The increasing demand for food, energy<br />
and materials not only due to a growing world population,<br />
but also per person due to economic development and higher<br />
living standards.<br />
Eat more<br />
chicken!<br />
[1] Food and Agricultural Policy Research Institute (FAPRI) 2012<br />
[2] M. de Vries, I.J.M. de Boer; Comparing environmental impacts<br />
for livestock products: A review of life cycle assessments;<br />
Livestock Science 128 (2010) 1–11; Elsevier<br />
[3] Jørgen E. Olesen: Scenarios of land use in Denmark under<br />
climate change, Aarhus University, Denmark; bit.ly/17oWTa0<br />
(image: iStock: Chris3fer)<br />
10 bioplastics MAGAZINE [03/13] Vol. 8
Report<br />
New data on land-use<br />
Feedstock required for bioplastics production accounts for only a<br />
minimal fraction of global agricultural area.<br />
The surface required to grow sufficient feedstock<br />
for today’s bioplastic production is less than<br />
0.006 % of the global agricultural area of 5 billion<br />
hectares. This is the key finding published recently by European<br />
Bioplastics, based on figures from the Food and<br />
Agriculture Organization of the United Nations (FAO) and<br />
calculations of the Institute for Bioplastics and Biocomposites<br />
(IfBB, University of Applied Sciences and Arts,<br />
Hanover, Germany).<br />
In a world of fast growing population with an increasing<br />
demand for food and feed, the use of feedstock for non-food<br />
purposes is often debated controversially. The new brochure<br />
Bioplastics - facts and figures recently published by European<br />
Bioplastics, moves the discussion on to a factual level.<br />
Of the 13.4 billion hectares of global land surface, around<br />
37% (5 billion hectares) are currently used for agriculture.<br />
This includes pastures (70%, approximately 3.5 billion<br />
hectares) and arable land (30%, approximately 1.4 billion<br />
hectare). These 30% of arable land are further divided into<br />
areas predominantly used to grow crops for food and feed<br />
(27%, approximately 1.29 billion hectares), as well as crops for<br />
materials (2%, approximately 100 million hectares, including<br />
the share used for bioplastics), and crops for biofuels (1%,<br />
approximately 55 million hectares).<br />
Minimal fraction of land used for bioplastics<br />
European Bioplastics market data depicts production<br />
capacities of around 1.2 million tonnes in 2011. This<br />
translates to approximately 300,000 hectares of land-use<br />
to grow feedstock for bioplastics. In relation to the global<br />
agricultural area of 5 billion hectares, bioplastics make use<br />
of only 0.006 %. Metaphorically speaking, this ratio correlates<br />
to the size of an average cherry tomato placed next to the<br />
Eiffel Tower.<br />
No competition to food and feed<br />
A glance at the global agricultural area and the way it is used<br />
makes it abundantly clear: 0.006 % used to grow feedstock<br />
for bioplastics are nowhere near being in competition with<br />
the 98 % used for pastures and to grow food and feed.<br />
According to European Bioplastics, increasing the<br />
efficiency of feedstock and agricultural technology will be<br />
key to assuring the balance between land-use for innovative<br />
bioplastics and land for food and feed. The emergence of<br />
reliable and independent sustainability assessment schemes<br />
will also contribute to this goal.<br />
www.european-bioplastics.com<br />
Source: European Bioplastics | Institute for Bioplastics and<br />
Biocomposites (October 2012) / FAO<br />
bioplastics MAGAZINE [03/13] Vol. 8 11
Report<br />
Valorisation of<br />
by-products<br />
BioTRANSformation of by-products from fruit and vegetable<br />
processing industry into valuable BIOproducts<br />
by<br />
Thomas Dietrich<br />
TRANSBIO Coordinator<br />
TECNALIA<br />
Miñano – Álava, Spain<br />
Sustainable use of renewable raw materials is required to become<br />
a long lasting biobased economy. OECD stated already<br />
in 2001 that the use of eco-efficient bio-processes and renewable<br />
raw materials is one of the key strategic challenges for the 21 st<br />
century. Nevertheless, renewable raw materials must be used in a<br />
sustainable and environmental sound manner, as increasing demand<br />
for industrial products and energy from biomass will inevitably lead to<br />
an expansion of global arable land at the expense of natural ecosystems.<br />
Current strategies for utilization of biomass for food, biofuels<br />
and biomaterials resulted in some areas in increased land utilization<br />
for monocultures and competition of raw materials for food and fuel.<br />
According to OECD-FAO Agricultural Outlook (2012), some of 65% of<br />
EU vegetable oil, 50% of Brazilian sugarcane and 40% of US corn production<br />
are being used as feedstock for biofuel production. In parallel<br />
worldwide available agricultural area per person reduced significantly<br />
from 1,05 ha (1980) to 0,70 ha (2011) (FAOSTAT, 2013). Therefore, new<br />
untapped renewable resources such as by-products from fruit and<br />
vegetable transforming industry must be evaluated for their potential<br />
to be used as base material for biomaterials and platform chemicals.<br />
The aim of the European project TRANSBIO (grant agreement no.<br />
289603) is the implementation of an innovative cascading concept for<br />
the valorisation of by-products from fruit and vegetable processing<br />
industry, using environmental friendly biotechnological solutions to<br />
transform these by-products into biopolymers, platform chemicals<br />
and enzymes. Currently, Transbio is characterizing several fruit and<br />
vegetable by-products in order to select the most appropriate ones for<br />
further pre-treatment and enzymatic hydrolysis. In order to obtain a<br />
broad application potential for the by-products selected, the partners<br />
investigate different fermentation strategies – submerged cultivation<br />
in liquid media (bacteria, yeasts) and solid state fermentation (fungi).<br />
Parallel to on-going by-product characterisation and selection,<br />
partners identify several new strains to be utilized in the concept. Beside<br />
optimisation and up-scaling of fermentation protocols, down-stream<br />
processing will be developed keeping in mind economical feasible and<br />
sustainable procedures. The procedures will be implemented for extra<br />
cellular succinic acid production using novel non-conventional yeast<br />
strains, extracellular enzyme formation in solid state fermentation,<br />
as well as polyhydroxybutyrate (PHB) production in submerged<br />
fermentation. The obtained PHB will be tested in packaging application,<br />
enzymes will be proved for detergent utilisation and succinic acid will<br />
be purified for food applications. In order to achieve these objectives,<br />
the project is receiving funding from the European Union’s Seventh<br />
Framework Programme (FP7/2007-2013).<br />
www.transbio.eu<br />
12 bioplastics MAGAZINE [03/13] Vol. 8
Market study on<br />
Bio-based Polymers in the World<br />
Capacities, Production and Applications: Status Quo and Trends towards 2020<br />
Bio-based polymers – Production capacity<br />
will triple from 3.5 million tonnes in 2011<br />
to nearly 12 million tonnes in 2020<br />
Germany’s nova-Institute is publishing the most<br />
comprehensive market study of bio-based polymers<br />
ever made. The nova-Institute carried out this study<br />
in collaboration with renowned international experts<br />
from the field of bio-based polymers. It is the first<br />
time that a study has looked at every kind of biobased<br />
polymer produced by 247 companies at<br />
363 locations around the world and it examines in<br />
detail 114 companies in 135 locations (see table).<br />
Considerably higher production capacity was found<br />
than in previous studies. The 3.5 million tonnes<br />
represent a share of 1.5 % of an overall construction<br />
polymer production of 235 million tonnes in 2011.<br />
Current producers of bio-based polymers estimate<br />
that production capacity will reach nearly 12 million<br />
tonnes by 2020.<br />
million t/a<br />
12<br />
10<br />
8<br />
6<br />
4<br />
2<br />
0<br />
2011<br />
PLA<br />
Bio-based polymers: Evolution of<br />
production capacities from 2011 to 2020<br />
2012<br />
2013<br />
Starch Blends<br />
2014<br />
2015<br />
PHA<br />
2016<br />
2017<br />
PA<br />
2018<br />
2019<br />
PBAT<br />
2020<br />
PBS<br />
Content of the full report<br />
This over 360-page report presents the<br />
findings of nova-Institute’s year-long<br />
market study, which is made up of three<br />
parts: “market data”, “trend reports” and<br />
“company profiles”.<br />
The “market data” section presents market<br />
data about total production and capacities<br />
and the main application fields for selected<br />
bio-based polymers worldwide (status quo<br />
in 2011, trends and investments towards<br />
2020).<br />
The “trend reports” section contains a<br />
total of six independent articles by leading<br />
experts in the field of bio-based polymers<br />
and plastics. Dirk Carrez (Clever Consult)<br />
and Michael Carus (nova-Institute) focus<br />
on policies that impact on the bio-based<br />
economy. Jan Ravenstijn analyses the main<br />
market, technology and environmental<br />
trends for bio-based polymers and their<br />
precursors worldwide. Wolfgang Baltus (NIA)<br />
reviews Asian markets for bio-based resins.<br />
Roland Essel (nova-Institute) provides an<br />
environmental evaluation of bio-based<br />
polymers, and Janpeter Beckmann (nova-<br />
Institute) presents the findings of a survey<br />
concerning Green Premium within the value<br />
chain leading from chemicals to bio-based<br />
plastics. Finally, Harald Kaeb (narocon)<br />
reports detailed information about brand<br />
strategies and customer views within the<br />
bio-based polymers and plastics industry.<br />
These trend reports cover in detail every<br />
recent issue in the worldwide bio-based<br />
polymer market.<br />
The final “company profiles” section includes<br />
114 company profiles with specific data<br />
including locations, bio-based polymers,<br />
feedstocks, production capacities and<br />
applications. A company index by polymers,<br />
and list of acronyms follow.<br />
“Bio-based Polymers Producer<br />
Database” and updates to the report<br />
To conduct this study nova-Institute<br />
developed the “Bio-based Polymers<br />
Producer Database”, which includes a<br />
company profile of every company involved<br />
in the production of bio-based polymers and<br />
their precursors. This encompasses (state of<br />
affairs in 2011 and forecasts for 2020) basic<br />
information on the company (joint ventures,<br />
partnerships, technology and bio-based<br />
products) and its various manufacturing<br />
facilities. For each bio-based product,<br />
the database provides information about<br />
production and capacities, feedstocks, main<br />
application fields, market prices and biobased<br />
share.<br />
Access to the database is already available.<br />
The database will be constantly updated by<br />
the experts who have contributed to this<br />
report. Buyers of the report will have free<br />
access to the database for one year.<br />
Everyone who has access to the database<br />
can automatically generate graphics and<br />
tables concerning production capacity,<br />
production and application sectors for all<br />
bio-based polymers based on the latest<br />
data collection.<br />
Order the full report<br />
The full 360-page report contains three main<br />
parts – “market data”, six “trend reports”<br />
and 114 “company profiles” – and can be<br />
ordered for 6,500 € plus VAT at:<br />
www.bio-based.eu/market_study<br />
This also includes oneyear<br />
access to the “Biobased<br />
Polymers Producer<br />
Database”, which will be<br />
continuously updated.<br />
©<br />
©<br />
Polyolefins<br />
-Institut.eu | 2013<br />
PET<br />
CA<br />
PU<br />
Thermosets<br />
Evolution of the shares of<br />
bio-based production capacities in different regions<br />
20% 15%<br />
52%<br />
-Institut.eu | 2013<br />
2011 2020<br />
13%<br />
North America<br />
South America<br />
14% 13%<br />
55%<br />
Asia<br />
Europe<br />
18%<br />
Quellen: FEDIOL 2010<br />
BIO-BASED POLYMERS<br />
AVERAGE BIOMASS CONTENT<br />
OF POLYMER<br />
PRODUCING<br />
COMPANIESUNTIL<br />
2020<br />
LOCATIONS<br />
Cellulose Acetate CA 50% 9 15<br />
Polyamide PA rising to 60%* 14 17<br />
Polybutylene Adipate PBAT rising to 50%* 3 3<br />
Terephthalat<br />
Polybutylene Succinate PBS rising to 80%* 11 12<br />
Polyethylene PE 100% 3** 2<br />
Polyethylene Terephthalat PET 30% to 35%*** 4 4<br />
Polyhydroxy Alkanoates PHAs 100% 14 16<br />
Polylactic Acid PLA 100% 27 32<br />
Polypropylene PP 100% 1 1<br />
Polyvinyl Chloride PVC 43% 2 2<br />
Polyurethane PUR 30% 10 10<br />
Starch Blends **** 40% 19 21<br />
Total companies covered with detailed information in this report 114 135<br />
Additional companies included in the “Bio-based Polymer Producer Database” 133 228<br />
Total companies and locations recorded in the market study 247 363<br />
* Currently still mostly fossil-based with existing drop-in solutions and a steady upward trend of the average bio-based share up to given percentage in 2020<br />
** Including Joint Venture of two companies sharing one location, counting as two<br />
*** Upcoming capacities of bio-pTA (purifi ed Terephthalic Acid) are calculated to increase the average bio-based share, not the total bio-PET capacity<br />
**** Starch in plastic compound
Report<br />
Greenhouse<br />
gas-based PHA<br />
A Breakthrough In Yield, A New<br />
Paradigm in Carbon Capture<br />
by Karen Laird<br />
When Mark Herrema and Kenton Kimmel set out in<br />
2003 to develop a technology to convert greenhouse<br />
emissions into useful materials, they were armed<br />
with optimism, idealism, a healthy measure of self-confidence<br />
and the resolution to succeed. Today, ten years, ten<br />
patents and millions of dollars in research and development<br />
later, they’re the founding partners of Newlight Technologies<br />
LLC, a company specialized in high yield greenhouse gasto-PHA<br />
conversion and functionalization technologies, that is<br />
fast overturning all preconceptions about biopolymers.<br />
“When we started, our goal, simply put, was to reverse<br />
climate change by using carbon emissions to produce<br />
materials on a global scale,” says Mark Herrema. “Not only<br />
were we seeking a way to turn carbon emissions into plastics<br />
that actually removed more carbon from the air than they<br />
produced, we also knew that the only way we could do this on<br />
a commodity scale was if our material could out-compete on<br />
its own merits, without reference to environmental benefit.”<br />
In other words, the plastic materials Newlight produced<br />
would need to match oil-based plastics on performance<br />
and out-compete on price, definitely not features that had<br />
characterized most bioplastics up until now.<br />
Technological hurdles<br />
Kimmel and Herrema soon discovered that the idea of<br />
converting carbon-containing gases into plastics - in this<br />
case, PHA bioplastic - was not a new one; indeed, it was an<br />
ongoing object of study at companies in countries around<br />
the world, from Germany to the US to China. Everywhere,<br />
however, everyone kept running up against the same,<br />
seemingly insurmountable hurdle: yield.<br />
All currently available technologies had thus far failed<br />
to deliver a cost-effective and economically viable process<br />
14 bioplastics MAGAZINE [03/13] Vol. 8
Report<br />
to produce greenhouse gas-based PHA plastic at scale.<br />
“Obviously, more expensive PHA wasn’t something that could<br />
move at meaningful scale on the market,” said Herrema. “In<br />
addition, we found that the performance of the PHAs produced<br />
via the greenhouse gas route needed to be significantly<br />
improved to render these functionally competitive with oilbased<br />
plastics.”<br />
Next to these yield and performance limitations, Newlight<br />
also encountered new challenges, such as gas mass transfer<br />
conversion efficiency—that is, the amount of energy required<br />
to make greenhouse gases chemically accessible. Herrema:<br />
“Basically we realized that we were facing the task of having to<br />
develop new technology, which meant generating novel methods<br />
to approach yield, performance, and mass transfer efficiencies,<br />
and capabilities in catalyst engineering, reactor design, and<br />
polymer performance.”<br />
Breakthrough<br />
“It took years, and it was far from easy”, said Mark Herrema.<br />
“But we finally cracked it.”<br />
The central problem, as Newlight had discovered in the<br />
course of its work, was the fact that the company’s proprietary<br />
biocatalyst, developed to convert air and greenhouse gasses,<br />
such as methane and carbon dioxide into PHA, was controlled<br />
by a negative feedback control loop. This meant that when the<br />
concentration of plastic produced reached a certain maximum<br />
level, it would stop making plastic.<br />
To address this, Newlight developed a set of novel catalyst<br />
engineering tools, aimed at producing a biocatalyst with a<br />
malleable overproduction control switch—that is, the ability<br />
