T ENDER - SPORT - DIVING & RESCUE - PROFESSIONALwww.marinepower.com2006
2If you would like informationon foldable inflatable boats,ask your dealer for aQUICKSILVER ® catalogue.
Safe, stable, light, fast, fuel-efficient, easy to trans<strong>port</strong>, with multichamber tubesacting as shock absorbers.Valiant craft are manufactured with a highly industrialised process, guaranteeing greater reliability with aconstant and uniform quality. Through design, planning and development with the most advanced techniquesof CAD/CAM, production of the craft is automated and robotised in the main production stages, having advancedenvironmental controls for the manufacturing of GRP, where applied high technology eliminates vapours and byproducts.S<strong>port</strong>s series materialThis material, designed specifically for inflatable craft of recreational usage, is manufactured by MEHLERHAKU, group from Germany, with more than more than 40 years experience in the manufacturing of reinforcedmaterials answering the technical demands of the RIB industry for high performance materials.THERMOWELDING ®This process which combines fusion with calendering at high pressure is used to assemble the different partsof the tubes with a system of double internal/external tapes providing welds stronger than the material itself.VITECH ®Derived from the technology of the aeronautical industry, the lamination process of the semi-rigid Valiantcraft is a combination of advanced techniques in injection moulding achieving an excellent strength / weight ratio.Professional series materialAKRON TPE ® of High Resistance to Abrasion has been developed for the use in professional, army, andrescue craft, having been accepted for this purpose by the most prestigious organisations of rescue and safety atsea, such as the US COAST GUARD and British RNLI, complying with the MIL B-53067 Regulations of theUS Department of Defence and having both the RINA CCE 36599/1 certification and SOLAS certification foruse in the manufacture of rescue craft.The main characteristics of the material can be summarised as having an extremely high resistance to abrasion,five times greater than that of Neoprene / Hypalon, together with a very high resistance to pollution, to theaction of U.V. rays and to impact in accordance to the puncture test, FD standard NO-101B (method 2031).ISO 9001:2000 CertificationIn 2001 the Quality Management System of Valiant has been certified ISO 9001:2000 which applies to:Design, manufacture and repair management for semi-rigid inflatable boats.Valiant is part of Brunswick Corporation, world leading manufacturer of boat engines and recreational craft. Sister brands include:3www.marinepower.com
Dynamic 240/270/300Tender SeriesD-240Manufactured using VITECH (Vacuum Injection Technology), the Dynamic seriesis recognised as being the lightest R.I.B. tender on the market.With its non-slip deck, davit lifting points, and fibreglass seat, the Dynamic serieswith its light grey coloring offers both an attractive and practical solution to thetender needs of both motor and sailing vessels.Main Characteristics:- Lightweight, ideal as tenders as well as for the davits.- Ease of lifting and launching.- Non-slip deck.D-240D-240 D-2404
Fibreglass seatErgonomic lifting handleD-300D-240 D-240 D-300CHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)Dimensions (packed)OarsDYNAMIC-240-2.40 m1.50 m1.40 m0.64 m0.38 m2350 kg3S6 H.P. - 4.4 kW4 H.P. - 2.9 kW3 H.P. - 2.2 kW34 kg35 kg2.35x0.95x0.60 m2DYNAMIC-270D2.70 m1.70 m1.40 m0.64 m0.38 m2400 kg3+1S6 H.P. - 4.4 kW6 H.P. - 4.4 kW4 H.P. - 2.9 kW35 kg36 kg2.45x1.00x0.60 m2DYNAMIC-300C3.00 m1.90 m1.64 m0.80 m0.42 m2470 kg4S9.9 H.P. - 7.4 kW8 H.P. - 6 kW6 H.P. - 4.4 kW40 kg44 kg2.70x1.10x0.60 m2Standard Fittings- Bow handle- Davit lifting eyes- Drain plug- Lifelines- Lifting handles- Mooring eye- Non-slip deck- Rubbing strake- Transom pad- Transom plateStandard Accessories- Air Pump- Fibreglass seat- Repair Kit- OarsOptional Accessories- Boat cover5www.marinepower.com
Dynamic 300/340/380D-380 BasicD-340 FamilyNot only an ideal boat for first-time buyers but also as a tenderfor larger yachts these models are the image of the Rigid InflatableBoat concept: stability, load capacity, light and excellentseaworthiness.Its light weight, davit lifting points and attractive non-slipsynthetic teak deck enables easy trans<strong>port</strong>, launching and handling.These attributes also give the boat excellent performance figureseven with low horsepower engines.These models are available in three versions: the “Basic” versionhaving no additional accessories, the “S<strong>port</strong>” version having theJockey Console S3 and the “Family” version having the CenterConsole S3 and Backrest Seat S3.Main Characteristics:- Attractive non-slip synthetic teak deck.- Large diameter tubes making for a comfortable ride.- Ideal for davits due to its light weight.D-340 FamilyD-340 S<strong>port</strong>6
