<strong>Technical</strong> <strong>Specification</strong> <strong>01</strong> / 2<strong>01</strong>1
Type / Model I 9910 I 9940 I 9950Length / Width / Height cm 899/232/350 899/232/350 899/232/350Internal height cm 207 207 207Towing weight** 12% / without brakes kg 3000/750 3000/750 3000/750Tyres 225/75R 16C 225/75R 16C 225/75R 16CWheel base cm 475 475 475Bed Pull-down bed cm 198x140* 198x140* 198x140*Alternative cm 200/160/200x200 - -Rear cm 2x 200x80 200x160/130 200x160/130Standard engine Iveco Daily 3.0 l JTD Iveco Daily 3.0 l JTD Iveco Daily 3.0 l JTDkW (BHP) 125 (170) 125 (170) 125 (170)Chassis Iveco Iveco IvecoWeight net kg 5020 5020 5020Mass in running order (approx.) kg 5300 5300 5300Maximum user payload (approx.) kg 1700 1700 1700Maximum authorised weight (approx.) kg 7000 7000 7000Designated passenger seats 4 4 4Designated passenger seats for max. weightincrease4 4 4Heating ALDE ALDE ALDEFridge / thereof freezer compartment l 175/31 175/31 175/31Water incl. boiler (reduced volume) / wastewater tank capacitiesl 320 (100)/220 320 (100)/220 320 (100)/220I 9910 I 9940 I 9950Storage space D2 • B2 • B2 •Swivel driver seat • • •Swivel passenger seat • • •Battery / charger Ah/ A 1x160/ 36 1x160/ 36 1x160/ 36Outlets 230 V / 12 V 6 / 2 6 / 2 6 / 2• = Standard* only in conjunction with optional extras „pull-down bed“** with automatic gearbox „Agile“ the towing weight is reduced to 2.000 kgWhen desired, availablewith L-shaped lounge
Chassis Package „I“ Differential lock ASR Air suspension spring for rear axle Headlights in bus optic Chromed wheel trimsChassis Package „II“ Differential lock ASR Full air suspension spring Headlights in bus optic Chromed wheel trimsDriver Package Sunblinds for driver and passenger (manual)(5381 / 35 kg)(5380 / 55 kg)(5379 / 50 kg) SKA air swinging seats with lumber support and seat heatingAir Conditioning Package Underfloor air conditioning Saphir Comfort(5376 / 65 kg) Roof air conditioning Telair Silent 7300 H (air conditioning forliving and sleeping area)Electric Package „small“ 2nd battery 160 Ah Mastervolt AGM Charging device EBL 220 Charging rate at 54 A Front blinds (electrical) Inverter module 150 WattElectric Package „large“ 2 x 225 Ah Mastervolt AGM batteries Truma Vicon 2 energy-management system Charging rate at 90 Ah Front blinds (electrical) Inverter module 1500 WattLeather Package Leather cushions AMALFI or SANSIBAR Leather driver and passenger seats Leather cab dash Leather steering wheel Leather gearshift cover Leather hand brake gaiter Leather facing for coffers and seat pansGourmet Package Central vacuum cleaner Shower doors in homelike optic(5378 / 66 kg)(5377 / 122 kg)(5382/5383 / 30 kg)(5414 / 80 kg) Sliding door with full-length portrait mirror Kitchen working surface and top with mineral material Spinflow-3-burner gas hob and stainless steel sinkMultimedia Package Navigation Pioneer F920-BT SAT system Teleco Digital 85 Twin Flat screen 22“ incl. bracket (living room) Flat screen 19“ incl. bracket (sleeping room) Radio pre-wiring with Sound package Jehnert Sound system Radio JVC CD / MP3 Radio pre-wiring for sleeping room Reversing camPremium Liner Package Smooth sides Silver / Anthracite Side wall applications (attached) Exterior mirrors silver-painted Additional access locker door in the rear N/S Alternative applications for the exterior bodywork Interior trim with chequer plate for rear garageWellness Package(5307 / 50 kg)(5413 / 80 kg)(5385/5386 / 60 kg) Otten-Comfort-Sleeping system: 7-zones mattress with 3Dmembrane and visco-elastic surface Slatted frame with adjustable heading section Indirect illumination (LED illumination in the overhead lockers) Furniture Cypress Villa with cream-coloured HPL high-glossfronts Heki with plinth in sleeping room
