DZ 12K S MAGNUM five axisTwin Spindle and complete 5-axis machiningwith 2-axis swivel rotary table for simultaneous milling and turningThe multiplier effect:More spindles, more cutting edges, more profitBy using CHIRON multi-spindle machining centerswith 2-axis NC tilt rotary table and highperformance tools, users can achieve multipleperformance increases.With the CHIRON DZ-12KS MAGNUM Twin-Spindle, Five-Axis Machining Center, two partscan be completely machined in one set-up withsuperior quality at the lowest cost. That means:I Reduction of the total machining timeI Reduction of piece priceI Simplification of material flowI Savings of human resources(reduced manpower)I Reduction of energySwiveling control panelCNC Control – Option for Siemens or FANUC.Spindle speed:up to 24.000 min -1Tool taper:HSK - A 63Automatic tool change with thepick-up procedure in as fast as 0.9 sArguments:I 2 Spindles – double productivity – over 30 % energy savingI CHIRON 2-axis tilt rotary table with TORQUE motorI Fully integrated standard automation (FLEXCELL UNO, MPC) possibleI Easy access to the machine through side door, swiveling control panelI Compact design for high productivity per unit areaI Turning up to 1,000 rpmI Stable, robust mineral cast machine baseI High thermal stabilityI High running, positioning, running accuracyI Fully enclosed working areaI Stainless steel protective coversI Central chip disposalI Low maintenace and durableI Service friendly access to all auxiliary unitsI Machine tool construction “Designed and made in Germany”Technical Data:I Travel [X -Y - Z]550 - 400 – 360 mmI Acceleration [X -Y - Z] up to 10 - 15 - 15 m / s²I Rapid feeds75 m / minI Spindle speedup to 24,000 rpmI Tool taper HSK - A 63I Milling capacity in St 602 x 150 cm 3 / minI Drilling capacity in St 602 x Ø 25 mmI Rigid Tapping 2 x M 20I Chain magazine / tool places 2 x 16 (optionally: 2 x 42 / 2 x 70)I Tool change time0,9 sI Chip-to-chip time2,4 sI 2-axis tilt rotary table- Swivel range ± 120°- 4th axis driven by backlash-free,pre-tensioned precision gears- Speed of 4th axis 50 rpm- 5th axis with digital direct TORQUE drive 2 x 360°- Speed of 5th axis 200 rpm / 1,000 rpm- Direct path-measuring system for 4th/5th axis ± 5” / ± 5”- Faceplate diameter 2 x Ø 245 mm- Bore hole pattern M16 x Ø 15H7 x 50 mm- Transport load max. 2 x 200 kgOptions:I Mist collector for working areaI 5th axis with 1,000 rpmI Coolant through the spindle, up to 150 barI Dry machiningI Machining with MQL(Minimum quantity lubrication)I Oil packageI CHIRON Thermo-ControlI CHIRON Laser-ControlI CHIRON Energy Efficiency PackageI CHIRON Fluid TowerI Stationary 3D probing systemI ProbeI Tool breakage controlI Robot interfaceI MPC (Multi Pallet Changer)I Flexcell UNO / Flexcell DUOI Automatic doorsI Zero point clamping system integratedwith face platesI Pneumatic connection for clamping devicesI Hydraulic unit and and connection forclamping devices2 ICHIRON DZ 12K S MAGNUM five axiswww.chiron.de
