A <strong>new</strong> <strong>dimension</strong> <strong>in</strong> <strong>water</strong> <strong>management</strong>
Disclaimer<br />
The slides follow<strong>in</strong>g hereafter conta<strong>in</strong> <strong>in</strong>formation that is confidential and proprietary to<br />
Huntsman Corporation. Recipients of this presentation and the <strong>in</strong>formation conta<strong>in</strong>ed here<strong>in</strong><br />
shall not copy or replicate them by any means whatsoever and shall not share or show them<br />
to third parties.<br />
While the <strong>in</strong>formation conta<strong>in</strong>ed here<strong>in</strong> is to the best of our knowledge, <strong>in</strong>formation and belief<br />
accurate at the date of publication, it is the responsibility of recipients to determ<strong>in</strong>e the<br />
applicability or the suitability of such <strong>in</strong>formation for their own particular purpose. Huntsman<br />
Corporation accepts no responsibility for any damages of any nature result<strong>in</strong>g from the use of,<br />
reliance upon, or the misuse of such <strong>in</strong>formation for any purpose.<br />
VYDRO is a registered trademark of Huntsman Corporation or an affiliate thereof <strong>in</strong> one or more, but not all, countries
Why are green roofs <strong>in</strong>stalled ?<br />
Assist with <strong>water</strong> <strong>management</strong>: As it is reta<strong>in</strong><strong>in</strong>g ra<strong>in</strong><strong>water</strong> for plant consumption,<br />
run-off is m<strong>in</strong>imized, which reduces the risk of localized flood<strong>in</strong>g.<br />
Improve a build<strong>in</strong>g s <strong>in</strong>sulat<strong>in</strong>g envelope: The green roof is add<strong>in</strong>g an extra layer of<br />
<strong>in</strong>sulation which boosts the energy efficiency and reduces heat<strong>in</strong>g and cool<strong>in</strong>g costs<br />
up to 5%.<br />
Reduce the impact of urbanization: Plants improve urban air quality by filter<strong>in</strong>g out<br />
pollut<strong>in</strong>g particles that create smog. Accord<strong>in</strong>g to the US <strong>in</strong>dustry association Green<br />
Roofs For Healthy Cities; "One square meter of grass roof can remove up to 2.0kg of<br />
airborne particles every year, depend<strong>in</strong>g on the foliage type."<br />
Decrease the Urban Heat Island Effect (UHIE): The widespread use of heat<br />
absorb<strong>in</strong>g materials like concrete and asphalt make cities up to 10 degrees hotter than<br />
rural areas. Add<strong>in</strong>g more foliage <strong>in</strong>to metropolitan areas reduces this problem.<br />
Improve biodiversity: Green roofs provide a safe refuge for native <strong>in</strong>sect, bird and<br />
animal species that might struggle otherwise to thrive amid a mass of concrete, glass<br />
and asphalt.<br />
Counter urban sprawl: Green roofs help create a more aesthetically pleas<strong>in</strong>g built<br />
environment. A sanctuary away from the hustle and bustle of metropolitan life they are<br />
more visually appeal<strong>in</strong>g and serve as a relax<strong>in</strong>g outdoor space for the people that live,<br />
work or regularly visit a build<strong>in</strong>g. They also reduce noise pollution by dampen<strong>in</strong>g sound<br />
and decreas<strong>in</strong>g the number of hard surfaces available for sound to reflect off.<br />
Reduce build<strong>in</strong>g ma<strong>in</strong>tenance costs: Green roofs dramatically <strong>in</strong>crease a roof s life<br />
expectancy by shield<strong>in</strong>g it from <strong>in</strong>clement weather.
