<strong>The</strong> Ultimate Presentation Catalogue 2006/07<br />
<strong>The</strong> <strong>Conference</strong> <strong>Company</strong><br />
Düsseldorf • London • Mailand<br />
Willstätterstr. 7 · D-40549 Düsseldorf · Germany · Tel. ++49-211-52 76-0 · Fax ++49-211-52 76-100<br />
Internet: www.medium.de · E-Mail: info@medium.de
Visit our website at<br />
www.medium.de<br />
for detailed product<br />
information, a picture<br />
gallery and latest<br />
news.<br />
MEDIUM –<br />
the specialist for presentation technology –<br />
since 1975!<br />
May we take you along on a trip through the whole world of presentation<br />
technology! We are glad to introduce you to a whole range of high-performance<br />
products including a number of true innovations of which only a few<br />
shall be listed here:<br />
● a first class selection of digital projectors of all categories (pages 2-35)<br />
● the ultra-bright Laser Green (page 49)<br />
● the most mobile of all screens: easyfixx comfort (page 75)<br />
● a new electrostatic Flip Chart for mobile use (page 99)<br />
● the first colour copyboard worldwide: Plus M-10 (page 67)<br />
● the multifunctional camera system Casio YC 400 (page 53)<br />
● solutions for modern interactive presentations (pages 45, 50-51)<br />
As one of the top specialist suppliers in the world of presentation<br />
technology, MEDIUM offer the most comprehensive and up-to-date product<br />
range with more than 900 presentation products.<br />
For more than 30 years, the multidistributor MEDIUM have successfully been<br />
selling their products not only in Germany but also in more than 90 export<br />
countries. MEDIUM and the MEDIUM distribution partners are pleased to<br />
provide you with all relevant equipment plus a range of useful accessories<br />
for nearly any presentation requirement.<br />
Take advantage of our full one-stop service:<br />
1. <strong>The</strong> MEDIUM Catalogue: gather all the information you need and<br />
conveniently place your order by fax or mail.<br />
2. Competent consulting: please contact your MEDIUM distribution partner for<br />
competent advice on the appropriate product selection.<br />
3. Product demonstration: the MEDIUM distribution partners will be happy to<br />
demonstrate individual products to you on request.
All Products from A-Z Contents<br />
Accessories Copyboards 69<br />
Accessories Digital Projectors 37–56<br />
Accessories Overhead Projectors 49, 63, 94-97<br />
Active Loudspeakers 45<br />
Anti-theft Protection 48<br />
Avio Projectors 13, 31, 33<br />
BenQ Projectors 20, 21, 23–28, 36<br />
Bluetooth Tablet 45<br />
Brochure Rack 105<br />
Brochure Stand 112<br />
Cables (Projectors) 46, 47<br />
Camera Systems 52–56<br />
Canon Projectors 16, 17, 26–34<br />
Casio Camera System 53<br />
Casio Projectors 9, 25, 28, 29<br />
Ceiling Lift Electrical 42<br />
Ceiling Mounting (for Projectors) 37, 41–43<br />
Colour Copyboard 67<br />
Copyboards 66–69<br />
Copyboard Accessories 69<br />
Copyboard Overview 69<br />
Desktop Cameras 52–56<br />
Desktop Cameras Overview 56<br />
Digital Camera Systems 52–56<br />
Digital Projectors 2–22<br />
Digital Projectors Accessories 37–56<br />
Digital Projectors Overview 23–35<br />
Direct Presenter 72<br />
Display Boards 102, 103<br />
Flat Displays 38–40<br />
Flip Charts 98–100, 106, 107<br />
Flip Chart Accessories 98–100<br />
Flip Chart Electrostatic 99<br />
Fold Screens 80, 81<br />
Furniture 92–97<br />
Hitachi Interactive Presentation 45, 50, 51<br />
Hitachi Projectors 2–5, 23–35, 36<br />
Home Cinema 36, 37<br />
Interactive Board / Panel 50, 51<br />
Laser Pointer 49<br />
LCD Displays 38–40<br />
Lecterns 91<br />
... that’s NEW TOP Design<br />
highlights special<br />
product design<br />
This Catalogue is determined for trade, industry and commerce.<br />
<strong>The</strong> general terms and conditions of sale of the vendor apply.<br />
This Catalogue is subject to technical changes, errors or omissions.<br />
Loudspeakers 45<br />
Mobile Screens 74–81<br />
Mouse Remote Control 44, 45<br />
Multifunctional Board 107<br />
Optoma Projectors 18, 19, 23–35<br />
Overhead Projectors 58–65<br />
Overhead Projection “ABCs“ 64<br />
Overhead Projector<br />
Accessories 49, 63, 94–97<br />
Overview Copyboards 69<br />
Overview Digital Projectors 23–35<br />
Overview Overhead Projectors 64, 65<br />
Panasonic Projectors 14, 15, 25–33<br />
Partition Boards 101<br />
Pin Boards 111<br />
Planning Boards 110<br />
Plasma Displays 39<br />
Plus Projectors 6–8, 23–30<br />
Presentation Aids 44<br />
Presentation Case 102<br />
ProjectionDesign Projector 22, 34<br />
Projection Furniture/Trolleys 92–97<br />
Projector Overview 23–35<br />
Projector Tables 96, 97<br />
Rail System 104–106<br />
Sanyo Projectors 10–12, 23–36<br />
Screens 37, 73–90, 105<br />
Screen Background Information 73<br />
Screen Frame 87<br />
Signal Distribution 46, 47<br />
Slide Projectors 70<br />
Slide Scanner 71<br />
Tables 93–97<br />
Tabletop Screen 74<br />
Transparencies 63<br />
Tripod Screens 78, 79<br />
Trolleys 93–97<br />
TV Cabinet 93<br />
TV Tuner 37, 48<br />
Varioboard 100<br />
Wall Screens 82–90<br />
Whiteboards 106–109<br />
MEDIUM Design<br />
Exklusiv highlights<br />
sophisticated MEDIUM<br />
Design<br />
Digital Projectors . . . . . . . . . . . . . . 2–22<br />
Overview . . . . . . . . . . . . . . 23–35<br />
Home Cinema . . . . . . . . . . . . . . 36–37<br />
Flat Displays + Accessories . . . . . . . . 38–40<br />
Accessories Digital Projectors . . . . . . 41–49<br />
Interactive Presentation . . . . . . . . . 50–51<br />
Digital Camera Systems . . . . . . . . . . 52–56<br />
Overhead Projectors . . . . . . . . . . . 57–65<br />
Copyboards . . . . . . . . . . . . . . . . . . . . 66–69<br />
Slide Projectors . . . . . . . . . . . . . . . . . 70–71<br />
Direct Presenter . . . . . . . . . . . . . . . . 72<br />
Screens . . . . . . . . . . . . . . . . . . . . 73–90<br />
Presentation Furniture . . . . . . . . . . . . 91–97<br />
Flip Charts . . . . . . . . . . . . . . . . . . . 98–100<br />
Partition Boards. . . . . . . . . . . . . . . . 101–103<br />
Rail System . . . . . . . . . . . . . . . 104–106<br />
Whiteboards . . . . . . . . . . . . . . 107–109<br />
Planning/Pin Boards . . . . . . . . . . . . 110–111<br />
Accessories . . . . . . . . . . . . . . . . . . . . 112<br />
1
Digital Projectors<br />
2<br />
HITACHI CP-S240/CP-X250/CP-X255 –<br />
the portable business projectors<br />
Highlights<br />
● Easy maintenance, lamp and filter also<br />
accessible when ceiling-mounted<br />
● Individual start image can be protected<br />
against overwriting with a PIN code<br />
● Expanded anti-theft protection, security<br />
bar for securely tying up the projector as<br />
theft protection<br />
● Remote maintenance/control via<br />
IP networks (CP-X255)<br />
Highlights EDX-8250<br />
(school version of CP-X250)<br />
● Easy maintenance, lamp and filter also<br />
accessible when ceiling-mounted<br />
● Individual start image can be protected<br />
against overwriting with a PIN code<br />
● Expanded anti-theft protection, security<br />
bar for securely tying up the projector as<br />
theft protection<br />
● 36 Months lamp warranty on the lamp<br />
supplied with the projector<br />
● 4,000 Hours (approx.) lamp life,<br />
eco mode is standard factory setting<br />
HITACHI CP-S240<br />
Resolution: SVGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 2.8 kg<br />
Code No. 1000240 price on request<br />
HITACHI CP-X250<br />
Resolution: XGA<br />
Technology : LCD (Psi)<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 2.8 kg<br />
Code No. 1000X250 price on request<br />
HITACHI CP-X255<br />
Resolution: XGA<br />
Technology : LCD (Psi)<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 2.8 kg<br />
Code No. 1000255 price on request<br />
HITACHI EDX-8250<br />
Resolution: XGA<br />
Technology : LCD (Psi)<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 2.8 kg<br />
Code No. 10008250-S price on request<br />
Accessories<br />
For detailed information on technical specifications refer to pages 23, 26 and 27.<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Mobile screens pages 74–81<br />
● Wall screens pages 82–83<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Further ceiling mounts pages 37, 41–43<br />
Image Size Chart<br />
HITACHI CP-S240/CP-X250/CP-X255<br />
Projection distance approx. Image width approx.<br />
0.90 – 1.10 m 0.61 m<br />
2.30 – 2.80 m 1.50 m<br />
3.00 – 3.70 m 2.00 m<br />
9.30 – 11.30 m 6.10 m
HITACHI CP-X1200WA/CP-X1250W/CP-SX1350W –<br />
for rentals, events and fixed installation<br />
Highlights<br />
● Bayonet fitting for easy change of lenses<br />
● Standard zoom lens included in delivery<br />
standard<br />
● Motorised zoom lens for flexible<br />
installation<br />
● Motorised lens-shift function for<br />
distortion-free projection<br />
● Flicker-free video display thanks to<br />
progressive signal scanning<br />
● RJ-45-network connection for remote<br />
maintenance/remote control via<br />
IP networks, free of charge control<br />
software is provided for download<br />
by the supplier<br />
● Interface panel that meets all your<br />
requirements<br />
● Remote-ID: with one remote control you<br />
can control up to 3 projectors individually<br />
HITACHI CP-X1200WA<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 3,500 ANSI lumens<br />
Weight approx.: 7.7 kg<br />
Code No. 10001200 price on request<br />
HITACHI CP-X1250W<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 4,500 ANSI lumens<br />
Weight approx.: 7.7 kg<br />
Code No. 10001250 price on request<br />
HITACHI CP-SX1350W<br />
Resolution: SXGA+ (1,400x1,050)<br />
Technology: LCD (Psi)<br />
Light output approx.: 3,500 ANSI lumens<br />
Weight approx.: 7.7 kg<br />
Code No. 10001350 price on request<br />
Wide-angle Wide-angle Standard Tele Ultratele<br />
lens zoom lens zoom lens zoom lens zoom lens<br />
FL-501 SL-502 NL-500 LL-503 LL-504<br />
Throw-Ratio 0.8:1 1.1 – 1.5:1 1.5 – 2.3:1 2.3 – 4.0:1 4.0 – 7.2:1<br />
Distance 0.9 0– 3.70 0.90 – 15.60 0.90 – 13.90 1.80 – 30.70 3.10 – 57.10<br />
Image width 1.13 – 4.63 0.60 – 14.18 0.39 – 9.30 0.45 – 13.35 0.43 – 14.28<br />
Diagonal 1.50 – 5.80 1.00 – 12.70 0.76 – 7.60 1.00 – 12.70 1.00 – 12.70<br />
Projection on-axis off-axis off-axis off-axis off-axis<br />
MEDIUM Code No. 1905-501 1905-502 delivery std. 1905-503 1905-504<br />
Accessories<br />
For detailed information on technical specifications refer to pages 31, 32 and 35.<br />
Transport Case<br />
for both projector and accessories,<br />
with scratch-resistant silver-grey plastic<br />
surface and aluminium fittings<br />
Code No. 1186-29<br />
Trolley Upgrade Set for Transport Case<br />
with 2 wheels and a 3-part telescopic handle<br />
(up to 98 cm)<br />
Code No. 11850-0<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Stationary screens pages 82–90<br />
● Projection furniture pages 96–97<br />
● Ultrabright Laser Green page 49<br />
● Further ceiling mounts pages 37, 41–43<br />
Digital Projectors<br />
3
Digital Projectors<br />
4<br />
HITACHI CP-X260/CP-X265/CP-X268 – strong light output,<br />
IP networks, WLAN and PC-free presentations<br />
Highlights<br />
● Quick-on function: maximum brightness<br />
straight after turning on the projector<br />
● Direct-off: the projector can immediately<br />
be disconnected from the net<br />
● Easy maintenance, lamp and filter also<br />
accessible when ceiling-mounted<br />
● Expanded anti-theft protection, security<br />
bar for securely tying up the projector as<br />
theft protection<br />
● Image transmission, remote control and<br />
remote maintenance via IP networks<br />
(CP-X265, CP-X268)<br />
● W-LAN transmission for cable-free<br />
presentations (CP-X268)<br />
● PC-free presentation from SD-card or<br />
USB flash memory (CP-X268)<br />
Image Size Chart HITACHI CP-X260/265/268<br />
Projection distance approx. Image width approx.<br />
1.00 – 1.20 m 0.61 m<br />
2.60 – 2.90 m 1.50 m<br />
3.40 – 3.80 m 2.00 m<br />
9.70 – 10.00 m 5.70 m<br />
HITACHI CP-X260<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 2.8 kg<br />
Code No. 1000260 price on request<br />
HITACHI CP-X265<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 2.8 kg<br />
Code No. 1000265 price on request<br />
HITACHI CP-X268<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 2.8 kg<br />
Code No. 1000268 price on request<br />
Accessories<br />
For detailed information on technical specifications refer to page 28.<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
ill. similar<br />
● Mobile screens pages 74–81<br />
● Wall screens pages 82–83<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Mouse remote controls pages 44–45<br />
● Further ceiling mounts pages 37, 41–43
HITACHI CP-RS56/CP-RX61 –<br />
functional projection technology at a feel-good price<br />
Highlights<br />
● Variable projection size thanks to manual<br />
zoom lens<br />
● Fully-equipped connector panel<br />
with 2x computer inputs,<br />
1x monitor output<br />
● Lightweight, only 2.2 kg<br />
● Quiet, only 33 dB in eco mode<br />
● PIN code anti-theft protection<br />
Image Size Chart HITACHI CP-RS56<br />
Projection distance approx. Image width approx.<br />
1.30 – 1.60 m 0.81 m<br />
2.50 – 3.00 m 1.50 m<br />
3.30 – 3.90 m 2.00 m<br />
10.00 – 12.03 m 6.10 m<br />
HITACHI CP-RS56<br />
Resolution: SVGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 1,600 ANSI lumens<br />
Weight approx.: 2.2 kg<br />
Code No. 1000RS56 price on request<br />
HITACHI CP-RX61<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 1,600 ANSI lumens<br />
Weight approx.: 2.2 kg<br />
Code No. 1000RX61 price on request<br />
Image Size Chart HITACHI CP-RX61<br />
Projection distance approx. Image width approx.<br />
1.20 – 1.40 m 0.81 m<br />
2.20 – 2.70 m 1.50 m<br />
3.00 – 3.60 m 2.00 m<br />
9.00 – 10.90 m 6.10 m<br />
Accessories<br />
For detailed information on technical specifications refer to pages 23 and 24.<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Projector/Laptop Bag<br />
with integrated trolley function, for laptop<br />
and projector up to H/W/D: 8/33/26 cm<br />
Code No. 1185-09<br />
Further Accessories<br />
● Mobile screens pages 74–81<br />
● Wall screens pages 82–83<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Mouse remote controls pages 44–45<br />
● Further ceiling mounts pages 37, 41–43<br />
ill. similar<br />
ill. similar<br />
Digital Projectors<br />
5
Digital Projectors<br />
6<br />
PLUS V-339 –<br />
perfect colours in tiny design for mobile presenters<br />
Highlights<br />
● Particularly small: no bigger than A5<br />
size<br />
● Ultra-light: weighs merely 1.3 kg<br />
● Patented 2-colour-wheel system for best<br />
colour output in any presentation<br />
● Unplug-and-go function: unplug, stow<br />
away, ready-to-go. <strong>The</strong> fan cools down the<br />
projector without mains current.<br />
● Lens cover with swivel mechanism for<br />
ease of use<br />
● Presentation timer for controlling the<br />
length of the presentation<br />
● Security password preventing<br />
unauthorized usage<br />
● Front ventilation: no bothersome air flow<br />
disturbing the audience<br />
Plus V-339<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 1,300 ANSI lumens<br />
Weight approx.: 1.3 kg<br />
Code No. 1000V339 price on request<br />
Only available in Germany and Benelux.<br />
For detailed information on technical specifications refer to page 24.<br />
Further Accessories<br />
● Mobile screens pages 74–81<br />
● Wall screens pages 82–83<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Mouse remote controls pages 44–45<br />
Image Size Chart Plus V-339<br />
Projection distance approx. Image width approx.<br />
1.20 m 0.63 m<br />
1.91 – 2.30 m 1.00 m<br />
3.82 – 4.60 m 2.00 m<br />
5.73 – 6.90 m 3.00 m
PLUS U5h Series –<br />
the compact all-rounder<br />
Highlights<br />
● Integrated wide angle lens for large<br />
images at a short distance (U5-632h)<br />
● Front ventilation: no bothersome air flow<br />
disturbing the audience<br />
● 2,000:1 contrast for enhanced black<br />
performance<br />
● Presentation timer for controlling the<br />
length of the presentation<br />
● Security password preventing<br />
unauthorized usage<br />
● IR remote control with laser pointer and<br />
mouse remote control (does not apply to<br />
U5-532h)<br />
Only available in Germany and Benelux.<br />
Image Size Chart Plus U5-732h<br />
Projection distance approx. Image width approx.<br />
1.2 m 0.65 m<br />
3.70 – 4.48 m 2.00 m<br />
5.55 – 6.72 m 3.00 m<br />
9.25 – 11.20 m 5.00 m<br />
PLUS U5-532h<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 2.0 kg<br />
Code No. 1000U5532H price on request<br />
PLUS U5-632h<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 2,300 ANSI lumens<br />
Weight approx.: 2.0 kg<br />
Code No. 1000U5632H price on request<br />
PLUS U5-732h<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 2.1 kg<br />
Code No. 1000U5732H price on request<br />
Image Size Chart Plus U5-632h<br />
Projection distance approx. Image width approx.<br />
1.2 m 0.93 m<br />
2.58 – 3.12 m 2.00 m<br />
3.87 – 4.68 m 3.00 m<br />
6.45 – 7.80 m 5.00 m<br />
Accessories<br />
For detailed information on technical specifications refer to pages 25 and 26.<br />
Projector/Laptop Bag<br />
with integrated trolley function, for laptop<br />
and projector up to H/W/D: 8/33/26 cm<br />
Code No. 1185-09<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Mobile screens pages 74–81<br />
● Wall screens pages 82–83<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Mouse remote controls pages 44–45<br />
● Further ceiling mounts pages 37, 41–43<br />
Image Size Chart Plus U5-532h<br />
Projection distance approx. Image width approx.<br />
1.2 m 0.67 m<br />
3.60 – 4.34 m 2.00 m<br />
5.40 – 6.51 m 3.00 m<br />
9.00 – 10.85 m 5.00 m<br />
Digital Projectors<br />
7
Digital Projectors<br />
8<br />
PLUS U7SF Series –<br />
ultra-bright, compact and rich in features<br />
Highlights<br />
● DVI-I input for lossless transmission of<br />
analogue and digital signals<br />
● 2,000:1 Contrast for enhanced black<br />
performance<br />
● Integrated wide angle lens for large<br />
images at a short distance<br />
● Presentation timer for controlling the<br />
length of the presentation<br />
● Security password preventing<br />
unauthorized usage<br />
● Easy lamp replacement even when<br />
ceiling-mounted<br />
● CompactFlash TM card slot (only U7-137SF)<br />
for:<br />
– WLAN presentations<br />
–Control of projector in the network via<br />
telnet-protocol<br />
–PC-free presentations of image files and<br />
Power Point presentations<br />
● USB slot for playing back data from a USB<br />
stick (only U7-137SF)<br />
● Component output for external monitor<br />
(only U7-137SF)<br />
Only available in Germany and Benelux.<br />
Image Size Chart Plus U7-137SF/132hSF/132SF<br />
Projection distance approx. Image width approx.<br />
1.2 m 0.79 m<br />
3.04 – 3.56 m 2.00 m<br />
4.56 – 5.34 m 3.00 m<br />
9.12 – 10.68 m 6.00 m<br />
PLUS U7-137SF<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 3,500 ANSI lumens<br />
Weight approx.: 3.1 kg<br />
Code No. 1000U7137SF price on request<br />
PLUS U7-132hSF<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 3,500 ANSI lumens<br />
Weight approx.: 3.0 kg<br />
Code No. 1000U7132hSF price on request<br />
PLUS U7-132SF<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 3,000 ANSI lumens<br />
Weight approx.: 3.0 kg<br />
Code No. 1000U7132SF price on request<br />
Accessories<br />
Transport Case<br />
available on request<br />
For detailed information on technical specifications refer to pages 29 and 30.<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Screens pages 73–90<br />
● Presentation furniture pages 96–97<br />
● Ultra-bright Laser Green page 49<br />
● Mouse remote controls pages 44–45<br />
● Further ceiling mounts pages 37, 41–43
XJ-360<br />
Highlights XJ-360<br />
● 2xZoom lens, extremely large<br />
focusing range for the image size<br />
● Monitor output for connection of a<br />
control monitor<br />
● Ceiling mounting possible<br />
Highlights XJ-460/XJ-560<br />
● 2x Motorised zoom lens for flexible<br />
positioning of the projector<br />
● Auto focus for sharp images<br />
● Automatic vertical and horizontal<br />
keystone correction for an optimal image<br />
geometry<br />
● Direct power-off, no time wasted for<br />
waiting, integrated rechargeable battery<br />
enables switching off and stowing away<br />
the projector straight after the<br />
presentation<br />
● Ceiling mounting possible<br />
Image Size Chart CASIO XJ-360/XJ-460/XJ-560<br />
Projection distance approx. Image width approx.<br />
0.80 ~ 1.70 m 0.60 m<br />
2.10 ~ 4.20 m 1.50 m<br />
2.80 ~ 5.60 m 2.00 m<br />
8.00 ~ 16.00 m 5.70 m<br />
(auto focus + auto keystone only up to a max.<br />
distance of 6.10 m)<br />
XJ-460/XJ-560<br />
CASIO XJ-360/XJ-460/XJ-560 –<br />
precious design with unique 2x zoom<br />
CASIO XJ-360<br />
Resolution: XGA<br />
Technology: DLP<br />
Light output approx.: 2,200 ANSI lumens<br />
Weight approx.: 1.8 kg<br />
Code No. 1000XJ360 price on request<br />
CASIO XJ-460<br />
Resolution: XGA<br />
Technology: DLP<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 2.7 kg<br />
Code No. 1000XJ460 price on request<br />
CASIO XJ-560<br />
Resolution: XGA<br />
Technology: DLP<br />
Light output approx.: 3,000 ANSI lumens<br />
Weight approx.: 2.7 kg<br />
Code No. 1000XJ560 price on request<br />
Only available in selected countries.<br />
Accessories<br />
For detailed information on technical specifications refer to pages 25, 28 and 29.<br />
Document Camera CASIO YC-400<br />
(see page 53)<br />
Code No. 190YC400 price on request<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Projector/Laptop Bag<br />
with integrated trolley function, for laptop<br />
and projector up to H/W/D: 8/33/26 cm<br />
Code No. 1185-09<br />
Further Accessories<br />
● Design projection trolley Multistage<br />
page 96<br />
● Mouse remote controls pages 44–45<br />
● Ultra-bright Laser Green page 49<br />
● Wall screens pages 82–90<br />
● Mobile screens pages 74–81<br />
● Further ceiling mounts<br />
pages 37, 41–43<br />
Digital Projectors<br />
9
Digital Projectors<br />
10<br />
SANYO PLC-XP57L/XP56/XP51 –<br />
network-compatible, super-bright<br />
multimedia professional<br />
Highlights<br />
● DVI-D input (with HDCP) for lossless transmission<br />
of analogue and digital signals<br />
● Optical lens-shift function for optimal<br />
image quality even with keystone effect<br />
● Digital horizontal and vertical keystone<br />
correction<br />
● 4 Optional interchangeable lenses with<br />
bayonet fitting for a quick change<br />
● Optional network box for remote<br />
maintenance and control of the projectors<br />
and transmission of image contents via<br />
the network<br />
● Ideal for rental services:<br />
projector can also be supplied without<br />
standard lens<br />
(XP57L generally without standard lens)<br />
● Appropriate for 24 hours/7 days a week<br />
non-stop operation (only XP57L) with<br />
optional service package (available upon<br />
request)<br />
For further powerful SANYO projectors refer<br />
to pages 33–35.<br />
Image Size Chart PLC-XP56/ XP51 with standard lens<br />
Projection distance approx. Image width approx.<br />
3.40 – 4.60 m 2.00 m<br />
SANYO PLC-XP57L (without lens)<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 5,500 ANSI lumens<br />
Weight approx.: 9.2 kg<br />
Code No. 1000XP57L price on request<br />
SANYO PLC-XP56<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 5,000 ANSI lumens<br />
Weight approx.: 9.2 kg<br />
Code No. 1000XP56 price on request<br />
SANYO PLC-XP51<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 4,000 ANSI lumens<br />
Weight approx.: 8.7 kg<br />
Code No. 1000XP51 price on request<br />
5.10 – 6.90 m 3.00 m<br />
8.50 – 11.50 m 5.00 m<br />
15.30 – 20.70 m 9.00 m Image size charts for interchangeable<br />
lenses are available upon request.<br />
Accessories<br />
For detailed information on technical specifications refer to pages 32 and 33.<br />
Network Manager (POA-PN02)<br />
Code No. 1909-NW02<br />
Wide-angle Lens<br />
f= 22.3 mm (LNS-W32)<br />
Throw ratio: 0.8:1<br />
Code No. 1909-30A<br />
Wide-angle Zoom Lens<br />
f= 34.3–48 mm (LNS-W31A)<br />
Throw ratio: 1.3–1.8:1<br />
Code No. 19082-43E<br />
Tele-zoom Lens<br />
f= 63.5–111.5 mm (LNS-T31A)<br />
Throw ratio: 2.4–4.3:1<br />
Code No. 19082-63E<br />
Super Tele-zoom Lens<br />
f= 112–155 mm (LNS-T32)<br />
Throw ratio: 4.2–6.0:1<br />
Code No. 19082-T32<br />
Transport Case<br />
for PLC-XP57L/XP56/XP51 with standard<br />
lens;<br />
for projector and accessories, with scratchresistant<br />
silver-grey plastic surface and<br />
aluminium fittings<br />
H/W/D: approx. 37.5/60/21.2 cm<br />
Weight: approx. 6.6 kg<br />
Code No. 1186-02<br />
Trolley Upgrade Set for Transport Case<br />
with 2 wheels and 3-part telescopic handle<br />
(up to a max. of 98 cm)<br />
Code No. 11850-0<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● can be found on pages 41–56, 82–90<br />
● further ceiling mounts pages 37, 41–43
SANYO PLC-XF60A/PLC-EF60A –<br />
high-end performance in light output and features<br />
Highlights<br />
● Optical lens-shift function horizontal and<br />
vertical<br />
● 2 Lamp system for safety in case of a lamp<br />
failure<br />
● 13 Optional interchangeable lenses with<br />
one-touch closure<br />
● 6 Optional connection boards<br />
● Lens memory function<br />
(only with lenses LNS-W04/LNS-W05)<br />
● Mechanical shutter to avoid light<br />
remaining<br />
● Radio remote control for best possible<br />
freedom of movement<br />
● Optional long-life lamp with lamp life of<br />
10,000 hours<br />
● Optional boards for “warping” (digital<br />
correction of the image geometry on<br />
curved projection surfaces) and “edge<br />
blending“ (for panoramic projections)<br />
● Exemplary safety: PIN code lock, key lock<br />
and optional USB lock to prevent<br />
unauthorized usage<br />
SANYO PLC-XF60A<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 6,500 ANSI lumens<br />
Weight approx.: 25 kg<br />
Code No. 1000XF60A price on request<br />
SANYO PLC-EF60A<br />
Resolution: SXGA+<br />
Technology: LCD (Psi)<br />
Light output approx.: 5,800 ANSI lumens<br />
Weight approx.: 25 kg<br />
Code No. 1000EF60A price on request<br />
All projectors are supplied without lenses.<br />
Image size charts for interchangeable lenses<br />
are available upon request.<br />
Accessories<br />
For detailed information on technical specifications refer to pages 33 and 35.<br />
Smoke- and Dust-Resistant Box<br />
Code No. 1909-RST<br />
Interface boards and interchangeable<br />
lenses are available upon request.<br />
Further Accessories<br />
● Stationary screens pages 82–90<br />
● Ultra-bright Laser Green page 49<br />
● Mouse remote controls pages 44–45<br />
Digital Projectors<br />
11
Digital Projectors<br />
12<br />
SANYO PLC-XU86/XU83 –<br />
for network or PC-free presentations<br />
Highlights<br />
● DVI-I input for top transmission quality<br />
● Board mode: ideal for projections on green<br />
boards in schools<br />
● Key lock function and logo PIN code<br />
protection against unauthorized usage of<br />
the projector<br />
● Automatic vertical keystone correction<br />
● 2nd PC input to be used as monitor output<br />
● Extremely quiet fan (29 dB in eco mode)<br />
● Direct power on/off – no loss of time,<br />
projector can immediately be turned off<br />
without cool-down time<br />
● Integrated LAN connection (RJ-45)<br />
● USB WLAN key for WLAN presentations<br />
with moderator function is included in<br />
delivery standard<br />
● PC-free presentations possible with a<br />
number of standard USB sticks<br />
Image Size Chart SANYO PLC-XU86<br />
Projection distance approx. Image width approx.<br />
1.23 – 1.93 m 1.00 m<br />
2.46 – 3.86 m 2.00 m<br />
4.92 – 7.72 m 4.00 m<br />
7.38 – 11.58 m 6.00 m<br />
SANYO PLC-XU86<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 2.6 kg<br />
Code No. 1000XU86 price on request<br />
SANYO PLC-XU83<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 2.6 kg<br />
Code No. 1000XU83 price on request<br />
Further SANYO projectors can be found in the<br />
overview charts on pages 23–35.<br />
Image Size Chart SANYO PLC-XU83<br />
Projection distance approx. Image width approx.<br />
1.44 – 2.25 m 1.00 m<br />
2.88 – 4.50 m 2.00 m<br />
5.76 – 9.00 m 4.00 m<br />
8.64 – 13.50 m 6.00 m<br />
Accessories<br />
For detailed information on technical specifications refer to pages 26 and 27.<br />
Projector/Laptop Bag<br />
with integrated trolley function, for laptop<br />
and projector up to H/W/D: 8/33/26 cm<br />
Code No. 1185-09<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Further ceiling mounts pages 37, 41–43<br />
● Screens pages 74–90<br />
● Presentation furniture pages 96–97
AVIO iP-25, iP-55, iP-750 –<br />
allow you to project virtually anything!<br />
Highlights<br />
AVIO iP-55<br />
● Versatile fields of application<br />
–asdirect presenter (print media,<br />
objects, transparencies)<br />
–asscanner, data and video projector or<br />
whiteboard (a comment can be written<br />
into the presentation over the PC)<br />
● Integrated digital camera with 2 million<br />
pixels and 6 images p. sec. for highest<br />
resolution and rapid image formation<br />
● A4 scanning surface (216 x 288 mm),<br />
projects nearly an entire A4 size page<br />
● Digital image rotation for display of<br />
portrait and landscape format<br />
● Integrated frame buffer stores up to 32<br />
pages for flexible working<br />
● USB output for copying the image memory<br />
onto a connected PC<br />
● Overlay function allows writing notes<br />
directly into the projected image<br />
● IR remote control with graphical pointer<br />
Only available in selected countries.<br />
Image Size Chart AVIO iP-25<br />
Projection distance approx. Image width approx.<br />
1.50 ~ 1.80 m 0.80 m<br />
2.80 ~ 3.30 m 1.50 m<br />
3.70 ~ 4.40 m 2.00 m<br />