Weight Code I 9950 I 9910 I 9940Chassis / Base vehicleAlloy wheels (alloy wheels front axle, wheel trims rear axle) – 1790 ¦ ¦ ¦Tow bar 26 1752 ¦ ¦ ¦Automated gearbox „Agile“ (authorised towing weight is reduced to 2.000 kg) 5 105 ¦ ¦ ¦Bodywork exteriorElectr. corner steadies with leveling system E&P 60 1742 ¦ ¦ ¦Cab insulation mat 1 934 ¦ ¦ ¦2nd access locker door 10 331 ¦ ¦ ¦Awning Omnistor 6 m (electrical) 60 519 ¦ ¦ ¦Rear corner steadies (2 pieces) 6 1685 ¦ ¦ ¦Fridge vent cover (for standard fridge only) 1 282 ¦ ¦ ¦Bodywork interiorElectr. pull-down bed with elegant undersurface 75 1793 ¦ ¦ ¦Heki III in the rear 60 442 ¦ ¦ ¦Sunblind for driver and passenger (manual) 3 1708 ¦ ¦ ¦Soft furnishingSleeping system Otten Comfort for double bed rear 2 1852 ¦ – ¦Sleeping system Otten Comfort for single beds rear 2 1852 – ¦ –3D mattress 7 zones with visco-elastic surface for double bed rear – 1949 ¦ – ¦3D mattress 7 zones with visco-elastic surface for single beds rear – 1947/1948Real leather SANSIBAR – 1828 ¦ ¦ ¦Real leather AMALFI – 1800 ¦ ¦ ¦InstallationsCrash sensor – 1902 ¦ ¦ ¦Shower mixer tap „Water fall“ (splash water shower) 4 1779 ¦ ¦ ¦BBQ 30 mbar 1 878 ¦ ¦ ¦Air conditioning Saphir Comfort 34 1791 ¦ ¦ ¦Solar system (2 x 135 Watt) 15 1795 ¦ ¦ ¦Second cassette for Thetford toilet 2 502 ¦ ¦ ¦SOG tank ventilation (toilet) 3 1681 ¦ ¦ ¦Switch over system Duo Control 1 1903 ¦ ¦ ¦WEBASTO additional heating 7 517 ¦ ¦ ¦Additional pump 230 V for ALDE heating 1 314 ¦ ¦ ¦KitchenOven (only in conjunction with fridge/freezer combination!Not available with Compressor fridge, microwave or dish washer)4 290 ¦ ¦ ¦Microwave (not in conjunction with oven or dish washer) 15 718 ¦ ¦ ¦Dish washer (only in conjunction with Compressor fridge) 10 1856 ¦ ¦ ¦Compressor fridge 8 651 ¦ ¦ ¦MiscRegistration documents – – « « «Equipment: ¦ Optional Extras – Not possible « Obligatory
Chassis / Base vehicle Iveco Daily 70 C 17 | 3.0 l JTD (125 kW/170 BHP),standard transmission 6-gears (manual) Diesel particulate filter – compliance withEURO 5 emissions Rear wheel drive with twin tyres ABS EBV Fuel tank 90 l Drop chassis extension with protection wheelsunderneath Panorama surrounding windscreen Steering wheel lock and anti-theft device Bus-style windscreen wiper system Wing mirrors heated and electrical Bi-Halogen headlights with day-time runninglights and additional headlights Cruise control Swivel Pilote seats with integrated safety belt,arm rests and height/ inclination adjustment,seat cushion adjustable lengthwise Warning triangle, First-Aid-Kit, warning lightand wheel chockConversion Smooth sides in white/silver (option silver/anthracite) Heated double floor (365 mm intermediateheight) with load-through possibility Wall thickness: sides and roof: 44mm,underfloor: 44 mm, inserted floor: 38 mm Fully insulated wall joining technique usinghigh-density solid PU profiles and Styrofoam Sidewalls and floor without wooden inlays Front and rear made off double-skin GRPmaterial. Two-pieces front (easy access tothe engine bay) Spacious rear garage, illuminated, with 230 V/12 V socket Large garage door in the rear O/S. Access lockerdoor N/S for skirt area Bus-style aluminium access locker doors withwide opening angle for optimal access to anyarea of the double floor Conversion door with window, interior trimand storage compartments Robust, double-glazed flush fitting windowwith integrated blind and flyscreen Double-glazed Panorama skylight (Heki III)with illuminated plinth, blind and flyscreen Bonnet made off clear Plexiglass, opening,with blind and flyscreen Electrical entrance step, optically integratedinto the vehicle skirtInstallations On-board-control panel Luxus