Voice Cabling Systems from ExcelExcel Internal Grade Low Smoke and Fume Cable – CW1308The following range of multipair internal telephone cables aremanufactured in accordance with BT type CW1308. These Cores aretwisted into pairs and the required number of pairs are then laid up ineither layers for cables containing up to and including 25 pairs, or inunits for items of 32 pairs and above, the pairs are colour coded forease of identification. An earth conductor of 1.38mm plain copper isincluded where shown.Features● Choice of reel sizes● Low smoke and fume asstandard● Cut to length service above20 Pair● For colour and reel sizeavailability please contact ourSales Office● 0.5mm conductor sizeDescriptionPart Number2 Pair CW1308 TC002P3 Pair CW1308 TC003P4 Pair CW1308 TC004P6 Pair CW1308 TC006P10 Pair CW1308 TC010P10 Pair + Earth CW1308 TC010PE20 Pair CW1308 TC020P20 Pair + Earth CW1308 TC020PE25 Pair CW1308 TC025P25 Pair + Earth CW1308 TC025PE32 Pair + Earth CW1308 TC032PE40 Pair + Earth CW1308 TC040PE50 Pair + Earth CW1308 TC050PE100 Pair + Earth CW1308 TC100PE160 Pair + Earth CW1308 TC160PE200 Pair + Earth CW1308 TC200PE320 Pair + Earth CW1308 TC320PELSF CABLEAS STANDARDFREECut to lengthservice above 20 Pair112

Voice Cabling Systems from ExcelExcel Internal/External Grade Low Smoke Zero Halogen Cable – CW1308BThe following range of Multipair Telephone Cables are constructed ina similar way to Standard CW1308 but are suitable for Internal andExternal use due to a UV resistant jacket. The Cables specification isfurther enhanced by the use of Low Smoke Zero Halogen (LSOH)Outer Sheath.Features● Internal/External grade● Save installation time and cost● Black LSOH outer sheath● Integral 1/1.38mm earthconductor● 0.5mm conductor sizeDescriptionPart Number10 Pair + Earth CW1308B TC010PE-INEX20 Pair + Earth CW1308B TC020PE-INEX25 Pair + Earth CW1308B TC025PE-INEX50 Pair + Earth CW1308B TC050PE-INEX100 Pair + Earth CW1308B TC100PE-INEX200 Pair + Earth CW1308B TC200PE-INEX320 Pair + Earth CW1308B TC320PE-INEXExcel External Grade Cable – CW1128The following range of cables are made up from conductors of solidplain copper insulated with cellular (foamed) polyethylene. Theseconductors are twisted into pairs and the required number of pairs arelaid up into units which are identified by coloured tapes. The cablesare petroleum jelly filled and sheathed in black polyethylene, and aremanufactured in accordance with BT type CW 1128.Features● UV and moisture resistant● Choice of conductor sizeDescriptionPart Number5 Pair 1/0.50mm CW1128 TCJF5005PB10 Pair 1/0.50mm CW1128 TCJF5010PB20 Pair 1/0.50mm CW1128 TCJF5020PB50 Pair 1/0.50mm CW1128 TCJF5050PB100 Pair 1/0.50mm CW1128 TCJF5100PB200 Pair 1/0.50mm CW1128 TCJF5200PB5 Pair 1/0.90mm CW1128 TCJF9005PB10 Pair 1/0.90mm CW1128 TCJF9010PB113

Voice Cabling Systems from ExcelExcel Armoured External Grade Cable – CW1128/1198These cables are manufactured as the external cables detailedpreviously but have the addition of a steel wire armouring for directburial applications. The cables are manufactured in accordance withBT type CW 1128/1198.Features● UV and moisture resistant● Suitable for direct burial● 0.5mm conductor sizeDescriptionPart Number5 Pair CW1128/1198 TCJFA5005PB10 Pair CW1128/1198 TCJFA5010PBExcel Jumper Wire – CW1423CW1423 Jumper Wire is a Single Pair cable and is Insulated with anIrradiated Outer Sheath for use on Distribution Frames.Features● CW1423 - Blue/Yellow● 0.5mm conductor size● Supplied on 500 Metre reelsDescriptionPart NumberCW1423 Jumper Wire Blue/Yellow 550-030Excel Line Jack Units – 2 SeriesSingle Outlet Surface Mounted Line Jack Units. Supplied completewith Back Box and Fittings.Features● Choice of PSTN, PABX,Secondary● Supplied with Back Box● Single Gang● Dimensions 68 x 68 x 29mm(with Back Box).● Right Hand LatchDescriptionPart NumberPSTN Surface Mount LJU, Type 2/1A 550-250PABX Surface Mount LJU, Type 2/2A 550-251Secondary Surface Mount LJU, Type 2/3A 550-252114

