2013Hydraulic <strong>Repair</strong> &Products <strong>Catalog</strong>P.O. Box 249 • 22927 McAuliffe Dr. • Robertsdale, AL 36567-0249(888) 698.1978 Toll Free • (251) 947.5200 • (251) 947.5203 Faxwww.crconline.com
Contents3 Honed ID Tubing4 Standard Sizes7 Metric Sizes8 Chrome ID Sizes8 Aluminum Sizes9 <strong>Cylinder</strong> Ram Products10 Chrome Plated Standard12 Chrome Plated Metric13 Chrome Plated Induction Hard15 Chrome Plated Metric/Induction Hard16 Chrome Plated OD Tubing17 Stainless Steel17 Chrome Plated Stainless Steel19 Component Materials20 Aluminum21 Ductile/Cast Iron23 Steel Round Bar 1018 HF24 Heavy Wall Mechanical Tube25 Bearing Bronze SAE 66025 JIC Hydraulic Line Tube25 Tie Rod – 1144 Stress Proof27 Component Parts28 Internal Threaded Ductile Heads29 Internal Threaded Ductile Heads (wide)30 Aluminum Head Glands30 Aluminum O-Ring Pistons31 Aluminum Polypak Pistons31 Ductile Polypak Pistons32 Head Caps33 Butt Plates33 Eye Brackets34 Clevis Brackets34 MP1 Detachable Mounts34 MP2 Detachable Mounts35 MP4 Detachable Mounts35 Rod Clevis36 Rod Eye36 Pivot Pins – Grooves37 Pivot Pins – Holes38 Spherical Ball Bushing (<strong>Inc</strong>h Series)39 Spherical Ball Bushing (Metric Series)39 Rectangular Flange40 Spherical Rod Eye40 Alignment Coupler41 Ports and Fittings42 Threaded Nuts(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 1
Terms & Conditions of SaleDeliveries and claims against carrier:A clear receipt given to the carrier by the consignee eliminates the possibility of a claim for damage or shortageagainst the carrier. In cases of damaged goods, the customer will be responsible for any damages received fromtruck lines during delivery. <strong>Cylinder</strong> <strong>Repair</strong> <strong>Components</strong> will handle UPS damage claims in order to reimburse thecustomer. Once UPS approves the shipment claim, <strong>Cylinder</strong> <strong>Repair</strong> <strong>Components</strong> will reimburse the customer on theamount rendered. If a package is late, <strong>Cylinder</strong> <strong>Repair</strong> <strong>Components</strong> will reship the package and the customer will beresponsible for the cost of material and freight expenses. Guaranteed UPS freight shipments will be reimbursed tothe customer when <strong>Cylinder</strong> <strong>Repair</strong> <strong>Components</strong> is notified within the one-week period.Return of goods:Orders shipped in error or being restocked must be shipped one week of the invoice date or the customer willbe responsible for payment. Customers will pay a 50 percent restocking fee on canceled orders or materialsbeing returned for credit. Packages are required to have a return authorization document from <strong>Cylinder</strong> <strong>Repair</strong><strong>Components</strong> for the return to be authorized.Defective Material:In spite of the greatest care, it is sometimes impossible to detect all imperfections. We guarantee to replacewith new material, such goods as prove defective within one week of receipt of material. No charges for labor orexpenses required to repair defective goods will be accepted from <strong>Cylinder</strong> <strong>Repair</strong> <strong>Components</strong>.* Special Orders Can Not Be Cancelled Once The Order Is Placed — No ExceptionsP.O. Box 249 • 22927 McAuliffe Dr. • Robertsdale, AL 36567-0249(888) 698.1978 Toll Free • (251) 947.5200 • (251) 947.5203 Faxwww.crconline.com2(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Honed ID TubingHoned ID Tubing4 Standard Sizes.......................... 1.500" – 14.000" Bore7 Metric Sizes.............................. 40mm – 200mm Bore8 Chrome ID Sizes....................... 1.500" – 10.000" Bore8 Aluminum Sizes........................ 2.000" – 10.000" Bore(888) 698.1978 Toll Free • www.crconline.com3
Cold Drawn Carbon Honed TubeDrawn over mandel or cold-drawn seamless honed tube. Material is stress-relief annealed andoffers surface finishes commonly ordered 10-20 micro inch. Can furnish skived and burnishedID-finished tube and chrome-plated OD and/or ID.American SpecificationsASTM A513 Type 5, ASTM A519 cold drawn seamless, KR3504 (ST52.3 (ST37.2)ApplicationsUsed for hydraulic and pneumatic cylinder manufacturing and pump barrels.Close tolerances and smooth surface finishes are critical in these applications.MachinabilityMaterials can be readily machined, honed, skived, etc. as well as thermally treated to produce asuperior finished product.WeldabilityThe absence of alloying elements in combination with the low manganese contentmakes for easy welding.Heat TreatingCan be heat treated.Typical Chemical AnalysisSAE 1026 (for KR 3504,see suitable-to-hone:for KR3503 see special smooth ID)C .22 – .28MN .60 – .90PS.010 Max.025 MaxSi .10 – .25NiCrCu.15 Max.15 Max.25 MaxTypical Mechanical PropertiesSAE 1026Tensile Strength (ksi) 85Yield Point (ksi) 75Elongation (% in 2”) 15Rockwell HardnessRB804(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Honed Tube1026/ST52.3 Dom Stress Relieved & AnnealedPART#SIZEHT-1875X1500 1 1/2" X 1 7/8"HT-2000X1500 1 1/2" X 2"HT-2000X1625 1 5/8" X 2"HT-2250X1750 1 3/4" X 2 1/4"HT-2250X1875 1 7/8" X 2 1/4"HT-2375X2000 2" X 2 3/8"HT-2500X2000 2" X 2 1/2"HT-2750X2250 2 1/4" X 2 3/4"HT-2875X2500 2 1/2" X 2 7/8"HT-3000X2000 2" X 3"HT-3000X2500 2 1/2" X 3"HT-3250X2500 2 1/2" X 3 1/4"HT-3250X2750 2 3/4" X 3 1/4"HT-3375X3000 3" X 3 3/8"HT-3500X3000 3" X 3 1/2"HT-3750X3000 3" X 3 3/4"HT-3750X3250 3 1/4" X 3 3/4"HT-3875X3250 3 1/4" X 3 7/8"HT-4000X3000 3" X 4"HT-4000X3250 3 1/4" X 4"HT-4000X3500 