cpp – Process technology for the chemical industry 03.2020

03-2020

22 TITEL

DATA – THE NEW OIL?

8 TWIN SCREW PUMPS

HYGIENIC DESIGN

PERFECTLY EXECUTED

30 MAINTENANCE

HOW DUMB COMPONENTS

LEARN TO TALK

48 DRY VACUUM

NOTES FOR THE USE OF

SCREW VACUUM PUMPS

PROCESS TECHNOLOGY FOR THE CHEMICAL INDUSTRY

WWW.CPP-NET.COM

TABLETING TOOLS

EFFICIENCY FOR TABLET MANUFACTURING

+ Long dwell times

+ Continuously high, efficient productivity

+ Application-specific solutions

+ Highest quality in every tablet

www.fette-compacting.com

A member of

Ideal for the production

of homogeneous mixtures

with high solids content

An autumn without

Powtech

Powtech was the original plan. Then came Powtech Special Edition.

And now the exhibition has been cancelled altogether owing to co -

ronavirus. This late decision by the Nuremberg organiser was taken

in response to the concerns of numerous exhibitors and trade visitors

regarding on-site events. It was also not at all clear whether, as

the number of cases continues to rise, enough visitors would actually

be willing to travel to Bavaria’s second biggest city. Against

this background, the cancellation was definitely the right move. In

the present tense economic situation, who needs a Powtech that

could well end in a fiasco? Powtech may no longer be taking place

now, yet companies who were looking forward to exhibiting in

Nuremberg can nevertheless make their voice heard in this issue.

The relevant articles are combined in a special section on “Powder

and bulk solids processing” starting on page 32.

Our cover story on page 22 is all about Plantsight. This solution was

jointly developed by Siemens and Bentley Systems with the specific

requirements of the process industry in mind. Plantsight makes it

possible to collect, connect, contextualise, validate and make use of

all existing plant data. The solution transforms raw data into one

complete digital twin that is continuously updated.

A visit to Wangen Pumpen which was planned for June unfortunately

also had to be called off due to the coronavirus pandemic. However,

thanks to modern telecommunications, I was able to conduct the

interview with application engineer Klaus Renzelmann by telephone

instead. In the article on page 8, he explains how his firm has so far

managed to navigate the turbulence of the coronavirus era. In addition

to this, he introduces the twin screw pumps in the Twin NG series and

reveals why MX pumps are the icing on the cake of Wangen Pumpen’s

portfolio. I hope you enjoy reading this issue. Stay well!

XPP

/// Compact & extremely

efficient mixing and

dispersing plant

IKA-Werke GmbH & Co. KG

Phone: +49 7633 831-0

eMail: process@ika.de

www.ikaprocess.com // IKAworldwide

Lukas Lehmann, Assistant Editor-in-Chief

cpp 03-2020 3

cpp CONTENTS 03-2020

22 Cover In Plantsight

from Siemens, real

and virtual worlds can be

brought into harmony

through an all-encompassing

digital twin

platform.

8 In an interview with

cpp, Klaus Renzelmann

presents the Twin NG

series of twin screw

pumps. He also reveals

why the MX pumps are

the icing on the cake of

the Pumpenfabrik

Wangen product range.

30 With the batterypowered

edge computer

the size of a field ice

hockey puck many dumb

plant components learn

to talk.

PHARMACEUTICAL TECHNOLOGY

8 Hygienic design perfectly executed

Twin screw pumps and progressing cavity pumps

from Wangen

13 Flexible cobot gripper handles cosmetics

Powerful solution for collaborative robots

34 Powder processing for additive manufacturing

Use of a 3-in-1 conical mix-dryer and reactor provides

advantages

36 PRODUCTS

38 For clean bags and pallets

Optical measuring system detects irregularities on

bag valves

INSTRUMENTATION, CONTROL, AUTOMATION

20 Pitfalls and opportunities in the selection of HMIs

Seeing the bigger picture

22 COVER Data – the new oil?

Added value in process industries

26 Functional safety in the petrochemical industry

Oil – Gas – SIL 3

28 Radar sensor monitors filling level in storage silo

Use in paint production

30 How dumb components learn to talk

Condition-based maintenance of mechanical

components

FOCUS: POWDER AND BULK SOLIDS PROCESSING

32 Tablet press field test

Pharmaceutical manufacturer puts efficiency to the test

PLANTS, APPARATUS, COMPONENTS

40 New installation during operation

Fully automated filling technology for a large

storage facility

42 How to solve the most frequent issues

Overcoming common process sampling system

challenges

44 Digitisation in the field of explosion safety

Central monitoring and control with the safety

software iQ Safety Cockpit

46 Choosing the right blower

Rotary lobe, rotary screw or turbo

48 Notes for the use of screw vacuum pumps

Dry vacuum technology for chemical and

pharmaceutical processes

50 Added value at all levels

Supervision and control system for valve actuators

4 cpp 03-2020

46 Rotary piston, screw

and turbo blowers – the

variety of machines for

the production of compressed

air is large. It

pays off to have a comprehensive

demand

analysis to select the right

blowers.

50 The Sima² Master

station guarantees highest

plant availability, thanks

to reliable and efficient

communication via stand -

ardised fieldbus protocols,

comprehensive redundancy

options, and a multitude of

diagnostics.

COLUMNS

3 Editorial

4 Contents

6 News

15 PRODUCTS

52 List of Advertisers

52 Contact to the Editors

52 Imprint

WWW.CPP-NET.COM

More news, facts, products and

solutions for the process technology

in the chemical industry can be found

on our internet page!

www.cpp-net.com


cpp

NEWS

FORTY YEARS OF GRANULATION OF CHEMICALS

MILESTONE FOR IPCO’S ROTOFORM SYSTEM

Continuous development of Ipco Rotoform

granulation technology from 1980 to 2020

Picture: Ipco

Chemical processing and handling equipment

manufacturer Ipco is celebrating 40

years’ continuous production of its Rotoform

granulation system.

The development of this rotary dropforming

technology in 1980 brought new levels

of quality and productivity to the market

and changed the face of chemical granulation.

A premium quality formed product –

one with consistent specifications – enables

safer, easier handling during storage and

transportation. Such is the quality and reliability

of granulation delivered by Rotoform

that it has gone on to sell more than 2000

systems to date.

“We had been supplying flaking systems

since the early 1950s,” says Johan Sjögren,

Managing Director of Ipco’s Equipment

division,“and our ranges now encompass

storage and handling solutions too, but the

introduction of Rotoform was a defining

moment in our company’s history. It put us

on the map in this respect and the system

remains the market leader to this day.”

While the core principle – direct-from-themelt

solidification on a steel belt cooler –

remains unchanged, Rotoform technology

has undergone significant advances over the

years. In 2013 the company introduced the

4G (4th Generation) Rotoform, the foundation

of an entire family of models designed

to meet specific process requirements.

These include the granulation of

abrasive and sedimenting materials (e.g.

catalysts and suspensions), melts requiring a

high feed temperature (e.g. bitumen, resins),

the pastillation of subcooling melts in

supercooling plants (e.g. photo chemicals)

and the handling of high viscosity products

(e.g. chocolate, hot melts and resin).

With pioneering spirit passion

130 YEARS OF PFEIFFER VACUUM

Corporate building of Pfeiffer Vacuum

Pfeiffer Vacuum has been setting standards

in vacuum technology for 130 years.

Science and industry have benefited equally

from the numerous innovations developed

and successfully brought to the market by

Picture: Pfeiffer Vacuum

this long-established company. The best

example of this is the turbomolecular

pump, which was developed by the company

in 1958 and has been indispensable in

the market ever since. Thanks to its expertise,

Pfeiffer Vacuum is still the world market

and technology leader in this field.

The vacuum specialist has been characterised

by its pioneering spirit and passion

from the very beginning. When Arthur

Pfeiffer founded the company in Wetzlar,

Germany, in 1890, he initially devoted his

attention to the production of remote ignition

systems for gas lamps. Once electric

light bulbs had established themselves on

the market, the company founder quickly

turned his attention to the new lighting

technology that led him to look at the vacuum

technology used in its production.

Arthur Pfeiffer quickly recognized the

significance that vacuum technology could

have in practically all areas of industry and

research – and he subsequently concentrated

entirely on this field.

Today, Pfeiffer Vacuum products still stand

for high-tech solutions with excellent reliability

and efficient performance. Customers

such as the Max Planck Institute, CERN,

XFEL and EADS are proof of this reliability –

vacuum pumps made by the Asslar-based

manufacturer are even in use in the ISS

space station.

CLARIANT DOUBLES THE

DEVELOPMENT CAPACITY

Sample preparation with a high-throughput

robot in Clariant Catalysts’ expanded

research center in Palo Alto, California

Clariant Catalysts is picking up speed

with the successful expansion of its highthroughput

R&D center in Palo Alto, California.

Thanks to a significant investment,

the upgraded facility is fitted with

the latest high-throughput equipment,

and will be home to an expanded team

of technical experts. By doubling the research

and development capacity of its

Palo Alto facility, the company greatly

strengthens its ability to offer faster and

better solutions to its customers, and to

support partners with custom catalyst

scale-up projects. High-throughput R&D

combines state-of-the art hardware, robotics,

automated procedures, and

specialised software to enable up to 100

times faster experimentation compared

to traditional practices.

Picture: Clariant


Strategic partnership

THYSSENKRUPP AND AIR PRODUCTS COOPERATE ON GREEN HYDROGEN

Picture: Thyssenkrupp

Thyssenkrupp has developed high-efficiency

alkaline water electrolysis technology

The industrial gases group Air Products

and the electrolysis plant manufacturer

Thyssenkrupp Uhde Chlorine Engineers

have announced the signing of a strategic

cooperation agreement. The two companies

will collaborate exclusively in key regions,

using their complementary technology, engineering

and project execution strengths to

develop projects supplying green hydrogen.

Thyssenkrupp will deliver its technology

and supply specific engineering, equipment

and technical services for water electrolysis

plants to be built, owned and operated by

Air Products. The collaboration leverages

Thyssenkrupp’s technology supporting Air

Products’ development of green hydrogen

as an energy carrier for sustainable trans-

portation, chemicals and power generation.

„We are proud to cooperate with Air Products

in making value chains for fuels,

chemicals, and industry feedstocks sustainable.

Large-scale electrolysis is the key technology

to connect renewable power to the

different sectors of mobility and industry. As

a world market leader in electrolysis we

bring in both: technology and production

capacity at scale. Already today, we are set to

supply one gigawatt for water electrolysis

plants per year, and we are prepared to

ramp up the capacity in this rapidly evolving

market,“ said Denis Krude, CEO at

Thyssenkrupp Uhde Chlorine Engineers.

Relocation of production to Poland

GEA INVESTS EUR 30 MILLION IN SITE EXPANSION

Picture: GEA

GEA advances the optimisation of its production

network and invests in site expansion

in Poland

The plant manufacturer GEA decided on strategic guidelines and significant

investments to further optimise its production network. In this context, pro -

duction at the Bodenheim site near Mainz will be discontinued by the end of

2024. The plant in Koszalin, Poland, will be expanded into a center of competence

for pump production and comprehensive machining. GEA will invest around EUR

30 million in this expansion. Investments and a further consolidation of production

and process activities are planned at other locations, too. The aim is to further

strengthen GEA’s global production network in order to increase productivity and

reduce its cost base.