Voice Cabling Systems from ExcelExcel Line Jack Units – 3 SeriesSingle Outlet Flush Mounted Line Jack Units. Supplied complete withfixings but without a back box.Features● Choice of PSTN, PABX,Secondary● Fits Standard Single GangPatress Box● Dimensions 86 x 86 x 8mm● Right Hand LatchDescriptionPart NumberPSTN Flush Mount LJU, Type 3/1A 550-253PABX Flush Mount LJU, Type 3/2A 550-254Secondary Flush Mount LJU, Type 3/3A 550-25521mm Back Box to Suit AboveLB3Excel Line Jack Units – 4 SeriesTwin Outlet Flush Mounted Line Jack Units. Supplied complete withfixings but without a back box.Features● Choice of PSTN, PABX,Secondary● Fits Standard Single GangPatress Box● Dimensions 86 x 86 x 8mm● Right Hand LatchDescriptionPart NumberPSTN Flush Mount Twin LJU, Type 4/1A 550-256PABX Flush Mount Twin LJU, Type 4/2A 550-257Secondary Flush Mount Twin LJU, Type 4/3A 550-25821mm Back Box to Suit AboveLB3115

Voice Cabling Systems from ExcelExcel RJ45 – LJU Telephone AdaptorsExcel Tailed Voice Adaptors convert RJ45 sockets to LJU presentationto allow telephones and modems to be connected to structuredcabling systems.Features● Matt white finish● Choice of Secondary, PSTN,PABX, ISDN● 6” Cable tail● Individually bagged● High density designDescriptionPart Number6” Tailed RJ45 plug – LJU Socket, Secondary Adaptor 100-6246” Tailed RJ45 plug – LJU Socket, PSTN Mastered Adaptor 100-6266” Tailed RJ45 plug – LJU Socket, PABX Mastered Adaptor 100-6286” Tailed RJ45 plug – LJU Socket, ISDN Adaptor 100-630Excel RJ45 – LJU Direct Connect Telephone AdaptorsExcel direct connect voice adaptors convert RJ45 sockets to LJUpresentation to allow telephones and modems to be connected tostructured cabling systems.Features● Choice of secondary, PSTN,PABX● Individually bagged● 54mm long x 24mm wide x23 mm deepDescriptionPart NumberDirect Connect RJ45 Plug – LJU Socket, Secondary Adaptor 100-640Direct Connect RJ45 Plug – LJU Socket, PSTN Mastered Adaptor 100-642Direct Connect RJ45 Plug – LJU Socket, PABX Mastered Adaptor 100-644Excel RJ45 – LJU Switchable Telephone AdaptorExcel tailed connect telephone adaptors with the added feature of thefacility to switch the adaptor to either secondary or PABX, makingeach unit suitable for use with both analogue and digital telephonesystems. These items are ideal for installations where the type ofPABX is not known prior to arriving on site or for installations where avariation of handsets are employed.Features● Time saving switchable design● Individually baggedDescriptionPart NumberTailed Switched RJ45 Plug – LJU Socket 100-646116

