<strong>Excel</strong> WebsiteVisit www.excel-networking.com to keep up to date on all the latest news,product releases and information on <strong>Excel</strong>.Downloads include:• Catalogues• Specification Sheets• Independant Test Certificates• Conformance Sheets• Cabling Partner Programme• Labeling Software• Case Studies• White Papers• News and Events Calendar
Essential Products from <strong>Excel</strong><strong>Essentials</strong>ToolingCable Cutters 128Cable Strippers / Slitters 129Crimp Tools 132UTP/FTP Cable Punchdown Tools 133T28 and T36 Cable Tackers 133Consumables<strong>Excel</strong> Mounting Hardware - Back Boxes 134<strong>Excel</strong> Cable Management Bars 134<strong>Excel</strong> Blanking Plates and Letterbox Panels 135Cage Nuts 135RJ45 Connectors 135RJ45 Strain Relief Boots 136Floor & Basket Matting 136Cable Drum Dispenser Kit 137Cable Ties 137, 138Fixtures & Fittings (PVC Installation Tape, Cable Clips, Woodscrews & Wallplugs) 139Extension Leads and Power Cables 140Telephone Adaptors and Extensions 140, 141<strong>Excel</strong> Connection Boxes 142, 143<strong>Excel</strong> Terminal Strips 143Curing Oven 144Polishing Plate & Pucks 144, 145Fibre Scribes 145Kevlar Scissors 146Splice Bridge and Protector 146Disposal Bins 146Cleaning Wipes 147Epoxy Syringe and Needle 147Expotek Heat Curing Epoxy 147Lapping Film 148Blanking Plugs 148Isopropyl Alcohol (IPA) 148Miniature Cotton Buds 149Cable Glands with Strain Relief 149<strong>Excel</strong> Cold Cure Termination System – Connector Packs 149Containment<strong>Excel</strong> Mini Trunking 150<strong>Excel</strong> Maxi Trunking 152<strong>Excel</strong> Dry Lining Boxes 154<strong>Excel</strong> Flexible Conduit and Cable Binding Wrap 154, 155<strong>Excel</strong> Floor Boxes and Accessories 158Please check with your local <strong>Excel</strong> Sales Office or distributor for in country product availability127
Essential Products from <strong>Excel</strong>ToolingCable CuttersA range of cable cutting and preparation tools are available to suit awide range of copper and fibre cables. These come competitivelypriced and of a high quality.Side CuttersFeatures● Suitable for general purposecutting and trimming● Vinyl dipped handles● Recommended for use with<strong>Excel</strong> Toolless JacksDescriptionPart NumberSide cutters 202-043Cable CuttersFeatures● Range of sizes available forcables up to 13mm in diameter● Flattening of the cable isprevented by the rounded jawsposition● Blue vinyl non-slip handle gripsDescriptionPart NumberCutting dia
Essential Products from <strong>Excel</strong>Cable Cutters100 Pair CutterFeatures● Up to 100 pair telephone cablecan be cut● Moulded plastic handles● Return spring built in● Blade is kept closed by latchwhen not in useDescriptionPart Number100 Pair Cutter 202-048Cable Strippers/SlittersUTP/FTP Cable StrippersThe toggle stripper removes the outer sheath of cables with anoutside diameter of upto 11mm by simply rotating the tool in 360°around the cable.Features● Lightweight, easy to use● Supplied with set of blades● Ensures nick free preparationof cablesDescriptionPart NumberToggle Stripper - removes jacket of UTP/FTP 45-514Fibre Optic Patch Cable Jacket StripperFeatures● Suitable for tight jacket cables– 2.4-3.2mm● Blade returned to open positionby spring action designDescriptionPart NumberJacket Stripper 202-049129
Essential Products from <strong>Excel</strong>Cable Strippers/SlittersHeavy Duty Jacket Stripper with Swivel BladeFeatures● Suitable for cables of 8-25mmdiameter● Can be used for CST FibreCable● Blade depth is adjustable toprevent damage to subunits byup to 4.5mm● Consistency provided by alocking blade● Circumferential and longitudinalcuts can be performed by ablade which rotates by 90degrees● Six rollers support the cableduring cuttingDescriptionPart NumberHeavy duty stripping tool 8-25mm 202-061Spare blade 202-062Peg Style Jacket StripperFeatures● Stripping tools available to suit14.3mm diameter cables● Blades for radial andlongitudinal cuts● Blade depth can be adjustableto suit thickness of jacket● Three straight and one roundblade supplied with each toolDescriptionPart Numberup to 3.2mm cable diameter (grey handle) 202-0633.2-5.5mm cable diameter (blue handle) 202-0646.4-14.3mm cable diameter (blue handle) 202-0654.8-8mm cable diameter (black handle) 202-066Spare blades for 45-162, 45-163, 45-165 202-067Spare blades for 45-164 202-068Fibre Optic Clauss Buffer/Jacket StripperFeatures● Blade has two holes● Tight jacket patch cable isstripped by 1mm hole● Spring action handles can belocked when not in use● 140µm hole strips 250µmprimary bufferDescriptionPart NumberClauss Fibre stripper 202-089130
