EDITORIAL<br />
Die-casting in focus!<br />
EUROGUSS trade fair will be taking place in Nuremberg in mid-January<br />
of next year. Most likely again with an international participation of<br />
more than 50 percent. Overall, the number of exhibitors has risen to<br />
more than 700 – who will show their innovations for the first time in<br />
four fully occupied exhibition halls.<br />
Robert Piterek<br />
e-mail: robert.piterek@bdguss.de<br />
Now, at the end of December,<br />
die casters have to consider two<br />
major upcoming events: the New<br />
Year and the EUROGUSS fair in mid-<br />
January. While the orders situation in<br />
the foundry industry for die-casters is<br />
still mostly satisfactory, iron foundries<br />
are coming under increasing pressure.<br />
Some companies, such as the Norican<br />
Group, therefore have drawn conclusions<br />
during recent years and purchased<br />
companies from the non-ferrous segment,<br />
such as furnace manufacturer<br />
Striko Westofen and die-casting machine<br />
constructor Italpresse. This increasingly<br />
shifts the material preference of the<br />
corporate group (based in Denmark)<br />
towards aluminum. In an interview with<br />
CP+T, DISA President Peter Holm Larsen<br />
discusses the strategic realignment of<br />
his parent company.<br />
This issue also offers other widerang<br />
ing articles on the topics of diecasting<br />
and light-metal casting: about<br />
digitalization in furnace construction,<br />
for example, or about strategic prospects<br />
such as the future of die-cast<br />
structural components. We also take a<br />
look at a user example of a very promising<br />
blast ing method for aluminum castings.<br />
The company report about the<br />
globally active die-casting plant constructor<br />
Oskar Frech, which celebrated<br />
its 70th jubilee this year, is particularly<br />
interesting. Frech is a successful example<br />
of a strong family-led SME – the<br />
backbone of German industry. A wealth<br />
of inventiveness and corporate courage<br />
enables Frech to withstand global competition<br />
with international groups. The<br />
Swabian company from near Stuttgart<br />
has also played its part in maintaining<br />
the very good reputation of ‘Made in<br />
Germany’ throughout the world.<br />
Last but not least, this issue also has<br />
an interesting story about the Lütgemeier<br />
foundry. It casts components for<br />
vehicle tuner Brabus using 3-D-printed<br />
molds. This therefore successfully combines<br />
the new technology of additive<br />
manufacturing with casting. it is regrettable<br />
though that the very successful<br />
international additive manufacturing<br />
trade fair Formnext in Frankfurt/Main<br />
at the end of November did not really<br />
show many examples of this successful<br />
collaboration between the two worlds.<br />
Have a good read and perhaps we’ll<br />
meet soon at EUROGUSS!<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 3
CONTENTS<br />
FEATURES<br />
6 INTERVIEW<br />
“The acquisitions strengthen our<br />
aluminum expertise“<br />
Interview with Peter Holm Larsen, COO and President<br />
of the Norican brand DISA. Robert Piterek<br />
8 MELTING SHOP<br />
Induction furnace control<br />
by virtual machines<br />
The iron foundry Adam Hönig AG improves<br />
transparency with a new data management system.<br />
Erwin Dötsch, Dietmar Mitschulat, Pierre Hacquin<br />
Melting furnace 4.0 – Thinking ahead,<br />
developing further, moving on<br />
Sensors and progressive automation at temperatures<br />
up to 900 °C: Future-proof melting operation<br />
thanks to long-term R&D projects. Sven-Olaf Sauke<br />
INTERVIEW<br />
Peter Holm Larsen:<br />
„Our aim is to connect<br />
all parts of the<br />
foundry and visualize<br />
it for the customer.”<br />
MELTING SHOP<br />
Via an app on a smart<br />
phone, the iron<br />
foundry Adam Hönig<br />
from Kempten saves<br />
energy and resources.<br />
18 DIGITALIZATION<br />
Foundry Group pioneers data-driven<br />
productivity project<br />
Partnership sees foundry business make multi-site<br />
monitoring a reality. Rudi Riedel<br />
21 PRESSURE DIE CASTING<br />
The future of structural components in HPDC<br />
Structural components offer a considerable light<br />
weight construction potential.<br />
Herman Jacob Roos, Martin Lagler, Luis Quintana<br />
FETTLING AND<br />
FINSHING<br />
Romain Zorzi, Project<br />
Manager New Processes,<br />
introduced a new<br />
rubber belt tumble<br />
blast machine for aluminium<br />
castings at<br />
the SEW Usocome<br />
plant in France.<br />
Cover-Photo:<br />
Fotolia<br />
4
CONTENTS<br />
LOGISTICS<br />
Fondium‘s iron<br />
foundry in Singen has<br />
a new forklift fleet.<br />
26 PRESSURE DIE CASTING<br />
Castings for light-weight engineering<br />
Cast iron and aluminium alloys as alternatives for<br />
thin-section steel castings.<br />
Wolfgang Knothe<br />
30 RECYCLING<br />
Recycling – certainly safely!<br />
The GreCon spark extinguishing system sees to a<br />
safe production at Siegfried Jacob Metal Works.<br />
Denis Sauerwald<br />
32 FETTLING AND FINISHING<br />
Automated blasting of aluminium castings<br />
A joint project in the area of surface technology<br />
led to an automated blasting cell for mass-produced<br />
castings. Ulf Kapitza<br />
36 LOGISTICS<br />
Forklift fleet keeps the castings moving<br />
The industrial trucks at Fondium’s production<br />
works in Singen have been brought up-to-date by<br />
forklift expert Still. Gerd Knehr<br />
40 COMPANY<br />
70 years is not enough<br />
The family-rund Oskar Frech group turned 70 this<br />
year. Its secret of success: Inventiveness and entrepreneurial<br />
courage. Robert Piterek<br />
46 3-D PRINTING<br />
COMPANY<br />
To compete successfully<br />
on the market<br />
inventiveness is<br />
essential for the<br />
Oskar Frech group.<br />
3-D-PRINTING<br />
Lütgemeier GmbH<br />
casts metal parts for<br />
car tuner Brabus<br />
using 3-D printed<br />
molds.<br />
With the turbo from the 3-D printer<br />
to 900 hp<br />
Vehicle technology manufacturer Lütgemeier in creases<br />
flexibility and productivity using Voxeljet‘s<br />
VX1000 3-D-printing system to supply high-performance<br />
car tuner Brabus. Frederik von Saldern<br />
COLUMNS<br />
3 EDITORIAL<br />
50 EUROGUSS NEWS<br />
52 NEWS IN BRIEF<br />
57 NEW: SUPPLIERS GUIDE<br />
76 FAIRS AND KONGRESSES/AD INDEX<br />
78 PREVIEW/IMPRINT<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 5
INTERVIEW<br />
6
“Today you have to be very agile and close<br />
to the action, because the world is turning<br />
faster and faster.“<br />
Peter Holm Larsen has been working for the Norican<br />
Group since 2007 and is currently COO and President of<br />
the molding machine manufacturer DISA, who is part<br />
of the group<br />
„The acquisitions strengthen our<br />
aluminum expertise“<br />
At GIFA in June the Danish Norican Group presented itself for the first time with its four<br />
brands DISA, Wheelabrator, StrikoWestofen and Italpresse-Gauss. News at the stand was<br />
the networked foundry and zero-defect-management. In an interview with CP+T, Peter<br />
Holm Larsen, COO and President of the Norican brand DISA, talks about the enlarged<br />
group, the digitization and the outlook for the coming years.<br />
Photos: Martin Vogt/BDG<br />
Why did you buy so many companies?<br />
What is the big plan behind it?<br />
Until two years ago only DISA and<br />
Wheelabrator belonged to the Norican<br />
group. We have completely focused on<br />
iron casting. Although Wheelabrator<br />
also had other business units, it was<br />
mainly focused on cast iron. And DISA<br />
has been supplying plants to iron<br />
foundries for some 60 years. At the<br />
same time, DISA has always worked<br />
closely with the automotive industry<br />
and is increasingly moving towards aluminum.<br />
This trend – we all agree on<br />
that – will continue. Our group is part<br />
of a private equity fund, but regardless<br />
of that, our companies need to grow in<br />
their market. To strengthen Norican<br />
Group‘s aluminum capabilities, we<br />
acquired StrikoWestofen and Italpresse<br />
Gauss two years ago. Although we are<br />
now operating in two different material<br />
areas, if you look at the business<br />
dynamics of these industries you will<br />
see that there are many similarities.<br />
There are also some similarities in the<br />
technologies. And of course it is our<br />
intention to invest all our power in the<br />
company in the development of our<br />
brands.<br />
How will production become more<br />
efficient through the digital foundry<br />
you have developed?<br />
The conversation<br />
with Peter Holm<br />
Larsen took place<br />
at Norican’s GIFA<br />
stand.<br />
Our aim is to connect all parts of the<br />
foundry and then to visualize it for the<br />
customer via our cockpit. By having<br />
insight into all processes, they can be<br />
optimized. One can see where the processes<br />
fail and is able to fix the mistakes.<br />
Take the refill monitor, where a<br />
worker on the forklift with the ladle<br />
can see the level of the various furnaces<br />
to fill them up in time. So the furnaces<br />
cannot idle. This improves the<br />
availability of the customer with a very<br />
simple solution. You can reduce the<br />
downtime of the production line and<br />
the reject rate and use the data stored<br />
in the cloud for process optimization.<br />
Where will the Norican Group stand in<br />
10 years?<br />
We used to make strategic ten-year<br />
plans. But those times are over. Today<br />
you have to be very agile and close to<br />
