THE RIGHT DESIGNFOR THE JOB
LEVELLING1ROTATING JOINTS AND FRAME LEVELLING<strong>Scorpion</strong> frames are linked by rotating joints so that the mid-dle frame is kept hydraulically levelled. Position of the framesare followed by precise and robust sensor modules.2LONGITUDINAL LEVELLINGThe cabin is kept longitudinally levelled using the levellingcylinders between the middle and front frame.1 12LEVELLING ANGLE SIDEWAYS: 12°LEVELLING ANG