Investments and a further consolidation of production and process activities are

planned at other locations, too. The aim is to further strengthen GEA’s global

production network in order to increase productivity and reduce its cost base.

cpp NEWS TICKER

Namur Annual Conference

China postponed to 2021

Porotec becomes part of

Verder Scientific

Picture: Verder Scientific

Picture: Evonik

Evonik‘s new chief

innovation officer

Andreas Fischer has been named

Bild: Bauer Gear Motor

Change in management

Bauer Gear Motor has appointed

Nader Halmuschi as its new ma-

The planned Namur Annual

Conference with the motto “Enhanced

Connectivity for Smart

Production“ which is sponsored

by Phoenix Contact was intensively

prepared by Namur China

core team and Phoenix Contact

The Verder Group has acquired

Evonik‘s new chief innovation of-

naging director to take the reins

local team. Due to the current

the German company Porotec

ficer, effective July 1. He takes

as Karl-Peter Simon announces

global situation of Covid-19, the

GmbH, thus further expanding its

over from Ulrich Küsthardt, who

his intention to retire. Bauer Gear

Namur Annual Conference China

particle characterisation busi-

has held this position since 2015

Motor, which is part of Altra In-

will be postponed by one year.

ness. Porotec operates success-

and is now taking early retire-

dustrial Motion Corp., has used

Namur and Phoenix Contact will

fully as a dealer for Microtrac

ment. Fischer plans to further

the last few months to plan the

continue the close cooperation

MRB, a company under the roof

strengthen the link between in-

management succession and ap-

and prepare for the conference

of the Verder Scientific Division

novative capability and customer

point a replacement who has the

for August 2021.

also specialised in particle char-

focus, and make it an unmistak-

experience and technical knowl-

acterisation.

able hallmark of Evonik.

edge required for the position.




Pictures: Pumpenfabrik Wangen

Klaus Renzelmann works in the application technology team at Pumpenfabrik Wangen, where he is also responsible for the Twin NG and

MX ranges of hygienic pumps

Twin screw pumps and progressing cavity pumps from Wangen

Hygienic design

perfectly executed

In an interview with cpp, Klaus Renzelmann presents the Twin NG series of

twin screw pumps. The application engineer also reveals why the MX

pumps are the icing on the cake of the Pumpenfabrik Wangen product

range. And he reports on record months during the coronavirus crisis.

Mr. Renzelmann, how badly did the coronavirus crisis hit

Pumpenfabrik Wangen?

Klaus Renzelmann: Actually, we did really well throughout the first

half of the year. March, April and May were real record months for us.

We do not know how the situation will continue as the corona virus

will tend to have more and more of an impact on new projects.

Let us now talk about the Twin range of twin screw pumps. Since

when have the pumps been part of your company’s product range?

Renzelmann: We initially launched the Twin pumps at Anuga Foodtec

2012, but only sizes 104 and 130 back then. Since then, the

pumps have been used in a wide variety of different sectors. Our

engineers continued to gradually develop the pumps based on the

experience we gained there. The Twin NG series of twin screw

pumps is the result of this continuous development work, and this

year we will replace its predecessor, the Twin range.

How do Twin NG pumps differ from the previous models?

Renzelmann: Through their significantly improved ease of service.

This starts with the handles on the pumps, which make the removal

of the pump housing more convenient. Then the seals now have a

cartridge design, which makes it considerably easier to replace the

seal. A self-centering flange housing also ensures alignment of the

coupling after service work. And, last but not least, the Twin NG

pumps are equipped with Fast-X-Change technology.

What is behind this technology?

Renzelmann: It is a process for automatic synchronisation of the

spindles. During installation or maintenance of the pump, the screw

spindles simply need to be attached without the need for re-synchronisation.

Fast-X-Change makes changing the spindle unbelievably

easy, saves valuable time, avoids sources of error, and ultimately

simplifies the adjustment of the pump to the media to be pumped.


An important point to stress at this point: we have significantly increased

the variety of different spindles with the Twin NG pumps.

Does the operator need to remove the pump when changing the

spindle?

Renzelmann: No. The pump housing, complete with all its connections,

can remain in the system. The pump simply needs to be

opened and the old spindles replaced by new ones.

What about the robustness of the pumps?

Renzelmann: Once again here, the Twin NG pumps have much to

offer. For instance, particularly under harsh operating conditions,

shaft protection sleeves ensure that the shafts do not run into the

radial shaft seals as easily, and hence also prevent oil losses. More -

over, the couplings have a ledge, which prevents them from hitting

the housing should they become loose.

What sizes of pump are available?

Renzelmann: They are available in sizes 70, 104, 130 and 180. The

smallest pump, the Twin NG 70, has a pump capacity of 25 m 3 /h.

This figure rises to 200 m 3 /h with the largest pump, the Twin NG

180. The pump capacities are based on media with a viscosity of

1 mPas. The pumps can be used for media with a viscosity of up to

1,000,000 mPas.

Please give us a few examples of products that can be used with

the pump.

Renzelmann: The products range from low-viscosity products, such

as alcohol, juices, cleaning agents and water, to liquid sugar, soups,

mayonnaise and fruit preparations, and even high-viscosity pulps,

tomato purée, dough or sausage meat. It is important that the same

pump can be used to pump low- and high-viscosity products. This

means that Twin NG pumps can be used as product pumps and also

as CIP pumps. Customers save the cost of a separate centrifugal

pump, bypass lines, valves and measuring technology etc.

„The MX pumps are the icing on the cake.

They round off the top of our range of pro -

gressing cavity pumps in terms of hygiene

and pumping precision.“

In which materials are Twin NG pumps available?

Renzelmann: Wetted components are generally made of higherquality

stainless steel. However, we can also supply a galvanised or

coated grey cast iron bearing housing, with all wetted components

continuing to be made of stainless steel.

What qualities of stainless steel are used?

Renzelmann: We manufacture, as standard, in stainless steel 4404

or 4408. Special materials, such as Duplex or Hastelloy, are available

on request.

What hygienic standards or guidelines do the pumps meet?

Renzelmann: We are permitted to use the 3-A label and EHEDG for

the Twin NG 70, Twin NG104 and Twin NG 130 pumps. All four

sizes also achieve excellent values with CIP and SIP cleaning. Thanks

The Twin NG twin screw pump stands out on account of its ease

of service

to their ease of disassembly the pumps can also be manually cleaned

very easily – a factor that becomes increasingly important if the

pumps cannot be process-reliably cleaned by CIP.

In what sectors are the pumps used?

Renzelmann: The food industry is the major customer. The pumps

are also used in the chemical industry, especially in areas where

large volumes of product need to be pumped and where the ability

to clean the pump is crucial. I am thinking here about the production

of paints and coatings.

And what about the pharmaceutical industry?

Renzelmann: These pumps are rarely used in that sector. However,

this industry is one of the main customers of our MX range of progressing

cavity pumps.

That was a very elegant link to the second part of our interview in

which I would like to talk to you about MX progressing cavity

pumps. How do these pumps differ from your company’s other

progressing cavity pumps?

Renzelmann: We took over these pumps from Knoll. They ideally

complete the top of our range of hygienic progressing cavity

pumps – they are essentially the icing on the cake. These totally hygienic

pumps are designed for applications in which very high

pressures need to be generated in a few steps and where pumping

precision is crucial.

Does that mean that Wangen’s other progressing cavity pumps are

not as hygienic and precise in terms of metering?

Renzelmann: No, they are not. But they have other strengths, such

as their excellent robustness to foreign matter.

The MX range includes the four pump designs MX-R, MX-S, MX-T

and MX-F. How do these pumps differ from each other?

Renzelmann: The MX-R is a hopper feed pump, which is suitable

for use with high-viscosity products that are no longer free-flow -

ing. The MX-S is a suction design of progressing cavity pump. The

MX-T and MX-F designs are designed for vertical operation and so

are perfect for various metering and transfer tasks, with the MX-F

also featuring a follower plate. All the above pump designs share a

common feature: all their stators have an EvenWall design.




Please explain this technology to us.

Renzelmann: With EvenWall technology, the stator casing is adapt ed

to the inner contour of the stator and has a uniformly thick 4 to

12 mm thick elastomer layer. This results in attractive benefits to

users compared to conventional progressing cavity pumps with a

cylindrical outer stator casing geometry and correspondingly differ -

ent elastomer wall thicknesses: MX pumps achieve considerably higher

pressure stability, there is less backflow, fewer downtimes and

their efficiency is extended. Other benefits include less shearing of

the products being pumped and improved suction behaviour. Moreover,

thanks to EvenWall technology, the pumps generate 10 bar

per pressure stage. This value is between 4 and 6 bar with conventional

progressing cavity pumps. As the MX pumps can be designed

as multi-stage pumps, this enables them to achieve pres sures of up

to 80 bar – coupled with their extremely compact design.

Are there other benefits apart from the special design of the stator?

Renzelmann: Definitely. The pumps have a modular design so that

they can be easily adapted to the most diverse applications. Their

sealing chamber is generously sized providing space for all possible

sealing arrangements.

Are the pumps CIP- and SIP-capable?

Renzelmann: But of course. They are also designed to be easy-toclean

with no dead spaces. EHEDG and 3-A Sanitary Standard certification

approval will come in the next weeks.

Let us now talk about the materials used.

Renzelmann: We use stainless steels 1.4571, 1.4404 and 1.4301 for

the wetted metal components. The elastomer components are made

of different materials, which are all FDA-compliant and approved

PUMPENFABRIK WANGEN:

FACTS & FIGURES

Dr. Herbert Wallbrecher founded Pumpenfabrik Wangen

in 1969. Over the past 50 years, his small craft business

with a handful of employees has grown into a globally

operating plant manufacturer. The displacement pump

specialist today employs around 250 people. The company’s

product range includes progressing cavity pumps

and twin screw pumps for the food and beverage industry

as well as for the pharmaceutical, cosmetics and

chemical industries. The pumps are developed and produced

at the company’s headquarters in Wangen. The

medium-sized company also has a branch in Schwerin

and a subsidiary in the USA. The international sales of

pumps rely on a global network of sales and distribution

partners. The international sales and distribution

network is currently being expanded to include partners

in Great Britain, Ireland, Northern Ireland, Australia and

New Zealand.

Pumpenfabrik Wangen recorded a turnover of around

46 million euros in 2019.

The stators of the MX progressing cavity pumps are designed for Even

Wall technology

according to EU 1935/2004. They include EPDM, NBR and fluoro -

elastomers.

What capacities do the MX progressing cavity pumps provide?

Renzelmann: We supply four designs of pumps, with each one

being available in several sizes. Apart from the viscosity of the prod -

uct being pumped, the capacity, of course, also depends on the pump

being used. The capacity range extends from 1 to 100,000 l/h.

What about the viscosity of the products being pumped?

Renzelmann: MX pumps are able to pump both low and high viscosity

media. They work very well with low-viscosity products at

low capacity. This is because MX pumps do not experience the slippage

that frequently occurs with twin screw pumps.

Where are the pumps used in the chemical industry?

Renzelmann: Yes. For instance, a paint and coatings manufacturer has

60 of these pumps in its company. In the pharmaceutical industry,

they are used, among other things, for the metering of ointments.


Online search: Pumpenfabrik Wangen

THE INTERVIEW WAS CONDUCTED BY:

LUKAS LEHMANN

Assistant Editor-in-Chief




Powerful solution for collaborative robots

Flexible cobot gripper

handles cosmetics

Whether cartons, bags, tubes or glass containers, Piab‘s Kenos KCS gripper helps

the cosmetics industry to combine and pack many different small items in different

ways for different branch types. The matching UR-Caps app makes commissioning

the gripper for handling cosmetics on a cobot from Universal Robots particularly

easy. Thanks to the flexibility of the Kenos KCS gripper, it can handle products of

any shape or surface.