9.50 ~ 11.30 m 5.10 m<br />
AVIO iP-25<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 5.6 kg<br />
Code No. 1000IP25 price on request<br />
AVIO iP-55<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 3,000 ANSI lumens<br />
Weight approx.: 7.3 kg<br />
Code No. 1000IP55 price on request<br />
AVIO iP-755<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 4,500 ANSI lumens<br />
Weight approx.: 8.5 kg<br />
Code No. 1000IP750 price on request<br />
Image Size Chart AVIO iP-55<br />
Projection distance approx. Image width approx.<br />
1.40 ~ 1.80 m 0.80 m<br />
2.60 ~ 3.40 m 1.50 m<br />
3.50~ 4.50 m 2.00 m<br />
10.70 ~ 13.70 m 6.10 m<br />
Accessories<br />
For detailed information on technical specifications refer to pages 31 and 33.<br />
Transport Case<br />
for AVIO projector and accessories, made of<br />
scratch-resistant silver-grey plastic<br />
with aluminium fittings<br />
iP-25 Code No. 1186-80<br />
iP-55 Code No. 1186-81<br />
Trolley Upgrade Set for Transport Case<br />
with 2 wheels and 3-part telescopic handle<br />
(up to 98 cm)<br />
Code No. 11850-0<br />
Further Accessories<br />
● Stationary screens pages 82–90<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
Image Size Chart AVIO iP-750<br />
AVIO iP-25<br />
AVIO iP-750<br />
Projection distance approx. Image width approx.<br />
1.40 ~ 1.70 m 0.70 m<br />
2.90 ~ 3.70 m 1.50 m<br />
3.90 ~ 4.90 m 2.00 m<br />
10.20 ~ 12.90 m 5.30 m<br />
Digital Projectors<br />
13
Digital Projectors<br />
14<br />
Panasonic PT-D3500E and PT-D5500E/EL –<br />
the powerhouses for non-stop operation<br />
Highlights<br />
● Non-stop operation: projectors designed<br />
for 24-hours, 7-days-a-week operation<br />
● Network compatible: projectors can be<br />
controlled via webbrowser<br />
● Remote control with mouse function<br />
● Exceptionally quiet at only 29 dB thanks to<br />
a unique cooling system (PT-D5500E)<br />
● Optional lenses with bayonet fitting for<br />
instant change<br />
● Horizontal lens shift: vertical motorized<br />
● 6 Colour individual correction for<br />
achieving perfect images<br />
● 2 Lamp system for more security in case of<br />
a lamp failure (PT-D5500E/EL)<br />
● Fully-equipped connector panel:<br />
2 RGB inputs with 1x 5 BNC inputs<br />
● Optional: 4 further motorzoom/focus<br />
lenses and 1 lens with fixed focal length<br />
● Ideal for rental services: PT-D5500EL is<br />
supplied without standard lens<br />
● 3 Years warranty<br />
Panasonic PT-D3500E<br />
Resolution: XGA<br />
Technology: DLP<br />
Light output approx.: 3,500 ANSI lumens<br />
Weight approx.: 7.9 kg<br />
Code No. 1000PTD3500 price on request<br />
Panasonic PT-D5500E/EL<br />
Resolution: XGA<br />
Technology: DLP<br />
Light output approx.: 5,000 ANSI lumens<br />
Weight approx.: 13.7 kg<br />
Code No. 1000PTD5500 price on request<br />
Code No. 1000PTD5500-L price on request<br />
Image Size Chart PT-D3500 and PT-D5500E<br />
Projection distance approx. Image width approx.<br />
3.60 – 5.00 m 2.00 m<br />
5.40 – 7.50 m 3.00 m<br />
7.20 – 9.50 m 4.00 m<br />
9.00 – 12.00 m 5.00 m<br />
Accessories<br />
For detailed information on technical specifications refer to pages 32 and 33.<br />
Wide-angle Lens (ET-DLE050)<br />
Throw ratio: 0.8:1<br />
Code No. 1906-24<br />
Wide-angle Lens (ET-DLE100)<br />
Throw ratio: 1.3-1.8:1<br />
Code No. 1906-17<br />
Wide-angle Lens (ET-DLE200)<br />
Throw ratio: 2.5-4.0:1<br />
Code No. 1906-18<br />
Wide-angle Lens (ET-DLE300)<br />
Throw ratio: 3.7-5.7:1<br />
Code No. 1906-19<br />
Wide-angle Lens (ET-DLE400)<br />
Throw ratio: 5.7-8.0:1<br />
Code No. 1906-23<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
PT-D5500E/EL<br />
● Stationary screens pages 82–90<br />
● Presentation furniture pages 96–97<br />
● Ultra-bright Laser Green page 49<br />
● Further ceiling mounts pages 37, 41–43
Panasonic PT-LB50NTE/PT-LB55NTE/PT-LB60NTE –<br />
convenient wireless transmission of image and sound<br />
Highlights<br />
● Daylight View Technology 2, enhances<br />
colours in brighter rooms and improves<br />
the contrast under daylight conditions<br />
● Exceptionally low operating noise up to<br />
30 dB in eco mode<br />
● Highspeed WLAN for wireless<br />
transmission of image and sound (IEEE<br />
802.11b/g)<br />
● Safety thanks to WLAN-coding<br />
● Index window: for monitoring up to 16 PCs<br />
● Quick-start function: the projection can<br />
begin in no more than 2 seconds<br />
● Lamp-protection switch:<br />
automatic cool-down, simply unplug and<br />
go<br />
● Fully-equipped connector panel with<br />
2x computer input, 1x monitor output<br />
● PIN code anti-theft protection<br />
● Eco mode: reduces operating costs<br />
● 3,000 Hours lamp life in<br />
eco mode<br />
● 3 Years warranty<br />
Image Size Chart Panasonic<br />
PT-LB50NTE/55NTE/60NTE<br />
Panasonic PT-LB50NTE<br />
Projection distance approx. Image width approx.<br />
2.60 – 3.00 m 2.00 m<br />
3.90 – 4.50 m 3.00 m<br />
5.20 – 4.00 m 4.00 m<br />
6.50 – 7.50 m 5.00 m<br />
Panasonic PT-LB50NTE<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 1.9 kg<br />
Code No. 1000LB50NTE price on request<br />
Panasonic PT-LB55NTE<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 2.6 kg<br />
Code No. 1000LB55NTE price on request<br />
Panasonic PT-LB60NTE<br />
Resolution: XGA<br />
Technology: LCD (Psi)<br />
Light output approx.: 3,200 ANSI lumens<br />
Weight approx.: 2.6 kg<br />
Code No. 1000LB60NTE price on request<br />
without Daylight View2:<br />
fading colours at bright daylight<br />
Accessories<br />
For detailed information on technical specifications refer to pages 25, 27 and 30.<br />
Projector/Laptop Bag<br />
with integrated trolley function, for laptop<br />
and projector up to H/W/D: 8/33/26 cm<br />
Code No. 1185-09<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Mobile screens pages 74–81<br />
● Presentation furniture pages 96–97<br />
● Laser Pointer page 49<br />
● Further ceiling mounts pages 37, 41–43<br />
Seiten 37, 41–43<br />
with Daylight View2:<br />
brilliant colours even at bright daylight<br />
Digital Projectors<br />
15
Digital Projectors<br />
16<br />
Canon LCOS XEED Series –<br />
perfect projections in every detail<br />
Highlights<br />
● LCOS technology for virtually grid-free,<br />
brilliant images<br />
● SXGA+ resolution for sharp display of<br />
even finest details (does not apply to<br />
X600)<br />
● Motorzoom with extreme zoom area (x 1.7)<br />
for flexible usage<br />
● DVI input with HDCP compatibility<br />
● HDready for perfect display of HDTV<br />
signals (does not apply to X600)<br />
● High contrast: 2,000:1 (SX60, home<br />
cinema mode) and 1,000:1 (SX6, X600)<br />
● Ease of use: auto input, autofocus, auto<br />
keystone correction (vertical), auto screen<br />
colour correction<br />
● Whisper quiet with 26 dBA (SX60, home<br />
cinema mode) or 32 dBA (silent mode SX6,<br />
X600)<br />
Canon XEED SX6<br />
Resolution : SXGA+<br />
Technology : LCOS<br />
Light output approx.: 3,500 ANSI lumens<br />
Weight approx.: 4.6 kg<br />
Code No. 1000SX6 price on request<br />
Canon XEED SX60<br />
Resolution : SXGA+<br />
Technology : LCOS<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 4.6 kg<br />
Code No. 1000SX60 price on request<br />
Canon XEED X600<br />
Resolution : XGA<br />
Technology : LCOS<br />
Light output approx.: 3,500 ANSI lumens<br />
Weight approx.: 4.6 kg<br />
Code No. 1000X600 price on request<br />
Accessories<br />
For detailed information on technical specifications refer to pages 31 and 34.<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Screens pages 74–90<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Mouse remote controls pages 44–45<br />
● Further ceiling mounts pages 37, 41–43<br />
Canon XEED SX6 and SX60<br />
available approx. as of May 2006<br />
Canon XEED SX600<br />
available approx. as of June 2006<br />
Image Size Chart Canon XEED SX6/SX60/X600<br />
Projection distance approx. Image width approx.<br />
1.20 – 2.00 m 0.81 m<br />
3.00 – 4.90 m 2.03 m<br />
4.50 – 7.40 m 3.05 m<br />
8.90 m 6.10 m
Canon LV-7255/LV-7250/LV-X6 Series –<br />
the silent allround-talents<br />
Highlights<br />
● Extreme zoom area (x1.6)<br />
for flexible usage<br />
● Ultra-quick start time (approx. 9 sec.)<br />
and cool-down (approx. 30 sec.)<br />
● Ease of use: auto input,<br />
auto keystone correction (vertical),<br />
21 menu languages<br />
● Screen colour correction<br />
● Lamp life 4,000 hours in<br />
silent mode (only LV-X6)<br />
● Whisper quiet at 25 dBA in silent mode<br />
(LV-X6), 29 dBA (LV-7250)<br />
and 30 dBA (LV-7255)<br />
Image Size Chart Canon LV-7255<br />
Projection distance approx. Image width approx.<br />
1.00 m 0.51 m<br />
2.00 – 3.00 m 1.63 m<br />
3.80 – 5.90 m 3.05 m<br />
7.60 m 6.10 m<br />
Canon LV-7255<br />
Resolution : XGA<br />
Technology : LCD (Psi)<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 3.0 kg<br />
Code No. 1000LV7255 price on request<br />
Canon LV-7250<br />
Resolution : XGA<br />
Technology : LCD (Psi)<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 3.0 kg<br />
Code No. 1000LV7250 price on request<br />
Canon LV-X6<br />
Resolution : XGA<br />
Technology : LCD (Psi)<br />
Light output approx.: 1,500 ANSI lumens<br />
Weight approx.: 2.9 kg<br />
Code No. 1000LVX6 price on request<br />
Image Size Chart Canon LV-7250/X6<br />
Projection distance approx. Image width approx.<br />
1.10 m 0.51 m<br />
2.30 – 3.70 m 1.63 m<br />
4.40 – 6.90 m 3.05 m<br />
8.80 m 6.10 m<br />
Accessories<br />
For detailed information on technical specifications refer to pages 26, 27 and 29.<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Mobile screens pages 74–81<br />
● Wall screens pages 82–83<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Mouse remote controls pages 44–45<br />
● Further ceiling mounts pages 37, 41–43<br />
Digital Projectors<br />
17
Digital Projectors<br />
18<br />
Optoma EP747 –<br />
ready for use in just a few seconds<br />
Highlights<br />
● Quick-start function: ready for use within<br />
a few seconds<br />
● Extremely quiet operation: merely 27 dB<br />
in eco mode<br />
● 2,200:1 Contrast for excellent black values<br />
● 3,000 Hours lamp life in eco mode<br />
● Monitor output for connecting a control<br />
monitor<br />
● Scart on VGA adapter included in delivery<br />
standard<br />
● IR remote control with graphical pointer<br />
● 18 Different menu languages<br />
Optoma EP747<br />
Resolution: XGA<br />
Technology: DLP<br />
Light output approx.: 3,000 ANSI lumens<br />
Weight approx.: 3.15 kg<br />
Code No. 1000747 price on request<br />
Image Size Chart Optoma EP747<br />
Projection distance approx. Image width approx.<br />
1.20 m 0.50 – 0.60 m<br />
3.00 m 1.25 – 1.50 m<br />
5.00 m 2.08 – 2.50 m<br />
10.00 m 4.17 – 5.00 m<br />
Accessories<br />
For detailed information on technical specifications refer to page 29.<br />
Transport Case<br />
for Optoma projector and accessories, with<br />
scratch-resistant, silver-grey plastic surface<br />
and aluminium fittings<br />
Code No. 1185-05<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Mobile screens pages 74–81<br />
● Wall screens pages 82–83<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Further ceiling mounts pages 37, 41–43
Optoma EP910 –<br />
high resolution detail projection for control centres<br />
Highlights<br />
● SXGA+ (1,400x1,050) resolution for sharp<br />
display of even finest details<br />
(e.g. CAD/CAM)<br />
● Extremely quiet operation with only<br />
32 dB in eco mode<br />
● 3,000:1 Contrast for excellent black values<br />
● Monitor output for connecting a control<br />
monitor<br />
● DVI-I input for perfect signal transmission<br />
● RJ-45 network connection for remote<br />
maintenance via IP networks<br />
● USB output for controlling the mouse<br />
cursor via the IR remote control of the<br />
projector<br />
● Scart on VGA adapter included in delivery<br />
standard<br />
● IR remote control with graphical pointer<br />
Image Size Chart Optoma EP910<br />
Projection distance approx. Image width approx.<br />
1.20 m 0.50 – 0.60 m<br />
3.00 m 1.25 – 1.50 m<br />
5.00 m 2.08 – 2.50 m<br />
10.00 m 4.17 – 5.00 m<br />
Optoma EP910<br />
Resolution: SXGA+<br />
Technology: DLP<br />
Light output approx.: 3,500 ANSI lumens<br />
Weight approx.: 4.6 kg<br />
Code No. 1000910 price on request<br />
Accessories<br />
For detailed information on technical specifications refer to page 35.<br />
Transport Case<br />
for Optoma projector and accessories, with<br />
scratch-resistant, silver-grey plastic surface<br />
and aluminium fittings<br />
Code No. 1185-06<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Stationary screens pages 82–90<br />
● Presentation furniture pages 96–97<br />
● Further ceiling mounts pages 37, 41–43<br />
Seiten 37, 41–43<br />
Digital Projectors<br />
19
Digital Projectors<br />
20<br />
BenQ CP120 –<br />
wireless presentations in mini-format<br />
Highlights<br />
● Super lightweight: only 1.3 kg<br />
● Wireless image transmission via WLAN<br />
integrated (802.11a/b/g standard)<br />
● Auto keystone correction for automatic<br />
adjustment of the screen image<br />
● Quick cool-down function for rapid cooling<br />
after the projector has been switched off<br />
(approx. 30 sec.)<br />
● Front ventilation: no bothersome air flow<br />
disturbing the audience<br />
● sRGB compatible for genuine colour<br />
display<br />
BenQ CP120<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 1,500 ANSI lumens<br />
Weight approx.: 1.3 kg<br />
Code No. 1000CP120 price on request<br />
Image Size Chart BenQ CP120<br />
Projection distance approx.. Image width approx.<br />
1.81 – 2.10 m 1.00 m<br />
3.63 – 4.22 m 2.00 m<br />
5.44 – 6.32 m 3.00 m<br />
9.07 – 10.55 m 5.00 m<br />
Accessories<br />
For detailed information on technical specifications refer to page 24.<br />
Projector/Laptop Bag<br />
with integrated trolley function, for laptop<br />
and projector up to H/W/D: 8/33/26 cm<br />
Code No. 1185-09<br />
Further Accessories<br />
● Mobile screens pages 74–81<br />
● Wall screens pages 82–83<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Mouse remote controls pages 44–45
BenQ MP720/MP620/MP610 Series –<br />
the economic solution<br />
Highlights<br />
● Extremely low operating noise<br />
with less than 25 dB (MP610) or less than<br />
28 dB (MP620/720) in eco mode<br />
● Lamp life of up to approx. 4,000 hours<br />
(eco mode)<br />
● Quick cool-down function for rapid cooling<br />
after the projector has been switched off<br />
(approx. 30 sec.)<br />
● Front ventilation: no bothersome air flow<br />
disturbing the audience<br />
● Monitor output for connecting a control<br />
monitor (only MP610)<br />
Image Size Chart BenQ MP720/MP620/MP610<br />
Projection distance approx. Image width approx.<br />
1.82 – 2.10 m 1.00 m<br />
3.65 – 4.20 m 2.00 m<br />
5.47 – 6.30 m 3.00 m<br />
9.12 – 10.51 m 5.00 m<br />
BenQ MP720<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 2.72 kg<br />
Code No. 1000MP720 price on request<br />
BenQ MP620<br />
Resolution : XGA<br />
Technology : DLP<br />
Light output approx.: 2,200 ANSI lumens<br />
Weight approx.: 2.72 kg<br />
Code No. 1000MP620 price on request<br />
BenQ MP610<br />
Resolution : SVGA<br />
Technology : DLP<br />
Light output approx.: 2,000 ANSI lumens<br />
Weight approx.: 2.72 kg<br />
Code No. 1000MP610 price on request<br />
Accessories<br />
For detailed information on technical specifications refer to pages 23, 27 and 28.<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Mobile screens pages 74–81<br />
● Wall screens pages 82–83<br />
● Laser pointer page 49<br />
● Presentation furniture pages 96–97<br />
● Mouse remote controls pages 44–45<br />
● Further ceiling mounts pages 37, 41–43<br />
Digital Projectors<br />
21
Digital Projectors<br />
22<br />
ProjectionDesign EVO2SX+ –<br />
87%(*) more information on the projection surface<br />
Highlights EVO2SX+<br />
● More information on the projection<br />
surface with 1,400x1,050 pixels (SXGA+)<br />
● Distortion-free projection thanks to<br />
vertical lens shift (optical)<br />
● Hardly perceptible operating noise with<br />
24 dB (eco mode)<br />
● Programmable timer with 10 memory<br />
spaces, automated power on/off and<br />
change of input source<br />
● RJ-45 network connection for remote<br />
maintenance/control via IP networks<br />
● Portrait projections in 3:4 format are<br />
possible<br />
● DVI-D input and HDCP compatible<br />
● Strong true-colour effect thanks to<br />
RealColor Technology<br />
● Low-maintenance thanks to filter-free<br />
design<br />
● Rich contrast with 2,500:1<br />
(DMD DarkChip3 TM )<br />
● HDready compatible<br />
ProjectionDesign EVO2SX+<br />
Resolution: SXGA+ (1,400x1,050)<br />
Technology: DLP<br />
Light output approx.: 2,500 ANSI lumens<br />
Weight approx.: 2.9 kg<br />
Code No. 1000EVO2 price on request<br />
Accessories<br />
Ceiling Mount Exclusive<br />
with infinitely variable distance rod<br />
(from 67 to 110 cm)<br />
Weight: approx. 3 kg<br />
Code No. 22022<br />
Further Accessories<br />
● Design projection trolley Multistage<br />
page 96<br />
● Mouse remote controls pages 44–45<br />
● Ultra-bright Laser Green page 49<br />
● Wall screens pages 82–90<br />
● Mobile screens pages 74–81<br />
● Further ceiling mounts pages 37, 41–43<br />
Image Size Chart ProjectionDesign EVO2SX+<br />
Projection distance approx. Image width approx.<br />
1.00 ~ 1.30 m 0.60 m<br />
2.60 ~ 3.30 m 1.50 m<br />
3.40 ~ 4.40 m 2.00 m<br />
7.50 ~ 9.70 m 4.40 m<br />
For detailed information on technical specifications refer to page 34.<br />
(*) Comparison SXGA+ against XGA resolution
Digital SVGA Projectors<br />
Ranked according to portability and brightness<br />
Model<br />
Approx. ANSI lumens (normal/eco)<br />
Approx. weight in kg<br />
Native resolution<br />
Maximum resolution<br />
Technology<br />
Contrast<br />
Lamp life<br />
approx. hours (normal/eco)<br />
Throw ratio<br />
Approx. projection distance in m<br />
Approx. image width in m<br />
Approx. fan noise in dB (normal/eco)<br />
Approx. dimensions (H/W/D) in cm<br />
Functions<br />
Power off and go<br />
Lense type<br />
Ceiling-mounted projection<br />
WLAN-compatible<br />
PC-free presentation<br />
Optical lens shift<br />
Digital keystone correction<br />
Digital zoom<br />
HDready logo<br />
PIN code protection<br />
IR remote control<br />
Connectivity<br />
Input PC (D-SUB 15)<br />
Audio input computer<br />
DVI input computer<br />
Output PC monitor (D-Sub 15)<br />
RCA audio/video input<br />
S-Video input (DIN 4-pin)<br />
Component input<br />
5x BNC video input<br />
Audio output<br />
USB interface<br />
RS 232 interface<br />
Accessories/Consumables<br />
Spare lamp Code No.<br />
Case / Bag<br />
Interchangeable lenses<br />
Ceiling mount<br />
Other<br />
Specials<br />
Warranty projector<br />
Warranty original lamp<br />
Catalogue page<br />
HITACHI<br />
CP-RS56<br />
1,600/1,300<br />
2.2<br />
800 x 600 (SVGA)<br />
1,280 x 1,024 (SXGA)<br />
LCD (Psi)<br />
500:1<br />
2,000<br />
1.64–1.97:1<br />
1.3–12.1<br />
0.81–6.10<br />
38/33<br />
7.3/28.5/20.2<br />
●<br />
manual<br />
Code No.<br />
1000RS56<br />
Subject to technical changes and errors. ● yes – no<br />
●<br />
–<br />
–<br />
–<br />
●<br />
●<br />
–<br />
●<br />
●<br />
2<br />
1<br />
1<br />
1<br />
–<br />
–<br />
1<br />
1<br />
1<br />
1<br />
1 (audio via comp. audio) 1<br />
1 (via VGA)<br />
1 (via VGA)<br />
–<br />
–<br />
–<br />
–<br />
1<br />
1<br />
1<br />
–/–<br />
1127-101<br />
optional<br />
–<br />
optional<br />
digital<br />
gamma correction,<br />
My Memory<br />
3 years<br />
6 months or<br />
2,000 hours<br />
5<br />
PLUS<br />
U5-512h<br />
2,000/1,600<br />
1.9<br />
800 x 600 (SVGA)<br />
1,024 x 768 (XGA)<br />
DLP<br />
2,000:1<br />
2,000/3,000<br />
1.8–2.17:1<br />
1.2–13.36<br />
0.56–6.09<br />
37/33<br />
6.0/21.6/24.0<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
+14°/-18° vert.<br />
●<br />
–<br />
●<br />
optional<br />
1187-69<br />
optional<br />
–<br />
optional<br />
front ventilation,<br />
presentation timer<br />
3 years<br />
6 months or<br />
1,000 hours<br />
–<br />
1000U5512H<br />
Optoma<br />
EP716R<br />
2,200/n.s.<br />
2.0<br />
800 x 600 (SVGA)<br />
1,024 x 768 (XGA)<br />
DLP<br />
2,000:1<br />
3,000/4,000<br />
1.93–2.13:1<br />
1.5–10<br />
0.7–5.2<br />
32/28<br />
9.5/23/21<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±15° vert.<br />
●<br />
–<br />
●<br />
–<br />
2<br />
1<br />
–<br />
1<br />
–<br />
1<br />
–<br />
–<br />
–<br />
1<br />
1/–<br />
1127-65<br />
softcase<br />
–<br />
optional<br />
SCART adapter<br />
in delivery standard<br />
2 years<br />
6 months or<br />
1,000 hours<br />
–<br />
1000716R<br />
SANYO<br />
PLC-SU70<br />
2,000/1,600<br />
2.4<br />
800 x 600 (SVGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/3,000<br />
1.78–2.14:1<br />
1.43–13.19<br />
0.60–4.57<br />
34/29<br />
7.1/29.8/21.8<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±20 vert.<br />
●<br />
–<br />
●<br />
–<br />
2 (1x via VGA outp.)<br />
1<br />
–<br />
1<br />
1<br />
1<br />
1 x (via VGA)<br />
–<br />
1<br />
1<br />
1/–<br />
1183-77<br />
softcase<br />
–<br />
optional<br />
programmable<br />
start logo,<br />
board mode<br />
3 years incl.<br />
24 h on-site<br />
exchange service<br />
(only in D, F, I)<br />
1 year or<br />
2,000 hours<br />
–<br />
1000SU70<br />
BenQ<br />
MP610<br />
2,000/1,600<br />
2.72<br />
800 x 600 (SVGA)<br />
1,280 x 1024 (SXGA)<br />
DLP<br />
2,000:1<br />
3,000/4,000<br />
1.82–2.10:1<br />
1.0–10<br />
0.47–5.48<br />
< 25 / < 29<br />
9.4/23.8/23.8<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±16° vert.<br />
–<br />
–<br />
●<br />
–<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
–<br />
1/–<br />
1190-17<br />
softcase<br />
–<br />
optional<br />
quick cooling function,<br />
front ventilation<br />
3 years<br />
6 months<br />
21<br />
1000MP610<br />
More information<br />
on www.medium.de<br />
Micro-portable (1.5 – 2.49 kg) Ultra-portable (2.5–4.99 kg)<br />
HITACHI<br />
CP-S240<br />
2,000/1,600<br />
2.8<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/4,000<br />
1.52–1.86:1<br />
0.9–11.2<br />
0.61–6.10<br />
38/33<br />
8.6/30.6/24.9<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±15° vertical<br />
●<br />
–<br />
●<br />
●<br />
2<br />
1<br />
–<br />
1 via VGA input<br />
1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1 /–<br />
1127-102<br />
softcase<br />
–<br />
optional<br />
filter and lamp exchange<br />
when ceiling-mounted,<br />
extra security bar as antitheft<br />
protec., MyScreen<br />
withPIN code security<br />
3 years<br />
6 months or<br />
2,000 hours<br />
2<br />
1000240<br />
Overview Digital Projectors<br />
23
Overview Digital Projectors<br />
24<br />
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
Model<br />
Approx. ANSI lumens (normal/eco)<br />
Approx. weight in kg<br />
Native resolution<br />
Maximum resolution<br />
Technology<br />
Contrast<br />
Lamp life<br />
approx. hours (normal/eco)<br />
Throw ratio<br />
Approx. projection distance in m<br />
Approx. image width in m<br />
Approx. fan noise in dB (normal/eco)<br />
Approx. dimensions (H/W/D) in cm<br />
Functions<br />
Power off and go<br />
Lense type<br />
Ceiling-mounted projection<br />
WLAN-compatible<br />
PC-free presentation<br />
Optical lens shift<br />
Digital keystone correction<br />
Digital zoom<br />
HDready logo<br />
PIN code protection<br />
IR remote control<br />
Connectivity<br />
Input PC (D-SUB 15)<br />
Audio input computer<br />
DVI input computer<br />
Output PC monitor (D-Sub 15)<br />
RCA audio/video input<br />
S-Video input (DIN 4-pin)<br />
Component input<br />
5x BNC video input<br />
Audio output<br />
USB interface<br />
RS 232 interface<br />
Accessories/Consumables<br />
Spare lamp Code No.<br />
Case / Bag<br />
Interchangeable lenses<br />
Ceiling mount<br />
Other<br />
Specials<br />
Warranty projector<br />
Warranty original lamp<br />
Catalogue page<br />
PLUS<br />
V-339<br />
1,300/1,040<br />
1.3<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
1,500/2,000<br />
1.91–2.30:1<br />
1.2–11.8<br />
0.53-6.09<br />
37/35<br />
4.6/18.6/17.6<br />
●<br />
manual<br />
–<br />
–<br />
–<br />
+12°/-18° vert. autom.<br />
Code No.<br />
1000V339<br />
Subject to technical changes and errors. ● yes – no<br />
Palm-sized (up to 1.49 kg)<br />
●<br />
–<br />
●<br />
–<br />
1<br />
1<br />
–<br />
–<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
1<br />
–<br />
1187-73<br />
softcase<br />
–<br />
–<br />
2 colour wheel system,<br />
presentation timer<br />
3 years<br />
6 months or<br />
1,000 hours<br />
6<br />
BenQ<br />
CP120<br />
1,500/1,200<br />
1.3<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
2,000 / 3,000<br />
1.81–2.11:1<br />
1.00–10.00<br />
0.47–5.51<br />
< 35/< 32<br />
6.1/21.8/17.2<br />
–<br />
manual<br />
●<br />
●<br />
–<br />
–<br />
±16° vertical autom.<br />
–<br />
–<br />
●<br />
–<br />
1<br />
–<br />
–<br />
–<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
–<br />
–/–<br />
1190-21<br />
softcase<br />
–<br />
optional<br />
quick cooling function,<br />
front ventilation,<br />
sRGB-compatible<br />
3 years<br />
6 months<br />
20<br />
1000CP120<br />
Optoma<br />
EP729<br />
1,600/1,280<br />
1.0<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,200:1<br />
3,000/4,000<br />
2.0–2.3:1<br />
1.5–10<br />
0.65–5.0<br />
35/33<br />
6.2/15.2/20<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±8° vertical<br />
●<br />
–<br />
–<br />
●<br />
1<br />
–<br />
–<br />
–<br />
1<br />
1<br />
–<br />
–<br />
–<br />
1<br />
1/–<br />
1127-64<br />
softcase<br />
–<br />
–<br />
3 years<br />
6 months or<br />
1,000 hours<br />
–<br />
1000729<br />
SANYO<br />
PLC-XU70<br />
1,500/1,200<br />
2.4<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/3,000<br />
1.78–2.14:1<br />
1.43–13.19<br />
0.60–4.57<br />
34/29<br />
7.1/29.8/21.8<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±20 vertical<br />
●<br />
–<br />
●<br />
–<br />
2 (1xvia VGA output)<br />
1<br />
-<br />
1<br />
1<br />
1<br />
1 x (via VGA)<br />
-<br />
1<br />
1<br />
1/–<br />
1183-78<br />
softcase<br />
–<br />
optional<br />
most lightweight projec- programmable start<br />
tor in our range, remote logo,<br />
control incl. laser pointer,<br />
programmable start logo<br />
board mode<br />
Micro-portable (1.5 – 2.49 kg)<br />
3 years incl.<br />
24-hours on-site<br />
exchange service<br />
(only in D, F, I)<br />
1 year or<br />
2,000 hours<br />
–<br />
1000XU70<br />
HITACHI<br />
CP-RX61<br />
1,600/1,300<br />
2.2<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
LCD (Psi)<br />
500:1<br />
2,000/n.s.<br />
1.48–1.78:1<br />
1.2–11.0<br />
0.81–6.10<br />
38 / 33<br />
7.3/28.5/20.2<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
●<br />
●<br />
–<br />
●<br />
●<br />
2<br />
1<br />
–<br />
1<br />
1<br />
1 (audio via comp. audio)<br />
1 (via VGA)<br />
–<br />
–<br />
1<br />
1<br />
1127-101<br />
optional<br />
–<br />
optional<br />
digital gamma correction,<br />
MyMemory<br />
3 years<br />
6 months or<br />
2,000 hours<br />
5<br />
1000RS56
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
Panasonic<br />
PT-LB50NTE<br />
2,000/1,600<br />
1.9<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/3,000<br />
1.2–1.5<br />
1.1–10.7<br />
0.67–6.10<br />
n.s.<br />
5.7/29.7/21.0<br />
●<br />
manual<br />
●<br />
●<br />
–<br />
–<br />
±30° vertical<br />
●<br />
–<br />
●<br />
●<br />
2 (1x via VGA output)<br />
1<br />
–<br />
1 x (via VGA in)<br />
1<br />
1<br />
1 x (via VGA)<br />
–<br />
1<br />
–<br />
1/–<br />
1187-14<br />
softcase<br />
–<br />
optional<br />
2-sec. quick start, lamp<br />
protection switch, highspeed-WLAN,<br />
Daylight-<br />
View, shutter & freeze<br />
3 years<br />
6 months or<br />
400 hours<br />
15<br />
1000LB50NTE<br />
PLUS<br />
U5-532h<br />
2,000/1,600<br />
2.0<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
2,000/3,000<br />
1.8–2.17:1<br />
1.2–13.36<br />
0.56–6.09<br />
37/33<br />
6.0/21.6/24.0<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
+14°/-18° vertical<br />
●<br />
–<br />
●<br />
optional<br />
1<br />
1<br />
–<br />
–<br />
1<br />
1<br />
1x (via VGA)<br />
–<br />
–<br />
1<br />
1/–<br />
1187-69<br />
softcase<br />
-<br />
optional<br />
front ventilation,<br />
presentation timer,<br />
3,000 ANSI in<br />
black/white mode<br />
3 years<br />
6 months or<br />
1,000 hours<br />
7<br />
1000U5532H<br />
SANYO<br />
PLC-XU73<br />
2,000/1,600<br />
2.4<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/3,000<br />
1.78–2.14:1<br />
1.43–13.19<br />
0.60–4.57<br />
34/29<br />
7.1/29.8/21.8<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±20 vertical<br />
●<br />
–<br />
●<br />
–<br />
2 (1x via VGA output)<br />
1<br />
–<br />
1<br />
1<br />
1<br />
1 x (via VGA)<br />
–<br />
1<br />
1<br />
1/–<br />
1183-77<br />
softcase<br />
–<br />
optional<br />
programmable start<br />
logo,<br />
board mode<br />
3 years, incl. 24-hours<br />
on-site exchange service<br />
(only in D, F, I)<br />
1 year or<br />
2,000 hours<br />
–<br />
1000XU73<br />
CASIO<br />
XJ-360<br />
2,200/1,800<br />
1.8<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
2,000/n.s.<br />
1.4–2.8:1<br />
0.8–5.3 (16 m no AK)<br />
0.28–3.79 (6.10 m no AK)<br />
n.s./33<br />
5.5/23.0/17.1<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±20° vertical autom.<br />
●<br />
–<br />
●<br />
–<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
–<br />
–/–<br />
1189-32<br />
softcase<br />
–<br />
optional<br />
2xzoom,<br />
automatic vertical<br />
keystone correction,<br />
magnesium casing<br />
3 years<br />
90 days or<br />
1,000 hours<br />
9<br />
1000XJ360<br />
Optoma<br />
EP719R<br />
2,200/1,800<br />
2.0<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,500:1<br />
3,000/4,000<br />
1.95–2.13:1<br />
1.5–10<br />
0.7–5.2<br />
32/28<br />
9.4/22.8/20.9<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±15° vertical<br />
●<br />
–<br />
●<br />