with first-classclearness of display and extensive functions ALDE warm water heating with 10 l boiler Heat exchanger: reduces engine wear by coldstarting and uses the engine heat to warm upthe living room Energy-saving LED illumination technologyfor the interior Powerful AGM battery 160 Ah Current battery technology for fast chargingtimes and long durability, 100 % leak-proof Electrical charging device for leisure/ vehiclebattery 12 V/ 36 A CEE connection for 230 V with security deviceand earth leakage circuit breaker in doublefloor Gas bottle box for 2x11 kg with pullout foreasy change of gas bottles Powerful pressure water pump Water tank 320 l, waste water tank 220 l,frost-proof in heated double floor (100 lwaste water capacities during the driving) Comfortable tank cleanout by a centrallysituated drain valve in double floorKitchen Comfortable kitchen centre with 3-burnerhob and sink Spacious drawers on smooth steel runnersself-closing and central locking Waste bin integrated in drawer Gas block valves and gas control easy-to-accessand securely situated on the kitchen front Kitchen overhead locker with LED spots Large 175 l fridge / freezer combination withseparated freezer compartment Extractor fan (circulating air) Overhead locker with height-adjustable shelvesBathroom Bathroom and separated shower cubiclecan be connected to a large sanitary room Wooden furniture with chrome-colouredrail and stainless steel washbowl Spacious shower cubicle – illuminated,with plastic walls Cassette toilet with electrical pump andswivel ceramic seat LED illumination for bathroom Water tap with illuminated background Panorama window and skylight for goodventilationLiving Comfort One-level floor from the cab right throughto the rear Modern, swinging furniture design made offmassive plywood and lightweight materials AirPlus overhead locker ventilation forcondensation prevention Cold foam mattresses and wooden bed slatedframe with flexible strips for fixed beds Single beds with adjustable heading section Ergonomically shaped, high-quality seatcushions Compartment for flatscreen with pull-outbracket in living and sleeping area Two illuminated glass showcases and shoebin in entrance area Carpets in cab and living areaInterior Furniture:Standard: Cypress VillaOption: Cypress Villa with cream-colouredHPL high-gloss fronts Soft furnishing:Standard: BIRMAOption: Leather AMALFI or SANSIBAR
General Information<strong>Technical</strong> information for PREMIUM LINER <strong>01</strong>/2<strong>01</strong>1 is valid from 15.08.2<strong>01</strong>0.Previous technical specification brochure is no longer valid.The sizes and weights are approximate values. The installation of optionalextras will reduce the user payload and eventually authorised passenger number.<strong>Dethleffs</strong> reserve the right to alter technical and material specifications andstandard equipment at any time as material and conditions demand. Please note:the price of <strong>Dethleffs</strong> products in various European countries will differ. This is dueto differing levels of specification in the individual countries and varying rate ofVAT and luxury tax. Subject to change. Errors accepted.The maximum authorised total weight and axle load limits must not be exceededwhen passengers and personal items are taken into account therefore we displaythe weight net of the vehicle. This value informs you about the vehicle weight withstandard fittings without any fillings, optional extras and passengers.E1478 / 08.10 / 4.000 / Druckwerk SÜD / www.inallermunde.de<strong>Dethleffs</strong> GmbH & Co. KGArist-<strong>Dethleffs</strong>-Straße 12 • D-88316 IsnyTel. +49 (0) 75 62 / 98 71 79www.dethleffs.co.uk • info@dethleffs.co.uk