Console trayConsole LockerFuel tank tie downstrapsD-340 FamilyD-340 S<strong>port</strong>Backrest seatdocument lockerD-340 BasicConsole fuel tanklockerD-340 BasicCHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine) “Basic”Dimensions (packed)Telescopic PaddlesDYNAMIC-300C3.00 m1.90 m1.64 m0.80 m0.42 m2470 kg4S10 H.P. - 7.4 kW8 H.P. - 6 kW6 H.P. - 4.4 kW50 kg44 kg2.70x1.10x0.60 m2DYNAMIC-340C3.40 m2.30 m1.64 m0.80 m0.42 m3560 kg4S20 H.P. - 14.7 kW13.5 H.P. - 9.9 kW8 H.P. - 6 kW55 kg75 kg3.20x1.10x0.65 m2DYNAMIC-380C3.80 m2.55 m1.64 m0.80 m0.42 m3600 kg5S25 H.P. - 18.3 kW15 H.P. - 11.0 kW10 H.P. - 7.4 kW55 kg87 kg3.40x1.10x0.65 m27Standard Fittings- Bow handle- Davit lifting eyes- Drain plug- Fuel tank tie down strap- Lifelines- Lifting handles- Mooring eye- Non-slip synthetic teak deck- Rubbing strake- Transom pad- Transom plateStandard AccessoriesBasic S<strong>port</strong> Family- Air pump - Jockey Console S3 - Center Console S3- Telescopic Paddles - Air Pump - Backrest Seat S3- Repair kit - Telescopic Paddles - Air Pump- Repair Kit - Telescopic Paddles- Repair KitOptional Accessories- Boat Coverwww.marinepower.com
Vanguard 400/450/490S<strong>port</strong> SeriesUNSINKABLE HULLV-450S.O.L.A.S.TY PEEasy to use, compact and easy to store once the season is over, thesecraft are affordable and have an excellent design for touring duringthe week-end, navigation near the coast and recreational activities.The standard accessories on this series include the forward locker,the Center Console S4 with rotary steering and cable, as well as theBackrest Seat S4 for the V 400 and V 450, the V490 having theBackrest seat S5.Optional Accessories are available such as the diving ladder,solarium, navigation frame and others.Main Characteristics:- Fast planing insubmersible hull.- Easy to trans<strong>port</strong> and store.- Numerous standard accessories.V-450V-4508
SundeckBow cleatNavigation frame S-4Console lockerBackrest seat documentlockerV-450Console traySpacious Bow/Anchor lockerfor anchor and linesS-4 ladderFuel tank storageunder the seatV-450CHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)Dimensions (Wooden crate)Telescopic PaddlesVANGUARD-400C4.00 m2.85 m1.77 m0.85 m0.46 m3+1800 kg6L40 H.P. - 29.4 kW25 H.P. - 18.3 kW13.5 H.P. - 9.9 kW106 kg142 kg3.66x1.52x0.88 m2VANGUARD-450C4.50 m3.40 m1.94 m0.98 m0.48 m3+11,000 kg7L60 H.P. - 44.1 kW40 H.P. - 29.4 kW25 H.P. - 18.3 kW112 kg163 kg4.07x1.56x0.88 m2VANGUARD-490C4.90 m3.62 m1.94 m0.98 m0.48 m4+11,100 kg8L80 H.P. - 58.8 kW60 H.P. - 44.1 kW30 H.P. - 22.0 kW175 kg213 kg4.43X1.56X0.90 m2Standard Fittings- Bow cleat - Mooring eye- Drain plug - Non-slip deck- External lifelines - Rubbing strake- Hull drain socket - Stern davit lifting / ski eyes- Internal lifelines - Transom plate- Lifting handles - Tube reinforcementsStandard Accessories- Backrest seat S-4 - Air Pump- Folding backrest - Rotary steeringseat S-5 (V-490) - Telescopic paddles- Bow locker - Repair Kit- Center Console S-4Optional Accessories- Bathing ladder S-4 - Ice chest tie down kit- Boat Cover - Navigation frame V-DR 400/490- Ice chest Marine 25 - Sundeck Platform V 450/4909www.marinepower.com
Vanguard 520/570S<strong>port</strong> SeriesV-520This very successful and attractive series not only offers a generous beam allowing more usefulinner space but it retains the traditional values of the RIB, to name only a few, ease of trans<strong>port</strong>,storage and seaworthiness.The numerous standard accessories include a bow locker, center console with hydraulic steering,a backrest seat, integral fuel tank, diving ladder and electric bilge pump. A number of optionalaccessories are also available to cater to individual needs.Main Characteristics:- Integral fuel tank.- Complete hydraulic steering with steering wheel.- Electric bilge pump.V-520V-520 V-520V-520 V-52010
