84<br />
Signals and Spectra Chap. 2<br />
is the phase response of the network. Furthermore, since h(t) is a real function of time (for real<br />
networks), it follows from Eqs. (2–38) and (2–39) that ƒH(f)ƒ is an even function of frequency<br />
and lH(f) is an odd function of frequency.<br />
The transfer function of a linear time-invariant network can be measured by using a<br />
sinusoidal testing signal that is swept over the frequency band of interest. For example, if<br />
then the output of the network will be<br />
x(t) = A cos v 0 t<br />
y(t) = AƒH(f 0 )ƒ cos [v 0 t + lH(f 0 )]<br />
(2–138)<br />
where the amplitude and phase may be evaluated on an oscilloscope or by the use of a vector<br />
voltmeter.<br />
If the input to the network is a periodic signal with a spectrum given by<br />
X(f) =<br />
n=q<br />
a<br />
n=-q<br />
c n d(f - nf 0 )<br />
(2–139)<br />
where, from Eq. (2–109), {c n } are the complex Fourier coefficients of the input signal, the<br />
spectrum of the periodic output signal, from Eq. (2–134), is<br />
Y(f) =<br />
n=q<br />
a<br />
n=-q<br />
c n H(nf 0 ) d(f - nf 0 )<br />
(2–140)<br />
We can also obtain the relationship between the power spectral density (PSD) at the input,<br />
x ( f ), and that at the output, y (f), of a linear time-invariant network. † From Eq. (2–66),<br />
we know that<br />
y (f) = lim<br />
T: q<br />
Using Eq. (2–134) in a formal sense, we obtain<br />
1<br />
T ƒY T (f)ƒ2<br />
(2–141)<br />
y (f) = ƒH(f)ƒ 2<br />
lim<br />
T: q<br />
1<br />
T ƒX T (f)ƒ2<br />
or<br />
y (f) = |H(f)| 2 x (f)<br />
(2–142)<br />
Consequently, the power transfer function of the network is<br />
G h (f) = y(f)<br />
= |H(f)| 2<br />
x (f)<br />
A rigorous proof of this theorem is given in Chapter 6.<br />
(2–143)<br />
† The relationship between the input and output autocorrelation functions R x (t) and R y (t) can also be obtained<br />
as shown by (6–82).