Essential Products from <strong>Excel</strong>Cable Strippers/SlittersFibre Optic Primary Buffer StrippersFeatures● Industry standard tool for theremoval of 250µm buffers● Blade has precision laser drilled127µm hole for all 125µm cladfibres● Requires no adjustment, factoryset● Handles return jaws to openposition when not in useDescriptionPart NumberStripping tool 202-090Fibre Optic Tri Hole StrippersFeatures● Incorporates the same bufferremoval technology as theindustry standard (O 103-S) tool● Tri-hole tool removes 2-3mmtight jacket, 900µm secondarybuffer and 250µm primarycoatings● Dual-hole versions for 2-3mmand 900µm removal, or 2-3mmand 250µm removal● Requires no adjustment, factoryset● Jaws return to the openposition when not in useDescriptionPart NumberTri-hole 2-3mm, 900µm, and 250µm stripper 202-078Fibre Optic Clauss No Nik Buffer StrippersFeatures● Industry standard tools forremoving secondary andprimary buffers from fibres● Range of sizes with cuttingdiameter 102µm to 1.37mm● Plastic heads support the fibreon both sides of the blades● Strips fibre without cuts,scratches or niksDescriptionPart NumberGold 152µm 202-072Red 203µm 202-073Light Blue 254µm 202-074White 305µm 202-075Dark Green 356µm 202-076Yellow 457µm 202-077131
Essential Products from <strong>Excel</strong>Crimp ToolsUTP/FTP Cable Crimp ToolThe AMP RJ45 Crimp Tool is compatible with the entire utp and FTPstandard connector range.Features● High quality Ampmanufactured product● Ratchet action ensuresreliable crimpingDescriptionPart NumberAmp RJ45 fixed die, modular plug, crimp tool 22-0010Coaxial and UTP/FTP Cable Crimp ToolsThe Ideal Crimpmaster is one of the most versatile crimptoolsavailable. A wide range of die sets mean it is suitable for coax as wellas UTP and FTP cable.Features● High quality ratchet tool● Easily interchangeable dies● Maximum versatility in asingle toolDescriptionPart NumberCrimpmaster crimp tool frame 30-506Crimpmaster die set, 8 position RJ45, Amp compatible 30-560Crimpmaster die set, RG58, 59, 62, URM70 30-581Fibre Optic Connector Crimp ToolFeatures● Used for crimping connectorstrain relief crimp rings● Correct pressure is applied asthe cycle ratchet prevents thetool being opened until the dieshave been completely closed● Different connector styles aresuited with a wide range oftoolsCavity Shapes Cavity Size Part Number1 round, 2 hex .105", .090", .190" 202-0693 hexagonal .151", .178", .213" 202-0703 round .138", .165", .195" 202-071132
Essential Products from <strong>Excel</strong>UTP/FTP Cable Punchdown ToolsPunchdown tools are used to terminate cable into IDC Blocks in PatchPanels or work outlets.Features● Choose from Krone or 110 IDC● Either tool will terminate KATTIDC product35-485DescriptionPart NumberPunchdown tool, BT reference 2A 35-480110 punchdown tool 35-485Replacement blade set for 35-485 35-49535-480T28 and T36 Cable TackersThe rapid T28 and T36 are High Quality Fast Action Cable Tackersdesigned specifically for voice and data cabling.Features● Suitable for Cables up to4.5mm Diameter (T28)● Suitable for Cables up to6.0mm Diameter (T36)● Choice of Galv or White StaplesDescriptionPart NumberT28 Cable Tacker unit 350-075T28 11mm Galv Staples, Pack of 5000 350-077T28 11mm White Staples, Pack of 5000 350-079T36 Cable Staples Unit 350-080T36 14mm Galv Staples, Pack of 5000 350-082T36 14mm White Staples, Pack of 5000 350-084133
Essential Products from <strong>Excel</strong>Consumables<strong>Excel</strong> Mounting Hardware - Back BoxesA range of single and double gang high quality Back Boxes.Features● Choice Of SingleOr Double Gang● Choice Of DepthDescriptionPart NumberSingle Gang 27mm Deep Back Box 100-612Single Gang 32mm Deep Back Box 100-614Single Gang 37mm Deep Back Box 100-616Single Gang 47mm Deep Back Box 100-618Double Gang 27mm Deep Back Box 100-619Double Gang 37mm Deep Back Box 100-620Double Gang 47mm Deep Back Box 100-622<strong>Excel</strong> Cable Management BarsA wide range of 19” Vertical Cable Management bars are available.Features● Metal or PlasticManagement Hoops● 1 and 2u Options●●Horizontal and Vertical HoopsCage Nut Set includedDescriptionPart Number1u 5 Way Chrome Cable Management Bar 100-0311u Black Bar, 4 Vertical Metal Hoops 100-5821u Black Bar, 5 Vertical Plastic Hoops 100-5861u Black Bar, 3 Vertical, 2 Horizontal Metal Hoops 100-5902u Black Bar, 4 Vertical Metal Hoops 100-594Chrome version, see page 12 for full details134