Bow lockerDeck fill for underdeck fuel tankIce chest with cushionBimini sunshadeHydraulic steeringConsole withlocker and trayStern locker with accessto the electric bilgepumpSpacious anchor lockefor anchor and linesV-520Easy assembled sundeckplatform with trans<strong>port</strong> bagTelescopicbathing ladderAmple Backrest withfolding backrestNon-slip deck with teaklaminate with lowmaintenanceCHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)Dimensions (wooden crate)Telescopic PaddlesFuel tankElectric bilge pumpVANGUARD-520C5.20 m3.94 m2.16 m1.10 m0.48 m4+11,150 kg9L100 H.P. - 73.5 kW80 H.P. - 58.8 kW40 H.P. - 29.4 kW175 kg262 kg4.76x1.06x0.94 m273 Lts2,700 LPHVANGUARD-570C5.60 m4.00 m2.40 m1.30 m0.55 m5+11,450 kg15L135 H.P. - 99.3 kW100 H.P. - 73.5 kW60 H.P. - 44.1 kW195 kg371 kg5.09x1.90x0.97 m2106 Lts2,700 LPHStandard Fittings- Anchor locker - Lifting handles- Bow cleat - Mooring eye- Bow locker - Non-slip deck with teak laminate- Deck drain plug - Stern davit lifting / towing eyes- Rubbing strake - Transom plate- External lifelines - Tube reinforcements- Hull drain socket - Integral fuel tank- Internal lifelinesStandard Accessories- Air pump - Fuel gauge- Bathing ladder S-5 - Hydraulic steering system- Center Console S-5 (V-520) - Repair kit- Center Console S-6 (V-570) - Switch panel (3s)- Electric bilge pump - Telescopic paddles- Folding backrest seat S-5Optional Accessories- Bimini sunshade - Ice chest tie down kit- Boat Cover - Navigation frame S-5- Bow roller - Sundeck V-520- Ice chest Marine 48 - Sundeck V-570- Ice chest cushion Marine 4811www.marinepower.com
Vanguard 620/750S<strong>port</strong> SeriesSpacious anchorlocker for anchorand linesBow lockerDeck fill for underdeck fuel tankSki mastHydraulicsteeringDeck showerV-620Non slip deck with teaklaminate with lowmaintenanceTelescopicbathing ladderSundeck platform with ship’s lockersStern locker with access to theelectrical bilge pumpCHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)Dimensions (packed)Telescopic PaddlesFuel tankElectric bilge pumpVANGUARD-620C6.15 m4.50 m2.50 m1.35 m0.57 m51,750 kg171L150 H.P. - 110.3 kW115 H.P. - 84.6 kW90 H.P. - 66.2 kW210 kg486 kg5.00x2.00x1.20 m2106 Lts2,700 LPHVANGUARD-750C7.49 m6.20 m2.85 m1.60 m0.60 m72,300 kg221XL300 H.P. - 220.6 kW150 H.P. - 110.3 kW115 H.P. - 84.6 kW290 kg773 kg6.5x2.3x1.5 m2300 Lts2,700 LPHStandard Fittings- Bow cleat - Internal lifelines- Bow locker - Lifting handles- Deck drain plug - Mooring eye- Double rubbing - Non-slip deck withstrake bicolouredteak laminate- External lifelines - Stern davit lifting / towing eyes- Hull drain socket - Stern locker- Anchor locker - Transom plate- Integral Fuel Tank - Tube reinforcementsStandard Accessories- Air pump - Hydraulic steering system- Backrest seat S-7D (V-750) - Telescopic Paddles- Repair kit - Center console S-6/S-7- Stern seat - Console locker- Electrical bilge pump - Switch panel (6S)- Fuel gaugeOptional Accessories- Bathing ladder - Ski mast- Boat cover - Sundeck with lockers V-620- Bimini sunshade - Ice chest tie down kit- Ice chest cushion Marine 72 - Ice chest Marine 72- Stern bathing platform - Navigation frame V-DR 620/750- Deck shower kit - Sundeck with lockers V-75012
Spaciousanchor lockerfor anchor andlinesDeck fill forunder deckfuel tankHydraulicsteeringSki mastLockerunder seatDeck showerBow lockerNon slip deck with teaklaminate with lowmaintenanceV-750TelescopicbathingladderStern locker withaccess to the electricalbilge pumpOptional sundeck platform withship’s lockersLargest of the Vanguard series, versatile, with a big loading capacity theseboats offer great performance without compromising the high level of comfortand security.A very extensive standard accessories list includes a bow cleat, anchor locker,bow locker, Center Console with hydraulic steering, Backrest seat S7D (V-750),stern seat, stern lockers and electric bilge pump to name but a few.There are a number of optional accessories available as well to complementthe standard model.Main Characteristics:- Integral fuel tank.- Non-slip deck with synthetic teak laminate.V-75013www.marinepower.com
Vanguard 620S<strong>port</strong> SeriesV-620 CROne of the many high points of the Vanguard series, this6,20 m model is characterised by the high level of finish andlevel of standard accessories offered.Standard accessories for this model include the retractablebow roller, anchor locker, bow locker, stowable sundeck withlockers, center console with hydraulic steering, integral fueltank, stern seat, GRP navigation frame, stern lockers, skimast, deck shower kit, diving ladder, diving platform andelectric bilge pump.Optional accessories are available for this model.V-620 CRMain Characteristics:- GRP Navigation Frame with integrated double sternseat.- Stowable sundeck with lockers.- Deck shower kit, diving ladder, diving platform.V-620 CRV-620 CR14