Voice Cabling Systems from ExcelExcel RJ45 – LJU Telephone Adaptors – CouplersExcel telephone couplers provide the conversion between RJ45 andLJU by the use of an RJ45 and LJU socket. Installation is completedby the use of a standard RJ45 patch lead, connected from the walloutlet to the coupler and the telephone or modem is then connectedto the LJU socket. Ideal for installations where the apparatus whichneeds to be connected to the cabling system, is situated somedistance from the RJ45 socket.Features● Choice of tailed or direct connect● Quick and easy to install● Individually baggedDescriptionPart NumberCoupler RJ45 Socket - LJU Socket, Secondary Adaptor 100-650Coupler RJ45 Socket - LJU Socket, PSTN Mastered Adaptor 100-652Coupler RJ45 Socket - LJU Socket, PABX Mastered Adaptor 100-654Excel Category 5e RJ45 Inline ConnectorThe Excel Category 5e through coupler is ideal for the extension ofexisting cabling installations, offering a straight through RJ45 to RJ45connection whilst maintaining Category 5e performance.Features● RJ45-RJ45 Socket● Category 5e performanceDescriptionPart NumberCategory 5e RJ45-RJ45 inline 23-0035117

Voice Cabling Systems from ExcelExcel In Line Connection BoxesIn Line Connection Boxes are used for connecting telephoneextensions and for joining together different cable types. 550-267 upto 3 pairs, 550-266 up to 4 pairs, each mount via 2 fixing screws.Features● Dimensions 56 x 41 x 23mm(550-267/550-266)● White Finish● Quick and Easy to InstallDescriptionPart Number3 Pair In Line Connection Box, Type 77A 550-2674 Pair In Line Connection Box, Type 78A 550-266Excel Line Jack Double AdaptorA Line Jack Adaptor allows two telephones to be connected to oneLine Jack Socket.Features● Standard Design● Right Hand LatchDescriptionPart NumberLine Jack Double Adaptor 10/3A118

Voice Cabling Systems from ExcelExcel Telephone Extension and Line CordsA range of straight extension cords for extending phone, fax ormodem lines. Available in white only, with a choice of BT 6 way plugto 6 way BT socket or as standard line cords wired with a BT 6 wayplug at either end. The 6 way socket used in the extension leadversion will accept both 4 and 6 way plugs.Features● Choice of length● Choice of connector styles● Individually baggedDescriptionPart NumberExtension Lead, Plug to Socket 3 Metre 550-300Extension Lead, Plug to Socket 5 Metre 550-301Extension Lead, Plug to Socket 10 Metre 550-302Extension Lead, Plug to Socket 15 Metre 550-303Line Cord, Plug to Plug 3 Metre 550-304Line Cord, Plug to Plug 5 Metre 550-305Excel Telephone Extension ReelA handy telephone extension reel containing 15 metres of cordterminated with a BT plug, the centre of the reel contains a BT socket.Ideal for temporary extensions to telephone, fax or modemequipment.Features● Flexible extension lead● Robust cable housingDescriptionPart NumberExtension Reel, Plug to Socket 15 Metre 550-310Excel BT Plug to US Socket AdaptorIdeal for modem applications, this adapter allows leads with RJ11 USstyle terminations to be connected to BT style telephone sockets.Features● BT plug to US socketDescriptionPart NumberBT Plug to US Socket Adapter 550-311Telecom Plugs - Pack of 10631A119

Voice Cabling Systems from ExcelExcel Split-RThe Excel SPLIT-R allows you to take advantage of spare capacity in installed 4 paircabling networks. In many such installations no more than two of the cables pairs arebeing used for either data or voice transmission. The SPLIT-R product range has beendesigned to provide users with a quick and easy way of ‘splitting’ the installed pairs toallow multiple devices to operate from one socket.A range of units are available to suit all applications, just match your required outletconfiguration with the descriptions shown in each table below. Each installation ofSPLIT-R units will require a device to be connected at both the patch panel – the ‘cabbox’ – and the work outlet – the ‘desk box’ – these can be purchased in pairs for newinstallations, or as separate units for replacement installations.CABBOXESPart No. 100-814 100-812 100-810DESKBOXESPart No. 100-816 100-813 100-810120