Essential Products from <strong>Excel</strong><strong>Excel</strong> Blanking Plates and Letterbox PanelsTo improve cabinet appearance Blank Plates can be installed to coverunused space. Letterbox Panels allow patch cords to be fed to orfrom the rear of the cabinet.Features●Enhances Cabinet AppearanceDescriptionPart Number1u Black Blanking Plate 100-5982u Black Blanking Plate 100-6023u Black Blanking Plate 100-6061u Black Letterbox Panel 100-6101u Black Brush Strip Letterbox Panel 100-599Cage NutsCage nuts are used to fit equipment to the 19” profiles.DescriptionCage Nuts, pack of 50Part NumberM6CNURJ45 ConnectorsA wide range of AMP RJ45 connectors are available to suit bothunshielded and shielded twisted pair cables.DescriptionPart NumberAMP RJ45 Plug, Solid UTP 24-0002AMP RJ45 Plug, Stranded UTP 24-0004AMP RJ45 Plug, Solid FTP 24-0006AMP RJ45 Plug, Stranded FTP 24-0008135
Essential Products from <strong>Excel</strong>Cable Drum Dispenser KitThe Rack-A-Tier Cable Drum Dispenser kit is a simple, cost effectivemethod of installing multipair, fibre or other cables from drums of mostsizes.DescriptionPart NumberCable Drum Dispenser Kit 23-0040Hook and Loop Cable TiesEasy to install and remove, hook and loop cable ties will not crush ordamage copper or fibre cables.Features● Quick and Easy Installation● Reuseable● Will not crush cables● Choice of colour● 20mm wideDescriptionPart Number230mm Red Pack of 20180-080-PACK20230mm White Pack of 20180-079-PACK20230mm Red Pack of 20180-080-PACK20230mm Green Pack of 20180-081-PACK20230mm Blue Pack of 20180-082-PACK20330mm Black Pack of 20180-083-PACK20330mm White Pack of 20180-084-PACK20330mm Blue Pack of 20180-087-PACK20<strong>Excel</strong> Hook & Loop 25m Reel of individual Black ties 180-094<strong>Excel</strong> Hook & Loop 25m Reel of individual Blue ties 180-096<strong>Excel</strong> Hook & Loop 25m Reel of individual Green ties 180-098137
Essential Products from <strong>Excel</strong>Cable TiesThe <strong>Excel</strong> range of high quality nylon cable ties are available in Blackor Natural in a wide range of sizes and with a choice of pack type.DescriptionPart Number2.5 x 75mm Natural x 1000, Standard Pack CV-075K2.5 x 100mm Natural x 100, Value Pack CV-1002.5 x 100mm Black x 100, Value Pack CV-100B2.5 x 100mm Natural x 1000, Standard Pack CV-100K2.5 x 100mm Black x 1000, Standard Pack CV-100KB2.5 x 142mm Natural x 100, Standard Pack CV-140S2.5 x 142mm Black x 100, Standard Pack CV-140SB4.8 x 160mm Natural x 100, Standard Pack CV-160L4.8 x 160mm Black x 100, Standard Pack CV-160LB4.0 x 180mm Natural x 100, Standard Pack CV-1803.6 x 180mm Black x 100, Standard Pack CV-180B4.0 x 190mm Natural x 100, Standard Pack CV-1904.0 x 190mm Black x 100, Standard Pack CV-190B2.5 x 203mm Natural x 100, Standard Pack CV-2002.5 x 203mm Black x 100, Standard Pack CV-200MB3.6 x 265mm Natural x 100, Standard Pack CV-2653.6 x 265mm Black x 100, Standard Pack CV-265B7.6 x 240mm Natural x 100, Standard Pack CV-240L7.6 x 240mm Black x 100, Standard Pack CV-240LB4.8 x 280mm Natural x 100, Standard Pack CV-2804.8 x 280mm Black x 100, Standard Pack CV-280B4.8 x 365mm Natural x 100, Standard Pack CV-3687.6 x 380mm Natural x 100, Standard Pack CV-3807.6 x 380mm Black x 100, Standard Pack CV-380B4.8 x 635mm Black x 100, Standard Pack CV-368B2.5 x 203mm Natural x 100, Standard Pack CV-200MCable Tie CradlesCable Tie Cradle 9.5 x 15mm, pack of 100, Natural 180-220Cable Tie Cradle 16 x 23mm, pack of 100, Natural 180-222Identification PlatesIdentification Plate, pack of 100 180-228Self Adhesive Cable Tie BasesAdhesive Cable Tie Base, 20 x 20mm, pack of 100, Natural 180-230Adhesive Cable Tie Base, 28 x 28mm, pack of 100, Natural 180-232138
