THEBEN<br />
2<br />
Save energy with <strong>Theben</strong>.
Dear clients and partners,<br />
Even if they often work unseen: <strong>Theben</strong> products and systems<br />
are part of our everyday lives at home, in the workplace or on<br />
the road. Because time, light and climate control are needed<br />
everywhere if there is a requirement to:<br />
• Reduce CO 2 emissions<br />
• Protect the climate<br />
• To reduce energy costs<br />
»<strong>Energy</strong> saving ideas« made by <strong>Theben</strong>. In this brochure you can<br />
find lots of good examples of better living. Look forward to the<br />
future with <strong>Theben</strong>.<br />
Thomas Goes<br />
Chairman of the Board<br />
3<br />
THEBEN
THEBEN<br />
4<br />
<strong>Energy</strong> saving ideas by <strong>Theben</strong>.<br />
This is how it works.
It is basically very straightforward : Using <strong>Theben</strong> products<br />
enables energy to be supplied in a targeted manner and<br />
without wastage: Where it is needed – and only when it is<br />
needed. In other words: <strong>Energy</strong> in the right place at the<br />
right time. This saves money and the intelligent control of<br />
energy consumption quickly pays for itself.<br />
With time, light, and climate systems<br />
Time control, e. g.:<br />
• Limit stair lighting to a few minutes.<br />
• Activation of service water circulation pumps morning,<br />
noon and night.<br />
• Alternatively: Operation of service water heating pumps<br />
only during off-peak periods.<br />
Light control, e. g.:<br />
• Street, shop window and path lighting only come on when<br />
it's dark. And cheaper off-peak electricity is used at the<br />
same time.<br />
• Office, corridor, washroom and toilet lighting operate<br />
automatically in event of presence and darkness.<br />
Climate control, e. g.:<br />
• Comfort temperature only during the day; the temperature<br />
is reduced at night and energy saved.<br />
• Ventilation and air-conditioning in classrooms and offices<br />
are only activated when the room is occupied.<br />
• CO 2-dependent ventilation control is ideal.<br />
5<br />
THEBEN
LIGHT<br />
6<br />
Streets and private roads. <strong>Theben</strong><br />
helps provide a safe environment.
Good lighting makes public spaces safer, but that needs to be efficiently<br />
controlled. It stands to reason: Lights don't have to be on all<br />
the time. Excellent professional light ing control with twilight switches<br />
from <strong>Theben</strong>. In both public and in private spheres, <strong>Theben</strong> ensures<br />
the efficient use of light, easy to use, economical and safe.<br />
Lighting control<br />
LUNA 122 top2 RC<br />
Twilight switch<br />
• Digital light control device with weekly as well as holiday and bank holiday<br />
programs<br />
• Precisely adjustable lux value for desired control of lighting or sun protection<br />
• Text‑based programming and preset values make start‑up easy<br />
• Programs can easily be copied via insertable memory card<br />
• <strong>Energy</strong> can be saved at night and in the early hours of the morning using the<br />
adjustable night switch‑off facility<br />
• 2 date‑controlled special programs and programming via PC can be used<br />
LUNA 129 star-time<br />
Twilight switch<br />
• Digital photo‑electric switch with integrated energy‑saving night time cut‑out<br />
• Elegant housing, integrated light sensor with large lighting angles<br />
helps with selection of installation location<br />
• Easy set‑up using preset parameters that can, however, be altered as required<br />
• Adjustable brightness threshold for switching on/off, can be set from 2 – 200 lux<br />
• On/off switching delay of approx. 2 – 100 s to avoid faulty operation caused by<br />
lightning and car headlights<br />
• Preset night time cut‑out (23.00 off, 5.00 on)<br />
7<br />
LIGHT
LIGHT<br />
8<br />
Private outdoor areas. <strong>Theben</strong><br />
helps provide a sure footing.