3 1/2" X 4"HT-4250X3250 3 1/4" X 4 1/4"HT-4250X3750 3 3/4" X 4 1/4"HT-4250X3500 3 1/2" X 4 1/4"HT-4500X3500 3 1/2" X 4 1/2"HT-4500X3750 3 3/4" X 4 1/2"PART#SIZEHT-4500X4000 4" X 4 1/2"HT-4625X4000 4" X 4 5/8"HT-4750X4000 4" X 4 3/4"HT-4750X4250 4 1/4" X 4 3/4"HT-5000X4000 4" X 5"HT-5000X4250 4 1/4" X 5"HT-5000X4500 4 1/2" X 5"HT-5250X4500 4 1/2" X 5 1/4"HT-5250X4750 4 3/4" X 5 1/4"HT-5500X4500 4 1/2" X 5 1/2"HT-5500X4750 4 3/4" X 5 1/2"HT-5500X5000 5" X 5 1/2"HT-5625X5000 5" X 5 5/8"HT-5750X5000 5" X 5 3/4"HT-5750X5250 5 1/4" X 5 3/4"HT-6000X5000 5" X 6"HT-6000X5250 5 1/4" X 6"HT-6000X5500 5 1/2" X 6"HT-6250X5500 5 1/2" X 6 1/4"HT-6500X5500 5 1/2" X 6 1/2"HT-6500X6000 6" X 6 1/2"HT-6625X6000 6" X 6 5/8"HT-6750X6000 6" X 6 3/4"HT-6750X6250 6 1/4" X 6 3/4"HT-7000X6000 6" X 7"Prices subject to change without notice. $40.00 Minimum invoice. • “Let us quote your metric honed tubing requirements”(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 5
Metric Honed Dom Tubing 1026PART#MHT-40mmx50mmMHT-40mmx60mmMHT-45mmx55mmMHT-50mmx60mmMHT-50mmx65mmMHT-55mmx75mmMHT-60mmx70mmMHT-60mmx80mmMHT-63mmx73mmMHT-63mmx78mmMHT-63mmx83mmMHT-65mmx75mmMHT-65mmx85mmMHT-70mmx80mmMHT-70mmx90mmMHT-75mmx85mmMHT-75mmx90mmMHT-75mmx95mmMHT-80mmx90mmMHT-80mmx95mmMHT-80mmx100mmMHT-80mmx105mmMHT-85mmx95mmMHT-85mmx100mmMHT-85mmx105mmMHT-90mmx100mmMHT-90mmx105mmSIZE40mm x 50mm40mm x 60mm45mm x 55mm50mm x 60mm50mm x 65mm55mm x 75mm60mm x 70mm60mm x 80mm63mm x 73mm63mm x 78mm63mm x 83mm65mm x 75mm65mm x 85mm70mm x 80mm70mm x 90mm75mm x 85mm75mm x 90mm75mm x 95mm80mm x 90mm80mm x 95mm80mm x 100mm80mm x 105mm85mm x 95mm85mm x 100mm85mm x 105mm90mm x 100mm90mm x 105mmPART#MHT-90mmx110mmMHT-100mmx115mmMHT-100mmx120mmMHT-100mmx125mmMHT-100mmx130mmMHT-105mmx125mmMHT-110mmx130mmMHT-110mmx134mmMHT-110mmx140mmMHT-115mmx130mmMHT-115mmx135mmMHT-115mmx140mmMHT-120mmx140mmMHT-120mmx145mmMHT-125mmx140mmMHT-125mmx145mmMHT-130mmx150mmMHT-135mmx160mmMHT-140mmx159mmMHT-140mmx160mmMHT-140mmx165mmMHT-145mmx172mmMHT-150mmx180mmMHT-160mmx190mmMHT-170mmx200mmMHT-180mmx200mmMHT-200mmx230mmSIZE90mm x 110mm100mm x 115mm100mm x 120mm100mm x 125mm100mm x 130mm105mm x 125mm110mm x 130mm110mm x 134mm110mm x 140mm115mm x 130mm115mm x 135mm115mm x 140mm120mm x 140mm120mm x 145mm125mm x 140mm125mm x 145mm130mm x 150mm135mm x 160mm140mm x 159mm140mm x 160mm140mm x 165mm145mm x 172mm150mm x 180mm160mm x 190mm170mm x 200mm180mm x 200mm200mm x 230mmAll items can be cut to length.Prices subject to change without notice. No minimum invoice on parts order.(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 7
Chromed ID Honed Tube1026 Dom Stress Relieved & AnnealedAluminum Coated ID TubingPART#SIZECIHT-1750X1500 1 1/2" X 1 3/4"CIHT-2250X2000 2" X 2 1/4"CIHT-2750X2500 2 1/2" X 2 3/4"CIHT-3250X3000 3" X 3 1/4"CIHT-3500X3250 3 1/4" X 3 1/2"CIHT-4250X4000 4" X 4 1/4"CIHT-5250X5000 5" X 5 1/4"CIHT-6250X6000 6" X 6 1/4"CIHT-6375X6000 6" X 6 3/8"CIHT-7438X7000 7" X 7.438"CIHT-8475X8000 8" X 8.475"CIHT-10475X10000 10" X 10.475"PART#SIZEALHT-2250X2000 2" X 2 1/4"ALHT-2750X2500 2 1/2" X 2 3/4"ALHT-3250X3000 3" X 3 1/4"ALHT-3500X3250 3 1/4" X 3 1/2"ALHT-3750X3500 3 1/2" X 3 3/4"ALHT-4250X4000 4" X 4 1/4"ALHT-4750X4500 4 1/2" X 4 3/4"ALHT-5250X5000 5" X 5 1/4"ALHT-6250X6000 6" X 6 1/4"ALHT-8375X8000 8" X 8 3/8"ALHT-10405X10000 10" X 10.405"Stocked in 12' R/L,all items can be cut to length.6063-T832 Aluminum Air <strong>Cylinder</strong> TubeProduct is seamless extruded and cold-drawn to exacting tolerance and surface finish. Product is generally hard coated on ID,or OD and ID which gives it a tough abrasive-resistant surface. This improves wearability and improves corrosion resistance.American Specifications:KR 2001, ASTM B-210British SpecificationsH19, HE9TFApplicationsUsed for pneumatic cylinder applications requiring very goodcorrosion resistance and/or light weight. Can also be used forlow-pressure oil cylinders (250 PSI or less).Typical Chemical AnalysisC .10 MaxSi .20 – .60Fe .35 MaxMn .10 MaxMG .45 – .90Zn .10 MaxCr .10 MaxTi .10 MaxTypical Mechanical PropertiesTensile Strength (ksi) 40Yield Point (ksi) 35Elongation (% in 2”) 128(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
<strong>Cylinder</strong> RamProducts<strong>Cylinder</strong> Ram Products10 Chrome Plated Standard................................ .375" – 10.000" OD12 Chrome Plated Metric.................................... 12mm – 110mm13 Chrome Plated Induction Hard....................... .75" – 8.000" OD15 Chrome Plated Metric/Induction Hard........... 20mm – 160mm16 Chrome Plated OD Tubing............................. .75" OD – 9.000" OD17 Stainless Steel................................................. 1.000" OD – 6.000" OD17 Chrome Plated Stainless Steel........................ 1.000" OD – 7.000" OD(888) 698.1978 Toll Free • www.crconline.com9