Essential Products from <strong>Excel</strong>Fixtures & FittingsPVC Installation TapeSuitable for a multitude of applications including insulation, fixingcables and identification. Available in a range of colours and sizes, allsupplied in a 33 metre coil.Description19mm PVC Tape Black19mm PVC Tape Blue19mm PVC Tape Green19mm PVC Tape Green/Yellow19mm PVC Tape Red19mm PVC Tape White19mm PVC Tape Yellow25mm PVC Tape Black25mm PVC Tape Blue25mm PVC Tape White50mm PVC Tape BlackPart Number270219BK270219BU270219GN270219GY270219RD270219WT270219YW270225BK270225BU270225WT270250BKCable ClipsA broad range of high quality cable clips manufactured from impactresistant polypropylene, suitable for the attachment of cables of allsizes to many surfaces including wood and masonry.DescriptionWhite round cable clip, suits 3 to 5mm cable diameterWhite round cable clip, suits 5 to 7mm cable diameterBlack round cable clip, suits 5 to 7mm cable diameterWhite round cable clip, suits 7 to 10mm cable diameterBlack round cable clip, suits 7 to 10mm cable diameterPack quantity = 100Part NumberTC3-5WTC5-7WTC5-7BTC7-10WTC7-10BWoodscrews and WallplugsQuality hardened steel, twin threaded woodscrews available in eitherroundhead or countersunk versions. Wallplugs with a two way splitexpansion design for quick and easy installation.DescriptionPart Number8 x 25mm countersunk screws, box of 200 350-5128 x 38mm roundhead screws, box of 200 350-5148 x 38mm countersunk screws, box of 200 350-5165.5mm Red wallplugs, box of 1000 350-5187mm Brown wallplugs, box of 1000 350-520139
Essential Products from <strong>Excel</strong>Extension LeadsAvailable in a selection of lengths, these power extension cables aredurable and competitively priced.DescriptionPart Number<strong>Excel</strong> 4 Way Mains Extension Lead 2Mtr with neon indicator 350-704<strong>Excel</strong> 4 Way Mains Extension Lead 3Mtr with neon indicator 350-706Power CablesUK Style BS1363 plug top to IEC 320 ‘kettle’ style socketDescriptionPart NumberIEC 13Amp 2 metre UK socket mains lead 350-205IEC 13Amp 3 metre UK socket mains lead 350-210IEC 13Amp 5 metre UK socket mains lead 350-215<strong>Excel</strong> RJ45 – LJU Telephone Adaptors<strong>Excel</strong> Tailed Voice Adaptors convert RJ45 sockets to LJU presentationto allow telephones and modems to be connected to structuredcabling systems.Features● Matt white finish● Choice of Secondary, PSTN,PABX, ISDN● 6” Cable tail● Individually bagged● High density designDescriptionPart Number6” Tailed RJ45 plug – LJU Socket, Secondary Adaptor 100-6246” Tailed RJ45 plug – LJU Socket, PSTN Mastered Adaptor 100-6266” Tailed RJ45 plug – LJU Socket, PABX Mastered Adaptor 100-6286” Tailed RJ45 plug – LJU Socket, ISDN Adaptor 100-630140
Essential Products from <strong>Excel</strong><strong>Excel</strong> Telephone Extension and Line CordsA range of straight extension cords for extending phone, fax ormodem lines. Available in white only, with a choice of BT 6 way plugto 6 way BT socket or as standard line cords wired with a BT 6 wayplug at either end. The 6 way socket used in the extension leadversion will accept both 4 and 6 way plugs.Features● Choice of length● Choice of connector styles● Individually baggedDescriptionPart NumberExtension Lead, Plug to Socket 3 Metre 550-300Extension Lead, Plug to Socket 5 Metre 550-301Extension Lead, Plug to Socket 10 Metre 550-302Extension Lead, Plug to Socket 15 Metre 550-303Line Cord, Plug to Plug 3 Metre 550-304Line Cord, Plug to Plug 5 Metre 550-305<strong>Excel</strong> Telephone Extension ReelA handy telephone extension reel containing 15 metres of cordterminated with a BT plug, the centre of the reel contains a BT socket.Ideal for temporary extensions to telephone, fax or modemequipment.Features● Flexible extension lead● Robust cable housingDescriptionPart NumberExtension Reel, Plug to Socket 15 Metre 550-310141
Essential Products from <strong>Excel</strong><strong>Excel</strong> Connection Boxes – 200 SeriesThe <strong>Excel</strong> 200 Series accepts standard 237A IDC Connection Strips.Full wire management features are built into the base and the coverprovides ample knockouts for cable entry.Features● 20/30 Pair Capacity UsingStandard Terminal Strips● Cable Tie Fixings● Suits all Terminal Strips● Dimension -160(W) x 145(D) x 55(H)● Supports Protector Strip 51ADescriptionPart Number<strong>Excel</strong> 2 Way Connection Box 550-260<strong>Excel</strong> 2 Way Connection BoxLoaded with 2 x 10 Pair Terminal Strips550-261<strong>Excel</strong> 3 Way Connection Box 550-262<strong>Excel</strong> 3 Way Connection BoxLoaded with 2 x 10 Pair Terminal Strips550-263<strong>Excel</strong> Connection Boxes – 250 SeriesA Plastic Enclosure fitted with 5 Way Backmount Frame to allow theinstallation of up to 5 Terminal Strips. The cover is secured by largehead quick release screws.Features● Suits All Terminal Strips● Internal Clearance 70mm● Dimensions 210 x 160 x 90mm● Supplied with 4 Jumper Rings● Supplied with Earth PostDescriptionPart Number5 Way Connection Box, Type 251A 550-264Jumper Ring, Type 37B 550-400142