–<br />
2<br />
1<br />
–<br />
1<br />
–<br />
1<br />
–<br />
–<br />
–<br />
1<br />
1/–<br />
1127-65<br />
softcase<br />
–<br />
optional<br />
SCART adapter incl. in<br />
delivery standard<br />
3 years<br />
6 months or<br />
1,000 hours<br />
–<br />
1000719R<br />
PLUS<br />
U5-632h<br />
2,300/1,840<br />
2.0<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
2,000/3,000<br />
1.29–1.56:1<br />
1.2–9.56<br />
0.78–6.09<br />
37/33<br />
6.0/21.6/25.2<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
+8°/-11° vertical<br />
●<br />
–<br />
●<br />
●<br />
1<br />
1<br />
–<br />
–<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
1<br />
1/–<br />
1187-69<br />
softcase<br />
–<br />
optional<br />
front ventilation,<br />
presentation timer,<br />
3,000 ANSI in<br />
black/white mode<br />
3 years<br />
6 months or<br />
1,000 hours<br />
7<br />
1000U5632H<br />
Overview Digital Projectors<br />
25
Overview Digital Projectors<br />
26<br />
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
Model<br />
Approx. ANSI lumens (normal/eco)<br />
Approx. weight in kg<br />
Native resolution<br />
Maximum resolution<br />
Technology<br />
Contrast<br />
Lamp life<br />
approx. hours (normal/eco)<br />
Throw ratio<br />
Approx. projection distance in m<br />
Approx. image width in m<br />
Approx. fan noise in dB (normal/eco)<br />
Approx. dimensions (H/W/D) in cm<br />
Functions<br />
Power off and go<br />
Lense type<br />
Ceiling-mounted projection<br />
WLAN-compatible<br />
PC-free presentation<br />
Optical lens shift<br />
Digital keystone correction<br />
Digital zoom<br />
HDready logo<br />
PIN code protection<br />
IR remote control<br />
Connectivity<br />
Input PC (D-SUB 15)<br />
Audio input computer<br />
DVI input computer<br />
Output PC monitor (D-Sub 15)<br />
RCA audio/video input<br />
S-Video input (DIN 4-pin)<br />
Component input<br />
5x BNC video input<br />
Audio output<br />
USB interface<br />
RS 232 interface<br />
Accessories/Consumables<br />
Spare lamp Code No.<br />
Case / Bag<br />
Interchangeable lenses<br />
Ceiling mount<br />
Other<br />
Specials<br />
Warranty projector<br />
Warranty original lamp<br />
Catalogue page<br />
Code No.<br />
Subject to technical changes and errors. ● yes – no<br />
Micro-portable (1.5 – 2.49 kg) Ultra-portable (2.5–4.99 kg)<br />
PLUS<br />
U5-732h<br />
2,500/2,000<br />
2.1<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
2,000/3,000<br />
1.85–2.24:1<br />
1.2–13.81<br />
0.55–6.09<br />
37/33<br />
6.0/21.6/26.0<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
+12°/-15° vertical<br />
●<br />
–<br />
●<br />
●<br />
1<br />
1<br />
–<br />
–<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
1<br />
1/–<br />
1187-69<br />
softcase<br />
–<br />
optional<br />
front ventilation,<br />
presentation timer,<br />
3,000 ANSI in<br />
black/white mode<br />
3 years<br />
6 months or<br />
1,000 hours<br />
7<br />
1000U5732H<br />
Optoma<br />
EP739H<br />
2,500/2,000<br />
2.4<br />
1,024 x 768 (XGA)<br />
1,400 x 1,050 (SXGA+)<br />
DLP<br />
2,000:1<br />
3,500/5,000<br />
2.0–2.4:1<br />
1.2–10<br />
0.5–6.0<br />
32/27<br />
10.4/26.5/23.6<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±16° vertical<br />
●<br />
–<br />
–<br />
–<br />
1<br />
1<br />
1 (with HDCP)<br />
1<br />
1<br />
1<br />
1 via VGA<br />
–<br />
–<br />
1<br />
1/–<br />
1127-60<br />
softcase<br />
optional<br />
optional<br />
SCART RGB adapter<br />
in delivery standard,<br />
sRGB, programmable<br />
start logo<br />
3 years<br />
6 months or<br />
1,000 hours<br />
–<br />
1000739H<br />
Canon<br />
LV-X6<br />
1,500/1,200<br />
2.9<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
3,000/4,000<br />
n.s.<br />
1.1–8.8<br />
0.51–6.10<br />
32/25<br />
10.9/31/26.5<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±30° vertical autom.<br />
●<br />
–<br />
–<br />
●<br />
2<br />
2<br />
–<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
1<br />
–<br />
1/–<br />
1192-05<br />
softcase<br />
–<br />
optional<br />
ultra-fast<br />
start-up and<br />
shutdown<br />
3 years<br />
90 days<br />
17<br />
1000LVX6<br />
SANYO<br />
PLC-XU83<br />
2,000/1,600<br />
2.6<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/3,000<br />
1.44–2.25:1<br />
1.0–13.7<br />
0.81–6.09<br />
34/29<br />
6.95/29.4/20.8<br />
●<br />
manual<br />
●<br />
via USB<br />
●<br />
–<br />
±20° vertical. autom.<br />
●<br />
–<br />
●<br />
●<br />
1 (via VGA output)<br />
1<br />
1 (with HDCP)<br />
1<br />
1<br />
1<br />
1x (via VGA)<br />
–<br />
1<br />
1<br />
1/1<br />
1183-77<br />
softcase<br />
–<br />
optional<br />
programmable start<br />
logo,<br />
board mode,<br />
moderator function<br />
3 years incl.<br />
24-hours on-site<br />
exchange service<br />
(only in D, F, I)<br />
1 year or<br />
2,000 hours<br />
12<br />
1000XU83<br />
HITACHI<br />
CP-X250<br />
2,000/1,600<br />
2.8<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/4,000<br />
1.52–1.86:1<br />
0.9–11.2<br />
0.61–6.10<br />
38/33<br />
8.6/30.6/24.9<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±15° vertical<br />
●<br />
–<br />
●<br />
●<br />
2<br />
1<br />
–<br />
1 via VGA input<br />
1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1/–<br />
1127-102<br />
softcase<br />
–<br />
optional<br />
filter and lamp exchange<br />
when ceiling-mounted,<br />
extra security bar as antitheft<br />
protection, MyScreen<br />
with PIN code security<br />
3 years<br />
6 months or<br />
2,000 hours<br />
2<br />
1000X250
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
HITACHI<br />
EDX-8250<br />
2,000/1,600<br />
2.8<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/4,000<br />
1.52–1.86:1<br />
0.9–11.2<br />
0.61–6.10<br />
38/33<br />
8.6/30.6/24.9<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±15° vertical<br />
●<br />
–<br />
●<br />
●<br />
2<br />
1<br />
–<br />
1 (via VGA input)<br />
1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1/–<br />
1127-102<br />
optional<br />
–<br />
optional<br />
for schools: 36 mon. or 2,000 hours on<br />
lamp supplied with the projector<br />
2<br />
10008250-S<br />
HITACHI<br />
CP-X255<br />
2,000 / 1,600<br />
2.9<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/4,000<br />
1.52–1.86:1<br />
0.9–11.2<br />
0.61–6.10<br />
38/33<br />
8.6/30.6/24.9<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±15° vertical<br />
●<br />
–<br />
●<br />
●<br />
2<br />
1<br />
–<br />
1 (via VGA input)<br />
1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1/1<br />
1127-102<br />
softcase<br />
–<br />
optional<br />
filter and lamp exchange when cei- filter and lamp exchange<br />
ling-mounted, extra security bar as when ceiling-mounted,<br />
anti-theft protection, MyScreen extra security bar as anti-<br />
with PIN code security,<br />
theft protection, MyScreen<br />
eco mode as factory setting with PIN code security<br />
3 years<br />
3 years<br />
6 months or<br />
2,000 hours<br />
2<br />
1000255<br />
Canon<br />
LV-7250<br />
2,000 / 1,600<br />
3.0<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/3,000<br />
n.s.<br />
1.1–8.8<br />
0.51–6.10<br />
35/29<br />
10.9/31/26.5<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±30° vertical autom.<br />
●<br />
–<br />
–<br />
●<br />
2<br />
2<br />
–<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
1<br />
–<br />
1/–<br />
1192-06<br />
softcase<br />
–<br />
optional<br />
ultra-fast<br />
start-up and<br />
shutdown<br />
3 years<br />
90 days<br />
17<br />
1000LV7250<br />
BenQ<br />
MP620<br />
2,200 / 1,8000<br />
2.72<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
3,000/4,000<br />
1.82–2.10:1<br />
1.0–10<br />
0.47–5.48<br />
< 28/< 31<br />
9.4/23.8/23.8<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±16° vertical<br />
–<br />
–<br />
●<br />
–<br />
1<br />
1<br />
1<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
–<br />
1/–<br />
1190-20<br />
softcase<br />
–<br />
optional<br />
quick cooling function,<br />
front ventilation<br />
3 years<br />
6 months<br />
21<br />
1000MP620<br />
Panasonic<br />
PT-LB55NTE<br />
2,500 / 2,000<br />
2.6<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/3,000<br />
1.3–1.6<br />
1.1–10.8<br />
0.67–6.10<br />
n.s./30<br />
7.5/32.7/23.3<br />
●<br />
manual<br />
●<br />
●<br />
–<br />
–<br />
±30° vertical<br />
●<br />
–<br />
●<br />
●<br />
2 (1xvia VGA output)<br />
2<br />
–<br />
1 (via VGA input)<br />
1<br />
1<br />
(via VGA input)<br />
–<br />
1<br />
–<br />
1/–<br />
1187-15<br />
softcase<br />
–<br />
optional<br />
2-sec. quick start, lamp<br />
protection switch,<br />
highspeed-WLAN,<br />
Daylight-View,<br />
shutter & freeze<br />
3 years<br />
6 months or<br />
400 hours<br />
15<br />
1000LB55NTE<br />
SANYO<br />
PLC-XU86<br />
2,500 / 2,000<br />
2.6<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
500:1<br />
2,000/3,000<br />
1.23–1.93:1<br />
1.0–11.7<br />
0.81–6.09<br />
34/29<br />
6.95/29.4/20.8<br />
●<br />
manual<br />
●<br />
via USB<br />
●<br />
–<br />
±20° vertical autom.<br />
●<br />
–<br />
●<br />
●<br />
1 (via VGA output)<br />
1<br />
1 (with HDCP)<br />
1<br />
1<br />
1<br />
1x (via VGA)<br />
–<br />
1<br />
1<br />
1/1<br />
1183-77<br />
softcase<br />
–<br />
optional<br />
programmable start<br />
logo, board mode,<br />
moderator function<br />
3 years incl.<br />
24-hours on-site<br />
exchange service<br />
(only in D, F, I)<br />
1 year or<br />
2,000 hours<br />
12<br />
1000XU86<br />
Overview Digital Projectors<br />
27
Overview Digital Projectors<br />
28<br />
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
Model<br />
Approx. ANSI lumens (normal/eco)<br />
Approx. weight in kg<br />
Native resolution<br />
Maximum resolution<br />
Technology<br />
Contrast<br />
Lamp life<br />
approx. hours (normal/eco)<br />
Throw ratio<br />
Approx. projection distance in m<br />
Approx. image width in m<br />
Approx. fan noise in dB (normal/eco)<br />
Approx. dimensions (H/W/D) in cm<br />
Functions<br />
Power off and go<br />
Lense type<br />
Ceiling-mounted projection<br />
WLAN-compatible<br />
PC-free presentation<br />
Optical lens shift<br />
Digital keystone correction<br />
Digital zoom<br />
HDready logo<br />
PIN code protection<br />
IR remote control<br />
Connectivity<br />
Input PC (D-SUB 15)<br />
Audio input computer<br />
DVI input computer<br />
Output PC monitor (D-Sub 15)<br />
RCA audio/video input<br />
S-Video input (DIN 4-pin)<br />
Component input<br />
5x BNC video input<br />
Audio output<br />
USB interface<br />
RS 232 interface<br />
Accessories/Consumables<br />
Spare lamp Code No.<br />
Case / Bag<br />
Interchangeable lenses<br />
Ceiling mount<br />
Other<br />
Specials<br />
Warranty projector<br />
Warranty original lamp<br />
Catalogue page<br />
CASIO<br />
XJ-460<br />
2,500/2,000<br />
2.7<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
DLP<br />
2,000:1<br />
2,000/n.s.<br />
Code No.<br />
1000XJ460<br />
Subject to technical changes and errors. ● yes – no<br />
1.4–2.8:1<br />
0.8–5.3 (16 m no AF/AK)<br />
0.28–3.79 (6.10 m no AF/AK)<br />
n.s./33<br />
6.4/27.8/21.4<br />
●<br />
motorised<br />
●<br />
–<br />
–<br />
–<br />
±30° horiz./vert. both autom.<br />
●<br />
–<br />
Ultra-portable (2.5–4.99 kg)<br />
●<br />
●<br />
1<br />
1<br />
–<br />
–<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
1<br />
–/–<br />
1189-33<br />
softcase<br />
–<br />
optional<br />
2x zoom, auto focus motor<br />
zoom, autom. horizontal and<br />
vertical keystone correction,<br />
magnesium casing<br />
3 years<br />
90 days or<br />
1,000 hours<br />
9<br />
BenQ<br />
MP720<br />
2,500/2,000<br />
2.72<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
3,000/4,000<br />
1.82–2.10:1<br />
1.0–10<br />
0.47–5.48<br />
< 28/< 31<br />
9.4/29.1/23.4<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±16° vertical<br />
–<br />
–<br />
●<br />
–<br />
1<br />
1<br />
1<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
–<br />
1/–<br />
1190-20<br />
softcase<br />
–<br />
optional<br />
HITACHI<br />
CP-X260<br />
2,500/2,000<br />
2.8<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
500:1<br />
2,000/3,000<br />
1.7–1.9:1<br />
n.s.<br />
n.s.<br />
36/33<br />
8.6/30.6/24.9<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±30* vertical<br />
●<br />
–<br />
●<br />
●<br />
2<br />
2<br />
–<br />
1<br />
1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1/–<br />
n.s.<br />
optional<br />
–<br />
optional<br />
quick cooling function, autosearch,<br />
front ventilation direct off,<br />
quick on<br />
3 years<br />
6 months<br />
21<br />
1000MP720<br />
3 years<br />
6 months or<br />
2,000 hours<br />
4<br />
1000260<br />
HITACHI<br />
CP-X265<br />
2,500/2,000<br />
2.8<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
500:1<br />
2,000/3,000<br />
1.7–1.9:1<br />
n.s.<br />
n.s.<br />
36/33<br />
8.6/30.6/24.9<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±30* vertical<br />
●<br />
–<br />
●<br />
●<br />
2<br />
2<br />
–<br />
1<br />
1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1/1<br />
n.s.<br />
optional<br />
–<br />
optional<br />
network function,<br />
autosearch,<br />
direct off,<br />
quick on<br />
3 years<br />
6 months or<br />
2,000 hours<br />
4<br />
1000265<br />
HITACHI<br />
CP-X268<br />
2,500/2,000<br />
2.8<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
500:1<br />
2,000/3,000<br />
1.7–1.9:1<br />
n.s.<br />
n.s.<br />
36/33<br />
8.6/30.6/24.9<br />
●<br />
manual<br />
●<br />
●<br />
●<br />
–<br />
±30* vertical<br />
●<br />
–<br />
●<br />
●<br />
2<br />
2<br />
–<br />
1<br />
1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1/1<br />
n.s.<br />
optional<br />
–<br />
optional<br />
network function,<br />
wireless, JPEG,<br />
PPT reader,<br />
autosearch,<br />
direct off, quick on<br />
3 years<br />
6 months or<br />
2,000 hours<br />
4<br />
1000268
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
Canon<br />
LV-7255<br />
2,500/1,900<br />
3.0<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/3,000<br />
n.s.<br />
1.0–7.5<br />
0.51–6.10<br />
35/30<br />
10.9/31/26.5<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±30° vertical autom.<br />
●<br />
–<br />
–<br />
●<br />
2<br />
2<br />
-<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
1<br />
–<br />
1/–<br />
1192-07<br />
softcase<br />
–<br />
optional<br />
ultra-fast<br />
start-up and<br />
shutdown<br />
3 years<br />
90 days<br />
17<br />
1000LV7255<br />
SANYO<br />
PLC-XU48<br />
3,000/2,200<br />
2.7<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
450:1<br />
2,000/3,000<br />
1.65–1.95:1<br />
1.3–10.0<br />
0.66–6.07<br />
37/33<br />
7.1/29.8/21.4<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±20° vertical<br />
●<br />
–<br />
●<br />
–<br />
2 ( 1xvia VGA output)<br />
1<br />
-<br />
1<br />
1<br />
1<br />
1x (via VGA)<br />
–<br />
1<br />
–<br />
1/–<br />
1183-65<br />
optional<br />
–<br />
optional<br />
programmable start<br />
logo,<br />
board mode<br />
3 years incl.<br />
24-hours on-site<br />
exchange service<br />
(only in D, F, I)<br />
3 years or<br />
2,000 hours<br />
–<br />
1000XU48<br />
CASIO<br />
XJ-560<br />
3,000/2,400<br />
2.7<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
DLP<br />
2,000:1<br />
2,000/n.s.<br />
1.4–2.8:1<br />
0.8–5.3 (16 m no AF/AK)<br />
0.28–3.79 (6.10 m no AF/AK)<br />
n.s./33<br />
6.4/27.8/21.4<br />
●<br />
motorised<br />
●<br />
–<br />
–<br />
–<br />
±30° horiz./vert. both autom.<br />
●<br />
–<br />
●<br />
●<br />
1<br />
1<br />
–<br />
–<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
1<br />
–/–<br />
1189-33<br />
softcase<br />
–<br />
optional<br />
2xzoom, auto focus,<br />
autom. horizontal and<br />
vertical keystone correction,<br />
magnesium casing<br />
3 years<br />
90 days or<br />
1,000 hours<br />
9<br />
1000XJ560<br />
SANYO<br />
PLC-XU58<br />
3,000/2,400<br />
2.8<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
450:1<br />
1,000/2,000<br />
1.2–1.9:1<br />
1.0–7.7<br />
0.82–6.11<br />
34/29<br />
7.1/29.8/21.8<br />
–<br />
manual<br />
●<br />
optional<br />
optional<br />
–<br />
±40° vert. auto./±20° horiz.<br />
●<br />
–<br />
●<br />
●<br />
1 (via VGA output)<br />
1<br />
1 (with HDCP)<br />
1<br />
1<br />
1<br />
1x (via VGA)<br />
–<br />
1<br />
1<br />
1/optional<br />
1183-65<br />
softcase<br />
–<br />
optional<br />
programmable start logo,<br />
board mode<br />
3 years incl.<br />
24-hours on-site exchange<br />
service (only in D, F, I)<br />
1 year or<br />
2,000 hours<br />
–<br />
1000XU58<br />
PLUS<br />
U7-132SF<br />
3,000/2,400<br />
3.0<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
2,000/3,000<br />
1.52–1.78:1<br />
1.2–11.02<br />
0.69–6.09<br />
37/34<br />
8.3/25.8/32<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±20° vertical<br />
●<br />
–<br />
●<br />
●<br />
1<br />
1<br />
1<br />
1<br />
1<br />
1<br />
2 (1xvia DVI, 1xvia VGA)<br />
–<br />
–<br />
1<br />
1/–<br />
1187-72<br />
softcase<br />
–<br />
optional<br />
presentation timer<br />
3 years<br />
6 months or<br />
1,000 hours<br />
8<br />
1000U7132SF<br />
Optoma<br />
EP747<br />
3,000<br />
3.1<br />
1,024 x 768 (XGA)<br />
1,400 x 1,050 (SXGA+)<br />
DLP<br />
2,200:1<br />
2,000/3,000<br />
2.0–2.4:1<br />
1.5–10<br />
0.6–5.0<br />
n.s. / 32<br />
11/34.8/25.8<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±16° vertical<br />
●<br />
–<br />
●<br />
●<br />
2<br />
4<br />
1 (HDCP)<br />
1 (via VGA in)<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
1<br />
1<br />
1/–<br />
1127-70<br />
n.s.<br />
optional<br />
optional<br />
SCART adapter in delivery<br />
standard,<br />
mouse remote control<br />
via USB<br />
3 years<br />
6 months or<br />
1,000 hours<br />
18<br />
1000747<br />
Overview Digital Projectors<br />
29
Overview Digital Projectors<br />
30<br />
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
Model<br />
Approx. ANSI lumens (normal/eco)<br />
Approx. weight in kg<br />
Native resolution<br />
Maximum resolution<br />
Technology<br />
Contrast<br />
Lamp life<br />
approx. hours (normal/eco)<br />
Throw ratio<br />
Approx. projection distance in m<br />
Approx. image width in m<br />
Approx. fan noise in dB (normal/eco)<br />
Approx. dimensions (H/W/D) in cm<br />
Functions<br />
Power off and go<br />
Lense type<br />
Ceiling-mounted projection<br />
WLAN-compatible<br />
PC-free presentation<br />
Optical lens shift<br />
Digital keystone correction<br />
Digital zoom<br />
HDready logo<br />
PIN code protection<br />
IR remote control<br />
Connectivity<br />
Input PC (D-SUB 15)<br />
Audio input computer<br />
DVI input computer<br />
Output PC monitor (D-Sub 15)<br />
RCA audio/video input<br />
S-Video input (DIN 4-pin)<br />
Component input<br />
5x BNC video input<br />
Audio output<br />
USB interface<br />
RS 232 interface<br />
Accessories/Consumables<br />
Spare lamp Code No.<br />
Case / Bag<br />
Interchangeable lenses<br />
Ceiling mount<br />
Other<br />
Specials<br />
Warranty projector<br />
Warranty original lamp<br />
Catalogue page<br />
Code No.<br />
1000LB60NTE<br />
Subject to technical changes and errors. ● yes – no<br />
Ultra-portable (2.5–4.99 kg)<br />
Panasonic<br />
PT-LB60NTE<br />
3,200/2,600<br />
2.6<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/3,000<br />
1.2–1.40<br />
1.1–10.8<br />
0.67–6.10<br />
n.s./30<br />
7.5/32.7/23.3<br />
●<br />
manual<br />
●<br />
●<br />
–<br />
–<br />
±30° vertical<br />
●<br />
–<br />
●<br />
●<br />
2 (1x via VGA output)<br />
2<br />
–<br />
1 (via VGA in)<br />
1<br />
1<br />
(via VGA input)<br />
–<br />
1<br />
–<br />
1/–<br />
1187-16<br />
softcase<br />
–<br />
optional<br />
2-sec. quick start, lamp<br />
protection switch, highspeed<br />
WLAN, Daylight-<br />
View, shutter & freeze<br />
3 years<br />
6 months or<br />
400 hours<br />
15<br />
HITACHI<br />
CP-X444W<br />
3,200/2,600<br />
3.5<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200(UXGA)<br />
LCD (Psi)<br />
500:1<br />
2,000/n.s.<br />
1.5–1.8:1<br />
1.2–11.0<br />
0.61–6.10<br />
38/33<br />
9.5/33.6/26.5<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±15° vertical<br />
●<br />
–<br />
●<br />
●<br />
2<br />
1<br />
–<br />
1<br />
1<br />
1<br />
1<br />
-<br />
1<br />
1<br />
1/–<br />
1127-100<br />
optional<br />
–<br />
optional<br />
programmable<br />
start logo<br />
3 years<br />
6 months or<br />
2,000 hours<br />
–<br />
1000444<br />
HITACHI<br />
CP-X445W<br />
3,200/2,600<br />
3.9<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
400:1<br />
2,000/n.s.<br />
1.5–1.8:1<br />
1.2–11.0<br />
0.61–6.10<br />
38/33<br />
9.5/33.6/26.5<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±15° horiz./ ±15° vert. (auto)<br />
●<br />
–<br />
●<br />
●<br />
2<br />
1<br />
1 (HDCP)<br />
1<br />
1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1/1<br />
1127-100<br />
softcase<br />
–<br />
optional<br />
4 x 3 W audio output,<br />
programmable<br />
start logo, 12 DC control<br />
output, connector cable<br />
remote control<br />
3 years<br />
6 months or<br />
2,000 hours<br />
–<br />
1000445W<br />
PLUS<br />
U7-132hSF<br />
3,500/2,800<br />
3.0<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
2,000/3,000<br />
1.52–1.78:1<br />
1.2–11.02<br />
0.69– 6.09<br />
37/34<br />
8.3/25.8/32<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±20° vertical<br />
●<br />
–<br />
●<br />
●<br />
1<br />
1<br />
1<br />
1<br />
1<br />
1<br />
2 (1xvia DVI, 1xvia VGA)<br />
–<br />
–<br />
1<br />
1/–<br />
1187-72<br />
softcase<br />
–<br />
optional<br />
presentation timer<br />
3 years<br />
6 months or<br />
1,000 hours<br />
8<br />
1000U7132HSF<br />
PLUS<br />
U7-137SF<br />
3,500/2,800<br />
3.1<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
DLP<br />
2,000:1<br />
2,000/3,000<br />
1.52–1.78:1<br />
1.2–11.02<br />
0.69–6.09<br />
37/34<br />
8.3/25.8/32<br />
–<br />
manual<br />
●<br />
via CF card slot<br />
via USB<br />
–<br />
±20° vertical<br />
●<br />
–<br />
●<br />
●<br />
1<br />
1<br />
1<br />
1<br />
1<br />
1<br />
2 (1xvia DVI, 1xvia VGA)<br />
–<br />
–<br />
3<br />
1/1<br />
1187-72<br />
softcase<br />
–<br />
optional<br />
presentation timer,<br />
PC card slot,<br />
control via<br />
Telnet, component<br />
output<br />
3 years<br />
6 months or<br />
1,000 hours<br />
8<br />
1000U7137SF
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
Optoma<br />
EP759<br />
3,500/2,800<br />
3.4<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
DLP<br />
2,000:1<br />
2,000/3,000<br />
2.0–2.4:1<br />
1.5–10<br />
0.5–6.0<br />
32/28<br />
12.7/34/26<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±16° horiz. and vert.<br />
●<br />
–<br />
–<br />
●<br />
1<br />
1<br />
1 (HDCP)<br />
1<br />
–<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1/–<br />
1127-61<br />
optional<br />
optional<br />
optional<br />
SCART adapter in<br />
delivery standard<br />
3 years<br />
6 months or<br />
1,000 hours<br />
1000759<br />
Canon<br />
XEED X600<br />
3,500/2,800<br />
4.6<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCOS<br />
1,000:1<br />
1,500/2,000<br />
n.s.<br />
1.2–8.9<br />
0.81–6.10<br />
35/32<br />
11.4/26.6/33.6<br />
–<br />
motorised<br />
●<br />
–<br />
–<br />
–<br />
±20° horiz./±20° vert. (autom.)<br />
●<br />
●<br />
–<br />
●<br />
1<br />
1<br />
1 (with HDCP)<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
1<br />
1/–<br />
1192-08<br />
softcase<br />
–<br />
optional<br />
1.7xzoom area, auto focus,<br />
auto screen colour correction<br />
3 years<br />
90 days<br />
16<br />
1000X600<br />
Portable (5–8.99 kg)<br />
AVIO<br />
iP25<br />
2,000<br />
5.6<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
LCD (Psi)<br />
350:1<br />
2,000/3,000<br />
1.85–2.21:1<br />
1.5–11.3<br />
0.67–6.10<br />
38/36<br />
14.0/31.0/40.5<br />
–<br />
manual<br />
–<br />
–<br />
●<br />
–<br />
±15° vertical<br />
●<br />
–<br />
–<br />
●<br />
1<br />
1<br />
–<br />
–<br />
1<br />
1<br />
–<br />
–<br />
–<br />
1<br />
–/–<br />
1128-10<br />
optional<br />
–<br />
–<br />
integrated document<br />
camera,<br />
scanner function via<br />
USB output, 32 pages<br />
frame buffer<br />
2 years<br />
90 days or<br />
500 hours<br />
13<br />
1000IP25<br />
AVIO<br />
iP55<br />
3,000<br />
7.3<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
350:1<br />
1,500/n.s.<br />
1.75–2.24:1<br />
1.4–13.9<br />
0.65–6.10<br />
38/36<br />
14.5/40.0/31.5<br />
–<br />
manual<br />
●<br />
–<br />
–<br />
–<br />
±10° horiz./±15° vert.<br />
●<br />
–<br />
–<br />
●<br />
2<br />
2<br />
–<br />
1<br />
1<br />
1<br />
–<br />
–<br />
–<br />
1<br />
–<br />
1128-13<br />
optional<br />
–<br />
–<br />
integrated document<br />
camera,<br />
scanner function via<br />
USB output, 32 pages<br />
frame buffer<br />
2 years<br />
90 days or<br />
500 hours<br />
13<br />
1000IP50<br />
HITACHI<br />
CP-X1200WA<br />
3,500/2,800<br />
7.7<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
750:1<br />
2,000/n.s.<br />
1.5–2.2:1<br />
1.2–23.2<br />
0.80–10.16<br />
39/35<br />
16.0/42.0/32.0<br />
–<br />
motorised<br />
●<br />
–<br />
●<br />
●<br />
±5° horiz./±15° vert. (auto)<br />
●<br />
–<br />
●<br />
●<br />
1 + 1x BNC<br />
2<br />
VESA M1D (with HDCP)<br />
1<br />
1<br />
1<br />
1 + PC input 1<br />
–<br />
1<br />
1<br />
1/1<br />
1127-94<br />
optional<br />
optional<br />
optional<br />
bayonet fitting for interchangeable<br />
lenses, 12-DC<br />
control output, connector<br />
cable remote control,<br />
remote control ID<br />
3 years<br />
6 months or<br />
2,000 hours<br />
3<br />
10001200<br />
SANYO<br />
PLC-XT16<br />
3,500<br />
7.8<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
LCD (Psi)<br />
900:1<br />
1,500<br />
1.6–2.1:1<br />
1.2–10.0<br />
0.61–6.09<br />
36/30<br />
16.2/30.2/42.2<br />
–<br />
motorised<br />
●<br />
optional<br />
optional<br />
vertical<br />
±10 horiz./ ±30° vert.<br />
●<br />
–<br />
–<br />
●<br />
1<br />
2<br />
1<br />
1<br />
2/1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1/optional<br />
1183-68<br />
optional<br />
optional<br />
optional<br />
one-touch<br />
lens change<br />
3 years incl.<br />
24-hours on-site<br />
exchange service<br />
(only in D, F, I)<br />
1 year or<br />
1,000 hours<br />
–<br />
1000XT16<br />
Overview Digital Projectors<br />
31
Overview Digital Projectors<br />
32<br />
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
Model<br />
Approx. ANSI lumens (normal/eco)<br />
Approx. weight in kg<br />
Native resolution<br />
Maximum resolution<br />
Technology<br />
Contrast<br />
Lamp life<br />
approx. hours (normal/eco)<br />
Throw ratio<br />
Approx. projection distance in m<br />
Approx. image width in m<br />
Approx. fan noise in dB (normal/eco)<br />
Approx. dimensions (H/W/D) in cm<br />
Functions<br />
Power off and go<br />
Lense type<br />
Ceiling-mounted projection<br />
WLAN-compatible<br />
PC-free presentation<br />
Optical lens shift<br />
Digital keystone correction<br />
Digital zoom<br />
HDready logo<br />
PIN code protection<br />
IR remote control<br />
Connectivity<br />
Input PC (D-SUB 15)<br />
Audio input computer<br />
DVI input computer<br />
Output PC monitor (D-Sub 15)<br />
RCA audio/video input<br />
S-Video input (DIN 4-pin)<br />
Component input<br />
5x BNC video input<br />
Audio output<br />
USB interface<br />
RS 232 interface<br />
Accessories/Consumables<br />
Spare lamp Code No.<br />
Case / Bag<br />
Interchangeable lenses<br />
Ceiling mount<br />
Other<br />
Specials<br />
Warranty projector<br />
Warranty original lamp<br />
Catalogue page<br />
Panasonic<br />
PT-D3500E<br />
3,500/2,800<br />
7.9<br />
1,024 x 768 (XGA)<br />
1,600 x 1,280 (UXGA)<br />
DLP<br />
1,600:1<br />
1,500/2,000<br />
1.8–2.5:1 (standard lens)<br />
0.8–98.9<br />
1.02–12.19 (standard lens)<br />
33/29<br />
16.8/33.2/42.5<br />
●<br />
motorised<br />
●<br />
–<br />
–<br />
horizontal/vertical<br />
±30° vertical<br />
Code No.<br />
1000PTD3500<br />
Subject to technical changes and errors. ● yes – no<br />
●<br />
–<br />
Portable (5–8.99 kg)<br />
●<br />
●<br />
1 + 5x BNC<br />
2<br />
1<br />
–<br />
1<br />
1<br />
1<br />
1<br />
1<br />
–<br />
1/1<br />
1187-17<br />
optional<br />
optional<br />
optional<br />
24-hours/7-days non-stop opera- lens shift, network<br />
tion, network-compatible, remote function, direct off,<br />
control with mouse function, len- quick on, connection cable<br />
ses with bayonet fitting, 6-colour remote control,<br />
correction, opt. 4,000 h lamp auto search<br />
3 years<br />
3 years<br />
6 months or<br />
400 hours<br />
14<br />
HITACHI<br />
CP-X605<br />
4,000/3,200<br />
6.0<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
1,000:1<br />
3,000/n.s.<br />
1.7–2.0:1<br />
n.s.<br />
n.s.<br />
36/32<br />
15.0/42.0/31.5<br />
●<br />
manual<br />
●<br />
–<br />
–<br />
horizontal/vertical<br />
±5° horiz./±15° vert. (auto)<br />
●<br />
–<br />
●<br />
●<br />
2<br />
2<br />
VESA M1D<br />
1<br />
1<br />
1<br />
1<br />
–<br />
1<br />
–<br />
1/1<br />
n.s.<br />
optional<br />
optional<br />
optional<br />
6 months or<br />
2,000 hours<br />
–<br />
1000605<br />
HITACHI<br />
SANYO<br />
HITACHI<br />
CP-X608<br />
PLC-P51/XP51L CP-X1250W<br />
4,000/3,200<br />
4,000/3,200<br />
4,500/3,600<br />
6.0<br />
8.7/ 7.9<br />
7.7<br />
1,024 x 768 (XGA) 1,024 x 768 (XGA) 1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA) 1,280 x 1,024 (SXGA) 1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
LCD (Psi)<br />
LCD (Psi)<br />
1,000:1<br />
1,000:1<br />
850:1<br />
3,000/n.s.<br />
1,500/1,500<br />
1.7–2.3:1<br />
2,000/n.s.<br />
1.7–2.0:1<br />
1.4–14.4 (XP51) 1.5–2.2:1<br />
n.s.<br />
0.62–8.04 (XP51) 1.2–23.2<br />
n.s.<br />
39/35<br />
0.80–10.16<br />
36/32<br />
16.8/31.9/47<br />
39/35<br />
15.0/42.0/31.5<br />
–<br />
16.0/42.0/32.0<br />
●<br />
motorised<br />
–<br />
manual<br />
●<br />
motorised<br />
●<br />
–<br />
●<br />
●<br />
–<br />
–<br />
–<br />
vertical<br />
●<br />
horizontal/vertical ±10 horiz./±30° vert. ●<br />
±5° horiz./±15° vert. (auto) ●<br />