Chrome Plated BarsChemistry Size Range (In.) Yield Strength (PSI)1045/1050 – Hot Rolled Properties 1/2" to 10" 50,000 PSI Approx. Min.1045/1050 – Micro Alloy 1/2" to 5 1/2" 75,000 PSI Min. YieldPSI Thickness: .0005" Minimum (.0127 mm) hard chrome-plated unless otherwise specified.Hardness of Chrome Plate: Rc 68-72Surface Finish: RMS - 12 Maximum (.305 mm)Salt Spray Test: 48 hours minimum in accordance with ASTM B-1117.Length: Any specified length as required up to 24'.Packaging: Collared and boxed or individually fiber-tubed.Identification: Ends can be color-coded to customer requirements or industry standards.Tolerances: Tolerances, in decimals of an inch, provided for undersize variation only:To 2 1/4" (57 mm) inclusive .0015" (0.0381 mm)2 1/2" – 3" (63.50 mm) to 3" (76.20 mm) inclusive .002" (0.05 mm)Over 3" (76.20 mm) to 4" (101.60 mm) inclusive .003" (0.0762 mm)Over 4" (101.60 mm) .005" (0.127 mm)10(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Chrome Rod1045/1050 – 75,000 PSIPART# SIZE DECIMAL SIZECPO-0375 3/8" .375"CPO-0500 1/2" .500"CPO-0625 5/8" .625"CPO-06875 11/16" .6875"CPO-0750 3/4" .750"CPO-0875 7/8" .875"CPO-1000 1" 1.000"CPO-1062 1 1/16" 1.0625"CPO-1125 1 1/8" 1.125"CPO-1250 1 1/4" 1.250"CPO-1375 1 3/8" 1.375"CPO-1500 1 1/2" 1.500"CPO-1625 1 5/8" 1.625"CPO-1750 1 3/4" 1.750"CPO-1875 1 7/8" 1.875"CPO-2000 2" 2.000"CPO-2125 2 1/8" 2.125"CPO-2250 2 1/4" 2.250"CPO-2375 2 3/8" 2.375"CPO-2500 2 1/2" 2.500"PART# SIZE DECIMAL SIZECPO-2625 2 5/8" 2.625"CPO-2750 2 3/4" 2.750"CPO-3000 3" 3.000"CPO-3250 3 1/4" 3.250"CPO-3500 3 1/2" 3.500"CPO-3625 3 5/8" 3.625"CPO-3750 3 3/4" 3.750"CPO-4000 4" 4.000"CPO-4250 4 1/4" 4.250"CPO-4500 4 1/2" 4.500"CPO-4750 4 3/4" 4.750"CPO-5000 5" 5.000"CPO-5500 5 1/2" 5.500"CPO-5750 5 3/4" 5.750"CPO-6000 6" 6.000"CPO-7000 7" 7.000"CPO-8000 8" 8.000"CPO-9000 9" 9.000"CPO-10000 10" 10.000"SpecialSizes alsoQuotedPrices subject to change without notice. • We can also offer chrome plated OD tubing. Call for price and availability.(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 11
Metric Chrome Rod 1045/1050 – 75KPART# METRIC SIZE IMPERIAL SIZEMCPO-12 12 0.472MCPO-13 13 0.512MCPO-14 14 0.551MCPO-15 15 0.591MCPO-16 16 0.630MCPO-18 18 0.709MCPO-20 20 0.787MCPO-22 22 0.866MCPO-25 25 0.984MCPO-28 28 1.102MCPO-30 30 1.181MCPO-32 32 1.260MCPO-35 35 1.377MCPO-36 36 1.417MCPO-40 40 1.574MCPO-45 45 1.771MCPO-50 50 1.968MCPO-55 55 2.165MCPO-56 56 2.205MCPO-60 60 2.362MCPO-63 63 2.480MCPO-65 65 2.559MCPO-70 70 2.755MCPO-75 75 2.952MCPO-80 80 3.149MCPO-85 85 3.346MCPO-90 90 3.543MCPO-95 95 3.740MCPO-100 100 3.937MCPO-105 105 4.133MCPO-110 110 4.33012(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Induction Hardened Chrome Plated BarsChemistry Size Range (In.) Yield Strength (PSI)1045/1050 – Hot Rolled Properties 1/2" to 10" 50,000 PSI Approx. Min.1045/1050 – Micro Alloy 1/2" to 5 1/2" 75,000 PSI Min. Yield*1045/1050 – High Strength Properties 5/8" to 4 1/2" 100,000 PSI Min. Yield*1045 Standard in sizes to 2 1/2"; 1050 Standard in sizes over 2 1/2".TolerancesTolerances, in decimals of an inch, provided for undersize variation only:To 2 1/4" (57 mm) inclusive .0015" (0.0381 mm)2 1/2" – 3" (63.50 mm) to 3" (76.20 mm) inclusive .002" (0.05 mm)Over 3" (76.20 mm) to 4" (101.60 mm) inclusive .003" (0.0762 mm)Over 4" (101.60 mm) .005" (0.127 mm)Surface Hardness: Rc 50 Minimum (other specifications on inquiry)Case Depth: .050" Minimum (1.27 mm) effective case depth unless otherwise specified. (On full length bars, maximum of 1 1/2"(38.10 mm) from either end is neither hardened nor plated.)Effective Case Depth: Effective case depth is the perpendicular distance from the surface of a hardened case to the furthestpoint where a specified level of hardness is maintained. The hardness criterion is Rc 50, except where otherwise specified.Effective case depth should always be determined on the part itself, or on samples or specimens having a heat treated conditionrepresentative of the part under construction. (SAE recommended practice – METHODS OF MEASURING CASE DEPTH –SAE J 423 a.)Plate Thickness: .0005" Minimum (0.127 mm) hard chrome-plated unless otherwise specified.Hardness of Chrome Plate: Rc 68-72Surface Finish: RMS - 12 Maximum (.305 mm)Salt Spray Test: 48 hours minimum in accordance with ASTM B-1117.Length: Any specified length as required up to 24'.Packaging: Collared and boxed or individually fiber-tubed.Identification: Ends can be color-coded to customer requirements or industry standards.(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 13
Induction Hardened Rod1045/1050 - 100,000 PSIPART# SIZE DECIMALIHCP-0750 3/4" .750"IHCP-1000 1" 1.000"IHCP-1125 1 1/8" 1.125"IHCP-1250 1 1/4" 1.250"IHCP-1375 1 3/8" 1.375"IHCP-1500 1 1/2" 1.500"IHCP-1750 1 3/4" 1.750"IHCP-1875 1 7/8" 1.875"IHCP-2000 2" 2.000"ICHP-2125 2 1/8" 2.125"IHCP-2250 2 1/4" 2.250"IHCP-2375 2 3/8" 2.375"IHCP-2500 2 1/2" 2.500"IHCP-2750 2 3/4" 2.750"IHCP-3000 3" 3.000"IHCP-3250 3 1/4" 3.250"IHCP-3500 3 1/2" 3.500"IHCP-4000 4" 4.000"IHCP-4500 4 1/2" 4.500"IHCP-5000 5" 5.000"IHCP-5500 5 1/2" 5.500"IHCP-7000 7" 7.000"IHCP-8000 8" 8.000"Prices subject to change without notice.14(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Induction Hardened Chrome Plated Metric Rod1045/1050-100,000 PSIPART# METRIC SIZE IMPERIAL SIZEIHMCPO-20 20 MM .787IHMCPO-25 25 MM .984IHMCPO-30 30 MM 1.181IHCMPO-35 35 MM 1.377IHMCPO-40 40 MM 1.574IHMCPO-45 45 MM 1.771IHMCPO-50 50 MM 1.968IHMCPO-55 55 MM 2.165IHMCPO-56 56 MM 2.204IHMCPO-60 60 MM 2.362IHMCPO-63 63 MM 2.480IHMCPO-65 65 MM 2.559IHMCPO-70 70 MM 2.755IHMCPO-75 75 MM 2.952IHMCPO-80 80 MM 3.149IHMCPO-85 85 MM 3.346IHMCPO-90 90 MM 3.543IHMCPO-95 95 MM 3.740IHMCPO-100 100 MM 3.937IHMCPO-105 105 MM 4.133IHMCPO-110 110 MM 4.330IHMCPO-115 115 MM 4.527IHMCPO-120 (75k) 120 MM 4.724IHMCPO-125 (75k) 125 MM 4.921IHMCPO-130 (75k) 130 MM 5.118IHMCPO-140 (75k) 140 MM 5.511IHMCPO-150 (75k) 150 MM 5.905IHMCPO-160 (75k) 160 MM 6.299(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 15