to turn off this negative feedback response. By turning off<br />
this response, the catalyst would overproduce PHA, thereby<br />
fundamentally altering the yield profile of the process. “That,<br />
at least, was the theory,” said Herrema. “Getting it to work in<br />
practice was trickier. “<br />
Yet ultimately, work it did, and with dramatic results, as<br />
illustrated by the immediate 500% increase in yield performance<br />
compared to before. The net result was that Newlight had<br />
successfully developed a market-driven solution to capturing<br />
carbon: technology able to produce plastic from greenhouse gas<br />
for significantly less than the cost to produce plastic from oil. In<br />
short, a PHA plastic offering a revolutionary value proposition.<br />
Herrema: “Explaining it like this makes it sound so simple.<br />
But an incredible amount of time and R&D ten years and<br />
millions of dollars - went into this development, and it unlocked<br />
something tremendous.“<br />
The breakthrough had immediate and profound impact. “We<br />
were able to reduce our unit operations by a factor of 3, the<br />
company’s capital equipment cost dropped by a factor of 5, and<br />
total operating costs were dramatically reduced.”<br />
At the same time, Newlight also developed a suite of<br />
polymer functionalization tools, and teamed with key<br />
partners to improve the performance of its resins, addressing<br />
classical PHA functional challenges, such as strength,<br />
flexibility, thermal stability, molecular weight, and aging.<br />
As a result, the company was able to develop the ability to<br />
tailor its materials to meet a wide range of performance<br />
specifications, spanning replacements for various grades of<br />
polypropylene, polyethylene, ABS, and TPU, in both durable<br />
and biodegradable grades.<br />
New challenges: sales and capacity<br />
expansion<br />
In 2012, Newlight began selling its Airflex (also known<br />
as AirCarbon) plastics for the first time. Since the<br />
commencement of sales, demand for Newlight’s materials<br />
has grown significantly in excess of capacity, with over<br />
5,700 tonnes of material now under executed letter of<br />
intent for purchase. “The response of the market has been<br />
overwhelming - we’ve been inundated with applications.<br />
In fact, everything we make is presold,” said Herrema.<br />
Moreover, in recognition of the company‘s technological and<br />
commercialization achievements in 2012, Newlight‘s plastic<br />
was named “2013 Biomaterial of the Year“ by the nova-<br />
Institut at an international biomaterials conference in April<br />
2013 (see p.9).<br />
Newlight’s customers and product development partners<br />
already include some of the largest manufacturers in the<br />
world, including Fortune 500 companies, brand-name market<br />
leaders, and an $8 billion consumer goods manufacturing<br />
company—making everything from chairs and containers to<br />
caps and bags. “We’re getting ready for a number of product<br />
launches,” said Herrema. “We’re preparing to launch a<br />
furniture line in the course of this year.”<br />
The company’s new focus is on growth and expansion, in<br />
order to be able to keep up with demand and, ultimately, to<br />
accomplish its founding objective: to use its carbon-negative<br />
plastics as a market-driven tool to reverse climate change.<br />
Newlight has its eye on a number of sites for a facility with<br />
a multi-thousand tonne per year projected annual capacity<br />
of. A first step in this direction is the capacity expansion that<br />
Newlight will have in place by the end of this year. “We’ve got<br />
the technology,” said Herrema. “The next challenge is to get<br />
it out to the market at large scale. That’s our mission now.”<br />
www.newlight.com<br />
bioplastics MAGAZINE [03/13] Vol. 8 15
Injection Moulding<br />
Not only for<br />
film making<br />
Potential applications: ecovio IS for injection moulding<br />
Six years ago BASF launched the compostable plastic<br />
ecovio ® – which is biodegradable as defined by EN 13432<br />
and based to a large extent on renewable resources.<br />
Since then the material was able to prove itself in a variety<br />
of film applications. To date, the primary fields of application<br />
have been bags for collecting biodegradable waste and mulching<br />
film, which helps to cultivate fruit and vegetables in fields.<br />
Now BASF has once again added variants to its range of<br />
the compostable and partially biobased plastic ecovio. The<br />
ecovio T2308 is now available for the processing method<br />
of thermoforming. For injection moulding the company<br />
offers the new ecovio IS1335 grade. Both of these products<br />
are now available in commercial quantities. They consist<br />
predominantly of renewable raw materials and lend<br />
themselves well for being dyed.<br />
Thermoforming: Processing on conventional<br />
flat-film installations<br />
The new ecovio T2308 can now be used to make<br />
thermoformed trays and cups can. It exhibits mechanical<br />
properties similar to those of amorphous PET, but it differs<br />
from this conventional thermoforming material by its<br />
compostability and its high content of renewable resources<br />
(PLA). The content of ecoflex ® , which is BASF’s compostable<br />
polyester, accounts for the fact that the material is not too<br />
stiff or too brittle. Thus, thermoformed trays and cups are<br />
not damaged during transportation and storage. The ecoflex<br />
component also ensures a balanced stiffness-to-strength<br />
ratio and sufficient low-temperature impact strength.<br />
The processing window for ecovio T, between 80°C<br />
and 120°C, is very broad in comparison to other plastics.<br />
Processing can be carried out on conventional flat-film<br />
installations and at the processing speeds that are typical for<br />
thermoforming. Like all ecovio grades, it also complies with<br />
the stipulations for products that come into contact with food.<br />
The material is translucent and can be adequately sealed<br />
with cover films.<br />
Injection molding: For thin-walled highquality<br />
packaging<br />
The second novelty in the ecovio product line, the injectionmoulding<br />
grade ecovio IS1335, can be processed using<br />
single-cavity or multi-cavity moulds that are equipped with or<br />
without hot runners. This material exhibits moderate flowing<br />
characteristics and is dimensionally stable under heat up<br />
to 55°C (HDT-B). This variant lends itself for thin-walled,<br />
complex and high-quality packaging, which should preferably<br />
be manufactured by injection moulding and should be<br />
compostable. The product can also be decorated employing<br />
in-mould labeling. Results of experiments on compostability<br />
show that, depending on the application, injection-moulded<br />
products made of ecovio IS1335 having wall thicknesses of as<br />
much as 1.1 mm degrade in accordance with the EN 13432<br />
standard for compostable packaging. Thicker mouldings will<br />
certainly biodegrade completely too, however, it takes longer<br />
than required in the compostability standards.<br />
A first serial application of this new injection mouldable<br />
ecovio grade is just being finalized together with a customer,<br />
a newcomer in the market. In this application (for the time<br />
being still confidential) the compostable plastic is part of a<br />
system solution for food packaging. The injection moulded<br />
grade is being used in combination with an ecovio-based<br />
multi-layer system with specific barrier properties.<br />
www.ecovio.de<br />
16 bioplastics MAGAZINE [03/13] Vol. 8
organized by<br />
supported by<br />
17. - 19.10.2013<br />
Messe Düsseldorf, Germany<br />
Bioplastics in<br />
Packaging<br />
Bioplastics<br />
Business<br />
Breakfast<br />
B 3<br />
PLA, an Innovative<br />
Bioplastic<br />
Bioplastics in<br />
Durable applications<br />
Subject to changes<br />
Call for Papers now open<br />
www.bioplastics-breakfast.com<br />
Contact: Dr. Michael Thielen (info@bioplastics-magazine.com)<br />
At the World’s biggest trade show on plastics and rubber:<br />
K’2013 in Düsseldorf bioplastics will certainly play an<br />
important role again.<br />
On three days during the show from Oct 17 - 19, 2013 (!)<br />
biopolastics MAGAZINE will host a Bioplastics Business<br />
Breakfast: From 8 am to 12 noon the delegates get the<br />
chance to listen and discuss highclass presentations and<br />
benefit from a unique networking opportunity.<br />
The trade fair opens at 10 am.<br />
Bio meets plastics.<br />
The specialists in plastic recycling systems.<br />
An outstanding technology for recycling both<br />
bioplastics and conventional polymers
Injection Moulding<br />
Watch bracelets<br />
made in Austria<br />
Cooperation agreement<br />
for biopolymer use<br />
In April 2012 an extensive research agreement with the Austrian<br />
FFG (a governmnet research body) and the Austrian states<br />
of Lower Austria and Carinthia was initiated. Cooperation with<br />
the Hirsch watch bracelet manufacturers (Carinthia), NaKu (Lower<br />
Austria) and Doraplast (Lower Austria) led to an optimisation of<br />
bioplastic technology.<br />
The first project, the development of an innovative watch<br />
bracelet, mount and fixture, made of biologically, compostable and<br />
heat resistant bioplastics, will enter the market in the summer of<br />
2013.<br />
The commercially available bioplastics did not meet the basic<br />
requirements of the project, so the team had to start right from the<br />
beginning with the development of a new material.<br />
The company NaKu (short for Natürlicher Kunststoff, i.e. natural<br />
plastic) is one of Austria’s pioneers in the field of bioplastics. Its<br />
range reaches from special compounds, acquired for higher<br />
temperatures, or made of waste materials such as sunflower seed<br />
cases, through to product development of items for retail sales or<br />
industry. Also NaKu supports its clients with the introduction of the<br />
process in the market, which is especially complex in the bioplastic<br />
sector. In Austria, NaKu supplies (amongst others) retailer Rewe<br />
with special fresh storage bags made of bioplastics. An expansion<br />
of the product range into kitchen articles led to shared interests<br />
with the company Doraplast.<br />
“The NaKu company was recommended to us by one of our long<br />
term clients, namely the Hirsch company”, said Franz Sprengnagel,<br />
manager of Doraplast. “We already had a wide product range of<br />
kitchenware made of traditional plastics. An expansion into the<br />
bioplastic sector with the company NaKu was perfectly obvious for<br />
us.” As a result, the Biodora or NaKuWare product line emerged.<br />
During the process of selecting basic working materials, the<br />
maximization of renewable and ecological resources was a crucial<br />
factor. Another important factor was the high biocompatibility and<br />
therefore the tolerance of lactic acid with the human body. The<br />
compostability of our kitchenware was not a real factor.<br />
In this way, a kitchen product line with 52 parts was generated,<br />
and one which is being extended permanently. The main focus for<br />
the kitchen line is the contact between food and plastic.<br />
This successful cooperation between the companies NaKu and<br />
Doraplast was one of the main reasons for the company Hirsch to<br />
start an alliance for their high quality watch bracelets. The first<br />
step was the invention of a laser-resistant watch bracelet mount<br />
made of bioplastics.<br />
18 bioplastics MAGAZINE [03/13] Vol. 8
The world market leader Hirscharmbänder GmbH,<br />
with head office in Klagenfurt, is confident that the issue<br />
of sustainability has to be actively faced and expanded<br />
in different areas during the production process of high<br />
quality watch bracelets.<br />
Hirsch is known for its pioneering role when it comes<br />
to the development of innovative materials, innovative<br />
products or innovative sales programmes. Thus they<br />
succeeded again and again in obtaining a clear advantage<br />
in the sector, true to the slogan “there is nothing that<br />
cannot be improved”.<br />
The watch bracelet mount, the so called Hirsch<br />
Point, is now produced by ABS/PC in the Far East. “The<br />
difficulties were, in particular, to combine the different<br />
technologies like thin walls for deep flow processes, laser<br />
markability and embossed sheet, with natural polymers.<br />
There is almost no experience to draw on,” said Johann<br />
Zimmermann, manager of company NaKu said.<br />
BuilDing<br />
a BioBaseD<br />
futuRe<br />
foR euRoPe<br />
At the same time, the production costs had to be<br />
reduced while moving production to Europe - a task<br />
that is only possible by using a high level of automation.<br />
Many principles had to be reviewed and a high number of<br />
material tests had to be carried out. The watch bracelet<br />
mount will be entering the market in the summer of 2013.<br />
The fascinating idea of the NaKu-Doraplast-Hirsch<br />
Cooperation is the investigation and introduction of a<br />
product line that is sustainable at all levels.<br />
The actual successes has convinced all project partners<br />
that the Hirsch bracelet mount will not be the last mutual<br />
project. More products are already in progress. MT<br />
www.naku.at<br />
www.hirschag.com<br />
www.doraplast.at<br />
Laser markability<br />
Register now!<br />
10 / 11 December 2013<br />
InterContinental Berlin<br />
More information is available at:<br />
conference@european-bioplastics.org<br />
Phone: +49 (0)30 28 48 23 50<br />
www.conference.european-bioplastics.org<br />
bioplastics MAGAZINE [03/13] Vol. 8 19
Cover Story<br />
Toys and more…<br />
Markus Swoboda, founder and managing director of the<br />
company BioFactur GmbH (Datteln, Germany) produces<br />
small things from bioplastics for day to day life.<br />
However, the way to market his products was not always easy.<br />
More than ten years ago he had the idea of making products<br />
from bioplastics because he was convinced that petroleum<br />
would, sooner or later, no longer be available - or affordable<br />
as a resource for plastics. “One day we will ask ourselves,<br />
why we didn’t start to do this earlier,” Markus Swoboda said<br />
to bioplastics MAGAZINE. Fossil-based plastics, with all the<br />
additives and plasticizers, had given him cause for concern,<br />
and he initially looked into toys. However, “to replace a<br />
conventional plastic material by a renewably sourced one was<br />
a tough road to follow - with many drawbacks”. Ten years ago<br />
there were not so many different biobased plastics available,<br />
he explained. At the end of 2009 Swoboda finally founded<br />
BioFactur with some of his first marketable products.<br />
Today BioFactur produces sand-box toys and food contact<br />
articles such as jugs for juices, drinking cups, lunch boxes<br />
or salad servers, exclusively from a cellulose acetacte-based<br />
bioplastic with properties in some ways even better than<br />
those of tradtional plastics, as Markus Swoboda explained.<br />
About 10 tonnes of this material per year is being purchased<br />
from a German supplier. “The wood cellulose all comes from<br />
sustainably managed forests - 80% from Europe and the<br />
rest from Canada,” Markus Swoboda pointed out. For the<br />
manufacture of his products he relies on standard injection<br />
moulding machines. The processing parameters, such as<br />
pressures, temperatures and processing times, do however<br />
have to be adjusted according to the requirements of the<br />
resins. Also the moulds have to be designed slightly differently.<br />
“A lot of things we had to learn the hard way,” he said.<br />
The material is free of any kind of toxic substances such as<br />
plasticizers, as confirmed by TÜV Rheinland, an independent<br />
testing and certification body. “So no problem for parents to<br />
let their kids chew on the toys,” as Swoboda commented.<br />
The latest product from BioFactur, just introduced<br />
to the market a few days before printing this issue of<br />
bioplastics MAGAZINE, is a set of toy blocks. Like most of<br />
their other products BioFactur sells them through two large<br />
mail order businesses, Memo and Waschbär, both strongly<br />
committed to sustainable products. In addition all products<br />
are available via BioFactur’s own online-shop. The company<br />
is planning to launch about two or three new products each<br />
year – mostly toys or household items.<br />
Being asked what pioneers such as BioFactur expect from<br />
bioplastics resin suppliers and from politicians, Swoboda<br />
said that first of all he hopes for a decrease in raw material<br />
prices. “With raw material costs 30% above tradtional plastics<br />
it is not so easy”, he said. He sees his growth potential in a<br />
sustainable commercial market. Swoboda makes it clear:<br />
“The advantages of bioplastics must be communicated very<br />
strongly, and here too we need the policy makers.” MT<br />
www.biofactur.de<br />
20 bioplastics MAGAZINE [03/13] Vol. 8
Injection Moulding<br />
Pitcher with separate<br />
bamboo handle<br />
Well Water (Reeuwijk, The Netherlands) recently announced<br />
that the patented and stylish Well Jug pitcher<br />
with its crystal clear Ingeo bioplastic pitcher and removable<br />