Essential Products from <strong>Excel</strong><strong>Excel</strong> Connection Boxes – 300 SeriesA Plastic Enclosure fitted with 10 Way Backmount Frame to allow theinstallation of up to 10 Terminal Strips. The cover is secured by largehead quick release screws. Jumper Rings can be added to provideCable Management.Features● Suits all Terminal Strips● Internal Clearance 90mm● Dimensions 320 x 210 x 120mm● Supplied with Earth PostDescriptionPart Number10 Way Connection Box, Type 301A 550-265Jumper Ring, Type 37B 550-400<strong>Excel</strong> Terminal StripsTerminal Strips are used to join Multipair Telecom and Data Cables.They can be mounted in either 19" Sub Racks, in various sized BoxConnections or Frames. Designation Strips are used to identifyindividual connections or strips.DescriptionPart Number10 Pair Terminal Disconnection Strip, 237A style 550-240Designation Strip 550-241143
Essential Products from <strong>Excel</strong>Curing OvenFeatures● Industry standard oven for thecuring of epoxy used in fibreoptic connector terminations● Temperatures can be variedbetween 65˚C and 125˚C● Thermostat control● Temperature monitoringprovided by dial gaugethermometer● Removable oven block canaccept up to 24 SC, ST, SMA orFC connectors● Oven blocks for ESCON, MTRJ,FDDI and LC● 110Vac and 230Vac versionsavailableDescriptionPart Number230Vac oven including connector block 202-081Spare connector block for FDDI (x4), ST,SC,SMA,FC (x12) 202-082Spare connector block - 24 port ST,SC,SMA,FC 202-083Spare connector block for LC (x24) 202-084Spare connector block for MTRJ (x15) 202-085Polishing PlateFeatures● Hand polishing of fibre optic connectors can be performed on thesmooth clean flat surface the glass plate providesDescriptionPart NumberGlass polishing plate 202-086Polishing Puck - PlasticFeatures● Economy polishing pucks● The connector ferrule is heldperpendicular to the polishingsurface● Manufactured from hardwearing engineering polymer● Universal free floating pucks for2.5mm ferrule connectorsDescriptionPart NumberUniversal 2.5mm puck (ST,SC,FC) 200-878144
Essential Products from <strong>Excel</strong>Polishing Puck - MetalFeatures● Range of metal hard wearingpolishing pucks● The connector ferrule is heldperpendicular to the polishingsurface● Universal free floating pucks for2.5mm ferrule connectors● Free floating pucks hold ferruleonly and must be held in lightcontact with the polishing film● Ferrule is normally held incontact with film by connectorspring pressure, however thelocking pucks require theconnector body to be matedwith the puck● Locking pucks are specific to atype of connectorDescriptionPart NumberLC Metal Puck 202-087Universal Puck - FC/SC/ST 202-088Fibre ScribesFeatures● During connector termination itcleaves the sprig of fibre● Gently pull the fibre after usingthe scribe to nick the fibre asclose to the ferrule as possible● Cleave will propagate acrossthe fibre● Diamond and Sapphire tipsavailable● Pen style designsDescriptionPart NumberDiamond with 90˚ Wedge Tip 202-091Sapphire 202-092145
Essential Products from <strong>Excel</strong>Kevlar ScissorsThese general purpose scissors are suitable for trimming Kevlar oraramid yarns and for cutting light duty cables. The carbon steelblades are chrome plated and have a cutting length of 40mm.DescriptionPart NumberKevlar Scissors 202-093Splice Bridge and ProtectorA compact 12 way Splice Bridge which provides an effective means tostore up to 12 Fusion Splice Protectors. Ideal for use in patch panelsor wall enclosures. The bridge can be fixed to any flat clean surfaceusing the self adhesive pads on the base.DescriptionPart Number12 Way Splice Bridge 200-391Splice Protectors (Clear) 61mm 200-398Splice Protectors (Clear) 45mm 200-399Disposal BinsDisposal Bins should be used to store fibre ends after cleaving andgeneral cable preparation. With sealable lid.DescriptionPart NumberDisposal Bin 200-921146