the action, because the world is turning<br />
faster and faster. At the end of<br />
the day, it‘s all about understanding<br />
how to improve the customer‘s performance<br />
with technical solutions. Will we<br />
buy other companies in the next few<br />
years? Yes, I think so, because there are<br />
still many technologies that fit our<br />
business. But we will not go far from<br />
our core business in the foundry industry.<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 7
MELTING SHOP<br />
Photos and graphics: Kemptener Eisengiesserei and ABP Induction<br />
engineering industry.<br />
Induction furnace<br />
control by virtual machines<br />
As an important step towards Industry 4.0, the iron foundry Adam Hönig AG, based in<br />
Kempten, Germany, has introduced a data management system which makes the foundry’s<br />
wide and varied production processes more transparent – by means of an App on a<br />
smart phone. Through the consistent acquisition and evaluation of the process data, the<br />
foundry saves significantly on energy and material use.<br />
Introducing the data management system<br />
placed extremely exacting<br />
demands on the control system of the<br />
two induction furnace tandems operated<br />
by the foundry. Here the melting<br />
processor Prodapt Enterprise supplied<br />
by the German induction furnace manufacturer<br />
ABP and operating in combination<br />
with virtual systems and an inhouse<br />
server left nothing to be desired.<br />
Erwin Dötsch, Dietmar Mitschulat, ABP Dortmund, and Pierre Hacquin, Adam Hönig AG, Kempten<br />
Kemptener Iron Foundry<br />
A family-managed company for more<br />
than 60 years, Kemptener Eisengießerei<br />
Adam Hönig AG (KE) (Figure 1), produces<br />
iron castings and provides advice<br />
in casting design mainly for mechanical<br />
engineering companies. Adam Hönig is<br />
a contract foundry with its own mouldmaking<br />
lines. Grey and ductile iron castings<br />
with item weights ranging from<br />
Treatment of a melt at the iron foundry Adam Hönig.<br />
A contract foundry with pattern making facilities and<br />
provider of casting design consultation, Adam Hönig<br />
manufactures iron castings mainly for the mechanical<br />
just a few kilograms up to and including<br />
8.5 t are produced as single pieces<br />
or in small and medium series in a<br />
hand-moulding shop or in automatic<br />
moulding lines (Figure 2). The sheer<br />
number of 6,000 to 7,000 different patterns<br />
gives an idea of the great variety<br />
of products. Figure 3 shows two impressive<br />
examples of medium-weight castings.<br />
At the foundry, 170 employees<br />
8
Figure 1: Adam<br />
Hönig Iron Foundry<br />
is based in Kempten,<br />
in the south of Germany.<br />
Figure 2: Casting of<br />
a machine bed<br />
weighing 8.5 t.<br />
Figure 3: Structural parts made of<br />
EN-GJS-400-15, each weighing 484 kg.<br />
produce about 1,000 t of good castings<br />
per month. Adam Hönig is certified<br />
according to DIN EN ISO 9001: <strong>2019</strong> and<br />
commits to high quality and environmental<br />
standards.<br />
The great number of different grades<br />
and casting weights calls for highly<br />
flexible meltshop equipment, such as<br />
the two induction furnace tandems<br />
from ABP, which both fully meet this<br />
requirement. Tandem 1 consists of two<br />
3-t crucible furnaces, type ITMK 6000,<br />
and a 1,800 kW/250 Hz converter for<br />
the power supply. The second tandem<br />
consists of two 6-t crucible furnaces,<br />
type FS 60 (Figure 4), and a 3,500<br />
kW/250 Hz converter. Both tandems are<br />
equipped with the TwinPower system<br />
which enables the power to be distributed<br />
– by electronic means - in any desired<br />
ratio between the two furnaces of a<br />
tandem [1].<br />
The meltshop is a one-shift operation.<br />
At the end of a shift, when the last<br />
heat has been tapped, the hot crucible<br />
is charged for the first heat of the next<br />
production shift, and left to cool down<br />
to near room temperature. The next<br />
morning at six o’clock, the melting operation<br />
is resumed. For this purpose, starting<br />
at 3 o’clock in the morning, the<br />
cold 6-t furnaces are automatically switched<br />
on to be heated up in the cold<br />
start-up mode, which raises the furnace<br />
temperature linearly to 1,000 °C. For<br />
the 3-t furnaces the heating program<br />
starts at 4 o’clock. In this way, by 6<br />
o’clock, all furnaces are ready for<br />
full-power operation with the charge<br />
having reached a temperature of<br />
1,000 °C.<br />
Developments at Adam Hönig<br />
towards Industry 4.0<br />
With the support of the Kempten University<br />
of Applied Sciences and funding<br />
by the German Federal Environmental<br />
Foundation, Adam Hönig has<br />
developed a data management system<br />
designed to make the production process<br />
more transparent and optimize the<br />
processes in order to reduce energy and<br />
material use [2]. This entails the acquisition<br />
and evaluation of process data<br />
from the charge make-up and mould<br />
making down to the shake-out. The<br />
digital monitoring process is performed<br />
via a smart phone app. Bar code labels<br />
attached to the ladles and flasks, for<br />
example, are scanned by the staff and<br />
the information is sent to a database<br />
(Figure 5). In this way, it is possible to<br />
track what mould was filled at what<br />
time with what alloy. This information<br />
can be used to speed up, for example,<br />
the production of castings of high priority<br />
without having to increase the production<br />
capacity. Additionally, it can be<br />
used to further enhance the energy and<br />
resource efficiency because by optimizing<br />
the sand-metal ratio it can be assured<br />
that only exactly the quantity of<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 9
MELTING SHOP<br />
Figure 4: The 6 t/3500<br />
kW induction furnace<br />
tandem of type ABP FS<br />
60.<br />
Figure 5: Scanning a<br />
bar code on a flask.<br />
Process data<br />
acquisition<br />
Terminal Terminal Terminal<br />
Charge<br />
make-up<br />
3-t tandem<br />
6-t tandem<br />
Virtual system<br />
Charge make-up<br />
Virtual system Control<br />
of melting furnace<br />
Virtual system Control<br />
of melting furnace<br />
Virtual system<br />
Process data<br />
Thermal<br />
analysis<br />
Scale<br />
for ladle<br />
treatment<br />
Scale for<br />
alloying<br />
elements<br />
Spectrometer<br />
Figure 6:<br />
Hardware concept of<br />
the meltshop control<br />
system.<br />
metal needed for the respective casting<br />
will be used, not more.<br />
The specific energy consumption of<br />
the melting furnaces of 611 kWh per t<br />
of molten metal is another positive<br />
result of the data management system.<br />
This value has to be considered in relation<br />
to the fact that the meltshop is run<br />
as a one-shift operation and that the<br />
production range is extremely diversified.<br />
The fact that the furnaces have to<br />
be heated up every day from room<br />
temperature means that also the heat<br />
stored in the refractory material has to<br />
be input every day anew. A second<br />
aspect to be considered is that whenever<br />
the quantities of molten metal needed<br />
for a production order are greater<br />
than the furnace capacity, long holding<br />
times are unavoidable. Against this<br />
backdrop, an energy rate of slightly<br />
above 600 kWh/t is a good value, achieved<br />
thanks to the enhanced transparency<br />
of the production process and of<br />
the associated logistics.<br />
In this context, the control of the<br />
melting furnaces plays a key role. Here<br />
the installation of the ABP control system<br />
Prodapt Enterprise in connection<br />
with an inhouse, virtual-system-based<br />
server has made the meltshop ready<br />
and fit to cope with the exacting requirements<br />
placed on it by the new data<br />
management system.<br />
Control by means of<br />
virtual systems<br />
Foundries often use PC systems that<br />
have larger capacities than actually needed.<br />
This means resources remain unused.<br />
In other words, the operating costs<br />
are higher than necessary. A way out of<br />
this unsatisfactory situation is the use of<br />
virtual systems as implemented at Adam<br />
Hönig. Here use has been made of a<br />
dedicated software that simulates hardware<br />
functions and generates virtual<br />
computers, thus enabling several computers<br />
with different operating systems<br />
to be run on one server. This leads to<br />
more efficient server utilization and to<br />
a higher availability of the applications<br />
because the risk of hardware failure<br />
decreases. Figure 6 shows the hardware<br />
concept for the meltshop operations at<br />
Adam Hönig.<br />
Virtual machines and the respective<br />
control systems for the various meltshop<br />
functions are installed on a central<br />
server. Data exchange between the<br />
applications on the virtual machines<br />
and the field components is via TCP/<br />
IP-based protocols. Should any of the<br />
field components not be networkable,<br />
they will be expanded by a device that<br />
allows them to be connected with and<br />
integrated into the data exchange system<br />
via a connector software.<br />
Thus it is possible to capture basically<br />
all process-relevant data of the<br />
various meltshop functions, store it in a<br />
database where the data is available for<br />
cross-functional analyses that make the<br />
production process of each and every<br />