±5° horiz./±15° vert. (auto)<br />
●<br />
–<br />
●<br />
–<br />
–<br />
–<br />
●<br />
●<br />
●<br />
●<br />
1<br />
●<br />
2<br />
1<br />
1 + 1x BNC<br />
2<br />
1 (with HDCP)<br />
2<br />
VESA M1D<br />
1 (via VGA input) VESA M1D (with HDCP)<br />
1<br />
1/–<br />
1<br />
1<br />
1<br />
1<br />
1<br />
2<br />
1<br />
1<br />
1<br />
1 + PC input 1<br />
–<br />
1<br />
–<br />
1<br />
1<br />
1<br />
–<br />
1/optional<br />
1<br />
1/1<br />
1183-74<br />
1/1<br />
n.s.<br />
optional<br />
1127-94<br />
optional<br />
optional<br />
optional<br />
optional<br />
optional<br />
optional<br />
optional<br />
4 interchangeable<br />
optional<br />
lens shift, network lenses,<br />
bayonet fitting for inter-<br />
function, direct off, one-touch lens change changeable lenses, 12-DC<br />
quick on, connection cable<br />
control output, connector<br />
remote control,<br />
cable remote control,<br />
auto search<br />
3 years<br />
remote control ID<br />
3 years<br />
3 years<br />
6 months or<br />
2,000 hours<br />
–<br />
1000608<br />
90 days or<br />
300 hours<br />
6 months or<br />
10<br />
2,000 hours<br />
1000XP51/ 1000XP51L 3<br />
10001250
Digital XGA Projectors<br />
Ranked according to portability and brightness<br />
SANYO<br />
PLC-XP57L<br />
5,500 / 4,400<br />
7.9<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
1,000 :1<br />
1,500 / n.s.<br />
depending on lens<br />
depending on lens<br />
depending on lens<br />
39/35<br />
16.8/31.9/47<br />
–<br />
motorised<br />
●<br />
–<br />
–<br />
depending on lens<br />
±10 horiz./±30° vert.<br />
●<br />
–<br />
–<br />
●<br />
1<br />
1<br />
1 (with HDCP)<br />
1 (via VGA input)<br />
1/–<br />
1<br />
2<br />
1<br />
1<br />
1<br />
1/optional<br />
n.s.<br />
optional<br />
optional<br />
optional<br />
4 interchangeable lenses,<br />
one-touch lens<br />
change, 24 h/7 days<br />
non-stop operation<br />
with optional package<br />
3 years<br />
90 days or<br />
300 hours<br />
10<br />
1000XP57L<br />
AVIO<br />
iP750<br />
4,500<br />
8.5<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
500:1<br />
1,500/n.s.<br />
1.93–2.44:1<br />
1.4–13.0<br />
0.65–6.10<br />
41/41<br />
19.0/39.0/38.0<br />
–<br />
manual<br />
–<br />
–<br />
●<br />
–<br />
±10° horiz./±15° vert.<br />
●<br />
–<br />
–<br />
●<br />
2<br />
2<br />
–<br />
1<br />
1<br />
1<br />
–<br />
–<br />
–<br />
1<br />
–/–<br />
1128-14<br />
optional<br />
–<br />
–<br />
integrated document<br />
camera,<br />
scanner function via<br />
USB output, 32 pages<br />
frame buffer<br />
2 years<br />
90 days or<br />
500 hours<br />
13<br />
1000IP750<br />
Stationary (more than 9.0 kg)<br />
SANYO<br />
PLC-XP56/ XP56L<br />
5,000/4,000<br />
9.2/7.9<br />
1,024 x 768 (XGA)<br />
1,280 x 1,024 (SXGA)<br />
LCD (Psi)<br />
1,000:1<br />
1,500/1,500<br />
1.7–2.3:1<br />
1.4–14.4 (XP56)<br />
0.62–8.04 (XP56)<br />
39/35<br />
16.8/31.9/47<br />
–<br />
motorised<br />
●<br />
–<br />
–<br />
vertical<br />
±10 horiz. u. ±30° vert.<br />
●<br />
–<br />
–<br />
●<br />
1<br />
1<br />
1 (with HDCP)<br />
1 (via VGA input)<br />
1/–<br />
1<br />
2<br />
1<br />
1<br />
1<br />
1/–<br />
1183-74<br />
Panasonic<br />
PT-D5500E/EL<br />
5,000/4,000<br />
13.8/12.9<br />
1,024 x 768 (XGA)<br />
1,600 x 1,280 (UXGA)<br />
DLP<br />
1,600:1<br />
2,000/1,500<br />
2-lamp operation<br />
1.8–2.5:1/depending on lens<br />
0.8–98.9<br />
1.02–12.19 (standard lens)<br />
32/29<br />
16.5/52.9/42.5<br />
●<br />
motorised<br />
●<br />
–<br />
–<br />
horizontal/vertical<br />
±30°<br />
●<br />
–<br />
●<br />
●<br />
1 + 5x BNC<br />
–<br />
1<br />
–<br />
–<br />
1<br />
1<br />
1<br />
–<br />
–<br />
1/1<br />
optional<br />
1187-10<br />
1183-75<br />
optional<br />
optional<br />
–<br />
optional<br />
optional<br />
optional<br />
4 interchangeable lenses,<br />
optional<br />
optional<br />
one touch lens change 24-hours non-stop operation, 6 opt. interface boards,<br />
network-compatible, remote 13 interchangeable<br />
control with mouse function, len- lenses,<br />
ses with bayonet fitting, 6-colour 2-lamp security system,<br />
3 years<br />
correction, opt. 4,000 h lamp mech. shutter, radio RC<br />
3 years<br />
3 years<br />
90 days or<br />
300 hours<br />
10<br />
1000XP56/1000XP56L<br />
6 months or<br />
400 hours<br />
14<br />
1000PTD5500/1000PTD5500-L<br />
SANYO<br />
PLC-XF60A<br />
6,500 / 5,200<br />
25<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
1,300:1<br />
1,500/3,000<br />
depending on lens<br />
depending on lens<br />
depending on lens<br />
42/39<br />
25.2/51.8/60.6<br />
–<br />
motorised<br />
●<br />
–<br />
optional<br />
depen. on lens (vert./horiz.)<br />
±35° vert./±20°horiz.<br />
●<br />
–<br />
–<br />
●<br />
1<br />
2<br />
1 (with HDCP)<br />
1<br />
2/1<br />
1<br />
1<br />
1<br />
–<br />
2<br />
1x in, 1x out/optional<br />
90 days or<br />
300 hours<br />
11<br />
1000XF60A<br />
SANYO<br />
PLC-XF46<br />
12,000<br />
37.5<br />
1,024 x 768 (XGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
1,200 :1<br />
1,500 / n.s.<br />
depending on lens<br />
depending on lens<br />
depending on lens<br />
n.s.<br />
25.2/58.1/78.3<br />
–<br />
motorised<br />
●<br />
–<br />
–<br />
depen. on lens (vert./horiz.)<br />
+40°/-20° vertical<br />
●<br />
–<br />
–<br />
●<br />
1<br />
2<br />
1 (with HDCP)<br />
–<br />
2/–<br />
1<br />
1 (via BNC)<br />
1<br />
1<br />
1<br />
1x in, 1x out/optional<br />
n.s.<br />
–<br />
optional<br />
optional<br />
8 opt. interface boards,<br />
11 interchangeable<br />
lenses,<br />
4-lamp security system,<br />
Real Colour Manager<br />
3 years<br />
90 days or<br />
300 hours<br />
–<br />
1000XF46<br />
Overview Digital Projectors<br />
33
Overview Digital Projectors<br />
34<br />
Digital SXGA+/UXGA Projectors<br />
Ranked according to portability and brightness<br />
Model<br />
Approx. ANSI lumens (normal/eco)<br />
Approx. weight in kg<br />
Native resolution<br />
Maximum resolution<br />
Technology<br />
Contrast<br />
Lamp life<br />
approx. hours (normal/eco)<br />
Throw ratio<br />
Approx. projection distance in m<br />
Approx. image width in m<br />
Approx. fan noise in dB (normal/eco)<br />
Approx. dimensions (H/W/D) in cm<br />
Functions<br />
Power off and go<br />
Lense type<br />
Ceiling-mounted projection<br />
WLAN-compatible<br />
PC-free presentation<br />
Optical lens shift<br />
Digital keystone correction<br />
Digital zoom<br />
HDready logo<br />
PIN code protection<br />
IR remote control<br />
Connectivity<br />
Input PC (D-SUB 15)<br />
Audio input computer<br />
DVI input computer<br />
Output PC monitor (D-Sub 15)<br />
RCA audio/video input<br />
S-Video input (DIN 4-pin)<br />
Component input<br />
5x BNC video input<br />
Audio output<br />
USB interface<br />
RS 232 interface<br />
Accessories/Consumables<br />
Spare lamp Code No.<br />
Case / Bag<br />
Interchangeable lenses<br />
Ceiling mount<br />
Other<br />
Specials<br />
Warranty projector<br />
Warranty original lamp<br />
Catalogue page<br />
ProjectionDesign<br />
EVO2 SX+<br />
2,500/2,000<br />
2.9<br />
1,400 x 1,050 (SXGA+)<br />
1,920 x 1,080<br />
DLP<br />
2,500:1<br />
2,250/3,000<br />
1.7–2.2:1<br />
1.5–10.0<br />
0.56–4.40<br />
28/23<br />
9.4/27.8/23.4<br />
–<br />
manual<br />
Code No.<br />
1000EV02<br />
Subject to technical changes and errors. ● yes – no<br />
Ultra-portable (2.5–4.99 kg)<br />
●<br />
–<br />
–<br />
●<br />
horizontal and vertical<br />
–<br />
●<br />
●<br />
●<br />
1<br />
1<br />
1 (with HDCP)<br />
–<br />
1<br />
1<br />
1<br />
–<br />
–<br />
1<br />
1/1<br />
1128-3<br />
optional<br />
–<br />
optional<br />
magnesium casing, week timer<br />
with real time clock and 10 program.<br />
combinations, upright installation,<br />
selectable lamp output (180-220 watt),<br />
lamp change from the front<br />
3 years<br />
90 days or<br />
500 hours<br />
22<br />
Canon<br />
XEED SX60<br />
2,500/2,000<br />
4.6<br />
1,400 x 1,050 (SXGA+)<br />
1,600 x 1,200 (UXGA)<br />
LCOS<br />
1,000:1 (home cinema mode 2,000:1)<br />
2,500/4,000<br />
n.s.<br />
1.2–8.9<br />
0.81–6.10<br />
32/29<br />
11.4/26.6/33.6<br />
–<br />
motorised<br />
●<br />
–<br />
–<br />
–<br />
±20 horiz. u. ±20° vert. (autom.)<br />
●<br />
●<br />
–<br />
●<br />
1<br />
1<br />
1 (with HDCP)<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
1<br />
1/–<br />
1192-09<br />
softcase<br />
–<br />
optional<br />
1.7x zoom area, HDready,<br />
only 26 dBA in cinema mode, autofocus,<br />
auto screen colour correction<br />
3 years<br />
90 days<br />
16<br />
1000SX60<br />
Canon<br />
XEED SX6<br />
3,500/2,800<br />
4.6<br />
1,400 x 1,050 (SXGA+)<br />
1,600 x 1,200 (UXGA)<br />
LCOS<br />
1,000:1<br />
1,500/2,000<br />
n.s.<br />
1.2–8.9<br />
0.81–6.10<br />
35/32<br />
11.4/26.6/33.6<br />
–<br />
motorised<br />
●<br />
–<br />
–<br />
–<br />
±20 horiz. u. ±20° vert. (autom.)<br />
●<br />
●<br />
-<br />
●<br />
1<br />
1<br />
1 (with HDCP)<br />
1<br />
1<br />
1<br />
1 (via VGA)<br />
–<br />
–<br />
1<br />
1/–<br />
1192-08<br />
softcase<br />
–<br />
optional<br />
1.7x zoom area, HDready,<br />
autofocus,<br />
auto screen colour correction<br />
3 years<br />
90 days<br />
16<br />
1000SX6
Digital SXGA+/UXGA Projectors<br />
Ranked according to portability and brightness<br />
Optoma<br />
EP910<br />
3,500/2,800<br />
4.6<br />
1,400 x 1,050 (SXGA+)<br />
1,600 x 1,200 (UXGA)<br />
DLP<br />
3,000:1<br />
2,000/3,000<br />
2.1–2.4:1<br />
1.5–10<br />
0.6 –5.0<br />
n.s./32<br />
11.6/41.1/31.1<br />
–<br />
manual<br />
●<br />
●<br />
–<br />
–<br />
±16° horizontal and ±16° vertical<br />
●<br />
●<br />
●<br />
●<br />
1<br />
4<br />
1<br />
1<br />
1<br />
1<br />
1<br />
–<br />
1<br />
1<br />
1 / 1<br />
1127-69<br />
n.s.<br />
–<br />
optional<br />
Texas Instruments<br />
DarkChip 3,<br />
mouse remote control<br />
via USB<br />
3 years<br />
6 months or<br />
1,000 hours<br />
19<br />
1000910<br />
Portable (5–8.99 kg) Stationary (more than 9.0 kg)<br />
HITACHI<br />
CP-SX1350W<br />
3,500/2,800<br />
7.7<br />
1,400 x 1,050 (SXGA+)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
650:1<br />
2,000 hours/n.s.<br />
1.5–2.2:1<br />
1.2–23.2<br />
0.80–10.16<br />
42/38<br />
16.0/42.0/32.0<br />
–<br />
motorised<br />
●<br />
–<br />
●<br />
●<br />
±5° horizontal/±15° vertical (auto)<br />
●<br />
●<br />
●<br />
●<br />
1 + 1x BNC<br />
2<br />
VESA M1D (with HDCP)<br />
1<br />
1<br />
1<br />
1 + PC input 1<br />
–<br />
1<br />
1<br />
1 / 1<br />
1127-94<br />
optional<br />
optional<br />
optional<br />
bayonet fitting for interchangeable<br />
lenses, 12-DC control output,<br />
connection cable remote control,<br />
remote control ID<br />
3 years<br />
6 months or<br />
2,000 hours<br />
3<br />
10001350<br />
SANYO<br />
PLC-EF60A<br />
5,800/4,600<br />
25<br />
1,400 x 1,050 (SXGA+)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
1,300:1<br />
1,500/3,000<br />
depending on lens<br />
depending on lens<br />
depending on lens<br />
42/39<br />
25.2/51.8/60.6<br />
–<br />
motorised<br />
●<br />
–<br />
optional<br />
depending on lens (vert./horiz.)<br />
±35° vertical./±20° horizontal<br />
●<br />
–<br />
–<br />
●<br />
1<br />
2<br />
1 (with HDCP)<br />
1<br />
2/1<br />
1<br />
1<br />
1<br />
-<br />
2<br />
1x in, 1x out /optional<br />
1183-75<br />
–<br />
optional<br />
optional<br />
6 opt. interface boards,<br />
13 interchangeable lenses,<br />
2-lamp security system, mech.<br />
shutter, radio remote control<br />
3 years<br />
90 days or<br />
300 hours<br />
11<br />
1000EF60A<br />
SANYO<br />
PLC-UF15<br />
7,700<br />
37.5<br />
1,600 x 1,200 (UXGA)<br />
1,600 x 1,200 (UXGA)<br />
LCD (Psi)<br />
1,000:1<br />
1,000<br />
depending on lens<br />
depending on lens<br />
depending on lens<br />
45<br />
25.2/58.1/78.3<br />
–<br />
motorised<br />
●<br />
–<br />
–<br />
depending on lens (vert./horiz.)<br />
+40°/-20° vertical<br />
●<br />
–<br />
–<br />
●<br />
1 x BNC<br />
2<br />
1<br />
–<br />
2/–<br />
1<br />
–<br />
2<br />
1<br />
1<br />
3/optional<br />
1183-55<br />
–<br />
optional<br />
optional<br />
8 opt. interface boards,<br />
11 interchangeable lenses,<br />
4-lamp security system, Real<br />
Colour Manager<br />
3 years<br />
90 days or<br />
300 hours<br />
–<br />
1000UF15<br />
Overview Digital Projectors<br />
35
Home Cinema<br />
36<br />
Hitachi PJ-TX200<br />
Highlights HITACHI PJ-TX200<br />
● Horizontal and vertical lens shift<br />
no limits as to where the projector should<br />
be positioned<br />
● HDMI connection (with HDCP) for the<br />
connection of digital signal sources<br />
● HDready certified thus suited for replaying<br />
HDTV signals<br />
● High contrast for natural images<br />
HITACHI PJ-TX200<br />
Resolution: 1,280 x 720 (16:9)<br />
Technology: LCD (Psi)<br />
Light output approx.: 1,200 ANSI lumens<br />
Contrast approx.: 7,000:1<br />
Operating noise: 24 dB (eco mode)<br />
Code No. 1000TX200 price on request<br />
Image Size Chart HITACHI PJ-TX200<br />
Projection distance approx.Image width approx.<br />
0.80 – 1.20 m 0.80 m<br />
1.90 – 3.10 m 1.50 m<br />
2.60 – 4.10 m 2.00 m<br />
8.60 – 13.70 m 6.60 m<br />
Sanyo PLV-Z4<br />
Highlights SANYO PLV-Z4<br />
● Native 16:9 panel for original<br />
16:9 wide-screen format<br />
● HDready logo for unspoilt joy while<br />
viewing HDTV signals<br />
● HDMI connection (with HDCP) for<br />
connecting digital signal sources<br />
● Contrast of 7.000:1 for brilliant and sharp<br />
images thanks to excellent black values<br />
● Horizontal and vertical lens shift<br />
no limits as to where the projector should<br />
be positioned<br />
● Whisper quiet: merely 22 dB fan noise<br />
in eco mode<br />
● Integrated 2x wide-angle zoom lens for<br />
greater flexibility in use<br />
● Automatic motorised shutter for<br />
protection of the lens<br />
SANYO PLV-Z4<br />
Resolution : 1,280 x 720 (16:9)<br />
Technology: LCD (Psi)<br />
Light output approx.: 1,000 ANSI lumens<br />
Contrast approx.: 7,000:1<br />
Operating noise: 22 dB (eco mode)<br />
Code No. 1000PLVZ4 price on request<br />
Image Size Chart SANYO PLV-Z4<br />
Projection distance approx.Image width approx.<br />
1.36 – 2.76 m 1.00 m<br />
2.72 – 5.52 m 2.00 m<br />
4.08 – 8.28 m 3.00 m<br />
5.44 – 11.04 m 4.00 m<br />
BenQ PE7700<br />
Home Cinema – take fun & action home<br />
For detailed information on the respective products visit www.medium.de<br />
Subject to technical changes without notice or errors.<br />
Highlights BenQ PE7700<br />
● Real 16:9 panel for original<br />
16:9 wide-screen format<br />
● 2.500:1 Contrast<br />
● 6 Segment colour wheel for brilliant<br />
colours<br />
● HDMI connection (with HDCP) for<br />
connecting digital signal sources<br />
BenQ PE7700<br />
Resolution : 1,280 x 720 (16:9)<br />
Technology: DLP<br />
Light output approx.: 1,100 ANSI lumens<br />
Contrast approx.: 2,500:1<br />
Operating noise: 26 dB (eco mode)<br />
Code No. 1000PE7700 price on request<br />
Image Size Chart BenQ PE7700<br />
Projection distance approx.Image width approx.<br />
1.35 – 1.83 m 1.00 m<br />
2.70 – 3.66 m 2.00 m<br />
4.05 – 5.49 m 3.00 m<br />
5.40 – 7.32 m 4.00 m
1) TV Tuner<br />
● Display of television programmes, video<br />
signals of cameras, game consoles, LCD<br />
screens, plasma displays via projector<br />
● Video text function<br />
● Resolution of up to 1,280 x 1,024 pixels<br />
● Functions like picture-in-picture as well as<br />
progressive scan and de-interlacing<br />
● VGA input and output, S-Video,<br />
Component (via S-Video), antenna input,<br />
stereo/audio in- and output<br />
● Supplied remote control allows control of<br />
all functions such as setting of image<br />
quality, auto-scanning and fine tuning of<br />
all TV channels or managing the channel<br />
storage<br />
Code No. 190019<br />
2) Universal Ceiling Mount Home<br />
● For universal usage thanks to variable<br />
mounting arms<br />
● Flexible arrangement thanks to ball and<br />
socket joints<br />
● Fixed length of 15 cm<br />
● Load capacity up to 25 kg<br />
Code No. 22020<br />
3) MEDIUM Movielux Electric Design<br />
● <strong>The</strong> attractive screen for home cinema<br />
entertainment<br />
● Projection surface available in 4:3 video or<br />
16:9 wide screen format<br />
● Black screen border for projections richer<br />
in contrast<br />
● Especially shapely, oval aluminium casing<br />
● Maintenance-free, quiet electric motor<br />
● Projection surface infinitely adjustable<br />
Code numbers and formats can be found on<br />
page 90.<br />
4) MEDIUM easyfixx comfort<br />
● Revolutionary development in the field of<br />
mobile screens; wall mount also allows<br />
fixed installation<br />
● An unparalleled lightweight: weighs no<br />
more than approx. 3000 g<br />
● Ultramobile: compact dimensions and<br />
instant set-up in no time at all thanks to<br />
an easy assembly system<br />
● A special tensioning mechanism provides<br />
perfect flatness of the screen surface<br />
● Space-saving: in set-up, transport and<br />
storage<br />
● 4-point base for smallest footprint and<br />
good stability<br />
● Black border reinforcing – 5 cm – for clean<br />
edges, makes the projection richer in<br />
contrast<br />
Code numbers and formats can be found on<br />
page 75.<br />
1<br />
2<br />
3<br />
4<br />
Home Cinema<br />
37
LCD Displays<br />
38<br />
NEC LCD Display Solutions –<br />
up-to-date large format communication<br />
Highlights<br />
● Ideal for lounges, show or control rooms,<br />
exibitions<br />
● Low running cost thanks to intelligent<br />
power management<br />
● Flexible installation options in landscape<br />
or portrait<br />
● Brilliant image quality even with bright<br />
ambient light<br />
● Fully-equipped interface panel - no further<br />
connection modules required<br />
● Video walls possible up to a maximum of<br />
5x5 (LCD 3210 max. 4x4) with the help of<br />
the integrated electronics<br />
● Integrated timer for automatic control<br />
(on/off/source) on day and week basis<br />
● Easy transport and installation<br />
Accessories<br />
Loudspeaker, at the sides<br />
2x 7 Watt, for LCD3210<br />
Code No. 1003210-LS<br />
Loudspeaker, at the sides<br />
2x 80 Watt for LCD4010<br />
Code No. 1004010-LS<br />
Loudspeaker, at the sides<br />
2x 80 Watt for LCD4610<br />
Code No. 1004610-LS<br />
Wall mount, rigid<br />
Code No. 23000<br />
LCD3210 LCD4010 LCD4610<br />
Display Technology S-IPS PVA TFT PVA TFT<br />
Resolution (native) 1,366 x 768 1,366 x 768 1,366 x 768<br />
Aspect ratio 16:9 16:9 16:9<br />
Light output (typ.) cd/m 2 500 500 500<br />
Contrast (typ.) 600:1 800:1 800:1<br />
Usable image size W /H cm 70.07 / 39.55 88.52 x 49.76 101.84 / 57.25<br />
Viewing angle (typ.) 176 °/176° 170 °/170° 170 °/170°<br />
TileMatrix, max. 4 x 4 5 x 5 5 x 5<br />
Input PC 1x 15 pin D-Sub 1x 15 pin D-Sub 1x 15 pin D-Sub<br />
1x BNC 1x BNC 1x BNC<br />
1x DVI-D 1x DVI-D 1x DVI-D<br />
Output PC 1x 15 pin D-Sub 1x BNC (RGBHV) 1x BNC (RGBHV)<br />
Input Video 1x FBAS 1x FBAS 1x FBAS<br />
1x Y/C 1x Y/C 1x Y/C<br />
1x Component 1x Component 1x Component<br />
for further connections refer to: www.medium.de<br />
*Approx. W/H/D in cm 78.9 /47.9 /14.0 98.18 /57.98 /14.0 111.28 /65.58 /14.0<br />
*Approx. weight in kg 15.2 27.5 31.0<br />
Price on request on request on request<br />
Code No. 1003210 1004010 1004610<br />
*Dimensions and weight without base Subject to technical change and errors.<br />
Wall mount, inclinable<br />
maximum 20°<br />
Code No. 23001<br />
Display Trolley<br />
Height at the display centre approx. 150 cm<br />
Code No. 23022
Professional Plasma Displays – drawing attention<br />
Superior image quality up to a picture<br />
diagonal of 165 cm<br />
<strong>The</strong> new 8-series by Panasonic boast the<br />
industry’s currently best daylight contrast<br />
values, top brightness and the finest shades<br />
of gradation. <strong>The</strong> enhanced colour spectrum<br />
from 3.6 to 8.6 billion displayable colours<br />
provides brilliant pictures that immediately<br />
draw attention. <strong>The</strong> new Slim Line Design of<br />
the models 42” and 50” with an unobtrusive<br />
frame of only 2 cm give the displays an<br />
elegant look . Thanks to their long life with<br />
60,000 operating hours and their excellent<br />
integration options based on a wide variety<br />
of solutions and modular interfaces, the<br />
Panasonic displays range among the<br />
favourites in all professional environments.<br />
HDTV formats<br />
<strong>The</strong> PHD models are well-prepared for highresolution<br />
TV formats. Optionally available<br />
digital boards make these displays comply<br />
with HDready standard and they are thus<br />
compatible to all HD formats like 1080i and<br />
720p in 50 and 60 Hz.<br />
Flexible Solutions Thanks to Slot-in System<br />
<strong>The</strong> interfaces of the Panasonic Plasma<br />
Displays can easily be exchanged thanks to<br />
the well-proven slot system. <strong>The</strong> slot accepts<br />
terminal boards for the most diverse signal<br />
sources from Composite over<br />
RGB/Component video up to digital<br />
DVI/HDMI and HD-SDI signals. Even the<br />
integration of an entire PC for intelligent<br />
network applications is possible (PDP<br />
controller VC-250).<br />
Highlights NEW 8-Series<br />
● 8.6 Billion colours<br />
● HDready with opt. boards (HDMI/DVI)<br />
● Contrast ratio of up to 4,000:1<br />
● Long-life panel with 60.000 operat. hours<br />
● Several terminal boards (analogue and<br />
digital)<br />
● E.g. 4,096 shades of gradation via DVI<br />
● Deep black filter<br />
● Picture-in-picture function<br />
● Numerous energy-saving functions<br />
TH-65PHD8EK TH-50PHD8EK/ES TH-42PHD8EK/ES TH-42PWD8EK/ES<br />
Picture diagonal 165 cm 127 cm 106 cm 106 cm<br />
Resolution (native) 1,366 x 768 1,366 x 768 1,024 x 768 852 x 768<br />
Light output (typ.) cd/m 2 900 1,000 1,100 1,200<br />
Contrast (typ.) 3,000:1 3,000:1 3,000:1 4,000:1<br />
Approx. weight in kg 78 43 31.5 29.5<br />
Code No. 100TH65 100TH50-4 100TH42-10 100TH42-7<br />
100TH50-3 100TH42-9 100TH42-8<br />
Optionally available: a comprehensive range of accessories like wall holders, floor stands, loudspeakers and<br />
terminal boards.<br />
<strong>The</strong> Slim Line Design<br />
with an unobtrusive<br />
frame of merely 2 cm<br />
gives the displays their<br />
particularly elegant<br />
look.<br />
Flexible solutions<br />
thanks to slot-in<br />
system.<br />
Connections<br />
fixed<br />
integrated<br />
interface slot 3 slot 2<br />
slot 1 (preset<br />
with TY-<br />
42TM6B)<br />
Plasma Displays<br />
39
Accessories LCD/Plasma Displays<br />
40<br />
Universal Mounts for Plasma and LCD Displays<br />
Plasma Floor Stand FH T<br />
● Display can be set up in either landscape<br />
or portrait format<br />
● Concealed cable duct<br />
● Display tilt of +10°/-3°<br />
● Incl. 3-way mains socket<br />
● Maximum weight: 100 kg<br />
● A shelf is optionally available<br />
● Both the display and the shelf are heightadjustable<br />
● Universal adapter H UniSlide is required<br />
for fixing the display to the stand; needs<br />
to be ordered separately<br />
● Colour: anodised aluminium<br />
FH T1150<br />
Height: 112.5 cm (display centre)<br />
Code No. 22501<br />
FH T1450<br />
Height: 142. cm (display centre)<br />
Code No. 22502<br />
FH T2000<br />
Height: 197.5 cm (display centre)<br />
Code No. 22503<br />
Display set up<br />
in landscape format<br />
Table Stand TH F<br />
Display set up<br />
in portrait format<br />
● Height: 55 cm (display centre)<br />
● Display tilt -3°<br />
● Maximum weight: 100 kg<br />
● Universal adapter H UniSlide is required<br />
for fixing the display to the stand; needs<br />
to be ordered separately<br />
● Colour: anodised aluminium<br />
Code No. 22504<br />
Trolley FH MT<br />
● Concealed cable duct<br />
● Display tilt +10°/-3°<br />
● Incl. 3-way mains socket<br />
● Maximum weight: 100 kg<br />
● Shelf and base plate are optionally<br />
available<br />
● Both the display and the shelf are heightadjustable<br />
● Universal adapter H UniSlide is required<br />
for fixing the display to the stand; needs<br />
to be ordered separately<br />
● Colour: anodised aluminium<br />
FH MT1150<br />
Height: 123 cm (display centre)<br />
Code No. 22505<br />
FH MT1450<br />
Height: 153 cm (display centre)<br />
Code No. 22506<br />
FH MT2000<br />
Height: 208 cm (display centre)<br />
Code No. 22507<br />
Wall Mount WH 3D<br />
● Distance from wall: 10.6 cm (folded) /<br />
70 cm (extended)<br />
● 90° swivel and 10° tilt (depending on<br />
display model)<br />
● Maximum weight: 50 kg<br />
● Universal adapter H UniSlide is required<br />
for fixing the display to the stand; needs<br />
to be ordered separately<br />
● Colour: silver<br />
Code No. 22508<br />
Special colours are available upon request.<br />
Wall Mount WH T<br />
● Tilt of 10° possible<br />
● Maximum weight: 100 kg<br />
● Incl. universal adapter H UniSlide<br />
● Colour: silver<br />
Code No. 22509<br />
Ceiling Mount CH VST2<br />
● Variable height from 85.5 up to 145.5 cm<br />
(display centre)<br />
● Concealed cable duct<br />
● 360° swivel and 25° tilt<br />
● Maximum weight: 100 kg<br />
● Universal adapter H UniSlide is required<br />
for fixing the display to the stand; needs<br />
to be ordered separately<br />
● Colour: silver<br />
Code No. 22510<br />
Universal Adapter H UniSlide<br />
● Suitable for most makes and models<br />
● Maximum weight: 50 kg<br />
Colour: silver<br />
Code No. 22500<br />
Shelves for FH T and FH MT<br />
Black Code No. 22511<br />
Grey Code No. 22512<br />
Beech Code No. 22513<br />
Birch Code No. 22514<br />
Plexiglass Code No. 22515<br />
Base Plates for FH MT<br />
Black Code No. 22516<br />
Grey Code No. 22517<br />
Beech Code No. 22518<br />
Birch Code No. 22519
1<br />
1) Universal Projector Mount CL V<br />
● Smart design<br />
● Concealed cable duct<br />
● Suited for ceiling-mounting at ceilings<br />
with a tilt of up to 30°<br />
● Maximum weight: 12 kg<br />
● Universal adapter UniSlide is required for<br />
fixing the projector; needs to be ordered<br />
separately<br />
● Colour: aluminium/silver finish<br />
CL V 300-350<br />
Infinitely variable length from 30 to 35 cm<br />
Code No. 22531<br />
CL V 500-750<br />
Infinitely variable length from 50 to 75 cm<br />
Code No. 22532<br />
CL V 650-900<br />
Infinitely variable length from 65 to 90 cm<br />
Code No. 22533<br />
CL V 850-1100<br />
Infinitely variable length from 85 to 110 cm<br />
Code No. 22534<br />
12 kg<br />
Universal Projector Mounts –<br />
for any projector up to 12 kg<br />
2) Universal Projector Mount CL F<br />
● Flexible Design<br />
● Concealed cable duct<br />
● Maximum weight: 12 kg<br />
● Universal adapter UniSlide is required for<br />
fixing the projector; needs to be ordered<br />
separately (only included with CL F 75)<br />
● Colour: aluminium/silver finish<br />
CL F 75<br />
Fixed length of 15 cm<br />
Length cannot be shortened<br />
Includes Universal Adapter UniSlide<br />
Code No. 22535<br />
CL F 500<br />
Fixed length of 57.5 cm<br />
If required mount can be shortened to the<br />
desired length<br />
Code No. 22536<br />
CL F 1000<br />
Fixed length of 107.5 cm<br />
If required mount can be shortened to the<br />
desired length<br />
Code No. 22537<br />
CL F 1500<br />
Fixed length of 157.5 cm<br />
If required mount can be shortened to the<br />
desired length<br />
Code No. 22538<br />
2<br />
Special lengths and colours are available upon request.<br />
3) Projector Wall Mount WL V<br />
● Infinitely variable length up to 40 cm<br />
● Maximum weight: 12 kg<br />
● Universal adapter UniSlide is required for<br />
fixing the projector; needs to be ordered<br />
separately<br />
● Colour: aluminium/black<br />
Code No. 22539<br />
3<br />
4) Universal Adapter Unislide<br />
● Flexible adjustment thanks to ball joint<br />
● 360° swivel and 25° tilt<br />
● Colour: silver finish<br />
Code No. 22530<br />
4<br />
Accessories Digital Projectors<br />
41
Accessories Digital Projectors<br />
42<br />
Electrical Ceiling Lift for Digital Projectors –<br />
for convenient ceiling mounting<br />
Highlights<br />
● Product update: increased operation<br />
speed, RS-232 interface, new control unit,<br />
user-friendly remote control<br />
● For universal usage with all current<br />
projectors up to the portable category<br />
● Ceiling mounting: aesthetic and protects<br />
against theft<br />
● Space-saving mounting of only 28 cm (incl.<br />
a small projector)<br />
● Projection height can be exactly<br />
programmed and changed with the<br />
supplied IR remote control<br />
● Extremely safe thanks to a wear-free, quiet<br />
universal joint mechanism<br />
● Optimal placement of the projector thanks<br />
to movable support points<br />
● Secure projector foothold thanks to a belt<br />
fastening<br />
● Integrated cable duct<br />
● Maximum load: 20 kg<br />
● Dimensions: see graphic<br />
Fields of Application<br />
<strong>Conference</strong> rooms, training rooms,<br />
showrooms etc.<br />
Delivery Standard:<br />
● Ceiling lift<br />
● Ceiling mounting plates<br />
● IR remote control / IR receiver<br />
● Manual<br />
Code No. 22400<br />
Universal Ceiling Lift XL<br />
Identical with Code No. 22400 but:<br />
● 135 cm lift<br />
● Approx. 50 cm mounting height<br />
Code No. 22400-XL<br />
Available upon request<br />
● Fire- and thief-proof ceiling mounting<br />
chest (only available for Code No. 22400)<br />
● Ceiling finishing kit<br />
6,7<br />
20 kg<br />
47,9 56,6<br />
46,3<br />
42<br />
(34)<br />
44<br />
(36)<br />
51,4<br />
<strong>The</strong> ceiling lift is TÜV/GS/CE-certified.<br />
50<br />
can be<br />
shortened as<br />
required<br />
70<br />
28<br />
folded<br />
Low mounting<br />
height of 28 cm<br />
All dimensions in cm. Green measurements<br />
(dimensions of the projector’s bearing surface): 34 cm<br />
with cable connection at the back/front respect. 36 cm<br />
with cable connection at the sides. Red measurements<br />
are dimensions of the ceiling lift.