For the cosmetics industry, placing

products into packages ranging from

huge divisions in department stores

or flagship outlets to tiny cosmetic

shops, is a particular challenge. Today

this task is often fulfilled by an armada

of workers hand picking and

placing each item into each specific

box. The opportunity for automation

seems obvious, but it is also challenging,

as it demands an extremely high degree

of flexibility to make an investment

economically worthwhile.

Piab’s UR Plus certified Kenos KCS

gripper considers these requirements

of customers from the cosmetics industry

who are in need of a solution that

provides a combination of many small

The Kenos KCS gripper can handle almost everything – an important feature

when it comes to cosmetics distribution

Pictures: Piab

items in various ways for different store

types.

Automation tool

Cobot manufacturer Universal Robots

specialises in the provision of automation

solutions that solve tasks together with the

human workforce. While cobots are easy to

use and fast to deploy, flexibility often

depends on the gripper technology.

To support Universal Robots’ vision of

providing an out-of-the-box usable solution,

the gripper must seamlessly integrate

into the UR-Plus plug-and-playplatform,

which allows easy installation

and implementations. The start-up phase

when using new UR-Plus certified

grippers is considerably shortened by the

UR-Caps developed by the gripper manufacturer.

These small programmes are similar

to mobile phone apps. Within a few

minutes they enable the user to commission

a new gripper on a Universal Robots

cobot without detailed programming

know-how. Piab’s Kenos KCS gripper is

now equipped with the respective UR Cap

and listed on the respective UR-Plus-Solutions

website.

Any gripper used in cosmetics distribution

needs to offer the flexibility of being able

to handle all kinds of products, in every

shape and packaging type, be it cartons,

bags, tubes or glass containers. With the

flexibility of the Kenos KCS gripper, customers

in the cosmetics industry are able

to pick and place products with any shape




Every

child

is one of a kind and

unique. Each child

needs individual

support according to

their needs. Please

help us by donating.

Thank you!

The Kenos KCS gripper consists

of a pump unit for vacuum

generation and a

gripper unit made of a technical

foam that can adapt to a

variety of contours

Tel.: 0800/50 30 300 (free of charge)

IBAN DE22 4306 0967 2222 2000 00

BIC GENO DE M1 GLS

www.sos-kinderdoerfer.de

2016/1

or surface. This makes it easy for them to

handle a variety of different parts with just

one end-of-arm-tool.

KCS system

The Kenos KCS gripper consists of a separate

pump unit, which integrates modular vacuum

generation in a very small space, and of

a gripper unit. Both are connected by a

quick-change system. The main gripper consists

of a technical foam, which can adapt to

a wide variety of contours and can thus flexibly

accommodate different parts. This eliminates

in many cases the need for accurate

identification of a product as well as the

gripping surfaces. Accordingly, in many

applications, exchanging the gripper when

changing the products to be handled is not

necessary. The cobot is therefore ready for

immediate use for different processes. In

addition to the greatest possible flexibility in

the field of application, time and cost savings

are achieved through shorter downtimes and

time needed for retooling.

Another advantage in this context is that the

worn foam layer can be easily replaced without

having to replace the entire gripper. For

direct handling of food, the gripper can also

be equipped with a special FDA-approved

technical foam. For special applications, such

as the handling of plastic bags of concentrates

or granulates, Piab has developed another

gripper unit, which can be swiftly exchanged

via the quick-change system.

Flexibility in terms of forms and surfaces that

can be handled, as well as in the placement

of products to be handled, are a plus for the

cosmetics industry. It does not matter for the

Kenos KCS gripper if a product is placed

exactly in a specifically planned location – it

can pick it up as long as its foam surface can

hold most of the product.

The gripper units are characterised by their

edgeless design. Due to the rounded sides

and the surface of technical foam, possible

injury hazards were largely eliminated. This

makes the gripper units particularly safe to

use on cobots, which cooperate freely with

humans.

Use of Coax vacuum technology

The pump unit is equipped with the powerful

Coax SX vacuum technology. The lightweight

Pichip unit is a small, integrationoptimised

vacuum pump and was selected

because of its almost silent operation, making

it ideal for using it directly next to the

operator. Because Coax ejectors are very fast

and deliver three times more flow than a

conventional ejector with identical air consumption,

the Pichip unit can deliver high

performance even with low or fluctuating

supply pressure. Independent comparison

tests at the Fraunhofer Institute for Machine

Tools and Forming Technology IWU in

Dresden have shown that the Piab ejectors

require significantly lower compressed air

to achieve the same output compared to

ejectors from other manufacturers. This

makes them particularly energy efficient.

Accordingly, their use reduces the cost of

providing compressed air and thus the total

cost of production.


Online search: Piab

AUTHOR:

BERND GRIES

Manager Global Sales

Strategic Accounts,

Piab Vakuum



PRODUCTS

Self-learning level switch

The level switch Cleverlevel

PL20from Baumer makes processes

more flexible – because it

no longer matters what is in the

tank. The self-learning sensor

automatically adjusts to the

different media. This ensures

maximum flexibility with minimum

setup times. In addition,

thanks to its compact design

and low installation depth, it

has only a minor impact on the

process.

Even adhesions such as those

that occur with pasty materials

Picture: Baumer

and electrostatic charging do

not affect the performance of

the sensor. In such cases as well,

the level switch adjusts the

switching level without any type

of parameterisation, minimising

downtimes that may be caused

by faulty switching. With an additional

optional 4…20 mA

analog output, the PL20 can

help differentiate the media

within the process or evaluate

the cleaning process. What is

more, the graphic evaluation of

the measurement results with

the help of the Flexprogrammer

ensures a transparent process. In

addition, the sensor can be

easily and quickly integrated in

already existing systems via the

analogue interface. At the same

time, the large selection of process

connections and adapters

allows the flexible and easy integration

of the sensor.


Online search: Baumer

amixon ® Mix-Dryers and Reactors

Mixing, drying and synthesizing in one apparatus

✓

✓

Particularly gentle mixing and contact drying

Ideal heat exchange - mixing chamber and mixing tool can be

temperature controlled

✓

Sizes from 100 liters to 50.000 liters available

Service packages for expert assistance

With GEA Remote Support, GEA

experts are instantly available

via video, which neither

requires pre-installing software

nor an updated IT-infrastructure.

GEA now offers customers

two new service packages providing

different types of remote

expert assistance.

The standard package includes

instant GEA expert support and

is compatible with any commercially

mobile device. This GEA

remote support option leverages

a video streaming service that is

safe and ensures the protection

of customer data given it uses a

closed video network. Customers

can initiate a session from

their own production location

via e-mail or SMS, which contains

a secure link to initiate a

video conversation. This option

also allows for sharing imagery

back and forth during the conversation,

as well as sending descriptions

and instructions via

the chat function. To make

accessing support even easier

for customers, GEA also offers a

second, hands-free option: The

eye wear package includes

specially-designed glasses and

provides customers with the

freedom to communicate with

GEA experts while performing

tasks. The optimised GEA Remote

Eye Wear glasses include

an integrated high-resolution

camera and reliable microphone,

providing several bidirectional

functions.


Online search: GEA

Picture: GEA

✓ Virtually complete discharge

✓ Can be used for powders, granulates, liquids and highly

viscous pastes

✓ Filling levels can vary from approx. 15% to 100%

✓

✓

✓

Variable peripheral speed from 0.3 to 5 m/s

Easy to clean and sterilize, fully automatic

All components of the amixon ® mixer are made in Germany.

The machines are manufactured exclusively in the amixon ®

factory in Paderborn, Germany.

Save the date! Trade Shows 2021:

Eurotier 09.-12. February 2021 Hannover

amixon GmbH

Paderborn, Germany

sales@amixon.com

www.amixon.com

Interpack 25. Februar - 03. March 2021 Duesseldorf

Solids 17.-18. March 2021 Dortmund

Anuga FoodTec 23.-26. March 2021 Cologne

Achema 14.-18. June 2021 Frankfurt cpp / Main 03-2020 15


PRODUCTS

Optimised interfaces to CAE programmes

The optimised interfaces to

popular CAE programmes in the

Project complete planning and

marking software from Phoenix

Contact enable data from electrical

planning to be integrated

with a click of the mouse. The

corresponding terminal strip is

configured automatically.

The following changes can then

be made in Project complete:

replace terminal blocks, add

accessories, exchange bridges.

Picture: Phoenix Contact

After editing the configuration,

the changes are exported to the

CAE programmes. The interface

between the Project complete

planning software and the CAE

programme is established with

just a few clicks.

The Project complete software

enables the easy configuration

of terminal strips. It provides

support through the entire process

of control cabinet manufacturing

– from configuration

through to the finished application.

The programme features

an intuitive user interface that

enables the individual planning,

automatic checking, and direct

ordering of terminal strips. The

marking and planning software

is part of the Complete line system.


Online search: Phoenix Contact

Combining performance with durability

The CSA and CSI Frame 1

groups of sealless pumps take a

modular approach to combining

performance with durability

and versatility while ensuring

industry and regulatory safety

compliance to ASME, ISO and

IECEx standards. The HMD Kontro

CSA and CSI ranges offer

total containment, eliminating

potentially dangerous leaks, essential

for handling hazardous,

toxic or hot substances, and preventing

the loss of high value

product. The containment shell

can be provided either in metal

Picture: HMD Kontro

or as HMD Kontro’s unique

Zeroloss format, which increases

resistance against system

upsets and saves energy. A fully

contained casing gasket further

improves safety by eliminating

the risk of blowouts, dangerous

and potentially costly where unexpected

breakdowns occur.

The new range conforms fully

to the latest IECEx standard and

assures compliance with ASME

B73.3 and ISO 2858/15783 for

the CSA and CSI respectively.


Online search: HMD Kontro

Oil-free rotary screw blower

Hot block for open-vessel digestion

The EBS 410 rotary screw

blower from Kaeser is based on

an oil-free compression blower

technology, designed especially

with water industry applications

in mind. The blowers have a

flow rate of 10 to 40 m 3 /min

and pressure differentials from

0.3 to 1.1, as well as a selection

of motors ranging from 22 to

75 kW. The SFC version is

equipped with a frequency converter

and a synchronous reluctance

motor – a slip-free design

that combines all the advantages

of high efficiency permanentmagnet

motors with those of

robust, service-friendly asynchronous

motors. Thanks to

variable speed control, the flow

rate can be adjusted as required

and a control range of 1:4 is

achieved, which allows exceptionally

dynamic operation.

The STC version is now

equipped with an energy-saving

IE4 Super Premium Efficiency

motor that reduces energy consumption

and therefore costs,

making the STC version more

efficient than ever before.

With both versions, power

transmission from the motor to

the airend takes place via lossfree

and maintenance-free gearing,

which results in an up to

8 % improvement in specific

power compared to the previous

model. The complete machine

achieves an isentropic efficiency

of up to 80 %.


Suchwort: Kaeser

Picture: Kaeser

Well-known for its microwave-assisted digestion instruments,

Anton Paar has now launched a laboratory hot

block for the acid digestion, evaporation, and concentration

of samples. Multicube 48 comes with pre-installed

and customisable methods and complies with standard

methods such as EPA 3010a, 3020b, 3050b, and 3060 for

solid waste and EPA 200.2, 200.7, 200.8, 200.9, 245.1,

and 365.1 for water. The new hot block combines an easy

workflow and operation with Anton Paar precision. High

temperature homogeneity of ±1 °C over the whole block

guarantees the same digestion quality for all samples. The

disposable low-cost vials with lowest metal blanks elimi -

nate the risk of external contamination.