Chrome Plated OD TubingPART #SIZECPOD750X500 .750 X .500CPOD1000X500 1.000 X .500CPOD1000X750 1.000 X .750CPOD1375X500 1.375 X .500CPOD1375X750 1.375 X .750CPOD1500X500 1.500 X .500CPOD1500X750 1.500 X .750CPOD1500X1000 1.500 X 1.000CPOD1750X1000 1.750 X 1.000CPOD1750X1250 1.750 X 1.250CPOD2000X750 2.000 X .750CPOD2000X1000 2.000 X 1.00CPOD2000X1250 2.000 X 1.250CPOD2000X1500 2.000 X 1.50CPOD2125X1250 2.125 X 1.250CPOD2250X1000 2.250 X 1.000CPOD2250X1500 2.250 X 1.500CPOD2250X1750 2.250 X 1.750CPOD2375X2000 2.375 X 2.000CPOD2500X1500 2.500 X 1.500CPOD2500X1750 2.500 X 1.750CPOD2500X2000 2.500 X 2.000CPOD2750X2000 2.750 X 2.000CPOD3000X2000 3.000 X 2.000CPOD3000X2250 3.000 X 2.250CPOD3000X2500 3.000 X 2.500CPOD3500X2500 3.500 X 2.500PART #SIZECPOD3500X2750 3.500 X 2.750CPOD3500X3000 3.500 X 3.000CPOD3750X3000 3.750 X 3.000CPOD3750X3250 3.750 X 3.250CPOD4000X3000 4.000 X 3.000CPOD4000X3250 4.000 X 3.250CPOD4000X3500 4.000 X 3.500CPOD4500X3500 4.500 X 3.500CPOD4500X4000 4.500 X 4.000CPOD4750X4000 4.750 X 4.000CPOD4750X4250 4.750 X 4.250CPOD5000X4000 5.000 X 4.000CPOD5000X4500 5.000 X 4.500CPOD5500X4500 5.500 X 4.500CPOD5500X5000 5.500 X 5.000CPOD6000X5000 6.000 X 5.000CPOD6000X5250 6.000 X 5.250CPOD6000X5500 6.000 X 5.500CPOD6500X5500 6.500 X 5.500CPOD6500X6000 6.500 X 6.000CPOD6750X6250 6.750 X 6.250CPOD7000X5000 7.000 X 5.000CPOD7000X6000 7.000 X 6.000CPOD7500X7000 7.500 X 7.000CPOD7750X7000 7.750 X 7.000CPOD8000X7000 8.000 X 7.000CPOD9000X8000 9.000 X 8.000Other sizes available.Please call for pricing and availability.16(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Stainless Steel Rod 17-4 H1150TG&PChrome Plated 17-4 H1150Stainless SteelPART #SSB-1000SSB-1250SSB-1375SSB-1500SSB-1750SSB-2000SSB-2250SSB-2500SSB-2750SSB-3000SSB-3500SSB-4000SSB-4500SIZE1.000 TG&P 17-4SS/H11501.250 TG&P 17-4SS/H11501.375 TG&P 17-4SS/H11501.500 TG&P 17-4SS/H11501.750 TG&P 17-4SS/H11502.000 TG&P 17-4SS/H11502.250 TG&P 17-4SS/H11502.500 TG&P 17-4SS/H11502.750 TG&P 17-4SS/H11503.000 TG&P 17-4SS/H11503.500 TG&P 17-4SS/H11504.000 TG&P 17-4SS/H11504.500 TG&P 17-4SS/H1150PART #SIZESS17-4/CPO-0625 .625SS17-4/CPO-0750 .750SS17-4/CPO-1000 1.000SS17-4/CPO-1250 1.250SS17-4/CPO-1375 1.375SS17-4/CPO-1500 1.500SS17-4/CPO-1625 1.625SS17-4/CPO-1750 1.750SS17-4/CPO-2000 2.000SS17-4/CPO-2250 2.250SS17-4/CPO-2500 2.500SS17-4/CPO-2750 2.750SS17-4/CPO-3000 3.000SS17-4/CPO-3500 3.500SS17-4/CPO-4000 4.000SS17-4/CPO-4500 4.500SS17-4/CPO-5000 5.000All sizes can be cut to length or sold as randoms.Items may be stocked in 12' or 24' random lengths.(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 17
Leading Global Seals ProviderSeals · O-Rings · Seal Kits · Imperial & Metric SizesCall For A CRC Seals <strong>Catalog</strong> Or Visit Our Website(888) 698.1978 Toll Free · www.CRCseals.com
Component Materials20 Aluminum........................................ 2.125” – 10.130”21 Ductile/Cast Iron............................. 2.000” – 16.000”23 Steel Round Bar.............................. 2.000” – 10.000”24 Heavy Wall Mechanical Tube25 Bearing Bronze25 JIC Hydraulic Line Tube25 Tie Rod – 1144 Stress ProofComponent Materials(888) 698.1978 Toll Free • www.crconline.com19
Aluminum Round BarGrade 6061-T6PART#SIZEALUM-2125 2 1/8"ALUM-2500 2 1/2"ALUM-2625 2 5/8"ALUM-3000 3"ALUM-3500 3 1/2"ALUM-4000 4"ALUM-4500 4 1/2"ALUM-4750 4 3/4"ALUM-5000 5"ALUM-5500 5 1/2"ALUM-6000 6"ALUM-6500 6 1/2"ALUM-7000 7"ALUM-8000 8"ALUM-10130 10.130"6061 Aluminum Rod, Bar, and StructuralsHeat treatable aluminum alloy. This offers a wide range of mechanical properties and corrosion resistance.It is easily fabricated and has good formability. This is the most versatile of the heat treatable aluminum alloys.American Specifications:Drawn bar – ASTM B211, QQ-A-225/8Extruded Bar – ASTM B221, AMS 4150, QQ-A-200/8Structural Shapes – ASTM B308, QQ-A-200/16British Specifications: HE 20Typical Chemical AnalysisC .15 – .40Si .40 – .80Fe.70 MaxMn.15 MaxZn 1.2 – .25Cr .04 – .35Ti.15 MaxTypical Mechanical PropertiesT6/T651 bareTensile Strength (ksi) 45Yield Point (ksi) 40Elongation (% in 2”) 17Brinell Hardness 9520(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Continuous Cast Iron BarCast iron bars are usually alloys that contain more than 2% carbon and from 1% to 3% silicon.Cast iron bar is offered in gray and ductile types. The major difference in these types is the shapeand distribution of graphite in their micro structure. Continuous casting virtually eliminates porosity,inclusions, burned-on impurities, and surface flaws.ApplicationsPistons, glands, caps, manifolds, rams, valve bodies.Size Range1" – 20" (25 mm – 508 mm) rdSize and Weight TableRoundMachinabilityHigher machining speeds than steel and there is usually no need for deburring machined parts.The graphite flakes in cast bar act as a self lubricant and provide better lubricity.HardeningThis product can be flame or induction hardened as well as deep hardened.Typical Chemical AnalysisClass 40 65 – 45 – 12 80 – 55 –06C 2.9 – 3.7 3.6 – 3.9 3.6 – 3.9Si 1.6 – 2.7 2.3 – 2.8 2.3 – 2.8Mn .5 – .8 .1 – .4 .1 – .4Typical Mechanical PropertiesClass 40 65 – 45 – 12 80 – 55 –06Tensile Strength (ksi) 40 65 80Yield Point (ksi) N/A 45 55Elongation (% in 2”) N/A 12 6Brinell Hardness 183 – 235 131 – 220 187 – 269(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 21