casting traceable all the way back.<br />
Monitoring these production data<br />
enables the foundry to detect faults at<br />
a very early stage so that efficient countermeasures<br />
can be taken early on.<br />
Modern plants and equipment<br />
monitor themselves autonomously and<br />
send out messages to the plant operator<br />
as soon as the equipment leaves its<br />
normal operating range. For this rea-<br />
10
Figure 7: Monitor-based control of the meltshop operations.<br />
son, the data monitoring was expanded<br />
to include the furnace and converter<br />
cooling circuits as well as the<br />
cooling station. The acquired data can<br />
be exchanged between the plant operator<br />
and the plant manufacturer, constituting<br />
another important step in the<br />
implementation of rule-based plant<br />
monitoring.<br />
The melting process is controlled by<br />
the Prodapt Enterprise melting processor,<br />
which will be described below in<br />
further detail. The charge calculator<br />
determines the composition of the<br />
charge based on the formulated recipe<br />
and transmits the data to the automatic<br />
charge make-up crane. The crane fills<br />
the calculated quantities of ferrous<br />
charge material into the charging car.<br />
The charge is then filled into the crucible<br />
in the specified quantities and<br />
melted. At the same time, the additives<br />
are manually charged from the furnace<br />
platform into the crucible in the quantities<br />
determined also by the charge calculator.<br />
At the end of the melting process<br />
a sample is taken and analyzed by a<br />
spectrometer. The result is compared<br />
with the target analysis in the charge<br />
calculator. From this comparison the<br />
additives needed for the correction of<br />
the charge are calculated and brought<br />
to the furnace platform. This process<br />
also takes into account the calculations<br />
of the additives to be added during<br />
ladle tapping, which are kept on the<br />
casting floor.<br />
In addition to the spectrometer analysis,<br />
random thermal analyses are performed<br />
to verify the quality of the melt.<br />
This is done by measuring the C and Si<br />
contents, and the K factor as a measure<br />
of the nucleation status of the melt.<br />
Prodapt Enterprise melting<br />
processor<br />
The Prodapt Enterprise processor from<br />
ABP is a solution that enables all meltshop<br />
operations to be controlled with<br />
one consistent system. It supports the<br />
furnace operator during the furnace<br />
modes sintering, melting and cold<br />
start-up. The process diagrams on the<br />
monitor inform the operator immediately<br />
and in great detail about the status<br />
of the melting process, imminent incidents<br />
and the current measured values<br />
(Figure 7). This achieves highly efficient<br />
furnace operation, and increases the<br />
availability and operating security of<br />
the meltshop.<br />
The process visualization allows the<br />
user – while viewing the current data<br />
- to also access the chronology of the<br />
measured values by a simple mouse<br />
click. Additionally, instructions for<br />
action in graphical or text form can be<br />
assigned to the individual messages<br />
from the fault alarm system.<br />
Figure 8 shows, as an example, the<br />
screen view of the 6-t tandem with furnaces<br />
3 and 4. This view appears on the<br />
monitor at the operating pulpit when<br />
the melting process is running smoothly.<br />
The operator receives – in a clearly<br />
structured view - all necessary information<br />
about the current process status of<br />
the two furnaces. The large numbers<br />
indicate – from the top to the bottom:<br />
furnace weight in kg, melt temperature<br />
in °C, power input in kW. The horizontal<br />
bar (under the illustration of the furnace)<br />
indicates the crucible wear, an<br />
aspect that will be covered below sepa-<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 11
MELTING SHOP<br />
Figure 8: General view of the furnaces of the 6-t tandem.<br />
rately. The boxes under the green bar<br />
contain the charge number, the material<br />
number and an ID number for the<br />
operator. The vertical, orange bar is an<br />
indicator of the current power.<br />
By unmistakably relating the charge<br />
and the corresponding melt via the<br />
charge make-up number and the melt<br />
number, Prodapt Enterprise complies<br />
with the requirement of making the<br />
melting process traceable. Additionally,<br />
all treatment activities performed on the<br />
furnace are logged. The log protocol stores<br />
the general data of the melt and all<br />
treatment-related activities minute-wise.<br />
The treatment-related activities include<br />
the heating process and activities such as<br />
the taring of the scale, temperature<br />
measurement and the tappings. For each<br />
activity, related data such as time, duration,<br />
furnace content and melt temperature,<br />
are stored. The parameters of the<br />
selected steel grade and the measured<br />
analysis values are archived in the process<br />
database.<br />
In addition to the process data, Prodapt<br />
Enterprise visualizes the current status<br />
of the cooling, hydraulics and energy<br />
supply systems. In case any limits are<br />
exceeded or abnormal incidents occur,<br />
this is indicated by changing the colour<br />
of the respective value boxes or the corresponding<br />
icons. Let’s describe the furnace<br />
cooling system as an example of<br />
these detailed process views (Figure 9).<br />
The acquired data is displayed in a<br />
schematic illustration of the plant. The<br />
measured value boxes indicate not only<br />
the current value but also any exceeding<br />
of limits by a color change. By clicking<br />
on a box, the evolution of the<br />
value over the past eight hours can be<br />
viewed. The icons are animated, i.e. different<br />
colours indicate different statuses.<br />
Additionally, the system captures<br />
the water temperatures and quantities<br />
for each individual cooling circuit. Any<br />
deviations from trends generate warnings<br />
that are automatically transmitted<br />
to the maintenance staff.<br />
Swift and targeted reaction to incidents<br />
is essential for a high availability<br />
level of the meltshop. Any incident is<br />
firstly indicated in clear text in the head<br />
line of the process diagrams. The messages<br />
are displayed in different colours<br />
depending on how they are classified.<br />
This information is complemented by<br />
the “switch off” sub-view, which lists all<br />
incidents that may lead to the switchoff<br />
of the plant or the respective furnace.<br />
The explicit notes in the sub-view<br />
make it easy for the operator to assess<br />
the severity of an incident. Additionally,<br />
the responsible operator will be notified<br />
about the incident by text message.<br />
This has proved very useful especially<br />
during the times outside the shifts, e.g.<br />
during the nights, when the cold furnaces<br />
are being restarted automatically.<br />
Monitoring of the crucible wear<br />
In order for the meltshop to operate<br />
smoothly, monitoring of the crucible is<br />
of paramount importance. After tapping,<br />
when the wall surface is still dark<br />
red, the crucible is visually inspected. In<br />
addition to the visual inspection,<br />
> the resistance between a contact<br />
established to the moltenmetal and<br />
a coil is checked (earth-fault indicator),<br />
> the active power and frequency are<br />
measured and the results evaluated<br />
by means of Prodapt Enterprise.<br />
While the method based on earth-fault<br />
indication is extensively described in the<br />
literature [3], we here describe in greater<br />
detail the second method, which is<br />
based on the use of Prodapt data. Information<br />
about the crucible wear is derived<br />
from the change in coil inductance<br />
as a result of a change in the distance<br />
from the molten metal. Both the active<br />
power and the frequency increase when<br />
the wall thickness decreases. During<br />
every melting of a charge, the frequency<br />
is measured. The measurements<br />
take place under uniform conditions,<br />
i.e. with the furnace completely filled<br />
and at a defined temperature. Based on<br />
the result of the measurement, a wear<br />
index is calculated from the given<br />
power in each individual case and from<br />
the ratio between the actual voltage<br />
and the nominal voltage.<br />
The measured frequency values and<br />
the wear index are plotted as curves<br />
over time for the duration of a lining<br />
life. Figure 10 shows, as an example, the<br />
12
Figure 9. Detail view of the furnace cooling circuit.<br />
measurement curves for several crucible<br />
campaigns. At the end of the crucible<br />
campaign, the recorded curves are compared<br />
with the actual wear condition of<br />
the crucible and correlated. In this way,<br />
it is possible to derive - from the characteristics<br />
of these curves - the expected<br />
duration of a crucible campaign and the<br />
time at which a reline will become<br />
necessary.<br />
The advancing wear is clearly visualized<br />
in the process screen views, as<br />
shown in Figure 8. The measured frequency<br />
and the wear index are represented<br />
by the length of the green horizontal<br />
bar. When the crucible has been<br />
freshly relined, the green bar is completely<br />
filled. The length of the bar decreases<br />
as the crucible wall becomes thinner.<br />
The green bar disappears completely<br />