Voice Cabling Systems from ExcelExcel Split-RThe SPLIT-R 100-824 consists of 2 units, the cab box and the deskbox. The cab box enables the connection of 4 standard time breakrecall telephones, and certain digital handsets (please call us toadvise you), to one standard RJ45 CAT5 outlet using standard RJ45patch leads. The desk box has a self adhesive pad to secure it intodesk management and is small enough to fit into a floor box.Features● No need for RJ45 to telephone master adaptors, unlike similarproducts, the SPLIT-R is unique as the desk box has them built in.● Each voice port is presented as a standard LJU socket to enablethe direct connection of telephones, modems or fax's.● Supplied either as a pair ready for instant installation in cabinet andwork area locations, or individuallyDescriptionPart NumberExcel Split-R Pair – 4 RJ45 Voice Ports + 4 LJU Voice Ports 100-824Excel Split-R 4 RJ45 Voice Ports 100-814Excel Split-R 4 LJU Voice Ports 100-816100-814100-816Excel Split-RThe SPLIT-R 100-822 consists of 2 units, the cab box and the deskbox. The cab box enables the connection of 2 standard time breakrecall telephones, and some digital (please call us to advise you), andone 10/100MB LAN connection to one standard RJ45 CAT5 outletusing standard RJ45 patch leads. The desk box has are-useable self adhesive pad to secure it into desk management andis small enough to fit into a floor box.Features● No need for RJ45 to telephone master adaptors, unlike similarproducts, the SPLIT-R is unique as the desk box has them built in● Each voice port is presented as a standard BT telephone socket toenable the direct connection of telephones, modems or fax's.● Supplied either as a pair ready for instant installation in cabinet andwork area locations, or individuallyDescriptionPart NumberExcel Split-R Pair – 1 RJ45 Data Port/2 LJU Voice Ports+ 1 RJ45 Data Port/2RJ45 Voice Ports100-822Excel Split-R 1 RJ45 Data Port/2RJ45 Voice Ports 100-812Excel Split-R Splitter 1 RJ45 Data Port/2 LJU Voice Ports 100-813100-812100-813121

Voice Cabling Systems from ExcelExcel Split-RThe SPLIT-R 100-820 consists of 2 components, the cab box and thedesk box. The cab box enables the connection of two 10/100MB LANconnections to one standard RJ45 CAT5 outlet using standard RJ45patch leads. The desk box has a re-useable self adhesive pad tosecure it into desk management and is small enough to fit into a floorbox and is identical to the cab box.Features100-810● Supplied either as a pair ready for instant installation in cabinet andwork area locations, or individuallyDescriptionPart Number100-820 Excel Split-R Pair - 2 RJ45 Data Ports 100-820Excel Split-R 2 Port RJ45 Data Ports 100-810Excel Connection Boxes – 200 SeriesThe Excel 200 Series accepts standard 237A IDC Connection Strips.Full wire management features are built into the base and the coverprovides ample knockouts for cable entry.Features● 20/30 Pair Capacity UsingStandard Terminal Strips● Cable Tie Fixings● Suits all Terminal Strips● Dimension -160(W) x 145(D) x 55(H)● Supports Protector Strip 51ADescriptionPart NumberExcel 2 Way Connection Box 550-260Excel 2 Way Connection BoxLoaded with 2 x 10 Pair Terminal Strips550-261Excel 3 Way Connection Box 550-262Excel 3 Way Connection BoxLoaded with 2 x 10 Pair Terminal Strips550-263122

Voice Cabling Systems from ExcelExcel Connection Boxes – 250 SeriesA Plastic Enclosure fitted with 5 Way Backmount Frame to allow theinstallation of up to 5 Terminal Strips. The cover is secured by largehead quick release screws.Features● Suits All Terminal Strips● Internal Clearance 70mm● Dimensions 210 x 160 x 90mm● Supplied with 4 Jumper Rings● Supplied with Earth PostDescriptionPart Number5 Way Connection Box, Type 251A 550-264Jumper Ring, Type 37B 550-400Excel Connection Boxes – 300 SeriesA Plastic Enclosure fitted with 10 Way Backmount Frame to allow theinstallation of up to 10 Terminal Strips. The cover is secured by largehead quick release screws. Jumper Rings can be added to provideCable Management.Features● Suits all Terminal Strips● Internal Clearance 90mm● Dimensions 320 x 210 x 120mm● Supplied with Earth PostDescriptionPart Number10 Way Connection Box, Type 301A 550-265Jumper Ring, Type 37B 550-400123