Retractable bow rollerConsolestorage lockerHydraulic steeringSki mastSpacious anchorlocker for anchor andcablesNon slip deck withteak laminate withlow maintenanceStern locker withaccess to the electricbilge pumpBow lockerV-620CruiserBathing ladderDeck showerPop-up stern mooring cleatsSundeck platform with ship’s lockersCHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)Dimensions (packed)Telescopic PaddlesFuel tankElectric bilge pumpVANGUARD-620 CruiserC6.15 m4.50 m2.50 m1.35 m0.57 m51,750 kg171L150 H.P. - 110.3 kW115 H.P. - 84.6 kW90 H.P. - 66.2 kW210 kg486 kg5.00x2.00x1.20 m2106 Lts2,700 LPHStandard Fittings- Internal lifelines - Stern mooring cleats- Bow locker - Lifting handles- Deck drain plug - Mooring eye- Double rubbing strake - Non-slip deck with teak laminate- External lifelines - Stern davit lifting / towing eyes- Hull drain socket - Stern locker- Anchor locker - Transom plate- Integral Fuel Tank - Tube reinforcementsStandard Accessories- Air pump - Hydraulic steering system- GRP Navigation Frame - Telescopic Paddles- Bathing ladder - Repair kit- Stern bathing platform - Retractable Bow Roller- Center console S-6 - Stern seat- Console locker - Sundeck with lockers- Deck Shower Kit - Ski mast- Electrical bilge pump - Switch panel (6S)- Fuel gauge - 12V Accessories plugOptional Accessories- Boat cover - Ice chest tie down kit- Bimini sunshade - Ice chest Marine 72- Ice chest cushion Marine 7215www.marinepower.com
Vanguard 750S<strong>port</strong> SeriesV-750 CRThe Admiral of the Vanguard series fleet, this 7,50 mmodel is characterised by the high level of finish and levelof standard accessories offered, all coupled with excellentperformance.Standard accessories for this model include theretractable bow roller, anchor locker, bow locker, stowablesundeck with lockers, center console with hydraulicsteering, integral fuel tank, stern seat, GRP navigationframe, stern lockers, ski mast, deck shower kit, divingladder, diving platform and electric bilge pump.Optional accessories are available for this model.V-750 CRV-750 CRMain Characteristics:- GRP Navigation Frame with integrated triple sternseat.- Stowable sundeck with lockers.- Deck shower kit, diving ladder, diving platform.- Double Backrest Seat S7D with lockers, foldable table,and fire extinguisher holder.V-750 CRV-750 CR16
Retractablebow rollerElectric ice chestHydraulicsteeringShip’s holdunder the seatSki mastSpaciousanchor lockerfor anchor andlinesBow lockerNon slip deck with teaklaminate with lowmaintenanceV-750 CruiserSundeck platform with ship’s lockersStern lockerDeck showerV-750 CRPop-up stern mooring cleatsBathing ladderCHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)Dimensions (packed)Telescopic PaddlesFuel tankElectric bilge pumpVANGUARD-750 CruiserC7.49 m6.20 m2.85 m1.60 m0.60 m72.300 kg221XL300 H.P. - 220.6 kW150 H.P. - 110.3 kW115 H.P. - 84.6 kW290 kg773 kg6.5x2.3x1.5 m2300 Lts2,700 LPHStandard Fittings- Internal lifelines - Stern mooring cleats- Bow locker - Lifting handles- Deck drain plug - Mooring eye- Double rubbing strake - Non-slip deck with teak laminate- External lifelines - Stern davit lifting / towing eyes- Hull drain socket - Stern locker- Anchor locker - Transom plate- Integral Fuel Tank - Tube reinforcementsStandard Accessories- Air pump - Hydraulic steering system- GRP Navigation Frame - Telescopic Paddles- Bathing ladder - Repair kit- Stern bathing platform - Retractable Bow Roller- Center console S-7 - Stern seat- Console locker - Sundeck with lockers- Deck Shower Kit - Switch panel (6S)- Electrical bilge pump - Ski mast- Fuel gauge - 12V Accessories plug- Double Backrest Seat S7D - Electric Ice ChestOptional Accessories- Boat cover- Bimini sunshade17www.marinepower.com
DR 400/450/490Diving&RescueSeries of working craft “Diving & Rescue” designed with themaximum of versatility to satisfy the demands of diving, rescue andvigilance in s<strong>port</strong>s clubs and in other professional requirements. Theseries is also easy to trail and to launch and recover.Very robust craft manufactured with AKRON TPE material andwith extra strong accessories, double rubbing strake fender, lifelineswith stainless steel rings, reinforcements with non-slip finish on topof the tubes, inflation H.D. valves and pressure relief valves as standardequipment.The deck presents a non-slip finish directly integrated in thelamination process.The design of the G.P. (General Purpose) hulls has been carefullydeveloped to fit the different tasks and sea conditions that users maypotentially face. Its design achieves an excellent balance of seaworthyperformance, speed, running comfort and low fuel consumption dueto its quick planning.DR-490UNSINKABLE HULLS.O.L.A.S.TY PEDR-400DR-450DR-49018
Console fuel tank lockerBow lockerDR-490S-4 ladderDR-490DR-490CHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)Dimensions (wooden crate)Telescopic PaddlesFuel tankElectric bilge pumpDR-400C4.00 m2.85 m1.77 m0.85 m0.46 m3+1800 kg6L40 H.P. - 29.4 kW25 H.P. - 18.3 kW13.5 H.P. - 9.9 kW106 kg142 kg3.66x1.52x0.88 m2--DR-450C4.50 m3.40 m1.94 m0.98 m0.48 m3+11,000 kg7L60 H.P. - 44.1 kW40 H.P. - 29.4 kW25 H.P. - 18.3 kW112 kg163 kg4.07x1.56x0.88 m2--DR-490C4.90 m3.62 m1.94 m0.98 m0.48 m4+11,100 kg8L80 H.P. - 58.8 kW60 H.P. - 44.1 kW30 H.P. - 22.0 kW175 kg213 kg4.43x1.56x0.90 m2--Standard Fittings- Bow cleat - Internal lifelines- Deck drain plug - Lifting handles- Mooring eye - External lifelines- Rubbing strake - Safety relief valves- Tube reinforcements - Stern towing eyesStandard Accessories- Air pump - Repair kit- Bow locker - Telescopic paddlesOptional Accessories- Bathing ladder S-4 - Ice chest Marine 25- Bow roller - Ice chest Marine 48- Boat cover - Ice chest tie down kit- Double Jockey Console S-5 - Jockey S-3- Navigation frame S-419www.marinepower.com