when the minimum wall thickness has<br />
been reached.<br />
The information derived from this<br />
signal has always an “integral” meaning.<br />
For physical reasons, the described<br />
method of determining the wall thickness<br />
based on characteristic measured<br />
values always refers to the complete<br />
crucible in the area of the active coil.<br />
Any localized lining wear, such as an<br />
“elephant’s foot” or annular erosions,<br />
are detected during the regular visual<br />
inspections of the empty, red-hot crucible.<br />
In combination with these visual<br />
checks, the “integral” system assures a<br />
reliable and straightforward assessment<br />
of the crucible wear.<br />
Figure 10: Detail picture of a crucible wear diagram (red: course of the frequency,<br />
blue: course of the wear number).<br />
Outlook<br />
While we have already achieved many<br />
important benefits from the consistent<br />
data management so far, there is more<br />
potential available. To tap this potential,<br />
we, the plant operator, work closely<br />
with the plant manufacturer. It<br />
may become possible, for example, to<br />
use the results from the thermal analysis<br />
more efficiently for an enhancement<br />
of the melt quality. It is also conceivable<br />
to develop algorithms from<br />
the available data, which facilitate and<br />
help to further enhance the coordination<br />
between the meltshop and the<br />
mouldmaking staff, making processes<br />
even more efficient. Another conceivable<br />
function would be to determine<br />
where in the process chain specific<br />
quality features are influenced and –<br />
vice versa - to correlate these features<br />
with specific instances of the process<br />
chain. Based on the acquired process<br />
data and the evaluation of tolerances,<br />
deviations in the production process<br />
may be used to identify weaknesses,<br />
for example, by means of automatically<br />
generated algorithms specifically<br />
designed for the requirements of<br />
foundry processes.<br />
www.abpinduction.com<br />
www.ke-ag.de<br />
References:<br />
www.cpt-international.com<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 13
MELTING SHOP<br />
14
Demonstrator for a measuring technique for the sensor<br />
detection of the furnace chamber.<br />
Melting furnace 4.0 - Thinking<br />
ahead, developing further,<br />
moving on<br />
Sensors and progressive automation at temperatures up to 900 °C: Future-proof<br />
melting operation thanks to long-term R&D projects<br />
Sven-Olaf Sauke, head of R & D at ZPF GmbH, Siegelsbach<br />
Photos: zpf<br />
The future is moving inexorably<br />
towards smart factories, but many<br />
smelting plants are still stuck with<br />
their assembly line production in industry<br />
2.0 without IT support. Central elements<br />
of a modern factory of the 21st<br />
century, such as the interface to a central<br />
database server or an intelligent, yet<br />
heat-resistant automation including<br />
sensor technology enabling all facilities<br />
to communicate with each other, are<br />
frequently not available. Although<br />
there are numerous protocols for this<br />
purpose, the possibility of retrofitting<br />
these protocols standards does not exist<br />
in many older facilities. A lack of expenditure<br />
resources and the absence of visions<br />
for the future have often led to<br />
missed opportunities. Therefore, research<br />
strategies that build on each other<br />
are always recommended in order to<br />
keep up with the times. Only in this way<br />
can a smelting plant face the numerous<br />
challenges of the future in the long<br />
term. ZPF GmbH has been investing for<br />
years in close cooperation with various<br />
universities, supported by the German<br />
Federal Ministry for Economic Affairs<br />
and Energy (BMWi) and other research<br />
sponsors, in order to meet the current<br />
requirements of the industry and create<br />
a basis for innovative products.<br />
A major challenge in industry 4.0 is<br />
currently the automation of so-called<br />
predictive maintenance. In this process,<br />
the machine park is monitored on an<br />
ongoing basis and throughout the<br />
entire process (continuous system monitoring)<br />
to perform condition-based<br />
maintenance work. In a Smart Factory<br />
Moveable burner system that can be continuously aligned to the melting charge via the recorded<br />
measurement data and thus increases the efficiency of the overall system.<br />
with a melting furnace, for example,<br />
cleaning could be carried out by a robot<br />
that knows all the parameters of a furnace<br />
and can take action in good time<br />
already before a critical degree of contamination<br />
is reached. Consequently, the<br />
robot automatically prevents a later<br />
complete breakdown of the system and<br />
a standstill of the entire machine park<br />
in just a few minutes.<br />
However, as long as there is no suitable<br />
and at the same time safe sensor<br />
technology that can withstand the extremely<br />
high temperatures, these essential<br />
parameters cannot be recorded,<br />
even though they are the basis for<br />
industry 4.0. In order to master these<br />
complex automation tasks, the entire<br />
factory needs extensive knowledge of<br />
all important plant data - from the filling<br />
level of the furnace to the degree<br />
of contamination in the bath area. For<br />
this reason, ZPF, for example, has<br />
already laid the foundations for solutions<br />
for intelligently networked melting<br />
furnaces through various research<br />
projects in the past.<br />
Enoptal – from refractory materials<br />
to burner technology<br />
At this point, the ZPF project „Enoptal“<br />
serves as an example for the beginning<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 15
MELTING SHOP<br />
of such a research chain. As a result of<br />
the climate policy surrounding Directive<br />
2009/29/EC, aluminium producers and<br />
processors with a total rated thermal<br />
input of 20 MW had to limit their CO 2<br />
emissions from 2013 and purchase new<br />
certificates if necessary. This put pressure<br />
on companies in the aluminium<br />
industry to find timely solutions for<br />
lower CO 2<br />
emissions. Following this,<br />
more investment was made in the<br />
development of efficient burner technology<br />
to reduce energy costs and<br />
reduce the impact of greenhouse gases<br />
on the environment. The charging<br />
methods and cleaning intervals of the<br />
furnaces as well as the melting losses<br />
were examined and the influence these<br />
parameters have on the critical emission<br />
values.<br />
The research project „Enoptal“ was<br />
funded by the German Federal Ministry<br />
for Economic Affairs and Energy, supervized<br />
by the Project Administrator<br />
Jülich, conducted together with the<br />
Technical University Bergakademie Freiberg<br />
and successfully completed in<br />
2011. With the help of various field<br />
tests, the essential parameters of a melting<br />
and holding furnace with a melting<br />
capacity of 300 kg/h and a holding<br />
capacity of 700 kg were determined<br />
and optimization potential was identified<br />
for the refractory material and the<br />
burner arrangement resulting in energy<br />
savings of up to 10 percent. These fundamental<br />
results formed the basis for<br />
the next major research project.<br />
Edusal-I + II – from burner technology<br />
to sensor technology<br />
As the next step in this research chain,<br />
the melting plant together with other<br />
plant components was at the centre of<br />
the task in order to optimize the entire<br />
furnace system. The aim was to search<br />
for further energy saving potentials in<br />
melting processes with aluminium, to<br />
minimise melting loss, to improve process<br />
monitoring and to create the basis<br />
for a modern and efficient heat recovery<br />
system.<br />
Since the field of „measurement<br />
technology“ in particular has large<br />
gaps, the possibilities for a system for<br />
monitoring and control were examined<br />
in cooperation with the Federal Ministry<br />
for Economic Affairs and Energy,<br />
the Technical University Bergakademie<br />
Freiberg and the Leibniz University of<br />
Hanover. The focus in the projects<br />
„Edusal-I and II“ was mainly on the<br />
development of a measuring technique<br />
for the sensory detection of the furnace<br />
chamber.<br />
In some areas, water-cooled, optical<br />
systems are used for furnace interior<br />
monitoring – for example after the<br />
repair of glass troughs. Although these<br />
provide an insight into the condition<br />
of the refractory lining and other process<br />
parameters, for safety reasons<br />
they cannot be used in rough everyday<br />
operation or must not be used by operators<br />
of aluminium melting plants. If<br />
such a system is damaged and the<br />
water is unintentionally heated from<br />
20 °C to 900 °C, the sudden change in<br />
volume of the water can lead to explosions<br />
and thus to serious damage to<br />
property and persons. For the first<br />
time, the measurement method<br />
developed with the associated software<br />
made it possible to precisely<br />
determine the amount and position of<br />
material on the melting bridge during<br />
melting operation. In this context, a<br />
dynamic burner system was developed<br />
that can be regularly aligned to the<br />
melting charge via the recorded measurement<br />
data and thus increases the<br />
efficiency of the overall system.<br />