Where we live should be light and safe, including outdoors. And in<br />
order to prevent lighting on terraces, gardens or driveways being<br />
permanently switched on, <strong>Theben</strong> motion detectors ensure that lighting<br />
only comes on when somebody approaches. A function that has<br />
an effect on uninvited guests : Which burglar wants to be under the spotlight?<br />
Motion detector<br />
LUXA 101-180<br />
Motion detector<br />
• Passive infrared motion detector for internal and external wall installation<br />
• Corner wall installation with optional corner installation bracket for internal and<br />
external corners<br />
• Lighting control based on presence and brightness<br />
• Large detection area with a max. 12 m radius<br />
• Sensor head can be rotated horizontally by +/‑ 90° and tilted downwards by<br />
40°, thus allowing maximum adjustability<br />
• Additional creep under protection to cover a 360° area with a maximum diameter<br />
of 5 m at an installation height of 2,5 m<br />
SPHINX 105-300<br />
Motion detector<br />
• Passive infrared motion detector for wall and ceiling installation<br />
• Internal or external installation possible using optional corner installation bracket<br />
• Lighting control based on presence and brightness<br />
• Large detection area of max. 30 m diameter<br />
• Sensor head can be adjusted vertically by 90° upwards or 25° downwards, thus<br />
allowing universal installation<br />
• Detection area can be limited using accompanying segments and thus avoid switching<br />
lights on unnecessarily<br />
• Remote control can be used for easy set‑up of teach‑in function for current lux value<br />
9<br />
LIGHT
LIGHT<br />
10<br />
Airports and foyers. <strong>Theben</strong> helps<br />
provide light at the right moment.
Whether in airports or foyers, classrooms or corridors: Wherever it's<br />
busy , it is good to know that lighting and room temperature are<br />
reliably controlled. Discretely installed and optionally connected to a<br />
EIB/KNX BUS system, thebenHTS presence detectors record presence<br />
and movement of people in the room and use this data to control lighting, heating<br />
and air conditioning systems – and it is also good to know that the set-up is<br />
really easy thanks to factory presets and remote control.<br />
Presence detector<br />
thebenHTS ECO-IR 360C NT<br />
Presence detector<br />
• 360° presence detector with 2 channels for ceiling mounting and for automatic<br />
lighting and HVAC control based on presence and brightness<br />
• Also records slight movements<br />
• Adjustable brightness range from 10 – 1500 lux with self‑learning run‑on time<br />
• User remote control »click« operates the lighting and controls light scenes<br />
• Rectangular detection range, 8 m x 8 m (installation height 3.5 m)<br />
• Fully‑ or semi‑automatic operation with manual setting for increased energy savings<br />
• Suitable for master/slave and master/master switching<br />
• High switching capacity via inrush current limitation (EVG)<br />
thebenHTS compact passage<br />
Corridor presence detector<br />
• 360° presence sensor optimised for corridors with 2 channels for ceiling installation<br />
and for automatic lighting and HVAC control based on presence and brightness<br />
• For brightness‑ and movement‑dependent control of lighting<br />
• Brightness range of 10 – 1500 lux and run‑on time of 10 seconds – 20 minutes<br />
• Easy start‑up possible via service remote control<br />
• User remote control »click« operates the lighting and controls light scenes<br />
• Rectangular detection range, 30 m x 4 m (installation height 2.5 m)<br />
• Fully‑ or semi‑automatic operation with manual setting for increased energy savings<br />
• Suitable for master/slave and master/master switching<br />
11<br />
LIGHT
TIME<br />
12<br />
Shop windows and advertising hoardings.<br />
<strong>Theben</strong> helps provide an attractive look.
What would shopping be like without illuminated shop windows?<br />
<strong>Theben</strong> weekly and yearly timers help present goods and hoardings in<br />
their best light and for exactly the desired amount of time. Not only<br />
the world of dreams but also completely everyday processes can be<br />
controlled by <strong>Theben</strong> time control solutions: from pump controls through heating<br />
and ventilation control to complete lighting provision for buildings.<br />
Time control<br />
TERMINA 611 top2<br />
Weekly time switch<br />
• 1‑channel weekly timer with easy‑to‑follow, text‑based instructions<br />
• Spring terminals enable quick and easy installation<br />
• Interface for OBELISK top2 memory card enables PC programming<br />
• Copying, archiving and operation is possible via a second insertable switching<br />
program on memory card<br />
• Date‑controlled holiday program<br />
• 10 year power reserve through lithium battery, for operational reliability even<br />
after long power cuts<br />
TERMINA 644 S<br />
Yearly time switch<br />
• Programming on PC with OBELISK programming set or via key entry<br />
• 4 channels for 10 standard weekly programs with various priority levels<br />
• Calendar‑controlled automatic summer‑/winter time changeover<br />
• With pre‑programmed public holiday database for all German Länder<br />
• Bank holiday date adjustment for following years saves time‑consuming<br />
reprogramming<br />
• Program simulation and printing possible via PC<br />
• Large power reserve via exchangeable lithium batteries<br />
13<br />
TIME
CLIMATE<br />
14<br />
Hotels, offices and private houses.<br />
<strong>Theben</strong> helps provide a good climate.