DR 520/570Diving&RescueKeeping the same multi-use characteristics as the previous series,these boats are easy to trail, to launch and solidly constructed. Theyare distinguished by the design of their ample beam, and a deep“V” at the bow with evolution towards stern which provides fastplaning as well as stability and security when confronting strongsea conditions.The integral fuel tank of 73/106 litres drastically increases therange of the craft while providing a larger useful deck surface freefrom <strong>port</strong>able fuel tanks.Its large bow locker for equipment storage is complemented withan anchor locker, as well as an inspection hatch at stern with directaccess to the bilge and electric bilge pump.This series can be complemented with a center console PT-5 andwith a backrest seat PT-7M for comfortable piloting in a standingposition.DR-570DR-520DR-570DR-57020
DR-570Bow lockerConsole lockerDR-570S-4 ladderDR-570S-5 ladderCHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)Dimensions (wooden crate)Telescopic PaddlesFuel tankElectric bilge pumpDR-520C5.20 m3.94 m2.16 m1.10 m0.48 m4+11,150 kg9L100 H.P. - 73.5 kW80 H.P. - 58.8 kW40 H.P. - 29.4 kW185 kg262 kg4.76x1.60x0.94 m273 Lts2,700 LPHDR-570C5.60 m4.00 m2.40 m1.30 m0.55 m5+11,450 kg15L135 H.P. - 99.3 kW100 H.P. - 73.5 kW60 H.P. - 44.1 kW195 kg371 kg5.09x1.90x0.97 m2106 Lts2,700 LPHStandard Fittings- Anchor locker - Internal lifelines- Bow cleat - Lifting handles- Bow locker - Mooring eye- Deck drain plug - Safety relief valves- Double rubbing strake - Stern towing eyes- External lifelines - Tube reinforcements- Hull drain socket - Integral fuel tankStandard Accessories- Air pump - Repair kit- Electrical bilge pump - Switch panel (3s)- Fuel gauge - Telescopic paddlesOptional Accessories- Backrest seat PT-7M - Ice chest tie down kit- Bathing ladder S-4 - Ice chest Marine 25- Boat cover - Ice chest Marine 48- Bow roller - Navigation frame S-5- Center console PT-5 - Sundeck V-520- Double jockey console S-5 - Sundeck V-57021www.marinepower.com
DR 620/750Diving&RescueDR-750DR-750These working “Diving & Rescue” craft are fast, strong, agile, spacious andfeature a G.P. (General Purpose) hull. The material and manufacturing detailsare the same as the ones described in the previous series, and are widely acceptedby diving clubs, underwater activity clubs and the most demanding professionalusers.The models of this series include a 106 and 300 litre fuel tank respectively.It is located under the deck in a watertight compartment perfectly adapted tothe “V” shape of the hull. This lowers the center of gravity even more, ensuresa clear deck and greatly increases the range of the craft.The models of this range can be personalised according to the user’s needs.A wide range of optional equipment such as the aluminium hatch which allowsaccess to a wide hold below the deck is available.DR-75022
DR-750DR-620 DR-750 DR-750CHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)DimensionsTelescopic PaddlesFuel tankElectric bilge pumpDR-620C6.15 m4.50 m2.50 m1.35 m0.57 m51,750 kg171L150 H.P. - 110.3 kW115 H.P. - 84.6 kW90 H.P. - 66.2 kW210 kg486 kg5.00x2.00x1.20 m2106 Lts2,700 LPHDR-750C7.49 m6.20 m2.85 m1.60 m0.60 m72,300 kg221XL - 2L300 H.P. - 220.6 kW150 H.P. - 110.3 kW115 H.P. - 84.6 kW350 kg773 kg6.50x2.30x1.50 m2300 Lts2,700 LPHStandard Fittings- Lifting handles - Internal lifelines- Bow cleat - Mooring eye- Bow locker - Safety relief valves- Deck drain plug - Stern towing eyes- Double rubbing strake - Stern locker- External lifelines - Tube reinforcements- Hull drain socket - Under deck fuel tankStandard Accessories- Air pump - Repair kit- Electrical bilge pump - Switch panel (6s)- Fuel gauge - Telescopic paddlesOptional Accessories- Aluminium Hatch - Backrest Seat PT-7D- Backrest seat PT-7M - Boat cover- Ice chest cushion Marine 72 - Bottle rack 12-B- Ice chest tie down kit - Bow roller- Ice chest Marine 72 - Center console PT-5- Navigation frame S-6/7 - Center console PT-6- Single modular seat - Dive center Diving Ladder- Double jockey console S-7 - Double modular seat23www.marinepower.com