Ductile Round BarGrade 65-45-12PART#SIZEDUCT-2000 2"DUCT-2500 2 1/2"DUCT-3000 3"DUCT-3500 3 1/2"DUCT-4000 4"DUCT-4500 4 1/2"DUCT-5000 5"DUCT-5500 5 1/2"DUCT-6000 6"DUCT-6500 6 1/2"DUCT-7000 7"DUCT-7500 7 1/2"DUCT-8000 8"DUCT-8500 8 1/2"DUCT-9000 9"DUCT-9500 9 1/2"DUCT-10000 10"DUCT-11000 11"DUCT-12000 12"DUCT-13000 13"DUCT-14000 14"DUCT-16000 16"All sizes are produced oversized to ensure clean up.22(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Hot Finished SteelRound BarPART# SIZE1018HF-20002.000" 1018HF Round Bar1018HF-25002.500" 1018HF Round Bar1018HF-30003.000" 1018HF Round Bar1018HF-35003.500" 1018HF Round Bar1018HF-40004.000" 1018HF Round Bar1018HF-42504.250" 1018HF Round Bar1018HF-45004.500" 1018HF Round Bar1018HF-50005.000" 1018HF Round Bar1018HF-60006.000" 1018HF Round Bar1018HF-70007.000" 1018HF Round Bar1018HF-80008.000" 1018HF Round Bar1018HF-90009.000" 1018HF Round Bar1018HF-10000 10.000" 1018HF Round BarAll sizes cut to length.1018 HF – Low carbon steel with medium manganese content. Has good case hardening properties, fair machinability.Readily brazed and welded. Suitable for shafting and for applications that do not require the greater strength ofhigh carbon and alloy steels. HF conforms to ASTM A108. Material is produced to indicated size.(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 23
Heavy Wall Mechanical TubeASTM-A519/HR 1026PART# SIZEHWT-3000X1000 3" X 1"HWT-3000X1500 3" X 1 1/2"HWT-3500X1500 3 1/2" X 1 1/2"HWT-4000X2000 4" X 2"HWT-4500X2000 4 1/2" X 2"HWT-4500X2500 4 1/2" X 2 1/2"HWT-5000X2000 5" X 2"HWT-5250X2250 5 1/4" X 2 1/4"HWT-5500X3000 5 1/2" X 3"HWT-5750X3250 5 3/4" X 3 1/4"HWT-6000X3000 6" X 3"HWT-6000X4000 6" X 4"HWT-6500X3500 6 1/2" X 3 1/2"HWT-6500X4000 6 1/2" X 4"HWT-7000X4000 7" X 4"HWT-7500X4000 7 1/2" X 4"HWT-8000X6000 8" X 6"HWT-9000X6000 9" X 6"HWT-10000X6000 10" X 6"HWT-10000X6500 10" X 6 1/2"HWT-11000X5000 11" X 5"HWT-12000X6000 12" X 6"HWT-13000X8000 13" X 8"Other sizes available.Prices subject to change without notice. $35.00 Minimum invoice. Please call for pricing and other sizes that are not listed.24(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
CDA 932 Bronze SAE 660JIC Hydraulic Line TubingPART #SIZE – ID X OD660-1500 1.500 SOLID660-2000 2.000 SOLID660-3000 3.000 SOLID660-4000 4.000 SOLID660-5000 5.000 SOLID660-6000 6.000 SOLID660-7000 7.000 SOLIDWe cut everything to length.PART #SIZEJIC250X035 1/4" X .035JIC375X049 3/8" X .049JIC500X049 1/2" X .049JIC500X065 1/2" X .065JIC625X065 5/8" X .065JIC750X049 3/4" X .049JIC750X065 3/4" X .065JIC1000X095 1.00" X .095JIC1250X120 1.25" X .120JIC1500X120 1.50" X .120Stocked and sold in 20' R/L only.Can be cut for UPS shipment.Tie Rod – 1144 Stress ProofTie PART Rod # - 1144 Stress SIZE ProofTR-2500.250 1144 Stress ProofTR-312TR-375TR-437TR-500TR-562TR-625TR-750TR-875TR-1000TR-12500.312 1144 Stress Proof0.375 1144 Stress Proof0.437 1144 Stress Proof0.500 1144 Stress Proof0.562 1144 Stress Proof0.625 1144 Stress Proof0.750 1144 Stress Proof0.875 1144 Stress Proof1.000 1144 Stress Proof1.250 1144 Stress ProofStocked and sold in 12' lengths only.Can be cut for UPS shipment.(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 25
Leading Global Seals ProviderSeals · O-Rings · Seal Kits · Imperial & Metric SizesCall For A CRC Seals <strong>Catalog</strong> Or Visit Our Website(888) 698.1978 Toll Free · www.CRCseals.com
Component Parts28 Internal Threaded Ductile Heads29 Internal Threaded Ductile Heads (wide)30 Aluminum Head Glands30 Aluminum O-Ring Pistons31 Aluminum Polypak Pistons31 Ductile Polypak Pistons32 Head Caps32 Butt Plates33 Eye Brackets33 Clevis Brackets34 MP1 Detachable Mounts34 MP2 Detachable Mounts34 MP4 Detachable Mounts35 Rod Clevis35 Rod Eye36 Pivot Pins – Grooves36 Pivot Pins – Holes37 Spherical Ball Bushing (<strong>Inc</strong>h Series)38 Spherical Ball Bushing (Metric Series)39 Rectangular Flange39 Spherical Rod Eye40 Alignment Coupler41 Ports and Fittings42 Threaded NutsComponent Parts(888) 698.1978 Toll Free • www.crconline.com27
Internal ThreadedDuctile HeadsThreads are UN/UNR Standard ThreadsECDFABPART # BORERODA B C D E F+.003"/ -.003" +.000"/.003"ITH150100 1.500 1.000 2.00 2.00 1.50 0.75 .25 1-3/4"-12ITH200100 2.000 1.000 2.50 2.12 1.93 1.00 .12 2-1/4"-12ITH200112 2.000 1.125 2.50 1.875 1.625 0.75 .19 2-1/4"-12ITH200125 2.000 1.250 2.50 1.875 1.625 1.00 .19 2-1/4"-12ITH250112 2.500 1.125 3.00 2.00 1.75 0.75 .19 2-3/4"-12ITH250125 2.500 1.250 3.00 2.00 1.75 0.75 .19 2-3/4"-12ITH250150 2.500 1.500 3.00 2.38 2.00 1.00 .19 2-3/4"-12ITH250175 2.500 1.750 3.00 2.25 1.88 0.88 .25 2-3/4"-12ITH300100 3.000 1.000 3.50 2.25 2.00 1.00 .19 3-1/4"-12ITH300125 3.000 1.250 3.50 2.25 2.00 1.00 .19 3-1/4"-12ITH300150 3.000 1.500 3.50 2.25 2.00 1.00 .19 3-1/4"-12ITH300175 3.000 1.750 3.50 2.25 2.00 1.00 .19 3-1/4"-12ITH300200 3.000 2.000 3.50 2.50 2.00 1.00 .19 3-1/4"-12ITH325150 3.250 1.500 3.75 2.25 2.00 1.00 .19 3-1/2"-12ITH325175 3.250 1.750 3.75 2.25 2.00 1.00 .19 3-1/2"-12ITH350125 3.500 1.250 4.00 2.25 2.00 1.00 .19 3-3/4"-12ITH350150 3.500 1.500 4.00 2.25 2.00 1.00 .19 3-3/4"-12ITH350175 3.500 1.750 4.00 2.25 2.00 1.00 .19 3-3/4"-12ITH350200 3.500 2.000 4.00 2.25 2.00 1.00 .19 3-3/4"-12ITH350250 3.500 2.500 4.00 2.50 2.12 1.00 .19 3-3/4"-12ITH400150 4.000 1.500 4.50 2.25 2.00 1.00 .19 4-1/4"-12ITH400175 4.000 1.750 4.50 2.25 2.00 1.00 .19 4-1/4"-12ITH400200 4.000 2.000 4.50 2.25 2.00 1.00 .19 4-1/4"-12ITH400225 4.000 2.250 4.50 2.25 2.00 1.00 .19 4-1/4"-12ITH400250 4.000 2.500 4.50 2.50 2.12 1.12 .19 4-1/4"-12ITH400300 4.000 3.000 4.50 2.50 2.12 1.00 .19 4-1/4"-12ITH450175 4.500 1.750 5.00 2.25 2.00 1.00 .19 4-3/4"-12ITH450200 4.500 2.000 5.00 2.25 2.00 1.00 .19 4-3/4"-12ITH450225 4.500 2.250 5.00 2.25 2.00 1.00 .19 4-3/4"-12ITH450350 4.500 3.500 5.00 2.38 2.00 1.00 .19 4-3/4"-12ITH500175 5.000 1.750 5.50 2.25 2.00 1.00 .19 5-1/4"-12ITH500200 5.000 2.000 5.50 2.25 2.00 1.00 .19 5-1/4"-12ITH500250 5.000 2.500 5.50 2.50 2.12 1.12 .19 5-1/4"-12ITH500300 5.000 3.000 5.50 