In addition, the plant was equipped<br />
with a heat exchanger system. With the<br />
help of the exhaust gas, the required<br />
burner air is heated in the heat exchanger<br />
and directed to the burners. This<br />
heating results in a higher temperature<br />
level during the combustion process and<br />
leads to significant gas savings. Due to<br />
the design of the system, a series product<br />
could be generated directly from<br />
research. The research project ended<br />
successfully in 2016 and enabled a<br />
ZPF GMBH<br />
The ZPF GmbH was established in 2013 from ZPF therm Maschinenbau GmbH,<br />
which was founded in 1993, and - like its predecessor - focuses on the<br />
development, design and manufacture of highly efficient aluminium melting<br />
furnaces. The product range also includes chip melting and holding furnaces.<br />
The systems are produced at the plant in Siegelsbach, Baden-Wuerttemberg,<br />
and where possible already pre-assembled, are delivered to metal processing<br />
companies worldwide.<br />
further increase in energy efficiency of<br />
up to 15 percent in the melting plant.<br />
On this basis, assemblies were revised<br />
for series use. Today there are already<br />
plants for trial operation, which have<br />
been successfully used there. The measured<br />
values from the research project<br />
are confirmed at these plants in the<br />
rough melting operation.<br />
AlSO 4.0 – from sensor<br />
technology to automation<br />
Thanks to the findings from the Edusal<br />
II project on sensor technology, a<br />
non-contact optical test method was<br />
developed which detects a change in<br />
the state of the aluminium block.<br />
This is a camera system with a special<br />
evaluation logic that is able to<br />
detect non-molten aluminium on the<br />
bridge during the melting process. This<br />
new sensor technology enables an<br />
objective evaluation of the melting<br />
process in the aluminium furnace and<br />
the user can automatically determine<br />
the current quantities of the material<br />
to be molten. In this way, characteristic<br />
values can be derived for objective<br />
evaluation of the melting performance<br />
guaranteeing continuous monitoring<br />
throughout the entire melting process.<br />
It also opens up further possibilities for<br />
automatic control processes within a<br />
Smart Factory.<br />
All results of these research projects<br />
serve as a basis for the current project<br />
called AlSO 4.0 (Aluminium melting furnace<br />
4.0).<br />
Research on control and evaluation<br />
options for automation, required for<br />
further steps in the process chain, is<br />
conducted in close cooperation with the<br />
Technical University Bergakademie Freiberg,<br />
the University of Bremen and the<br />
Leibniz University of Hanover as well as<br />
aluminium melting furnace operator<br />
and is funded by the German Federal<br />
Ministry for Economic Affairs and<br />
Energy. In this process, the areas to be<br />
examined are extended to the entire<br />
furnace system and the first prerequisites<br />
are created for integrating adjacent<br />
peripherals and achieving the desired<br />
increase in efficiency. The frequently<br />
described scarcity of resources will be<br />
the driver for further technical development,<br />
which cannot be achieved<br />
without research work. Long-term and<br />
systematic research pays off.<br />
www.zpf-gmbh.de<br />
16
MOTIVATED<br />
BY CHALLENGES<br />
Casting service<br />
The retrofitting of existing die-casting systems and trimming presses has been a key strength of Antrok for many<br />
years. As a long-term partner, we support casting plants well beyond retrofitting, providing a specialised range of<br />
services in all upstream and downstream performance areas that are all to do with optimising your production and<br />
increasing your profitability.<br />
– Retrofitting die-casting systems<br />
– Partial retrofitting<br />
– Retrofitting trimming presses<br />
– Casting cell assembly and customized constructions<br />
– Inspection and measurement<br />
– Mould and punch maintenance<br />
– Plant servicing<br />
WWW.ANTROK.DE/EN
DIGITALIZATION<br />
Group production site.<br />
Foundry Group pioneers<br />
data-driven productivity project<br />
Partnership sees foundry business make multi-site monitoring a reality.<br />
Work in progress in the<br />
melting shop of a MAT Foundry<br />
Rudi Riedel, President Norican Digital GmbH, Munich<br />
Photo: Norican<br />
What if retrospective analysis<br />
of casting production could<br />
be replaced by real-time<br />
process awareness? If reactive, afterthe-fact<br />
responses to sub-optimal output<br />
could be replaced by proactive<br />
foundry management? What if we<br />
could see at any time, not just how one<br />
site is performing, but how multiple<br />
global sites are performing in relation<br />
to each other?<br />
These are all questions MAT Foundry<br />
Group, Poole, United Kingdom, were<br />
asking. They were approached by longterm<br />
supplier Norican Group with a proposition<br />
– one solution that would answer<br />
all their questions, boost<br />
productivity and make the need to<br />
wonder ‘what if’, redundant.<br />
Unifying the equipment and extensive<br />
foundry solutions expertise of DISA<br />
and Wheelabrator, and the digital<br />
know-how of Norican Digital, an IIoT<br />
solution built around Norican’s Monitizer<br />
platform is now in place. This will<br />
allow MAT Foundry Group to collect,<br />
monitor and analyze complete foundry<br />
data – initially from two of its key<br />
EURAC sites, Poole (UK) and Hradec<br />
(Czech Republic) – to fulfil its productivity<br />
ambitions.<br />
Kick-starting a pioneering<br />
digital collaboration<br />
Comprizing 7 foundries and 8 businesses<br />
located across three continents, MAT<br />
Foundry Group is a world-renowned<br />
specialist in the engineering and manufacture<br />
of cast and machined parts for<br />
the automotive sector.<br />
Prior to the Group’s formation in<br />
2015, the separate companies and respective<br />
foundries were run as standalone<br />
businesses. On bringing the different<br />
entities together under one roof,<br />
the need to identify shared operating<br />
threads and strategic partnerships<br />
became clear. For Shaun Lindfield, Head<br />
18
Order your<br />
benchmark<br />
part now<br />
3D Core & Mold Printing<br />
“All of our foundries have one thing in common,” explained Shaun.<br />
“They all run Disamatic molding lines and use Wheelabrator shot<br />
blasting technology. Working with Norican more closely to achieve<br />
servicing, support and costing benefits across the Group was a clear<br />
priority. We wanted to create a strong alliance that would allow us<br />
to get the best of everything.”<br />
Ready for<br />
Production<br />
of Procurement for MAT Foundry Group, Norican was an<br />
obvious choice.<br />
Four years on, that alliance has proven successful and is<br />
helping MAT Group achieve its ambitions. “Simply put”, said<br />
Shaun “we know we are always getting the very latest in<br />
foundry solutions, services and processes. We trust Norican to<br />
push us forward. We want to pioneer new things and know<br />
Norican can help us do it.<br />
“One such ‘new thing’ we’d been thinking about more<br />
and more, was how we could do more with our data. Get<br />
more value from it. So when Norican approached us last year<br />
to see if we would like to pilot one of the industry’s first multi-site<br />
cloud-based solutions, we didn’t hesitate.”<br />
Getting to the heart of what matters with KPIs<br />
Norican‘s Monitizer pairs the data capture and analysis capabilities<br />
of the on-premise Monitizer CIM (Computer Integrated<br />
Manufacturing) platform with NoriGate technology. The<br />
solution can pull, collate, correlate and display meaningful<br />
data from any connected foundry machine (not just Norican<br />
equipment) and – thanks to the Cloud – from any geographical<br />
location, enabling site comparisons. Authorized users can<br />
simply log into their online portal and, at the click of a button,<br />
see a digital picture of foundry operations. But in order<br />
to deliver optimal results, a personal approach is needed. The<br />
end solution must reveal actionable information tailored to<br />
each customer.<br />
“Data for data’s sake is pointless,” said Markus Bremer,<br />
Norican’s Senior Vice President Sales & Service Europe – West,<br />
and manager of the MAT Foundry Group project. “It’s only<br />
meaningful when it shows what a customer needs it to show.<br />
So, we sat down with MAT’s senior team, site managers, production<br />
team and engineers from Poole and Hradec, to look<br />
at the KPIs that would have the biggest impact on operations”.<br />
With these identified, work began on designing specific<br />
mini systems – ‘digital cupcakes’ – that utilize Norican’s Monitizer<br />
capabilities to create a complete solution that’s tailored<br />
to MAT’s specific needs.<br />
Experience the innovation of<br />
industrial 3D printing technology<br />
for the digital foundry of tomorrow.<br />
Parts on Demand<br />
Customized<br />
3D printing projects<br />
on demand for prototyping<br />
and engineering in our<br />
ExOne Production Center<br />
Systems<br />
Innovative 3D printing<br />
systems for fast and flexible<br />
core and mold productions<br />
Services<br />
Full service from installation<br />
and commissioning trough<br />
maintenance up to in-house<br />
trainings<br />
Daimlerstrasse 22<br />
D-86368 Gersthofen<br />
+49 821 65063-0<br />
europe@exone.com<br />