Universal Ceiling Mount –<br />
for all projectors up to 25 kg<br />
Highlights<br />
● Infinitely height-adjustable mount made of<br />
scratch-resistant, high-quality aluminium<br />
● For universal use thanks to variable<br />
mounting arms<br />
● Optimal projector ventilation thanks to<br />
standoff bolt<br />
● Flexible tilting thanks to ball and socket<br />
joints<br />
● Maximum load: up to 25 kg<br />
Delivery Standard of all three models:<br />
mounting, screw stands in different sizes,<br />
mount screws and assembly instruction<br />
Special lengths and colours are available<br />
upon request.<br />
For detailed dimensioned drawings click on<br />
www.medium.de.<br />
4<br />
1) Home<br />
● Fixed length of 15 cm<br />
● Low weight: only 1 kg<br />
Code No. 22020<br />
2) Standard<br />
● Unobtrusive cable duct for hiding cables<br />
● Infinitely variable length from 40 to 70 cm<br />
● Mechanical fall arrester<br />
● Low weight: only 1.5 kg<br />
Code No. 22023<br />
3) Standard<br />
Identical with Code No. 22023<br />
● Infinitely variable length from 60 to 110<br />
cm<br />
● Mechanical fall arrester<br />
● Low weight: only 2 kg<br />
Code No. 22021<br />
4) Exclusive<br />
● Angle assembly of up to 90 degrees is<br />
possible<br />
● Easy mounting thanks to quick tension<br />
device<br />
● Cable channel to hide cables<br />
● Infinitely variable length from 67 to 110<br />
cm<br />
● Mechanical fall arrester<br />
● Low weight: only 3 kg<br />
25 kg<br />
All mounts are supplied in RAL colour 7035 (grey) and are TÜV/GS-certified.<br />
1<br />
Ceiling Mount Home<br />
2 3 4<br />
Cable channel to hide cables<br />
1 2 3 4<br />
4 universally adjustable mounting arms for all three<br />
models<br />
Accessories Digital Projectors<br />
43
Presentation Aids<br />
44<br />
1<br />
Electronic Presentation Aids<br />
Radio-controlled – for professionals<br />
<strong>The</strong> radio-controlled mice and keyboards as<br />
offered by MEDIUM are just the right<br />
presentation aids for controlling the<br />
audience’s attention. All products allow you<br />
to move about freely in the room since they<br />
work with radio technology.<br />
Control of the mouse cursor<br />
All Gyration products use the GyroPoint<br />
Technology for controlling the mouse cursor.<br />
This technology converts hand movements<br />
directly into a mouse motion thus allowing a<br />
precise control of the mouse cursor. A mouse<br />
pad is not required.<br />
Focussing the Attention<br />
For focussing the attention of the audience<br />
on certain aspects, additional programmes<br />
can be used that allow the presenter to<br />
conceal (curtain), emphasize (highlighter) or<br />
enlarge (zoom) certain parts of the<br />
presentation to name but a few functions.<br />
Comparison Chart<br />
2<br />
Gyration Highlights<br />
1) Gyration AirMouse GC615MCE<br />
2)Gyration AirMouse Compact<br />
Keyboard Suite GC715MCKDE<br />
3) Gyration AirMouse Full-Size<br />
Keyboard Suite GC815MFKDE<br />
3<br />
● Control of the mouse cursor through the<br />
movement of your hand (GyroPoint-<br />
Technology)<br />
● Full-function desktop mouse thus also to<br />
be used on your desk<br />
● An unlimited number of units may be<br />
connected to one common receiver<br />
● Also available in combination with radio<br />
keyboards in compact and standard<br />
design<br />
AirMouse AirMouse AirMouse GyroTransport<br />
GP615MCE Compact Full-Size<br />
Keyboard Suite Keyboard Suite<br />
GP715MCKDE GP815MFKDE<br />
Approx. link distance in m 30 30 30 30<br />
Hand mouse control Gyroscope Gyroscope Gyroscope Gyroscope<br />
Table mouse control Laser Laser Laser no<br />
Programmable Special Functions<br />
1 1 2<br />
1 3<br />
4<br />
Mouse keys yes yes yes yes<br />
Hand motion yes yes yes yes<br />
Function keys 2 2 2 no<br />
Laser pointer virtual virtual virtual virtual<br />
USB flash memory no no no 1 GByte<br />
Supplied with GyroTools GyroTools GyroTools GyroTools<br />
presentation Presentation Presentation Presentation Presentation<br />
software Edition Edition Edition Edition<br />
Code No. 20110 20111 20112 20130<br />
4) Gyration GyroTransport<br />
● GyroTools work with Windows XP<br />
straight from the USB receiver without<br />
pre-installation<br />
● Extremely handy format, can be taken<br />
along in any bunch of keys<br />
● USB receiver with 1 GByte memory for<br />
PowerPoint presentations or other data<br />
● Compatible to the AirMouse product<br />
line<br />
Detailed information on the individual products can be found on www.medium.de. Subject to technical changes without notice and errors.<br />
4<br />
Special function<br />
“curtain“ to partly<br />
conceal the<br />
presentation<br />
Special function<br />
“highlight“ to point out<br />
certain aspects<br />
Special function<br />
“spotlight“<br />
Special function<br />
“pointer“
5<br />
7<br />
5) MEDIUM LaserMouse<br />
6) Interlink Pilot Pro<br />
7) RemotePoint Navigator<br />
8) RemotePoint Global Presenter<br />
● Sleek design<br />
● Integrated laser pointer<br />
● Compact dimensions, ideally suited for<br />
mobile use<br />
Comparison Chart<br />
6<br />
5 6 7 8<br />
MEDIUM Pilot Pro RemotePoint RemotePoint<br />
LaserMouse Navigator Global Presenter<br />
Approx. link distance in m 10 15 15 30<br />
Hand mouse control track point track point no track point<br />
Table mouse control no no no no<br />
Programmable Special Functions<br />
8<br />
Nota bene: All products on this page only work with a computer that has a free USB interface. <strong>The</strong> required operating system<br />
needs to be Microsoft Windows 98 SE, Windows Me, Windows 2000 or Windows XP.<br />
Mouse keys no no no no<br />
Hand motion no no no no<br />
Function keys no blanking blanking blanking<br />
Laser pointer ja ja ja ja<br />
USB flash memory<br />
Supplied with<br />
no no no no<br />
presentation software no no no no<br />
Code No. 200025 200034 200030 200032<br />
Detailed information on the individual products can be found on www.medium.de.<br />
Interlink GoSpeak! – active speakers<br />
giving sound to your message<br />
Interlink GoSpeak! Highlights<br />
● Compact dimensions, instant and easy<br />
set-up for mobile use, supplied with a<br />
transport case<br />
● Connections for a microfone, line-in and<br />
line-out, separate adjuster for total volume<br />
and line-in, mute key<br />
● NXT flat panel speaker for clear,<br />
volumetric sound, language optimized<br />
frequency response<br />
● Suitable for acoustic irradiation of rooms<br />
with up to 200 people<br />
Technical Data<br />
● Frequency response: 100 Hz–10 kHz ±3 dB<br />
● Line-in: 1 Vss at 50 kOhm impedance<br />
● Audio output: 2 x 40 Watt<br />
● Input sensitivity:<br />
-55 dB ± 2 dB (0 dB = 1 Vss)<br />
● Weight: 2.2 kg<br />
● Dimensions H/W/D: 22/34/6.5 cm<br />
InterLink GoSpeak!<br />
Code No. 200036 price on request<br />
34<br />
6,5<br />
22<br />
HITACHI Bluetooth<br />
Tablet – interactive<br />
presentation<br />
HITACHI Interactive Bluetooth Tablet<br />
Freedom with wireless presentations<br />
● Particularly suited for presentations and<br />
trainings<br />
● Light and compact like a writing pad<br />
● Pen replaces the mouse: free moving<br />
about the room and interactive input from<br />
the audience is possible<br />
● Simple connection to the PC: via Bluetooth<br />
or USB cable<br />
● To be used with or without the HITACHI<br />
interactive board or panel (cf pages 50/51)<br />
Delivery Standard<br />
Tablet, electronic pen, Bluetooth receiver,<br />
USB cable, USB extension, software and<br />
driver CD, charger, 4 rechargeable batteries,<br />
2 replacement pen tops, manual<br />
Technical Data<br />
Working area: 152 x 114 mm<br />
Weight: 470 g<br />
Range: approx. 10 m (in Bluetooth mode)<br />
Code No. 10330<br />
See further HITACHI interactive products<br />
on pages 50/51.<br />
Presentation Aids<br />
45
Accessories Digital Projectors<br />
46<br />
Cables and Signal Distribution<br />
RGB Connecting Cable<br />
● Standard quality<br />
● 15p.D-sub connector/15 p.D-sub connector<br />
● 3x coaxial + 7x copper core<br />
● double shielded, full metal cover<br />
● Cable colour: black<br />
Length Code No.<br />
3.00 m 1955-3<br />
5.00 m 1955-5<br />
10.00 m 1955-10<br />
15.00 m 1955-15<br />
20.00 m 1955-20<br />
30.00 m 1955-30<br />
50.00 m 1955-50<br />
RGB Extension Cable<br />
● Standard quality<br />
● 15p.D-sub jack/15p.D-sub connector<br />
● 3x coaxial + 7x copper core<br />
● double shielded, full metal cover<br />
● Cable colour: black<br />
Length Code No.<br />
3.00 m 1956-3<br />
5.00 m 1956-5<br />
10.00 m 1956-10<br />
15.00 m 1956-15<br />
20.00 m 1956-20<br />
30.00 m 1956-30<br />
50.00 m 1956-50<br />
RGB Connecting Cable<br />
● Extra quality<br />
● Halogen-free, flame-retardant<br />
● 15p.D-sub connector/15 p.D-sub connector<br />
● 4x coaxial + 6x copper core<br />
● double shielded, full metal cover<br />
● Cable colour: green<br />
Length Code No.<br />
5.00 m 1954-20<br />
10.00 m 1954-21<br />
15.00 m 1954-22<br />
20.00 m 1954-23<br />
Special lengths on request<br />
DVI-A Connecting Cable<br />
● Extra quality<br />
● Halogen-free, flame-retardant<br />
● 4x coaxial + 6x copper core<br />
● 15p.D-sub connector/DVI-A connector<br />
● Cable colour: green<br />
Length Code No.<br />
5.00 m 1954-24<br />
10.00 m 1954-25<br />
15.00 m 1954-26<br />
AV Connecting Cable<br />
● Extra quality<br />
● 3x RCA connector / 3x RCA connector<br />
● 1x0.4 mm 2 HF, 2x0.08 mm 2 (both coaxial)<br />
● High quality golden connectors<br />
Length Code No.<br />
5.00 m 1954-11<br />
10.00 m 1954-12<br />
15.00 m 1954-13<br />
20.00 m 1954-14<br />
Special lengths up to 60 m on request<br />
S-Video Connecting Cable<br />
● Extra quality<br />
● 1x Hosiden connector/1x Hosiden connec.<br />
● 2 x 0 1 mm 2 coaxial<br />
● High quality golden connectors<br />
Length Code No.<br />
5.00 m 1954-6<br />
10.00 m 1954-7<br />
15.00 m 1954-8<br />
20.00 m 1954-9<br />
Special lengths up to 30 m on request<br />
RGB Distributor (active)<br />
● 1 Input (15 p. D-subconnector)<br />
● 2 Outputs (15 p. D-sub jack)<br />
● Max. 1,920 x 1,440 at 85 Hz<br />
● Max. 65 m cable length (approx.)<br />
Code No. 1952-VS1<br />
RGB Distributor (active)<br />
● 1 Input (15 p. D-subconnector)<br />
● 4 Outputs (15 p. D-sub jack)<br />
● Max. 1,920 x 1,440 at 85 Hz<br />
● Max. 65 m cable length (approx.)<br />
Code No. 1952-VS4<br />
Adapter DVI-A to 15 p. D-sub<br />
● 12 + 5 DVI-A connector / 15 p. D-sub jack<br />
Code No. 1957-V<br />
RGB-/CAT 5 Converter (active)<br />
● Transfer of RGB signals via CAT 5 cable<br />
● Max. 1,280x1,024 at 85Hz<br />
● Max. 80 m CAT 5 cable length<br />
Code No. 1954-CAT<br />
MEDIUM Desktop Switch81 (active)<br />
● 8 Inputs (15 p. D-sub connector)<br />
● 1 Output (15 p. D-sub jack)<br />
● Max. 2,048 x 1,536<br />
● Max. 200 MHz band width<br />
● Max. 65 m cable length (approx.)<br />
Code No. 1960-DTS81
DVI-D Connecting Cable<br />
● Standard quality<br />
● Dual link up to max. 2,048 x 1,536 pixels<br />
● 24+1 connector / 24+1 connector<br />
● Pixel clock max. 330 MHz<br />
Length Code No.<br />
1.80 m 1957<br />
3.00 m 1957-3<br />
5.00 m 1957-5<br />
10.00 m 1957-10<br />
DVI-D Extension Cable<br />
● Standard quality<br />
● Dual link up to max. 2,048 x 1,536 pixels<br />
● 24+1 connector / 24+1 jack<br />
● Pixel clock max. 330 MHz<br />
Length Code No.<br />
1.80 m 1957-11<br />
3.00 m 1957-12<br />
5.00 m 1957-13<br />
10.00 m 1957-14<br />
DVI-I Connecting Cable<br />
● Standard quality<br />
● Dual link up to max. 2,048 x 1,536 pixels<br />
● 24+5 connector / 24+5 connector<br />
● Pixel clock max. 330 MHz<br />
Length Code No.<br />
1.00 m 1957-15<br />
3.00 m 1957-16<br />
5.00 m 1957-17<br />
10.00 m 1957-18<br />
HDMI Connecting Cable<br />
● Standard quality<br />
● Video data max. 165 Mhz<br />
● Audio data max. 192 kHz<br />
● HDMI connector / HDMI connector<br />
Length Code No.<br />
2,00 m 1957-20<br />
3,00 m 1957-21<br />
5,00 m 1957-22<br />
HDMI / DVI-D Adapter Cable<br />
● Standard quality<br />
● Video data max. 165 MHz<br />
● No audio<br />
● HDMI connector / 18+1 connector<br />
Länge Code No.<br />
2.00 m 1957-23<br />
3.00 m 1957-24<br />
5.00 m 1957-25<br />
DVI-D Distributor 1/2 (active)<br />
● 1 Input (DVI-D 24+1 jack)<br />
● 2 Outputs (DVI-D 24+1 jack)<br />
● Video band width max. 165 MHz<br />
(VGA-UXGA)<br />
● max. 1,920x1,200 at 60 Hz<br />
● max. 10 m cable length (approx.)<br />
Code No. 1959-VS1<br />
DVI-D Distributor 1/4 ( active)<br />
● 1 Input (DVI-D 24+1 jack)<br />
● 4 Outputs (DVI-D 24+1 jack)<br />
● Video band width max. 165 MHz<br />
(VGA-UXGA)<br />
● max. 1,920x1,200 at 60 Hz<br />
● max. 10 m cable length (approx.)<br />
Code No. 1959-VS4<br />
IPL System<br />
For the integration into standard cable channels<br />
(wall/floor) according to VDE specification.<br />
Type and number of connections can be<br />
chosen individually. Solderless mounting<br />
since all connections are readily converted<br />
(30 cm cable, soldered on both sides).<br />
Supports nearly all connector systems i.a.<br />
Sub-D, DVI, Cinch, Hosiden, BNC, 3.5mm<br />
jack, RJ45<br />
IPL Support Frame<br />
● Made of anodised aluminium for accepting<br />
up to 3 slots incl. fixing material<br />
Code No. 1954-IPL213<br />
IPL Cover Frame<br />
● Cover frame (anodised aluminium)<br />
Type Code No.<br />
3 Slot 1954-IPL200<br />
6 Slot 1954-IPL201<br />
9 Slot 1954-IPL202<br />
IPL Blind Slot<br />
● Blind slot made of anodised<br />
aluminium incl. fixing material<br />
Type Code No.<br />
1 Slot width 1954-IPL210<br />
2 Slot width 1954-IPL211<br />
3 Slot width 1954-IPL212<br />
IPL Signal Slots Computer / Audio<br />
● Support frame made of anodised<br />
aluminium, one slot width incl. 30 cm cable<br />
piece readily converted<br />
Length Code No.<br />
1x VGA 15p. D-sub ja./ja. 1954-IPL260<br />
1x VGA 15p. D-sub ja./ja.<br />
1x 3.5 mm stereo plug<br />
jack/jack 1954-IPL266<br />
1x DVI-A jack/jack 1954-IPL268<br />
1x DVI-D jack/jack 1954-IPL270<br />
IPL Signal Slots Video / Audio<br />
● Support frame made of anodised aluminium,<br />
one slot width incl. 30 cm cable<br />
piece readily converted<br />
Length Code No.<br />
1x RCA video jack/jack 1954-IPL224<br />
3x RCA video/<br />
audio jack/jack 1954-IPL234<br />
1x S-Video jack/jack 1954-IPL239<br />
1x S-Video jack/jack<br />
1x 3.5 mm plug<br />
stereo jack/jack 1954-IPL247<br />
Further IPL signal slots (computer, audio,<br />
video, USB, serial, PS2, LAN, ISDN etc.) are<br />
available upon request.<br />
Accessories Digital Projectors<br />
47
Accessories Digital Projectors<br />
48<br />
Clever Multimedia Accessories<br />
TV Tuner<br />
<strong>The</strong> MEDIUM TV Tuner (TV Box 9) allows you<br />
to show television programmes and also<br />
video signals from cameras and game<br />
consoles on LCD screens, plasma displays or<br />
via a projector.<br />
● Video text function<br />
● Functions like picture-in-picture as well as<br />
progressive scan and de-interlacing<br />
● VGA input and output, S-Video,<br />
Component (via S-Video), antenna input,<br />
stereo/audio in- and output<br />
● Supplied remote control allows control of<br />
all functions such as setting of image<br />
quality, auto-scanning and fine tuning of<br />
all TV channels or managing the channel<br />
storage<br />
● Resolution of up to 1,280 x 1,024 pixels<br />
● Dimensions: 2.5/11.5/16 cm (H/W/D)<br />
● Incl. remote control<br />
Code No. 190019<br />
Anti-<strong>The</strong>ft Protection<br />
● Kensington lock<br />
● <strong>The</strong> anti-theft protection for your projector<br />
or your laptop<br />
● Lock with key<br />
● Length of the steel cable: 1.5 m<br />
Code No. 1908-4<br />
Anti-<strong>The</strong>ft Protection<br />
● With alarm system<br />
● If the steel cable is cut or the projector is<br />
moved an alarm signal of 105 dB resounds<br />
● Security thanks to a combination lock with<br />
10,000 possible combinations<br />
● Blinking LED display indicates that the<br />
alarm is set<br />
● Self-recoiling, unsliceable, stainless steel<br />
cable<br />
● Variable cable length of up to 90 cm<br />
Code No. 1908-5<br />
Travel Bag<br />
Classical travel bag for projector/laptop in<br />
solid workmanship and precious design.<br />
● Padded travel bag for safe transport of<br />
projector and laptop<br />
● Trolley handle extensible up to 90 cm<br />
● Pocket on the rear side<br />
● Different compartments for cables and<br />
accessories<br />
● Zipper compartment at the front of the<br />
travel bag<br />
● Adjustable shoulder strap with pad<br />
● Stable leather handle<br />
● Plastic feet at the bottom<br />
● Allowed as hand luggage in the aircraft<br />
● Travel bag for projectors up to 8/33/26 cm<br />
(H/W/D)<br />
● External dimensions of the travel bag:<br />
34/38/21.5 cm (H/W/D)<br />
● Material: polyester/nylon, leather handle<br />
● Weight: 3.1 kg<br />
Without MEDIUM logo<br />
Code No. 1185-09
Laser Pointer –<br />
draw full attention to your message!<br />
Green Laser Pointers<br />
● <strong>The</strong>y exceed the brightness performance<br />
of red laser pointers by far<br />
● Particularly suited for use in bright and<br />
large rooms<br />
● Approx. range 200 m<br />
1) Laser Green<br />
● Incl. black metal case<br />
● Incl. batteries: 2 x 1.5 V AAA micro<br />
Length approx. 14 cm<br />
Diameter approx. 1.2 cm<br />
Weight: approx. 72 g incl. batteries<br />
Code No. 192101<br />
2) Laser Green II<br />
● Incl. case<br />
● Incl. batteries: 2 x 1.5 V AAA micro<br />
Length approx. 15.4 cm<br />
Diameter approx. 1.8 cm<br />
Weight: approx. 78 g incl. batteries<br />
Code No. 192102<br />
3<br />
1<br />
Red Laser Pointers<br />
● Approx. range 100 m<br />
3) Laser Delta<br />
● Laser pointer for professionals:<br />
Perfect presentations with a steady hand<br />
● Select between a constant beam or a<br />
blinking light dot<br />
● Benefits of the blinking function:<br />
– increases audience attention<br />
– saves energy<br />
● Material: black plastic with red decor<br />
Excl. batteries: 4 x 1.5 V AAA micro<br />
Weight: approx. 110 g incl. batteries<br />
Code No. 192120<br />
4<br />
2<br />
4) Pen Laser<br />
Unique:<br />
Ultra-bright Laser Green<br />
● Material: brass, black<br />
● Incl. batteries: 2 x 1.5 V AAA micro<br />
Weight: approx. 44 g incl. batteries<br />
Code No. 192150<br />
5) Laser Classic<br />
Classic, elegant laser pointer with integrated<br />
ball pen<br />
● Material: silver-coloured metal<br />
● Incl. batteries: 3 x 1.55 V SR 41 button cell<br />
Weight: approx. 30 g incl. batteries<br />
Code No. 192160<br />
All MEDIUM Laser Pointers are Laser Class 2<br />
and certified according to DIN EN 60 825-1.<br />
5<br />
Accessories Digital Projectors<br />
49
Interactive Presentation<br />
50<br />
Highlights<br />
Fields of Application<br />
● School classes, trainings, team work in<br />
smaller groups<br />
● Video conferences: saves travel expenses<br />
● Data can instantly be processed and saved<br />
during the training or meeting<br />
● Wireless data transfer from pen to board<br />
via ultrasound/infrared in high speed:<br />
approx. 66 points/sec.<br />
● Wireless Bluetooth data transfer from<br />
board to PC<br />
● Data access via web server possible<br />
● Magnetic board surface<br />
● Large board diagonal: 77”<br />
● Quick and easy operation of the main<br />
functions is facilitated by eight defined<br />
and four user-customizable function<br />
surfaces on the Starboard<br />
HITACHI StarBoard FX-77 – versatile and interactive<br />
1) HITACHI StarBoard FX-77<br />
Delivery Standard<br />
● Bluetooth receiver<br />
● Interactive pen<br />
(no whiteboard marker)<br />
● Wall mounting brackets<br />
● Incl. comprehensive application software<br />
StarBoard Software 6, 5 languages<br />
(1 licence)<br />
Code No. 1077<br />
System Requirements<br />
● Windows 98Se/Me/2000/XP<br />
● CPU Pentium II, min. 300 MHz<br />
● RAM min. 128 MB<br />
● Graphic colours min. 16 bit<br />
● Free HDD memory min. 100 MB<br />
● USB interface<br />
Installation Example<br />
Wireless data transfer<br />
via Bluetooth<br />
VGA connection<br />
StarBoard FX-77<br />
Projection<br />
Laptop/Computer Data/Video<br />
Projector<br />
Accessories<br />
2) Floor Stand<br />
● Mobile and height-adjustable to 6 levels<br />
(approx. 170 – max. 200 cm)<br />
Code No. 1063<br />
3) Whiteboard Roll Sheet (without ill.)<br />
● Allows the board to be used as a<br />
whiteboard<br />
● Easy to apply (magnetic) and remove<br />
● Can be dry-wiped clean<br />
Code No. 10753<br />
4) Electronic Pens<br />
● Allow colour copyboard function<br />
● Recommended in conjunction with<br />
Code No. 10753<br />
Delivery Standard<br />
● 4 electronic pens,<br />
red, blue, green, black<br />
● Electronic board eraser<br />
● Whiteboard marker,<br />
red, blue, green, black (EXPO)<br />
● Cleaning spray<br />
Code No. 10754<br />
5) Whiteboard Marker (EXPO)<br />
Set of 4 colours: red, blue, green, black<br />
● For replacement needs<br />
Code No. 10982<br />
Make notes or changes,<br />
add information and<br />
save the data instantlyduring<br />
your presentation<br />
Create presentations<br />
individually, e.g. choose<br />
your background<br />
Electronic pens<br />
Electronic board eraser<br />
For further information and technical specifications please refer to www.medium.de. Subject to technical changes without notice and errors.<br />
1<br />
incl. comprehensive<br />
StarBoard<br />
Software 6<br />
Also take a look at the interactive<br />
HITACHI Bluetooth Tablet on page 45!<br />
4<br />
4<br />
2
1<br />
HITACHI Panels T-15XL and T-17SXL –<br />
interactive work with a large audience<br />
Highlights Panels T-15XL and T-17SXL<br />
● Application in front of a large audience<br />
where the StarBoard FX-77 does not<br />
suffice due to its board size<br />
● With the PC and digital projector<br />
presentations can be projected onto a<br />
screen in any desired size<br />
● Interactive working while keeping eye<br />
contact to the audience all the time<br />
● Convenient and intuitive PC control via the<br />
panel; the pen replaces the mouse<br />
● High mobility: can be carried just as easily<br />
as a laptop or projector<br />
● Delivery standard incl. comprehensive<br />
StarBoard Application Software 6,<br />
5 languages (1 licence)<br />
Installation example<br />
USB connection<br />
VGA connection<br />
VGA connection<br />
Laptop/Computer Data/Video Projector<br />
Interactive Colour LCD Monitors<br />
with active TFT matrix<br />
● Technology: electromagnetic<br />
● Input: battery-powered pen<br />
● Transfer rate: 125 rates/sec.<br />
● Resolution: 0.05 mm<br />
● Accuracy: +/- 0.5 mm<br />
● USB 1.1 interface<br />
1) HITACHI Panel T-15XL<br />
● 15” Diagonal<br />
● Resolution: 1,024 x 768 pixels (XGA)<br />
● Brightness: 250 cd/m 2<br />
● Contrast: 400:1<br />
● Viewing angle: L/R 60°, O/U 40°/60°<br />
● VGA input<br />
● Audio input and output<br />
● Integrated loudspeakers<br />
● Tiltable between 15°-75°<br />
● Outer dimensions without monitor stand:<br />
H/W/D: approx. 31/34/5 cm<br />
● Weight: approx. 3.7 kg<br />
Code No. 10324<br />
incl. comprehensive<br />
StarBoard<br />
Software 6<br />
2) HITACHI Panel T-17SXL<br />
● 17” Diagonal<br />
● Resolution: 1,280 x 1,024 pixels (SXGA)<br />
● Brightness: 260 cd/m 2<br />
● Contrast: 450:1<br />
● Viewing angle: L/R 70°, O/U 70°<br />
● VGA input and output<br />
● Audio input<br />
● Integrated loudspeakers<br />
● Tiltable between 20°-70°<br />
● Outer dimensions without monitor stand:<br />
H/W/D: approx. 37.5/39.5/5.7 cm<br />
● Weight: approx. 5 kg<br />
Code No. 10325<br />
Accessories<br />
Carry Bag for HITACHI Panel T-15XL<br />
(without ill.)<br />
Inner dimensions incl. monitor stand:<br />
H/W/D: approx. 30/38/12 cm<br />
Colour: black<br />
Code No. 10323<br />
For further information please refer to www.medium.de. Subject to technical changes and errors.<br />
2<br />
Also take a look at the interactive<br />
HITACHI Bluetooth Tablet on page 45!<br />
Interactive Presentation<br />
51
Digital Camera Systems<br />
52<br />
Samsung UF-80DX –<br />
fresh design, easy to use<br />
Highlights<br />
● Suited for versatile application: present<br />
documents or objects and even integrate<br />
them into a video conference<br />
● Comfortable and easy to use: this camera<br />
system allows PC-free presentations<br />
● All functions can conveniently be<br />
controlled via the integrated user interface<br />
● 14x optical / 3x digital zoom: perfect<br />
display of 3-dimensional objects<br />
● A4 pages can be presented<br />
Samsung UF-80DX<br />
Lens<br />
Zoom<br />
Shooting area max/min<br />
Focus<br />
Iris<br />
Pick-up device<br />
VGA/DVI output<br />
White balance<br />
Negative/positive<br />
Application software<br />
Graphic user interface<br />
Freeze function<br />
Image save & recall<br />
Multi-display<br />
Image divide<br />
Image rotation<br />
Upper illumination<br />
Lower illumination<br />
Inputs<br />
Outputs<br />
Power supply<br />
W/H/D<br />
Accessories<br />
1<br />
● Flexible: adjustment to ambient light conditions<br />
with an additional illumination<br />
built into the camera arm or through the<br />
optionally available Light Box (ill. 2)<br />
● Easily connects to a PC or notebook via a<br />
USB interface<br />
● Exclusive software: recording images and<br />
video in next to no time, processing and<br />
forwarding the data e.g. via e-mail is quick<br />
and easy to master<br />
f=4.8 –67.2 mm; F1.5–2.1<br />
14X optical, 3x digital<br />
298 x 221 (DIN A4) / 21.7 x 16.4 mm<br />
automatic/manual<br />
automatic with fine-level adjustment<br />
1/3” CCD, 850,000 pixels<br />
XGA (1,024 x 768 pixels), RGB<br />
automatic/manual (one touch type)<br />
selectable<br />
MAC: viewer; WIN: viewer, Twain driver, AVI capture software<br />
OSD; drawing and highlighting with the mouse<br />
yes<br />
8<br />
display of all saved images<br />
2 (saved/live)<br />
90°, 180°, 270°, 360°<br />
1 Lamp attached to the camera arm, 90° tiltable<br />
280 x 194 mm (with optional Light Box)<br />
1 VGA (15-pin Sub-HD); 1 PS/2 (mouse); 1 RS-232<br />
1 VGA (15-pin Sub-HD); 1 DVI-D; 1 USB 2.0<br />
12 VDC, 4.0 A external power supply unit<br />
404/488/504 mm<br />
remote control, power supply unit, carrying bag<br />
Example of application<br />
Additional illumination<br />
Example of application<br />
Light Box<br />
1) Samsung UF-80DX<br />
● Portable XGA desktop camera<br />
● Weight: 5 kg<br />
● Incl. carrying bag<br />
Code No. 10210<br />
Carrying bag<br />
2) Light Box for Samsung UF-80DX<br />
For the display of transparencies, slides,<br />
X-rays, negatives etc.<br />
Code No. 10211<br />
2
CASIO YC-400 – multi-functional camera system<br />
Highlights<br />
Multiple fields of application<br />
● Document camera: Present real objects<br />
and documents in your presentation in an<br />
easy manner.<br />
● Whiteboard camera: Just take a photo of<br />
the copyboard or flipchart, the camera<br />
software will automatically optimise the<br />
image geometry.<br />
● Scanner: uncomplicated digitising of<br />
documents or objects<br />
● Digital camera: Document e.g. business<br />
trips, work processes etc.<br />
Available only in selected countries.<br />
● 4 Mill. pixels resolution<br />
● USB interface for easy connection to the<br />
PC/Laptop<br />
● Easy menu for ease of use<br />
● Automatic image optimisation for best<br />
image quality<br />
● Adjustment of digital images for easy<br />
further processing<br />
● Integrated illumination for unfavourable<br />
ambient light<br />
● Detachable camera to be used as a regular<br />
digital camera<br />
● Portable thanks to retractable document<br />
tray<br />
● Softcase incl. in delivery standard<br />
CASIO YC-400<br />
Resolution: 4 mill. pixels<br />
Weight approx.: 1.6 kg<br />
Code No. 190YC400 price on request<br />
Accessories<br />
Ideal in combination<br />
with any digital<br />
projector<br />
USB extension cable, active<br />
5 m with int. amplifier<br />
Code No. 1958-USB<br />
Product video as free download on<br />
www.medium.de or on CD-ROM free of<br />
charge (Code No. 52895)<br />
Digital Camera Systems<br />
53
Desktop Cameras<br />
54<br />
ClearOne Desktop Cameras –<br />
make small objects visible<br />
for everyone<br />
Highlights<br />
● Project small objects such as slides,<br />
microscopic samples, tiny electronic<br />
pieces or even documents<br />
● Possible areas of application: schools,<br />
labs and industry<br />
● Plug & Play: no software required (except<br />
FlexCam-USB and USB adaptor)<br />
● Connects to most televisions, video<br />
recorders, digital projectors and PC-video<br />
card - PAL-systems (depending on the<br />
output signal of the camera)<br />
● Long flexible "gooseneck" and swivel head<br />
ensure precise positioning of the camera<br />
to the object<br />
● Simultaneous audio transmission thanks<br />
to integrated microphone (except ICam)<br />
● Suitable for integration into video<br />
conference systems<br />
Illuminable base in the<br />
camera stand<br />
1 2<br />
Microscope adapter<br />
3 4<br />
1) TeachCam®<br />
● Specifically designed for medical<br />
sciences, sciences and technology<br />
● Illuminable camera base - for the<br />
presentation of 35 mm slides and object<br />
slides with lab samples<br />
● Includes wooden case for safe storage and<br />
transportation of camera and accessories<br />
● Includes object slides and object cases<br />
both made of plastic<br />
Code No. 100032<br />
2) StudentCam®<br />
● Great for schools<br />
● Same specifications as the TeachCam,<br />
however with less functions and<br />
accessories (without illuminated camera<br />
base, wooden case, object slides and<br />
object case)<br />
Code No. 100031<br />
Installation example<br />
e.g. FlexCam USB<br />
or with USB adapter<br />
e.g. S-Video or USB<br />
3) FlexCam USB<br />
● Digital camera, ideal for the supplement<br />
and integration into PC-based<br />
presentations<br />
● For direct connection to PC or MAC<br />
● Includes video and photo image software<br />
ArcSoft’s VideoImpression and<br />
PhotoStudio ®<br />
System requirements<br />
● Windows 98, 98SE, 2000, ME, XP<br />
(MAC: OS 8.6, 9.0, X)<br />
● Pentium II CPU 350 MHz<br />
(Mac Power PC or higher)<br />
● Available USB interface 64 MB RAM<br />
● 200 MB free hard-disc storage<br />
Code No. 100030<br />
4) FlexCam ICam<br />
● Inexpensive entry model suitable for many<br />
applications in presentations or schools<br />
Code No. 100010<br />
FlexCam USB<br />
or with USB adapter<br />
For further technical specifications and accessories for all cameras please refer to the chart on page 56.<br />
Video/TV<br />
Data/ video<br />
projector
AVerVision 330/300i/130 –<br />
present small objects in XXL<br />
Highlights AVerVision 330/300i<br />
● Sophisticated colour video cameras for<br />
recording 3-dimensional objects and<br />
documents<br />
● 1/3” CCD image sensor<br />
● DVI and VGA output<br />
● VGA input (15 pin D-Sub)<br />
● Switching from camera to PC signal is<br />
possible<br />
● Flexible, telescopic camera arm<br />
● 180° Image rotation is possible<br />
● Image mirroring is possible<br />
● Freeze function<br />
● Functions controlled via remote control<br />
● Includes transport bag<br />
1) AVerVision 330<br />
● 5x Optical / 8x digital zoom<br />
● Auto focus<br />
● Pictures can be saved in JPG format on a<br />
CF/SD card and transferred to the PC<br />
● CF/SD card slot<br />
● Data transfer via USB<br />
● Remote control incl. laser pointer<br />
● New additional LED light to be used with<br />
unfavourable light conditions<br />
Code No. 1017<br />
AverVision 330<br />
1<br />
2) AVerVision 300i<br />
● <strong>The</strong> “Business Class“ model for<br />
demanding applications<br />
● 8x Digital zoom<br />
● Internal memory for up to 80 pictures<br />
● Integrated LED lamp to be used with<br />
unfavourable light conditions<br />
● Can be used as webcam via USB<br />
connection<br />
Code No. 1019<br />
3) AVerVision 130<br />
● Suitable for standard applications in<br />
conference or school rooms or labs<br />
● 1/2" CMOS image sensor<br />
● 4x Digital zoom<br />
● Internal memory for 4 pictures<br />
● Can be used as webcam via USB<br />
connection<br />
● Flexible “goose-neck”<br />
Code No. 1018<br />
2<br />
Removable<br />
additional light<br />
Accessories<br />
4) Light Box for<br />
AVerVision 330, 300i and 130 (without ill.)<br />
For the display of transparencies, slides,<br />
X-rays, negatives etc.<br />
L/W/H: 35.3/26.3/1 cm<br />
Code No. 10152<br />
5) Carrying Bag for<br />
AVerVision 130 (without ill.)<br />
H/W/D: approx. 17/36/12 cm<br />
Colour: black<br />
Code No. 10151<br />
Further accessories available upon request.<br />
3<br />
Desktop Cameras<br />
55
Accessories / Technical Data Desktop Cameras<br />
56<br />
Recommended Accessories<br />
ClearOne FlexCam<br />
1) USB Adapter for TeachCam,<br />
StudentCam and FlexCam iCam<br />
● Incl. video and photo image software<br />
ArcSoft´s VideoImpression and<br />
PhotoStudio<br />
● USB-Rev. 1.1<br />
● Signal input: Composite, S-Video, audio<br />
● Signal output: video “Pass Through“<br />
● Image resolution 160x120 (QCIF) up to<br />
640x480 (VGA)<br />
System requirements<br />
● Windows 98, 98SE, 2000,<br />
ME, XP (MAC: OS 8.6,9.0)<br />
● Pentium II CPU 350 MHz<br />
(Mac Power PC or higher)<br />
● Available USB interface<br />
● Interface software: Video for Windows,<br />
Twain or WDM driver<br />
● Supported file formats:<br />
BMP, AVI, PCX, TIF, JPG, TAG<br />
Code No. 100012<br />
S-Video USB<br />
Model<br />
Effective resolution<br />
Image sensor<br />
Signal output<br />
Signal input<br />
Focal length (f)<br />
Focus<br />
Iris<br />
Zoom<br />
White balance<br />
Specials<br />
Delivery standard<br />
Length camera arm<br />
Microscope adapter<br />
Power supply<br />
Colour<br />
Transport bag<br />
Camera weight approx.<br />
Code No.<br />
Video Pass<br />
Through<br />
Model<br />
Effective resolution<br />
Image sensor<br />
Photosensitivity<br />
Signal output<br />
Focal length (f)<br />
Focus<br />
Iris<br />
White balance<br />
Specials<br />
Delivery standard<br />
Length camera arm<br />
Microphone<br />
Power supply<br />
Colour<br />
Transport case<br />
Camera weight<br />
Code No.<br />
AVerVision 330<br />
1,024 x 768 pixels<br />
1/3” CCD<br />
DVI / VGA / Composite / S-Video / USB / RS-232<br />
VGA / RS-232<br />
10 mm<br />
5.4 – 27 mm<br />
automatic<br />
8x digital / 5x optical<br />
automatic and manual<br />
modes for text, graphics and microscope images<br />
change colour / black/white<br />
positive / negative colour inversion<br />
S-Video cable, RCA cable,<br />
DVI-RGB cable, USB cable,<br />
