TheMygoSeat

Stronger together.We work with individuals, therapistsand carers to design products withboth a clinical and an emotionalfocus. Using the latest research andclinical understanding, we createpractical solutions which are easilyintegrated into family life, becausefor us, life is about going, enjoying,participating and doing.24 hourpostural care forbabies, kids & adults.Sleeping, Sitting,Standing, Walking,Moving, Bathing,Toileting.Bigger, The new Better,Stronger. 2010 Mygo

The new 2010Mygo is bigger!It comes in 2 sizesfor kids aged 3-10and 8-14 years.2010Mygo Size 1MygoMygo Size 2

We’ve not only made the new 2010Mygo bigger, it’s better and stronger!By redesigning components andspecifying new materials we’ve made anumber of key design changes to give thenew 2010 Mygo seat added practicality,strength, durability and support.Added PracticalityRemovable machine washable covers, 40ºC.Added StrengthReinforced backrest and seat base.Added DurabilityAllen key screws supplied as standard withanti-vibration washers to prevent looseningthrough continued use.And we’ve added somuch more!HeadWider contouredheadrest providinggreater lateral support.TrunkIncreased back heightby 100mm (can be retrofitted to old Mygo seatbases but completenew backrest assemblyis required).2 armrest height options:Size 1: 160 – 210mmSize 2: 210 – 260mm.PelvisPelvic cradleand hip guide.Increased seat depthadjustment by 50mm.Depth of seat cushionincreased to 50mm forimproved pressure relief.Design of seat basecushion changed to beone piece cushion forimproved comfort.Legs & FeetGreater windsweepingrange: 30º abduction.Additional rampingunder upper legsupports.2 foot plate optionsto provide greateradjustment range:Size 1: 200 – 350mmSize 2: 315 – 465mm.Added SupportPelvic harness attachment points andwebbing reinforced to cater for kids withstrong extensor patterns.

Posture,Function& ComfortThe Mygo Seating System’sground breaking design is theculmination of over 25 years’experience working with parents,therapists, technicians andkids from all over the world.It has been designed to allowtherapists to optimise posture,function and comfort.

4. Largercontouredheadrest1.2.Pelvic Cradle with independenthip guides provides moreproximal positioning forchildren with high tone.Ramped one piece basecushion to support the ischialtuberosities and help preventthe child sliding forward.Additional foam inserts canbe used to accommodatefixed obliquity.4.5.Larger contoured headrestwhich is compatible with anumber of head supports,e.g. Whitmyer and Otto Bock.Leg support canaccommodate both shorteningand windsweeping.Size 1 can accommodatewindsweeping up to 10ºabduction or 12º adduction.3. Contouredshoulder section/ backrestextension3.Contoured shoulder section/backrest extensionfor additional support fortaller children.Size 2 can accommodatewindsweeping up to 30ºabduction or 12º adduction.1. Independent hip guides1. Pelvic Cradleand hip guides1. Pelvic Cradle2. Rampedone piecebase cushion5. Leg supportsAccommodates windsweepingAccommodates abductionand adduction

17. Push handle12. Adjustablearmrests8. Adjustablebackrest10. Adjustablelateral supports6. 4 point pelvic harness6.7.8.The 4 point pelvic harness withintegral hip guides gives asecure, stable base of support,is cushioned for comfort andcan be adjusted to ensure amid line position.Flexible sacral cushion, whichcan be shaped to the contoursof the lower back, supportsthe lower spine in the desiredposition by encouraginga degree of forward tilt inthe pelvis and lower trunkextension. In cases of lumbarlordosis, the pelvic positioningsystem can help achieve amore neutral position, withthe sacral cushion beingdesigned to mould to thechild’s shape and maintaina comfortable position.Backrest can be adjusted to suitdifferent heights.9.10. Cushioned adjustable lateralsupports provide sidesupport to help maintain asafe, upright position.11.Adjustable back anglemechanism maintains theposition of the head and trunksupports as the back angleis changed.Optional chest harness canhelp maintain an uprightposture without inhibitingfunctional movement.12. Cushioned height andangle adjustable armrestscan be easily removed tofacilitate transfer.13. Activity tray supports a widerange of activities. A grabrail can also be attached toassist the child if required.14. Individually adjustablefootplates, which can be tiltedto the preferred angle, ensurethat the feet are well supported,providing a secure base formaximum upper body function.The footplates flip away toallow for easy transfers.15. Optional sandals or anklesupports can be attached.16. Hi-low chassis can adjust fromfloor to table height allowingthe child to enjoy a wide rangeof activities from circle timeto family meals. The chassishas angle adjustment for tiltin space supporting variouspostures. All adjustments canbe made safely with the childin the seat.17.Push handles allow the chairto be easily moved around thehome or classroom.9. Adjustableback angle7. Flexiblesacral support16. Hi-lowchassis15. Optionalsandals6. 4 Point pelvic harness14. Adjustablefootplates10. Adjustable lateral supports11. Optional chest harness 13. Activity Tray

With its bright colours andclinical focus, Mygo has alwaysbeen about fulfilling the posturaland emotional needs of youngchildren and their families. Thenew 2010 Mygo is able to helpan even broader range of kidsto carry out everyday functionsat home, in the classroom oreven out and about.