bamboo handle is now being made available to hotels,<br />
restaurants, food service organizations, and distributors for direct-to-consumer<br />
sales in the U.S. The Well Jug has been sold in<br />
Europe for the past year and with every unit purchased Well Water<br />
provides 264 gallons (1,000 liters) of clean drinking water to a village<br />
in Africa or Asia.<br />
Well Water has been giving 25% of the gross income from its<br />
bottled water business to charities since 2003. Several years ago,<br />
when the Dutch government launched a campaign to promote<br />
the use of tap water in order to reduce packaging, Well Water<br />
launched what would become a two and a half year research and<br />
development project into the Well Jug. The idea was to promote<br />
sustainability in the hospitality and food services industry with<br />
a reusable and sustainable cold drinks pitcher, while expanding<br />
efforts in Africa and Asia to bring fresh water to rural villages. The<br />
company is still working out how the sales of the Well Jug in the<br />
U.S. will figure into its drinking water and other charitable efforts.<br />
The Well Jug consists of a durable crystal clear injection<br />
molded Ingeo PLA 1 liter (1.06 quart) pitcher. To achieve the<br />
Well Jug’s crystal clear appearance with no flow marks was a<br />
balancing act in injection molding dependent on finding the<br />
optimum thickness for the pitcher’s walls.The removable handle<br />
is made from solid bamboo, one of the world’s fastest growing<br />
grasses. The handle can also be used by hotels, restaurants, or<br />
foodservice organizations to hold table announcements cards.<br />
Well Jug pitchers and handles are ultra-light, stackable, and<br />
require minimal transport and storage space. These pitchers are<br />
suitable for water, beer, juices, and other cold drinks and are hand<br />
washable in warm water.<br />
“The uniqueness of the Well Jug comes from its striking design,<br />
its utilization of sustainable materials, and the contribution of<br />
clean water to villages in Africa and Asia,” said Michel Rijkaart,<br />
director of sales and a principal/founder of Well Water. “The Well<br />
Jug on any table, whether it’s in a hotel or at a catered event,<br />
generates greater awarness and conversation about sustainable<br />
innovations.”<br />
Well Jugs can be customized with an orgnaization’s name<br />
and can be purchased in various colors. Hospitality, foodservice<br />
organizations, and distributors for direct-to-consumer sales<br />
interested in learning more about the innovative Well Jug may<br />
contact Michel Rijkaart directly.<br />
www.welljug.co.uk<br />
www.wellwater.nl<br />
bioplastics MAGAZINE [03/13] Vol. 8 21
Injection Moulding<br />
Liquid wood<br />
and more…<br />
Fig. 1: Green Lantern, Romolo Stanco<br />
by<br />
Lars Ziegler<br />
Jürgen Pfitzer<br />
Helmut Nägele<br />
Benjamin Porter<br />
Tecnaro GmbH<br />
Ilsfeld-Auenstein, Germany<br />
Founded in 1998, TECNARO GmbH develops, produces<br />
and markets bio-based and biodegradable compounds.<br />
Focusing on thermoplastic compounds made from renewable<br />
resources like lignin, cellulose, natural fibres, PLA,<br />
PHB, Bio-PE, Bio-PA and others, Tecnaro has been developing<br />
solutions for injection moulding, compression moulding,<br />
extrusion, calendaring, blow molding or thermoforming into<br />
moulded parts, semi-finished products, sheets, films or profiles.<br />
One of the raw materials mentioned is lignin, which is<br />
the second most abundant natural polymer after cellulose.<br />
More than 20 billion tonnes of lignin are generated naturally<br />
by photosynthesis per year. Lignin can be obtained as a<br />
by-product of the pulp and paper industry and the volume<br />
arising worldwide is about 50 to 60 million tonnes per year.<br />
Lignin can be extracted also from wood bark or straw. Mixing<br />
lignin with natural fibres like e. g. flax, hemp, wood or others<br />
and natural additives results in thermoplastic composites.<br />
These granules made from 100% renewable resources are<br />
named ARBOFORM ® (arbor, Latin = the tree) and protected<br />
with various patent families. Besides Arboform , Tecnaro´s<br />
business is focused on two other compound categories:<br />
Biopolymer compounds ARBOBLEND ® and natural fibre<br />
reinforced plastic composites ARBOFILL ® .<br />
ARBOFORM<br />
Arboform is sustainable, independent from crude oil,<br />
reduces environmental impacts and offers new markets<br />
for agriculture and forestry business. It combines two<br />
big industrial sectors: Wood industry can provide three<br />
dimensional parts in an economic way and plastics<br />
processors can substitute their materials by an ecological<br />
alternative. It can be considered as liquid wood.<br />
ARBOFILL<br />
The compounds are made from plastics and natural<br />
fibers like wood, hemp, flex, sisal, bagasse from sugarcane,<br />
bamboo, coir fibre from coconut husk, etc. This combination<br />
offers sustainable and aesthetical materials with good<br />
mechanical and thermal properties at very competitive costs.<br />
22 bioplastics MAGAZINE [03/13] Vol. 8
Injection Moulding<br />
Fig. 2: Bios line: Household series made<br />
from Arbofill with FDA approval, COZA<br />
ARBOBLEND<br />
Arboblend can be 100% biodegradable or durable. It<br />
consists – depending on the grade - of biopolymers like the<br />
wood constituent lignin or of lignin derivatives and/or other<br />
biopolymers like polylactic acid, polyhydroxyalkanoates,<br />
starch, natural resins and waxes, cellulose, but also grades<br />
with sugar based Polyethylene and plant oil based Polyamides<br />
are available.<br />
The scope of material properties covers bio-compounds<br />
for injection moulding with very low up to very high Young‘s<br />
moduli of 100 to 16,000 MPa and high tensile strengths up to<br />
100 MPa. Heat deflection temperatures (HDT-B) higher than<br />
150°C are possible and impact strength can be modified to<br />
non-break (Charpy unnotched).<br />
New Arboblend grades include Thermoplastic Elastomers<br />
(TPEs) which can have biobased carbon contents of more<br />
than 90%. Compounds with following properties are already<br />
available:<br />
• hardness in a range from 65 to 95 Shore A<br />
• compression set below 45%<br />
• tensile strength up to 8 MPa<br />
• elongation at break up to 800%<br />
Processing and Application<br />
Tecnaro´s approach as a specialized compounder is the<br />
optimal choice of polymers, fibres, fillers, processing aids and<br />
additives preferably from renewable and natural resources<br />
in order to achieve the required material properties and<br />
processability at lowest possible cost and environmental impact.<br />
Additives allow special functionalities and properties like<br />
flame resistance, UV stability and high impact strength. High<br />
heat deflection temperatures and impact properties can also<br />
be achieved by blending, fibre reinforcement and processing<br />
adaptations.<br />
Today’s series applications can be found in a wide range<br />
of products like e.g. household, toys, automotive, furniture,<br />
electronics, music instruments, packaging, stationary,<br />
building and construction industries as well as in funeral<br />
business, agriculture and forestry. Until today, more than 200<br />
series products have been realized so far.<br />
Due to free form geometries excellent designs can be<br />
achieved with Arboform. Low shrinkage grades allow<br />
precise tolerances in general without sink marks and very<br />
low warpage as well as a broad variation in wall thicknesses<br />
including thick-wall applications.<br />
Natural fibers are incorporated for reinforcement and<br />
sustainability reasons but also for special aesthetical<br />
designs: Injection moulded Arboform F results in surface<br />
appearances similar to root wood (see Fig 1).<br />
Arboform L and Arbofill have a regular visible fibre surface<br />
structure (see picture 2) which can be injection moulded<br />
without cloudiness or other typical moulding defects.<br />
Arboblend and Arbofill include grades which can be<br />
injection moulded into products with film hinges. Special<br />
Arboblend grades are available with Melt Volume Rates<br />
higher than 80 cm 3 /10 min. These are suitable for extreme<br />
thin-wall applications.<br />
Due to their low shrinkage and good bondage behavior<br />
several grades from all Tecnaro material families are suitable<br />
for Inmould Decoration IMD by back-filling of polymer and<br />
metal films as well as genuine wood veneers. According to<br />
a Tecnaro patent the latter can be moulded with overlap and<br />
therefore perfect intarsia can be realized without minimal<br />
gaps.<br />
Tecnaro´s bio-compounds can be chosen from an existing<br />
data base of already more than 2,000 formulations. For<br />
existing products and moulds the foreseen shrinkage and demoulding<br />
behavior as well as compatibility with hot runner<br />
systems, needle valves, etc. are taken into consideration. In<br />
case existing data seems not adequate for a new enquiry,<br />
modifications and new developments can be a suitable<br />
approach. Processing guidelines for each compound and<br />
technical assistance are provided for a successful start-up<br />
of serial production.<br />
www.tecnaro.de<br />
bioplastics MAGAZINE [03/13] Vol. 8 23
From Science & Research<br />
Lacquer from tomato<br />
for metal cans<br />
by<br />
D.ssa Angela Montanari,<br />
coordinator of BIOCOPAC project<br />
16-hydroxyhexadecanoic acid<br />
16Hid<br />
Introduction<br />
HO<br />
O<br />
10,16-dihydroxyhexadecanoic acid<br />
HO<br />
O<br />
Fig. 4: Composition of tomato cutin<br />
OH<br />
OH<br />
16Hid-10ol<br />
OH<br />
Every year millions of tons of tomatoes are used and<br />
large amounts of tomato by-products are treated as<br />
waste. About 300 million tonnes of by-products, waste<br />
and effluent are produced in the EU each year.<br />
Tomato waste consists essentially of the fibrous parts of<br />
fruits, seeds and skins, and can constitute as much as 2.2%<br />
of the weight of the processed tomato. The cost of disposing<br />
of these wastes is over 4 €/t. Currently tomato waste is used<br />
mainly for animal feed or, once it is dried, as the substrate<br />
for the production of fertiliser and lately for the production of<br />
biogas.<br />
Now BIOCOPAC, a project funded by the EU with € 800,000<br />
under the 7th European Framework, is to develop a biobased<br />
lacquer for the protection of metal food packaging, using a<br />
natural biopolymer, cutin, extracted from peels and skins of<br />
industrial tomato by-products. The idea for the project is based<br />
on an old patent developed by SSICA (Stazione Sperimentale<br />
per l‘Industria delle Conserve Alimentari) in the 1940.<br />
Lacquers for metal packaging<br />
The lacquers currently used are based on synthetic resins,<br />
mostly epoxy resins. However in recent years those synthetic<br />
lacquers have been the subject of several cases of alert due<br />
to problems of the migration of residues of polymerisation,<br />
monomers and oligomers, plasticizers added to the lacquering<br />
system or other additives. The object of the Biocopac project<br />
is to develop a natural based lacquer from the tomato skins.<br />
In this way Biocopac will meet the demand for sustainable<br />
24 bioplastics MAGAZINE [03/13] Vol. 8
From Science & Research<br />
Fig. 2: Dried tomato peels<br />
Fig. 1: Separation of tomato peels and seeds from tomato waste<br />
Fig. 3: Raw cutin<br />
production and for the safeguarding of consumer health,<br />
increasing at the same time the competitiveness of the metal<br />
can industry, valorising waste produced by the food industry,<br />
reducing refuse and obtaining a product with high added<br />
value.<br />
Analysis of tomato skins<br />
Tomato samples, collected in two tomato factories (one<br />
in Italy, one in Spain) have been subject to chemical and<br />
microbiological analysis. As the lacquer will be in contact<br />
with food products, the concentration of heavy metals and<br />
pesticides have been analysed. While tin (~ 80 ppb – parts<br />
per billion) and copper (4.9-11.8 ppb) were detected, other<br />
heavy metals were at values below the quantification limit of<br />
the measuring equipment. All samples analyzed for pesticide<br />
residues presented values below the significance’s limit.<br />
Set-up of the extraction’s method<br />
The procedure of extraction of raw cutin from tomato peels<br />
consists in a treatment of skins with an alkaline solution and<br />
then cutin is separated through precipitation for successive<br />
centrifugation after a treatment with an acid solution.<br />
This procedure has shown very good results, with regard to<br />
the final product obtained, the yield and the reproducibility of<br />
the method as well as the applicability of the method even on<br />
an industrial scale.<br />
The final bioresin obtained with the extraction procedure<br />
showed a good ability to form a new bio-lacquer that is the<br />
target of Biocopac project.<br />
The method has run not only in laboratory but also in a<br />
pilot plant with large quantities and high volumes. This is<br />
an important result for the project, as regarding a future<br />
application of the patent to industries. Naturally some<br />
improvements and modifications can be even studied and<br />
applied to obtain a continuous process.<br />
Analysis of the cutin extracted<br />
The composition of tomato skins’ cutin has just been<br />
extensively studied in relation to the plant’s botany.<br />
Recently Graça [1] provided a tomato cutin consisting of<br />
n,16-dihydroxyhexadecanoic acids where the 10-isomer<br />
is largely dominant. The tomato cutin is a polyester<br />
biopolymer interesterificated. The significant proportion<br />
of secondary esters (esterification in the C-10 secondary<br />
hydroxyl) shows that the polyester structure is significantly<br />
branched.<br />
Resin’s production<br />
The experimental work, in the consecutive phase, still in<br />
progress, has examined the production of the resin.<br />
For the production of the cutin-based resin two alternative<br />
methods are currently underway:<br />
• Homopolymerization of the extracted raw cutin<br />
With the homopolymerization the cutin-based resin has<br />
been obtained from extracted cutin applying particular<br />
experimental conditions of polymerization; in this method<br />
the cutin polymerizes with itself to get a higher molecular<br />
weight resin.<br />
bioplastics MAGAZINE [03/13] Vol. 8 25
From Science & Research<br />
• Copolymerization of the extracted cutin with selected<br />
petrochemicals raw materials<br />
With the copolymerization some standard polyester resins<br />
have been copolimerized with the extracted raw cutin (10%<br />
and 20%) and the resultant resins have been characterized.<br />
Development and application of the<br />
Biocopac lacquer<br />
Different formulations of lacquer containing from 10 to<br />
100% of cutin have been prepared and characterized in order<br />
to find the best formulations for the final bio-lacquer. The<br />
more promising formulations have been applied on different<br />
metallic substrates (tinplate, tin free steel and aluminium)<br />
and some properties such as degree of curing, appearance,<br />
sterilization’s resistance were measured.<br />
The first results obtained with at least two formulations,<br />
showed good values of chemical resistance (MEK - Methyl<br />
Ethyl Ketone - test), good adherence (tape test), good<br />
mechanical properties and a good resistance to thermal<br />
sterilization in water.<br />
Production of cans and caps<br />
Based on the first best formulations, sheets of tinplate<br />
and aluminium have been lacquered. From these lacquered<br />
sheets it has been possible to produce two piece cans,<br />
crown corks and caps. In all cases the lacquer didn’t show<br />
adherence’s loss, rather it has showed a good behaviour in<br />
all the products obtained as it can be seen in Fig. 5.<br />
Conclusions<br />
All these first results are considered very satisfactory<br />
and from these first results the researchers are optimistic<br />
about the possibility of realize a natural lacquer and chances<br />
of getting a polymeric film obtained from tomatoes are<br />
becoming a reality.<br />
www.biocopac.eu<br />
Fig. 5: Samples of cans and caps lacquered with varnish.<br />
[1] J. Graça and P Lamosa, ”Linear and Branched Poli<br />
(ω-hydroxyacid) Esters in Plant cutin”, J. Agric. Food Chem.<br />
2010,58,9666-9674.<br />
[2] J.C. Saam, “Low temperature polycondensation of carboxylic<br />
acids and carbinols in heterogeneous media”, J. Polym. Sci.,<br />
Part A: Polym. Chem.; 1998, 36, 341-356.<br />
[3] J.J. Benìtez, R. Garcìa-Segura, A. Heredia, “Plant biopolyester<br />
cutin: a tough way to its chemical synthesis”, Biochim. Biophys.<br />
Acta; 2004, 1674, 1-3.<br />
[4] J.A. Heredia-Guerrero, A. Heredia, R. Garcìa-Segura, J.J.<br />
Benìtez, “Synthesis and characterization of a plant cutin mimetic<br />
polymer”, Polymer, 2009, 50, 5633-5637<br />
[5] D. Arrieta-Baez, M. Cruz-Carrillo, M. B. Gòmez-Patino, L. G.<br />
Zepeda-Vallejo, “ Derivatives of 10,16-dihydroxyhexadecanoic<br />
acid isolated from tomato (Solanum lycopersicum) as potential<br />