9 pin mini DIN to S-Video/<br />
Composite/RS-232 adapter,<br />
additional LED light,<br />
remote control incl. batteries,<br />
driver and software CD,<br />
manual, carrying bag,<br />
mains adapter<br />
approx. 34 cm – 50 cm<br />
optional (upon request)<br />
12 Vmains adapter<br />
black<br />
included<br />
2 kg<br />
1017<br />
TeachCam / StudentCam<br />
FlexCam USB<br />
752 x 512 pixels<br />
692 x 404 pixels<br />
1/4” CCD<br />
1/4” Progressive Color CCD<br />
1.5 Lux<br />
n.s.<br />
S-Video / audio<br />
USB<br />
8 mm<br />
8 mm<br />
1/4”–50' (6.35 cm up to 15.24 m) 1/4” (6.35 mm) up to L<br />
automatic<br />
automatic<br />
automatic / –<br />
via ArcSoft software<br />
flickerless mode<br />
incl. ArcSoft and<br />
change between colour / black/white – PhotoStudio software<br />
positive / negative colour inversion / – up to 16.8 mill. colours<br />
– / manual brightness adjustment (24-bit)<br />
5 object slides / –<br />
USB cable (1.32 m)<br />
2 object cases / –<br />
microscope adapter<br />
1.8 m and 7.6 m S-Video/audio cable,<br />
S-Video to Composite adapter,<br />
BNC adapter,<br />
mains adapter<br />
(each 1x 26, 28 and 34 cm)<br />
approx. 65 cm / 50.8 cm<br />
approx. 45 cm<br />
integrated<br />
integrated<br />
12 VDCmains adapter<br />
via USB<br />
black<br />
light grey<br />
wooden case / –<br />
–<br />
approx. 1.5 kg / 1.9 kg<br />
approx. 1.8 kg<br />
100032 / 100031<br />
100030<br />
AVerVision 300i<br />
1,024 x 768 pixels<br />
1/3” CCD<br />
VGA / Composite / S-Video / USB<br />
VGA<br />
6.7 mm<br />
< 1 cm to L<br />
automatic<br />
8x digital<br />
automatic and manual<br />
text and graphics image mode<br />
change colour / black/white<br />
positive / negative colour inversion<br />
S-Video cable, RCA cable,<br />
VGA cable, USB cable,<br />
remote control incl. batteries,<br />
driver and software CD,<br />
manual, carrying bag,<br />
mains adapter<br />
approx. 34 cm – 53.3 cm<br />
optional (upon request)<br />
12 Vmains adapter<br />
black<br />
included<br />
2 kg<br />
1019<br />
FlexCam iCam<br />
628 x 582 pixels<br />
1/4” CMOS<br />
3 lux<br />
S-Video / Composite<br />
8 mm<br />
1/4” (6.35 mm) bis L<br />
automatic<br />
automatic<br />
flickerless mode<br />
S-Video cable (3.65 m)<br />
S-Video on RCA adapter<br />
Scart adapter<br />
microscope adapter<br />
(each 1x 26, 28 and 34<br />
cm), mains adapter<br />
approx. 50.8 cm<br />
–<br />
12 VDCmains adapter<br />
transparent blue<br />
–<br />
approx. 1.8 kg<br />
100010<br />
AVerVision 130<br />
1,024 x 768 pixels<br />
1/2” CMOS<br />
VGA / Composite / S-Video / USB<br />
–<br />
9.6 mm<br />
< 1 cm to L<br />
automatic<br />
4x digital<br />
automatic and manual<br />
text and graphics image mode<br />
change colour / black/white<br />
positive / negative colour inversion<br />
S-Video cable, RCA cable,<br />
VGA cable, USB cable,<br />
driver and software CD,<br />
manual,<br />
mains adapter<br />
approx. 55.9 cm<br />
optional (upon request)<br />
12 Vmains adapter<br />
black<br />
optional (Code No. 10151)<br />
2 kg<br />
1018
OHP MEDIUM Traveller ECO –<br />
be mobile at an excellent value<br />
Highlights<br />
● <strong>The</strong> MEDIUM overhead projector<br />
Traveller ECO is the entry-level model for<br />
price-conscious presenters. Advanced<br />
technology at a competitive price.<br />
● Ease of set-up<br />
<strong>The</strong> ECO is ready to use in<br />
two simple steps.<br />
● Twin column support<br />
Ensures a constantly sharp image since<br />
the optical axis remains unchanged.<br />
● Lamp changer<br />
Saves the presentation even after lamp<br />
failure.<br />
● Softcase<br />
Is included in delivery standard and<br />
protects the projector during transport.<br />
MEDIUM Traveller ECO<br />
Dimensions H/W/D:<br />
approx. 13/30.5/49 cm (folded)<br />
approx. 45/30.5/44 cm (in use)<br />
Work surface: approx. 28.5 x 28.5 cm<br />
Lens: 3-element vario-focal 280-320 mm<br />
Lamp: 2 x 24 V/250 W (EHJ)<br />
Approx. weight: 7.5 kg without softcase<br />
Approx. 10.5 kg with softcase<br />
Code-No. 106046<br />
Image Size Chart Vario PA lens<br />
Proj. distance approx. Image size approx.<br />
min. 130 cm 120 x 120 cm<br />
150 cm 135 x 135 cm<br />
180 cm 165 x 165 cm<br />
200 cm 170 x 170 cm<br />
max. 220 cm 200 x 200 cm<br />
Overhead Projectors<br />
57
Overhead Projectors<br />
58<br />
OHP MEDIUM Traveller 3 –<br />
for presenters on the move<br />
Highlights<br />
● <strong>The</strong> MEDIUM Traveller 3 is both a welldesigned<br />
overhead projector for the office<br />
and a practical, mobile presentation tool.<br />
It is extremely easy to set up and boasts<br />
exemplary performance.<br />
● <strong>The</strong> twin column support ensures<br />
constantly sharp projection images. Even<br />
after years of usage the optical axis<br />
remains unchanged.<br />
● <strong>The</strong> transverse projection head gives the<br />
presenter a free view onto the worktop<br />
and protects the unit during transport.<br />
● Utmost ease of use: the Traveller is set up<br />
and ready for use in only two steps<br />
● <strong>The</strong> quick lamp changer ensures an<br />
uninterrupted presentation in case of a<br />
lamp failure<br />
● <strong>The</strong> extremely flat worktop is durable<br />
thanks to a robust aluminium pressuredie-casting<br />
chassis guaranteeing an<br />
excellent long-time image quality<br />
Image Size Chart Traveller 3 (3-element lens)<br />
Focal length f = 270–300 mm<br />
Projection distance approx. Image size approx.<br />
1.00 m 1.00 x 1.00 m<br />
1.50 m 1.35 x 1.35 m<br />
2.00 m 1.80 x 1.80 m<br />
1<br />
1) MEDIUM Traveller 3<br />
H/W/D folded: approx. 9.5/30/46 cm<br />
Worktop W/D: approx. 28.5/28.5 cm<br />
Lens: 3-element vario focal<br />
Lamp: 2 x 24 V/250 W (EHJ)<br />
Light output: approx. 2,300 ANSI lumens<br />
Quick lamp changer<br />
Weight: approx. 7.2 kg<br />
Code No. 106040<br />
Traveller 3 with Case<br />
Code No. 106040K<br />
37<br />
30<br />
57<br />
30<br />
46<br />
9,5<br />
Portable and user-friendly<br />
for desktop projection<br />
Accessories<br />
2) Case matching Traveller 3<br />
Safety hardcase in top design<br />
Code No. 1148<br />
3) Spare lamp (without ill.)<br />
OHP lamp 24 V 250 W (EHJ)<br />
Packing unit: 5 pieces<br />
Code No. 1132<br />
4) MEDIUM Write-on Sheets (without ill.)<br />
● Highly transparent, can be written on with<br />
OHP markers<br />
● A4 size, 100 sheets per package,<br />
approx. 0.10 mm (polypropylene)<br />
Code No. 141001-PP<br />
Further Accessories<br />
● Mobile screens pages 74 – 81<br />
● Projection trolleys pages 93 – 97<br />
● Laser pointer page 49<br />
2
OHP MEDIUM Manager –<br />
the small and lightweight globetrotter!<br />
Highlights<br />
● This is him: the Manager among all<br />
overhead projectors. A truly unique<br />
product allowing you to hold presentations<br />
in an absolutely business-like<br />
manner in any situation. <strong>The</strong> OHP Manager<br />
is the smallest and most quiet full-size A4<br />
OHP with halogen lamp technology on the<br />
world market.<br />
Smallest mobile projector<br />
no more than 6.5 cm high<br />
Image Size Chart OHP Manager<br />
Vario lens 280–320 mm<br />
Projection distance approx. Image size approx.<br />
1.10 m (min.) 0.57 x 0.83 m<br />
1.25 m 0.75 x 1.10 m<br />
1.50 m 0.95 x 1.40 m<br />
2.00 m 1.25 x 1.85 m<br />
2.50 m 1.55 x 2.15 m<br />
2.80 m (max.) 1.75 x 2.40 m<br />
1<br />
1) OHP Manager for 200-260 Volt<br />
● Laptop format, approx. 3.9 kg<br />
● Light output approx. 2,600 ANSI lumens<br />
● Award-winning design<br />
● Whisper-quiet operation<br />
● No annoying light borders<br />
● Revolving fresnel lens<br />
for A4 portrait and landscape format<br />
● Easy handling<br />
thanks to lift-up technology<br />
● Supplied with attractive shoulder carry<br />
bag (ill. 2)<br />
● 3-element precision lens 280-320 mm<br />
● Quick lamp changer:<br />
2 x 24 V/250 W lamps (EHJ)<br />
● H/W/D: approx. 6.5/26/42 cm<br />
Code No. 106025<br />
26<br />
32<br />
For an overview of all overhead projectors please refer to pages 64 and 65.<br />
56<br />
42<br />
26<br />
6,5<br />
Accessories<br />
3) Spare lamp (without ill.)<br />
OHP lamp 24 V 250 W (EHJ)<br />
Packing unit: 5 pieces<br />
Code No. 1132<br />
4) MEDIUM Write-on Sheets (without ill.)<br />
● Highly transparent, can be written on with<br />
OHP markers<br />
● A4 size, 100 sheets per package,<br />
approx. 0.10 mm (polypropylene)<br />
Code No. 141001-PP<br />
Further Accessories<br />
● Mobile screens pages 74 – 81<br />
● Projection trolleys pages 93 – 97<br />
● Laser pointer page 49<br />
2<br />
Overhead Projectors<br />
59
Overhead Projectors<br />
60<br />
OHP MEDIUM futur Series –<br />
exclusive desktop design for<br />
convenient reading and writing<br />
Highlights<br />
Smart technology<br />
and modern design<br />
for sophisticated demands<br />
● <strong>The</strong> series MEDIUM futur sets standards<br />
in the field of overhead projection and<br />
fulfills all requirements: ease of use,<br />
inclusion of latest technological<br />
developments, an awareness for quality<br />
and the environment.<br />
● Top image sharpness even in the longrun<br />
thanks to dual projection arm design (only<br />
one axis as opposed to conventional<br />
multiple axis constructions)<br />
● Extremely powerful light output<br />
with approx. 5,000 ANSI lumens (futur 5)<br />
and approx. 11,000 ANSI lumens (futur 10)<br />
● Easy handling thanks to a quick lamp<br />
changer (futur 5), an additional<br />
socket and a transparency clip<br />
● Desktop design for convenient reading of<br />
presentation notes and writing on<br />
transparencies<br />
Comfortable writing<br />
thanks to modern desktop<br />
design<br />
Easy to carry with<br />
integrated handle<br />
1<br />
2<br />
1) OHP MEDIUM futur 5<br />
Worktop W/D: approx. 28.5/28.5 cm<br />
Lens: vario focal 300–340 mm<br />
Quick lamp changer<br />
Lamps: 2 x 36 V/400 W low voltage (EVD)<br />
Light output approx. 5,000 ANSI lumens<br />
H/W/D (folded):<br />
approx. 75 (26)/34/46 (62) cm<br />
Weight: approx. 13.5 kg<br />
Code No. 108036<br />
2) OHP MEDIUM futur 10<br />
Worktop W/D: approx. 28.5/28.5 cm<br />
Lens: vario focal 300–340 mm<br />
Lamp: 575 W metal halide lamp<br />
Light output more than 11,000 ANSI lumens<br />
H/W/D (folded):<br />
approx. 75 (26)/34/46 (62) cm<br />
Weight: approx. 14.5 kg<br />
Code No. 108575<br />
For large-screen and steep-angle projections<br />
3) OHP MEDIUM futur 10-KC<br />
Same as futur 10 but with keystone<br />
correction<br />
H/B/T (ready for use):<br />
approx. 81 (26)/35/46 (67) cm<br />
Code No. 108575-KC<br />
Transport case with<br />
wheels (optional)<br />
Image Size Chart futur 5/10<br />
Focal length f = 300–340 mm<br />
Accessories<br />
Projection distance approx. Image size approx.<br />
1.50 m 1.20 x 1.20 m<br />
2.40 m 1.70 x 1.70 m<br />
3.00 m 2.30 x 2.30 m<br />
For an overview of all overhead projectors please refer to pages 64 and 65.<br />
3<br />
For large-screen and steep-angle<br />
projections<br />
4) Spare Lamp (without ill.)<br />
OHP lamp 36 V 400 W (EVD)<br />
for OHP futur 5; packing unit 5 pieces<br />
Code No. 1133<br />
5) OHP Metal Halide Lamp 575 W<br />
(without ill.) for OHP futur 10/10-KC<br />
Code No. 1135<br />
6) Transport Case<br />
Made of durable polyester material,<br />
for OHP futur 5 and 10 (not for KC)<br />
Code No. 1143<br />
7) Magnifying Lens (without ill.)<br />
For OHP futur 5, 10 and futur 10-KC. Enlarges<br />
your projections by approx. 25%. Easy to<br />
mount underneath the projection head.<br />
Code No. 19273<br />
Further Accessories<br />
● Screens pages 73 – 90<br />
● Projection trolleys pages 93 – 97<br />
● Laser pointer page 49<br />
6
Highlights<br />
Image Size Chart OHPs 2036/2024<br />
Focal length f = 315 mm<br />
Projection distance approx. Image size approx.<br />
1.80 m 1.40 x 1.40 m<br />
2.00 m 1.60 x 1.60 m<br />
2.50 m 2.05 x 2.05 m<br />
1 2<br />
OHP MEDIUM 2036/2024 –<br />
the perfect projectors for daily use<br />
● Sturdy housing<br />
● Proven design<br />
● Very bright<br />
● Lamp economy switch for fourfold life<br />
span of the lamp<br />
● Quick lamp changer<br />
● Overheating proctection<br />
● Quiet propeller fan<br />
● Even when placed in a table it can easily<br />
be opened from the top<br />
● On/off switch is located on the worktop<br />
● Pens always close at hand in the pen tray<br />
Worktop W/D: ca. 28.5/28.5 cm<br />
Lens: 3-element, f = 315 mm<br />
Option: 290 mm or 340 mm<br />
H/W/D: approx. 62.5/40/36.5 cm<br />
1) OHP MEDIUM 2036<br />
Lamps: 2 x 36 V/400 W (EVD)<br />
Light output: approx. 6,500 ANSI lumens<br />
Weight: approx. 12.5 kg<br />
Code No. 102036<br />
2) OHP MEDIUM 2024<br />
Lamps: 2 x 24 V/250 W (EHJ)<br />
Light output: approx. 4,000 ANSI lumens<br />
Weight: approx. 10.5 kg<br />
Code No. 102024<br />
OHP 2024 in use with projection trolley MEDIUM PT<br />
4 (see page 94)<br />
Accessories<br />
Roll Feed Cassette (without ill.)<br />
Very functional and easy to use; provides<br />
optimal protection for transparency rolls<br />
Roll width: approx. 26 cm and<br />
approx. 29.7 cm for OHP 2024/2036<br />
Colour: black<br />
Code No. 1105<br />
Halogen Lamps (without ill.) for Low-<br />
Voltage<br />
Projectors 24 V/250 W (EHJ)<br />
for OHP 524P/2024/Manager/Traveller3<br />
Packing unit: 5 pieces<br />
Code No. 1132<br />
Lamp 36 V/400 W (EVD)<br />
for OHP 536P/2036/futur5<br />
Packing unit: 5 pieces<br />
Code No. 1133<br />
MEDIUM Write-on Sheets (without ill.)<br />
● Highly transparent, can be written on with<br />
OHP markers<br />
● A4 size, 100 sheets per package,<br />
approx. 0.10 mm (polypropylene)<br />
Code No. 141001-PP<br />
Further Accessories<br />
● Screens pages 73 – 90<br />
● Projection trolleys pages 93 – 97<br />
● Laser pointer page 49<br />
Overhead Projectors<br />
61
Overhead Projectors<br />
62<br />
OHP MEDIUM 536P/524P–<br />
great technology - competitive price<br />
1) OHP MEDIUM 536 P<br />
● Great value for money<br />
● Robust metal housing<br />
● Quick lamp changer<br />
● Lamp economy switch<br />
● Fold-down arm<br />
Working surface W/D: approx. 28.5/28.5 cm<br />
Lens: 3-element f =315 mm<br />
Lamps: 2 x 36 V/400 W (EVD)<br />
Light output: approx. 5,200 ANSI lumens<br />
H/W/D (folded):<br />
approx. 57 (27)/42/35 (47) cm<br />
Weight: approx. 14 kg<br />
Code No. 100536P<br />
Image Size Chart OHPs 536 P/524 P<br />
Focal length f = 315 mm<br />
Projection distance approx. Image size approx.<br />
1.50 m 1.14 x 1.14 m<br />
2.00 m 1.62 x 1.62 m<br />
2.50 m 2.08 x 2.08 m<br />
3.00 m 2.56 x 2.56 m<br />
1 2<br />
2) OHP MEDIUM 524 P<br />
● Great value for money<br />
● Robust metal housing<br />
● Quick lamp changer<br />
● Lamp economy switch<br />
● Fold-down arm<br />
Working surface W/D: approx. 28.5/28.5 cm<br />
Lens: 3-element f =315 mm<br />
Lamps: 2 x 24 V/250 W (EHJ)<br />
Light output: approx. 2,400 ANSI lumens<br />
Weight: approx. 13.5 kg<br />
Code No. 100524P<br />
For an overview of all overhead projectors please refer to pages 64 and 65.<br />
PT5<br />
Accessories<br />
Roll Feed Device (without ill.)<br />
Optionally available as a cassette<br />
Code No. 1106-A<br />
Or as an attachment<br />
Code No. 1104<br />
Halogen Lamps (without ill.) for Low-Voltage<br />
Projectors 24 V/250 W (EHJ)<br />
for OHP 524P/2024/Manager/Traveller3<br />
Packing unit: 5 pieces<br />
Code No. 1132<br />
Lamp 36 V/400 W (EVD)<br />
for OHP 536P/2036/futur5<br />
Packing unit: 5 pieces<br />
Code No. 1133<br />
MEDIUM Write-on Sheets (without ill.)<br />
● Highly transparent, can be written on with<br />
OHP markers<br />
● A4 size, 100 sheets per package,<br />
approx. 0.10 mm (polypropylene)<br />
Code No. 141001-PP<br />
Further Accessories<br />
● Screens pages 73 – 90<br />
● Projection trolleys PT 3/PT5 page 95<br />
● Laser pointer page 49
1<br />
MEDIUM Presentation Transparencies –<br />
for universal use with copier or printer<br />
Highlights<br />
● <strong>The</strong> universality of MEDIUM OHP<br />
transparencies provides safety and<br />
multiple benefits<br />
● Thanks to consistent enhancement of the<br />
transparencies they adapt to new<br />
requirements caused by technological<br />
changes in the device market<br />
● <strong>The</strong> transparencies are universally usable<br />
for the respective technologies<br />
● Avoidance of equipment failure due to<br />
usage of wrong transparencies<br />
● Clear product range hence low stockage<br />
cost<br />
1)MEDIUM Universal Standard Transparency<br />
for copiers<br />
● Standard laser transparency with coating<br />
on both sides for almost all dry toner<br />
copiers b/w without optical detection<br />
● For nearly all b/w copiers (also suitable<br />
for b/w laser printers)<br />
● Single and multiple sheet feeding<br />
possible<br />
● Clear, 100 my, 100 sheets<br />
Code No. 12600<br />
2) MEDIUM Universal Ink Jet Transparency<br />
● Specially coated universal ink jet<br />
transparency with very short drying time<br />
(allows multiple sheet feeding)<br />
● High sharp contours, brilliant original<br />
colours on the OHP<br />
● Suitable for almost all ink jet printers<br />
● Also suitable for pigmented ink<br />
● Clear, 100 my, 50 sheets<br />
Code No. 12601<br />
3)MEDIUM Universal Colour Laser<br />
Transparency<br />
● Heat-resistant transparency<br />
● Universal coating on both sides provides<br />
permanent safety<br />
● Suitable for almost any colour laser<br />
printers (also for colour laser printers<br />
without optical sensor)<br />
● Higher thickness of the polyester offers<br />
optimal feeding and thermal stability even<br />
for printers with higher temperatures<br />
● Brilliant colour prints<br />
● Ideal for OHP presentations and<br />
transparent covers<br />
● Multiple sheet feeding possible<br />
● Clear, 125 my, 50 sheets<br />
Code No. 12602<br />
5<br />
4) MEDIUM Write-on Rolls<br />
● Highly transparent polypropylene film to<br />
be written on with OHP pens<br />
● Tear-proof, approx. 20 m length<br />
Packing unit: 20 pcs.<br />
Roll width approx. 29.7 cm<br />
Code No. 1729720<br />
4<br />
3<br />
2<br />
5) Transparent Archiving Pouch<br />
● For safely archiving your overhead<br />
transparencies or other documents<br />
● <strong>The</strong> pouch does not stick to the<br />
transparency<br />
● Opens easily to both sides<br />
● Highly transparent<br />
● With standard punch holes suitable for all<br />
filing systems<br />
● Made of environmentally friendly<br />
polypropylene<br />
● 100 pcs.<br />
Code No. 1601<br />
Transparencies<br />
63
Overview Overhead Projectors<br />
64<br />
<strong>The</strong> A-Z of MEDIUM Overhead Projectors<br />
A checklist of features that should be considered when<br />
purchasing an overhead projector:<br />
Additional socket:<br />
For connection of additional equipment (e.g. document cameras);<br />
ensures comfortable and professional presentations.<br />
Condenser lens:<br />
Additional light focusing for improved sharpness of projection<br />
image along the margins.<br />
External lamp house adjustment:<br />
Adjustment of the optimal sharpness without having to open the<br />
machine; colour borders are easy to remove.<br />
Fold-down projection arm:<br />
Ensures easy transport and saves storage room.<br />
Glare-free fresnel lens:<br />
Avoids light scattering thus allows working for longer periods<br />
without eyes getting tired.<br />
Lamp economy switch:<br />
Prolongs the life span of a lamp.<br />
Lumens:<br />
<strong>The</strong> light output of the overhead projector necessary for producing<br />
the picture i.e. the higher the lumens, the better the projected<br />
picture.<br />
On/off switch on worktop:<br />
No need to search for the switch when switching the projector on<br />
or off during a lecture.<br />
Optical axis:<br />
Responsible for the sharpness of a projection picture. Only if the<br />
projection head is positioned vertically above the lamp house and<br />
the concave mirror you are able to get a sharp projection picture.<br />
It is important that there is a stable connection between projection<br />
head and projection arm.<br />
Quick lamp changer:<br />
In case of a lamp failure you activate the spare lamp with just one<br />
hand movement without having to interrupt your lecture.<br />
Vario focal lens:<br />
Lens with a variable focal length (270-340 mm); avoids annoying<br />
blue or yellow light borders.<br />
OHP<br />
Lamp<br />
Approx. light output<br />
in ANSI lumens<br />
Lamp economy switch<br />
Quick lamp changer<br />
Glare-free fresnel lens<br />
Standard lens<br />
in mm<br />
Interchangeable lens<br />
Roll feed cassette<br />
Roll feed attachment<br />
Additional socket<br />
Electr. power supply<br />
Approx. weight in kg<br />
Dimensions ready for use<br />
(ready for transport), mm<br />
Depth approx.<br />
Width approx.<br />
Height approx.<br />
Fold-down arm<br />
Magnifying lens<br />
Transport case/carry bag<br />
Description<br />
on catalogue page<br />
CE<br />
Code No.<br />
Portable reflective<br />
Traveller 3<br />
24 V/250 W<br />
2,300<br />
–<br />
●<br />
–<br />
vario focal<br />
270-300<br />
–<br />
–<br />
–<br />
–<br />
–<br />
7.2<br />
360 (460)<br />
300<br />
560 (95)<br />
●<br />
–<br />
O<br />
58<br />
●<br />
106040<br />
Subject to technical changes and errors.<br />
● yes – no O optional * with LCD projection<br />
+<br />
referring to 28 x 21 cm for portrait and landscape format<br />
Manager<br />
24V/250W<br />
2,600+<br />
–<br />
●<br />
–<br />
vario focal<br />
280-320<br />
–<br />
–<br />
–<br />
–<br />
●<br />
3.9<br />
315 (425)<br />
260<br />
560 (65)<br />
●<br />
–<br />
●<br />
59<br />
●<br />
106025<br />
incl.<br />
shoulder bag<br />
Traveller Eco<br />
24 V / 250 W<br />
2,700<br />
–<br />
●<br />
–<br />
vario focal<br />
280–320<br />
–<br />
–<br />
–<br />
–<br />
–<br />
7.5<br />
490 (440)<br />
305<br />
130 (450)<br />
●<br />
–<br />
●<br />
1<br />
●<br />
106046
<strong>The</strong> Art of Presenting Perfection<br />
Desktop projectors with fold-down arm Desktop projectors<br />
524P<br />
24 V / 250 W<br />
2,400<br />
●<br />
●<br />
●<br />
315<br />
O<br />
O<br />
O<br />
–<br />
–<br />
13.5<br />
350 (470)<br />
420<br />
570 (270)<br />
●<br />
–<br />
–<br />
62<br />
●<br />
100524P<br />
536P<br />
36 V / 400 W<br />
5,200<br />
●<br />
●<br />
●<br />
315<br />
O<br />
O<br />
O<br />
–<br />
–<br />
14<br />
350 (470)<br />
420<br />
570 (270)<br />
●<br />
–<br />
–<br />
62<br />
●<br />
100536P<br />
2024<br />
24 V / 250 W<br />
4,000<br />
●<br />
●<br />
●<br />
315<br />
O<br />
O<br />
–<br />
–<br />
–<br />
10.5<br />
365<br />
400<br />
625<br />
–<br />
O<br />
–<br />
61<br />
●<br />
102024<br />
2036<br />
36 V / 400 W<br />
6,500<br />
●<br />
●<br />
●<br />
315<br />
O<br />
O<br />
–<br />
–<br />
–<br />
12.5<br />
365<br />
400<br />
625<br />
–<br />
O<br />
–<br />
61<br />
●<br />
102036<br />
Portable transmissive<br />
futur 5<br />
36 V/ 400 W<br />
5,000<br />
●<br />
●<br />
●<br />
vario focal<br />
300-340<br />
–<br />
–<br />
O<br />
●<br />
–<br />
13.5<br />
460 (620)<br />
340<br />
750 (260)<br />
●<br />
O<br />
O<br />
60<br />
●<br />
108036<br />
futur 10<br />
metal halide<br />
575 W, DE<br />
more than<br />
11,000*<br />
●<br />
–<br />
●<br />
vario focal<br />
300-340<br />
–<br />
–<br />
O<br />
●<br />
●<br />
14.5<br />
460 (620)<br />
340<br />
750 (260)<br />
●<br />
O<br />
O<br />
60<br />
●<br />
108575<br />
futur 10-KC<br />
metal halide<br />
575 W, DE<br />
more than<br />
10,000*<br />
●<br />
–<br />
●<br />
vario focal<br />
300-340<br />
–<br />
–<br />
O<br />
●<br />
●<br />
14.5<br />
460 (670)<br />
350<br />
810 (260)<br />
●<br />
O<br />
–<br />
60<br />
●<br />
108575-KC<br />
Overview Overhead Projectors<br />
65
Copyboards<br />
66<br />
PLUS Copyboard Manager USB –<br />
no one is taking notes, everyone is listening<br />
Highlights<br />
● Floor stand included in delivery standard<br />
● Easy set-up and handling<br />
● Integrated USB-1.1 interface for data<br />
transfer to a PC<br />
● Incl. Plus Image Viewer for further<br />
processing of the notes<br />
● File formats: BMP, JPEG, PNG, TIFF<br />
● Incl. TWAIN and printer driver<br />
● B/W thermal paper printout on integrated<br />
printer<br />
1<br />
1) Manager USB<br />
● 2 Writing surfaces in classical landscape<br />
format W/H 124/88 cm<br />
Code No. 10940<br />
System Requirements<br />
● Windows 98SE/Me/2000 Professional/XP<br />
● CPU Pentium II<br />
● 64 MB RAM (128 MB RAM recommended)<br />
● CD ROM drive<br />
● USB-1.1. interface<br />
● Free HDD memory min. 40 MB<br />
(plus memory capacity for image files)<br />
Control of all functions straight at the Board<br />
or over the PC.<br />
Accessories<br />
2) Wall Mounting (without ill.)<br />
Code No. 100094-2<br />
For technical details and accessories please refer to page 69.<br />
copy of the visible<br />
writing surface<br />
copy of the hidden<br />
writing surface<br />
Both writing surfaces can be printed out<br />
on one A4 copy.
Free Product Video for<br />
download on www.medium.de<br />
or to be ordered on a free<br />
CD-ROM, Code No. 52896<br />
Highlights<br />
● <strong>The</strong> first colour copyboard worldwide with<br />
a printout in colour and an integrated<br />
memory function<br />
● No need to connect a PC for saving data<br />
during a meeting<br />
● Data are saved on a compact flash card at<br />
the push of a button<br />
● <strong>The</strong> flash card is flexible and suitable for<br />
universal use<br />
● Data transfer and later processing of the<br />
notes on the PC is possible<br />
● Instant duplication and distribution of the<br />
notes as printout or via e-mail<br />
● Long-lasting, archivable printouts on<br />
standard A4 paper (in colour or B/W)<br />
supersede taking notes so that the<br />
audience pays full attention to the<br />
presenter<br />
● Colour printout is absolutely true to the<br />
original preventing any loss of information<br />
since the colour used for accentuation on<br />
the board is not lost on the printout<br />
● 1:1 Copy of the notes on the board leaves<br />
no room for misinterpretation<br />
● More intense team work is stimulated<br />
Data Transfer at the Push of a Button<br />
● Direct wireless data transfer from board to<br />
compact flash card in *.png-format<br />
● Standard A4 paper printout in 4 colours<br />
(red, green, blue, black) on an external<br />
printer; can be switched to black/white<br />
printing mode<br />
1<br />
3<br />
PLUS Colour Copyboard M-10 –<br />
finally the colour is also on your printout<br />
1) M10S<br />
● Easy to install and use<br />
● Delivery standard includes wall mounting,<br />
printer tray and USB printer cable<br />
● Printer and compact flash card are<br />
not part of the delivery standard<br />
● Suitable for ink jet colour printers from HP<br />
and Epson with printer language PCL 3 e<br />
and USB interface (For a full list of suitable<br />
printers please check www.medium.de)<br />
Code No. 10931<br />
2) M10W<br />
Identical with Code No. 10931 but:<br />
● Size of the copyable surface W/H approx.:<br />
2x each 174/85 cm<br />
● Total dimensions with floor stand W/H/D<br />
approx.: 197/197/60 cm<br />
● Total dimensions wall model W/H/D<br />
approx.: 197/103/22 cm<br />
Code No. 10931-W<br />
Accessories<br />
3) Floor Stand<br />
for Colour Copyboard M10S/M10W<br />
● Mobile<br />
● Height-adjustable to 177, 187 and 197 cm<br />
Code No. 10932<br />
For technical details and accessories please refer to page 69.<br />
Choose printing mode:<br />
expressive 4-colour<br />
printout or quick<br />
black/white printout<br />
Floor stand, printer and compact flash<br />
card are optional accessories<br />
Save the notes straight<br />
from the board onto a<br />
compact flash card and<br />
print them out - at the<br />
push of a button - via an<br />
external colour printer<br />
PC-free saving of data:<br />
save up to 640 board<br />
pages on a 128 MB<br />
compact flash card<br />
Transfer the data from<br />
the compact flash card<br />
via a card reader (here<br />
via a PC card adapter)<br />
in the past<br />
today<br />
Copyboards<br />
67
Copyboards<br />
1<br />
2<br />
3<br />
68<br />
Printouts on standard paper at<br />
the touch of a button and/or<br />
data transfer via USB interface<br />
Panasonic Copyboards UB Series –<br />
take the meeting minutes along!<br />
Highlights<br />
1<br />
● Delivery standard includes wall mounting<br />
(only UB-7325 excl. wall mounting)<br />
● Integrated USB 1.1 interface (USB 2.0 for<br />
UB-7325) for data transmission to a PC<br />
(supplied without USB cable)<br />
● Incl. Panasonic Document Management<br />
Software (PDMS) for further processing of<br />
the minutes<br />
● Documents can be filed on the PC, printed<br />
out via the board printer or an external<br />
printer or distributed via e-mail<br />
● File formats: BMP, TIFF, PNG or PDF<br />
● Incl. TWAIN and printer driver<br />
● No need to take notes: undivided attention<br />
of your audience<br />
● Intensive team work is stimulated<br />
● Instant duplication and distribution of the<br />
notes<br />
● the meeting notes can be processed on<br />
the PC later<br />
● Control of all functions directly at the<br />
board or via PC<br />
● Printouts in two different exposure levels<br />
● Long lasting, archivable copies in b/w on<br />
standard A4 paper (60-90 g/m2)<br />
● Integrated b/w printer can also be used<br />
via PC<br />
System Requirements<br />
● Windows 98/Me with a min. of 64 MB RAM<br />
● Windows 2000/XP with a minimum of<br />
128 or 256 MB RAM<br />
● CPU Pentium II<br />
● CD-ROM drive<br />
● USB 1.1 interface<br />
(USB 2.0 for UB-7325)<br />
● HDD-free memory with a min. of 40 MB<br />
(plus memory capacity for image data)<br />
1 2 3 4<br />
Standard paper<br />
Copyboard<br />
UB-7325<br />
Standard paper<br />
Copyboard<br />
UB-5815<br />
Standard paper<br />
Copyboard<br />
UB-5315<br />
<strong>The</strong>rmal paper<br />
Copyboard<br />
UB-5310<br />
For technical details and accessories please refer to page 69.<br />
Control of all functions at<br />
the board or via PC<br />
1) UB-7325<br />
● 3 Writing surfaces + 1 projection surface in<br />
landscape format W/H approx. 133/85 cm<br />
● High-quality metal design<br />
● Supplied without wall mounting / floor<br />
stand<br />
Code No. 10979<br />
2) UB-5815<br />
● 2 Writing surfaces in widescreen format<br />
W/H approx. 161.3/85 cm<br />
Code No. 10976<br />
3) UB-5315<br />
● 2 Writing surfaces in classical landscape<br />
format W/H approx. 125/85 cm<br />
Code No. 10975<br />
4) UB-5310<br />
● All benefits of the UB series but with a<br />
thermal paper printer<br />
● 2 Writing surfaces in standard landscape<br />
format W/H approx. 125/85 cm<br />
Code No. 10974
Copyboard Accessories<br />
Copyboard M10S/M10W<br />
Compact Flash Card, 128 MB<br />
● Sufficient for approx. 640 written board<br />
pages<br />
Code No. 10933<br />
USB memory card reading device<br />
for compact flash card<br />
● For data transfer from compact flash card<br />
to PC<br />
● For PCs with USB interface<br />
(without own compact flash card slot)<br />
Code No. 10934<br />
PC card adapter for compact flash cards<br />
● For data transfer from compact flash card<br />
to the laptop<br />
● Compact flash card/PCMCIA card adapter<br />
Code No. 10935<br />
Technical Specifications<br />
Product Name<br />
Code No.<br />
Paper type A 4 size<br />
Resolution<br />
Copy technology<br />
Writing surfaces<br />
Approx. size copying area W/H in cm 2 xeach 124/ 85<br />
Compressed copyable<br />
writing surfaces<br />
Number of copies per copy run<br />
Approx. copy speed per page<br />
Integrated printer<br />
Integrated tray for accessories ●<br />
Approx. total dimensions incl.<br />
floor stand W/H/D in cm<br />
max. 147/197/60<br />
Approx. total dimensions wall<br />
model W/H/D in cm<br />
147/103/22<br />
Approx. weight in kg (* incl. fl. stand) 26/36*<br />
Floor stand<br />
Interface<br />
Wall<br />
mounting<br />
PLUS<br />
Colour Copyboard M10S<br />
10931<br />
standard<br />
8 dots/mm<br />
CCD<br />
2<br />
–<br />
1-20<br />
–<br />
–<br />
CF card optional<br />
CF card reader optional<br />
incl.<br />
Copyboard UB Series<br />
Floor Stand for UB-7325<br />
● Mobile with lockable castors<br />
● Height-adjustable to two levels<br />
Code No. 100092-1<br />
Wall Mounting for UB-7325<br />
Code No. 100094-6<br />
Floor Stand for UB-5815/5315 and 5310<br />
● Mobile with lockable castors<br />
● Height-adjustable to approx.<br />
175, 187.5 and 200 cm<br />
Code No. 10977<br />
<strong>The</strong>rmo Transfer Film/Print Film<br />
for UB-7325/5815 and 5315<br />
2 Films for 140 A4 pages each<br />
Code No. 10978<br />
PLUS<br />
Manager USB<br />
10940<br />
thermal paper<br />
8 dots/mm<br />
CCD<br />
2<br />
2x each 124/88<br />
2<br />
1<br />
11 sec.<br />
●<br />
●<br />
147/189/60<br />
147/92/20<br />
37*<br />
incl.<br />
supplied with<br />
USB cable<br />
Panasonic<br />
UB 7325<br />
10979<br />
standard<br />
8 dots/mm<br />
CCD<br />
3+1 project.surface<br />
133 x 85 cm<br />
n.s.<br />
1-9<br />
15 sec.<br />
●<br />
●<br />
165/188/110<br />
165x140x24<br />
42.5<br />
not supplied with<br />
USB cable<br />
Panasonic<br />
UB 5815<br />
10976<br />
standard<br />
8 dots/mm<br />
image sensor<br />
2<br />
2x each 161.3/85<br />
2<br />
1-9<br />
15 sec.<br />
●<br />
●<br />
173.5/max. 200/110<br />
173.5/133.4/21.2<br />
27<br />
not supplied with<br />
USB cable<br />
incl.<br />
For all Copyboards<br />
● yes – no Supplied with: markers, board wiper All dimensions and weights are approx. specifications. Subject to technical changes and errors.<br />
MEDIUM Whiteboard Markers<br />
Set of 10 whiteboard markers<br />
● Dry-wipe clean<br />
● Black, red, blue, green<br />
Code No. 1838-11<br />
Board Wiper<br />
● With replaceable felt<br />
Code No. 1839-5<br />
Felt Strips, 10 pieces<br />
● Self-adhesive/non-permanent<br />
● For magnetic board wiper<br />
Code No. 1839-6<br />
Cleaning Spray, approx. 100 ml<br />
Code No. 1839-70<br />
<strong>The</strong>rmal Paper Roll<br />
Only for thermal paper copyboards<br />
W/L: approx. 210 mm/30 m<br />
Inner diameter core: 1’’<br />
Packing unit: 6 pieces<br />
Code No. 1154<br />
Panasonic<br />
UB 5315<br />
10975<br />
standard<br />
8 dots/mm<br />
image sensor<br />
2<br />
2x each 125/85<br />
2<br />
1-9<br />
15 sec.<br />
●<br />
●<br />
137.2/max. 200/110<br />
137.2/133.4/21.2<br />
25<br />
not supplied with<br />
USB cable<br />
incl.<br />
Panasonic<br />
UB 5310<br />
10974<br />
thermal paper<br />
8 dots/mm<br />
image sensor<br />
2<br />
2x each 125/85<br />
2<br />
1-9<br />
15 sec.<br />
●<br />
●<br />
137.2/max. 200/110<br />
137.2/140/23.3<br />
23<br />