The adjustability of thenew Mygo seating systemprovides clinicians withthe tools to maximise:Pelvic stabilityTrunk and head alignmentLeg and foot positioning“Seating systems are aimed at providing an appropriatelevel of postural support for each child, as well asoffering comfort, skin protection and stability to enabledaily functional activities to be carried out at home andat school. As postural control is a pre-requisite for mostfunctional tasks, the inability to control posture has asignificant impact on function” (Wright et al, 2010).Wright C, Casey J, Porter-Armstrong A. Establishing Best Practice in SeatingAssessment for Children with Physical Disabilities using Qualitative Methodologies.Disability and Rehabilitation: Assistive Technology 2010; 5(1):34-47.

Posture, Function & ComfortPelvic stabilityThe most important feature of any seating or mobilitysystem is its ability to provide pelvic stability (for tilt, rotationand obliquity) as this gives the optimum base for trunkand head alignment and upper limb function. The MygoSeating System has a range of unique features to supportthe pelvis for each individual’s postural needs.POSTUREPELVIC STABILITY CHALLENGESSACRAL SUPPORT AND CUSHIONING FOR PELVIC STABILITYIntegral to the Mygo Seating System’s pelvicharness is the flexible sacral support and hipguides. The flexible sacral support adjusts eitherto encourage a lumbar curve (neutral pelvis) oraccommodate a posteriorly tilted pelvis.The hip guides provide lateral pelvic support,and encourage a midline position, but can alsoaccommodate asymmetry by being off-set whenneeded. The generous seat cushion allows immersionof the ischial tuberosities, helping to prevent theirforward excursion and providing pressure relief.Additional pads can be used to increase theramping under the femurs when necessary.Posterior pelvic tilt Pelvic rotation Pelvic obliquity AlignmentThe pelvic seat depth (seat back to gluteal crease)can be adjusted from a point on the seat whichcorrelates to the position of the ischial tuberosities.As we rotate about the ITs, this means the lateralsupports stay in the correct anatomical position whenthe seat back is reclined, ensuring the best possiblestability. The pelvic seat depth can be adjustedasymmetrically in order to accommodate a fixedpelvic rotation, along with the sacral support andbackrest which can also be angled independently.HARNESSING FOR PELVIC STABILITY4-point pelvic harnessThe multi-adjustable 4-pointpelvic harness on the MygoSeating System ensures stabilityof the pelvis by providingsupport across the anteriorsuperior iliac spines (ASIS).The 4-point attachments (two atthe hip guides and two at 90º)mean that the harnesses stay inthe correct anatomical position.FUNCTION & COMFORTWhere it can be achieved, the optimum position ofthe pelvis for function is in neutral or slight anteriortilt. This pelvic position allows the spine to adoptits natural lumbar, thoracic and cervical curves,aligning the trunk and balancing the head. In turn,when the body is well supported, it maximises thepotential for upper limb function for playing, feedingetc; improves opportunities for social interaction;and maximises breathing and digestive capacity.Pelvic cradleThe Mygo Seating System can also be fitted with the pelviccradle (patent pending). The flexible adjustment in the backsection can encourage a posteriorly tilted pelvis into neutralalignment, and the overall design prevents users slidingforward. This gives unsurpassed proximal pelvic positioningand support for more complex body shapes. Where pelvicmobility is reduced, and tilt, rotation or obliquity need to beaccommodated, either harness, along with the hip pads,can successfully stabilise the pelvis in these unique positions.Comfort is integral to sustaining a functional posture as itreduces unwanted movement which can occur when childrenare uncomfortable. The new 2010 Mygo Seating System hasa 50mm one-piece seat cushion which consists of a singlelayer of new reflex foam which provides excellent pressuredistribution. It allows immersion for the ischial tuberosities toaid pelvic stability as well as providing comfort and maintainingskin integrity. Additional high density foam can be simplyadded under the cushion to accommodate pelvic obliquity or toprevent bottoming out under the ischial tuberosities or femurs.