material for aliphatic polyesters”; Mol., 2011, 16, 4923-4936.<br />
[6] European patent application EP 2 371 805 A1 “Method for the<br />
application of oligo- and polyesters from a mixture of carboxylic<br />
acids obtained from suberin and/or cutin and their use thereof”<br />
published by VTT Technical Research Centre of Finland on the<br />
5th November 2011.<br />
[7] Società Italiana Pirelli, Brevetto per invenzione industriale<br />
N° 389360 “Vernici a base di resina estratta dalle bucce di<br />
pomodoro” ,1944<br />
A significantly more comprehensive<br />
version of this article with more results<br />
and details about the project can be<br />
downloaded from<br />
www.bioplasticsmagazine.de/20<strong>1303</strong><br />
The project partners:<br />
• Stazione Sperimentale per l’Industria delle Conserve Alimentari<br />
(IT – RTD Performer)<br />
• Centro Tecnologico Agroalimentario Extremadura<br />
(ES – RTD Performer)<br />
• Fundacion TECNALIA Research & Innovation<br />
(ES – RTD Performer)<br />
• SYNPO A.S. (CZ – RTD Performer)<br />
• Salchi Metalcoat S.r.l. (IT – lacquer manufacturer)<br />
• Chiesa Virginio Azienda Agricola (IT – livestock & biogas producer)<br />
• Conservas Martinete S.A. (ES – manufacturer of canned tomato)<br />
• National Can Hellas S.A. (GR – metal packing)<br />
• Rodolfi Mansueto S.p.A. (IT – transformation of tomatoes)<br />
• Schekolin AG (LI – manufacturer of lacquers)<br />
• Saupiquet S.A.S. (FR – canned seafood producer)<br />
26 bioplastics MAGAZINE [03/13] Vol. 8
THE NO. 1 FOR<br />
WORLD PREMIERES:<br />
K 2013<br />
Get ready for your most important global business and contact platform. On a net exhibition space of more than<br />
168,000 sqm, some 3,000 exhibitors from over 50 countries will be presenting innovative solutions and visionary<br />
concepts in the areas of machinery and equipment, raw materials and auxiliaries, semi-finished products,<br />
technical parts and reinforced plastics. Plan your visit now. Welcome to your K 2013.<br />
International Trade Fair<br />
No. 1 for Plastics<br />
and Rubber Worldwide<br />
k-online.de<br />
Messe Düsseldorf GmbH<br />
Postfach 10 10 06 _ 40001 Düsseldorf _ Germany<br />
Tel. +49 (0)2 11/45 60-01 _ Fax +49 (0)2 11/45 60-6 68<br />
www.messe-duesseldorf.de
From Science & Research<br />
Bioplastic<br />
products<br />
from citrus<br />
wastes<br />
by<br />
Mohammad Pourbafrani 1<br />
Jon McKechnie 2<br />
Heather L. MacLean 1,3<br />
Bradley A. Saville 1<br />
1<br />
Department of Chemical Engineering and Applied Chemistry, University<br />
of Toronto, 200 College Street, Toronto, ON, M5S 3E5, Canada<br />
2<br />
Division of Energy and Sustainability, University of Nottingham,<br />
University Park, Nottingham NG7 2RD, UK<br />
3<br />
Department of Civil Engineering, University of Toronto, 35 St George<br />
Street, Toronto, ON, M5S 1A4, Canada<br />
Introduction:<br />
Biomass-derived plastics have the potential to displace<br />
relatively high market value products, while also contributing<br />
to sustainability objectives. In particular,<br />
second generation feedstocks such as agricultural residues<br />
offer great potential. Employing citrus wastes (CW) as a feedstock<br />
for bioplastics production has potential as a low-cost<br />
alternative, while providing other environmental advantages.<br />
Approximately 30 million tonnes of CW is estimated to be<br />
produced annually, representing half of the citrus fruit used<br />
for juice production [1]. New strategies for processing CW<br />
are required to address disposal challenges, including high<br />
costs, a lack of disposal sites, and concerns about negative<br />
environmental impacts of current practices. Citrus waste<br />
contains simple sugars and carbohydrate polymers such as<br />
cellulose and hemicellulose. The proposed CW biorefinery<br />
discussed in this article could convert these sugars and<br />
carbohydrates into bioethanol, while recovering limonene<br />
(natural solvent), and producing biomethane and nutrientrich<br />
digestate (fertilizer) from residual materials [1]. The<br />
bioethanol could then be further processed to renewable low<br />
density polyethylene (LDPE) following ethanol dehydration to<br />
ethylene.<br />
To evaluate the CW to LDPE process, it is important to<br />
understand the associated environmental implications from<br />
a life cycle perspective (from feedstock production through<br />
to the final product) and to compare with current production<br />
technologies. Understanding the greenhouse gas (GHG)<br />
emissions of the process is important due to the GHGintensity<br />
of current LDPE production from fossil fuels. In this<br />
article, the potential to reduce life cycle GHGs when LDPE is<br />
produced from citrus wastes is evaluated.<br />
Citrus waste to bioethanol<br />
A biorefinery for production of bioethanol from CW<br />
is presented in Fig.1. The technical data related to the<br />
28 bioplastics MAGAZINE [03/13] Vol. 8
From Science & Research<br />
Citrus<br />
Waste<br />
Acid<br />
Ethanol<br />
Hydrolysis<br />
Reactor<br />
Fermentation<br />
Distillation<br />
Flash<br />
Liquid Solid<br />
Flash<br />
Stillage<br />
Limonene<br />
Recovery<br />
Biogas<br />
Purification<br />
Anaerobic<br />
Digestion<br />
Limonene<br />
Methane<br />
Steam Boiler<br />
Steam<br />
Citrus<br />
Waste<br />
Biorefinery<br />
Methane<br />
Ethanol<br />
Power Plant<br />
Electricity<br />
and Heat<br />
Ethylene and LDPE<br />
Production Plant<br />
Excess<br />
to grid<br />
LDPE<br />
Limonene and Digestate<br />
Fig. 1. Block Flow Diagram of Ethanol Production from Citrus Wastes [1]<br />
Fig.2. Production of LDPE from Citrus Wastes<br />
biorefinery were published previously [1]. The biorefinery’s<br />
main stages include hydrolysis, fermentation, distillation and<br />
anaerobic digestion. Citrus waste carbohydrate polymers<br />
are converted into sugars during hydrolysis, and then<br />
fermented to produce bioethanol. The ethanol is purified<br />
by distillation and the non-fermentable sugars and other<br />
process residues are converted to biomethane by anaerobic<br />
digestion. Some of the biomethane is combusted to satisfy<br />
the thermal energy requirements for the biorefinery; excess<br />
biomethane is converted to electricity. In this biorefinery<br />
design, one dry tonne of CW yields 198 liters of ethanol,<br />
45 liters of limonene, 270 m 3 of biomethane and 220 kg<br />
digestate. For a hypothetical 40,000 dry tonne per year CW<br />
biorefinery, the ethanol production cost is estimated to be<br />
0.65 USD per litre [1].<br />
Bioethanol to bioplastic<br />
The ethanol produced by the CW biorefinery is dehydrated<br />
to ethylene in a catalytic process at high pressure and<br />
temperature [2]. Each kg of ethanol yields 0.59 kg of ethylene.<br />
This process is energy intensive and requires 5.6 MJ of<br />
thermal energy and 1.8 MJ of electricity per kg of ethylene<br />
produced. The ethylene is polymerized to LDPE, consuming<br />
0.3 MJ of thermal energy and 6.4 MJ of electricity per kg of<br />
LDPE. With 1 kg of ethylene yielding 1 kg of LDPE, each dry<br />
tonne of CW can produce ~92 kg of LDPE.<br />
Life Cycle Assessment of renewable LDPE<br />
from citrus wastes<br />
Although LDPE production from CW is an energy intensive<br />
process, biomethane generated in the biorefinery can provide<br />
the required energy (Fig. 1 and Fig. 2). The biomethane is<br />
utilized in a power plant that generates heat and electricity,<br />
which are consumed by the ethanol and ethylene production<br />
processes and the ethylene polymerization process; excess<br />
electricity is exported to the grid. Therefore, the production<br />
of LDPE from CW is energy self-sufficient.<br />
A life cycle assessment was performed to calculate the<br />
life cycle GHG emissions associated with LDPE production<br />
from CW. The key inputs, outputs and processes are shown<br />
in Figure 2, and include CW transportation, bioethanol<br />
production, ethylene production and LDPE polymerization.<br />
The emissions associated with LDPE production include all<br />
process steps, inputs and outputs. In addition, emissions<br />
credits resulting from the biorefinery’s co-products<br />
(limonene, digestate and biomethane) displacing chemical<br />
and fossil fuel products (acetone, biofertilizer and natural<br />
gas, respectively) are assigned to the LDPE. This method<br />
of co-product treatment, termed displacement or system<br />
expansion, is recommended under the International<br />
Organisation for Standardisation guidelines for life cycle<br />
assessment [3].<br />
Since generation of electricity and heat from biomethane<br />
is considered to be a carbon neutral process, the life cycle<br />
GHG emissions of LDPE production are dominated by<br />
chemical inputs to the process stages, fossil fuel use in<br />
transportation of CW to the biorefinery, and biomethane<br />
emissions from the biorefinery’s anaerobic digesters [4].<br />
The net life cycle emissions for the production of renewable<br />
LDPE are -4,100 g CO 2<br />
eq./kg. Negative emissions are<br />
achieved because of two factors: CW LDPE sequesters<br />
biomass carbon that would otherwise be released to<br />
the atmosphere; and emissions credits for co-products<br />
more than offset the production-related emissions. By<br />
comparison, the life cycle GHG emissions values for<br />
LDPE produced from crude oil are significantly greater<br />
(2,130 g CO 2<br />
eq./kg of LDPE) [5]. Prior work has assessed<br />
LDPE production from sugar cane [2], which found<br />
emissions to exceed those of crude oil-derived LDPE when<br />
including land use change-related emissions (e.g., land<br />
clearing directly or indirectly linked to sugar cane cultivation<br />
for ethanol production). In contrast, when using CW, no land<br />
use change related GHG emissions are incurred since CW is<br />
a byproduct of juice manufacture.<br />
bioplastics MAGAZINE [03/13] Vol. 8 29
From Science & Research<br />
Financial considerations<br />
Ongoing work will evaluate the financial performance of the<br />
above CW biorefinery system. Based on recent market prices<br />
for ethanol and LDPE [6, 7], process costs for converting<br />
ethanol to LDPE would have to be less than ~$0.20/kg<br />
LDPE to offer a competitive use of ethanol without subsidy.<br />
The financial attractiveness of LDPE production from CW is<br />
affected by the high market price of ethanol, which results<br />
in part from existing policies that mandate its use as a<br />
transportation fuel. Currently, similar support is not available<br />
to biomass-derived chemicals or plastics.<br />
Summary<br />
Conversion of CW to renewable LDPE is demonstrated<br />
to have the potential to significantly reduce life cycle GHG<br />
emissions compared to LDPE produced from fossil fuel or<br />
sugar cane. Utilizing global CW supply for producing LDPE<br />
would provide up to 3.5% of worldwide demand [8] and reduce<br />
emissions by approximately 3.4 million tonnes CO 2<br />
eq./yr,<br />
while simultaneously addressing environmental concerns<br />
related to CW disposal practices.<br />
[1] Pourbafrani M., 2011. Citrus Waste Biorefinery: Process<br />
Development, Simulation and Economic Analysis. PhD<br />
Dissertation. Published by Chalmers University of Technology.<br />
Gothenburg. Sweden.<br />
[2] Liptow C., Tillman A.M., 2009. Comparative Life Cycle<br />
Assessment of Polyethylene based on Sugarcane and Crude<br />
Oil. Report No.2009:14. Published by Chalmers University of<br />
Technology. Gothenburg. Sweden.<br />
[3] ISO 14044 (International Organisation for Standardisation)<br />
2006 Environmental Management—Life Cycle Assessment—<br />
Requirement and Guidelines<br />
[4.] Pourbafrani M., McKechnie J., MacLean L.H., Saville A.B., 2013.<br />
Life Cycle Greenhouse Gas Impacts of Ethanol, Biomethane<br />
and Limonene Production from Citrus Waste. Environmental<br />
Research Letter, 8, 015007 doi:10.1088/1748-9326/8/1/015007<br />
[5] PlasticsEurope, 2008. Low Density Polyethylene. http://www.<br />
plasticseurope.org/plastics-sustainability/eco-profiles.aspx<br />
(accessed 15/04/2013)<br />
[6] NASDAQ, 2013. Ethanol Futures. http://www.nasdaq.com/<br />
markets/ethanol.aspx (accessed 15/04/2013)<br />
[7] Platts, 2013. Platts Global Low-Density Polyethylene Price Index.<br />
http://www.platts.com/newsfeature/2013/petrochemicals/pgpi/<br />
ldpe (accessed 15/04/2013)<br />
[8] Nexant, 2010. Polyolefins planning service: Executive report,<br />
Global commercial analysis. http://www.chemsystems.com/<br />
about/cs/news/items/POPS09_Executive%20Report.cfm<br />
(accessed 15/04/2013)<br />
www.utoronto.ca<br />
www.nottingham.ac.uk<br />
Big enough to innovate,<br />
small enough to cooperate!<br />
It takes sophisticated technology to make plastics recycling<br />
sustainable and more efficient and to continuously improve pellet quality.<br />
And it takes commitment to really be successful.<br />
SIMPLY ONE STEP AHEAD<br />
®<br />
www.ngr.at<br />
30 bioplastics MAGAZINE [03/13] Vol. 8
Chinaplas Review<br />
Chinaplas 2013 took place from May 20 - 23 in the<br />
southern Chinese city of Guangzhou, being Asia’s No. 1 and<br />
the world’s no. 2 plastics and rubber exhibition. More than<br />
2900 exhibitors from 38 countries showed their expertise on<br />
220,000 m² of floor space. Chinaplas expected to attract more<br />
than 115,000 Chinese and foreign visitors from 150 countries<br />
looking to learn about, exchange and source chemicals and<br />
raw materials and a variety of plastics and rubber machinery.<br />
In a special Bioplastics Zone in hall 12.2 again more<br />
than 30 companies were listed in the show catalogue to<br />
present their products and services in terms of biobased<br />
and/or biodegradable plastics. Still there were a significant<br />
number of companies offering traditional PE or PP filled<br />
with starch, straw or bamboo and it could be argued whether<br />
or not such blends should be considered as bioplastics.<br />
The 5th International Seminar on Bioplastics Applications<br />
took place on May 18-19 in a Guangzhou hotel, sharing the<br />
latest trends, government policy on bioplastics and lowcarbon<br />
economy, and the technologies of the bioplastics<br />
industry. Key material suppliers, manufacturers, professional<br />
research organizations and machinery suppliers were invited<br />
to offer their expertise.<br />
As in previous years, the booth of bioplastics MAGAZINE was very<br />
well visited. We had lots of interesting talks and many visitors<br />
seriously interested in bioplastics. The 1000 copies of bioplastics<br />
MAGAZINE that were printed specially for this show were gone after<br />
two and a half of the four very busy days at Chinaplas.<br />
In addition to the Chinaplas Preview that we published in<br />
the last issue, we now add some more small reports about<br />
selected companies from the Bioplastics Zone in Guangzhou.<br />
Hubei Guanghe Bio-technology Co., Ltd.<br />
Since 2006 Hubei Guanghe Bio-technology has been<br />
engaged in the development of ultra-high molecular weight<br />
PLA compounds in cooperation with different universities<br />
and colleges. At Chinaplas they presented four different<br />
grades: GH401 for injection moulding, GH501 for sheeting,<br />
GH601 for stretch blow moulding and GH701 for film.<br />
Products made from the<br />
GH materials include<br />
disposable tableware, hotel<br />
consumables, agricultural<br />
applications and bags. All<br />
GH reins are OK-Compost<br />
certified (EN 13432).<br />
www.ghbt.com.cn<br />
Jiangsu Jinhe Hi-tech Co., Ltd<br />
This company is located in Yangzhou (Jiangsu province)<br />
near Shanghai. The main products are starch and straw<br />
filled polypropylene. The materials are well suited for<br />
injection mouding of high<br />
quality products such as<br />
cutlery, plates and bowls<br />
or even coat hangers, child<br />
chairs and toothbrushes.<br />
www.jsjhgk.com<br />
Guangzhou Bioplus Materials Technology<br />
CO., Ltd<br />
Bio-plus Materials<br />
Technology is specialized<br />
in the development<br />
of modified PLA. The predecessor,<br />
Junjia Technology<br />
Co., Ltd., was founded<br />
in 1998 and in 2006, the<br />
company started to step<br />
into the field of modified<br />
PLA and its application.<br />
Their current focus is on<br />
property improvement of<br />
PLA, especially on heat<br />
resistance and impact<br />
strength. By now, we have<br />
already made great progress on its heat resistance.<br />
Bioplus’ products include grades for injection moulding<br />
and such for extrusion and thermoforming with heat deflection<br />
temperatures up to 100°C without inorganic filers<br />
and such with white inorganic fillers. Special grades for<br />
foam appications and for bottle blowing as well as such for<br />
melt spinning are also available.<br />
www.bio-plus.cn<br />
bioplastics MAGAZINE [03/13] Vol. 8 31
Chinaplas Review<br />
ITENE<br />
The Spanish Packaging, Transport & Logistics<br />
Research Center ITENE is a Technological Center that<br />
promotes, in general and for any type of business,<br />
scientific research, technological advancement, the<br />
development of information society and promoting<br />
sustainability in the areas of packaging, logistics,<br />
transportation and mobility. Now ITENE presented<br />
itself in the Bioplastics Zone at Chinaplas. Among other<br />