The Multicube 48 vials can be used for weighing and

digesting, storing digested solutions, and as volumetric

flasks for filling up the samples to the appropriate volume.

The vials are fully compatible with autosamplers for metal

analysis by F-AAS, GF-AAS, ICP-OES, or ICP-MS.


Online search: Anton Paar

Picture: Anton Paar

Modular worm gear unit

IP 68 waste water pumps

The worm gear unit SN5VH

from Ruhrgetriebe has a lightweight

aluminium body and

impresses with its compact design

based on the modular principle

and thus offers a wide

range of possible uses for industrial

applications. The output

shafts can be implemented both

as solid and hollow shafts – in

order to be able to react to different

conditions in different

applications, the mounting

position can be selected variably.

Available are gear-motor combinations

between 32 and 120 W

(other engine power possible)

and ratios from 7 to 50:1 with

which effective torques of up to

9 Nm are possible in a compact

installation space.

In addition to the many possible

applications for new designs,

the SN5VH is also suitable for

repair or replacement requirements

for gearboxes already in

use.


Online search: Ruhrgetriebe

Picture: Ruhrgetriebe

The submersible motor pumps

Amarex KRT from KSB have

jacket-cooled drives. The pump

sets are available with drive ratings

of 10 to 30 kW and are

suitable for vertical or horizontal

dry installation. Since the

pump motors remain fully operational

when not submerged,

the pump sets can also be used

in pump sumps when water

levels have dropped. Thanks to

IP 68 enclosures, the pumps also

offer trouble-free continuous

operation when flooded. The

pump sets meet all explosion

protection requirements set out

Picture: KSB

in the Atex, FM and CSA stand -

ards. The motor is cooled via a

closed circuit which avoids contact

between the circulating

water-glycol mixture and the

fluid handled. The cooling

liquid is circulated by a special

impeller which the pump’s design

engineers have integrated

into the cartridge seal. The

pumps are able to transport

fluids with a temperature of up

to 40 °C and operate in environments

with a temperature of up

to 55 °C.


Online search: KSB















Measure

Analyze

Understand

Connect

Take Action





PRODUCTS

Improved generation of gas analysers

Depth filter cartridge for slurry filtration

Picture: Pfeiffer Vacuum

Pfeiffer Vacuum improved the

Omnistar and Thermostar GSD

350 compact, portable benchtop

gas analysers for atmo -

spheric pressure. The gas inlet is

fitted with a heated capillary for

use at up to 350 °C. This prevents

vapours from condensing.

With the new PV Massspec software,

it is possible to perform

qualitative and quantitative

anal yses. This software offers a

clear and user-friendly platform

for recording and displaying

measurement data and param -

eter settings. Even complete

measuring procedures can be

programmed and automated.

With a variety of equipment

variants available, the mass

ranges of 1 to 100 u, 1 to 200 u

and 1 to 300 u are covered.

The two new models differ

from comparable devices by

their compact size and easy

operation using an integrated

touch display or a web user interface.

The device can be fully

controlled and the user can also

perform simple measurements

without a PC or PV Massspec via

a smartphone or tablet.

The low detection limit of up

to

High-quality stills produce ultra-pure water

Picture: Lauda

Lauda has extended its laboratory

technology product range

with the Lauda Puridest stills

product line. The devices with

the GFL technology quality

mark produce an ultra-pure,

low-gas, sterile and pyrogenfree

distillate with very low conductivity.

Puridest stills are used

in bacteriological and medical

sample preparation and also in

the preparation of cell and tissue

cultures. The distillate complies

with the DAB regulations and

the specifications of international

pharmacopoeias. Puridest

stills also distill raw water

of lower quality, separate pollutants,

and reliably kill germs

such as bacteria and viruses.

They are available in four highperformance

product lines with

14 single- or two-stage model

variants in the form of stainless

steel or glass stills. Depending

on the model, the devices are

equipped with a storage tank

and produce 2 to 12 l/h of distillate

with conductivities down

to below 1.6 μS/cm. The stills

are easy to commission and

operate. The ultra-pure water

can be extracted directly after

connection to the raw water and

power supply. The devices are

maintenance-free, because the

glass stills automatically remove

pollutants.


Online search: Lauda

MASS FLOW

CONTROLLERS

for Air and Specialty Gases

High accuracy and reproducibility

Gas flow ranges from 1 ml n /min up to 500 m3 n /h

Pressure rating up to 700 bar

www.bronkhorst.com

Analysis software increases plant efficiency

Picture: Bilfinger

COG MAKES ITS MARK:

Brilliant rings for

all occasions.

With Bilfinger Connected Asset

Performance (BCAP), Bilfinger

Digital Next offers operators of

industrial plants a modular dig -

itisation solution. At its core is a

cloud-based platform on which

all data from the areas of engineering,

operation and maintenance

of a plant is brought together.

From now on the Trendminer

software is also available

in the BCAP Solution Store. Its

diverse functionalities for analysing

data can be fully used in

the BCAP environment and

combined with other modules.

BCAP self-service analytics

powered by Trendminer is an

advanced yet easy to use data

analytics solution for all workforce

dealing with operation,

processes and plants. BCAP integrates

all different data sources

and allows for advanced analytics,

automatic monitoring

and alarms of critical plant conditions.

The advanced analytics

provide intuitive functionalities

such as similarity search, golden

batch analysis, anomalies detection

and so on. Overall, the software

supports the operators to

reveal potentials for increasing

the overall equipment effectiveness

(OEE) of plants, reducing

energy consumption and forecasting

necessary maintenance

measures.


Online search: Bilfinger

Precision O-rings for diverse industrial

applications and the highest demands.

01. – 03.12.2020

Visit us in:

hall 3, booth 3E28

www.COG.de/en




Seeing the bigger picture

Pitfalls and opportunities

in the selection of HMIs

HMIs are now without a doubt one of the essentials of any modern manufacturing,

processing or exploration application. We talked to Patrick Neuhalfen, associate

product line manager at power management company Eaton, about the pitfalls and

opportunities when it comes to selecting HMI solutions, and the added value that

specialist suppliers can bring.

With the advance of Industry 4.0 and the

colossal levels of connectivity derived from

Industrial Internet of Things (IIoT) hardware,

it can be argued that data is now industry’s

single most powerful tool. But

without an efficient means of collecting,

analysing, deciphering and then – most importantly

– presenting this data, all the gains

from a connected infrastructure are for

naught.

Patrick Neuhalfen, associate product line

manager for HMI at Eaton, which includes

the Gecma workstation range, explains: “Increasing

automation and data capture in

industry has resulted in a far greater use of

human machine interfaces, but there is no

‘one size fits all’, as every application is

different – some placing extraordinary

demands on the HMI solutions.”

Assessing the risk

Hazardous areas are a case in point. Money

used to be no object for industries such as

oil & gas, but as market demands fluctuate

and industry pressures manifest new and interesting

challenges, many operators – and

Increasing automation and data capture in industry has resulted in a far greater use of

human machine interfaces (HMI), but there is no ‘one size fits all’

Picture: amixstudio – Getty Images

not just in oil and gas – are seeking to reduce

costs and overheads. Changing the infrastructure

and re-assessing the Atex zones

can be one option.

However, assessing the appropriate level of

hazard and implementing the correct precautions

involves an element of risk for the

company and its employees. A single mistake

in a long chain of activities – zone classification,

selecting the right product, product

design, complex installation, regular

maintenance – can cause disaster.

“Standards are essentially guidelines on how

to design a product, but they are subject to

change: for example, becoming more restrictive

in response to lessons learned from

major incidents or amended to take account

of new technology etc,” says Neuhalfen.

For many customers, the decision to select a

zone 2 product can be a risk too far. Zone 2

products can be self-declared for Atex and

do not require any notified body to certify

the design. Specifying a zone 1 product,

even in a declared zone 2 environment, adds

a significant layer of additional protection

and eliminates potential risks. There is also

the benefit of future-proofing the system:

for example, if a plant reconfiguration

changes an area from zone 2 to zone 1.

Sometimes a static HMI must be re-located,

or it’s important to eliminate the risk that a

mobile HMI will be accidentally placed in

the wrong zone-environment.

Modular design benefits

“At Eaton, we think that every company

should do everything they can to provide

the safest environment possible,” says Neuhalfen.

“So, we decided to develop an op-


Picture: Eaton

Picture: wwing – Getty Images

“Every company should do everything they can to provide

the safest environment possible,” Patrick Neuhalfen, associate

product line manager for HMI at Eaton

Eaton recently designed an HMI solution capable of operating at temperatures

of -40 °C for a customer in Kazakhstan. Their service included recertification

to ensure compliance.

tion that can keep long term costs under

control without compromising safety in

hazardous areas.” The solution, spearheaded

by the Gecma team, is the deployment of

modular HMI designs.

A major benefit of this approach relates to

downtime, where individual modules – as

opposed to the whole system – can be replaced

and hot swapped, reducing non-productive

time to a minimum.

This modular approach also delivers the allimportant

service differentiators. Due to

their high flexibility and configurability –

in both electrical and mechanical aspects –

customers have a far greater range of

choices. One example would be transforming

a KVM transmission HMI into a Thin

Client or PC. By offering a variety of housings,

users have more options available,

such as mounting and positioning especially

for areas with limited space.

“We complete the service picture with

strong support and management of our customers’

expectations,” Neuhalfen elaborates.

“Our expertise can offer the best possible

support, based on in-depth knowledge

across multiple applications and the associated

certification requirements, such as

Atex, IECEx, TIIS, etc. As a result, our ETO

solutions are always genuine options that fit

the precise needs of the customer and the

legislation they must comply with.“

“Compliance is a big area where Eaton can

add value,” he continues, “not only at the

front end, but also further down the design

chain. If compliance is not fully understood

and addressed by a preferred main OEM

supplier, customers can potentially run into

problems: for example, because a CE decla -

ration for an individual product does not

mean it remains CE compliant when combined

with others. Compliance is largely dependent

on circumstance.”

The bigger picture

Industry knowledge and application exper -

tise are vital. “Sometimes adding value can

be relatively simple, like offering ceiling

and wall mounts for offshore applications

where space is at a premium,” Neuhalfen

says. “We are also seeing a growing need for

dual displays, especially in relation to the

boom in data capture. As well as offering

more screen real estate for broader information

delivery, this dual screen approach

can also cut costs, via savings in

both wiring and installation.”

A recent example highlights the importance

– and effectiveness – of Eaton’s expertise.

On an oil and gas zone 1 application in

Kazakhstan, HMI equipment would be exposed

to temperatures as low as -40 °C.

Standard solutions cannot operate at these

temperatures.

Eaton worked directly with the project management

company on behalf of the main instrumentation

contractor to develop a bespoke

solution. Eaton also conducted a

feasibility study to ensure its recommended

approach was viable, managing end customer

expectations and setting out a clear

delivery schedule.

The specially designed HMI is capable of

operating at temperatures of -40 °C, and so

required recertification to ensure compliance

under Atex, IECEx and EAC. The customised

enclosures were also IP 66 tested, at

an Eaton facility, and all retesting was

undertaken to ensure full compliance under

one certification. An internal heater was

added to ensure reliable operation and

maintain a temperature of 0 °C inside the

HMIs.


Online search: Eaton

DR. BERND RADEMACHER

Editor




Added value in process industries

DATA – THE NEW OIL?

We humans often have a better understanding of facts with the help

of figurative comparisons. With an expression like „data is the new

oil“, each one of us has vivid ideas about the potential that lies dormant

in unimpressive data. But to what extent does this comparison

apply to the process industries? Is data not valuable here, too? If so,

what is necessary to use data from process plants profitably?