Essential Products from <strong>Excel</strong>Cleaning WipesPre-saturated Cleaning Wipes IPA – Non abrasive lint free wipes areused to clean fibre and connectors prior to installation, pre-saturatedwith ISO propyl alcohol in order to eliminate problems with thetransportation and use of solvents on site. Supplied in Packs of 80individually sealed sachets.Lint free Cleaning Wipes – Non abrasive lint free wipes are used toclean Fibre and connectors prior to installation. Supplied in boxes of 100.DescriptionPart NumberPre-saturated IPA Cleaning Wipes, Pack of 80 200-911Lint Free Dry Cleaning Wipes, Pack of 100 200-906Epoxy Syringe and NeedleHand held needle and 3cc syringe sets, used to load connectors withepoxy prior to termination.DescriptionPart Number3cc Syringe and Needle, Pack of 5 200-903Syringe - Single200-903-ANeedle - Single200-903-BExpotek Heat Curing EpoxyEPO-TEK 353ND is a two part heat curing Epoxy which can be usedwith any type of connector. To ensure the correct mix ratio the Epoxyis supplied in a Bi Pack containing measured amounts of resin andhardener. Removal of the plastic divider allows the two to mix beforebeing loaded in to the syringe. It is sufficient for over 100 connectorsand with pot life of up to 45 minutes. Cure time typically 15 minutes at80°C or 2 minutes at 120°C.DescriptionPart NumberEPO-TEK 353ND Epoxy - Pack of Ten 200-907-10147
Essential Products from <strong>Excel</strong>Lapping FilmA complete range of high quality lapping film for connector polishing.Sheet size is 250 x 280mm.DescriptionPart Number0.3um White Lapping Film 200-8641.0um Lime Green Lapping Film 200-8663.0um Dark Pink Lapping Film 200-8685.0um Brown Lapping Film 200-8709.0um Blue Lapping Film 200-87212.0um Yellow Lapping Film 200-87430.0um Green Lapping Film 200-876Blanking PlugsBlanking plugs can be used in part loaded panels to ensure a tidyand professional installation.DescriptionPart NumberST 200-392SC (Duplex) 200-395SC (Simplex) 200-931LC (Duplex) 200-930Isopropyl Alcohol (IPA)Isopropyl alcohol is used on lint free wipes to remove grease and dirtfrom optical fibres during splicing and termination. It is recommendedthat the fluid is decanted into fluid dispensers before use.Please note that IPA is highly flammable and should be used only inwell ventilated areas.DescriptionPart NumberIsopropyl Alcohol (IPA) 202-094148
Essential Products from <strong>Excel</strong>Miniature Cotton BudsMiniature cotton buds are used for cleaning in-line adaptors,connectors and other small or inaccessible areas, usually inconjunction with IPA fluid. The buds are lint free and are manufacturedusing pharmaceutical grade cotton. They are smaller in size thanthose sold commercially.DescriptionPart NumberMiniature Cotton Buds (200 Pack) 202-104Cable Glands with Strain ReliefCompression glands are used to provide strain relief for cables asthey enter patch panels and wall boxes. The glands are resistant toboth benzene and oil.The gland is supplied with a lock nut as standard. Cable diametersfrom 2.6mm to 25mm can be accommodated.Technical DataColour: Grey Temperature Range: -30°C to +100°CMaterial: Polyamide Protection Rating: IP68Cable Sizes (mm) Cut Out Diameter (mm) Part Number2.6 – 6.5 12.5 PG7 202-0954.0 – 10.0 18.6 PG11 202-0966.0 – 12.0 20.4 PG13 202-0979.0 – 14.0 22.5 PG16 202-098<strong>Excel</strong> Cold Cure Termination System – Connector PacksThe Cold Cure Connector Packs Include either ST or SC connectorsand boots together with sufficient adhesive and activator to terminateapproximately 200 connectors.Description ST SC100 x Connectors Plus Adhesive and Activator 200-332 200-343Adhesive and Primer 202-080149
Essential Products from <strong>Excel</strong>Containment<strong>Excel</strong> Mini Trunking<strong>Excel</strong> Mini PVC Trunking manufactured to BS4678 Part 4.Features● 3 Metre lengths● Wide range of suitable fittingsDescriptionPart Number16 x 16mm Trunking, 20 x 3 Mtr lengths 450-00516 x 16mm Trunking, 10 x 3 Mtr lengths 450-00716 x 25mm Trunking, 20 x 3 Mtr lengths 450-01016 x 25mm Trunking, 10 x 3 Mtr lengths 450-01216 x 40mm Trunking, 10 x 3 Mtr lengths 450-01525 x 40mm Trunking, 10 x 3 Mtr lengths 450-02040 x 40mm Trunking, 10 x 3 Mtr lengths 450-025<strong>Excel</strong> Self-Adhesive Mini Trunking<strong>Excel</strong> Mini PVC Trunking with peel off self adhesive base for fast,easy installation.Features● 3 Metre lengths● Self adhesive baseDescriptionPart Number16 x 16mm S/A Trunking, 25 x 3 Mtr lengths, Pack of 25 450-03016 x 25mm S/A Trunking, 25 x 3 Mtr lengths, Pack of 25 450-03516 x 25mm S/A Trunking, 1 x 3 Mtr lengths 450-035-Single25 x 40mm S/A Trunking, 10 x 3 Mtr lengths 450-04025 x 38mm S/A Trunking, 1 x 3 Mtr lengths 450-040-Single150