2.50 2.12 1.12 .19 5-1/4"-12ITH600200 6.000 2.000 6.50 2.50 2.12 1.12 .19 6-1/4"-12ITH600250 6.000 2.500 6.50 2.50 2.12 1.12 .19 6-1/4"-12ITH600300 6.000 3.000 6.50 2.50 2.12 1.12 .19 6-1/4"-12ITH600350 6.000 3.500 6.50 2.50 2.12 1.12 .19 6-1/4"-12ITH700300 7.000 3.000 7.50 2.88 2.50 1.12 .56 7-1/4"-8ITH700350 7.000 3.500 7.50 2.88 2.50 1.12 .56 7-1/4"-8ITH700400 7.000 4.000 7.50 2.88 2.50 1.12 .56 7-1/4"-8ITH800400 8.000 4.000 8.50 3.75 3.25 1.50 .88 8-1/4"-8ITH800450 8.000 4.500 8.50 3.75 3.25 1.50 .88 8-1/4"-8ITH800500 8.000 5.000 8.50 3.75 3.25 1.50 .88 8-1/4"-828(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Internal ThreadedDuctile Heads (Wide)Threads are UN/UNR Standard ThreadsCE GDFBAPART #BORE+.003"/-.003"ROD+.000"/-.003"A B C D E F GITHW300175 3.000 1.750 3.50 2.62 2.25 1.00 .56 3-1/4"-12 .38ITHW300200 3.000 2.000 3.50 2.62 2.25 1.00 .56 3-1/4"-12 .38ITHW350175 3.500 1.750 4.00 2.62 2.25 1.00 .56 3-3/4"-12 .38ITHW350200 3.500 2.000 4.00 2.62 2.25 1.00 .56 3-3/4"-12 .38ITHW400200 4.000 2.000 4.50 3.25 2.75 1.25 .56 4-1/4"-12 .38ITHW400250 4.000 2.500 4.50 3.25 2.75 1.25 .56 4-1/4"-12 .38ITHW400300 4.000 3.000 4.50 3.62 3.12 1.38 .19 4-1/4"-12 N/AITHW450200 4.500 2.000 5.00 3.25 2.75 1.25 .56 4-3/4"-12 .38ITHW450250 4.500 2.500 5.00 3.25 2.75 1.25 .56 4-3/4"-12 .38ITHW450300 4.500 3.000 5.00 3.25 2.75 1.25 .56 4-3/4"-12 .38ITHW450350 4.500 3.500 5.00 3.62 3.12 1.38 .19 4-3/4"-12 N/AITHW500200 5.000 2.000 5.50 3.00 2.50 1.12 .56 5-1/4"-12 .38ITHW500250 5.000 2.500 5.50 3.62 3.12 1.38 .81 5-1/4"-12 .56ITHW500300 5.000 3.000 5.50 3.62 3.12 1.38 .81 5-1/4"-12 .56ITHW500350 5.000 3.500 5.50 3.62 3.12 1.38 .81 5-1/4"-12 .56ITHW500400 5.000 4.000 5.50 3.62 3.12 1.38 .19 5-1/4"-12 N/AITHW550250 5.500 2.500 6.00 3.62 3.12 1.38 .81 5-3/4"-12 .56ITHW550300 5.500 3.000 6.00 3.62 3.12 1.38 .81 5-3/4"-12 .56ITHW550350 5.500 3.500 6.00 3.62 3.12 1.38 .81 5-3/4"-12 .56ITHW550400 5.500 4.000 6.00 3.62 3.12 1.38 .81 5-3/4"-12 .56ITHW550450 5.500 4.500 6.00 3.62 3.12 1.38 .19 5-3/4"-12 N/AITHW600250 6.000 2.500 6.50 3.62 3.12 1.38 .81 6-1/4"-12 .56ITHW600300 6.000 3.000 6.50 3.62 3.12 1.38 .81 6-1/4"-12 .56ITHW600350 6.000 3.500 6.50 3.62 3.12 1.38 .81 6-1/4"-12 .56ITHW600400 6.000 4.000 6.50 3.62 3.12 1.38 .81 6-1/4"-12 .56ITHW600450 6.000 4.500 6.50 3.38 2.88 1.25 .81 6-1/4"-12 .62ITHW700250 7.000 2.500 7.50 4.25 3.75 1.50 1.00 7-1/4"-10 .75ITHW700300 7.000 3.000 7.50 4.25 3.75 1.50 1.00 7-1/4"-10 .75ITHW700350 7.000 3.500 7.50 4.25 3.75 1.50 1.00 7-1/4"-8 .75ITHW700400 7.000 4.000 7.50 4.25 3.75 1.50 1.00 7-1/4"-8 .75ITHW800350 8.000 3.500 8.50 4.50 3.75 1.50 1.00 8-1/4"-8 .75ITHW800400 8.000 4.000 8.50 4.50 3.75 1.50 1.00 8-1/4"-8 .75ITHW800450 8.000 4.500 8.50 4.50 3.75 1.50 1.00 8-1/4"-8 .75ITHW800500 8.000 5.000 8.50 4.50 3.75 1.50 1.00 8-1/4"-8 .75ITHW1000400 10.000 4.000 10.50 5.00 4.25 1.50 1.25 10-1/4"-8 1.00ITHW1000500 10.000 5.000 10.50 5.00 4.25 1.50 1.25 10-1/4"-8 1.00(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 29
AAluminum Head GlandsDCBPART #CYLINDERBORE(A)RODHOLE(B)OVERALLLENGTH(C)LENGTHINSIDE TUBE(D)HG-20100A 2" 1" 2 1/2" 2 1/4"HG-20125A 2" 1 1/4" 2 1/2" 2 1/4"HG-25100A 2 1/2" 1" 2 1/2" 2 1/4"HG-25125A 2 1/2" 1 1/4" 2 1/2" 2 1/4"HG-30100A 3" 1" 2 1/2" 2 1/4"HG-30125A 3" 1 1/4" 2 1/2" 2 1/4"HG-30150A 3" 1 1/2" 2 1/2" 2 1/4"HG-35150A 3 1/2" 1 1/2" 2 1/2" 2 1/4"HG-35175A 3 1/2" 1 3/4" 2 1/2" 2 1/4"HG-35200A 3 1/2" 2" 2 1/2" 2 1/4"HG-40150A 4" 1 1/2" 2 1/2" 2 1/4"HG-40175A 4" 1 3/4" 2 1/2" 2 1/4"HG-40200A 4" 2" 2 1/2" 2 1/4"HG-45175A 4 1/2" 1 3/4" 2 1/2" 2 1/4"HG-45200A 4 1/2" 2" 2 1/2" 2 1/4"HG-50150A 5" 1 1/2" 2 1/2" 2 1/4"HG-50200A 5" 2" 2 1/2" 2 1/4"HG-50250A 5" 2 1/2" 2 1/2" 2 1/4"HG-60200A 6" 2" 2 1/2" 2 1/4"HG-60250A 6" 2 1/2" 2 1/2" 2 1/4"HG-60300A 6" 3" 2 1/2" 2 1/4"Aluminum O-Ring PistonsBACPART #CYLINDER BORE(A)LENGTH(B)HOLE SIZE(C)OP-20100075A 2" 1" 3/4"OP-25100075A 2 1/2" 1" 3/4"OP-30100075A 3" 1" 3/4"OP-35100100A 3 1/2" 1" 1"OP-40100100A 4" 1" 1"30(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
AAluminum Polypak PistonsBCPART #CYLINDER BORE(A)LENGTH(B)HOLE SIZE(C)PP-20150075A 2" 1 1/2" 3/4"PP-20175075A 2" 1 3/4" 3/4"PP-25150075A 2 1/2" 1 1/2" 3/4"PP-25175075A 2 1/2" 1 3/4" 3/4"PP-30150075A 3" 1 1/2" 3/4"PP-30175075A 3" 1 3/4" 3/4"PP-35150100A 3 1/2" 1 1/2" 1"PP-35175100A 3 1/2" 1 3/4" 1"PP-35175125A 3 1/2" 1 3/4" 1 1/4"PP-40150100A 4" 1 1/2" 1"PP-40150125A 4" 1 1/2" 1 1/4"PP-40175100A 4" 1 3/4" 1"PP-40175125A 4" 1 3/4" 1 1/4"PP-40200125A 4" 2" 1 1/4"PP-45150125A 4 1/2" 1 1/2" 1 1/4"PP-50175125A 5" 1 3/4" 1 1/4"PP-50200125A 5" 2" 1 1/4"PP-50200175A 5" 2" 1 3/4"PP-60200150A 6" 2" 1 1/2"ADuctile Polypak PistonsBCPART #CYLINDER BORE(A)LENGTH(B)HOLE SIZE(C)PP-20150075D 2" 1 1/2" 3/4"PP-25150075D 2 1/2" 1 1/2" 3/4"PP-30175075D 3" 1 3/4" 3/4"PP-35175100D 3 1/2" 1 3/4" 1"PP-40175100D 4" 1 3/4" 1"PP-45175125D 4 1/2" 1 3/4" 1 1/4"PP-50200125D 5" 2" 1 1/4"PP-60200150D 6" 2" 1 1/2"PP-80300200D 8" 3" 2"(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 31