People in hotels: Individual characteristics mean individual requirements<br />
for temperature and light. No problem with individual room<br />
control from <strong>Theben</strong>: Flexible application, reliable technology and<br />
easy to use, <strong>Theben</strong> thermostats provide semi-public and private<br />
areas with exactly the right climatic conditions wherever they are used – and they<br />
save energy at the same time.<br />
Individual room control<br />
RAMSES 831 top2<br />
Digital clock thermostat<br />
• Attractive pilot room or individual room thermostat for functional buildings and<br />
private housing<br />
• Suitable for radiator, underfloor and electrical heating systems<br />
• High level of energy saving through program‑controlled temperature reduction at<br />
night and during working hours<br />
• Easy operation through text guidance on illuminated screen<br />
• External input for connection of presence detectors, floor sensors, window contacts<br />
or telephone remote switch<br />
RAMSES 782<br />
Anlalog clock thermostat<br />
• Flat design clock thermostate for independent monitoring and control of room<br />
temperature.<br />
• Simple setting of the energy‑saving night set‑back on the program dial.<br />
• Changeable tappet dial for 24 hours or 7 days.<br />
15<br />
CLIMATE
CLIMATE<br />
16<br />
Schools, conference rooms, halls.<br />
<strong>Theben</strong> helps provide fresh air.
Lots of people sharing a room can quickly produce poor air quality –<br />
through exhaled carbon dioxide. The result: Reduction in powers of<br />
concentration,performance and well-being. It's good if somebody<br />
makes sure that certain values are not exceeded – ventilation control<br />
from <strong>Theben</strong>, suitable for meeting rooms, offices, schools and nurseries, passive<br />
and low energy houses and living rooms.<br />
Ventilation control<br />
AMUN 716 R<br />
CO 2 sensor for automatic fan control<br />
• Fan control for meeting, conference, office, school or waiting rooms as well as<br />
passive and low energy houses<br />
• To increase the feeling of well‑being, performance and to avoid loss of concentration<br />
• 2‑stage fan control with 2 relay outputs<br />
• Key for manual and automatic operation<br />
• Warning display for CO 2 concentration via lights (3 LEDs )<br />
• 3 proportional outputs 0 –10 V for CO 2 concentration, temperature and relative<br />
humidity in the room<br />
• Simple upgrade of uncontrolled ventilation systems possible<br />
17<br />
CLIMATE
SYSTEMS<br />
18<br />
Private and business premises.<br />
<strong>Theben</strong> helps provide comfort.
Heating, ventilation, lighting,<br />
blinds: The <strong>Theben</strong> KNX<br />
building controller controls<br />
everything that belongs in<br />
buildings with modern comfort levels<br />
– and all in an energy efficient manner<br />
and with all components perfectly<br />
matched to each other.<br />
KNX building controller<br />
KNX weather station<br />
Reduced energy consumption through use<br />
of home and building technology systems<br />
Maximum values in the “Potential energy savings through modern electrical installations” study<br />
Reduced energy consumption as %<br />
Individual room<br />
control<br />
Individual room<br />
control<br />
Bremen University research project (2006)<br />
on the subject of energy saving potential using KNX in buildings.<br />
VARIA 826 KNX<br />
Room thermostat and multi-function display<br />
Automation of<br />
sun protection<br />
Automation of<br />
lighting<br />
Automation of<br />
ventilation<br />
• Central display and control unit in glass design<br />
• Integrated room temperature control for heating/cooling/air conditioning systems<br />
• Temperature profile control of up to 8 rooms with 3 different temperatures<br />
• Freely configurable for displaying and controlling functions e. g. light scenes, sun<br />
protection systems<br />
• Aluminium push button for easy operation of lighting, light scenes, room<br />
temperature and blinds<br />
• Up to 7 different editable display pages<br />
• Weekly timer with 8 channels with up to 3 different statuses, e. g. for light, shutters,<br />
fans etc.<br />
• Combination device for smaller business premises and detached and semi‑detached<br />
houses<br />
• Are directly connected to the BUS without laying additional cables<br />
• Records wind, rain, brightness and temperature<br />
• Highly sensitive rain sensor (incl. delay to avoid unnecessary blinds operation)<br />
• Automatic sun protection mechanism controls blinds independently<br />
• Optimised sun protection for up to 3 sides of building is possible<br />
19<br />
SYSTEMS
SYSTEMS<br />
20<br />
Private houses.<br />
<strong>Theben</strong> helps to save energy.