Pictures: Siemens

In Plantsight, real and virtual worlds can be brought into harmony through an all-encompassing

digital twin platform

Assuming that data really is the new oil of the digitalised world,

every owner/operator of process plants would thus possess a source

of tremendous potential – today, hardly anything is easier than producing

data. Surely you already realise that it is obviously not that

simple and that the oil comparison is misleading. So the 2006

quote was extended to „Data is the new oil. It’s valuable, but if

unrefined it cannot really be used. It has to be changed into gas,

plastic, chemicals, etc. to create a valuable entity that drives profitable

activity; so must data be broken down, analysed for it to have

value.“ This makes the comparison more precise. While oil must be

explored, drilled and processed in order to be sold as fuel or as a

chemical feedstock, data must also be refined in order to use it

profitably. What might this look like in real terms?

Data is ubiquitous and often unused

Measured values, messages, alarms, real time or maintenance data –

in plant operation, masses of data are produced. And terabytes of

data are already generated before commissioning, from process

planning, hardware project planning, possibly from simulations,

process models, etc. All this information is important – not only

for the work of individual trades, but also for the productivity and

safety of the entire plant. Now, however, this data is distributed

across countless systems, software applications, databases and, as

before, over innumerable spatial meters of files in the archive.

Today’s software systems are often specialised for a particular type

of task, but often still lack the connectivity that would allow easy

comparison or cross-referencing of asset information. One of the

reasons for the absence of connectivity is the lack of support to

keep systems synchronised. In addition, the tools used often require

high demands on skills, licensing costs, computing and network resources.

So, finally, operators are confronted with countless formats

and data that is often outdated, inaccurate, difficult to access and

poorly synchronised – which is why they are called ‚dark data‘.

Modern dream child: the digital twin

But if all data is collected, consolidated, contextualised and stand -

ardised, the virtual image of reality emerges: the digital twin of the

plant or production. It allows the entire plant lifecycle to be depicted

and optimised – for both greenfield and brownfield plants or

projects. However, the digital twin must always be kept up to date.

Plantsight from Siemens is a solution that scores in all required disciplines

with the right tools and services. The system provides the

technological basis for the complete digital twin, which is continuously

updated, truly replicates its physical counterpart in both behaviour

and information context, and provides users with the information

required for the subsequent steps. This provides site managers,

operators, engineers and/or plant managers with reliable and

up-to-date information about plant operation. This dynamic image,

which is created from data from process and plant technology, plant

design, design and engineering steps as well as maintenance




In Plantsight, the real and virtual worlds come together to form a comprehensive digital twin platform

measures, is particularly important for the process industry, as the

plants here are characterised by permanent modifications.

Holistic approach to value creation from data

Easily and securely accessible via a browser, the Plantsight cloudbased

solution facilitates the digital twin by aggregating data from

many sources. These sources can include engineering or mainte -

nance databases, stored 3-D models, 3-D measurements and photogrammetric

information, as well as data from enterprise resource

planning (ERP) systems, recipe databases, project and portfolio

management systems or laboratory information management systems.

This is made possible by functionalities in the form of micro

services and connectors. This approach of distributed data management

(where data sets are intelligently connected to each other)

avoids replication while providing consistency and accessibility.

Such functionalities can significantly reduce the effort to build the

digital twin and increase the percentage of documented inventory

information. The time and energy required to merge and complete

asset information – especially for existing plants – is enormously

reduced by the use of artificial intelligence; static and dynamic asset

information can be merged automatically.

Trusted data for better decisions

Services for validating and linking data to other information, combined

with change tracking, improve the accuracy, completeness,

and also the reliability of asset data and documentation, enabling

better and faster decisions. Whether plant or site managers, plant

designers or operators, all benefit equally from reliable and up-todate

data and information. Context is critical to understand the

meaning of data and responding to it appropriately in daily operations.

When, as with Plantsight, data is automatically contextualised,

added and updated on a daily basis, this results in a higher

level of information documentation and makes the data all the more

trustworthy. The Siemens solution presents all information rolebased

in the Plantsight Web Portal and all involved parties can rely

on AI-supported proposals for action in their daily decision-making.

To make long-term success measurable, integrated technologies ensure

that the quality and completeness of plant information is con-

stantly monitored and that changes in plant performance in terms

of plant characteristics or plant modifications are comparable.

In Plantsight, real and virtual worlds can be brought into harmony

through an all-encompassing digital twin platform. This platform

can be used to determine capacity utilisation and effectiveness data,

and to enable well-founded decision-making in the simulation of

the virtual plant by means of integrated artificial intelligence and

machine learning technologies – for more efficient production lifecycles

and thus for more growth. So, is data the new oil? In contrast

to oil, data is the bigger challenge. To transform it into valuable insights,

a great deal of experience in handling data, analysing and

contextualising it is necessary. Equating data with oil neglects this

complicated reality. The biggest difference, however, is that both the

supply of oil and its applications are finite. With data, the opposite

is true, as long as there are people, we will continue to generate

more and more data, and we are now only at the beginning of

countless data application possibilities.


Online search: Siemens

AUTHOR:

ALEXANDER MANKEL

Head of Strategic CIS

Portfolio Management,

Siemens

AUTHOR:

NIGEL SAMS

Portfolio Management

Business Development Director,

Siemens


Industrie

The

network of

expertise

for industry

17 media brands for all major sectors

of industry

Information, inspiration and networking

for professionals and industry executives

Practical knowledge spanning all media

channels: Trade journals, websites, newsletters,

whitepapers, webinars, events

Your qualified partner for future topics

of industry

Discover the appropriate media for

you and your specific industry sector:

konradin.de/industrie

media.industrie.de




Oil – Gas – SIL 3

Functional safety in the

petrochemical industry

Functional safety is highly important in the petrochemical industry, as it is in

general in the process industry. Even insurance premiums for operators are

based on the extent of the risk-reduction measures that are in place at a

plant. Functional safety is not only of great importance for the protection

of people, plants, and the environment, also the economic factor must not

be underestimated.

Crude oil and gas that is extracted from

underground deposits must be chemically

processed to form compounds from the

mixture of different hydrocarbons. The two

main stages in this process are refining and

cracking. Fractional distillation involves a

mixture of substances being separated into

their components, whereas cracking involves

chemical processes taking place.

Deviations from the process sequence in

petrochemical plants often represent dangerous

errors. Petrochemical processes automatically

require SIL 3. Major control system

manufacturers only list suppliers of interface

products if the entire portfolio is

suitable for use in SIL 3 applications and has

also been tested accordingly.

The principles of functional safety are set

out in IEC/EN 61508, which was first published

in 1998. Edition 2 was published in

2010. IEC 61511 describes the principles of

functional safety for safety instrumented

systems in the process industry and is derived

from IEC/EN 61508. Some trends in

how these guidelines are implemented have

been observed in recent years.

To avoid scenarios like this under all circumstances, petrochemical processes automatically require

SIL 3 for functional safety

Pictures: Pepperl+Fuchs

Field and interface devices with SIL suitability

are increasingly being used where SIL

suitability is not required by a risk assessment.

Using a single, uniform device type

simplifies storage and prevents confusion

between devices with and without SIL suitability.

Around two thirds of all interface

devices delivered by Pepperl+Fuchs today

feature SIL 2 or SIL 3 suitability.

Quick Shutdown

In the event of a critical operating state in

the plants, the emergency shut down system

(ESD) must stop the supply of material and

vent the lines. Solenoid valves are often used

for this purpose. Solenoid valves function as

an upstream interface between the electrical

control level and the pneumatic drive. They

are operated by electromagnets and can

switch very quickly. The electromagnets are

controlled by solenoid drivers, which protect

the intrinsically safe field circuit and establish

galvanic isolation between the control

panel and the intrinsically safe solenoid

valve. Solenoid drivers prevent compatibility

problems between the field device and the

diagnostics of the digital output (DO) cards

in the emergency shut down system. The

user can fully utilise the diagnostics and

protective features provided by the DO

cards during operation, while the general

safety function remains unaffected. These

measures include test pulses with frequencies

in the kHz range and a duration in the

microsecond range; a specific load current

in the on/off state, depending on the card

and manufacturer; and a limitation of the

inrush current to protect the DO card. Sen-


sors monitor the shutdown. In addition,

acoustic and visual warning systems, and

fire extinguishing devices must be activated

in an emergency. Safety relays are used to

activate these systems.

With integrated diagnostics

To optimise the availability of the safety

functions, Pepperl+Fuchs has developed a

safety relay that includes fault monitoring

in the switching elements, integrated diagnostics,

and line fault detection for fieldside

short circuits and lead breakages. All

contacts have been arranged redundantly to

increase the availability of the safety functions.

The design is based on MooN architecture,

which means that M-out-of-N

elements must be in an operating state.

Integrated diagnostics are performed using

time-delayed switching of the elementary

relays, with one relay checked during each

switching operation. In ETS (energized-tosafe)

circuits, all three relays of both contact

groups are initially closed if three consecutive

switching operations occur. During the

delay period, the device checks whether this

operation closes the circuit as a way of detecting

a faulty contact. By changing the sequence

for time-delayed switching, all contacts

are checked after three switching operations.

Diagnostic checks of DTS (de-energized-to-safe)

circuits take place during the

restart process rather than during shutdown.

Initially, two relay contacts are closed

simultaneously and the third contact is

closed after a time delay. The idea is that

there is no current flowing before this contact

closes, otherwise this relay is faulty because

it no longer disconnects the circuit. A

different relay is checked during every

switching cycle. The checks are typically carried

out on an annual basis. The safety relay

executes the routine described above once

during these annual tests, and will have

been fully tested after three years without

any additional effort.

The line fault transparency feature provides

seamless monitoring of voltage and load resistance.

It detects field-side short circuits

and lead breakages and can assign them to a

specific signal circuit.

Thought was also given to the need for

quick adjustments of the safety relay. The

input circuit is identical for all devices. This

means that once a device has been tested

using one of the control panel's DO cards,

all other modules of the safety relays are

compatible. The complete product family of

The safety relays from Pepperl+Fuchs carry out integrated diagnostics during each switching

operation

the single-channel and loop-powered safety

relay KFD2-RSH includes a total of four

modules for DTS and ETS applications with

either 24 V(DC9 or 230 V(AC). They are approved

for Atex Zone 2, and comply with

SIL 3 (IEC 61508 ed2) and PL e (EN/ISO

13849 for the DTS modules).

Extended test cycles

Operators are increasingly discussing extending

the test cycles for safety devices.

Operators should carefully consider the

benefits and potential disadvantages of extended

test cycles since systematic failures

are frequently discovered during tests, such

as the media incompatibility of field devices.

Currently, attempts are being made to

extend testing cycles from a typical oneyear

period to one of up to five years. Typically,

a plant or plant part is shut down at

specific intervals for maintenance purposes,

instead of testing each device individually.

The idea that the weakest link determines

the strength of the chain applies in this

scenario. All components used must be able

to be incorporated into the desired maintenance

cycle, i. e., each component must

individually have a sufficiently long proof

time.

Pepperl+Fuchs has responded to precisely

this development by developing the safety

relay with integrated diagnostics. Diagnosing

the state of the elementary relays increases

the proof times to well over ten years.

Redundant SIL 2 devices

In addition to the above-mentioned integrated

diagnostics in devices, the redundant

design of SIL 2 devices has become established

in SIL 3 applications. This is permissible

if systematic failures are excluded as

far as possible. This can be ensured by

heterogeneous redundancy. Homogeneous

redundancy is also possible if the devices

have systematic capability for SIL 3 applications.