PT 520/650/750/850ProfessionalThis series of craft for professional and commercial use hasbeen developed for the most demanding users, rescueorganisations, coastguards, army, fire brigades, merchant marine,oil platforms and any other industrial activity which requiresthe use of strong, resistant, seaworthy, fast and safe craft capableof operating in the roughest working conditions.The military design of the hull, with a deep “V” from bowto stern combined with very pronounced spray rails along thehull, improve navigation and buoyancy. This design offersexceptional performance in offshore and general tasks under veryrough sea conditions. The material details of manufacture and deckare the same as those described in the DR series. The models of thisseries include a fuel tank located under the deck in a watertightcompartment perfectly adapted to the “V” shape of the hull. This lowers thecenter of gravity even more and greatly increases the range of the craft. This seriesincludes a wide hold below the deck, with access through an aluminium hatch (exceptPT-520). The models of this range can be personalised according to the user’s needs,with a wide choice of optional equipment.PT-520-SSPT-520-SSPT-750PT-85024
PT-850PT-750PT-750PT-850CHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)Dimensions (Packed)Telescopic PaddlesFuel tankElectric bilge pumpPATROL-520C5.20 m3.75 m2.22 m1.15 m0.50 m51,850 kg91 L100 H.P. - 73.5 kW80 H.P. - 58.8 kW40 H.P. - 29.4 kW175 kg300 kg4.77x1.80x0.94 m273 Lts2,700 LPHPATROL-650B / C6.50 m5.10 m2.50 m1.38 m0.56 m52,654 kg191 XL - 2 L150 H.P. - 110.3 kW115 H.P. - 84.6 kW100 H.P. - 73.5 kW235 kg610 kg5.75x2.30x1.50 m2300 Lts2,700 LPHPATROL-750B / C7.49 m6.00 m2.84 m1.78 m0.56 m73,176 kg221 XXL - 2 XL300 H.P. - 220.6 kW200 H.P. - 147.1 kW150 H.P. - 110.3 kW600 kg965 kg6.50x2.30x1.50 m2300 Lts2,700 LPHPATROL-850B8.50 m6.91 m3.00 m1.88 m0.56 m74,780 kg261XXL - 2 XL500 H.P. - 367.8 kW300 H.P. - 220.6 kW200 H.P. - 147.1 kW705 kg1,160 kg8.00x2.60x1.60 m2300 Lts2,700 LPH25Standard Fittings- Bow cleat - Lifting handles- Bow locker - Mooring eye- Bow davit lifting eyes - Safety relief valves- Double rubbing strake - Stern davit lifting/- Elephant trunk deck drains towing points(Except PT-520)- Tube reinforcements- External lifelines - Under deck fuel tank- Hull drain socket - Wide hold below deck- Internal lifelines - Drain valves (only PT-520)Standard Accessories- Air pump - Fuel gauge- Aluminium hatch (Except PT-520) - Telescopic paddles- Electric bilge pump - Repair kitOptional Accessories- Double jockey console S-7 - Backrest seat PT-7M- Double jockey console S-5 - Backrest seat PT-7D- Double modular seat - Boat cover- Flag mast - Bottle rack 12-B- Frame with self righting device - Bow roller- Keel protection - Bow Samson post- Navigation frame PT - Center console PT-5- Single modular seat - Center console PT-6- Larger Capacity Fuel Tanks - Center console PT-7www.marinepower.com
PT-SD 650/750/850ProfessionalPT-SD 750PT-SD 750Extending the excellent performance of the PATROL series,the PATROL SD series has been developed for those users whoneed high performance craft with long range and low fuelconsumption. For this reason, they are powered with diesel orpetrol sterndrive inboard engines, or water jet, with differenthorsepowers according to the user’s need. The craft of this seriesare delivered fully equipped and “ready to go”. Please ask yourdistributor about the different options of diesel or gasolineengines from among a wide range of models and horsepowers.The models of this series include a fuel tank of 300 litres locatedunder the deck in a watertight compartment perfectly adaptedto the “V” shape of the hull. This lowers the center of gravityand greatly increases the range of the craft. This series includesa wide hold under deck, with access through an aluminiumhatch. The models of this range can be personalised accordingto the user’s needs, with a wide collection of optional equipmentavailable.During the year of 2001, a team consisting of three ValiantR.I.B.’s Patrol 750 SD equipped with Mercruiser 4.2 LD-Tronicrealised a successful crossing of 1000 nautical miles on thenorth Atlantic between Lisbon and Azores ( Horta ) in 47 hourswithout any assistance or refuelling.PT-SD 75026