www.exone.com
DIGITALIZATION<br />
“If we know we’re running at 85 % in terms of tonnes per hour, we can investigate why straight<br />
away. It might be that we’re not producing molds quick enough. Again, we can ask why<br />
and perhaps discover that it’s because we need extra staff to keep up. The point is, if you<br />
don’t know, you can’t improve. With the solution and monitoring parameters we’ve agreed<br />
with Norican, we can.”<br />
Real time productivity –<br />
the real priority<br />
The two priorities that emerged from<br />
this consultation stage were tracking<br />
machine performance against specified<br />
standards and checking productivity in<br />
real time by monitoring metrics like poured<br />
tonnes per hour, molds not poured<br />
and bottlenecks (stop/wait times). “Ultimately,<br />
you can’t sell what you don’t<br />
make,” commented Andrew Wren, MAT<br />
Foundry Group’s Head of Engineering<br />
Projects. “That’s why these monitoring<br />
objectives were top of our list.<br />
Making what’s possible, practical<br />
All new Norican machinery is Industry<br />
4.0 ready but Norican worked with<br />
Shaun and Andrew to upgrade MAT<br />
Foundry Group’s existing equipment<br />
and retrofit the necessary data capture<br />
and IoT technology so it could be part<br />
of the global picture. In fact, a key<br />
benefit of Norican’s solution is this ability<br />
to upgrade legacy foundry plant so<br />
it can feed valuable data to the Monitizer<br />
system.<br />
The Norican solution is also designed<br />
to flex around a customer’s needs and<br />
display information in a way that is<br />
going to be most useful for the recipient.<br />
For MAT, this was a big attraction.<br />
“Our CEO doesn’t need to see specific<br />
sensor data, pressure readings or any<br />
such granular detail,” continued Shaun.<br />
“He does need to be able to log on and<br />
see, on one dashboard, a simple set of<br />
“Our production managers may need more<br />
detail but only for their specific site, while<br />
on our shop floor, our team are likely to get<br />
more benefit from simple green/red colourcoded<br />
screens linked to live data so they can<br />
quickly spot and fix small technical issues<br />
that might otherwise grow into big productivity<br />
problems.<br />
indicators from both sites which show if<br />
we are meeting daily targets – and if<br />
not, why not.<br />
Broader benefits: predictive<br />
maintenance, monitoring<br />
emissions<br />
Still linked to productivity but a step<br />
beyond the initial monitoring capability,<br />
another ‘cupcake’ is also being<br />
developed to support MAT’s predictive<br />
maintenance strategy for shot blasting<br />
at both sites. With the new digital solution,<br />
in addition to making performance<br />
indicators such as blasting times,<br />
batch count and loading/unloading<br />
times visible, it will now be possible to<br />
pull and display data relating to vibration<br />
levels – a key factor in blast wheel<br />
wear. By setting alerts against vibration<br />
thresholds, MAT Foundry Group will be<br />
able to see when servicing or replacements<br />
are required and avoid unnecessary,<br />
unplanned downtime.<br />
In addition to monitoring common<br />
KPIs across both pilot sites, the digital<br />
project also supports objectives specific<br />
to each foundry. “Basically the door has<br />
been opened to wider areas of business<br />
improvement that we hadn’t necessarily<br />
foreseen,” said Andrew.<br />
“Currently, we have to have a person<br />
walk the dust collectors every day<br />
to check differential pressure readings<br />
which indicate the effectiveness of our<br />
filters” added Shaun. “If we get a<br />
blockage, it’s not only a potential issue<br />
in terms of emissions, it’s a risk factor<br />
for our internal environment and staff.<br />
With the new Norican solution, we can<br />
pull data from our dust collectors into<br />
the mix and get a live picture of filter<br />
performance. We can demonstrate to<br />
local authorities we are constantly, and<br />
responsibly, on top of things.”<br />
Optimizing worldwide processes<br />
with meaningful data<br />
Beyond the initial two-site pilot phase of<br />
the project, MAT Foundry Group has big<br />
ambitions for where Norican’s Monitizer<br />
solution can take them. Andrew says:<br />
“We’ve actually tried to look at data<br />
monitoring as an operational improvement<br />
measure before but attempts have<br />
fallen flat because we just couldn’t find<br />
the right mechanism or get buy-in from<br />
the team. With this project, that’s<br />
changed. Our ambition, once we review<br />
this pilot phase, is to connect all the<br />
foundries in our group. That holds exciting<br />
potential as you can begin to benchmark<br />
beyond foundry walls. If seemingly<br />
identical lines are producing different<br />
results in two sites, why is that? With our<br />
new framework, we can find out and<br />
make sure best practice systems and processes<br />
are then shared across our global<br />
network. We are still in our infancy as a<br />
unified group. Tools such as this can help<br />
speed up our maturing process quickly<br />
and profitably. Long term success means<br />
grasping opportunities to boost productivity<br />
with both hands. With Norican,<br />
that’s what we are doing”, he concludes.<br />
www.noricangroup.com<br />
www.matfoundrygroup.com<br />
20
PRESSURE DIE CASTING<br />
Photo: Bühler AG<br />
The future of structural<br />
components in HPDC<br />
Die-cast structural components<br />
offer enormous potential for<br />
weight and cost minimization<br />
in the automotive industry.<br />
Fundamental changes in the automotive industry with a profound impact on the industry<br />
await foundries all over the world. Consumer demand and environmental regulations<br />
have changed the way how people want to use cars, as well as the requirements<br />
for cars. Consequently, automotive manufacturers seek the obligation to produce sustainable<br />
vehicles – at the lowest possible costs. One of the measures to reduce fuel<br />
consumption, larger battery range or less emissions is the production of lighter cars.<br />
Here, structural components offer an enormous technological and economical potential.<br />
Herman Jacob Roos and Martin Lagler, Bühler AG, and Luis Quintana, BuhlerPrince Inc.<br />
The continuing quest for lighter-weight<br />
components in the<br />
automotive industry has seen the<br />
emergence of a lucrative new market<br />
for die casting: structural components.<br />
The demand for these large, complex<br />
components, such as shock towers and<br />
longitudinal beams, was estimated to<br />
cover just under 6 million cars in 2018,<br />
many with multiple structural components.<br />
Current usage is predicted to<br />
grow to nearly 9 million cars by 2025<br />
[1]. But whilst these structural components<br />
offer a more rigid, lighter solution<br />
that car makers want, the cost for<br />
longer production runs has so far limited<br />
adoption to sports cars, luxury cars,<br />
SUVs and quality D segment saloons,<br />
where smaller runs make economic<br />
sense. But the economics of die casting<br />
are changing. Over the past few years,<br />
the costs of structural components have<br />
dropped by as much as 20 percent. This<br />
paper shows how a combination of<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 21
PRESSURE DIE CASTING<br />
High usage<br />
Medium usage<br />
Low usage<br />
> 6 large components<br />
• S sport coupés<br />
• F luxury cars<br />
4-6 large components<br />
• E executive cars<br />
• J sport utility cars<br />
1-3 large components<br />
• D large cars<br />
• E executive cars<br />
Exemplary<br />
components<br />
<br />
<br />
<br />
<br />
<br />
Front shock towers<br />
Rear shock towers<br />
Longitudinal beams<br />
Firewall<br />
Other<br />
Exemplary<br />
components<br />
<br />
<br />
<br />
Front shock towers<br />
Rear shock towers<br />
Longitudinal beams<br />
Firewall<br />
Other<br />
Exemplary<br />
components<br />
<br />
<br />
Front shock towers<br />
Rear shock towers<br />
Longitudinal beams<br />
Firewall<br />
Other<br />
Source: Roland Berger<br />
Graphics: Roland Berger<br />
Figure 1: Current usage for structural components in the automotive market.<br />
advanced thermal management, the<br />
use of new alloys and careful product<br />
design could drive down production<br />
costs even further. Hereby die-cast structural<br />
components get more cost-effective<br />
for the mass car market. With new<br />
car production predicted to hit the 110<br />
million vehicle mark in 20231, and with<br />
between two and six structural components<br />
per car, these technological<br />
advances could potentially transform<br />
the opportunity for die casters around<br />
the world. If the manufacturing chain<br />
– from die-casting machine manufacturers,<br />
to foundries and OEMs – work<br />
together, it will be possible.<br />
3.3<br />
0.6<br />
0.5<br />
2.2<br />
5.9<br />
0.7<br />
2.2<br />
3.1<br />
+3 m units<br />
8.2<br />
0.8<br />
3.3<br />
4.0<br />
8.9<br />
0.8<br />
3.8<br />
4.4<br />
High user<br />
(>6 parts)<br />
Medium user<br />
(4-6 parts)<br />
Low user<br />
(1-3 parts)<br />
Why are die-cast structural components<br />
so attractive to the automotive<br />
industry?<br />
Die-casting foundries around the world<br />
are seeing fundamental changes in the<br />
automotive industry that are profoundly<br />
affecting the industry. Consumer<br />
demand and environmental regulation<br />
is driving significant changes in the<br />