This systematic capability can be

proven by a functional safety management

(FSM) certificate. In cases where the Machinery

Directive applies, the EMC standard

EN 61326–3–1 also applies. According to

this standard, the test duration must be increased

by three to five times for some tests

on an SIL 2 device if the device will be used

for SIL 3 applications. However, this is not a

requirement in the corresponding standard

for the PA division, EMC standard EN

61326–3–2.


Online search: Pepperl+Fuchs

AUTOR:

ANDREAS GRIMSEHL

Product Marketing Manager

Interface Technology,

Pepperl+Fuchs




Use in paint production

Radar sensor monitors

filling level in storage silo

A European paint and varnish manufacturer stores quartz sand and other components

in its German production plants, partly in special silos with a small diameter.

The storage bins are divided into three parts and have additional deflector plates

and ladders on the inside walls. In order to completely and precisely monitor the

level despite the special design of the silos, the company uses the free-radiating

radar sensor Nivoradar NR 3000.

Facade and interior paints, varnishes and

glazes, plasters, floor coatings and concrete

protection, each with a myriad of specifications:

for the painter, varnish and plasterer

trades, there are thousands of products

for all kinds of needs. The European system

operator also has an extremely large product

range with more than 10,000 articles. It has

one of the most advanced goods distribution

centres in the industry. It is particularly

important for the producer to be able to

react compliantly to market developments

and orders thanks to the open and flexible

system and to guarantee short delivery

times in addition to high delivery security.

More than 900 of its vehicles are in use

every day to supply customers and subsidiaries

mainly in Germany, Austria, Italy, the

Netherlands, Poland and Switzerland. This

sophisticated logistics system is supported

by reliable level monitoring within the silo

systems.

The radar sensor Nivoradar NR

3000 is equipped with an air

purge connection for cleaning

the lens antenna

Pictures: UWT

In the chemical industry in particular, sensors

are usually exposed to aggressive, adhesive

or corrosive materials. High temperatures,

dust, varying DK values and viscosity

have to be dealt with quickly and reliably by

the measuring technology.

Radar sensor for special silo design

For its production plants in Germany, the

operator was looking for a precise solution

for level measurement detection in its various

silo containers, where components for

paint production, such as solvents and

binders, pigments, oils, resins, fillers and

additives, are stored. The decisive factor is

an even and controlled introduction into the

production system. Convinced of the

measurement technology of UWT GmbH

for years, the project planner again turned

to the Allgäu-based company. For continuous

level measurement, work was also carried

out on site to find a reliable solution

for some special storage silos on site, where

quartz sand is deposited, among other materials.

These silos have a small diameter, are

divided into three parts and have additional

deflector plates, and a ladder is mounted on

the inner walls. This makes it particularly

difficult for a level sensor to continuously

monitor the entire measuring range.

With the contactless radar, a holistic so -

lution for the diverse storing processes was

found. In addition to electromechanical lot

or plumb bob systems, radar sensors are

mostly used for continuous level measurement

in content monitoring. They measure

distances of up to 100 m (328 ft) and, due

to their high sensitivity, can be used in both


The Nivotec system offers reliable support of the logistics concept

through targeted silo management with optimised inventory planning

coarse-grained and very fine powdery

bulk materials as well as in different liquids

and pastes.

Dust-proof construction

The silo containers for component storage

have an average height of 17 m (55.78 ft).

The bulk weight of the quartz sand is

1400 g/l (87.39 lb/ft³) and the DK value is

between 2,0 to 3.0. The process temperatures

reach up to 80 °C (176 °F) and the

given process pressure is around 0.8 bar

(11.6 psi). Vibration in the container or

electrostatic charging are not relevant to the

application. However, there is a dust-intensive

atmosphere, especially within quartz

sand storage. The contact-free radar was accordingly

equipped with a completely dustproof

construction and delivers reliable

measurement results at process temperatures

of up to 200 °C (392 °F). The device

works at 78 GHz high frequency and therefore

has a very narrow beam angle of only

4 °, which eliminates any signal interference

at the flange but allows optimum reflection

of the bulk solids material, even with

steeper cones. The radar is perfectly aligned

via the adjustment flange, since the beam

can be fixed at the desired point, e. g. on the

silo discharge. This enables smooth use in

tight, high silos and makes installation and

placement of the sensor considerably easier.

Thanks to its encapsulated housing construction,

the radar is optimally protected

within the demanding environmental conditions

and delivers reliable measurement

results. In addition, due to the integrated air

flush connection for cleaning the lens antenna,

application here was problem-free.

The sensor’s self-cleaning function also ensures

reliable measurement when it comes

to condensation or dust build-up. The device

works with two-wire technology and is

easily put into operation via an optimised

local programming device with display and

a quick start assistant.

Optional data visualisation

For the use of the acquired data, the radar

sensor can be connected to the Nivotec

visualisation system. The data visualisation

provides the detected levels in height, percentage,

weight or volume. Trends are saved

and e-mails about fill levels or silo messages

can be activated. The remote retrieval of the

data obtained can also be done via a GSM

modem at any PC in the company Ethernet.

System installation is straightforward and

can be done by the own service staff. The

availability of all detected levels improves

the planning reliability of the plant

operator.


Online search: UWT

AUTHOR:

ARMIN WAIBEL

Technical Service,

UWT

















handling systems for different kinds of





IPCO offers:



of 96%



2000 systems installed

in 30+ years












Condition-based maintenance of mechanical components

How dumb components

learn to talk

The condition-based maintenance discussions have some parallels with Bizet’s Opera

l’Arlésienne, everybody talks about it but, like the protagonist never shows up in

the opera, only few can show real live applications. Performing maintenance of

industrial sites based upon a need instead of on a scheduled time interval is widely

accepted as the right thing to do, so why are there only few who do this?

A recent study by the World Economic

Forum and the consulting firm Accenture

lends substance to the high hopes currently

riding on predictive maintenance. According

to the study, it can reduce the cost of

planned repairs by 12 %, cut maintenance

costs by almost 30 % and reduce unsched -

uled downtime by a massive 70 %. Present

tools to monitor the condition of process

equipment like safety valves (PSV) are too

expensive to procure and install. Consequently,

many process and equipment parameters

to define the health of such devices

are simply not monitored. Maintenance is

performed following a fixed plan and the

equipment is removed for tests, even when

nothing is wrong. With Ideation’s “no

threshold” solution the previously dumb

equipment can now be monitored continuously.

It allows customers to start with one

piece of equipment and an app.

The CBM Predictor can be equipped with eight sensors

Pictures: R. Bösch

Roots in off-shore platforms

The Ideation concept finds its roots in offshore

O&G production platforms and terminals,

where maintenance is a significant

customer burden. An average oil platform

has more than 500 silent mechanical devices

that need periodic maintenance interventions

to make sure that they operate

within specifications. Many of these must

even be periodically dismantled for testing

and refurbishing, an enormous cost.

Of course, these maintenance practises are

also happening in other industries. The preventive

scheduled maintenance interventions

are a high cost for many businesses.

Often, historical data is used as a measure


The device the size of an ice hockey puck is a battery-powered edge computer

for reducing the intervals between interventions,

it helps to reduce cost – but it is definitely

not a prediction for future behaviour

of the equipment.

The widely available new and off the shelve

technologies bring the required solutions to

reduce the installed cost of the condition

monitoring devices. Historical data shows

that only 3 % of the serviced devices on

standard oil rigs really need an intervention.

No need to say that removing, for example,

a PSV is a costly undertaking, especially

when scaffolding is to be built, explosive atmospheres

need to be monitored and/or

parts of plants must be shut down for these

interventions. Especially the example of PSV

underlines how easy to install equipment

can change the maintenance costs.

Condition-based maintenance

The CBM Predictor from Ideation is a sophisticated

multifunctional wireless battery-operated

information server with the functionality

for abnormal condition detection (ACD)

of uninstrumented equipment in the process

industry. The on-board processor can be

equipped with up to eight sensors for specific

applications. All data processing, filtering

and mathematical calculations are performed

locally, the CBM Predictor only sends

actionable information to the outside world.

In the following paragraph, we expand on

three of many typical applications for this

technology.

Minimum temperature monitoring

Often, process equipment like pipelines is

provided with additional heating systems to

warrant that the transported medium stays

within temperature specifications. To avoid

single points of failure, it is often required

to monitor the health of the heating system

separately from the standard control systems.

The CBM Predictor guards the temperature,

reports abnormal condition via a

Bluetooth message and keeps the timestamped

events in the internal stack. The

user can then consult detailed and historical

information via the Android app or via the

Gateway. The stored events are alarm, revert

and every ten minutes when in alarm condition.

Monitoring of pressure safety valves

Most process safety valves (PSV) are pure

mechanical devices and are un-instrumented

and rarely connected to a DCS system.

It is thus almost impossible to know if

they are functioning properly, if they

opened recently and/or if they re-seated

without leaking. The CBM Predictor analyses

and records these abnormal situations,

stores the time-stamped events on its internal

memory, plus reports an abnormal condition

via a Bluetooth message. Also in this

case, the user can request detailed and historical

information via the Android app or

via the Gateway.

Humidity detection in enclosures

When provided with a humidity sensor, the

same CBM Predictor can monitor the humidity

in cabinets and other enclosures. The

sensor is directly mounted on the CBM Predictor

and penetrates the enclosure via the

cable gland. The CBM Predictor measures

The detailed information can be requested

directly via the Android app

humidity, stores the time-stamped events/

data on its internal memory and reports an

abnormal condition via a Bluetooth message.

The user can then request detailed and

historical information directly via the Android

app or via the Gateway. The stored

event data is on alarm, on revert and every

ten minutes when in alarm condition, similar

to the minimum temperature application.

Ideation is currently working on further applications

for the CBM Predictor, always

with a focus on monitoring dumb components.

While in Bizet‘s opera the hero remains

unhappy, a solution has been found

for the problem of dumb devices in process

plants.


Online search: Ideation

AUTHOR:

ALEXANDER SCHMIDT

Advisor to the Board,

Ideation


cpp FOCUS POWDER AND BULK SOLIDS PROCESSING

Pharmaceutical manufacturer puts efficiency to the test

Tablet press field test

There are many ways of improving efficiency in tablet production – for example, by

saving electricity, increasing output volumes, and reducing changeover times. With

its F10i tablet press, Fette Compacting aims to make all of these adjustments at the

same time. In an extensive field test, the pharmaceutical manufacturer Artesan put

the efficiency of the machine to the test.

Since July 2019, the pharmaceutical manufacturer Artesan has been testing the F10i tablet

press supplied by Fette Compacting at its production facility in Lüchow (Germany)

Pictures: Fette Compacting

Since the beginning of the coronavirus

crisis, pharmaceutical manufacturers have

been mobilising all of their forces to find

vaccines and medicine to combat the

Sars-CoV-2 virus while simultaneously

safeguarding the supply of standard

medication. At the same time, the pharmaceutical

industry is also feeling the eco -

nomic impacts of the pandemic – for

example, through disruptions of the

supply chains.

In view of these challenges, pharmaceutical

companies are reliant on reducing costs

and producing efficiently, whereby the

focus is shifting to the role played by machine

manufacturers. Fette Compacting regards

it as its key task to support pharmaceutical

customers in finding efficiency

potentials for their production. Machine

manufacturers nowadays need to know

their customers’ entire machine park and

keep an eye on all production processes.

Fette Compacting has therefore initiated

technological developments, which have

considerably driven the topic of improving

efficiency. One result of this work is the

new i series.

For many years, Fette Compacting has been

supplying pharmaceutical manufacturers

with tablet presses from the classic i series.