Voice Cabling Systems from ExcelExcel Connection Boxes – 500 SeriesThe Excel Series of Connection Boxes offer increased pair capacitywhile maintaining an industry standard footprint. The stainless steelbackmount frame verticals support 237 Style strips giving a normalcapacity of 340, 690, 1020 and 1600 pairs depending on themodel. The Excel Connection Box Range allows an extra 5 waybackmount to be fitted under the standard verticals increasing thecapacities to a roomy 390, 780 or 1170 pairs. The door opensthrough a 180° for a ease of access, it can be removed entirelyusing quick release hinges and is easily reversed for left-rightopening applications.Features● Industry Standard Footprint● Extra Backmounts IncreaseCapacity● Jumper Rings for Tidy CableManagementDescription Dimensions (WxHxD)mm Part NumberExcel Box Connection 510 (340 Pairs) 300 x 1000 x 130 550-270Excel Box Connection 520 (690 Pairs) 500 x 1000 x 130 550-272Excel Box Connection 530 (1020 Pairs) 750 x 1000 x 130 550-274Excel Distribution Frame – 111BThe Modular construction of the 111B means that any size ofinstallation can be equipped using a standard building block. The111B is compatible with older style frames e.g. 105, 108 to allowextension of existing installations. Single verticals can be joined sideby side for wall mounting or back to back to form a free standingsystem. If height reduction is required, the legs can be removed andthe 111B mounted directly on the floor giving an overall height ofjust 1850mm.Features● British Telecom Approved● Single Vertical● Modular Growth● Light Weight● Easily Transportable● Wall Mounting or Free Standing● 690 Pair CapacityDescription Dimensions (WxHxD)mm Part Number69 Way Distribution Frame 280 x 1850 x 150 (H=2101mm with legs) 111B124

Voice Cabling Systems from ExcelExcel Distribution Frame – 108a/City 80Supplied as a dual distribution frame as standard the 108a framehas the capacity for up to 1380 pairs when using 10 pairtermination strips. The City 80 is an extended version and offersup to 1600 pair capacity. The flexible design allows for mountingframes on the floor with or without the supplied legs – on the wall,or back to back.Features● Dual Vertical● Light Weight● Wall Mounting or Free Standing● Up to 1600 Pair CapacityDescription Dimensions (WxHxD)mm Part NumberExcel 108a Dual Distribution Frame (1380 Pairs) 560 x 2004 x 150 550-278Excel City 80 Distribution Frame (1600 pairs) 570 x 2250 x 150 550-276Excel Sub Rack Termination Strip CarrierThe Sub Rack Strip Carrier is used to mount Terminal Strips in 19"Cabinets. Two styles are available for the 3u, the recessed versionpositions the terminal strips inside the 19" Cabinet profile, the flatversion aligns the strips with the cabinets profiles.Features● 3u Version, 150 Pair Capacity● 4u Version, 180 Pair CapacityDescription3u Sub 3u Sub Rack Flat3u Sub Rack Recessed4u Sub Rack Recessed● Flat or Recessed 3u Version● Suits All Terminal StripsPart Number3USRF3USRR4USRR125

Voice Cabling Systems from ExcelExcel Terminal StripsTerminal Strips are used to join Multipair Telecom and Data Cables.They can be mounted in either 19" Sub Racks, in various sized BoxConnections or Frames. Designation Strips are used to identifyindividual connections or strips.DescriptionPart Number10 Pair Terminal Disconnection Strip, 237A style 550-240Designation Strip 550-241Excel Voice Panel – RJ45 PresentationThe Excel voice panel is a 1u panel which provides a cost effectivemethod of terminating and presenting multipair voice cables. Eachpanel has 25 or 50 RJ45 ports per 1u and an integral rear cablemanagement tray. Each port is numbered and each can be wired withup to 3 pairs.Features● Cost effective● Integral rear cable management● High density design● Cage nut sets included● Upto 3 pairs per RJ45 socket● Lifetime product warranty● 25 year system warrantyavailableDescriptionPart Number1u 3 pair 50 Port RJ45 voice panel, Black 100-4641u 3 pair 25 Port RJ45 voice panel, Black 100-465126