Essential Products from <strong>Excel</strong><strong>Excel</strong> Mini Trunking Fittings – AnglesA wide range of angles are available to suit the above mini trunking.These are used when creating corners or tap off points when installing.Features● Choose flat, internal or external● Suit all mini trunking sizes● Small minimum pack quantitiesDescriptionPart Number16 x 16mm Flat Angle, Pack of 10 450-04516 x 25mm Flat Angle, Pack of 10 450-05016 x 40mm Flat Angle, Pack of 10 450-05525 x 40mm Flat Angle, Pack of 10 450-06040 x 40mm Flat Angle, Pack of 10 450-06516 X 16mm Internal Angle, Pack of 10 450-07016 X 25mm Internal Angle, Pack of 10 450-07516 X 40mm Internal Angle, Pack of 10 450-08025 X 40mm Internal Angle, Pack of 10 450-08540 X 40mm Internal Angle, Pack of 10 450-09016 X 16mm External Angle, Pack of 10 450-09516 X 25mm External Angle, Pack of 10 450-10016 X 40mm External Angle, Pack of 10 450-10525 x 40mm External Angle, Pack of 10 450-11040 x 40mm External Angle, Pack of 10 450-115151
Essential Products from <strong>Excel</strong><strong>Excel</strong> Mini Trunking Fittings – Tees, Couplers & CapsA wide range of accessories to complement the <strong>Excel</strong> range of minitrunking. Flat tees are used to tap into other trunking runs. Couplersjoin together adjacent trunking lengths and end caps act asterminators for installed lengths.Features● Suit all Mini Trunking sizes● Small minimum pack quantitiesDescriptionPart Number16 x 16mm Flat Tees, Pack of 10 450-12016 x 25mm Flat Tees, Pack of 10 450-12525 x 40mm Flat Tees, Pack of 10 450-13540 x 40mm Flat Tees, Pack of 10 450-14016 x 16mm Couplers, Pack of 10 450-14516 x 25mm Couplers, Pack of 10 450-15016 x 40mm Couplers, Pack of 10 450-15525 x 40mm Couplers, Pack of 10 450-16016 x 16mm End Caps, Pack of 10 450-16516 x 25mm End Caps, Pack of 10 450-17016 x 40mm End Caps, Pack of 10 450-17525 x 40mm End Caps, Pack of 10 450-18040 x 40mm End Caps, Pack of 10 450-185<strong>Excel</strong> Maxi Trunking<strong>Excel</strong> Maxi trunking manufactured to BS4678 Part 4.Features● 3 Metre lengths● Small pack quantities● Wide range of suitable fittingsDescriptionPart Number50 x 50mm Trunking, 6 x 3 Mtr Lengths 450-19075 x 50mm Trunking, 4 x 3 Mtr Lengths 450-20075 x 75mm Trunking, 4 x 3 Mtr Lengths 450-205100 x 50mm Trunking, 4 x 3 Mtr Lengths 450-210100 x 100mm Trunking, 2 x 3 Mtr Lengths 450-215152
Essential Products from <strong>Excel</strong><strong>Excel</strong> Maxi Trunking Fittings – AnglesA wide range of angles to suit the above maxi trunking. These areused when creating corners and tap off points when installing.Features● Choose flat, internal or external● Suit all maxi trunking sizes● Supplied individuallyDescriptionPart Number50 x 50mm Flat Angle 450-30075 x 50mm Flat Angle 450-30575 x 75mm Flat Angle 450-310100 x 100mm Flat Angle 450-320100 x 50mm Flat Angle 450-31550 x 50mm Internal Angle 450-35075 x 75mm Internal Angle 450-360100 x 50mm Internal Angle 450-36550 x 50mm External Angle 450-25075 x 75mm External Angle 450-260100 x 50mm External Angle 450-265100 x 100mm External Angle 450-270100 x 100mm Internal Angle 450-370<strong>Excel</strong> Maxi Trunking Fittings – Tees, Couplers and End CapsA wide range of accessories are available to complement the <strong>Excel</strong>range of maxi trunking. Flat tees are used to tap into other trunkingruns. Couplers join together adjacent trunking lengths and end capsact as terminators for installed lengths.Features● Suit all maxi trunking sizes● Ensures tidy● professional installationDescriptionPart Number50 x 50mm Flat Tees 450-32550 x 50mm Couplers 450-225100 x 50mm Couplers 450-24050 x 50mm End Caps 450-27575 x 50mm End Caps 450-28075 x 75mm End Caps 450-285100 x 100mm End Caps 450-295100 x 50mm End Caps 450-290153
Essential Products from <strong>Excel</strong><strong>Excel</strong> Dry Lining Boxes<strong>Excel</strong> Dry Lining Boxes are suitable for installations in plaster boardand false wall environments.Features● 35mm Deep● Single and DoubleGang AvailableDescriptionPart NumberSingle Gang 35mm Dry Lining Box, Packs of 20 450-660Double Gang 35mm Dry Lining Box, Packs of 10 450-665<strong>Excel</strong> Flexible Conduit<strong>Excel</strong> Polypropylene Low Smoke Zero Halogen flexible conduitprovides cost effective, flexible protection to cables in sub floor, falseceiling or exposed installations. Supplied in 100 or 50 Metre lengths toenable on site installation to reduce wastage. Compatible glands andlocknuts are available for fixing to sub floor, floor or desk units.Features● Black LSOH Polypropylene● Highly Flexible● Choice of Sizes● Full Range of FittingsDescriptionPart Number20mm O.D ( 14mm ID ) Conduit, 100 Mtr 750-01025mm O.D ( 18mm ID ) Conduit, 50 Mtr 750-01520mm Gland and Locknut, Pack Of 10 750-02525mm Gland and Locknut, Pack Of 10 750-030154