These include the high-performance 2090i

and 3090i machines as well as the standard

1200i, 2200i, and 3200i tablet presses.

More than 3000 models of this series are

already in use around the world.

The new i Series represents an innovative

development of these established machines.

This concerns numerous aspects – from

cross-generation system compatibility

through dust-tight standard design to digital

connectivity.


Quickly ready for production

The new i series was kicked off with the

F10i tablet press, a single rotary press for

smaller batches, which was presented to the

public in 2019. Even the initial production

figures during practical operation indicate

that Fette Compacting is capable of keeping

its promise of efficiency associated with the

new generation of machines right from

the start.

Since July 2019, the pharmaceutical manufacturer

Artesan has been testing the efficiency

of the F10i tablet press at its production

facility in Lüchow (Germany). Even

commissioning of the new machine triggered

great excitement among those responsible:

it usually takes pharmaceutical

manufacturers several weeks to set up a new

machine for production but this period was

reduced to a mere two days for the F10i.

This is made possible by the cross-generation

system compatibility displayed by the

new i series. Despite its fully-revised design,

almost all of the process-relevant assemblies

featured in the F10i are identical to those of

previous models. This is particularly valuable

when companies are already using

other machines from Fette Compacting:

“Apart from the F10i, we are already using

tablet presses from the series P1200, P2200,

1200i, and FE55,” claims Torsten Schewe,

team leader at Artesan. “Because the old and

new components are very similar, we had

significantly less effort regarding validation

and qualification.”

According to Schewe, the field test demonstrated

that at Artesan the F10i is a suitable

substitute for the P2200 from Fette Compacting.

“We were easily able to process

large magnesium tablets requiring a pressing

force of 70 to 80 kN. And machine

usage was considerably quieter than with

the P2200.”

Significantly higher output

But Artesan was even more impressed when

previous production volumes were compared

with the initial results of the F10i

tablet press: on average, the new machine

increased the output of all products tested

by 63 %. In individual cases, it was even

possible to quadruple the previous production

volume.

Two factors are primarily responsible for

these good results: the general efficiency of

the machine and intensive support provided

by Fette Compacting. During installation,

service technicians adapted the process pa -

rameters and optimised the setup of the filling

unit. These two fine adjustments alone

had a significant impact on improving the

performance.

Despite the high level of output, the F10i

works very economically. So economically,

in fact, that during the entire period of use,

Artesan was able to save 15 % energy over a

comparably high-performance machine.

This is attributable to a very efficient torque

drive, which can also be operated in an optimal

performance range even for high production

volumes.

The F10i has also proven its efficiency in

terms of saving production time. The

contract manufacturer Artesan converts its

tablet presses for a new product roughly

twice a week. For each changeover, the machine

has to be cleaned of any residue of

the previous product. In order to minimise

these cleaning efforts, the cladding components

to be cleaned were reduced by 70 %.

For Artesan, this means 45 minutes saved

for each product change. Seen over an entire

year of production, this translates into 66

hours of additional production time.

Easy format change

Complex geometries are a challenge in tablet

production. The more unusual the shape

of a tablet is, the more complications can

The F10i increases the output

of all tested products by

63 % on average

arise during the early phase of production.

As revealed by the test production of a convex

tablet, this problem could soon be a

thing of the past at Artesan. Smooth production

generally requires aligning the machine’s

tablet scraper to the particular shape

of the tablet. But it was possible to dispense

with this adjustment for the F10i as the tablet

scraper can be adjusted reproducibly

using a coding element. This setting is saved

by RFID for the respective formula, which

means complex readjustment is not

necessary.

Torsten Schewe draws a clear conclusion:

“The field tests were convincing. With the

F10i, Fette Compacting has built a tablet

press, which represents a real gain at many

levels. After the end of the test phase, we

will be integrating the F10i into our regular

machine park as fast as possible.”


Online search: Fette

AUTHOR:

JÖRG GIERDS

Senior Product Manager,

Fette Compacting



Use of a 3-in-1 conical mix-dryer and reactor provides advantages

Powder processing for

additive manufacturing

3D printing finds applications in many branches of industry. In addition to more obvious

applications in mechanical engineering, automotive manufacturing and architecture,

new applications in biomedicine and dentistry are looking highly promising.

The German company Amixon offers the appropriate technology for the preparation

of the powders, including the conical mix-dryer and reactor AMT.

Rapid Prototyping, 3D printing and additive

manufacturing are all terms commonly

used to refer to a manufacturing process in

which three-dimensional components are

created by laying down successive layers of

material from the bottom up. In powderbased

3D printing, each layer of the structure

constitutes a thin cross-section of the

final object and is generated according to

data from 3D-CAD tools. The layers of the

object are printed by applying an energy

source, usually a laser, and thereby melting

fine powders into the precise shapes detailed

in each cross-section. After completing one

layer, the laser returns to the starting position

and melts the newest layer together

with the earlier ones, binding the structure.

The final result is that the computer-generated

3D model is directly translated into a

physical 3D object. Materials used in powder

bed 3D printing include metals, plastics, ceramics,

synthetic resins, carbon and graphite.

Vacuum mix-dryer and reactor AMT 2000 – the conically shaped mixing vessel and convex

helical blades facilitate the complete discharge of the mixer without segregation

Pictures: Amixon

In particular, 3D printing is the method of

choice when manufacturing products with

complex geometric structures, small batches,

and a high degree of customisation. 3D

printing is also useful in the case of machine

repair, especially to recreate complex parts

that are no longer in production. Even the

mechanical and technological aspects of the

component can be replicated through 3D

printing.

In comparison to more conventional machining

and cutting processes, 3D printing

does not involve a wide range of devices,

castings, or product-specific tools. In many

cases, significant savings can be made in

terms of component volume and material

loss. Furthermore, the process makes it possible

to create complex structures that cannot

be created via casting or machining. So, the

economic efficiency of 3D printing rises in

relation to increasing complexity and decreasing

batch size.

Powder 3D printing process

Powder bed 3D printing proceeds successively,

layer by layer. For each layer of the

structure, a powder bed is first laid to the

desired thickness. Next, a precisely controlled

energy source melts these clusters of

powdery particles into the exact dimensions

of the cross-section. Finally, surplus

powders are removed, ideally to be repurposed

for use in subsequent layers.

In order to achieve a functional end-product,

the powders used in 3D printing must

be adequately stable so that particle size,

bulk density, and rheological characteristics

remain unaffected by the melting process.

At the same time, each step of the process


must take place in quick succession if costefficiency

is to be ensured. Speedy processing

is usually aided by the implementation

of pneumatic conveyance, which can often

lead to a high degree of abrasion. For this

reason, polymer powders used in 3D printing

must be expertly conditioned.

This same challenge applies to selective

laser micro sintering, a 3D manufacturing

process that uses metallic powders. The

metallic materials are laid into the powder

bed by means of a doctor blade, a process

that is often relatively time-intensive. The

flowability characteristics of the materials

play a decisive role in the resulting homogeneity

of the powder bed. The powders

must be as free-flowing as possible, requiring

a spherical particle shape and a narrow

particle size distribution. Additionally, agglomerates

must be eliminated in order to

prevent the formation of laminar or lineal

defects in the finished component. Most

metallic powders used in 3D printing are

cohesive and have a particle size less than

10 μm, meaning they have a tendency to

clump and adhere to the doctor blade or

work surface. While this phenomenon is objectionable,

it is also difficult to avoid.

In order to prevent the formation of unwanted

agglomerates, 3D printing powders

may be coated with nanoscopic additives as

a means of conditioning them. Such a conditioning

process is best performed in an

automated precision mixer or fluidised bed

processor, where clumping and unwanted

agglomerates are less likely to form and the

flowability characteristics of the powders

can be improved.

3-in-1 mixer, dryer and reactor

Mixing, drying, and reacting equipment,

such as the Amixon’s conical mix-dryer type

AMT, plays an important role in powder

metallurgy and the preparation of polymers

for 3D printing. These devices must be incredibly

precise, because it is only possible

to create a nanoscopic coating on each individual

particle by adding the coating agent

to the mixture in minute dosages as a weak

solution or suspension.

Homogeneously integrating coating agents

into bulk ingredients involves creating uniform

levels of moisture within the powder.

In order to achieve this, each and every individual

particle must be wetted. If the

liquid phase is ultimately to be dried, then

the coating will remain evenly distributed

upon the surface of each particle. Ideally the

The AMT conical mix-dryer creates a three dimensional current within the mixing chamber

drying process will take place under a vacuum,

reducing both duration and heat involved.

As a solution to this processing challenge,

vertical mixing equipment that also doubles

as a dryer and reactor can be used. A helical

mixing blade rotates in the centre of the

mixing chamber, generating a three-dimensional

current that conveys its contents upwards

along the periphery before they sink

gravimetrically along the mixing shaft. This

current envelopes the entire volume of the

mixing chamber, making the process completely

free of dead space.

Under these mixing conditions, only a low

rotary frequency is necessary, reducing the

amount of shear to which the particles are

subjected. Every particle moves in relation

to every other particle, flowing constantly

and completely within the mixing vessel.

The evaporation of liquid elements proceeds

by gently warming the powders. Every contact-surface

within the mixer is doublejacketed,

from the walls to the arms of the

helical mixing tool. Heated fluids (thermal

oil, water or vapour) circulate below their

surface.

Almost complete discharge

The ability to clearly separate each batch

and avoid their intermixing is crucial for

batch tracing and quality assurance. Amixon’s

3-in-1 conical mixer, dryer and reactor

type AMT is exemplary in this regard.

The conically shaped mixing vessel and

convex helical blades facilitate the complete

discharge of the mixer without segregation.

In some use cases, preparing powders for

3D printing requires the introduction and

gentle homogenisation of trace amounts of

extremely light flow additives, like pyrogenic

silicon dioxide, to the mixture. Flow

additives are only effective when mixed

gently and homogeneously with bulk

powders and cannot withstand any friction.

The challenge lies in the fact that these light

fractions have a bulk density of 150 g/dm³,

a particle size of 10 μm, and a specific surface

area of 350 m²/g, which explains their

tendency to float to the surface of the

powder mixture. This phenomenon is detrimental

to the mixing process, as it can both

slow down the operation and require a

higher energy input, which may damage

the delicate particle structures.

Special ceramic coatings

Special ceramic coatings are provided when

the mixer or mixer dryer has to keep the

powders free from any metal abrasion during

mixing. The solutions are similar if the

powders are particularly abrasive and the

premature wear of the mixing tools has to

be counteracted. Almost every processing

machine that Amixon manufactures is a

prototype – individual – partly in tiny but

decisive nuances tailored to the requirements

of the respective customer, in a wide

variety of industries.


Online search: Amixon

AUTHOR:

LUDGER HILLEKE

Technical manager and

member of the management

board,

Amixon


Versatile laboratory mixers

Crystal clear

Picture: MTI Mischtechnik

Laboratory mixers with heatable

and coolable mixing vessels

from MTI Mischtechnik are suitable

for the entire scope of bulk

material processing tasks including

the production of trial

mixtures and small-scale production

batches in laboratories

and technology centres. The laboratory

mixer range includes

the type M vertical high-speed

mixers with working volumes

of up to 28 l, heating/cooling

mixer combinations from the

M/KMV series with working

cooling mixer volumes of up to

51 l and the Uni tec type UT

vertical universal mixers with

working volumes of up to 51 l.

On a small scale, they cover the

entire range of conventional

industrial applications from

homogenisation via friction

mixing, coating, agglomeration

and granulation to drying. All

MTI laboratory mixers share the

same plug-and-play layout ensuring

immediate usability and

convenient handling. Various

optional add-ons, such as liquid

addition lances, choppers or

aspiration systems, expand the

range of applications.