products and services they showed blends of PLA and<br />
nano-clay. These products were developed in order to<br />
enhance mechanical and barrier properties.<br />
www.itene.com<br />
DuPont<br />
The RS product range of DuPont (RS for renewably<br />
sourced) is well known. It comprises among other<br />
products the long-chain Zytel RS polyamide 1010, the<br />
elastomer Hytrel RS and the PTT material Sorona.<br />
While the PA 1010 offers different properties and<br />
functionalities compared to PA 11 or PA 12, the Hytrel<br />
RS elastomer is a drop-in material with the same<br />
properties as the oil based Hytrel. Here it is important<br />
for customers that the biobased version is not more<br />
expensive. Sorona is not very much used in China, but<br />
the Japanese automotive company Toyota recently<br />
decided for an air outlet in the instrument panel of the<br />
Prius model for Sorona. This saved cost compared to<br />
PBT or PA6. Not due to the resin price, but due to the<br />
fact, that the PTT version did not need to be painted in<br />
a secondary step.<br />
With an R&D center in Shanghai and compounding<br />
plant in Shenzhen DuPont offer their clients<br />
comprehensive consultation in the development of<br />
applications.<br />
www.dupont.com<br />
Fukutomi<br />
The core business<br />
of Fukutomi Company<br />
Ltd. From Shantou,<br />
China, is the production<br />
of plastic parts from<br />
plastic scrap. To prove<br />
their commitment to<br />
environmental protection<br />
and to follow the company’s objective of sustainable<br />
development, Fukutomi also started to produce PLA<br />
compounds as well as parts from PLA. Fukutomi has<br />
produced products such as ice cream spoons, golf tees and<br />
flower pots from Biodegradable Polylactic Acid. The PLA<br />
compounds include grades for injection moulding, bottle<br />
blowing and sheet grades.In order to meet the customers<br />
growing requirements, Fukutomi provide PLA material<br />
modification, mould design and production service.<br />
www.fukutomi.com<br />
Shandong Fuwin New Material Co. Ltd.<br />
Shandong Fuwin New<br />
Material Co. Ltd., from Zibo<br />
Shandong is primarily engaged<br />
in the production and R&D<br />
of fully biodegradable plastic<br />
materials and fine chemicals.<br />
Their products include BDO,<br />
PBS and PBS co-polymers<br />
and are marketed under the brand name ECONORM. Fuwin’s<br />
capacity for the production of PBA and PBSA is about 25,000<br />
tonnes/annum. Their materials are made with biobased<br />
succinic acid and currently still with fossil based BDO. Injection<br />
moulding grades (e.g. for disposable cutlery, plant pots etc)<br />
are available as well as blown film grades e.g. for shopping<br />
bags or mulch film.<br />
www.sdfuwin.com<br />
Nafigate<br />
Nafigate Corporation a.s.<br />
from Prague (Czech Republik)<br />
presented their biotechnology<br />
for PHA production that was<br />
developed by (Czech) Brno<br />
University of Technology.<br />
Nafigate is now seeking to<br />
find partners to invest into this<br />
technology. The distinctive feature of the technology is that it uses<br />
waste cooking oil as the raw material und thus does not compete<br />
in any way with food or feed.production. The high performance<br />
bioprocess for the production of PHA assures lower operational<br />
cost and market price, as a spokesperson told bioplastics<br />
MAGAZINE. A model calculation for a 10,000 tonnes/annum plant<br />
shows the potential to achieve a market price of EUR 2.1 (USD<br />
2.8) per kg of raw material.<br />
www.nafigate.com<br />
Shenzhen Esun Industrial CO., Ltd.<br />
Established in 2002 and<br />
located in Shenzhen Special<br />
Economic Zone, Shenzhen<br />
Esun Industrial Co., Ltd.<br />
is a high-tech enterprise<br />
specializing in researching,<br />
developing, producing and<br />
operating degradable polymer<br />
materials, such as PLA and<br />
PCL. The company strives<br />
for becoming the leader<br />
in biodegradable material<br />
industry and achieving the<br />
breakthrough of 200,000<br />
tonnes annual capacity within<br />
the next ten years. One of the highlights at Chinaplas is the new<br />
PLA sheet material for the production of cards: membership<br />
cards, gift cards, etc.<br />
www.brightcn.net<br />
32 bioplastics MAGAZINE [03/13] Vol. 8
Chinaplas Review<br />
Tianjin GreenBio Materials Co., Ltd<br />
GreenBio is dedicated<br />
in the development,<br />
production and sale of<br />
the fully degradable<br />
bio-based polymer<br />
materials PHA and its<br />
application products.<br />
So far GreenBio has<br />
established the worlds largest production base of PHA<br />
in the Binhai District in China (capacity 10,000 tonnes/<br />
annum). The PHA materials are marketed under the<br />
brand name Sogreen. Among other products GreenBio<br />
have developed exclusive PHA foam pellets. This kind of<br />
foam pellets have over 20 times in expansion and can<br />
be made into full-biodegradable foam food service ware<br />
and industry or electric appliance packaging to replace<br />
conventional EPS. As highlights at Chinaplas the company<br />
presented heat stretch film and nonwoven fibre products.<br />
www.tjgreenbio.com<br />
Toray<br />
Toray Industries Inc. headquartered in Tokyo, Japan,<br />
offers a range of different products under the common<br />
brandname ecodear. This includes blends of PLA with<br />
ABS (offering higher strength), blends of PLA with PC (with<br />
enhanced flame retardance) and PLA blends with PMMA<br />
offering an excellent transparency in combination with heat<br />
resistance. Other members of the ecodear family are a<br />
PA 610, a bio-Polyethylene foam based on Braskem Green<br />
PE and a partly biobased PBT, made with bio-BDO.<br />
Grabio Greentech Corporation<br />
Grabio Greentech<br />
Corporation specializes<br />
in the development<br />
and manufacture of<br />
100% biodegradable<br />
and compostable starch<br />
plastics. Their products<br />
are GRABIO film grade resin and GRABIO agri grade<br />
resin. Grabio starch plastics are all certified (EN 13432<br />
and ASTM D6400) compostable. At Chinaplas Grabio<br />
displayed its existing GB series film grade products,<br />
among which a newly developed GBL series film grade<br />
material was also on display. The new GBL series<br />
material has more rigid texture and higher renewable<br />
content, and is suitable for making shopping bag, fruit<br />
bag, magazine wrapping and other flexible packing<br />
applications. Moreover, besides the GB and GBL series,<br />
the developing GBXV series material is designed for high<br />
transparency require packaging application.<br />
www.grabio.com.tw<br />
www.toray.co.jp/english/plastics<br />
Shanghai Disoxidation Macromolecule<br />
Materials Co., Ltd<br />
With the mission of Life<br />
&Environment Balance<br />
and Natural, No Harm,<br />
Shanghai Disoxidation<br />
Macromolecule Materials<br />
Co., Ltd (DM) is providing<br />
plastic manufacturers<br />
and consumers with<br />
biodegradable starch<br />
resins and related<br />
derivatives, such as<br />
shopping bags, garbage<br />
bags, films and outside<br />
package. The company<br />
is located in Xiangshi Road Jin Ban Industrial Zone of<br />
Kunshan, Jiangsu Province and runs 10 Coperion dual<br />
screw extruders, automatic feeding and packaging.<br />
DM have a capacity of 32, 000 tones/year. Their product<br />
BSR-09 was developed for blown film application and is<br />
EN 13432/ASTM 6400 certified compostable.<br />
www.dmmsh.com<br />
bioplastics MAGAZINE [03/13] Vol. 8 33
Application News<br />
Biobased barrier<br />
packaging for cheese<br />
Bicycle mudguards<br />
As part of a diploma project on the subject<br />
of “Ecologically sustainable packaging in<br />
the food industry” the Ecological Dairies<br />
at Allgäu (ÖMA – Ökologische Molkereien<br />
Allgäu) worked closely together with Plantic<br />
Technologies GmbH (the German branch<br />
of Australian Plantic Technologies Limited)<br />
on the basic concepts of using sustainable<br />
packaging materials. After an extensive<br />
series of product tests the cheeses<br />
specialists, who consistently focuses on ecological products,<br />
decided in February 2013 to try a new approach to the<br />
packaging question and from April used Plantic eco Plastic<br />
for the first time for their pre-packaged sliced cheese.<br />
Plantic eco Plastic was developed to replace petroleumbased<br />
plastics with bioplastics in the food industry. It is the<br />
first barrier packaging in the world that is biobased up to 80%<br />
from renewable resources. The thermoform sheet consists<br />
of a three-layer structure with the Plantic core layer being<br />
up to 80% of the total film thickness and having particularly<br />
good barrier properties, as explained to bioplastics MAGAZINE<br />
by Brendan Morris CEO at Plantic. “It is embedded between<br />
two very thin layers of polyethylene which also contributes to<br />
the excellent sealing performance of the laminate film. The<br />
new biobased lidding film will come in the next few months”.<br />
During the production process up to 50% less energy is<br />
used when compared with conventional polymers, and Plantic<br />
eco Plastic can offer this material, which is so important for<br />
food packaging, in good quantities.<br />
“That was an important step in the right direction, and<br />
underlines our company philosophy. We aim for ecological<br />
progress and high quality. In both areas, using the new<br />
packaging, we have made a significant step forward”, said<br />
Michael Welte, CEO of ÖMA. “As the first German supplier of<br />
bio-cheeses we have now developed a sustainable packaging<br />
solution for our bio-cheese slices that also supports the<br />
product’s freshness.”<br />
“At the time of the changeover we had two main problems”,<br />
continued Michael Welte. “Firstly we had to ensure that the<br />
maize-based packaging we were using was totally free of<br />
any genetically modified products, and secondly, since our<br />
product places high demands on the barrier performance<br />
of the packaging material it was important that our project<br />
partner Plantic Technologies, was able to offer a material that<br />
would not allow any loss of quality or taste”.<br />
“We were able to confirm this within the extensive product<br />
test programme that was carried out”, said Brendan Morris. MT<br />
Zéfal (Jargeau, France) is the world’s leading<br />
manufacturer of bicycle accessories. Innovation and<br />
environment play a significant part in the corporate<br />
strategy and eco-design of the products is part of a longterm<br />
progress undertaking.<br />
Zéfal launched its bio-based range Green’Z with a low<br />
carbon footprint at the Eurobike show in 2012. This range,<br />
the first in the world, comprises the Green’Z Deflector<br />
FC50 & RC50 mudguards made with plant-based plastic.<br />
To this end Zéfal selected Gaïalène ® (by Roquette) on<br />
account of its certified environmental qualities and its<br />
possible recyclability at the end of life. This plastic has<br />
turned out to be easy to use with slight manufacturing<br />
process adjustments and has enabled a reduction in the<br />
consumption of electricity used by the injection machines.<br />
‘’Focused on the future our teams who are passionate<br />
about their work innovate every day in order to improve<br />
the practice of cycling. The strong links we have forged<br />
with the cycling community and the bicycle distributors<br />
inspired the creation of this Green’Z range”, explains<br />
Mathieu Brunet, the Chairman and Chief Executive of<br />
Zéfal.<br />
This initiative enables Zéfal to propose a range<br />
of products that constitute a breakthrough from an<br />
environmental standpoint, while retaining the same<br />
manufacturing quality that the customers are used to.<br />
The mechanical and ageing tests have confirmed the<br />
suitability of this material for these applications linked to<br />
sport and nature.<br />
The result is a carbon footprint reduced by over<br />
65% compared with the products usually made from<br />
polypropylene, without any compromising on the technical<br />
or economic performances.<br />
Zéfal is consequently going to pursue this initiative with<br />
several products in its range and intends in the coming<br />
years to develop the Green’Z brand by innovating in other<br />
complementary applications. MT<br />
www.zefal.com<br />
www.gaialene.com<br />
www.oema.de<br />
www.plantic.eu<br />
34 bioplastics MAGAZINE [03/13] Vol. 8
Application News<br />
First PA 410 film introduced<br />
DSM Engineering Plastics (since early 2012 headquartered<br />
in Singapore) recently announced that its development<br />
partner MF Folien GmbH in Kempten, Southern Germany,<br />
successfully introduced a new polyamide film, which is based<br />
on DSM’s bio-based EcoPaXX ® polyamide 410.<br />
MF Folien is a leading expert in the production of polyamide<br />
film, and has been DSM’s development partner for EcoPaXX<br />
film from the start. In 2011, the company was the first to<br />
create samples of 30 µm cast film from EcoPaXX. This film<br />
has the same high quality level for which MF Folien is very<br />
well known in the market. Samples of film based on EcoPaXX<br />
are available in various thicknesses: 30, 40 and 50 µm.<br />
Potential application areas are in flexible food packaging,<br />
building & construction, medical, aviation and shipping.<br />
Rainer Leising, general sales manager MF Folien, said: “We<br />
are delighted to be working with DSM on the development of<br />
this innovative and sustainable material solution. Since we<br />
first introduced EcoPaXX film, with its distinctive shiny, silvery<br />
‘high-tech’ appearance, the material has been featured in our<br />
product brochure.” EcoPaXX polyamide 410 films are strong<br />
and transparent with a high puncture resistance. They have<br />
a reduced moisture transmission rate versus polyamide 6<br />
film, and a comparable oxygen barrier. When fully wet, the<br />
oxygen barrier of polyamide 410 is even higher.<br />
Recently, three grades of EcoPaXX were given the “Certified<br />
Biobased Product” label (70%), awarded by the United States<br />
Department of Agriculture (USDA). The bio based content of<br />
EcoPaXX polyamide 410 stems from one of its building blocks,<br />
derived from castor oil obtained from plants that grow in<br />
tropical regions and which are not used for food products. MT<br />
www.dsm.com<br />
www.ecopaxx.com<br />
www.mf-folien.de<br />
PLA serviceware in Asia<br />
Purac’s partners have successfully launched a range of<br />
PLA serviceware based on PURALACT ® Lactides. The range,<br />
available in retail outlets in Singapore, features printed text<br />
‘Love Eco’ and ‘PLA’ on each item.<br />
The packaging includes a variety of sustainability and<br />
performance statements, including:<br />
• dishwasher safe<br />
• microwave safe<br />
• food contact approved (USA & Europe)<br />
• biodegradable.<br />
The serviceware is being produced by New Sunrise<br />
Plastics Co and is retailed at Giant Hypermarket in<br />
Singapore.<br />
Puralact Lactide monomers for PLA are exclusively made<br />
from non-GMO feedstocks, heat resistant up to 120°C,<br />
biobased, biodegradable & recyclable.<br />
www.purac.com/bioplastics<br />
www.srplastic.com<br />
bioplastics MAGAZINE [03/13] Vol. 8 35
From Science & Research<br />
Advances in<br />
PLA chemistry<br />
by<br />
Alexander Hoffmann<br />
Sonja Herres-Pawlis<br />
Ludwig-Maximilians University<br />
Munich, Germany<br />
New robust catalysts for lactide polymerization:<br />
Zinc complexes of neutral nitrogen donors<br />
Ring-opening polymerisation (ROP) of lactide represents<br />
a growing field of research because the resulting polymers<br />
are biodegradable and based on renewable raw<br />
materials which ensures growing attention within the context<br />
of Green Chemistry. Up to now, neutral nitrogen donor ligands<br />
have been overlooked in their potential to stabilise catalytically<br />
active systems. This contribution highlights recent developments<br />
in this area as well as the applicability in the lactide<br />
polymerisation with special regard to the reaction conditions.<br />
Targeting a use in industrial scale, the tolerance towards<br />
moisture, air, lactide impurities and high temperatures is an<br />
important issue to be considered during catalyst design.<br />
For the well-controlled synthesis of polylactide with regard<br />
to composition, molecular weight and microstructure, the<br />
coordination-insertion process is now commonly regarded as<br />
the most efficient method [1-4]. This mechanism (Figure 1)<br />
involves the coordination of the monomer to the metal<br />
centre, followed by a nucleophilic attack of the alkoxide to the<br />
acyl carbon atom and the insertion of lactide into the metalalkoxide<br />
species with retention of configuration [5]. A new<br />
metal-alkoxide species is formed which is capable of further<br />
insertion reactions.<br />
Under industrial conditions, mostly homoleptic catalysts are<br />
used like tin(II)ethylhexanoate, zinc(II)lactate and aluminium<br />
isopropoxide in combination with alcohols as initiators [6].<br />
These catalyst systems can be conveniently synthesised<br />
and utilised in the polymerisation of cyclic esters but<br />