Posture, Function & ComfortTrunk and Head AlignmentSeating systems need to provide appropriate trunkand head support because this contributes to thestability of the pelvis, and facilitates upper limb function,concentration, and social interaction. The Mygo SeatingSystem’s trunk and head supports can be individuallytailored to match the needs of each user.POSTURETRUNK AND HEAD ALIGNMENT CHALLENGESWith the addition of the contoured shoulder sectionon the new 2010 Mygo, not only is the height of thebackrest extended for greater growth, but shoulderprotraction is facilitated for better trunk alignment,upper limb function, and neck and head stability.DYNAMIC BACKRESTLeckey now offer a dynamic backrest option forthe Mygo Seating System for children with extensorpatterns. Leckey is carrying out research withStrathclyde University including long term field trialswhich will provide evidence of the clinical benefits ofdynamic backrests. Available in 100N and 150N it isavailable on new Mygos or can be retrofitted ontoexisting Mygos.HEAD SUPPORTSPelvic stability and trunk alignment are the basisof head control. However when additional headsupport is needed, the Mygo Seating System is fullycompatible with the full range of Leckey, Whitmyerand Otto Bock head supports to meet eachindividual’s needs.Kyphosis Lordosis ScoliosisTRUNK SUPPORTThe Mygo Seating System’s flexible sacral supportallows the sacral and lumbar regions of the spineto be supported or accommodated whether thespine is kyphotic or lordotic. The sacral supports onthe Mygo Seating Systems are also able to rotate,giving proximal support to those with a fixed pelvicor spinal rotation.Flexible scoliosis can be managed by using thelateral supports in conjunction with the pelvicharness to provide 3-point positioning.The seat to back angle on the Mygo Seating Systemopens to 115º, and when used in conjunction withthe lower leg guides, ensures that even whenhamstrings are very tight, an appropriate seatingposture can be achieved.Where additional chest support is required, theMygo Seating System has a trunk harness anda cushioned chest support.115ºFUNCTION & COMFORTThe trunk harness has detachable shoulder fasteningsto allow increased use of upper limbs.Communication is a vital, but an often overlooked aspectof seating systems. The new 2010 Mygo Seating Systemhas a seat base to which communication devices can beeasily attached. Used in conjunction with the appropriatehead support, communication for those using augmentativedevices is simpler than ever.As with pelvic stability, the ability of the trunk and headsupports to provide a secure position is central to sustainingoptimum posture for function. With cushioning and trunksupports made from soft, comfortable materials, the MygoSeating System ensures that trunk and head stability andcomfort are perfectly combined for maximum function.All Leckey Hi-low bases come with tilt-in-space as standardand can be used to further align the trunk, shoulder andhead over the pelvis, or simply allow a change of positionfor pressure relief and comfort. In addition to the Hi-lowchassis, height adjustable arm rests, and cushioned activitytray ensure playing and feeding can be encouraged athome or at school.

Posture, Function & ComfortLeg and Foot PositioningThe Mygo Seating System’s lower leg supportsfollow the leg guides when they move intoadduction or abduction, ensuring the footplatesremain in position below the knees.Seating systems also need to provide appropriate leg and foot support as this playsa crucial role in maintaining the stability of the pelvis, and therefore the alignmentof the trunk and head. Often overlooked, hamstrings are frequently tight in thosewith limited movement and can disturb pelvic stability. In addition, the feet takeup to 19% of body weight, and when unsupported can add to pressure and pelvicstability issues. The Mygo Seating System’s pioneering leg and foot supports enablethe child’s legs and feet to be supported in a wide range of positions.The footplates can remain in position when theleg guides are extended, allowing the feet to bepositioned behind the knees. This alleviates thestrain on tight hamstrings which would otherwisepull the pelvis into posterior tilt, and affect trunkand head positioning.POSTURELEG AND FOOT POSITIONING CHALLENGESFootplates can also be adjusted into plantar ordorsiflexion, and with the addition of sandals,can accommodate foot rotation. If sandals aretoo restrictive, ankle huggers can be attacheddirectly to the foot plates for foot positioning.Windsweeping Real leg length discrepancy Apparent leg lengthdiscrepancy caused byfixed pelvic rotationTight hamstringsLEG GUIDES AND FOOT SUPPORTSThe Mygo Seating System has innovatively designedleg guides which can be independently adjustedto accommodate 10º of windsweeping to the leftor right on the smaller seat base and 30º on thelarger base. The leg guides can also accommodateadduction and abduction. Offsetting the hipguides to the left or right gives additional space toaccommodate a more extreme windsweeping.The Mygo Seating System’s leg guides adjustindependently to accommodate leg lengthdiscrepancy caused either by varying femur lengths,or a pelvic rotation presenting as an apparent leglength discrepancy.FUNCTION & COMFORTWhen legs and feet are appropriately accommodatedto allow the pelvis to remain stable, trunk and headalignment can be more easily sustained because theuser’s weight is evenly distributed across the seat surfaces.In turn, when the body is well supported, it maximisesthe potential for upper limb function for playing,feeding etc; improves opportunities for social interaction;and maximises breathing and digestive capacity.Comfort is not just achieved through cushioning,but through matching the individual’s bodymeasurements and angles to the seating system.Accommodating the position of the legs and feetwill add to the comfort, and therefore the functionalabilities of the user.