Essential Products from <strong>Excel</strong><strong>Excel</strong> Flexible Conduit – Contractor Pack<strong>Excel</strong> Conduit Contractor Packs consist of 10 Metres of LSOHPolypropylene Conduit together with 10 Glands and Locknuts to suit.This easy to store and use pack is ideal for smaller installations andon site manufacturing of assemblies.Features● Black LSOH Polypropylene● Choice of Sizes● Fittings IncludedDescriptionPart Number20mm Contractor Pack, 10 Mtr Conduit and 10 Fittings 750-03525mm Contractor Pack, 10 Mtr Conduit and 10 Fittings 750-040<strong>Excel</strong> Flexible Conduit – Pre-assembled<strong>Excel</strong> Low Smoke zero halogen flexible conduit, pre assembled invarious lengths for fast and easy on-site installation.Features● Black LSOH Polypropylene● Choice of Sizes● Complete With Glands andLock NutsDescriptionPart Number3 Mtr 20mm LSOH Conduit c/w Glands and Lock Nuts 750-0455 Mtr 20mm LSOH Conduit c/w Glands and Lock Nuts 750-0553 Mtr 25mm LSOH Conduit c/w Glands and Lock Nuts 750-0605 Mtr 25mm LSOH Conduit c/w Glands and Lock Nuts 750-0705 Mtr 32mm LSOH Conduit c/w Glands and Lock Nuts 750-085Cable Binding WrapThis easy to use polyethylene wrap provides a low cost method oftidying tangled cables and cords. Each coil allows the wrap to bedispensed without snagging.DescriptionPart NumberCable binding wrap, 22mm diameter, 25 Mtr Coil 180-202Cable Sock 180-208155
Essential Products from <strong>Excel</strong><strong>Excel</strong> Floor Boxes – Three and Four CompartmentThe <strong>Excel</strong> floor box is quick to install. Twin swivelling clamps securethe floor box to the floor panel. By design, adjustable dividersenable this versatile floor box to be configured into 3 or 4compartments dependent upon the number of outlets required.A wide range of accessory plates are available for power, data andtelecommunication services.Features● Wide range of mounting plates● Useable height to lid – 44mm● One size cut out for 3 or 4compartment box 292 x 201mm● Overall dimensions 310 x 220 x100mm deep● 20 and 25mm knockouts forcable or conduit entry● Accessory plates can beremoved via the top opening● Lid and cable guides can beremoved and re-orientatedthrough 180 degreesDescriptionPart Number3 Compartment Floor Box with 1 x twin power 350-6004 Compartment Floor Box with 1 x twin power 350-602<strong>Excel</strong> Floor Box Accessories (Main Outlets)Twin Switched Sockets for 3 and 4 compartment floor boxes.Features● BS 1363● Dual earth as standard● SwitchedDescriptionPart NumberTwin Switched Socket for 3 Compartment Box 350-604Twin Switched Socket for 4 Compartment Box 350-606High density, 3 way unswitched power outletFeatures● BS 1363● Dual earth as standard● UnswitchedDescriptionPart NumberTriple Power Socket for 3 Compartment Box 350-616156
Essential Products from <strong>Excel</strong><strong>Excel</strong> Floor Box Accessories (Mounting Plates)High density plate allowing up to 6 RJ45 6c outlets to be mounted.Features● Aperture 22mm x 37mmDescription● Suits 6c modules, <strong>Excel</strong> PartCodes 100-758 and 100-301Part Number6 Way Data Plate 6c for 3 Compartment Box 350-608Standard density plate allowing up to 4 RJ45 6c outletsFeatures● Aperture 22mm x 37mm● Suits 6c modules, <strong>Excel</strong> PartCodes 100-758 and 100-301DescriptionPart Number4 Way Data Plate 6c for 4 Compartment Box 350-610Twin gang plate for 3 comp box.Features● Accepts moulded twin gang accessoryDescriptionPart NumberTwin Gang Plate for 3 Compartment Box 350-612Double gang plate for 3 comp box.Features● Accepts 2 x Single gang data accessories (LJU 3/4/5)DescriptionPart NumberDouble Gang Plate for 3 Compartment Box 350-614157
Essential Products from <strong>Excel</strong><strong>Excel</strong> Floor Box Accessories (Mounting Plates) (continued)Euromod plate for 3 comp box. Suits <strong>Excel</strong> Part Codes 100-700,100-760, 100-300 and 100-366.Features● 2 x Euro 50mm x 50mm frames (complete)DescriptionPart NumberEuromod Plate for 3 Compartment Box 350-618Blank plate for 3 compartment boxes.Features● Flat plate● Can be cut to suit connectors● Dimensions 173mm x 87mmDescriptionPart NumberBlank Plate for 3 Compartment Box 350-620158