complicated equilibria phenomena and multiple nuclearities<br />
of the active species result in limited polymerisation control.<br />
Detrimental side reactions like transesterifications and<br />
epimerisations may occur which lead to a broadening of the<br />
molar mass distribution. Consequently, the development of<br />
new catalysts for the ring-opening polymerisation of lactide<br />
has seen tremendous growth over the past decade [1-5,7]. As<br />
amelioration, these catalysts shall enable a better control,<br />
activity and selectivity during the polymerisation by optimal<br />
adaption of the coordinating ligands. A vast multitude of<br />
well-defined Lewis acid catalysts following a coordinationinsertion<br />
mechanism has been developed for this reaction<br />
mainly based on tin,[8] zinc,[9-12] aluminium[13-15] and rare<br />
earth metals [16-20].<br />
To develop the polymer from a specialty material to a<br />
large-volume commodity plastic the development of new<br />
polymerisation catalysts is required. Most large-scale<br />
processes are based on the use of stannous compounds<br />
as initiators [3,4,7]. For use in food packaging or similar<br />
applications, heavy metals are undesirable because of<br />
accumulation effects [3,4].<br />
To date, the design of new catalysts mostly follows the<br />
paradigm that an efficient lactide ROP initiating system<br />
needs an anionic ligand, e.g. alkoxides, amides, ketiminates<br />
or an alcohol as co-initiator which forms the truly active<br />
species as alkoxide. The high polymerisation activity of all<br />
these systems is often combined with high sensitivity towards<br />
air and moisture. For industrial purposes and especially the<br />
breakthrough of PLA in the competition with petrochemical<br />
based plastics, there is an exigent need for active catalysts that<br />
tolerate air, moisture and small impurities in the monomer<br />
[3,4,7]. The disadvantageous sensitivity can be ascribed to<br />
the anionic nature of the ligand systems stabilising almost<br />
all of these complexes.<br />
36 bioplastics MAGAZINE [03/13] Vol. 8
From Science & Research<br />
the use of the sterically less demanding guanidine-pyridine<br />
ligands, a multitude of zinc complexes could be isolated and<br />
trends for the ROP activity were derived [29,30]. In case of<br />
the quinoline-guanidine complexes, mono(chelate) chlorido<br />
complexes exhibit smaller activity than the mono(chelate)<br />
acetato complexes [29,30]. Especially quinoline-guanidine<br />
bis(chelate) triflato zinc complexes exhibited very high<br />
activity and robustness towards monomer impurities at<br />
the same time. Using technical quality lactide, molecular<br />
weights of 70000 and 77000 g mol -1 (M n<br />
) with PDs of 2 could<br />
be obtained with conversions of >90% [29,30]. Together with<br />
comparative studies with guanidine mesylato complexes,[31]<br />
it came up that within the bis(chelate) triflato zinc complexes<br />
the zinc atom possesses a high positive partial charge and<br />
the guanidine a pronounced negative charge.<br />
Figure 1. Coordination-insertion mechanism for lactide ROP<br />
The role of neutral donor ligands for the stabilisation of<br />
ROP active systems has to be highlighted because this niche<br />
has been overlooked for years [21]. With regard to industrial<br />
usefulness, only systems with real applicability in lactide bulk<br />
polymerisation are discussed here (Figure 2). The scope of<br />
used neutral N donors ranges from simple alkylated amines<br />
and substituted pyridines over guanidines to sophisticated<br />
oxabispidines and oxalamidines. Historically, the pyridinecarbene<br />
zinc complexes of Tolman and coworkers are the<br />
first complexes of this class; they polymerise lactide at<br />
140°C within minutes with a polydispersity (PD) of 2.4 [22].<br />
The robust 9-oxabispidine zinc acetate complex has been<br />
reported as ROP active system in the lactide melt at 150°C<br />
(PD = 2) but with low yields [23]. As rather simple neutral ligand<br />
systems, the classic N donor ligands 2,2´-bipyridine and<br />
1,10-phenanthroline were proven to stabilise zinc complexes<br />
with surprising ROP activity under challenging conditions<br />
in melt in 2009 [24]. The polydispersities of approximately 2<br />
account for the presence of transesterification reactions.<br />
In order to overcome the limitations of anionic and other<br />
sensitive ligand systems, the potential of a neutral but<br />
highly nucleophilic ligand system was evaluated. Guanidines<br />
convince by their good donor properties and their strong<br />
nucleophilicity [25,26]. In 2007, the first cationic complex<br />
[Zn(DMEG 2<br />
e) 2<br />
][OTf] 2<br />
comprising an aliphatic bis(guanidine)<br />
has been reported as active ROP catalyst for the lactide<br />
polymerisation in melt at 150°C [27]. In following studies with<br />
the closely related but more basic imino-imidazoline 8MeBL,<br />
it appeared that the partial charge at the zinc atom as well<br />
as on the donating Nimine atom is crucial for the lactide<br />
activity [28]. Using mono(chelate) zinc imino-imidazoline<br />
complexes high conversions of 88 % were observed. With<br />
As guanidines are strong neutral donors, their<br />
nucleophilicity was proposed to help the ring-opening<br />
reaction. In all these polymerisation experiments with<br />
commercial grade PLA, no external initiator had been added.<br />
Hence, the working hypothesis implied the coordination<br />
of the lactide to the zinc centre followed by a nucleophilic<br />
attack of the guanidine on the carbonyl C atom of the lactide<br />
molecule. Guided by this idea, extensive density functional<br />
studies for the ROP with guanidine triflato zinc complexes<br />
were accomplished [32]. In fact, this computational study is<br />
the first DFT study for the ROP with neutral ligands without<br />
additional co-initiators. The fluorescence activity of the<br />
guanidine-quinoline ligands gave further mechanistic hint<br />
because the quinoline-related emission can be traced in the<br />
zinc complexes and the resulting polylactide. Moreover, the<br />
UV absorption of the guanidine-quinoline ligands was found<br />
in the corresponding lactide as well [32]. In summary, these<br />
studies showed that the guanidine zinc triflato complexes<br />
react in a variant of the coordination-insertion mechanism<br />
with the nucleophilic attack to the lactide performed by the<br />
guanidine and the classic ring-opening step as next transition<br />
state [32]. The great impact of the guanidine is expressed in<br />
two central traits: the excellent donor capacity stabilises<br />
very robust zinc complexes and the high nucleophilicity of<br />
the guanidines enables the ring-opening of cyclic esters by<br />
the guanidine donor functionality. The great advantage of<br />
guanidine systems is their extraordinary robustness towards<br />
moisture and monomer impurities. Until now, comparable<br />
robust systems have only been reported by Davidson et al.[33]<br />
who used tris-phenolate titanium complexes. However, the<br />
zinc guanidine systems combine in a unique manner many<br />
crucial features for efficient large-scale lactide ROP. In<br />
detail, the robustness of zinc guanidine complexes in lactide<br />
ROP supersedes monomer recrystallisation or sublimation<br />
and saves cost-effective processing steps. Moreover, the<br />
polymerisation can be accomplished under melt conditions<br />
at high temperatures up to 200°C without racemisation<br />
effects [32]. This is important for further applications in<br />
reactive polymer extrusion.<br />
bioplastics MAGAZINE [03/13] Vol. 8 37
From Science & Research<br />
magnetic_148,5x105.ai 175.00 lpi 15.00° 75.00° 0.00° 45.00° 14.03.2009 10:13:31<br />
Prozess CyanProzess MagentaProzess GelbProzess Schwarz<br />
Magnetic<br />
for Plastics<br />
• International Trade<br />
in Raw Materials,<br />
Machinery & Products<br />
Free of Charge<br />
Figure 2. Selected catalysts<br />
with neutral donor ligands<br />
Targeting simpler and cheaper donor systems, very<br />
recently, zinc complexes of peralkylated amines came<br />
into the focus of research: they are derived from lowpriced<br />
starting materials and convince by high ROP<br />
activity at 150°C to molecular weights of 65000 g mol -1<br />
at PD of 2 [34,35]. Parallely, the donor class of oxalic<br />
amidines has been investigated for the stabilisation of<br />
zinc complexes in the polymerisation of lactide which<br />
opens up a new neutral N-donor ligand class [36]. An<br />
oxalic amidine zinc chlorido complex yields polylactide<br />
with 50000 g mol -1 at PD of 1.4.<br />
www.plasticker.com<br />
• Daily News<br />
from the Industrial Sector<br />
and the Plastics Markets<br />
• Current Market Prices<br />
for Plastics.<br />
• Buyer’s Guide<br />
for Plastics & Additives,<br />
Machinery & Equipment,<br />
Subcontractors<br />
and Services.<br />
• Job Market<br />
for Specialists and<br />
Executive Staff in the<br />
Plastics Industry<br />
The comprehensive concept of robust N donor zinc<br />
systems has been proven to yield efficient and versatile<br />
ROP active catalysts. In general, the importance of<br />
neutral ligands for the ring-opening polymerisation of<br />
lactide cannot be underestimated. With regard to the<br />
major breakthrough of bioplastics for the substitution of<br />
petrochemical plastics in the commodity market, every<br />
robust catalyst system represents a huge step towards<br />
greater sustainability of our society.<br />
www.cup.lmu.de/ac/herres-pawlis<br />
Up-to-date • Fast • Professional<br />
A complete list of the quoted references<br />
can be found at http://bit.ly/12aHSmx<br />
38 bioplastics MAGAZINE [03/13] Vol. 8
Materials<br />
Innovative<br />
biopolymer blend<br />
An innovative PLA based blend with improved toughness and durability<br />
is close to reaching the market. The material, named Floreon<br />
was developed under a TSB funded knowledge transfer partnership<br />
between materials scientists at the University of Sheffield and CPD<br />
plc, a leading UK distributor of office water cooler bottles. Floreon is intended<br />
as a replacement for polyethylene terephthalate (PET) in CPD’s<br />
15 litre water bottles, but has also shown promise as a cutting/printing<br />
substrate for applications such as key cards and horticultural labels.<br />
A plant pot label made from Floreon<br />
CPD’s existing PET bottle<br />
Water cooler bottles present a promising application for this material<br />
as they are distributed in a closed loop system. It is intended that the<br />
improved durability will make the bottles suitable for reuse, allowing the<br />
bottles to go through many cycles of use before further conversion. The<br />
team are now exploring the use of reground bottles in extruded sheet<br />
applications for cutting and printing, or even reconversion into bottles.<br />
When extruded as sheet the material cuts well and is also a good<br />
substrate for printing. Floreon sheet items have excellent mechanical<br />
performance and feel and the challenge now is to make the material<br />
cost competitive. The use of recycled PLA as a base material for Floreon<br />
has been trialled with promising results and the aim is to match the<br />
price of current materials whilst offering better performance and a<br />
range of end of life options.<br />
Floreon is unique in comparison with other PLA based blends due<br />
to its simplicity and versatility. The patent pending blend uses small<br />
quantities of commercially available biodegradable (certified to<br />
EN13432) thermoplastics which enhance the mechanical performance<br />
of PLA whilst also making it easier to process. The material has passed<br />
independent food contact testing with a range of aqueous and fatty food<br />
simulants.<br />
A further innovation in the works is the use of self-sanitising additives<br />
with Floreon. Polycarbonate (PC) bottles can go through hundreds of<br />
cycles of reuse, being washed at ~60 °C before each refill and using<br />
strong detergents and chemicals. The inclusion of additives to prevent<br />
biofilm formation would reduce or alleviate this need saving large<br />
amounts of energy throughout the bottle life. Initial tests with additives<br />
that inhibit microbial growth have shown promising results when<br />
combined with Floreon. This could provide an alternative to reusable<br />
bottles made from PC, a material associated with health concerns due<br />
to the leaching of bisphenol A.<br />
The project has also been funded by the REY programme, which is<br />
delivered by the low-carbon consultancy CO2Sense and part-funded by<br />
the European Regional Development Fund. CO2Sense help businesses<br />
and public-sector organisations cut their greenhouse gas emissions<br />
and costs, and have accelerated the project with funding to purchase<br />
materials and tooling for production trials.<br />
www.floreon.com<br />
bioplastics MAGAZINE [03/13] Vol. 8 39
PLA Recycling<br />
Bioplastics want to<br />
be recycled as well<br />
EREMA makes sure the loop is closed<br />
Erema T recycling system for the recycling of PLA<br />
Plastic is becoming an increasing economic factor as a<br />
valuable secondary raw material. The reasons are plain to<br />
see. Whereas the production of plastics has risen by 8%<br />
per year over the last decade, primary raw material resources<br />
are declining dramatically. The fact is that raw material prices<br />
are continuing to soar. Increasing importance is being attached<br />
to bioplastics from renewable raw materials and high-quality<br />
secondary raw materials.<br />
Booming bioplastics trend – but the loop is not<br />
closed yet<br />
The ever growing ecological awareness in society and the<br />
increasing popularity of reusable materials has meant that the<br />
demand for bioplastics has risen considerably in recent years<br />
and products made of bioplastics have become a booming<br />
economic factor. The annual growth rate in Europe, for example,<br />
is in the region of 20%, with the share of biobased plastics<br />
becoming more and more predominant. According to European<br />
Bioplastics some 1.161 million tonnes are currently produced<br />
and the forecast for 2016 is over 5 million tonnes (with biobased<br />
equivalents of conventional plastics accounting for the major<br />
share).<br />
In order to be able to close the loop in the bioplastics sector,<br />
too, however, you need the appropriate recycling solution. This<br />
is currently possible only in the case of production waste in<br />
defined loops. Bioplastics in post-consumer waste, on the other<br />
hand, are not separated due to the amounts still being too low.<br />
As the amounts increase, however, so too does the necessity to<br />
handle new material flows so existing recycling loops are not<br />
jeopardised. The appropriate collecting and sorting systems are<br />
becoming increasingly important as a result.<br />
Bioplastics recycling requires expertise<br />
Since it was founded in 1983, EREMA (Ansfelden, Austria)<br />
has specialised in the development and production of plastic<br />
recycling systems and technologies and is regarded as the global<br />
market and innovation leader in these sectors. The team of the<br />
Austrian group of companies and subsidiaries in the USA and<br />
China, plus around 50 local representatives in all five continents<br />
provide custom recycling solutions for international customers.<br />
The recycling of packaging – made of bioplastics, among other<br />
things – is a key field.<br />
Erema has already been working on the processing of<br />
bioplastics of a wide variety of biopolymer types such as bioPE,<br />
bioPET, PLA (fibres, films), PHA, starch-based products,<br />
etc. for over ten years – whether it is flat film, blown film or<br />
biaxially oriented films and assorted types from a wide range<br />
of manufacturers including Mater-Bi ® film from Novamont,<br />
Ecoflex ® film from BASF or Ingeo PLA from Natureworks.<br />
Erema Marketing Manager Gerold Breuer explains<br />
what the recycling of bioplastics entails: “It is important to<br />
differentiate between biobased and biodegradable plastics. The<br />
characteristics of biobased drop-in types such as bioPET or<br />
bioPE are no different to those of conventional plastics based<br />
on fossil raw materials – they are merely made from a different<br />
raw material. This means that they can be processed with the<br />
same parameters. Bioplastics which are both biobased and<br />
biodegradable, such as starch-based products or also PLA,<br />
require an adapted processing profile in recycling. PLA is very<br />
sensitive to moisture, for example, and the shearing forces that<br />
arise in the course of processing.“<br />
40 bioplastics MAGAZINE [03/13] Vol. 8
PLA Recycling<br />
EREMA systems already close loops<br />
Erema has acquired a wealth of information in the field of<br />
bioplastics recycling thanks to over 400 trials in the Erema<br />
Customer Centre every year and recycling applications<br />
at customers. Bioplastic customers in Europe and the<br />
USA are already using Erema recycling systems with<br />
success for production waste from defined bioplastic loops.<br />
Moisture-sensitive materials such as PLA are carefully cut,<br />
homogenised, prewarmed and dried in the patented Erema<br />