Head CapsBECADPART # THREADS(A)CYLINDERBORELENGTH(B)O.D.(C)THRU HOLE(D)LIP(E)HC-2500-12 2 1/2" - 12 2" 1 1/4" 3" 1 1/2 1/4"HC-3000-12 3" - 12 2 1/2" 1 1/4" 3 1/2" 1 7/8 1/4"HC-3500-12 3 1/2" - 12 3" 1 3/8" 4" 2 1/4 1/4"HC-4000-12 4" - 12 3 1/2" 1 3/8" 4 1/2" 2 7/8 1/4"HC-4500-12 4 1/2" - 12 4" 1 1/2" 5 1/4" 3 1/4 3/8"HC-5000-12 5" - 12 4 1/2" 1 1/2" 5 3/4" 3 3/4 3/8"HC-5500-12 5 1/2" - 12 5" 1 3/4" 6 1/2" 4 1/4 1/2"HC-5625-12 5 5/8" - 12 5" 1 3/4" 6 1/2" 4 1/4 1/2"HC-5625-8 5 5/8" - 8 5" 1 3/4" 6 1/2" 4 1/4 1/2"HC-6500-12 6 1/2" - 12 6" 1 3/4" 7 1/2" 4 3/4 1/2"HC-6625-12 6 5/8" - 12 6" 1 3/4" 7 1/2" 4 3/4 1/2"HC-6625-8 6 5/8" - 8 6" 1 3/4" 7 1/2" 4 3/4 1/2"HC-7750-8 7 3/4" - 8 7" 2" 9" 6 1/2"HC-8750-8 8 3/4" - 8 8" 2" 10" 6 1/4 1/2"Butt PlatesB DACPART #BORE(A)LENGTH(B)BP-2000-500 2" 1/2" 2 1/2" 1/4"BP-2500-500 2 1/2" 1/2" 3" 1/4"BP-3000-500 3" 1/2" 3 1/2" 1/4"BP-3500-500 3 1/2" 1/2" 4" 1/4"BP-4000-500 4" 1/2" 4 1/2" 1/4"BP-4500-500 4 1/2" 1/2" 5" 1/4"BP-5000-750 5" 3/4" 5 1/2" 3/8"BP-5000-1000 5" 1" 5 5/8" 3/8"BP-6000-750 6" 3/4" 6 5/8" 3/8"BP-6000-1000 6" 1" 6 5/8" 3/8"BP-7000-750 7" 3/4" 7 3/4" 3/8"BP-7000-1000 7" 1" 7 3/4" 3/8"O.D.(C)LIP(D)32(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
LRCBEye BracketsMRE RMaterial: All are in cast ironFFLCDDIA.MDDDIA.REPART # CB CD DD E F FL LR M MR RDEB-05 3/4 1/2 13/32 2 1/2 3/8 1 1/8 3/4 1/2 9/16 1.63DEB-07 1 1/4 3/4 17/32 3 1/2 5/8 1 7/8 1 1/4 3/4 7/8 2.56DEB-10 1 1/2 1 21/32 4 1/2 3/4 2 1/4 1 1/2 1 1 1/4 3.25DEB-13 2 1 3/8 21/32 5 7/8 3 2 1/8 1 3/8 1 5/8 3.81DEB-17 2 1/2 1 3/4 29/32 6 1/2 7/8 3 1/8 2 1/4 1 3/4 2 1/8 4.95DEB-17H 2 1/2 1 3/4 29/32 6 1/2 1 1/8 3 3/8 2 1/4 1 3/4 2 1/8 4.95“H” Denotes heavy baseLRCWCBCWMRClevis BracketsME BAMaterial: All are in cast ironFCDDIA.FLMDDDIA.EAAPART # AA BA CB CD CW DD E F FL LR M MRDCB-05 2.3 1 5/8 .765 1/2 1/2 3/8 - 24 2 1/2 3/8 1 1/8 1/2 1/2 9/16DCB-06 2.9 2 1/16 1.265 3/4 5/8 1/2 - 20 3 5/8 1 7/8 1 3/4 1 1/16DCB-07 3.6 2 9/16 1.265 3/4 5/8 1/2 - 20 3 1/2 5/8 1 7/8 1 1/16 3/4 1 1/16DCB-10 4.6 3 1/4 1.515 1 3/4 5/8 - 18 4 1/2 3/4 2 1/4 1 1/4 1 1 1/8DCB-13 5.4 3 13/16 2.032 1 3/8 1 5/8 - 18 5 7/8 3 1 7/8 1 3/8 1 3/4DCB-20 8.1 5 3/4 2.531 2 1 1/4 1 - 14 7 1/2 1 3 1/2 2 1/8 2 2 1/8(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 33
Custom machined, cast, forged, or welded parts to customer specification • ISO mounts and hardware are also availableCBCMP1 Detachable MountsLRERGMaterial: All are in cast ironFFLCDDIA.DD DIA.OR TAPPEDGDPART # CD FL F B C D ER G LR TAPPED D-D DIA.DMP1-15 .502 .75 .38 .76 .50 2.00 .62 1.43 .62 1/4 - 28 .28DMP1-2 .502 .75 .38 .76 .50 2.50 .62 1.84 .62 5/16 - 24 .34DMP1-25 .502 .75 .38 .76 .50 3.00 .62 2.19 .62 5/16 - 24 .34DMP1-32 .752 1.25 .63 1.26 .62 3.75 .87 2.77 .87 3/8 - 24 .41DMP1-4 .752 1.25 .63 1.26 .62 4.50 .87 3.32 .87 3/8 - 24 .41DMP1-5 .752 1.25 .63 1.26 .62 5.50 .87 4.10 .87 1/2 - 20 .53DMP1-6 1.002 1.50 .75 1.51 .75 6.50 1.25 4.88 1.13 1/2 - 20 .53While ordering add “T” for tapped or “H” for thru hole at the end of part no.CBCMP2 Detachable MountsLRERGMaterial: All are in cast ironCDDIA.FFLDD DIA.OR TAPPEDGDPART # CD FL F B C D ER G TAPPED D-D DIA.DMP2-15 .502 1.13 .38 .76 .50 2.00 .62 1.43 1/4 - 28 .28DMP2-2 .502 1.13 .38 .76 .50 2.50 .62 1.84 5/16 - 24 .34DMP2-25 .502 1.13 .38 .76 .50 3.00 .62 2.19 5/16 - 24 .34DMP2-32 .752 1.88 .63 1.26 .62 3.75 .87 2.77 3/8 - 24 .41DMP2-4 .752 1.88 .63 1.26 .62 4.50 .87 3.32 3/8 - 24 .41DMP2-5 .752 1.88 .63 1.26 .62 5.50 .87 4.10 1/2 - 20 .53DMP2-6 1.002 2.25 .75 1.51 .75 6.50 1.12 4.88 1/2 - 20 .53While ordering add “T” for tapped or “H” for thru hole at the end of part no.CBMP4 Detachable MountsERD GMaterial: All are in cast ironFFLCDDIA.DD DIA.OR KKGDPART # CD FL F CB D ER G KK D-D DIA.DMP4-15 .502 1.13 .38 .75 2.00 .62 1.43 1/4 - 28 .28DMP4-2 .502 1.13 .38 .75 2.50 .62 1.84 5/16 - 24 .34DMP4-25 .502 1.13 .38 .75 3.00 .62 2.19 5/16 - 24 .34DMP4-32 .752 1.88 .63 1.25 3.75 .87 2.77 3/8 - 24 .41DMP4-4 .752 1.88 .63 1.25 4.50 .87 3.32 3/8 - 24 .4134(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
ERCWCBCWCHFRod ClevisMaterial: All are in cast iron except 07M & 10Mwhich are in steel forgingLCECDKK TAP THRUPART # CB CD CE CH CW F L A KK ERRC-05 .765 1/2 1 1/2 1 1/2 1 3/4 3/4 7/16 - 20 1/2RC-07 1.265 3/4 2 3/8 1 1/4 5/8 1 1/4 1 1/4 1 1/8 3/4 - 16 3/4RC-07M 1.265 3/4 2 1/8 1 3/8 5/8 1 1/4 1 1 1/8 3/4 - 16 3/4RC-10 1.515 1 3 1/8 1 1/2 3/4 1 1/2 1 1/2 1 5/8 1 - 14 1RC-10M 1.515 1 2 15/16 1 1/2 3/4 1 5/8 1 5/16 1 5/8 1 - 14 1RC-13 2.032 1 3/8 4 1/8 2 1 2 2 1/8 2 1 1/4 - 12 1 3/8RC-13M 2.032 1 3/8 3 3/4 2 1 2 1 3/4 2 1 1/4 - 12 1 3/8RC-17 2.531 1 3/4 4 1/2 2 3/8 1 1/4 2 3/8 2 1/4 2 1/4 1 1/2 - 12 1 3/4RC-20 2.531 2 5 1/2 2 15/16 1 1/4 2 15/16 2 1/2 3 1 7/8 - 12 2RC-25 3.032 2 1/2 6 1/2 3 1/2 1 1/2 3 1/2 3 3 1/2 2 1/4 - 12 2 1/2RC-30 3.032 3 6 3/4 3 7/8 1 1/2 3 7/8 3 1/4 3 1/2 2 1/2 - 12 2 3/4RC-30M 3.032 3 6 3/4 3 7/8 1 1/2 3 7/8 3 1/4 3 1/2 2 1/2 - 12 3RC-35 4.032 3 1/2 8 1/2 5 2 5 4 4 1/2 3 1/4 - 12 3 1/2RC-35M 4.032 3 1/2 7 3/4 5 2 5 4 1/4 3 1/2 3 1/4 -12 3 1/2RC-40 4.032 4 10 6 1/8 2 1/4 6 1/8 4 1/2 5 1/2 4 - 12 42xCDCBERRod EyeMaterial: All are in cast iron except 07M & 10Mwhich are in steel forgingCDCACDKKPART # A CA CB CD ER KKDE-05 3/4 1 1/2 3/4 1/2 5/8 7/16 - 20DE-07 1 1/8 2 1/16 1 1/4 3/4 7/8 3/4 - 16DE-10 1 5/8 2 13/16 1 1/2 1 1 3/16 1 - 14DE-10M 1 1/8 2 3/8 1 1/2 1 1 7/16 7/8 - 14DE-13 2 3 7/16 2 1 3/8 1 9/16 1 1/4 - 12DE-17 2 1/4 4 2 1/2 1 3/4 2 1 1/2 - 12DE-20 3 5 2 1/2 2 2 1/2 1 7/8 - 12DE-20M 2 1/4 4 3/8 2 1/2 2 2 7/8 1 3/4 - 12(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 35