Online search: MTI

Melt crystallization - an

effective and economical



Melt crystallization is used to obtain high

purity organic and specialty chemicals

from a variety of chemical solutions.

Key advantages:

Ideal on solutions with close boiling

point components

Does not require additional solvents

Operates at low temperature and

atmospheric pressures

Low energy consumption

Continuous operation

In-house test facilities, comprehensive

technology and process know-how and

customer-oriented service concepts

guarantee the productivity

and performance of your plant.

Screw compressors for jet mills

Aside from steam, jet mills are

most commonly operated using

nitrogen or compressed air. In

the case of the latter, heat energy

can be recovered from the

compressed air inside the jet

nozzles and subsequently reused

for the milling process. Exhaust

heat arises as a by-product of

compressed air generation,

which essentially makes it a

cost-free source of energy.

With the specific needs of jet

milling applications in mind,

Kaeser has now extended the

range of options available for its

two-stage, oil-free compression

rotary screw compressors to include

such features as compressed

air discharge temperature

control. Operating via flexible,

controlled adjustments to

the intercooler, this option can

lead to a clear reduction in specific

energy consumption per

tonne of the final product, depending

on the type of material

being processed.

Kaeser offers the option of compressed

air discharge temperature

control on compressors

from the CSG, DSG and FSG

model range, featuring a power

output from 37 to 355 kW and

pressure from 4 to 11 bar.


Online search: Kaeser

For contact details: gea.com/contact

Picture: Kaeser


Thin film dryer with short residence time

Space-saving articulated robot

In the thin film dryer from

Buss-SMS-Canzler, liquid, pasty

or solid material is continuously

applied by a rotor to the cylindrical

heating jacket in a thin

layer and dried. Advantages are

the low hold-up, the effective

heat transfer and the indirect

drying. Thus, even difficult drying

tasks with problematical

substances can be accomplished

under vacuum. New applications

are constantly being

tested and implemented in industrial

plants. An example is

the production of the monomer

Picture: Buss-SMS-Canzler

2-acrylamido-2-methylpropanesulfonic

acid (trade name

AMPS). It is made from acrylonitrile,

isobutene, fuming sulfuric

acid and water. After the

reaction, unreacted toxic, environmentally

hazardous and

caustic acrylonitrile is separated.

The monomer is then a white

powder. Thin film dryers from

Buss-SMS-Canzler are available

in horizontal and vertical versions.

www.prozesstechnik-online.de

Online search:

Buss-SMS-Canzler

Products for the chemical industry are filled in special

bags, barrels, canisters, cartons or buckets. To palletise

them, Beumer offers the space-saving articulated robot

robotpac. Depending on the packaged items, the company

equips the robot with the appropriate gripping

tools which can be easily and automatically changed, if

the packaged items change. The fork gripper, for

example, was designed specifically for palletising cardboard

boxes, the finger gripper for bagged goods.

Beumer also has a double gripper in its product portfolio

for both versions. The company also offers parallel

grippers for dimensionally stable packed items, suction

grippers for items with a smooth surface and many

other special grippers and combination tools.


Online search: Beumer

Picture: Beumer

Clean as a whistle,

fast as lightning. CMQ.

Flat, smooth mixer head and

a patented wing-shaped mixer

arm – the CMQ series reduces

cleaning times up to 80%.

The result: Highest

performance with first-class

dispersion and ease

of operation.

Quick – clean – safe

Naturally ATEX certified

zeppelin-systems.com

Unbenannt-2 1 01.09.20 13:11



Optical measuring system detects irregularities on bag valves

For clean bags and pallets

If bags aren‘t sealed properly, the product can escape uncontrollably, which can

cause entire pallets to become contaminated. Greif-Velox has therefore developed

the Valvo Detect system as extension for its bagging machines. Two optical sensors

detect irregularities on the bag valves and ensure that the faulty bags are rejected.

Valvo Detect is already being used by the ICL Group at their site in Ladenburg.

The damage caused by contaminated pallets

can result in annual costs for recalls

which hit the five-figure mark. And that’s

not all – depending on which product has

contaminated the pallets, the consequences

can be unpleasant: if it’s bagged chemicals

that cause the contamination, this means

that the applicable safety regulations are

violated.

The ICL Group was also having problems

with contaminated pallets. Safety and cleanliness

are deciding factors in their industry:

ICL is a global manufacturer of mineralbased

products used in agriculture and

technical materials, as well as in the food

industry. At their premises in Ladenburg,

Baden-Württemberg (Germany), the Group

focuses on developing, producing and distributing

additives for paints and coatings

for the cosmetics and construction industries,

as well as on manufacturing highquality

food additives for the food industry.

At this site sodium phosphate is also

packed, a chemical which is used in the

food industry as a sequestrant, acidity regulator,

melting salt or firming agent, among

others.

Valvo Detect is essentially made up of two optical sensors that detect the position of the

bag valve and the welding sonotrodes relative to each other

Pictures: Greif-Velox

Damage due to open bag valves

However, when bagging the product, the

same problem that affects powder producers

across many different industries kept arising

time and again: „Some of the bags were not

properly sealed,“ explains Thomas Jörder,

operations manager at ICL in Ladenburg.

„This led to product escaping from the partially

open valve.“ This meant that customers

from Asia, for example, would send back

entire pallets as the bags were contaminated

from the outside. Not only did this result in

high annual recall costs, but it also caused


immaterial damage, as it meant that customers

were unsatisfied with their delivery.

„It’s a shame when a premium quality

product gets judged by one contaminated

pallet,“ explains Jörder.

Together with his colleague, the operations

manager eventually turned to Greif-Velox

Maschinenfabrik in Lübeck (Germany) to

seek help for their problem. Not only does

Greif-Velox develop and realise bagging machines,

but the company also implements

full-line systems involving conveying, palletisation

and load-securing systems, tailormade

to meet individual customer requirements.

One example is the BVP 4.40 air packer, for

which the Valvomat empty bag applicator

and the Valvoseal ultrasonic sealing unit are

available as extensions. The Valvomat empty

bag applicator can automatically place up to

800 bags onto the filling machine every

hour. After being filled by the air packer, the

Valvoseal ultrasonic sealing unit welds the

bag valves securely and dust-free – generally

speaking. As the example of the ICL Group

shows, there is still a step between automated

placement and ultrasonic welding,

which has to be improved.

Optical measuring system developed

When the responsible employees heard

about the problem with faulty bag seals at

ICL, they worked together with the customer

to map out some ideas. The objective: to

join forces in order to develop a solution

which would be capable of resolving the

problem of faulty seals in this specific instance.

As the experts observed, there are always

bags which are processed incorrectly

when it comes to the valve. These deviations

from the norm mean that it isn’t possible to

automatically place every bag in the exact

correct position on the pneumatic packing

system. „For instance, if valve openings

stick together, the bag will be wonky when

put on the spout,“ explains operations manager

Jörder. „Immediately after filling, the

valve will then be welded shut at an angle.“

Depending on the angle, it can happen that

one side isn’t completely sealed. The consequence:

a small opening through which the

product can escape, ultimately contaminating

the entire pallet during palletisation.

As a solution, Greif-Velox developed Valvo

Detect, a system which comes into play

even before the palletisation stage. Valvo Detect

is an optical measuring system which

detects whether the bag has been placed at

The Valvo Detect system is available as an extension for bagging machines like the BVP 4.40

the correct angle. Should the angle be incorrect,

the system ensures that this bag can be

separated out before palletisation. In this

way, contamination of the entire pallet can

be prevented.

Sensors detect errors

Valvo Detect is essentially made up of two

optical sensors which detect the position of

the bag’s valve in relation to the position of

the Valvoseal sonotrodes. A light sensor will

identify, if the valve is incorrectly placed at

an angle to the sonotrode, which would

make 100 %-seal not possible. As shown in

testing, the optical detection works with

different coloured valves, as well as with

bent valves. If the Valvo Detect system iden -

tifies any irregularities, the filled bag will be

digitally marked and can be separated out.

This system also provides the opportunity

for any rejected bags to be analysed: why

were these bags removed? Are there any

universal deficiencies in bag quality? If

possible, how can the number of rejected

bags be reduced?

„Greif-Velox has now found a solution to

the problem, which is saving us recall costs

in the five-figure mark per year, as well as

lots of man-hours in complaint management,“

says operations manager Jörder. „An

absolute plus for us: at the end of the day,

we also have more customer satisfaction and

a better brand reputation.“


Online search: Greif-Velox

AUTHOR:

DR. ALEXANDER

MILDNER

Head of research and

development,

Greif-Velox




Fully automated filling technology for a large storage facility

New installation during

operation

An importent step when installing a new system in a complex industrial plant is the

commissioning. This is often the first time the individual machines are connected and

all process steps can be carried out together. SMB International has realised such a

complex project for LBC Tank Terminals, an independent operator of midstream and

downstream storage facilities for bulk liquid goods such as oils.

At a Belgian seaport, LBC Tank Terminals

mainly stores base oil, which is used for the

production of petroleum products. At the

end of 2019, the company decided to build

a new filling plant at the Antwerp site. SMB

International, a German planner and manufacturer

of customised plants, received the

order to install a fully automatic system,

from drum feeding, filling and palletising to

truck loading, and to supervise the project

from planning to commissioning on site.

A perfectly matched system

For the construction of plants of this size

and complexity, different technologies have

to be combined whose processes must be

precisely coordinated. This is the only way

to achieve a fully automatic filling process.

The starting situation for this project was

good: the existing hall and filling system at

LBC Tank Terminals in Antwerp were demolished

in order to build a new one on the

same site. This permitted to build a completely

new, automated plant consisting of

two line filling systems for drums with

matched palletisers and stretch wrappers, as

well as, an IBC filling system with matched

conveyor technology there. In order to be

able to continue the filling of bulk liquids

during the construction process, the old

systems were temporarily installed in another

building. SMB International had a total

of eight weeks for the installation and commissioning

of the system. To ensure efficient

implementation, all systems were set up at

SMB’s factory as far as possible and central

tests were carried out there, too. Nevertheless,

commissioning at the customer’s site is

still a decisive step, especially for fully automated

systems. All interfaces between the

individual components must function

smoothly.

The filling system in detail

SMB’s line filling systems are used for the

fully automatic, continuous filling of larger

quantities. With a total storage capacity of

almost 300,000 m 3 , this type of system was

exactly the right choice for LBC in Antwerp.

Different designs of the line filling system

allow the filling of drums, cans, canisters or

Pictures: SMB International

Central test in the factory: Jens Hachmann and Jan-Hendrik Woldt from SMB International

during the last check of the two line filling system before transport to Antwerp


OUR ENGINEERING IS

YOUR SYSTEM SOLUTION

Empty barrels are fed fully automatically to

the filling system with the aid of conveyor

technology

buckets via one or several filling points. In

the new 1,150 m 2 building at the Belgian

location, drums and intermediate bulk containers

(IBC) are filled fully automatically.

The first interface that had to be set up during

commissioning is the feeding of the two

container types. The empty drums are unloaded

automatically from three swap body

positions by an automatic drum unloader

and then fed to the filling system by means

of conveyor technology. Empty IBCs are,

however, placed on a roller conveyor outside

of the building by forklift trucks. In a next

step, the containers are then automatically

labelled and filled. The two vacuum palletisers

from SMB International are an ideal

supplement for the filling system. After filling,

the drums are lifted by means of a vacuum,

placed on pallets and then secured

with film.

Integration of an old system

SMB hat already successfully installed filling

systems, palletisers and stretch wrappers