cutter/compactor. The drying in this process is so efficient<br />
that in many cases there is no need for any additional extruder<br />
degassing. The warm material which is processed this way<br />
is thus melted, filtered and pelletised with minimum shear<br />
stress in the extruder. “In many cases PLA material can be<br />
recycled with an Erema T system, i.e. without any additional<br />
extruder degassing. The drying and treatment in the large<br />
cutter/compactor are so efficient and gentle that there is no<br />
thermal damage. We know from rheological measurements<br />
of recycled materials that the valuable polymer structure is<br />
retained and there is no viscosity loss,“ emphasises Gerold<br />
Breuer (see diagram).<br />
viscosity<br />
Viscosity function<br />
Rheometry; T=170°C<br />
EREMA T<br />
Input: PLA mill material<br />
shear rate<br />
Research findings confirm that PLA material processed with an<br />
EREMA T system, i.e. without additional extruder degassing, can be<br />
recycled without viscosity loss<br />
New innovation highlights at K 2013<br />
Erema’s research and development team works<br />
continuously on the further development of its technologies<br />
in order to drive forward a closing of the loops. The latest<br />
innovations from the global market leader will be on show<br />
this year at K 2013 (International Trade Fair for Plastics and<br />
Rubber, 16 to 23 October 2013, Düsseldorf, Germany). These<br />
will include the presentation of a new solution which gives<br />
customers additional benefits particularly for temperaturesensitive<br />
bio(plastics), too. Gerold Breuer shares with us<br />
exclusively what it is all about: “This whole package of<br />
technical innovations enables above all optimised material<br />
intake so that temperature-sensitive bioplastics such as<br />
PLA can also be processed at lower temperatures with high<br />
throughput rates.”<br />
Conclusion: (bio)plastic recycling – closing the<br />
loop<br />
Turning waste plastic, regardless of whether it is bioplastics<br />
or not, into high-quality and recognised secondary raw<br />
material calls for intensive communication in the entire<br />
plastics industry – between raw material suppliers, plastic<br />
processors and recyclers. This would result in the development<br />
of materials which would take into account their later<br />
recyclability at the time they are produced. The way forward is<br />
to organise material flows better and optimise the production<br />
of plastics in such a way that new, high-quality products with<br />
a high recycling content can be achieved. And as Erema says,<br />
‘Closing the loop’ makes sustainability happen.<br />
www.erema.at<br />
Bewährt zuverlässige<br />
Leistung<br />
Vorbildlicher<br />
Kundenservice<br />
Hohe<br />
Innovationskraft<br />
Engagiertes und<br />
erfahrenes Team<br />
Halle 09,<br />
Stand 9B65<br />
16 – 23 October 2013<br />
www.gala-europe.de<br />
bioplastics MAGAZINE [03/13] Vol. 8 41
PLA Recycling<br />
PLA recycling<br />
via thermal<br />
depolymerization<br />
by<br />
Ramani Narayan<br />
Xiangke Shi<br />
Daniel Graiver<br />
Biobased Materials Research Group<br />
Michigan State University<br />
Sample # Lactide monomer % Note<br />
1 93.49 PLA Resin<br />
2 93.49 PLA Resin<br />
3 91.79 NatureWorks Ingeo cups<br />
Table 1. Recovery of lactide by catalytic thermal depolymerization<br />
PBAT<br />
content<br />
Lactide recovered –no<br />
catalyst<br />
Table 2. Recovery of lactide monomer from PLA-PBAT blends<br />
Figure 3. Laboratory scale recovery of<br />
lactide from PLA polymers and blends<br />
Lactide recovered<br />
0.1% SnO 2<br />
0% 99.7% 99%<br />
10% 98.7% 99.6%<br />
25% 96.5% 81.6%<br />
50% 80.0% 68.2%<br />
Background<br />
PLA, poly(lactic acid) is a commercial 100%<br />
biobased thermoplastic polymer that has<br />
found wide spread industrial applications.<br />
It derives its value proposition from having a zero<br />
material carbon footprint arising from the short<br />
(in balance) sustainable biological carbon cycle.<br />
This is different from the process carbon footprint<br />
(the carbon and environmental footprint arising<br />
from converting the feedstock to product, use, and<br />
ultimate disposal, typically covered by LCA methodology<br />
[1, 2]. Many issues of bioplastics MAGAZINE<br />
have showcased the commercial applications of<br />
PLA, and it is the biobased plastic of choice in the<br />
market today. The typical end of life option for the<br />
PLA product is in industrial composting systems,<br />
where it is readily and completely assimilated by<br />
the microorganisms present in the compost environment<br />
as “food” (completely biodegraded in<br />
industrial composting environment) releasing<br />
energy that it utilizes for its life processes.<br />
A viable end-of-life option for PLA is chemical<br />
recycling back to monomer – a virtual cycle of<br />
monomer to polymer and back to monomer<br />
– a circular biobased economy. PLA can be<br />
manufactured by the direct condensation<br />
polymerization of lactic acid with concomitant<br />
removal of water. However, it is difficult to<br />
obtain the high molecular weights necessary<br />
for plastics applications because of the low<br />
equilibrium constant of lactic acid esterification<br />
and the difficulty of water by-product removal<br />
in the increasingly viscous reaction mixture.<br />
42 bioplastics MAGAZINE [03/13] Vol. 8
PLA Recycling<br />
O<br />
O<br />
OH<br />
OH<br />
HO<br />
HO<br />
(R,R)-lactide<br />
(R) or D-lactic acid<br />
(S) or L-lactic acid<br />
H O O<br />
3<br />
C<br />
H O O<br />
3<br />
C<br />
H O O<br />
3<br />
C<br />
O O<br />
CH 3<br />
O O<br />
(R,S) or meso-lactide<br />
CH O O<br />
3<br />
CH 3<br />
(S,S)-lactide<br />
O<br />
O<br />
Hydrolysis<br />
HO HO (<br />
OH<br />
O<br />
n<br />
OH<br />
Lactic Acid<br />
Purification<br />
Condensation<br />
O<br />
O<br />
O<br />
Lactide<br />
O<br />
Polymerization<br />
Depolymerization<br />
O<br />
Poly (latic acid)<br />
(<br />
Figure 1. Stereochemistry of the lactide monomers<br />
Figure 2 Chemistry of the interconversion between lactic acid,<br />
lactide, and poly(lactic acid),<br />
Today’s industrial processes are based on the ring opening<br />
polymerization of the lactide monomer. First lactic acid is<br />
heated under vacuum in a high surface area-to-volume<br />
process to obtain PLA oligomers with degree of polymerization<br />
between 2 and 25. A metal catalyst is added and the resultant<br />
lactide removed by distillation.<br />
The PLA system has a rich stereochemical architecture<br />
which controls physical and performance properties of the<br />
resultant product – the stereoisomers of lactic acid and<br />
lactide monomers are shown in Figure 1. The percent meso<br />
or D lactide in the L-lactide monomer would affect rate and<br />
percent crystallinity and the eventual polymer properties of<br />
the polymer product.<br />
Reversible Kinetics model approach for PLA<br />
recycling<br />
Current approaches to PLA recycle is to hydrolyze it to<br />
lactic acid, purify it and then reform into lactide which can<br />
then enter into the polymerization step. However, the authors<br />
and their workgroup have shown that the polymerization of<br />
lactide to PLA follows a reversible kinetic model [3]. “They<br />
have used this reversible polymerization to recycle PLA to<br />
lactide monomer using catalytic thermal depolymerization<br />
with success [4]. The chemistry scheme is shown in Figure<br />
2. Proof of concept was established in a laboratory scale setup<br />
with 10-50 gram samples of commercial PLA resin from<br />
NatureWorks. Tin(II) 2-ethylhexanoate catalyst was used.<br />
Melting occurred at 180-185 °C and the depolymerization<br />
reaction started at 185°C.The reaction was carried out under<br />
vacuum in a distillation set-up. The lactide distilled over<br />
driving the reaction forward. The melting point of lactide<br />
is 92-94°C and electric heating tape was used to keep the<br />
lactide in the liquid phase after vapor condensed. A trap<br />
was used to prevent lactide vapor from clogging the vacuum<br />
line. The reaction temperature was kept between 185-210°C<br />
by using an oil bath. Figure 3 shows the laboratory scale<br />
distillation set up with the pale yellow lactide clearly visible in<br />
the receiver flask.<br />
As can be seen from Table 1 the total yield of lactide<br />
was around 94% on a mass basis. Commercial Ingeo<br />
thermoformed cups were obtained from the marketplace,<br />
cut into small squares and added to the reactor vessel, 92%<br />
of lactide was recovered on a mass basis.<br />
The composition and optical purity of the lactide<br />
was established by 1H NMR (Proton Nuclear Magnetic<br />
Resonance) (Figure 4). The resonance peak at 1.7 ppm<br />
corresponded to meso lactide and the resonance peak at 1.65<br />
ppm corresponded to either LL or SS lactide (Figure 4). Due<br />
to the isomeric nature of LL and SS lactide, their resonance<br />
peaks are identical in the 1H NMR spectrum. According this<br />
analysis, the meso content of this product is 9.5%, very close<br />
to the previously reported14 meso content of PLA 3051D (8%).<br />
Since PLA is also blended with other polyesters to<br />
incorporate biobased content, it was important to establish<br />
lactide recovery from such blends. One such blend is a<br />
PLA-PBAT (polybutylene adipate-co-terephthalate) reactive<br />
blend marketed (e.g.) under the BASF trademark of Ecovio ® .<br />
Experiments were run with and without tin oxide catalyst. Table<br />
2 shows lactide recovery from blends with varying amount of<br />
PBAT resin content. The SnO 2<br />
catalyst in the resin did not aid<br />
in depolymerization but was processed with the resin. If was<br />
found that higher amounts of Ecoflex ® (PBAT) in the blended<br />
samples prevented recovery of lactide from PLA. PLA<br />
samples containing 50 wt% of Ecoflex yielded 80% recovery<br />
of available lactide in the samples without resin catalyst and<br />
68% recovery in the samples with resin catalyst. However, the<br />
bioplastics MAGAZINE [03/13] Vol. 8 43
PLA Recycling<br />
1<br />
1<br />
H 3<br />
C<br />
O O<br />
O O<br />
CH 3<br />
D-lactide<br />
1<br />
H 3<br />
C<br />
O<br />
2<br />
O<br />
O<br />
L-lactide<br />
O<br />
CH 3<br />
1<br />
1’<br />
H 3<br />
C<br />
O<br />
2’<br />
O<br />
O<br />
Meso-lactide<br />
O<br />
CH 3<br />
Solvent<br />
1’<br />
1.75 1.70 1.65<br />
2<br />
2’<br />
1.60<br />
1’<br />
Figure 4 Proton NMR of the recovered<br />
lactide from PLA depolymerization<br />
7.0 6.5 6.0 5.5 5.0 4.5 4.0 3.5 3.0 2.5 2.0 1.5 1.0<br />
Chemical Shift (ppm)<br />
recovery of lactide was unaffected when the amount of Ecoflex<br />
was lowered to below 25 wt% in both samples. The addition of<br />
resin SnO 2<br />
catalyst to the blended samples seemed to lower<br />
the recovery of lactide by approximately 10%-15% in blends<br />
with greater than 25% Ecoflex. One possible explanation for<br />
the decreased lactide recovery in blended samples could be<br />
due to the transesterification reaction between PBAT and the<br />
lactide oligomers.<br />
The depolymerization rate of PLA at constant catalyst<br />
concentration is dependent on temperature following the<br />
Arrhenius equation The thermogravimetric analysis of<br />
samples with 0.6% catalyst at different temperatures are<br />
shown in Figure 5. At lower temperatures (160-180), the rate<br />
of the reaction was low. After 60 min, the weight loss was less<br />
than 50%. In contrast, at 210, the depolymerization reaction<br />
resulted in 100% weight loss within only 30 min.<br />
In summary, the authors have shown that PLA polymers<br />
and their blends can be recycled back to lactide in 95% yields<br />
by using a simple catalytic thermal depolymerization process<br />
with lactide recovery by distillation. Kinetic modeling and<br />
engineering parameters development is in progress to scale<br />
to a pilot plant.<br />
[1] Ramani Narayan, Biobased & Biodegradable Polymer Materials:<br />
Rationale, Drivers, and Technology Exemplars; ACS (an<br />
American Chemical Society publication) Symposium Ser. 1114,<br />
Chapter 2, pg 13-31, 2012<br />
[2] Ramani Narayan, Carbon footprint of bioplastics using biocarbon<br />
content analysis and life cycle assessment, MRS (Materials<br />
Research Society) Bulletin, Vol 36 Issue 09, pg. 716 – 721, 201<br />
[3] Witzke, D. R.; Narayan, R.; Kolstad, J. J., Reversible Kinetics and<br />
Thermodynamics of the Homopolymerization of l-Lactide with<br />
2-Ethylhexanoic Acid Tin(II) Salt. Macromolecules 1997, 30 (23),<br />
7075-7085.<br />
[4] Narayan, R.; Wu, W.-m.; Criddle, C. S., Lactide Production from<br />
Thermal Depolymerization of PLA with applications to Production<br />
of PLA or other bioproducts. US Patent 13/421780 3/15/2012<br />
Weight percentage [%]<br />
100<br />
80<br />
60<br />
40<br />
20<br />
0<br />
0 10 20 30 40 50<br />
Time [min]<br />
Thermograms (TGA) of PLA depolymerization at different<br />
temperatures (from bottom to top: 210, 200, 190, 180, 170, and 160)<br />
at 0.6% catalyst concentration.<br />
44 bioplastics MAGAZINE [03/13] Vol. 8
PLA Recycling<br />
Solvent based<br />
PLA recycling<br />
Fig. 2: no colour changes<br />
by<br />
Nathalie Widmann, Tanja Siebert, Andreas Mäurer,<br />
Martin Schlummer / Fraunhofer IVV<br />
Felix Ecker / University of Applied Sciences Fulda<br />
In many cases waste containing PLA is currently sorted out<br />
as an impurity during the disposal of plastic materials, since<br />
low PLA amounts do not yet justify recycling activities. Instead<br />
PLA, separated from post-consumer waste, is finally<br />
processed into refuse-derived fuel or in waste incineration.<br />
With the increasing quantities in recent years the necessity<br />
also increases to establish efficient recycling systems for<br />
PLA and generate high-quality recyclates guaranteeing<br />
a good resource-efficiency. However, recycling of PLA is<br />
challenging since in packaging materials PLA is often used<br />
as a composite or blend. The main issues are therefore the<br />
separation of pure PLA fractions from post-consumer waste<br />
and the preservation of its mechanical properties in order to<br />
obtain a high-quality recyclate. These issues have not been<br />
solved by mechanical state-of-the-art recycling technologies.<br />
The solvent-based CreaSolv ® process was developed by the<br />
Fraunhofer Institute for Process Engineering and Packaging<br />
IVV in Freising, Germany, in cooperation with the CreaCycle<br />
GmbH in Grevenbroich, Germany (owner of the trademark).<br />
It represents a future-oriented alternative for the recycling<br />
of PLA. The process has been developed for conventional<br />
thermoplastics (e.g. PET, ABS, PA, PP, PE and PS) and<br />
generates pure and high-quality polymer recyclates from<br />
contaminated and heterogeneous waste.<br />
The process can be divided into four main steps including<br />
solution, cleaning, precipitation (the formation of a solid<br />
in a solution during a chemical reaction) and drying of the<br />
polymer (Fig. 1).<br />
The CreaSolv formulations used are selective for the<br />
respective plastic and non hazardous. Furthermore the<br />
process involves precipitation stages for soluble contaminants<br />
like degradation products, oligomers or undesired additives.<br />
It returns a solution of purified macromolecules where the<br />
size and molecular weight were found to comply with virgin<br />
material.<br />
The major advantage of the CreaSolv process over<br />
established mechanical recycling processes is the ability to<br />
separate effectively both undissolved foreign polymers and<br />
non-plastic materials from the dissolved target plastics.<br />
It is therefore particularly suitable for mixed waste and<br />
composites.<br />
Initial studies on a laboratory scale with PLA allow first<br />
statements about solvent selection and selectivity. The PLA<br />
solvent was applied to other typical packaging materials (PE,<br />
PP, PET and PS) and was confirmed to be selective for PLA.<br />
First results show that the molecular weight of PLA can be<br />
maintained by specific process control during the dissolution,<br />
precipitation and drying stages. Also colour changes of the<br />
PLA can be avoided by certain conditions (Fig. 2).<br />
Currently, results from laboratory scale experiments are<br />
being transferred onto the small scale technical line at the<br />
pilot plant of the Fraunhofer Institute in Freising.<br />
www.ivv.fraunhofer.de<br />
www.creacycle.de<br />
solvent refining<br />
waste solution purification precipitation drying product<br />
impurities,<br />
contaminants<br />
Fig. 1: CreaSolv process (Source CreaCycle)<br />
bioplastics MAGAZINE [03/13] Vol. 8 45
PLA Recycling<br />
PLA recycling<br />
with degassing<br />
The Institute of Plastic Processing (IKV) evaluates the recycling<br />
behaviour of PLA. Recycling helps cut raw material<br />
consumption and lowers material costs. Additionally, it<br />
improves the ecological balance. The different industrially practiced<br />
recycling strategies are analysed. A review is given about<br />
the processing by means of melt degassing.<br />
With the biggest production capacities of all bioplastics<br />
Polylactide (PLA) is a promising bio-plastic. However, although<br />