not supplied with<br />
USB cable<br />
incl.<br />
Accessories / Technical Data Copyboards<br />
69
Slide Projectors<br />
70<br />
1<br />
Braun Slide Projectors – high-performance results<br />
1) PAXIMAT MULTIMAG SC 669<br />
● Microprocessor-controlled flagship model<br />
● Wireless cross dissolve control via<br />
projector's remote control possible in<br />
conjunction with a 2nd model SC 669 - no<br />
accessories required<br />
● Multi-function infrared remote control with<br />
backlight keys<br />
● Selective infrared autofocus which can be<br />
turned off<br />
● Slide change with fade-in function<br />
● Powerful 24 V/250 W halogen lamp with<br />
brightness control and exposure value<br />
memory<br />
● Electronic timer from 0-99 sec. for automatic<br />
slide changing, forward and backward<br />
● Variable brightness adjustment<br />
● Additional PC interface RS-232<br />
Code No. 0131-SC669<br />
Model<br />
MEDIUM Code No.<br />
with multicoated lens Super Paxon<br />
2.8/85 mm MC; incl. 1 compact magazine 50<br />
with multicoated lens Super Paxon<br />
2.8/85 mm MC; and universal magazine (36 slides)<br />
Magazines<br />
PAXIMAT round magazines (100 slides), flat magazines<br />
(36/50 slides), MULTIMAG compact magazine (50 slides)<br />
universal magazine, CS magazine, LKM magazine<br />
Slide<br />
Picture size up to 24x36 mm in 5x5 cm frames<br />
Slide changer<br />
Automatic via infrared remote control<br />
Automatic via cable remote control<br />
Focus<br />
Manual for basic sharpness (with focusing wheel)<br />
Manual for basic sharpness (at the lens)<br />
Automatic via IR autofocus<br />
Manual override via infrared remote control<br />
Manual override via cable remote control<br />
Autofocus to be switched off via infrared remote control<br />
Autofocus to be switched off at the projector<br />
Remote Control (can be integrated)<br />
Multi function infrared remote control (timer, dissolve,<br />
brightness control, fade in/out, sharpness control)<br />
Infrared remote control<br />
Cable remote control<br />
Features<br />
Halogen lamp 24 V<br />
Cross dissolve function with PC or Braun SC 669/SC 668<br />
Slide softlift for single slide projection<br />
Slide light table with sliding lid (with signal)<br />
Infinitely variable brightness control at the projector<br />
Switch for two brightness levels<br />
Backlight LCD on the projector (2 brightness levels)<br />
Automatic lamp dimout during change of slides<br />
Antiblock system, turbo cooling fan, overheat protection<br />
Power supply<br />
14-pin AV connector (for timer/speed sensor/tape)<br />
8-pin AV connector (for serial interface RS232)<br />
6-pin AV connector (for timer/speed sensor/tape)<br />
Approx. dimensions (L/B/H) in cm<br />
Approx. weight (kg)<br />
Subject to technical changes and errors. ● yes – no<br />
2) PAXIMAT MULTIMAG SC-663<br />
● Suitable for cross dissolve projection with<br />
a second projector and control unit<br />
● Switchable, selective autofocus<br />
● Infinitely variable brightness adjustment<br />
● IR remote control<br />
Code No. 0131-SC663<br />
3) PAXIMAT MULTIMAG SC-640<br />
● Powerful basic model of the PAXIMAT<br />
MULTIMAG range<br />
● Lamp economy switch<br />
● For 6 magazine systems<br />
● Selective autofocus<br />
Code No. 0131-SC640<br />
PAXIMAT MULTIMAG<br />
SC 669<br />
0131-SC669<br />
●<br />
–<br />
●<br />
●<br />
●<br />
●<br />
–<br />
●<br />
–<br />
●<br />
●<br />
–<br />
●<br />
–<br />
●<br />
–<br />
–<br />
250 W<br />
●<br />
●<br />
●<br />
–<br />
–<br />
●<br />
●<br />
●<br />
230 V~/50~60 Hz<br />
●<br />
●<br />
–<br />
30.4/29.1/13.6<br />
6<br />
PAXIMAT MULTIMAG<br />
SC 663<br />
0131-SC663<br />
●<br />
–<br />
●<br />
●<br />
●<br />
●<br />
–<br />
●<br />
–<br />
●<br />
●<br />
–<br />
–<br />
●<br />
–<br />
●<br />
–<br />
250 W<br />
–<br />
●<br />
●<br />
●<br />
–<br />
–<br />
–<br />
●<br />
230 V~/50~60 Hz<br />
●<br />
–<br />
–<br />
30.4 /29.1/13.6<br />
5.8<br />
4<br />
4) NOVAMAT E-150<br />
● <strong>The</strong> top model in the compact 150 W slide<br />
projector range<br />
● IR remote control<br />
● IR autofocus<br />
Code No. 0130-E150<br />
5) NOVAMAT 130 AF<br />
● Affordable entry model of the 150 Wslide<br />
projectors<br />
Code No. 0130-130AF<br />
PAXIMAT MULTIMAG<br />
SC 640<br />
0131-SC640<br />
●<br />
–<br />
●<br />
●<br />
●<br />
–<br />
●<br />
●<br />
–<br />
●<br />
–<br />
●<br />
–<br />
–<br />
–<br />
–<br />
●<br />
250 W<br />
–<br />
●<br />
●<br />
–<br />
●<br />
–<br />
–<br />
●<br />
230 V~/50~60 Hz<br />
–<br />
–<br />
●<br />
30.4/29.1/13.6<br />
5.8<br />
NOVAMAT<br />
E 150<br />
0130-E150<br />
–<br />
●<br />
–<br />
●<br />
●<br />
●<br />
–<br />
●<br />
–<br />
●<br />
–<br />
–<br />
–<br />
–<br />
–<br />
●<br />
–<br />
150 W<br />
–<br />
●<br />
–<br />
–<br />
–<br />
–<br />
–<br />
●<br />
230 V~/50~60 Hz<br />
–<br />
–<br />
–<br />
24.5/24.5/12.3<br />
3.8<br />
NOVAMAT<br />
130 AF<br />
0130-130AF<br />
–<br />
●<br />
–<br />
●<br />
●<br />
–<br />
●<br />
–<br />
●<br />
–<br />
–<br />
–<br />
–<br />
–<br />
–<br />
–<br />
●<br />
150 W<br />
–<br />
●<br />
–<br />
–<br />
–<br />
–<br />
–<br />
●<br />
230 V~/50~60 Hz<br />
–<br />
–<br />
–<br />
24.5/24.4/11.9 3.8
6<br />
6) Slide Projector Trolley PT 9-L<br />
● Two-level solution for presentations in<br />
small rooms<br />
● Sturdy, foldable table with two panels<br />
● Upper panel tiltable thanks to crank<br />
mechanism<br />
● Frame: powder-coated circular tube;<br />
Panels: plastics coated<br />
(white with black rim)<br />
Upper panel H/W:<br />
approx. 45/30 cm, height 103.5 cm<br />
Lower panel H/W:<br />
approx . 35/20 cm, height 67 cm<br />
Code No. 1809-L<br />
Accessories<br />
Braun Super Paxon Vario 1:3.5/70–120 mm<br />
Code No. 0130-120<br />
PAXIMAT Original Magazine 50<br />
For 50 2–3.2 mm slide frames, white<br />
Code No. 0134<br />
PAXIMAT Round Magazine<br />
For 100 2–3.2 mm slide frames, white<br />
Code No. 0135<br />
PAXIMAT Multimag Compact Magazine 50<br />
particularly small, for 50 slide frames<br />
(without glass) up to 2 mm thickness,<br />
scatter-protected, dark grey<br />
Code No. 0136<br />
Universal Magazine<br />
Stacking box for 2 x 50 slides for slide<br />
frames with 1.8–3.2 mm thickness<br />
Code No. 0132-M<br />
Halogen Projection lamp 24 V/150 W,<br />
Packing unit 5 pieces<br />
Code No. 1131<br />
Halogen Projection lamp 24 V/250 W,<br />
Packing unit 5 pieces<br />
Code No. 1132<br />
7<br />
Slide Scanner –<br />
save your slides on CD-ROM<br />
7) MULTIMAG SlideScan 4000<br />
● Slide magazine scanner now with<br />
digital ICE technology<br />
● A simple way to digitise slides<br />
● In one scanning run up to 100 slides can<br />
be automatically scanned straight out of<br />
the slide magazine<br />
● No more annoying and time-consuming<br />
insertion of single slides<br />
● Digital ICETM – hardware based dust and<br />
scratch removal by means of infrared<br />
sensors and automatic software correction<br />
● Digital ROCTM - colour correction,<br />
enhancement of colour quality<br />
Technical Data Multimag SlideScan 4000<br />
Image sensor: Linear colour CCD<br />
Optical resolution: 3,600 x 3,600 dpi<br />
Light source: film-friendly LED<br />
Scanning preview: 15 seconds<br />
Scanning speed: approx. 50 sec. (colour scan at 1,800 dpi, without ICE)<br />
Scan area max.: 37.5 x 37.5 mm<br />
Density range: 3.2 Dmax<br />
approx. 90 sec. (colour scan at 3,600 dpi, without ICE)<br />
Multiple feeding: directly from 6 different slide magazine systems<br />
Connections: FireWire (IEEE1394) and 1x USB 2.0<br />
Slide preview: via built-in, backlight window<br />
Features: slide feeder, slide lift with soft brake, antiblock system,<br />
Weight: 2.9 kg<br />
Dimensions (L x W x H): 300 x 290 x 125 mm<br />
slide transport forwards/backwards (at the scanner)<br />
System requirements: Mac: OS X 10.1.5 or higher<br />
PC: Pentium III or higher, min. of 256 MB RAM (512 MB recommended),<br />
Code No. 0142<br />
Microsoft Win2000 or higher<br />
● Digital GEMTM – correction of sharpness,<br />
reduction of graining thus achieving<br />
improved image sharpness<br />
● Compatible to Paximat flat, round and<br />
MULTIMAG compact magazines, universal,<br />
CS and LKM magazines.<br />
Code No. 0142<br />
Accessories<br />
8) SilverFast Ai Scan Software with<br />
IT8 Calibration<br />
● Professional scanning and image<br />
processing software<br />
Code No. 0142-S<br />
Slide Projectors<br />
71
Direct Presenter<br />
72<br />
No more time-consuming preparation of<br />
transparencies: With the MEDIUM<br />
Presenter OPUS (successor of the DP-30)<br />
you can project almost anything, even<br />
3-dimensional objects.<br />
Your benefits:<br />
● project 3-dimensional objects<br />
● present original material vividly<br />
● integrate current data and documents<br />
into your lecture<br />
● react quickly to audience questions<br />
● removable cover hides larger objects<br />
during projection<br />
<strong>The</strong> MEDIUM Direct Presenter OPUS is:<br />
● user-friendly<br />
● usable under daylight conditions<br />
● an indispensable complement to your<br />
presentations with overhead projector and<br />
transparencies<br />
1<br />
1) MEDIUM Direct Presenter OPUS<br />
Worktop W/D: 28.5/28.5 cm<br />
Format: A4 portrait and landscape<br />
Lens: f = 330 mm<br />
Voltage: 230–240 V/ 50 Hz<br />
Lamps: halogen reflectors<br />
4 x 82 V/360 W (ENX)<br />
H/W/D: approx. 32/47/58 cm<br />
Weight: 19.5 kg<br />
Code No. 100240<br />
Simply place the object<br />
onto the projection<br />
surface – ready!<br />
MEDIUM Direct Presenter OPUS –<br />
the modern episcope:<br />
instant projection of threedimensional objects<br />
Image Size Chart Direct Presenter OPUS<br />
Projection distance approx. Image size approx.<br />
Lens f= 330 mm<br />
1.30 m 0.85 m<br />
1.70 m 1.20 m<br />
2.00 m 1.45 m<br />
2.40 m 1.80 m<br />
2.70 m 2.05 m<br />
3.00 m 2.30 m<br />
Accessories<br />
Spare Lamp for OPUS (without ill.)<br />
Packing unit: 4 pieces, (ENX)<br />
Code No. 1134<br />
2) Projection Trolley MEDIUM VT1<br />
3 Models in one!<br />
Detailed description see page 93<br />
Colour: black<br />
H/W/D: approx. 92.5 or 108/60/45 cm<br />
Weight: approx. 13.5 kg<br />
Code No. 1802<br />
Spare lamps for the former MEDIUM Direct<br />
Presenter models DP-30/DP-60 are still<br />
available.<br />
Opus with VT1, Code No. 1802, see page 93<br />
2
How to find the right screen for any presentation<br />
<strong>The</strong> main considerations for choosing the<br />
right screen are:<br />
● the screen type<br />
● the screen size<br />
● the aspect ratio (width/height)<br />
● the screen surface<br />
● the projector<br />
<strong>The</strong> Screen Type<br />
Mobile or fixed? <strong>The</strong> broad MEDIUM product<br />
range offers the correct screen solution for<br />
any presentation requirement. Thanks to<br />
their perfectly flat surfaces all screens<br />
provide an excellent image performance.<br />
<strong>The</strong> Screen Size<br />
<strong>The</strong> general rule of thumb to determine<br />
screen size is:<br />
● the minimum distance from screen to the<br />
front row of seats should be 1.5 times the<br />
width of the screen<br />
● the maximum distance for the audience<br />
should not exceed 6 times the screen<br />
width<br />
● the lower border of the screen should be<br />
90 - 120 cm above the floor (for seated<br />
rows!)<br />
<strong>The</strong> Aspect Ratio<br />
Each projection method has its particular<br />
ratio of width to height. <strong>The</strong> most common<br />
ratios are:<br />
Projection size W : H<br />
Digital video projection 4 : 3<br />
Widescreen projection (HDTV) 16 : 9<br />
Overhead projection 1 : 1<br />
Slide projection 3 : 2<br />
Moreover, many MEDIUM screen types can<br />
be adjusted to specific project or customer<br />
requirements.<br />
<strong>The</strong> appropriate screen for any presentation<br />
<strong>The</strong> Screen Surface<br />
<strong>The</strong> reflection quality of your screen is<br />
defined by the brightness gain:<br />
● <strong>The</strong> higher the brightness gain, the more<br />
restricted the viewing angle<br />
Different coatings of the screen surface<br />
involve different reflective properties.<br />
MEDIUM offer screens with two different<br />
reflection properties.<br />
Type D (d=diffuse) Screen Surfaces:<br />
● scatter the light evenly in all directions<br />
(horizontally and vertically)<br />
● have a matt white surface<br />
● provide good viewing angle conditions up<br />
to 45° r/l of the projection axis and<br />
acceptable conditions even up to 55-60°<br />
● correspond to a measured brightness gain<br />
factor of 1.0 - 1.2 (DIN 19045)<br />
Type S (s=specular) Screen Surfaces<br />
● reflect the light along the projection axis<br />
twice as intensely as Type D screens<br />
● have a pearl pigment coating<br />
● provide excellent, very bright viewing<br />
conditions up to 30-40° r/l of the<br />
projection axis<br />
● correspond to a measured brightness gain<br />
factor from 1.8 - 2.4 (DIN 19045)<br />
Roll down Tripod Fold Mobile Table top<br />
Projection type Type D Type S Screen Screen Screen Screen Screen<br />
Stationary use ● ● ● ● ● – –<br />
Mobile use<br />
Brighter room without<br />
dimming / less<br />
● ● – ● ● ● ●<br />
powerful projector – ● ● ● – ● ●<br />
Audience seated in centre<br />
Darkened room/<br />
– ● ● ● – ● ●<br />
powerful projector ● – ● ● ● ● ●<br />
Audience seated spread out ● – ● ● ● – ●<br />
● recommended – not optimally suited<br />
0% 10% 100%<br />
Listen View<br />
optimal information processing<br />
<strong>The</strong> Screen Size<br />
e Screen width<br />
r Recommended height of lower screen edge<br />
t Minimum distance: 1.5x the projection width<br />
u Maximum distance: 6x the projection width<br />
i Viewing angle of 45-50°<br />
o Viewing angle of 30-40°<br />
<strong>The</strong> Projector<br />
Type D screens are mainly suited for medium<br />
to high brightness projectors (2,000 ANSI<br />
lumens and above) in rooms that can be<br />
partially darkened. <strong>The</strong> projection surface<br />
should not exceed approx. 5 m≈.<br />
Type S screens achieve better results when<br />
less bright projectors are used, in<br />
environments with a high degree of ambient<br />
light or when large screen surfaces are<br />
required.<br />
Reflection properties Type D/S<br />
Brightness gain factor<br />
2<br />
1.5<br />
1<br />
0.5<br />
50° 40° 30° 20° 10° 0° 10° 20° 30° 40° 50°<br />
Viewing angle<br />
Projector<br />
● type S screen<br />
● type D screen<br />
● regular = standard white<br />
Screen<br />
● All MEDIUM screens are CE certified and<br />
conform to DIN 19045,1-5 / DIN 4102 B2<br />
technical standards.<br />
● Please contact your local MEDIUM partner to<br />
discuss your projection requirements and<br />
solutions.<br />
Screens<br />
73
Mobile Screens<br />
MEDIUM Table Screen LCD Mobile –<br />
portable and lightweight<br />
Highlights<br />
● <strong>The</strong> screen for mobile use<br />
● A true lightweight and ready to use in no<br />
time at all: simply pull the screen open -<br />
fold out the legs - ready!<br />
● Screen casing protects against dust and<br />
dirt<br />
● Casing: black<br />
Screen Surface<br />
● Front projection, Type S<br />
● Gain factor approx. 2<br />
(DIN 19045)<br />
● Black border of 2 cm at top and bottom<br />
● Rear side: black<br />
Truly brilliant<br />
projections even in<br />
smallest rooms<br />
Accessories<br />
2) Shoulder Bag for Table Screen LCD Mobile<br />
Black nylon bag with long shoulder strap for<br />
convenient and safe transport.<br />
Shoulder Bag for LCD Mobile<br />
for size W/H in cm Code No.<br />
107/76 18400-04<br />
82/61 18400-03<br />
Shoulder bag<br />
Screen size Diagonal Extern. dimens. Weight Code No.<br />
approx. W/H in cm cm/inch approx. W/H in cm approx. in kg<br />
107/76 127/50 107/80 2 184032<br />
82/61 100/40 82/65 1.7 184031<br />
74 Scale drawings and technical data of all screen types can be found on www.medium.de<br />
2<br />
Safe stand thanks<br />
to 4 fold-out feet<br />
Spring mechanism<br />
at the back
Available in two<br />
formats:<br />
4:3 and 16:9<br />
Highlights<br />
● Revolutionary development in the area<br />
of mobile screens<br />
● Unrivalled light<br />
● Ultra mobile: compact dimensions and<br />
instant set-up in no time at all thanks to<br />
an easy assembly system<br />
● Perfect flatness of screen surface thanks<br />
to special tensioning mechanism<br />
● Telescopic height-adjustment<br />
● Space saving: set-up, transport and<br />
storage<br />
● 4-point-base for smallest foot print and<br />
good stability<br />
External dimensions Diagonal Weight Code No.<br />
approx. W/H in cm cm/inch approx. in kg<br />
incl. black border (5 cm)<br />
Video format 4:3<br />
4:3<br />
180 x 135 225/88.6 5.3 13301<br />
200 x 150 250/98.4 5.8 13302<br />
240 x 183 302/119 6 13303<br />
Cinema format 16:9<br />
16:9<br />
Unique: easyfixx comfort –<br />
the ideal solution for mobile use<br />
● Black border - 5 cm - for clean edges,<br />
the image appears clearer in terms of<br />
contrast<br />
● Supplied with sturdy black nylon bag<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, foil basis<br />
● Back: grey<br />
Accessories<br />
Wall Mounting<br />
Code No. 13309<br />
180 x 101 207/81.5 4.8 13306<br />
200 x 113 230/90.5 5.1 13307<br />
240 x 140 278/109 6 13308<br />
Wall mounting bracket<br />
Scale drawings and technical data of all screen types can be found on www.medium.de<br />
Height<br />
Width<br />
Diagonal<br />
Mobile Screens<br />
75
Mobile Screens<br />
Infinitely height-adjustable<br />
MEDIUM Movielux Compact –<br />
the mobile screen for the small budget<br />
Highlights<br />
● With integrated carry handle for<br />
convenient transport<br />
● Sleek, modern design<br />
● Quick and easy set-up<br />
● Projection surface infinitely<br />
height-adjustable<br />
● Optimal flatness of screen surface<br />
● Black border for clean edges,<br />
the image appears clearer in terms of<br />
contrast<br />
● Space-saving storage; mounting for<br />
telescopic tripod underneath the<br />
screen casing<br />
● No loss of space through tripod feet<br />
● Available in both 1:1 and 4:3 format<br />
● Casing colour: white aluminium, RAL 9006<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, foil basis<br />
● Black border of 2 cm<br />
● Back: grey<br />
Image size A B C Diagonal Weight<br />
approx. W/H cm cm cm cm/inch approx. in kg Code No.<br />
120/ 90 cm 134 152 53 145/57 9 13035<br />
160/120 cm 174 181 52 195/77 11 13036<br />
160/160 cm 174 202 33 220/87 11 13037<br />
180/135 cm 194 209 65 225/89 11 13038<br />
B<br />
Height<br />
Diagonal<br />
Carry handle<br />
Reverse side: simply<br />
insert the tripod pole<br />
Sleek, modern design<br />
Mounting bracket for<br />
tilting the screen<br />
surface<br />
76 Scale drawings and technical data of all screen types can be found on www.medium.de<br />
Width<br />
A<br />
C<br />
24.5 cm<br />
8.5 cm
MEDIUM Movielux Mobile –<br />
movable and ready for use anytime, anywhere<br />
Highlights<br />
● Convenient and flexible – also suitable for<br />
professional presentations while travelling<br />
● Meets high standards in both quality and<br />
design<br />
● Projection surface is integrated into a<br />
solid, well-designed aluminium case that<br />
protects it against dust and damage<br />
● Quick and easy set-up: just pull the<br />
projection screen up out of the case<br />
● Four castors and two carry handles allow<br />
easy transport of this screen<br />
● Perfect flatness of the screen surface<br />
thanks to scissor action<br />
● Black border for clean edges,<br />
the image appears clearer in terms of<br />
contrast<br />
● Space-saving storage<br />
Image size A B C Diagonal Weight<br />
● No loss of space through tripod feet<br />
● Available in both 1:1 and 4:3 format<br />
● Casing colour: black, RAL 9005<br />
Screen Surface<br />
● Front projection<br />
● Woven base<br />
● Black border of 2 cm<br />
● Back: black<br />
approx. W/H cm cm cm cm/inch approx. in kg Code No.<br />
155/115 cm 175 190 64 195/77 14 13041<br />
155/155 cm 175 190 24 220/87 14 13044<br />
175/125 cm 195 194 58 219/86 15.5 13042<br />
196/147 cm 215 224 66 245/96 17.5 13045<br />
196/196 cm 215 224 17 277/109 17.5 13046<br />
B<br />
Height<br />
Width<br />
Diagonal<br />
A<br />
11 cm<br />
18.5 cm<br />
Back with<br />
scissor action<br />
Wheels and handle for<br />
easy transportation<br />
Scale drawings and technical data of all screen types can be found on www.medium.de<br />
C<br />
Mobile Screens<br />
77
Tripod Screens<br />
Highlights<br />
● For universal use: professional slide,<br />
overhead and data/video projection<br />
● Sturdy aluminium light construction<br />
tripod, very stable and suited for<br />
permanent use<br />
● Elegant design and easy set-up<br />
● Pneumatically cushioned telescopic height<br />
adjustment of the screen surface<br />
● Carry handle for convenient transportation<br />
● Screen lock for safe transport<br />
● Tensioning mechanism for optimal<br />
flatness of screen<br />
● Fold-out mounting bracket for tilting the<br />
projection surface<br />
(for keystone correction)<br />
● Casing colour: light grey, RAL 7035<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, woven fabric base<br />
● Back: black<br />
Ultralight aluminium<br />
tripod - very stable<br />
MEDIUM Tripod Screen Starello BUSINESS –<br />
the extremely stable first class screen<br />
Accessories<br />
Protective Cover/Transport Bag<br />
Made of robust nylon fabric<br />
Colour: black<br />
Bag for Starello BUSINESS<br />
for size W/H Code No.<br />
150/150 cm 13027<br />
180/180 cm 13030<br />
200/200 cm 13030<br />
External dimensions<br />
Projection surface Weight in kg<br />
approx. W/H approx. Code No.<br />
Type D<br />
150/150 cm 8.5 13015<br />
180/180 cm 12 13016<br />
200/200 cm 15 13017<br />
Carry handle for<br />
height-adjustment<br />
and transport<br />
78 Scale drawings and technical data of all screen types can be found on www.medium.de<br />
Height<br />
Width
1 2<br />
3<br />
MEDIUM Tripod Screens<br />
Combiflex STANDARD and Starflex BUDGET –<br />
the stable business & economy solutions<br />
1) MEDIUM Combiflex STANDARD<br />
● Stable square-bar steel tripod<br />
● Convenient handle for easy transport<br />
● Screen lock for safe transport<br />
● Infinitely height-adjustable screen surface<br />
● Screen clamp button guarantees optimal<br />
flatness of screen surface<br />
● Fold-out mounting bracket for tilting the<br />
projection surface<br />
(for keystone correction)<br />
● Casing colour: white aluminium,<br />
RAL 9006<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, foil basis<br />
● Back: black<br />
External dimensions<br />
projection surface Weight in kg<br />
approx. W/H approx. Code No.<br />
150/150 cm 9.5 13005<br />
180/180 cm 10.7 13006<br />
200/200 cm 14.5 13007<br />
2) MEDIUM Starflex BUDGET<br />
● Convenient handle for easy transport<br />
● Screen lock for safe transport<br />
● Infinitely height-adjustable screen surface<br />
● Screen clamp button guarantees optimal<br />
flatness of screen surface<br />
● Fold-out mounting bracket with raster for<br />
tilting the projection surface<br />
● Casing colour: black, RAL 9005<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, foil basis<br />
● Back: black<br />
External dimensions<br />
projection surface Weight in kg<br />
approx. W/H approx. Code No.<br />
125/125 cm 6 13001<br />
150/150 cm 7 13002<br />
175/175 cm 10.5 13003<br />
Accessories<br />
3) Protective Transport Bag<br />
Made of sturdy nylon fabric<br />
Colour: black<br />
Handle for<br />
height-adjustment and<br />
easy transportation<br />
Protective transport bag<br />
made of sturdy nylon<br />
fabric<br />
Bag for Combiflex STANDARD<br />
for size W/H Code No.<br />
150/150 cm 13026<br />
180/180 cm 13027<br />
200/200 cm 13030<br />
Bag for Starflex BUDGET<br />
for size W/H Code No.<br />
125/125 cm 13025<br />
150/150 cm 13026<br />
175/175 cm 13027<br />
Scale drawings and technical data of all screen types can be found on www.medium.de 79<br />
Tripod Screens
Fold Screens<br />
80<br />
MEDIUM Fold Standard –<br />
the mobile companion for big events<br />
Highlights<br />
● Mobile and flexible fold screen even for<br />
large formats<br />
● Easy assembly system: expansible<br />
snap-on frame made of single elements of<br />
a maximum length of 120 cm<br />
● Screen surface with approx. 5 cm black<br />
border reinforcement for projections richer<br />
in contrast<br />
● Screen surface is attached to the frame<br />
with snap fasteners<br />
● Frame consists of high-quality approx.<br />
32/32 mm square aluminium profile;<br />
optionally expansible up to 900/300 cm<br />
● No tools required for assembly and<br />
disassembly<br />
● Height-adjustable from approx. 5 up to<br />
140 cm (in increments of 15 cm)<br />
● Stable, fold-away feet<br />
● Small packing size (only approx. 120 cm)<br />
● Robust carrying case for frame and screen<br />
included in delivery standard<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, foil basis<br />
● Back: grey<br />
● 5 cm wide surrounding border<br />
Available upon request:<br />
● Screen surfaces individually<br />
● Rear projection screen surfaces<br />
● Other formats<br />
Accessories<br />
Wheeled Case for convenient transport<br />
and safe storage.<br />
● Robust, practical and shapely: the<br />
transport case for all MEDIUM Fold<br />
Screens Exclusive and Standard<br />
● Separate compartment for a maximum of<br />
two screen surfaces<br />
● Stackable to save space<br />
● With 2 wheels and a handle<br />
Material: polyethylene<br />
Colour: grey<br />
L/W/H: approx. 124/36/34 cm<br />
Code No. 18467<br />
External dimensions W/H approx.:<br />
incl. black Weight in kg<br />
border (5 cm) approx. Code No.<br />
Video format 4:3<br />
210/160 cm 11 18449<br />
240/180 cm 13 18450<br />
280/210 cm 14 18451<br />
320/245 cm 15 18457<br />
360/270 cm 17 18458<br />
400/300 cm 18 18452<br />
1:1<br />
250/250 cm 15 18454<br />
300/300 cm 16 18455<br />
Snap-on frame<br />
(expansible)<br />
Screen surface with<br />
5 cm black border<br />
reinforcement<br />
Frame consisting of<br />
32/32 mm square<br />
aluminium profile<br />
Scale drawings and technical data of all screen types can be found on www.medium.de
MEDIUM Fold Exclusive –<br />
particularly stable with one-piece frame<br />
Highlights<br />
● Sophisticated design frame-folding system<br />
allowing easy assembly and disassembly<br />
● One-piece frame prevents loss or<br />
mix-up of individual components -<br />
ideal for rental services!<br />
● Frame consists of high-quality 32/32 mm<br />
square aluminium profile<br />
● Automatically locking, stable snap joints<br />
on the frame and foot supports<br />
● Screen surface with 10 cm wide, black<br />
border reinforcement for projections richer<br />
in contrast<br />
● Screen surface is attached to the frame<br />
with snap fasteners<br />
● No tools required for assembly and<br />
disassembly<br />
● <strong>The</strong> height is adjustable from approx.<br />
5 - 140 cm (in increments of 15 cm)<br />
● Stable, fold-away feet<br />
● Dimensions in accordance with<br />
international standards<br />
● Small packing size of only 125 cm (length)<br />
External dimensions W/H approx.:<br />
incl. black Weight in kg<br />
border (10 cm) approx. Code No.<br />
Video format 4:3<br />
220/170 cm 13 18518<br />
264/203 cm 17 18519<br />
300/230 cm 18 18528<br />
325/249 cm 20 18529<br />
345/264 cm 21 18531<br />
406/310 cm 24 18540<br />
125<br />
1:1<br />
203/203 cm 14 18521<br />
294/294 cm 16 18530 approx.<br />
● Supplied with a robust carrying case<br />
for frame and screen<br />
Screen surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, foil basis<br />
● Back: grey<br />
● 10 cm wide surrounding border<br />
Available upon request:<br />
● Screen surfaces individually<br />
● Rear projection screen surfaces<br />
● Other formats<br />
Accessories<br />
see page 80<br />
Folding system with<br />
one-piece frame<br />
cm<br />
From a handy package<br />
(only 4 individual parts)<br />
the screen frame<br />
unfolds in just a few<br />
steps<br />
Height-adjustable from<br />
approx. 5 to 140 cm<br />
Proven snap joint locks<br />
automatically and can<br />
be folded up easily at<br />
the touch of a button<br />
One-piece folding frame<br />
<strong>The</strong> screen surface<br />
snaps on with snap<br />
fasteners. <strong>The</strong> feet are<br />
fixed to the rear side<br />
with wing screws.<br />
up to 406 cm<br />
Scale drawings and technical data of all screen types can be found on www.medium.de<br />
up to 310 cm<br />
up to 510 cm<br />
Fold Screens<br />
81
Wall Screens<br />
With wall/ceiling spacer and swivel head,<br />
tiltable<br />
MEDIUM Wall Screen Rollux 2 –<br />
pull down - tilt - swivel all in one easy step<br />
Highlights<br />
● Distortion-free projection thanks to INC<br />
(I = inclination) technology<br />
● Suitable for wall or ceiling mounting<br />
● Optimal flatness of screen surface thanks<br />
to scissor action on the back<br />
● Casing colour: white, RAL 9010<br />
With optional accessories the Rollux 2:<br />
● Tilts from 0-15 degrees<br />
● Infinitely swivels to the right and left<br />
● Is suited for mounting into suspended<br />
ceilings<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, foil basis<br />
● Back: black<br />
Accessories<br />
Instructions for optimal installation<br />
Desired installation: Required Accessories: Code No.<br />
Ceiling installation No accessories required<br />
Built- in suspended ceiling Spacer (does not swivel) 13063<br />
Ceiling mounting + No accessories required (just<br />
Tiltable from 0 to 15 degrees an appropriate distance to the wall)<br />
Ceiling mounting + Swivel head + appropriate 13064<br />
infinitely tiltable distance to the wall<br />
Wall mounting No accessories required<br />
Wall mounting + Spacer 30-50 cm 13063<br />
Tiltable from 0 to 15 degrees<br />
Wall mounting + Spacer 30-50 cm 13063<br />
infinitely tiltable + swivel head 13064<br />
Wall/Ceiling Spacer<br />
Allows mounting of the screen into<br />
suspended ceilings as well as tilting the<br />
screen to eliminate the keystone effect when<br />
wall-mounted.<br />
Spacing 30, 40 and 50 cm<br />
Code No. 13063<br />
Swivel Head<br />
Facilitates infinite screen swivelling to the<br />
left or right (when wall-mounted only in<br />
combination with wall/ceiling spacer Code<br />
No. 13063)<br />
Code No. 13064<br />
With wall/ceiling spacer<br />
Back: with spacer and<br />
swivel head, tilted<br />
Infinitely tiltable with<br />
swivel head<br />
Code No. 13064<br />
Back: scissor action for<br />
optimal flatness of<br />
screen surface<br />
External dimensions projection surface<br />
82 Scale drawings and technical data of all screen types can be found on www.medium.de<br />
Height<br />
Width<br />
30–50 cm<br />
W/H approx.: Code No.<br />
150/150 cm 13060<br />
180/180 cm 13061<br />
200/200 cm 13062
MEDIUM Wall Screens Premium and Universal –<br />
ready to use in no time at all<br />
MEDIUM Wall Screen Premium<br />
● Ready for use in one easy step thanks to<br />
the proven rolldown principle<br />
● Infinitely variable format selection<br />
● Square casing in a modern design<br />
● Can be wall or ceiling mounted<br />
● Can be tilted to eliminate keystone effect<br />
(optional spacer required)<br />
● Casing colour: white, RAL 9010<br />
● Supplied with pull-down cord<br />
● For universal use with slide, overhead and<br />
data/video projection<br />
● In 1:1 format (without black border)<br />
● In 4:3 and 16:9 format<br />
(with black border)<br />
External dimensions Premium<br />
approx. W/H Code No.<br />
Format 1:1<br />
150/150 cm 13355<br />
180/180 cm 13356<br />
200/200 cm 13357<br />
240/240 cm 13358<br />
External dimensions Universal<br />
approx. W/H Code No.<br />
Format 1:1<br />
150/150 cm 184821<br />
180/180 cm 184831<br />
200/200 cm 184841<br />
Premium Black border<br />
External dimensions Image size Diagonal at the top Code No.<br />
A B C D E F<br />
approx. W/H cm cm cm cm/inch cm<br />
Video format 4:3<br />
180 164 176 132 220/87 30 13361<br />
200 179 196 147 245/96 30 13362<br />
240 209 236 177 295/116 30 13363<br />
Cinema format 16:9<br />
MEDIUM Wall Screen Universal<br />
● Entry model at an affordable price<br />
● Ready for use in one easy step thanks to<br />
the proven rolldown principle<br />
● Square casing, white sheet steel<br />
● Can be wall or ceiling mounted<br />
● In 1:1 format (without black border)<br />
Screen Surface for Wall Screens<br />
Premium and Universal<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, on a woven fabric base<br />
● Back: black<br />
180 164 176 99 202/80 63 13366<br />
200 179 196 110 225/89 67 13367<br />
240 209 236 133 271/107 74 13368<br />
Accessories<br />
Wall/Ceiling Spacer<br />
for Wall Screen Universal<br />
Optionally adjustable up to 55 cm<br />
Code No. 184851<br />
Scale drawings and technical data of all screen types can be found on www.medium.de<br />
Wall/Ceiling Spacer<br />
for Wall Screen Premium<br />
Facilitates tilting of the screen to eliminate<br />
the keystone effect.<br />
● Incl. tilt-adjustable wall bracket<br />
● Spacing 30 cm<br />
● Colour: white, RAL 9010<br />
Code No. 13370<br />
Premium 4:3 and 16:9<br />
formats have a black<br />
border<br />
Wall Screen Premium<br />
F<br />
B D E<br />
C<br />
A<br />
2 cm<br />
Wall Screens<br />
83
Wall Screens<br />
MEDIUM Rollfix Electric Premium and Hand Crank Premium –<br />
MEDIUM Rollfix Electric Premium<br />
● Maintenance-free, quiet operation<br />
thanks to robust tube motor in soundabsorbing<br />
construction<br />
● Soundproof thanks to a covered foam fillet<br />
along the inside of the housing<br />
● Incl. integrated rotary wall switch and 300<br />
cm connection cable (outlet down right)<br />
● Safety thanks to automatic shutdown<br />
feature<br />
● Projection surface infinitely adjustable<br />
● Wall or ceiling mounting possible,<br />
supplied with universal mounting<br />
brackets<br />
● Steel sheet casing, 1.5 mm strong (cross<br />
section 8/8 cm up to fabric width of 240<br />
cm and 10/10 cm up to a fabric width of<br />
300 cm)<br />
● Casing colour: white, RAL 9010<br />
● New: Screen surface sits exactly in the<br />
casing thanks to a conic weight bar<br />
● New: Suitable for installation into<br />
suspended ceilings with separately<br />
packed mounting frame or casing<br />
(see page 86)<br />
● Other formats available upon request<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, on woven fabric base<br />
● Back: black<br />
or as of formats with 240 cm width<br />