Pivot Pins – GroovesMaterial: MS with Black OxideCDCBDAEPART # CD A B C D EDP-05G .500 .468 2.094 1.875 .041 .109DP-07G .750 .704 2.875 2.625 .048 .125DP-10G 1.000 .940 3.375 3.125 .048 .125DP-13G 1.375 1.291 4.485 4.187 .056 .149DP-17G 1.750 1.650 5.547 5.188 .068 .180DP-20G 2.000 1.886 5.547 5.188 .068 .180DP-25G 2.500 2.360 6.625 6.188 .086 .219DP-30G 3.000 2.838 6.780 6.250 .103 .265DP-35G 3.500 3.316 8.845 8.125 .120 .360DP-40G 4.000 3.792 9.845 9.125 .120 .360CBCPivot Pins – HolesMaterial: MS with Black OxideD DIA.ACDPART # CD A B C DDP-05H .500 2.281 1.938 .172 .106DP-07H .750 3.094 2.719 .188 .140DP-10H 1.000 3.594 3.219 .188 .140DP-13H 1.375 4.656 4.250 .203 .173DP-17H 1.750 5.656 5.250 .203 .173DP-20H 2.000 5.719 5.281 .219 .204DP-25H 2.500 6.781 6.313 .234 .219DP-30H 3.000 6.844 6.344 .250 .250DP-35H 3.500 8.969 8.406 .282 .312DP-40H 4.000 9.969 9.409 .282 .31236(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Spherical Ball Bushing<strong>Inc</strong>h SeriesB DCASIZE PART# BEARING WIDTH RACE O.D. RACE WIDTH1/2" SB12ES 0.437 0.875 0.3755/8" SB15ES 0.469 1.0625 0.4693/4" SB19ES 0.656 1.250 0.5627/8" SB22ES 0.765 1.4375 0.6561" SB25ES 0.875 1.625 0.7501 1/4" SB31ES 1.093 2.000 0.9371 3/8" SB34ES 1.187 2.1875 1.0311 1/2" SB38ES 1.312 2.4375 1.1251 3/4" SB44ES 1.531 2.8125 1.3122" SB50ES 1.750 3.1875 1.5002 1/4" SB57ES 1.969 3.5625 1.6872 1/2" SB63ES 2.187 3.9375 1.8752 3/4" SB69ES 2.406 4.375 2.0623" SB76ES 2.625 4.750 2.2503 1/4" SB82ES 2.844 5.125 2.4373 1/2" SB88ES 3.062 5.500 2.6253 3/4" SB95ES 3.281 5.875 2.8124" SB101ES 3.500 6.250 3.0004 1/2" SB114ES 3.937 7.000 3.3755" SB127ES 4.375 7.750 3.7506" SB152ES 4.750 8.750 4.125Add – 2RS to part# for sealed bushing(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 37
Spherical Ball BushingMetric SeriesB DCASIZE PART# BEARING WIDTH RACE O.D. RACE WIDTH15MM SBMM15ES 12 26 917MM SBMM17ES 14 30 1020MM SBMM20ES 16 35 1225MM SBMM25ES 20 42 1630MM SBMM30ES 22 47 1835MM SBMM35ES 25 55 2040MM SBMM40ES 28 62 2245MM SBMM45ES 32 68 2550MM SBMM50ES 35 75 2860MM SBMM60ES 44 90 3670MM SBMM70ES 49 105 4080MM SBMM80ES 55 120 4590MM SBMM90ES 60 130 50100MM SBMM100ES 70 150 55110MM SBMM110ES 70 160 55120MM SBMM120ES 85 180 70Add – 2RS to part# for sealed bushing38(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Rectangular FlangeMaterial: All are in cast ironFUFTFFB(4 HOLES)AA R EHC (4HOLES)PART # UF TF FB E R F AA HCDF 15 3 3/8 2 3/4 5/16 2 1.43 3/8 2.02 .28DF 20 4 1/8 3 3/8 3/8 2 1/2 1.84 3/8 2.60 .34DF 25 4 5/8 3 7/8 3/8 3 2.19 3/8 3.10 .34DF 32 5 1/2 4 11/16 7/16 3 3/4 2.76 5/8 3.90 .41DF 40 6 1/4 5 7/16 7/16 4 1/2 3.32 5/8 4.70 .41DF 50 7 5/8 6 5/8 9/16 5 1/2 4.1 5/8 5.79 .53DF 60 8 5/8 7 5/8 9/16 6 1/2 4.88 3/4 6.90 .53Spherical Rod EyeMaterial: All are in cast ironLECDER(MAX.)LUBEFITTINGCEAEXKKJLPART # CD - .0005 A CE EX ER LE KK JLDRES-05 .5000 11/16 7/8 7/16 7/8 3/4 7/16 - 20 7/8DRES-07 .7500 1 1 1/4 21/32 1 1/4 1 1/16 3/4 - 16 1 5/16DRES-10 1.0000 1 1/2 1 7/8 7/8 1 3/8 1 7/16 1 - 14 1 1/2DRES-13 1.3750 2 2 1/8 1 3/16 1 3/16 1 7/8 1 1/4 - 12 2DRES-17 1.7500 2 1/8 2 1/2 1 17/32 2 3/16 2 1/8 1 1/2 - 12 2 1/4DRES-20 2.0000 2 7/8 2 3/4 1 3/4 2 5/8 2 1/2 1 7/8 - 12 2 3/4(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 39
Alignment Coupler1/16 RADIAL FLOAT1˚ SPHERICAL MOTIONAG ACROSSFLATABMaterial: All are in steelFSHANKDIA.E DE HACROSSCFLATPART # A B C D E F G H MAXPULL AT YIELDDAC-250F 1/4-28 7/8 1 1/4 1/4 5/8 .245 3/16 13/16 4,000DAC-312F 5/16-24 7/8 1 1/4 1/4 5/8 .308 1/4 13/16 4,000DAC-375F 3/8-24 7/8 1 1/4 1/4 5/8 .370 5/16 13/16 5,000DAC-437F 7/16-20 1 1/4 2 1/2 3/4 5/8 9/16 1 1/8 10,000DAC-500F 1/2-20 1 1/4 2 1/2 3/4 5/8 9/16 1 1/8 14,000DAC-625F 5/8-18 1 1/4 2 1/2 3/4 5/8 1/2 1 1/8 14,000DAC-750F 3/4-10 1 3/4 2 5/16 5/16 1 1/8 31/32 7/8 1 1/2 34,000DAC-875F 7/8-14 1 3/4 2 5/16 5/16 1 1/8 31/32 7/8 1 1/2 34,000DAC-1000F 1-14 2 1/2 2 15/16 1/2 1 5/8 1 3/8 1 1/4 2 1/4 64,000DAC-1250F 1 1/4-12 2 1/2 2 15/16 1/2 1 5/8 1 3/8 1 1/4 2 1/4 64,000DAC-1375F 1 3/8-12 2 1/2 2 15/16 1/2 1 5/8 1 3/8 1 1/4 2 1/4 64,00040(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
NPT Ports National Pipe Thread PortsSIZEPSI1/8" - NPT 30001/4" - NPT 30003/8" - NPT 30001/2" - NPT 30003/4" - NPT 30001" - NPT 3000ORB Ports O-Ring Boss PortsSIZEPSI#4 (7/16-20) 3000#6 (9/16-18) 3000#8 (3/4-16) 3000#10 (7/8-14) 3000#12 (1 1/16-12) 3000#16 (1 5/16-12) 3000#24 (1 7/8-12) 3000NPT Coupling National Pipe Thread CouplingSIZEPSI1/4" - NPT 30003/8" - NPT 30001/2" - NPT 30003/4" - NPT 30001" - NPT 3000NPT Elbow National Pipe Thread ElbowSIZEPSI1/4" - NPT 30003/8" - NPT 30001/2" - NPT 30003/4" - NPT 30001" - NPT 3000NPT Tee National Pipe Thread TeeSIZEPSI3/8" - NPT 30001/2" - NPT 30003/4" - NPT 30001" - NPT 3000ORB Elbow PortsSIZEPSIORB 90 - #4 3000ORB 90 - #6 3000ORB 90 - #8 3000ORB 90 - #10 3000ORB 90 - #12 3000ORB 90 - #16 3000(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com 41
Threaded Nuts Nylon LockingPART# SIZE Nominal Hex (A) Thickness (B) Width Across Corners (C)NUT– 0750L 3/4" – 16 UNF 1.065 0.875"+/- .031 1.210"NUT– 0875L 7/8" – 14 UNF 1.25 0.985"+/- .031 1.420"NUT–1000L 1" – 14 UNF 1.625 1.060"+/- .031 1.646"NUT–1125L 1 1/8" – 12 UNF 1.812 1.165"+/- .031 1.855"NUT–1250L 1 1/4" – 12 UNF 2.00 1.105"+/- .031 2.282"NUT–1500L 1 1/2" – 12 UNF 2.375 1.300"+/- .031 2.703"NUT–1750SL (Short) 1 3/4" – 12 UNF 2.75 1.475"+/- .063 3.121"NUT–1750LL (Long) 1 3/4" – 12 UNF 2.75 2.350"+/- .063 3.121"NUT–2000SL (Short) 2.00" – 12 UNF 3.125 1.650"+/- .063 3.558"NUT–2000LL (Long) 2.00" – 12 UNF 3.125 2.295"+/- .063 3.558"NUT–2250L 2 1/4" – 12 UNF 3.50 1.950"+/- .063 3.988"NUT–2500L 2 1/2" – 12 UNF 4.00 2.180"+/- .063 4.543"42(888) 698.1978 Toll Free • (251) 947.5203 Fax • www.crconline.com
Leading Global Seals ProviderSeals · O-Rings · Seal Kits · Imperial & Metric SizesCall For A CRC Seals <strong>Catalog</strong> Or Visit Our Website(888) 698.1978 Toll Free · www.CRCseals.com
P.O. Box 249 • 22927 McAuliffe Dr. • Robertsdale, AL 36567-0249(888) 698.1978 Toll Free • (251) 947.5200 • (251) 947.5203 Faxwww.crconline.comCRC-3069; 03/13