many raw material suppliers are starting production lines, the<br />
amount of commercially available PLA is still limited [1].<br />
The end-of-life scenario for PLA has rarely been analysed, yet.<br />
Mechanical recycling is a reasonable option, but not well known<br />
in industry. The aim of this research project is the analysis of the<br />
material and process behaviour during mechanical recycling.<br />
This knowledge helps converters to improve their production.<br />
Production costs and raw material input are reduced. Four<br />
research institutes are analysing the recycling of internal PLA<br />
waste. Within the project the Flanders’ PlasticVision (Kortrijk,<br />
Belgium) analyses injection moulding while the Institute of<br />
Plastics Processing (IKV) focusses on the extrusion process. The<br />
chemical analysis of the recycled material and the development<br />
of biological chain extenders are done by the Fraunhofer<br />
Institute for Structural Durability and System Reliability (LBF),<br />
in Darmstadt, Germany. Celabor (Herve, Belgium) characterizes<br />
the physical properties of the recycled products and does a Life<br />
Cycle Analysis of the different recycling options.<br />
In the flat film extrusion process production waste arises<br />
mainly from the side cuts. In the thermoforming process punch<br />
scrap is produced. Both accounts for almost 40 % of the used<br />
raw material. The thermoplastic waste can be melted and reprocessed<br />
into a new product. But like every thermoplastic<br />
material PLA is exposed to degradation. The hydrolytical<br />
degradation is crucial for the processing of PLA. To achieve a<br />
sufficient quality certain production steps have to be followed<br />
during recycling, e.g. to avoid hydrolytical degradation PLA has<br />
to be dried [2].<br />
The material handling of PLA is important. Figure 1 shows<br />
the moisture absorption of r-PLA under real storage conditions.<br />
After a very strong increase in the beginning the moisture<br />
reaches the saturation level at given humidity and temperature.<br />
If moisture is present during the plasticization, hydrolysis<br />
leads to a very fast degradation. This results in a decrease of the<br />
average chain length, which can be described by the molecular<br />
weight. A low molecular weight induces insufficient product<br />
properties, e.g. bad mechanical properties and low chemical<br />
resistance. Furthermore, the extrusion process is affected.<br />
A low molecular weight is followed by a low viscosity and an<br />
unstable process. In extreme cases, the process collapses. To<br />
prevent hydrolysis an expensive, time and energy consuming<br />
pre-drying step has to be conducted. An alternative is the<br />
processing by means of a degassing extruder. The degassing<br />
allows processing of moist material. By applying a vacuum the<br />
moisture is removed during the process and pre-drying is not<br />
necessary anymore. Previous analyses have shown that nearly<br />
30 % energy can be saved by using a degassing extruder [3].<br />
Extrusion experiments are done with the IKV equipment<br />
on a 60 mm single screw degassing extruder (L=38 D) and a<br />
calandar stack. The degassing zone can be closed. In that<br />
case the extruder operates as normal extruder. The extrusion<br />
line is equipped with a melt pump and a 900 mm flat film<br />
die. Additionally, a bypass-rheometer is implemented. Films<br />
produced from virgin PLA are used for recycling. A shred mill<br />
processes these films to flakes which are subsequently used<br />
as r-PLA.<br />
Figure 2 shows the melt viscosity depending on the shear rate<br />
measured with the bypass-rheometer. It correlates directly with<br />
the molecular weight and therefore with the quality of the film.<br />
Virgin PLA is processed with a moisture content of less than<br />
250 ppm and without melt degassing. The artificially moistened<br />
r-PLA is processed with the specified moisture content.<br />
As shown in Figure 2 the melt viscosity drops with increasing<br />
PLA moisture. The higher the moisture the stronger is the<br />
hydrolysis. At 3200 ppm the viscosity drop is very high. As a result<br />
the melt stability is very low and the production of film is not<br />
possible anymore. The very strong viscosity drop at low shear<br />
rates is a result of the longer dwell times at low shear rates in the<br />
rheometer. This shows the very fast reactivity of the hydrolysis.<br />
By degassing the polymer melt its moisture is removed during<br />
processing. The hydrolytical degradation is lessened. At 750<br />
ppm the viscosity is comparable to the viscosity of virgin PLA.<br />
The quality loss is marginal. The degassing of the r-PLA with<br />
moisture of 3200 ppm leads not to a sufficient viscosity. One<br />
reason is that the capacity of the degassing system is limited.<br />
Another reason is that the polymer has to be plasticized before<br />
the degassing takes place. Between plasticization and actual<br />
degassing, hydrolysis has already started to degrade the<br />
polymer chains. At high moisture rates the degradation is too<br />
heavy. Hence, the degassing effect is limited.<br />
46 bioplastics MAGAZINE [03/13] Vol. 8
PLA Recycling<br />
by<br />
Ch. Hopmann<br />
S. Schippers<br />
Institute of Plastics Processing (IKV) at<br />
RWTH Aachen University<br />
Aachen, Germany<br />
The results of the viscosity are confirmed by<br />
measurements of the molecular weight of the produced<br />
film in Figure 3.<br />
The higher the moisture content, the lower is the<br />
molecular weight. This results from the hydrolysis. By using<br />
degassing the molecular weight loss can be reduced. The<br />
molecular weight of the 750 ppm r-PLA is nearly as high<br />
as the molecular weight of the film made from virgin PLA.<br />
Overall, the molecular weight is more stable compared to<br />
the viscosity. The trends are the same but the effect on the<br />
molecular weight is minor. Apart from the r-PLA with very<br />
high moisture content (3200 ppm) the achieved viscosity and<br />
the molecular weight are comparable to the values of virgin<br />
PLA. The molecular weight loss is little.<br />
Conclusion<br />
The material handling of PLA is important for the<br />
production process and for the later product quality.<br />
PLA shows a strong hygroscopic behaviour. To avoid the<br />
expensive pre-drying step the production using melt<br />
degassing is recommended. Hydrolysis of the PLA can be<br />
reduced as long as the moisture content does not exceed<br />
2000 ppm. At a moisture content higher than 3200 ppm<br />
the process and product quality is affected even though<br />
degassing is used. In that case a pre-drying step has to be<br />
conducted or a degassing system with a higher capacity has<br />
to be implemented.<br />
Acknowledgment<br />
The research project 44EN of the Forschungsvereinigung<br />
Kunststoffverarbeitung has been sponsored as part of the<br />
Collective Research Networking (Cornet) by the German<br />
German Federal Ministry of Economics and Technology<br />
(BMWi) due to an enactment of the German Parliament<br />
through the AiF. We would like to extend our thanks to all<br />
organizations mentioned.<br />
www.ikv-aachen.de<br />
[1] Auras, R.; Lim, L.T.; Selke, S.E.M.; Tsuji, H.: Poly Lactic Acid -<br />
Synthesis, Structures, Properties, Processing, and Application.<br />
Hoboken, New Jersey, USA: John Wiley & Sons Inc., 2010<br />
[2] Brandrup, J.: Recycling and Recovery of Plastics. München,<br />
Wien: Carl Hanser Publishing, 1996<br />
[3] Schmitz, T.: Verarbeitung von PET auf einem<br />
Einschneckenextruder mit Trichter-und Schmelzeentgasung.<br />
RWTH Aachen, Dissertation, 2005<br />
PLA moisture [ppm]<br />
4400 55<br />
4000 50<br />
3600 45<br />
3200 40<br />
2800 35<br />
2400 30<br />
2000 25<br />
1600 20<br />
1200 15<br />
800 10<br />
400 5<br />
0 0<br />
0 7 14 21 28<br />
time [days]<br />
PLA moisture [ppm] enviromental humidity [%] temperature [°C]<br />
Figure 1. Moisture absorption under storage conditions<br />
1000<br />
viscosity [Pas]<br />
virgin PLA<br />
moisture degassing<br />
750 ppm no<br />
750 ppm yes<br />
3200 ppm no<br />
3200 ppm yes<br />
100<br />
1 10 100 1000<br />
shear rate [s -1 ]<br />
Figure 2. Melt viscosity with and without degassing<br />
weight average molecular<br />
weight [kg/mol]<br />
250<br />
200<br />
150<br />
100<br />
50<br />
0<br />
Moisture [ppm] virgin 750 750 3200 3200<br />
degassing no yes no yes<br />
Figure 3. Molecular weight with and without degassing<br />
enviromental humidity / temperature<br />
bioplastics MAGAZINE [03/13] Vol. 8 47
PLA Recycling<br />
Mechanical<br />
PLA recycling<br />
by<br />
Steve Dejonghe<br />
Looplife Polymers<br />
Hulshout, Belgium<br />
When PLA was firstly introduced, the main proposal<br />
was a shift from fossil resources to renewable<br />
ones. But the remarkable versatility of the material<br />
also opened new recycling perspectives, further enhancing<br />
its environmental profile.<br />
Several complementary end-of-life options are therefore<br />
possible (ranging from composting to chemical recycling),<br />
the most appropriate recycling channel being ultimately<br />
determined by the nature of PLA waste.<br />
While growing steadily, bioplastics currently account for<br />
a marginal share of the global plastic production. Despite<br />
the emergence of small PLA post-consumer streams,<br />
field experience reveals the difficulties to properly identify<br />
recycling channels and shows the challenges to connect<br />
streams and potential recycling units.<br />
Mid-2000’s, Galactic, a leading actor of the green<br />
chemistry, started the first PLA recycling projects in Belgium.<br />
Partnering with international key stakeholders, the company<br />
was able to build an extensive know-how while acquiring a<br />
concrete market experience over the last few years.<br />
But to allow further industrial development, Galactic<br />
decided end of 2012 to transfer its PLA recycling projects to<br />
third parties.<br />
The mechanical recycling department has been recently<br />
acquired by Devetex, a company active since 1995 in the<br />
recycling of off-spec material issued from the textile industry<br />
(namely PA66 and PP). As post-consumer streams grew, a<br />
dedicated line was also installed in 2005 to handle soiled<br />
carpet waste.<br />
All know-how and experience acquired by Galactic and<br />
Devetex are now combined in one company, LoopLife<br />
Polymers, located in Hulshout (Belgium).<br />
LoopLife Polymers intends to support market demand for<br />
rPLA by proposing a tangible industrial recycling solution for<br />
various compatible waste streams, either post-industrial or<br />
post-consumer. For this purpose, the company continues<br />
to develop national and international partnerships and is<br />
setting a first demo-plant for PLA post-consumer streams<br />
(e.g. PLA cups). The philosophy is to turn less established<br />
waste streams into useful raw material.<br />
LoopLife Polymers and NatureWorks are collaborating<br />
to map out regular streams of post-industrial and postconsumer<br />
waste which can be considered for mechanical<br />
recycling. An effective system to valorize waste is an essential<br />
part of the biopolymer value chain optimization.<br />
For compatible waste streams, mechanical recycling<br />
remains a highly interesting option. With an adequate control<br />
of the process, thermal degradation is kept to a minimum<br />
and the resulting r-PLA still shows adequate mechanical<br />
and thermal properties for a wide range of applications. It<br />
also combines the advantages of being both bio-based and<br />
recycled, with expected benefits in Life Cycle Assessment<br />
studies. Furthermore, LoopLife’s recycling process is<br />
optimized to lessen environmental impacts.<br />
LoopLife Polymers can therefore be a partner;<br />
• as an output channel for various PLA waste streams (either<br />
Post-industrial, Post-consumer or closed-loop events),<br />
with no volume restrictions of compatible streams<br />
• as a supplier of several high-quality r-PLA grades with<br />
constant specifications<br />
Such grades are especially interesting for cost-sensitive<br />
applications where prime PLA cannot be considered, helping<br />
therefore to broaden the use of PLA. These r-PLA grades<br />
are well suited for less-demanding, non-food applications.<br />
At term, tailor-made grades could be developed to meet<br />
specific customer’s requests.<br />
www.looplife-polymers.eu<br />
48 bioplastics MAGAZINE [03/13] Vol. 8
PLA Recycling<br />
Supporting<br />
ecological advantages<br />
A<br />
division of Starlinger & Co GmbH (Vienna, Austria),<br />
world market leader in the field of machinery and<br />
complete lines for woven plastic packaging production,<br />
Starlinger recycling technology provides machinery<br />
solutions for the recycling and refining of a wide<br />
scope of plastics such as PE, PP, PLA, PA, PS, BOPP and<br />
PET. Starlinger recycling technology has focused on production<br />
waste: although companies emphasize the concept<br />
of zero-waste, production waste cannot be avoided<br />
completely. Mechanical recycling is the answer as use of<br />
rPLA can be up to 100 %.<br />
Decisive for the quality of the end product:<br />
Input material and recycling process<br />
PLA is now used in many applications, such as film<br />
for packaging, containers for juices, filaments for fabric,<br />
etc. New technologies allow the recycling of PLA in a way<br />
that high-quality re-granulate becomes a cost-saving<br />
alternative to virgin resin. To ensure the production of<br />
high value regranulate – which is the requirement for<br />
improving cost efficiency and stability of the production<br />
process – an analysis of the input material and the right<br />
choice of equipment is paramount. Starlinger recycling<br />
technology offers two suitable systems for the recycling<br />
of PLA production scrap: recoSTAR basic and recoSTAR<br />
universal.<br />
Technology principles<br />
The recostar basic uses an agglomerator for cutting<br />
the material by means of knives on a rotating disc at<br />
the bottom, suitable for film and pre-cut material. This<br />
frictional process heats and dries the mixed material,<br />
densifies it and brings it close to the melting point before<br />
it is fed into the extruder. Six extruder sizes from 150 –<br />
2,200 kg/h are available.<br />
Equipped with a heavy-duty single-shaft cutter arranged<br />
parallel to the extruder, the recostar universal enables<br />
also the processing of film and additionally of hard-togrind<br />
materials such as containers, fibres and start-up<br />
lumps. The hydraulic pusher in the single shaft cutter<br />
presses the material against a water-cooled rotating<br />
shaft and thus provides efficient crushing. The new<br />
feeding system into the extruder accounts for increased<br />
operational reliability, simplified operation, and lower<br />
energy consumption and higher output at the same time.<br />
Five extruder sizes from 150 – 1,300kg/h are available.<br />
Vacuum treatment, fine filtration and<br />
pelletising<br />
It’s all in the melt: To ensure high-quality regranulate<br />
although PLA is hygroscopic, both recycling systems can<br />
be equipped with an extruder vacuum unit in order to<br />
extract volatile contaminants and reduce viscosity loss<br />
in the melt. A variety of melt filtration systems ensure<br />
clean, high-grade melt: melt filters with and without<br />
backflushing, and power backflush filters are the most<br />
common. The choice of filter type and size depends on<br />
the type and amount of contaminants (e.g. paper) and<br />
required fineness (50 µm positively tested). Customers<br />
can choose water ring pelletizing, manual and automatic<br />
strand pelletising or underwater pelletising. MT<br />
www.recycling.starlinger.com<br />
bioplastics MAGAZINE [03/13] Vol. 8 49
PLA Recycling<br />
Linear polymer<br />
Better-than-virgin<br />
recycled PLA<br />
Chain extended polymer<br />
(PLA + chain extender by reactive extrusion)<br />
Ex: CESA-Extend, Joncryl, other epoxides<br />
Hyperbranched PLA<br />
(PLA + IFS Proprietary Chemistry by Reactive<br />
Extrusion)<br />
Top: PLA extrudate from a cast film process at 180°C,<br />
bottom: hyperbranched PLA,<br />
Interfacial Solutions LLC (River Falls, Wisconsin, USA) has<br />
developed proprietary processing technology that converts<br />
scrap PLA, possessing inferior properties, into a recycled<br />
PLA resin with properties that exceed those of virgin PLA.<br />
To do so, Interfacial Solutions utilizes a novel reactive extrusion<br />
process and chemistry to hyperbranch PLA polymer<br />
within a continuous extrusion process. Interfacial Solutions<br />
has shown that hyperbranching dramatically increases the<br />
molecular weight of the polymer while simultaneously creating<br />
many random branching sites along the backbone of<br />
PLA, creating a unique rheology during melt processing. The<br />
result is an improved PLA resin with superior melt strength<br />
and mechanical properties to virgin PLA. The hyperbranched<br />
recycled PLA resins are particularly suited for profile extrusion<br />
applications in durables markets.<br />
PLA itself is a linear polymer with low melt viscosity, and<br />