kind of cars people want to drive and<br />
how they want to use them. Electric<br />
mobility is developing at a fast pace,<br />
with global sales more than doubling,<br />
from around 2 million in 2017 to 5.1<br />
million in 2018 [2].<br />
Every car manufacturer is focused on<br />
producing more sustainable vehicles –<br />
preferably at a lower cost. And a key<br />
element in reducing fuel consumption,<br />
extending battery range or reducing<br />
emissions, is in making cars that weigh<br />
less. This is the motivation that is fueling<br />
the growing demand for structural<br />
components.<br />
2015<br />
2018<br />
vehicle architectures in million units<br />
The role of die-casting technology<br />
in vehicle weight reduction<br />
Die casting large structural components<br />
is a proven route to reduce weight in<br />
vehicles. Die casting in aluminum alloys<br />
delivers exceptional strength and good<br />
formability, but with less weight than<br />
traditional steel structures.<br />
This drive for lighter weight is independent<br />
of powertrain selection. As<br />
debates over the best sustainable motoring<br />
solutions rage, from ICE, PHEV,<br />
HEV, EV even hydrogen, and consumer<br />
attitudes and regional and local regulation<br />
skew demand across markets,<br />
investing in the production of structural<br />
components is a clear strategic solution<br />
for many die-casting foundries.<br />
2021<br />
2025<br />
Figure 2: Predicted growth in current structural components, 2015 to 2025.<br />
Pioneered in the German luxury car<br />
market, die-cast structural components<br />
are now being used in wider categories<br />
of vehicle, for a range of applications.<br />
(Figure 1).<br />
An important application<br />
for die casting<br />
S sport coupés and F segment luxury<br />
cars currently use the widest range of<br />
die-cast structural components, including<br />
front and rear shock towers and<br />
longitudinal beams designed for the<br />
dissipation of crash energy. The Jaguar<br />
I-PACE actually uses 15 structural components<br />
on each vehicle. E segment<br />
executive cars and J segment sports utilities<br />
use die-cast components in shock<br />
22
Situation Today<br />
Today’s Market of Structural Components<br />
Goal for 2030<br />
Future Market of Structural Components<br />
J sport utility cars…<br />
S sport coupés<br />
F luxury cars<br />
E executive cars<br />
D large cars<br />
C medium cars<br />
B small cars<br />
A: mini cars<br />
0 10 20 30 40<br />
Mio Cars with structural components<br />
Mio Cars without Structral componets<br />
~ 6 m<br />
units<br />
J sport utility cars…<br />
S sport coupés<br />
F luxury cars<br />
E executive cars<br />
D large cars<br />
C medium cars<br />
B small cars<br />
A: mini cars<br />
0 10 20 30 40<br />
Mio Cars with structural components<br />
Mio Cars without Structral components<br />
~ 25 m<br />
units<br />
Graphics: Bühler AG<br />
Figure 3: Potential structural component market growth with production cost savings.<br />
towers and rocker rein enforcements.<br />
Mercedes C-class is perhaps the highest<br />
volume user, with around 400,000 cars<br />
sold each year. D-segment large cars<br />
use die-cast parts for front shock towers<br />
and tunnel reinforcement.<br />
This move to die casting structural<br />
components is gathering momentum<br />
around the world. Bühler analysis of<br />
this current available market, conducted<br />
by global consulting firm, Roland<br />
Berger (see Figure 2), shows growth in<br />
units is predicted to almost triple in<br />
the 10 years from 2015 to 2025, from<br />
3.3 million units to 8.9 million [3]. The<br />
study takes into account the currently<br />
known production starts of the OEMs.<br />
New platforms could further increase<br />
the demand for structural components.<br />
Much of this growth is predicted to<br />
come from the E segment and D segment<br />
car market, and J segment sport<br />
utility vehicles.<br />
The potential for mass market<br />
adoption<br />
The current reality is that while the<br />
investment costs for tools are low compared<br />
to other processes, the tools are<br />
subjected to considerably more wear<br />
which, in turn, increases the tool maintenance<br />
costs for longer production<br />
numbers. This currently makes overall<br />
unit costs too high to break into the C<br />
segment medium car market, or smaller<br />
mass market cars.<br />
The Bühler analysis shows that<br />
achieving cost savings that allow a breakthrough<br />
into the C segment market,<br />
together with greater adoption in<br />
existing car segments, could be a<br />
Cycle time [s]<br />
100<br />
90<br />
80<br />
70<br />
60<br />
50<br />
40<br />
30<br />
20<br />
10<br />
0<br />
90s<br />
22<br />
15<br />
18<br />
12<br />
8<br />
10<br />
10<br />
18<br />
6<br />
6<br />
12<br />
8<br />
8<br />
6.5 6.5<br />
12 9 9<br />
8 8.5 8.5<br />
2 Cavity Shock Tower 2 Cavity Shock Tower<br />
(4,000 ton DCM) (Carat 440 c)<br />
game-changer for the industry (see<br />
Figure 3), expanding the market from<br />
six million cars today, to over 25 million<br />
by 2030.<br />
So the question is, what advances<br />
and techniques could be deployed now,<br />
with current technology, which would<br />
enable die-casting to break the cost<br />
barrier to mass market adoption?<br />
Three technological advances within<br />
our grasp<br />
Using application knowledge gained<br />
across Europe, China and North America,<br />
Bühler has identified three areas<br />
where application-specific developments<br />
could deliver the production<br />
cost-savings the industry needs:<br />
> Thermal Management<br />
60s<br />
Potential<br />
(Thermal balance &<br />
micro-spraying)<br />
Figure 4: How better thermal management can reduce cycle times by up to a third.<br />
Spraying<br />
Extraction<br />
Opening<br />
Solidification<br />
Injection<br />
Dosing<br />
Closing<br />
> Alloy Selection<br />
> Lightweight Construction by Product<br />
Design<br />
Using an advanced 4,400 ton machine,<br />
and assuming an application with two<br />
cavities with a three-plate tool, calculations<br />
show that using advanced<br />
techniques to reduce cycle times and<br />
improve die lifetimes will deliver significant<br />
cost reductions.<br />
Improving productivity through thermal<br />
management<br />
Thermal management is a key element<br />
in cycle times, die life and part quality.<br />
Improving thermal management in an<br />
existing process can therefore deliver<br />
improvement in all three of these areas.<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 23
PRESSURE DIE CASTING<br />
30.00<br />
25.00<br />
20.00<br />
15.00<br />
10.00<br />
5.00<br />
0.00<br />
28€<br />
4,000 g Shock Tower<br />
2-cav. & 3-plate tool<br />
(Baseline)<br />
A combination of improved thermal<br />
balance and the addition of targeted<br />
micro-spraying, together with optimum<br />
cell layout, can reduce cycle times for a<br />
typical structural shock tower by a third,<br />
from 90 seconds to just 60 seconds (see<br />
Figure 4).<br />
A well designed temperature concept<br />
allows the use of micro-spraying. This<br />
leads to a shorter solidification time and<br />
a significantly shorter cycle time. Productivity<br />
and quality are also improved.<br />
Improved thermal management also<br />
puts less wear on the die, extending die<br />
lifetime. In this example, it is calculated<br />
die lifetime could increase from 80,000 to<br />
at least 120,000 cycles, an improvement<br />
of 50 % or more. This is a significant<br />
advantage for mass market production.<br />
- 10%<br />
25€<br />
faster cycle (90 s vs. 60 s)<br />
extented die lifetime (+50 %)<br />
less scrap (5 % vs. 3 %)<br />
Operation costs<br />
Metal costs<br />
Die & tooling costs<br />
Peripheral woking costs (Trimming, Deburring, HT, Straightening,…)<br />
Machining costs<br />
Figure 5: Cost reduction using improved thermal management.<br />
Standard<br />
Structural<br />
Alloys<br />
Additional<br />
Tooling<br />
costs<br />
+ 5%<br />
Source: Bühler manufacturing cost saving study<br />
New<br />
Alloy<br />
Systems<br />
High Strength<br />
Alloy Systems<br />
Alloy System AlSi10MnMg AlMg4Fe2 AlMg6Si2MnZr<br />
HT T7 F T5<br />
UTM<br />
Rm [MPa]<br />
Yield strength<br />
Rp0,2% [MPa]<br />
Elongation<br />
A [%]<br />
200-240 240-260 350-380<br />
120-140 120-140 230-250<br />
10-20 10-22 8-12<br />
Figure 6: Possibilities of different alloy systems for Structural components.<br />
And this fine-tuning of the thermal<br />
process avoids hot spots and reduces<br />
shrinkage porosity – improving<br />
part-quality. This could reduce scrap<br />
rate from 5 to 3%, once again reducing<br />
overall production costs.<br />
Cost savings for a typical shock tower<br />
This combination of cycle time reduction,<br />
extended die life and scrap reduction,<br />
even with the need for some additional<br />
tooling, has the potential to<br />
reduce unit production costs by 10 % –<br />
an important first step in achieving an<br />
acceptable cost for mass market adoption<br />
(see Figure 5).<br />
Using new alloys to reduce process<br />
steps<br />
Many of the structural components<br />
currently being produced with die casting<br />
play an important role in safety or<br />
crash damage mitigation. To meet the<br />
specific material requirements for crumpling<br />
on impact or absorbing crash<br />
energy in addition to functional requirements,<br />
there is a very high mechanical<br />
specification.<br />
At the moment, these characteristics<br />
are achieved with special alloys that<br />