At home – that is the place that is beautifully and comfortably designed<br />
where you can feel safe and protected. In order to turn this desire<br />
into reality, <strong>Theben</strong> have produced the living comfort control.<br />
Whether it's external lighting, blinds control, panic function or deceptively<br />
genuine presence simulation: With equally innovative as reliable technology<br />
<strong>Theben</strong> provides for more comfort and greater safety – while using less energy.<br />
Living comfort controller<br />
LUXOR 400<br />
Basic model for living comfort control<br />
• System for building automation of small business premises and detached and<br />
semi‑detached houses<br />
• Upgradeable system for up to 64 channels with modules for lighting, shutters,<br />
blinds as well as time and weather sensor system<br />
• Setting options for central On/Off, panic and presence simulation<br />
• Absolute functionality thanks to "stand‑alone" function for each module<br />
• Easy adjustment via LED displays on modules<br />
• 2‑wire COM interface for communicating with other modules<br />
LUXOR 408<br />
Basic module for controlling blinds, awnings and shutters<br />
• Control of 4 drives<br />
• Upgradeable system for up to 64 channels, combinable with modules for time<br />
control with astronomical program and weather sensor system<br />
• Manual individual, group and central control<br />
• Absolute functionality thanks to "stand‑alone" function for each module<br />
• Easy adjustment via LED displays on modules<br />
• 2‑wire COM interface for communicating with other modules<br />
21<br />
SYSTEMS
22<br />
Reduce CO 2 emissions and<br />
save on energy costs as in the<br />
example of a school building in<br />
Schwäbisch Gmünd using an<br />
ECO‑IR 180A<br />
References<br />
Philipp Morris neon advertising signs<br />
Products used:<br />
LUNA 129 star‑time<br />
Hofer branches, Slovakia<br />
Products used:<br />
LUXOR<br />
Hotel Sacher, Vienna<br />
Products used:<br />
KNX products<br />
BASF, Ludwigshafen<br />
Products used:<br />
KNX OSIRIA wall clocks<br />
COOP, St. Gallen<br />
Products used:<br />
thebenHTS presence detector<br />
Street lighting‚ Berlin<br />
Products used:<br />
LUNA 129 star<br />
Doctors' surgery, Aalen<br />
Products used:<br />
RAMSES 822 top<br />
CO 2 emissions in tonnes per year<br />
0,600<br />
0,500<br />
0,400<br />
0,300<br />
0,200<br />
0,100<br />
0,000<br />
0,542<br />
before<br />
0,166<br />
after<br />
Technical Services Schussental<br />
Products used:<br />
KNX CHEOPS drive<br />
AOK Karlsruhe<br />
Products used:<br />
KNX weather station, LUNA 131<br />
University Library Mannheim<br />
Products used:<br />
KNX sun protection and<br />
lighting control<br />
Freudenberg KG, Weinheim<br />
Products used:<br />
KNX CHEOPS control<br />
Speyer District Hospital<br />
Products used:<br />
LUXOR lighting control<br />
SWR Baden-Baden,<br />
Products used:<br />
KNX lighting and blinds control<br />
with weather station<br />
Annual costs in euros<br />
150<br />
125<br />
100<br />
75<br />
50<br />
25<br />
0<br />
125<br />
before<br />
JC Decaux, France<br />
Products used:<br />
SELEKTA 170 top2<br />
7/11 Shops, Taiwan<br />
Products used:<br />
TERMINA 610 top2, LUNA 108<br />
Street lighting‚ Oman<br />
Products used:<br />
SELEKTA 170 top2<br />
38<br />
after<br />
Hohenzollern Castle, Bisingen<br />
Products used:<br />
TERMINA 644 S<br />
Heathrow Terminal 5, London<br />
Products used:<br />
KNX products
Further information on <strong>Theben</strong> is available via<br />
Telephone 0 74 74 -69 20 or at www.theben.de<br />
Further energy conservation links<br />
www.energiespartipps‑online.de<br />
www.thema‑energie.de<br />
www.energiesparen‑im‑haushalt.de<br />
www.stromeffizienz.de/stromsparen.html
<strong>Theben</strong> AG<br />
Hohenbergstraße 32, 72401 Haigerloch, GERMANY<br />
Postfach 56, 72394 Haigerloch, GERMANY<br />
Telefon +49 (0)‑74 74/6 92‑0<br />
Telefax +49 (0)‑74 74/6 92‑150<br />
e‑mail: info@theben.de, www.theben.de<br />
990 0 632 1809 We reserve the right to make technical modifications and improvements.