Are there different sorts of green roofs?<br />
There are ma<strong>in</strong>ly 2 types of roof <strong>in</strong>stallations:<br />
Extensive green roofs (eco-roofs) have limited or no access. These are lightweight,<br />
relatively low cost systems which require m<strong>in</strong>imal ma<strong>in</strong>tenance.<br />
Intensive green roofs (sometimes known as high-profile roofs) tend to look like traditional<br />
roof gardens because a much wider variety of plants (<strong>in</strong>clud<strong>in</strong>g trees and shrubs) can be<br />
grown. Generally, <strong>in</strong>tensive roofs require human access for regular upkeep.<br />
Extensive Intensive
What is VYDRO ® foam:<br />
VYDRO ® foam is a polyurethane-based,<br />
lightweight foam with a very high <strong>water</strong><br />
hold<strong>in</strong>g capacity. It is an extremely effective<br />
plant<strong>in</strong>g medium for roof<strong>in</strong>g and hydroponic<br />
projects.
Properties & Benefits<br />
Properties of VYDRO ®<br />
Up to 70% lighter than exist<strong>in</strong>g technologies (30 kg/m³)<br />
Can take up to 30 times its weight <strong>in</strong> <strong>water</strong><br />
Water buffer<strong>in</strong>g capacity of 40 60%<br />
Water dra<strong>in</strong><strong>in</strong>g: 65% still left after 24 hrs<br />
The foam swells 15% after 24 hrs of soak<strong>in</strong>g<br />
Benefits<br />
Easy to handle / <strong>in</strong>stall<br />
Increased roof life<br />
Suitable for old build<strong>in</strong>gs with structural weaker roofs<br />
Ability to rehydrate over multiple grow<strong>in</strong>g cycles<br />
Improved build<strong>in</strong>g <strong>in</strong>sulation, reduc<strong>in</strong>g heat<strong>in</strong>g and cool<strong>in</strong>g costs<br />
by up to 5%.
Determ<strong>in</strong>ation of <strong>water</strong> retention<br />
of VYDRO ® foam<br />
100<br />
90<br />
80<br />
70<br />
60<br />
50<br />
40<br />
30<br />
20<br />
10<br />
0<br />
Water retention after 1hr (l/m2)<br />
L<strong>in</strong>ear (Without load)<br />
L<strong>in</strong>ear (With load 0.5kPa)<br />
Thickness (mm)<br />
10 30 40 60 80 100 120 140
What is the life expectancy of<br />
VYDRO ® foam?<br />
Independent test<strong>in</strong>g <strong>in</strong>stitutes have assessed the bio-degradation nature of<br />
VYDRO ® foams aga<strong>in</strong>st DIN ISO norms.<br />
The results <strong>in</strong>dicate that the foam shows no bio-degradation. Life expectancy of<br />
VYDRO ® foams should be more than 25 years.
How does VYDRO ® foam work?<br />
Due to the physical, <strong>in</strong>ternal<br />
structure of VYDRO ® foam,<br />
<strong>water</strong> molecules can easily<br />
enter its cells but cannot easily<br />
exit it. This means that <strong>water</strong> is<br />
stored <strong>in</strong> the VYDRO ® matrix,<br />
where it can be readily<br />
accessed by plant roots.
Traditional Extensive Green Roof<br />
Extensive Green Roof<br />
Weight 80 110kg/m 2 / slope of m<strong>in</strong>. 3 degrees<br />
(Fully saturated)<br />
How does a typical green roof differ from a VYDRO ® foam green roof?
VYDRO ® Green Roof<br />
VYDRO ® Green Roof<br />
Weight 50 60kg/m 2 / slope of m<strong>in</strong>. 3 degrees<br />
(Fully saturated)
The Build Up<br />
Root resistant foil<br />
PE foil<br />
VYDRO ® substrate<br />
4 cm thick foam matt<br />
Eggshell slabs for <strong>water</strong> <strong>management</strong><br />
Lava stones<br />
Plants<br />
4 cm layer of a blend of different particle sizes<br />
Fully compacted still 15% of cavities<br />
Sedum<br />
Grasses<br />
Other plants
The Build Up<br />
Root resistant foil<br />
Easy cutt<strong>in</strong>g and<br />
<strong>in</strong>stallation<br />
Eggshell slabs
Total View
Substrate Spray<strong>in</strong>g
Sedum, grasses, plants,
F<strong>in</strong>al Look
Thank you for your attention<br />
vydro@huntsman.com<br />
www.thevydroeffect.com