Mygo Seating SystemSeat ShellMygo product sizesSize12The standardproduct includes:Seat baseBackrestFlexible sacral supportUpper leg supportsChassis interfaceSeat shellSize 1Seat shellSize 2Age (approx)3 - 108 - 14User WeightUser HeightSeat WidthMin 18kg / 40lbsMax 50kg / 110lbsMin 105cm / 41 inchesMax 150cm / 59 inchesMin 200mm / 8 inchesMax 325mm / 13 inchesMin 18kg / 40lbsMax 60kg / 132lbsMin 127cm / 50 inchesMax 168cm / 66 inchesMin 220mm / 8.7 inchesMax 345mm / 13.6 inchesColour OptionsSeat DepthKnee WidthFootplate:AbductionAdductionPlantarflexion/DorsiflexionMin 270mm / 10.6 inchesMax 420mm / 16.5 inchesMin 90mm / 3.5 inchesMax 110mm / 4.3 inches8º12º10ºMin 350mm / 13.8 inchesMax 470mm / 18.5 inchesMin 120mm / 4.7 inchesMax 140mm / 5.5 inches8º20º10ºEach cover packwill include thefollowing cushions:Backrest cushionSeat base cushionSacral cushionUpper leg cushionsChest WidthBackrest HeightMin 170mm / 6.7 inchesMax 270mm / 10.6 inchesMin 360mm / 14.2 inchesMax 470mm / 18.5 inchesMin 170mm / 6.7 inchesMax 270mm / 10.6 inchesMin 460mm / 18.1 inchesMax 570mm / 22.4 inchesOrange Blue Pink GreyBackrest Angle:ProneRecline10º25º10º25ºChassis OptionsSeat to SandalTop of Seat to FloorArmrest HeightTray SizeMin 215mm / 8.5 inchesMax 350mm / 13.8 inchesMin 360mm / 14.2 inchesMax 700mm / 27.5 inchesMin 160mm / 6.3 inchesMax 210mm / 8.3 inches550 x 480mm21.6 inches x 18.9 inchesMin 315mm / 12.4 inchesMax 470mm / 18.5 inchesMin 360mm / 14.2 inchesMax 700mm / 27.5 inchesMin 210mm / 8.3 inchesMax 260mm / 10.2 inches550 x 480mm21.6 inches x 18.9 inchesHi-low chassisIndoor only.4” castorsHi-low chassis -Indoor / OutdoorFoot pedal operated.12” backwheels5” castorsMygo on Mobility Base(UK only)Includes seat shelland Otto BockDiscovery Base.Mygo Seat onstroller baseIncludes seat shellon kimba baseSeat Unit Weight10kg / 22lbs14.5kg / 32lbsFoot pedal (gas)Foot pedal (hydraulic)PoweredFoot pedal (gas)Foot pedal (hydraulic)PoweredAvailable fromInvacareMygo on ReaAzaleaAvailable fromInvacareMygo 1 onTendercareSnappiBase OptionsIndoor chassis - gas spring foot pedalMin 340cm / 13.4 inchesMax 655cm / 25.8 inchesIndoor chassis - hydraulic foot pedalMin 325cm / 12.8 inchesMax 615cm / 24.2 inchesMobility InterfaceFor more interface options log onto leckey.comIndoor chassis - powered height adj.Indoor-outdoor chassis - gas spring foot pedalMin 370cm / 14.6 inchesMin 390mm/15.4 inchesMax 675cm / 26.6 inchesMax 690mm/27.2 inchesInterface AInterface Bfor Discovery 400mmInterface Cfor Discovery 360mmIndoor-outdoor chassis - hydraulic foot pedalMin 380mm/15.0 inchesMax 670mm/26.4 inchesIndoor-outdoor chassis - powered height adj.Min 420mm/16.5 inchesMax 710mm/28.0 inchesTilt in SpaceProne 10º Supine 25ºBase Weight12kg / 26.5lbsLeckey ServicingOur FREE service and support includes:Free product trainingFree product set upFree product assessmentFree product re-assessmentFree repair within 2 year warrantyFor service policies on all products outside warranty, please contact Leckey’sCustomer Service department. James Leckey Design Ltd as manufacturer withsole responsibility declares that all products conform to 93/42/EEC guidelines andEN12182 technical aids for disabled persons general requirements and test methods.Order forms and spare parts lists to extend the service life of the product and allowreissue are available on request or online at www.leckey.com.