PT-SD 850PT-SD 750CHARACTERISTICSCE CategoryLength overallLength insideBeam overallBeam insideTube diameterNumber of chambersMax. capacity weightMax. capacity personsEngine shaft typeMax. engineRecommended engineMinimum engineMaximum engine weightTotal boat weight (Exc.engine)DimensionsTelescopic PaddlesFuel tankElectric bilge pumpPATROL-650 SDB / C6.50 m5.10 m2.50 m1.38 m0.56 m52,654 kg19Inboard/Outdrive250 H.P. - 183.9 kW115 H.P. - 84.6 kW90 H.P. - 66.2 kW500 kg610 kg5.75x2.30x1.50 m2300 Lts2,700 LPHPATROL-750 SDB / C7.49 m6.00 m2.84 m1.78 m0.56 m73,176 kg22Inboard/Outdrive300 H.P. - 220.6 kW200 H.P. - 147.1 kW150 H.P. - 110.3 kW600 kg965 kg6.50x2.30x1.50 m2300 Lts2,700 LPHPATROL-850 SDB8.50 m6.91 m3.00 m1.88 m0.56 m74,780 kg26Inboard/Outdrive500 H.P. - 367.8 kW250 H.P. - 183.9 kW150 H.P. - 110.3 kW600 kg1,160 kg8.00x2.60x1.60 m2300 Lts2,700 LPHStandard Fittings- Bow cleat - Internal lifelines- Bow locker - Lifting handles- Bow davit lifting eyes - Mooring eye- Double rubbing strake - Safety relief valves- Elephant trunk deck drains - Stern davit lifting / towing points- Engine selected - Tube reinforcements- External lifelines - Under deck fuel tank- Hull drain socket - Wide hold below deckStandard Accessories- Aluminium hatch - Fuel gauge- Air pump - Repair kit- Electric Bilge pump - Telescopic paddlesOptional Accessories- Diving ladder - Backrest seat PT-7D- Backrest seat PT-7M - Double modular seat- Boat cover - Flag mast- Bottle rack 12-B - Keel protection- Bow “Samson” post - Motor Seat PT-SD7- Center console PT-6 - Navigation frame PT- Center console PT-7 - Self righting device- Single modular seat - Stern “Samson” post- Stern platform PT-SD27www.marinepower.com
Special seriesPT-850 CBAValiant has a qualified technical team for the design,development, manufacture, verification and manufacture controlaccording to the ISO 9001:2000 norm for any projects or specialrequests that are demanded by professional clients.In this range is the series with the SOLAS certification and craftfor rescue organisations, army and industry.PT-850 CBAPT-650 Maritime policePT-750 Red Cross28
RB-400 SOLASPT-650 JetLR/SOLAS SAS S020058EC MED MED 0250125Jet detail29Self righting devicewww.marinepower.com
AccessoriesConsole steering system includedCenter console S-3 Center console S-4Center console S-5 Center console S-6 Center console S-7 Center console PT-5Center console PT-6 Center console PT-7Jockey console S-3Double jockey console S-5Double jockey console S-7Seats and backrestsBackrest seat S-3 Backrest seat S-4 Folding backrest seat S-5Backrest seat PT-7MBackrest seat PT-7DFolding backrest seat S-7DSinglemodularseatDoublemodularseatMotor seat PT SD-730
VariousNavigationframe PTBottle rack 12-BNavigation frame S-4Navigation frame S-6/7Aluminium HatchStern Samson postBow Samson postFoot straps Bow roller 510 x 457 mm 370 x 270 mm 600 x 350 mmIce chest – Sundeck platforms & laddersBathing ladder S-4Cushion M-72Cushion M-48Ice chestMarine 72Ice chestMarine 25Ice chestMarine 48Diving center ladderBathing ladder S-5 and S-7Bimini sunshadeBOAT COVERSAccessories listPart NumbersD-240D-270D-300D-340D-380V-400V-450V-490V-520 LimitedV-520V-570V-620V-750V-620 CruiserV-750 CruiserDR-400DR-450DR-490DR-520DR-570DR-620DR-750PT-520PT-650PT-750PT-850PT-650SDPT-750SDPT-850SDBoat Cover D-240 VAC 31111D24005 OBoat Cover D-270 VAC 31111D27005 OBoat Cover D-300 TENDER/BASIC VAC 31111300B05 OBoat Cover D-300 SPORT VAC 31111300S05 OBoat Cover D-300 FAMILY VAC 31111300F05 OBoat Cover D-340 BASIC VAC 31111340B05 OBoat Cover D-340 SPORT VAC 31111340S05 OBoat Cover D-340 FAMILY VAC 31111340F05 OBoat Cover D-380 BASIC VAC 31111380B05 OBoat Cover D-380 SPORT VAC 31111380S05 OBoat Cover D-380 FAMILY VAC 31111380F05 OBoat Cover V / DR-400 VAC 31112V40005 O OBoat Cover V / DR-450 VAC 31112V45005 O OBoat Cover V / DR-490 VAC 31112V49005 O OBoat Cover V/DR/PT 520 VAC 31112V52005 O O O OBoat Cover V / DR-570 VAC 31112V57005 O OBoat Cover V 620 / DR 620 VAC 31112V62005 O OBoat Cover V 620 CRUISER VAC 31112V620CR05 OBoat Cover V / DR-750 VAC 31112V75005 O OBoat Cover V 750 CRUISER VAC 31112V750CR05 OBoat Cover PT-650 / PT-650 SD VAP 21020020 O OBoat Cover PT-750 / PT-750 SD VAP 21020015 O OBoat Cover PT-850 / PT-850 SD VAP 21020021 O O★: Standard Equipment ▲ : S<strong>port</strong> VersionO: Optional Equipment ◆: Family Version31www.marinepower.com
CONSOLESSEATS & BACKRESTSVARIOUSICE CHESTS& CUSHIONSAccessories listPart NumbersD-240D-270D-300D-340D-380V-400V-450V-490V-520 LimitedV-520V-570V-620V-750V-620 CruiserV-750 CruiserDR-400DR-450DR-490DR-520DR-570DR-620DR-750PT-520PT-650PT-750PT-850PT-650SDPT-750SDPT-850SDCenter Console S-3 VAC 11110030BR03 ◆ ◆ ◆Center Console S-4 VAC 11130040BR06 ★ ★ ★Center Console S-5 VAC 11130050BR06 ★ ★Center Console S-6 VAC 11130060BR06 ★ ★Center Console S-6 CRUISER VAC 11130060BA04 ★Center Console S-7 VAC 11130070BR06 ★Center Console S-7 CRUISER VAC 11130070BA04 ★Center Console PT-5 VAC 11130150BR06 O O O O O O O OCenter Console PT-6 VAC 11130160BR06 O O O O O O O OCenter Console PT-7 VAC 11130170BR06 O O O O O ODouble Jockey Console S-5 VAC 11110050BR06 O O O O O O ODouble Jockey Console S-7 VAC 11110070BR06 O O O O O OJockey Console S-3 VAC 11110030BR03 ▲ ▲ ▲ O O OHydraulic Steering System VAC 11141280NA03 ★ ★ ★ ★ ★ ★Backrest seat S-3 VAC 11230030BR03 ◆ ◆ ◆Backrest seat