Sec. 6–3 DC and RMS Values for Ergodic Random Processes 437<br />
the ensemble average required for a true x ( f ) of Eq. (6–42). In evaluating T ( f ), the DFT is<br />
generally used to approximate X T ( f ). This brings the pitfalls of DFT analysis into play, as<br />
described in Sec. 2–8.<br />
It should be stressed that Eq. (6–73a) is an approximation or estimate of the PSD. This<br />
estimate is called a periodogram, because it was used historically to search for periodicities in<br />
data records that appear as delta functions in the PSD. [Delta functions are relatively easy to<br />
find in the PSD, and thus, the periodicities in x(t) are easily determined.] It is desirable that<br />
the estimate have an ensemble average that gives the true PSD. If this is the case, the estimator<br />
is said to be unbiased. We can easily check Eq. (6–73a) to see if it is unbiased. We have<br />
and, using Eq. (6–50a) for T finite, we obtain<br />
T (f) = c |X T(f)| 2<br />
d<br />
T<br />
T (f) = cR x (t) a t T bd<br />
and then, referring to Table 2–2,<br />
sin pfT<br />
2<br />
T (f) = T x (f) * a (6–73b)<br />
pfT b<br />
Because T (f) Z x (f), the periodogram is a biased estimate. The bias is caused by the<br />
triangular window function ∂ (tT) that arises from the truncation of x(t) to a T-second<br />
interval. Using Sec. A–8, where a = pT, we see that lim T : q [ T (f)] = x (f), so that the<br />
periodogram becomes unbiased as T → q. Consequently, the periodogram is said to be<br />
asymptotically unbiased.<br />
In addition to being unbiased, it is desirable that an estimator be consistent. This means<br />
that the variance of the estimator should become small as T → q. In this regard, it can be<br />
shown that Eq. (6–73a) gives an inconsistent estimate of the PSD when x(t) is Gaussian<br />
[Bendat and Piersol, 1971].<br />
Of course, window functions other than the triangle can be used to obtain different PSD<br />
estimators [Blackman and Tukey, 1958; Jenkins and Watts, 1968]. More modern techniques<br />
assume a mathematical model (i.e., form) for the autocorrelation function and estimate parameters<br />
for this model. The model is then checked to see if it is consistent with the data. Examples are the<br />
moving average (MA), autoregressive (AR), and autoregressive-moving average (ARMA) models<br />
[Kay, 1986; Kay and Marple, 1981; Marple, 1986; Scharf, 1991; Shanmugan and Breipohl, 1988].<br />
Spectrum analyzers that use microprocessor-based circuits often utilize numerical techniques<br />
to evaluate the PSD. These instruments can evaluate the PSD only for relatively<br />
low-frequency waveforms, say, over the audio or ultrasonic frequency range, since real-time<br />
digital signal-processing circuits cannot be built to process signals at RF rates.<br />
6–3 DC AND RMS VALUES FOR ERGODIC RANDOM PROCESSES<br />
In Chapter 2, the DC value, the RMS value, and the average power were defined in terms<br />
of time average operations. For ergodic processes, the time averages are equivalent to ensemble<br />
averages. Thus, the DC value, the RMS value, and the average power (which are all