often require heat treatment and straightening.<br />
This is carried out after the<br />
part is cast, later in the process. In some<br />
cases straightening requires expensive<br />
manual work.<br />
New alloys are constantly emerging<br />
that could deliver comparable or superior<br />
mechanical properties with reduced<br />
heat treatment requirement, or indeed,<br />
cut out the heat treatment process step<br />
altogether (see Figure 6).<br />
Alloys for structural components with<br />
high requirements in elongation and<br />
strength<br />
Of course, any new alloy system will<br />
need to be approved and verified for<br />
the specific application, but the potential<br />
for improved quality and reduced<br />
costs is clear (see Figure 7). Indeed, in<br />
this example, there is the potential to<br />
reduce costs by a further 10 %, on top<br />
of the thermal management savings<br />
achieved in step 1.<br />
Designing for weight saving<br />
The drive towards die-cast structural<br />
components is motivated by saving<br />
weight. Structural components cast in<br />
aluminum alloy today have an average<br />
wall-thickness of 2.5 mm, with material<br />
concentration around connection points<br />
and ejector marks. By contrast, with<br />
careful design of the part and the casting<br />
process, the same components can<br />
be produced with a wall width of just<br />
1.8 mm. This can deliver up to 20 %<br />
savings in overall weight.<br />
Of course, the level of achievable<br />
weight reduction is limited by structural<br />
integrity, which depends upon the loads<br />
and stresses on each part when in use,<br />
in a vehicle. Using the shock tower<br />
example, intelligent design could<br />
reduce the weight of by 10 %, from<br />
4,000 g to 3,600 g.<br />
As well as helping to meet the argument<br />
for die-casting based on weight<br />
reduction, this would further reduce production<br />
costs by 4 % (see Figure 8), whilst<br />
creating a more sustainable product.<br />
24
30.00<br />
25.00<br />
20.00<br />
15.00<br />
10.00<br />
5.00<br />
0.00<br />
25€<br />
faster cycle (90 s vs. 60 s)<br />
extented die lifetime (+50 %)<br />
less scrap (5 % vs. 3 %)<br />
+ without HT & Straightening<br />
Operation costs<br />
Metal costs<br />
Die & tooling costs<br />
Peripheral woking costs (Trimming, Deburring, HT, Straightening,…)<br />
Machining costs<br />
Figure 7: Potential cost savings from new alloys.<br />
30.00<br />
25.00<br />
20.00<br />
15.00<br />
10.00<br />
5.00<br />
0.00<br />
22.5€<br />
faster cycle (90 s vs. 60 s)<br />
extented die lifetime (+50 %)<br />
less scrap (5 % vs. 3 %)<br />
+ without HT & Straightening<br />
- 10%<br />
- 4%<br />
22.5€<br />
+Light weight design<br />
(-10 % part weight)<br />
Operation costs<br />
Metal costs<br />
Die & tooling costs<br />
Peripheral woking costs (Trimming, Deburring, HT, Straightening,…)<br />
Machining costs<br />
Source: Bühler cost saving study<br />
Figure 8: Cost saving potential by light weight design.<br />
21.5€<br />
of material, thus contributing to a sustainable<br />
value chain.<br />
An overall cost reduction of over<br />
23 %<br />
In this example, fine-tuning thermal<br />
management, introducing new alloys<br />
and redesigning the shock tower to<br />
optimize weight and production has<br />
reduced the unit cost of each part from<br />
28 to 21.50 euros, an overall cost reduction<br />
of just over 23 %.<br />
Crucially, that could be enough to<br />
make this an attractive proposition for<br />
C segment medium cars, opening up a<br />
lucrative volume market for die-casting<br />
foundries worldwide.<br />
A powerful argument for<br />
application-specific cost-reduction<br />
programs<br />
This paper describes a theoretical cost<br />
reduction program for a typical shock<br />
tower and makes a powerful argument<br />
for fine-tuning products and processes<br />
to reduce costs and improve quality.<br />
At Bühler, investment in Industry 4.0<br />
technology, AI, SmartCMS and world-class<br />
digital services like Predictive<br />
Analytics and Downtime Analysis are<br />
designed to enable customers to continually<br />
refine processes for ongoing<br />
improvement.<br />
But every part has unique characteristics.<br />
Every application has specific parameters.<br />
And every foundry sets up and<br />
approaches cells differently. To make<br />
application-specific cost-reduction programs<br />
work, it’s essential that car companies,<br />
OEMs, product designers,<br />
foundries and die-casting machine<br />
manufacturers all work closely together<br />
to achieve the break-throughs that will<br />
serve the automotive industry – and sustain<br />
the die-casting industry – for many<br />
years to come.<br />
Herman Jacob Roos, Structural Process<br />
Manager, Martin Lagler, Director Global<br />
Application Technology Die Casting,<br />
Bühler AG, Uzwil, Switzerland, and Luis<br />
Quintana, Application Technology Specialist,<br />
BuhlerPrince Inc., Holland,<br />
Michigan, US<br />
An award-winning example<br />
of weight reduction<br />
In 2018, the 1st prize at Euroguss for<br />
the optimized design of a casting, went<br />
to a part which incorporated a weight<br />
reduction of 19 % compared to the functionally<br />
identical part of the previous<br />
model [4]. This was achieved with a<br />
high-strength, highly flowable alloy in<br />
combination with a strength-optimized<br />
T6 heat treatment. The thin-walled<br />
design also saves a significant amount<br />
References:<br />
www.cpt-international.com<br />
CASTING PLANT & TECHNOLOGY 4/<strong>2019</strong> 25
PRESSURE DIE CASTING<br />
Photo: ??<br />
Light-weight castings can be<br />
joined by means of latest laser<br />
welding methods to manufacture<br />
highly loadable and economically<br />
efficient structural components.<br />
Castings for lightweight<br />
engineering<br />
Cast iron and aluminium alloys as alternatives for<br />
thin-section steel castings.<br />
Wolfgang Knothe, Franken Guss, Kitzingen<br />
The urgent call for light-weighting<br />
solutions in automotive engineering<br />
entails two key requirements:<br />
reliable and consistent material properties<br />
of the component, and a design suitable<br />
for the expected in-service stress<br />
load of the component. In other words,<br />
the service life of a component depends<br />
to a large extent on the component<br />
design. This is where casting technology<br />
comes in because here both the geometry<br />
of a component and the material<br />
properties evolve in one and the same<br />
process. Additionally, thanks to the high<br />
degree of process automation, large<br />
series production is assured.<br />
Steel casting has its limits, above all<br />
for economic reasons. Steel‘s very high<br />
melting and casting temperatures, its<br />
high shrinkage rates and the complexity<br />
of steel heat treatments are the main<br />
causes for this. The development of<br />
advanced materials, such as ductile iron<br />
and T6 aluminium alloys, has overcome<br />
these constraints. This does not mean<br />
that the importance of aluminium as<br />
the classical light-weighting material<br />
has decreased. While ductile iron and<br />
steel alloys have similar properties, the<br />
melting temperature of ductile iron is<br />
lower by 400 K, giving it excellent teeming<br />
properties. Meanwhile, a number<br />
of highly loaded structural parts which<br />
used to be exclusively made of steel<br />
have been replaced by ductile iron castings.<br />
Ductile iron castings are characterized<br />
by the following features:<br />
a b c<br />
Figure 1: Light-weight ductile iron castings. a) tubular cross member, b) differential cage, c) pressure plate.<br />
a b c<br />
Figure 2: Light-weight aluminium castings. a) sill plate, b) bearing bracket for front suspension, c) steering support.<br />
26
forming of the part and adjusting<br />
the material properties take place in<br />
a single process,<br />
> automatic molding lines use 100%<br />
recyclable quartz sands,<br />
> high yield,<br />
> easy, mechanized cutting off of the<br />
casting from the runner system,<br />
> low residual stresses in the as-cast<br />
condition,<br />
> adjustment of specific grades<br />
through targeted heat treatments,<br />
> good weldability,<br />
> possibility of producing components<br />
with complex functions.<br />
The successful manufacturing of structural<br />
components consisting of ductile<br />
iron castings and steel parts joined by<br />
welding opens up great potential for<br />
innovative light-weighting solutions.<br />
Production at Franken Guss<br />
The iron foundry can produce castings<br />
from all types of cast iron, i.e. ductile<br />
iron, grey cast iron and compacted graphite<br />
cast iron. It is equipped with three<br />
mechanized and automated molding<br />
lines. With this highly advanced equipment,<br />
near-net-shape geometries can<br />
be produced and the implemented data<br />
Figure 3: Before new components are produced in series, Franken Guss prints<br />
3-D-prototypes.<br />
infrastructure assures stable production<br />
processes. Automated DISA molding<br />
lines operate in conjunction with<br />
laser-controlled “Pouromat” pouring<br />
equipment.<br />
The main alloys used in the aluminium<br />
foundry are EN-AC-AlSi9Cu3 (Fe),<br />
EN-AC- AlSi 10Mg (Fe) and EN-AC-AlSi<br />
12 (Cu). Twelve pressure casting cells are<br />
in place, operating in conjunction with<br />
robots which pick up the castings from<br />
the molds and transfer them via the<br />
flash trimming press to the transport<br />
unit. The biggest casting cell has a<br />