S-4 VAC 11230040BR03 ★ ★Folding Backrest seat S-7D T VAC 11230060BR03 ★Folding Backrest seat S-7D CRUISER VAC 11230060BA04 ★Backrest seat PT-7D VAC 11250072PR03 O O O O O O O OBackrest seat PT-7M VAC 11250071PR03 O O O O O O O O O O ODouble Modular Seat VAC 11240020BR03 O O O O O O O O OFolding Backrest Seat S-5 VAC 11230050BR03 ★ ★ ★Folding Backrest Seat S-6 VAC 11230060BR06 ★Motor Seat PT-SD7 VAC 11270072BR03 O O OSingle Modular Seat VAC 11240010BR03 O O O O O O O O OStern Seat V-620 T VAC 11270622CI03 ★Stern Seat V-750 T VAC 11270752CI03 ★Aluminium Hatch See Dealer ★ ★ ★ ★ ★ ★ ★ ★ ★Bathing Ladder S-4 VAC 22330032NA04 O O O O O O O OBathing Ladder S-5 VAC 22330053BR03 O ★ ★ O ★ O OBathing Ladder S-7 VAC 22330073BR03 O ★Bimini Sunshade V/DR-520 VAC 31120522BR03 O O OBimini Sunshade V/DR-570 VAC 31120572BR03 O OBimini Sunshade V/DR-620 VAC 31120620BR03 O O OBimini Sunshade V/DR-750 VAC 31120752BR03 O O OBottle Rack 12-B VAC 21310120NA04 O O O O O O O OBow Roller Black VAC 23110403PR03 O O O O O O O O O O OBow Roller Grey VAC 23110403CI03 O O OBow Samson Post VAC 22210020NA03 O O O O O ODeck Shower Kit VAC 21610653BR04 O O ★ ★Dive Center Diving Ladder DR-620 VAC 22330653NA04 ODive Center Diving Ladder DR-750 VAC 22330753NA04 ODiving Ladder VAP 33120001 O O OFlag Mast VAC 21190660NA03 O O O O O O OFrame with Self Righting Device See Dealer O O O O O OPVC Keel Protection See Dealer O O O O O O OKeel Protection PT-650 VAC 22110654NA03 O OKeel Protection PT-750/850 VAC 22110754NA03 O O O OLarger Capacity Fuel Tank See Dealer O O ONavigation Frame S-4 VAC 21110341NA03 O O O O O ONavigation Frame S-5 VAC 21110522NA03 O O O O ONavigation Frame S-6/7 VAC 21110524NA03 O O O O ONavigation Frame PT 650 VAC 21110654NA05 O ONavigation Frame PT 750 VAC 21110754NA05 O ONavigation Frame PT 850 VAC 21110854NA05 O ONavigation Frame V-620 Cr w/Sternseat VAC 21110622BR05 ★Navigation Frame V-750 Cr w/Sternseat VAC 21110752BR04 ★Retractable Bow Roller VAC 23110750BR04 O O ★ ★Ski Mast VAC 21290622NA03 O O ★ ★Bathing Platform V-620 VAC 22320053BR03 O ★Bathing Platform V-750 VAC 22320073BR03 O ★Stern Platform PT-SD See Dealer O O OStern Samson Post VAC 21210030NA03 O O OSundeck V 450 (Sundeck + Cushions) VAC 21510452CI04 OSundeck V 490 (Sundeck + Cushions) VAC 21510492CI04 OSundeck 520 Cushions VAC 21510522CI03 O O OSundeck 570 Cushions VAC 21510572CI03 O OSundeck Cushions V-620 VAC 21510622CI03 OSundeck Cushions Sup<strong>port</strong> V-620 VAC 21520622BR03 O ★Sundeck Cushions V-620 CRUISER VAC 21510622BA04 ★Sundeck Cushions V-750 VAC 21510752CI03 OSundeck Cushions Sup<strong>port</strong> V-750 VAC 21520752BR03 O ★Sundeck Cushions V-750 CRUISER VAC 21510752BA04 ★Electric Ice Chest Kool Mate 40 QS 875058 ★Ice Chest Marine 25 VAP 875036 O O O O O O O OIce Chest Marine 48 VAP 875038 O O O O O O O OIce Chest Marine 72 QS 875040 O O O OIce Chest Cushion Marine 48 VAP 21060028A1C O O OIce Chest Cushion Marine 72 VAP 21060029A1C O O O OIce Chest Tie down kit QS 875028 O O O O O O O O ★ O O O O O O OBoat covers on page 31★: Standard Equipment ▲ : S<strong>port</strong> VersionO: Optional Equipment ◆: Family VersionRemember - Life vests float. You don’t. Always use your engine’s safety stop lanyard.ISO 9001:2000Valiant is part of the familywww.marinepower.com© M.P.E. 2005 PPH GB PRINTED IN BELGIUM 90-883411-06Mercury Marine continuously explores means to improve the products its designs, manufactures and distributes. Changes to the specifications of its engines, boats and accessories are ongoing. Every effort is made to produce sales and serviceliterature which is current. This brochure should not be regarded as a precise guide to the latest specifications. This brochure is also not an offer for sales of any particular engine, boat, or accessories. Distributors and dealers are not agents of MercuryMarine and they have no authority to bind Mercury Marine by any express undertaking or representation, including but not limited to representations of a product, sales, applications, or service nature.The technical characteristics described in this brochure are based on the application of the ISO 6185 standard and could conflict with different national regulations. We advise you to consult the official norms of each country. Due to the special conditionof being foldable and collapsible, the weights and sizes of craft mentioned in this brochure are always approximate and can vary slightly. The company reserves the right to change the specifications of accessories and craft without previous notice.Some of the action photographs published in this catalogue may show a selection of accessories and equipment not included in the basic option or differ from the selection of accessories offered by Valiant.