● Front projection, Type S<br />
● Gain factor approx. 2.2<br />
(DIN 19045)<br />
● Pearl pigment, woven fabric base<br />
● Back: black<br />
Accessories<br />
for Rollfix Electric Premium<br />
Radio Remote Control with Hand Transmitter<br />
(without ill.)<br />
Receiver + 1 hand transmitter<br />
Code No. 184931<br />
Key Holder<br />
● Lockable to prevent unauthorised use<br />
● Concealed installation<br />
Code No. 13100<br />
Built-up Wall Switch (without ill.)<br />
Rotary switch, up/stop/down<br />
Code No. 13101<br />
Further Accessories<br />
see pages 85/86<br />
Type D<br />
External dimensions projection surface<br />
approx. W/H Code No.<br />
180/180 cm 13230<br />
200/150 cm 13231<br />
200/200 cm 13232<br />
240/180 cm 13233<br />
240/240 cm 13234<br />
300/250 cm 13235<br />
300/300 cm 13236<br />
Integrated rotary wall<br />
switch (incl. in<br />
delivery standard)<br />
Key holder (optional)<br />
Type S<br />
External dimensions projection surface<br />
approx. W/H Code No.<br />
240/180 cm 13237<br />
240/240 cm 13238<br />
300/250 cm 13239<br />
300/300 cm 13240<br />
84 Scale drawings and technical data of all screen types can be found on www.medium.de<br />
Height<br />
Width<br />
Connection cable
the convenient solutions at great value for money<br />
MEDIUM Rollfix Hand Crank Premium<br />
● Removable hand crank prevents<br />
unauthorised use<br />
● User-friendly thanks to smooth-running<br />
crank drive (at the right side)<br />
● Projection surface infinitely adjustable<br />
● Wall or ceiling mounting possible,<br />
supplied with universal mounting<br />
attachment<br />
● Steel sheet casing, 1.5 mm strong (cross<br />
section 8/8 cm up to fabric width of 240<br />
cm and 10/10 cm up to a fabric width of<br />
300 cm)<br />
● Casing colour: white, RAL 9010<br />
● Suitable for installation into suspended<br />
ceilings with accessories<br />
● New: Screen surface sits exactly in the<br />
casing thanks to a conic weight bar<br />
Type D<br />
External dimensions projection surface<br />
approx. W/H Code No.<br />
180/180 cm 13241<br />
200/150 cm 13242<br />
200/200 cm 13243<br />
240/180 cm 13244<br />
240/240 cm 13245<br />
300/250 cm 13246<br />
300/300 cm 13247<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2<br />
(DIN 19045)<br />
● Matt white, on woven fabric base<br />
● Back: black<br />
or as of formats with 240 cm width<br />
● Front projection, Type S<br />
● Gain factor approx. 2.2<br />
(DIN 19045)<br />
● Pearl pigment, on woven fabric base<br />
● Back: black<br />
Height<br />
Width<br />
Type S<br />
External dimensions projection surface<br />
approx. W/H Code No.<br />
240/180 cm 13248<br />
240/240 cm 13249<br />
300/250 cm 13250<br />
300/300 cm 13251<br />
Exact fitting thanks to<br />
conic weight bar<br />
Accessories<br />
Conic weight bar<br />
for Rollfix Electric Premium<br />
and Hand Crank Premium<br />
Scale drawings and technical data of all screen types can be found on www.medium.de<br />
Wall/Ceiling Spacer (without ill.)<br />
Space to wall/ceiling approx. 40 cm<br />
Code No. 13279<br />
Space to wall/ceiling approx. 30 cm<br />
Code No. 13280<br />
Installation Set for Suspended Ceilings<br />
(without ill.)<br />
With this set, up to 100 cm of space can be<br />
bridged in suspended ceilings.<br />
Code No. 13270<br />
New:<br />
Can be ordered with separately packed<br />
mounting frame or housing (see page 86)<br />
Wall Screens<br />
85
Wall Screens<br />
86<br />
Suspended ceiling<br />
MEDIUM Rollfix Premium –<br />
ideal for suspended ceilings<br />
with installation housing or mounting frame<br />
MEDIUM Rollfix Premium<br />
with installation housing<br />
● New: modular, separate installation of<br />
screen and protective casing for efficient<br />
integration into a ceiling<br />
● Particularly suited for installation into<br />
suspended ceilings<br />
● Easy installation thanks to modular<br />
construction. <strong>The</strong> standard product<br />
comprises two modules: the ceiling<br />
installation housing and the screen with<br />
the housing cover<br />
● No requirement for an adaptable opening<br />
as it has been integrated into housing<br />
cover<br />
● Profile housing made of sheet steel, 1.5<br />
mm strong (cross section 8/8 cm up to<br />
fabric width of 240 cm and 10/10 cm up to<br />
a fabric width of 300 cm)<br />
Installation Housing<br />
for surface width approx. Code No.<br />
180 cm 13275<br />
200 cm 13276<br />
240 cm 13277<br />
300 cm 13278<br />
Code numbers for the screens and further accessories<br />
can be found in the charts on pages 84-85.<br />
● Supplied with a flat plug to enable the<br />
Rollfix to be disconnected from<br />
the power supply without the need to<br />
turn off the current<br />
● A mounting set (length 100 cm) for<br />
suspended ceilings is incl. in the delivery<br />
standard of the installation housing<br />
● An optional baffle is available for the<br />
installation housing that can later be<br />
replaced by the screen<br />
Mounting Frame for Suspended Ceilings<br />
Perfect optical housing edges in suspended<br />
ceilings<br />
● Frame integrated into ceiling without extra<br />
adjustment flaps<br />
● Supplied with an installation set (length<br />
100 cm) for suspended ceilings.<br />
Mounting Frame<br />
for surface width approx. Code No.<br />
180 cm 13271<br />
200 cm 13272<br />
240 cm 13273<br />
300 cm 13274<br />
Installation housing<br />
Installation housing<br />
Mounting frame<br />
Scale drawings and technical data of all screen types can be found on www.medium.de
MEDIUM Frame –<br />
provides the right framework ...<br />
at home or in the office<br />
Highlights<br />
● <strong>The</strong> attractive frame for the cinematic<br />
experience at home or for use in the office<br />
● Sleek aluminium frame (width 8 cm) for<br />
projections richer in terms of contrast and<br />
improved brightness perception<br />
● Easy assembly of the frame (snap-on<br />
system)<br />
● Projection surface is fixed on the back on<br />
4 sides with tension poles and hooks<br />
● Guarantees a permanently flat screen<br />
surface for excellent consistent reflection<br />
Image size A B Diagonal<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2 (DIN 19045)<br />
● Matt white, on PVC basis<br />
● 8 cm Aluminium frame<br />
● Back: white<br />
approx. W/H cm cm cm/inch Code No.<br />
Video format 4:3<br />
120/ 90 cm 136 106 150/59 15412<br />
140/105 cm 156 121 175/69 15414<br />
160/120 cm 176 136 200/79 15416<br />
200/150 cm 216 166 250/98 15420<br />
240/180 cm 256 196 300/118 15424<br />
Cinema format 16:9<br />
160/ 90 cm 176 106 184/72 15516<br />
180/102 cm 196 118 207/82 15518<br />
200/113 cm 216 129 230/91 15520<br />
240/135 cm 256 151 275/108 15524<br />
300/169 cm 316 185 344/135 15530<br />
Scale drawings and technical data of all screen types can be found on www.medium.de<br />
B<br />
Height<br />
A<br />
Width<br />
Diagonal<br />
Frame Screens<br />
87
Wall Screens<br />
Choose your desired<br />
format via hand crank or<br />
at the touch of a button<br />
1) MEDIUM Electric Exclusive<br />
1<br />
2<br />
MEDIUM Electric Exclusive and Hand Crank Exclusive –<br />
sophisticated screens<br />
for conference rooms and executive suites<br />
● Infinitely variable format selection at the<br />
touch of a button<br />
● Maintenance-free and extremely quiet<br />
operation thanks to a high-quality electric<br />
motor with rubber coating<br />
● Connection cable – 240 cm long (outlet<br />
top left); excl. switch (see accessories)<br />
● Automatic shutdown feature<br />
● Neutral design: casing and weight bar in<br />
white, RAL 9010<br />
● Extruded aluminium casing, cross section<br />
approx. 9/8.5 cm or approx. 12.5/12 cm<br />
with format 300/300 cm or 16/16 cm as of<br />
format 400/300 cm<br />
● Supplied with universal mounting brackets<br />
for wall or ceiling mounting<br />
● Suitable for installation into suspended<br />
ceilings with accessories<br />
Electric Exclusive<br />
Screen surface: Type D<br />
Format W/H approx.: Code No.<br />
180/180 cm 184918<br />
200/200 cm 184920<br />
240/240 cm 184925<br />
300/300 cm 184930<br />
400/300 cm 184940<br />
400/400 cm 184944<br />
Screen surface: Type S<br />
240/240 cm 1849252<br />
300/300 cm 1849302<br />
400/300 cm 1849402<br />
400/400 cm 1849442<br />
2) MEDIUM Hand Crank Exclusive<br />
● User-friendly thanks to smooth-running<br />
crank (on the left)<br />
● Detachable crank prevents unauthorised<br />
use<br />
● Neutral design: casing and weight bar in<br />
white, RAL 9010<br />
● Extruded aluminium casing, cross section<br />
approx. 9/8.5 cm or approx. 12.5/12 cm<br />
with format 300/300 cm<br />
● Universal mounting brackets for wall or<br />
ceiling mounting are included in delivery<br />
standard<br />
● Suitable for installation into suspended<br />
ceilings with accessories<br />
Hand Crank Exclusive<br />
Screen surface: Type D<br />
Format W/H approx.: Code No.<br />
180/180 cm 1849201<br />
200/200 cm 1849203<br />
240/240 cm 1849253<br />
300/300 cm 1849303<br />
Screen surface: Type S<br />
240/240 cm 1849254<br />
300/300 cm 1849304<br />
88 Scale drawings and technical data of all screen types can be found on www.medium.de<br />
Screen Surface<br />
Electric Exclusive and Hand Crank Exclusive<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2 (DIN 19045)<br />
● Matt white, woven fabric base<br />
● Back: black<br />
or as of format 240 cm width<br />
● Front projection, Type S<br />
● Gain factor approx. 2.2 (DIN 19045)<br />
● Pearl pigment, woven fabric base<br />
● Back: black<br />
Height<br />
Width
3<br />
Inconspicuous mounting into suspended ceilings<br />
with a mounting frame Code No. 18490<br />
4<br />
Especially noise-reduced motor<br />
Wall and Ceiling Spacer (optional) Universal Mounting Brackets (incl. in delivery<br />
standard)<br />
Accessories<br />
3) Mounting Frame for the Integration into<br />
Suspended Ceilings<br />
● No additional adaptable openings<br />
required<br />
● Optically and technically perfect exterior in<br />
suspended ceilings. Must be ordered at<br />
the same time as the screen! Not on stock.<br />
Retrofit is not possible.<br />
Code No. 18490<br />
4) Wall and Ceiling Spacer<br />
● For wall mounting<br />
● For ceiling installation<br />
1 pair<br />
Screen up to size 240 x 240 cm<br />
Protective case 9x8.5 cm, length 60 cm<br />
Code No. 184941<br />
Screen size 300 x 300 cm<br />
Protective case 12.5 x 12 cm, length 60 cm<br />
Code No. 184942<br />
Screen size 400 x 300 cm<br />
and 400 x 400 cm<br />
Protective case 16x 16 cm, length 40 cm<br />
Code No. 184943<br />
5) Mounting Set for Suspended Ceilings<br />
With this set, up to 100 cm of space can be<br />
bridged in suspended ceilings.<br />
1 Set<br />
Screen up to size 240 x 240 cm<br />
Protective case 9x8.5 cm<br />
Code No. 184951<br />
Screen size 300 x 300 cm<br />
Protective case 12.5 x 12 cm<br />
Code No. 184952<br />
Screen size 400 x 300/400 x 400 cm<br />
Protective case 16 x 16 cm<br />
Code No. 184953<br />
Radio remote control<br />
Scale drawings and technical data of all screen types can be found on www.medium.de<br />
3<br />
5<br />
Mounting frame incl. mounting set for suspended<br />
ceilings. Clip brackets at the sides may be removed<br />
for direct access to screen fastening.<br />
7<br />
Only for Screen Electric:<br />
6) Radio Remote Control with Wall<br />
Transmitter (without ill.)<br />
● Receiver for integrated installation<br />
Code No. 18493<br />
7) Radio Remote Control with Hand<br />
Transmitter<br />
● Receiver for integrated installation<br />
Code No. 184931<br />
8) Integrated Wall Switch (without ill.)<br />
● With push button, up/stop/down<br />
Code No. 18491<br />
Further formats – also in 4:3 and 16:9 –<br />
are available upon request.<br />
Wall Screens<br />
89
Wall Screens<br />
MEDIUM Movielux Electric Design –<br />
simply enjoy your home cinema<br />
Highlights<br />
● Attractive design and ease of use<br />
● Suited for both cinema atmosphere at<br />
home or for professional demands in the<br />
conference room<br />
● Projection surface available in 1:1, 4:3<br />
video or 16:9 cinema format<br />
● Black screen border for projections richer<br />
in terms of contrast at 4:3 and 16:9<br />
● Sleek, oval aluminium casing<br />
● Radio remote control with hand<br />
transmitter is included in delivery<br />
standard<br />
● Projection surface infinitely adjustable<br />
● Wall or ceiling mounting possible<br />
● Supplied with spacer elements (40 cm) for<br />
wall mounting only<br />
● Maintenance-free, quiet electric motor;<br />
connection cable approx. 90 cm (outlet<br />
bottom right)<br />
● Security thanks to automatic shutdown<br />
feature<br />
● Casing colour: white, RAL 9003<br />
Image size approx. W/H Black border at top, cm Diagonal, cm/inch Code No.<br />
Video format 4:3<br />
176/132 cm 30 220/87 13343<br />
196/147 cm 30 245/96 13344<br />
236/177 cm 30 295/116 13345<br />
Cinema format 16:9<br />
Screen Surface<br />
● Front projection, Type D<br />
● Gain factor approx. 1.2 (DIN 19045)<br />
● Matt white, woven fabric base<br />
● Black border of 2 cm<br />
● Back: black<br />
Format 1:1 (without black border)<br />
External dimensions<br />
projection surface Code No.<br />
180/180 cm 13340<br />
200/200 cm 13341<br />
240/240 cm 13342<br />
optional: casing colour silver RAL 9006<br />
176/ 99 cm 63 202/80 13346<br />
196/110 cm 67 225/89 13347<br />
236/133 cm 74 270/106 13348<br />
Radio remote control<br />
included in delivery<br />
standard<br />
Accessories<br />
for Movielux Electric Design<br />
Spacer Element for Wall Mounting<br />
Spacing 40 cm<br />
Colour white, RAL 9003<br />
Code No. 13088<br />
Optional:<br />
Wall mounting incl.<br />
spacer element<br />
Sleek,<br />
sophisticated design<br />
Upper<br />
border<br />
90 Scale drawings and technical data of all screen types can be found on www.medium.de<br />
Height<br />
Width<br />
Diagonal<br />
2 cm
117,5–145<br />
112,5–140<br />
1<br />
53<br />
11<br />
Glare-free<br />
illumination<br />
MEDIUM Lecterns –<br />
elegant and prestigious<br />
Highlights<br />
● Height-adjustable<br />
● Great stability<br />
● Stands firmly; can optionally be equipped<br />
with a set of castors<br />
● <strong>The</strong> wooden elements are melanin-coated,<br />
the metal parts powder-coated<br />
● Colour: steel parts light grey RAL 7035,<br />
wood decor light grey<br />
Upon request: available in wood decor beech<br />
(steel parts light grey RAL 7035)<br />
1) MEDIUM Standard<br />
● Infinitely height-adjustable thanks to crank<br />
mechanism<br />
● With integraded anti-glare illumination<br />
● Manuscript panel with approx. 1 cm<br />
protection brink, W/D: approx. 50/43 cm<br />
● Spacious storage compartment (height<br />
approx. 11 cm)<br />
● 3-Way mains socket with 5 m cable<br />
Dimensions with castors:<br />
H/W/D: approx. 117.5–145/64/55 cm<br />
Dimensions with feet:<br />
H/W/D: approx. 112.5–140/64/49 cm<br />
Weight: approx. 48 kg<br />
Code No. 1890-EX<br />
2) MEDIUM Economy<br />
● Easy height-adjustment thanks to hand<br />
wheels<br />
● Open storage for easy access<br />
● Manuscript panel with approx. 1 cm<br />
protection brink,<br />
W/D: approx. 62.5/45.5 cm<br />
● Additional storage panel W/D: approx.<br />
55/25 cm<br />
● Perforated plate at the front<br />
Dimensions with castors:<br />
H/W/D: approx. 106–134.5/62.5/45 cm<br />
Dimensions with feet:<br />
H/W/D: approx. 101–129.5/62.5/45 cm<br />
Weight: approx. 20 kg<br />
Code No. 1894-EX<br />
3) Set of Castors for Standard and Economy<br />
● 4 Smooth-running castors (Ø 75 mm;<br />
2 castors lockable; height 11 cm)<br />
Code No. 18942-EX<br />
4) 20 WIllumination for Lectern Economy<br />
Code No. 18941-EX<br />
Lectern Standard Lectern Economy Lectern Multistage<br />
3<br />
106 – 134,5<br />
101 – 129,5<br />
2<br />
45<br />
62,5<br />
4<br />
73<br />
60<br />
60<br />
5<br />
5) Multistage Lectern<br />
● Stylish lectern with modern design steel<br />
tube arch and solid aluminium column<br />
● Easy height adjustment of the manuscript<br />
panel (via telescopic extension)<br />
● Manuscript panel with approx. 1 cm brink<br />
to prevent documents from slipping off,<br />
W/D: approx. 60/45 cm<br />
● Storage panel infinitely height-adjustable<br />
by hand wheel along an anodised<br />
aluminium column, W/D: 40/30 cm<br />
● Mobility thanks to 4 castors (Ø 65 mm,<br />
height 75 mm), 2 lockable<br />
● Colour aluminium column: anodised<br />
● Colour steel parts: white aluminium<br />
(RAL 9006), powder-coated<br />
● Colour storage panel: medium grey,<br />
similar to RAL 7036<br />
Dimensions H/W/D: 100-130/73/60 cm<br />
Weight: approx. 17 kg<br />
Code No. 18025<br />
50<br />
100–130<br />
5<br />
Lecterns<br />
91
Multimedia Cabinets<br />
92<br />
Multimedia Cabinets –<br />
optimal storage of valuable equipment<br />
Highlights<br />
1 2<br />
● Dust-free storage<br />
● Ventilation grid in each cabinet<br />
● Safety lock and additional bar fastening<br />
for extra safety<br />
● Doors open up to 270° - no obstruction<br />
when doors are open; convenient handling<br />
without risk of damaging the equipment<br />
● 3-Way mains socket with 5 m cable<br />
● Top and bottom shelf: load capacity each<br />
approx. 60 kg<br />
● Extendable middle shelf: load capacity<br />
approx. 20 kg<br />
● Height-adjustable shelf (only TV 7)<br />
● 4 Castors (2 lockable)<br />
● Colour wood decor: grey-white<br />
Colour steel elements: RAL 9002<br />
Safety lock and<br />
additional bar locking<br />
1) MEDIUM TV 7<br />
● Cabinet with 4 doors for storage of all<br />
equipment and accessories<br />
● Separate access to upper and lower<br />
cabinet<br />
● Conveniently accessible cable outlet<br />
● Extremely stable, even with heavy<br />
equipment<br />
External dimensions:<br />
H/W/D: approx. 190/95/63 cm<br />
Inside dimensions TV shelf:<br />
H/W/D: approx. 66.1/91/59 cm<br />
Weight: approx. 75 kg<br />
Code No. 18007-EP<br />
Extendable middle shelf Ventilation grid<br />
MEDIUM TV 7 MEDIUM TV 8<br />
95<br />
95<br />
91<br />
66,1<br />
33<br />
35<br />
32<br />
190<br />
63<br />
59<br />
270° 270°<br />
2) MEDIUM TV 8<br />
● 2-Door cabinet for television, video and<br />
other accessories<br />
● <strong>The</strong> upper shelf has a 4 cm high brink at<br />
the back and the sides for transport<br />
safety<br />
External dimensions:<br />
H/W/D: approx. 120/95/66 cm<br />
Weight: approx. 45 kg<br />
Code No. 18008-EP<br />
95<br />
29,5<br />
30,7<br />
50<br />
120 70<br />
66<br />
95<br />
61,8<br />
270° 270°
1 2<br />
MEDIUM <strong>Conference</strong> and Projection Furniture –<br />
great functionality in timeless design<br />
Highlights<br />
● Frame construction out of solid aluminium<br />
quarter circle profiles with large radiuses<br />
● Lockable tinted glass doors with 260°<br />
hinge-joints<br />
● Control of electronical devices works even<br />
with doors closed<br />
● 3-Way mains socket with 5 m safety cable<br />
● Mobile thanks to 4 smooth running castors<br />
(2 lockable)<br />
1) MEDIUM TV Cabinet Design<br />
● <strong>The</strong> load capacity (60 kg) is additionally<br />
supported by a stabilising frame made of<br />
steel tube located underneath the TV-shelf<br />
● Four tinted glass doors to be opened<br />
independently<br />
● Incl. 2 extensible shelves for video or<br />
other equipment<br />
External dimensions H/W/D: approx.<br />
190/105/60 cm<br />
TV Shelf inside H/W/D: approx. 58/92/55 cm<br />
TV Cabinet with Base Plate at the Bottom<br />
● Load capacity approx. 20 kg<br />
Weight: approx. 60 kg<br />
Code No. 18006-TV-EP<br />
TV Cabinet without Base Plate at the Bottom<br />
(without illustration)<br />
Weight: approx. 58 kg<br />
Code No. 18006-TVOB-EP<br />
105<br />
58<br />
60<br />
190 116<br />
2) MEDIUM TV Trolley Design<br />
● Two lockable tinted glass doors<br />
● 2 Height-adjustable shelves<br />
● Concealed cable duct and a both<br />
detachable and lockable rear panel<br />
Dimensions H/W/D: approx. 84/78/71 cm<br />
Cabinet inside H/W/D: approx. 62/60/50 cm<br />
Weight: approx. 39 kg<br />
Code No. 180010-TV-EP<br />
3) MEDIUM VT1<br />
● Projection trolley with cabinet –<br />
the mobile storage unit<br />
● Approx. 45 cm high, lockable cabinet<br />
● 2x Height-adjustable<br />
(to approx. 88.5 and approx. 109 cm)<br />
● Excellent stability and load capacity<br />
● Easy assembly<br />
● High mobility: 4 castors (2 lockable)<br />
● Beams made of shock- and scratchresistant<br />
black synthetic material<br />
● Cabinet: black coated metal<br />
● Cable outlet (Ø 6 cm)<br />
● Load capacity: approx. 90 kg per shelf<br />
H/W/D: approx. 88.5 or 109/60/45 cm<br />
Weight: approx. 20.5 kg<br />
Code No. 1802-T<br />
MEDIUM TV Trolley Design<br />
78<br />
62<br />
84<br />
4) MEDIUM VT1<br />
● Projection trolley without cabinet<br />
Delivery standard:<br />
● 3 Shelves, 1 assembly set of square<br />
beams with different lengths,<br />
8 pieces of approx. 42.5 cm each,<br />
4 pieces of approx. 22 cm each<br />
● 3 Different combinations of all elements<br />
are possible<br />
More details: see MEDIUM VT1 – 1802-T<br />
Weight: approx. 13.5 kg<br />
Code No. 1802<br />
3<br />
68<br />
4<br />
MEDIUM VT 1 with/without cabinet<br />
4<br />
42,5<br />
4 109<br />
42,5<br />
4 12<br />
68<br />
4<br />
22<br />
4<br />
88,5<br />
42,5<br />
4 12<br />
Ø 6<br />
60<br />
45<br />
Presentation Furniture<br />
VT 1: square beams<br />
provide great stability<br />
93
Multifunctional Trolleys<br />
94<br />
MEDIUM OHP Projection Trolleys –<br />
mobile and versatile<br />
Highlights<br />
● <strong>The</strong> ideal equipment for flexible use in<br />
different rooms<br />
● Vibration-free projection thanks to solid<br />
steel-tube construction<br />
● Very stable and mobile trolley thanks to<br />
4 castors (2 lockable)<br />
● Colour: light grey, RAL 7035<br />
3<br />
MEDIUM PT 4<br />
63<br />
3<br />
Infinitely<br />
height-adjustable<br />
75<br />
120<br />
1<br />
73<br />
28<br />
75<br />
34<br />
2<br />
73<br />
1) MEDIUM PT 4<br />
● Continuous work space of OHP and table<br />
top with the projector embedded into the<br />
cut-out plate<br />
H/W/D: approx. 75-120/73/63 cm<br />
Weight: approx. 25 kg<br />
Table with Cut-out<br />
● For projector with roll feed casette<br />
Cut-out W/D: approx. 42/53 cm<br />
Code No. 1804-MK2<br />
Table with Cut-out<br />
● For projector without roll feed casette<br />
Cut-out W/D: approx. 42/40 cm<br />
Code No. 1804-OK2<br />
2) Table without Cut-out<br />
● <strong>The</strong> free bottom shelf underneath the<br />
table provides extra storage space<br />
W/D: approx. 37.5 x 35 cm<br />
Code No. 1804-OA2<br />
3) Side Panel for PT 4<br />
● Expansion of the worktop for placing<br />
documents<br />
● To be hooked in at the side of the PT 4<br />
W/D: approx. 34/63 cm<br />
Code No. 1810-N2<br />
63<br />
4<br />
4) MEDIUM PT 6<br />
● Height-adjustable worktop of<br />
75-105 cm with OHP cut-out<br />
(W/D: 42/54 cm) for OHP (with<br />
roll feed cassette)<br />
● Side panel W/D: approx. 22/54 cm<br />
(without frame)<br />
● OHP platform: W/D: 42/42 cm<br />
● <strong>The</strong> height of the OHP platform up to<br />
the bottom line of the cut-out is<br />
approx. 24.5 cm<br />
H/W/D: approx. 75-105/70/60 cm<br />
Weight: approx. 25 kg<br />
Code No. 18006<br />
MEDIUM PT6<br />
60<br />
75<br />
Infinitely<br />
height-adjustable<br />
105<br />
70<br />
24,5<br />
75<br />
70<br />
60
Infinitely<br />
height-adjustable<br />
5) MEDIUM PT 5<br />
Lateral adjustment<br />
5<br />
● Handy and mobile, the classical OHP<br />
projection trolley for nearly all standard<br />
overhead projectors<br />
● OHP platform infinitely height-adjustable<br />
● 2 Side panels, adjustable both laterally<br />
and in height<br />
MEDIUM PT 5<br />
30<br />
45<br />
50<br />
18 -32<br />
50-75<br />
50-107<br />
45<br />
50<br />
30<br />
105<br />
45 30<br />
Infinitely<br />
height-adjustable<br />
Lateral adjustment<br />
H/W/D:<br />
Platform: approx. 50–75/45/45 cm<br />
Side panels: approx. 18–32/30/45 cm<br />
Total height: approx. 75–107 cm<br />
Weight: approx. 13 kg<br />
Code No. 18005<br />
45<br />
6<br />
6) MEDIUM PT 3<br />
● Handy, very mobile and stable –<br />
the PT 3 is ready to carry nearly any kind<br />
of equipment<br />
● Platform is infinitely height-adjustable<br />
H/W/D: approx. 62-102/37.5/39 cm<br />
Platform B/T: approx. 37.5/39 cm<br />
Load capacity: up to approx. 20 kg<br />
Total height: approx. 62–102 cm<br />
Weight: approx. 7.5 kg<br />
Code No. 18032<br />
MEDIUM PT 3<br />
38<br />
62<br />
102<br />
38<br />
Infinitely<br />
height-adjustable<br />
Multifunctional Trolleys<br />
95
Multifunctional Trolleys<br />
96<br />
Professional Presentation Furniture by MEDIUM –<br />
handy, sturdy, multifunctional<br />
1) MEDIUM Paladio<br />
● <strong>The</strong> projector is always adjustable to an<br />
optimal height of approx. 89-115 cm<br />
thanks to the continuous height<br />
adjustment (crank handle)<br />
● Top shelf W/D: approx. 40/63 cm,<br />
10 degrees tiltable<br />
● Pull-out platform for a notebook W/D:<br />
approx. 44/38 cm<br />
● Video shelf W/D: approx. 45/47 cm<br />
● Incl. 3-way mains socket with 5 m cable<br />
● Load capacity: approx. 40 kg<br />
● Mobile thanks to 4 castors, (2 lockable)<br />
● Colour: light grey, RAL 7035<br />
H/W/D: approx. 89-115/45/69 cm<br />
Code No. 180111<br />
MEDIUM Paladio<br />
Optional:<br />
3) Steel Panel W/D approx.: 32 x 35 cm<br />
Weight: approx. 4 kg<br />
Code No. 18021<br />
Multistage Media Trolley<br />
45<br />
1<br />
69<br />
89–115<br />
Infinitely<br />
height-adjustable<br />
2) Multistage Media Trolley<br />
● Elegant design with multifunctional<br />
combination options<br />
● Solid and stable steel-tube construction<br />
● Mobile thanks to 4 castors (� 65 mm,<br />
height: 75 mm; 2 lockable)<br />
● Colour: aluminium column: anodised<br />
● Colour: steel elements: white aluminium<br />
(RAL 9006), powder-coated<br />
● Incl. 3 steel panels (35 x 32 cm ) that are<br />
height-adjustable along an anodised<br />
aluminium column and positionable in<br />
height on both sides.<br />
● On the top level 2 steels panels can be<br />
mounted together making up a total<br />
surface of 32 x 70 cm.<br />
● Load capacity of the single steel panels:<br />
approx. 8-10 kg<br />
● 3-Way mains socket with 1.4 m cable for<br />
instant electrification of the devices<br />
H/W/D: 100/55/73 cm<br />
Weight: approx. 16 kg<br />
Code No. 18020<br />
Optional:<br />
4) Steel Panel W/D approx.: 32 x 35 cm<br />
with telescopic extension<br />
● <strong>The</strong> telescopic extension is heightadjustable<br />
(45 cm throw) and lockable<br />
with a hand wheel<br />
Weight: approx. 4.5 kg<br />
Code No. 18022<br />
2<br />
2 Steel panels<br />
positioned at the same<br />
height make up a<br />
surface of approx.<br />
W/D: 32 x 70 cm!<br />
Integrated multioutlet<br />
power strip<br />
<strong>The</strong> telescopic extension<br />
makes the media<br />
trolley approx. 45 cm<br />
higher.<br />
55<br />
73<br />
100–145<br />
100<br />
3<br />
2<br />
4<br />
Steel panels are<br />
individually<br />
height-adjustable<br />
73<br />
60<br />
100–145<br />
100
MEDIUM PT Variant to<br />
be used for digital or<br />
overhead projectors<br />
1) MEDIUM PT Variant<br />
86<br />
47<br />
70-105<br />
15°<br />
15°<br />
3<br />
1<br />
● Whether you need an OHP, LCD, slide<br />
projection trolley or a lectern: the<br />
practical, multi-purpose Variant is all<br />
in one. A small all-rounder for your<br />
presentations!<br />
● Mobile thanks to its free-moving castors<br />
(2 lockable)<br />
● Infinitely height-adjustable thanks to<br />
2 gas-pressured springs; adjusts easily to<br />
all body heights<br />
● Platform<br />
–tilts for LCD and slide projection/<br />
lectern<br />
–stays horizontally for OHP projection<br />
–load capacity: approx. 15 kg<br />
H/W/D: approx. 70 (105)/47/43 cm<br />
(highest position)<br />
Weight: approx. 12.5 kg<br />
Code No. 1811<br />
40,5<br />
22<br />
43<br />
58-86<br />
22<br />
86<br />
40,5 22<br />
40,5<br />
2<br />
Infinitely<br />
height-adjustable<br />
Accessories<br />
2) Two Side Panels<br />
● Infinitely height-adjustable<br />
● Load capacity approx. 10 kg<br />
● W/D: approx. 40.5/22 cm each<br />
● Weight: approx. 3 kg<br />
Code No. 18111<br />
3) One Storage Panel<br />
● Infinitely height-adjustable<br />
incl. front plate<br />
● W/D: approx. 40.5/22 cm<br />
● Weight: approx. 2.5 kg<br />
Code No. 18112<br />
MEDIUM PT Variant<br />
basic model as trolley<br />
for a digital projector<br />
MEDIUM PT Variant as<br />
lectern with storage<br />
panel Code No. 18112.<br />
Front plate for your<br />
company logo imprint is<br />
included.<br />
Swivelmounted<br />
panel<br />
4) MEDIUM VT 3<br />
Infinitely<br />
height-adjustable<br />
● Suitable for most types ofLCD projectors<br />
and notebooks<br />
● Completely stable: provides a vibrationfree<br />
environment for your keyboard<br />
● Top and lower shelves are heightadjustable<br />
thanks to gas-pressured<br />
springs<br />
● Great mobility thanks to large castors,<br />
Ø 12.5 cm<br />
● Both shelves foldable<br />
● Capacity of upper shelf: approx. 10 kg<br />
● Lower shelf swivel-mounted,<br />
load capacity: approx. 5 kg<br />
● Front legs allow tilting<br />
● Great to transport LCD projectors or other<br />
equipment<br />
● Colour: white, RAL 9016<br />
Upper shelf W/D: approx. 35/42 cm<br />
Lower shelf W/D: approx. 24/36 cm<br />
Total height approx. 85-125 cm<br />
Weight: approx. 13 kg<br />
Code No. 18003<br />
MEDIUM PT Variant MEDIUM VT 3<br />
4<br />
85 –125<br />
42 10<br />
36 5<br />
24<br />
35<br />
73–113<br />
Multifunctional Trolleys<br />
97
Flip Charts<br />
98<br />
1<br />
MEDIUM Flip Charts Exclusive, Standard and Mobile –<br />
the classical communication tools<br />
1) Flip Chart Exclusive<br />
● This is the classic model among the<br />
MEDIUM flip charts and a true all-rounder<br />
at that<br />
● White, coated steel surface, magnetic,<br />
write-on and dry-wipe clean<br />
● Sturdy tripod<br />
● Infinitely variable height<br />
● 2 Extractable clip arms for paper on the<br />
sides<br />
● 2 Movable paper hangers for all standard<br />
flip chart pads<br />
● Integrated tray for placing the flip chart<br />
markers<br />
Writing surface H/W: approx. 90/70 cm<br />
Total height: max. 200 cm, variable<br />
Weight: approx. 18 kg<br />
Code No. 1835<br />
3<br />
2) Flip Chart Standard<br />
● Entry model at a feel-good price: handy<br />
and functional<br />
● White, coated steel surface, magnetic<br />
● Sturdy tripod<br />
● Infinitely variable height<br />
● 2 Movable paper hangers for all standard<br />
flip chart pads<br />
● Integrated tray for placing the flip chart<br />
markers<br />
Writing surface H/W: approx. 90/70 cm<br />
Total height: approx. 190 cm, variable<br />
Weight: approx. 11 kg<br />
Code No. 1834<br />
4<br />
2<br />
3) Design Flip Chart Quick Clamp<br />
● Turns any magnetic whiteboard into a flip<br />
chart<br />
● With adjustable paper hangers<br />
● Suitable for all standard paper sizes up to<br />
approx. 100/65 cm (70 g/m 2)<br />
H/W/D: approx. 6/70/3.5 cm<br />
Weight: approx. 0.57 kg<br />
Code No. 1833<br />
Accessories<br />
4) MEDIUM Flip Chart Starter Set<br />
Contents:<br />
● 4 Flip chart markers in red, green, blue,<br />
black<br />
● Magnetic marker holder for 4 markers<br />
● Magnetic board wiper with replaceable felt<br />
strips<br />
● 10 Felt strips for board wiper<br />
● 100 ml Cleaning spray<br />
● 10 Coloured magnets assorted<br />
Code No. 1839-51<br />
MEDIUM Flip chart pads see p.100<br />
Further flip chart accessories see p.100
200<br />
5<br />
5) Flip Chart Mobile<br />
175<br />
infinitely<br />
heightadjustable<br />
from 1.75 m<br />
to 2 m<br />
with set screw<br />
● <strong>The</strong> deluxe model - mobile flip chart with<br />
clip rail and height-adjustment<br />
● User-friendly, ergonomic infinite heightadjustment<br />
thanks to a gas-pressured<br />
spring<br />
● Quick change clip for all current flip chart<br />
pads<br />
● Magnetic surface to write on and<br />
dry-wipe clean<br />
● Integrated tray for markers<br />
● Convenient working thanks to permanent<br />
tilt angle of 30 degrees yet great stability<br />
● Easy to move from one place to another<br />
with 5 smooth-running castors (3 lockable)<br />
● A gap at the front of the floor stand allows<br />
convenient writing on the flip chart<br />
Board size: H/W: approx. 106/74 cm<br />
Total height: approx. 175–200 cm<br />
Weight: approx. 25 kg<br />
Code No. 18348<br />
Flip Chart rotates on<br />
its own axis<br />
Expanded<br />
presentation<br />
surfaces with two<br />
arms attachable<br />
at the sides<br />
Highlights<br />
Innovative communication tool for mobile,<br />
spontaneous meetings and presentations<br />
● Adheres to walls, glass panes, doors and<br />
other even surfaces thanks to an<br />
electrostatic charging, no assembly<br />
required<br />
● Notes, cards or pictures adhere to the<br />
write-on surface without pins or magnets<br />
● Surface can be written on with quality<br />
whiteboard markers; the decent raster<br />
facilitates drafting<br />
● Works with supplied batteries<br />
● Ease of use and a light weight make this<br />
flip chart perfect for presenters on the<br />
move<br />
● Delivery standard includes a handy, robust<br />
transport case<br />
● Size: W/H: approx. 68/90 cm<br />
Code No. 1837<br />
Accessories<br />
Xstatic | meeting:<br />
Take down good thoughts<br />
● A thin white electrostatic adhering<br />
synthetic foil as an alternative to standard<br />
flip chart paper<br />
● Apply a sheet of Xstatic | meeting on an<br />
active Xstatic | chart and write on it or<br />
attach notes to it<br />
● While you are working Xstatic | meeting<br />
charges itself electrostatically<br />
● After 1–2 min. the synthetic foil can be<br />
taken off the Xstatic | chart and be adhered<br />
to any smooth surface (door, wall etc.)<br />
● Format: W/H: approx. 68/90cm<br />
(regular format of flip chart paper)<br />
100 Sheets, colour white, 100 my<br />
Code No. 1837-M<br />
Ideal for mobile use e.g.<br />
in external offices, hotels,<br />
on construction sites etc.<br />
Flip Charts<br />
Xstatic | chart – the all-purpose<br />
electrostatic flip chart<br />
Using Xstatic | chart<br />
is so easy:<br />
Unpack, unroll ...<br />
... switch on for electrostatic<br />
charging ...<br />
... adhere the chart to a<br />
smooth surface ...<br />
... and start your<br />
meeting or training.<br />
99
Multifunctional Board<br />
100<br />
1<br />
MEDIUM Varioboard –<br />
three in one: flip chart, whiteboard and presentation board<br />
Front: whiteboard with flip chart clamp and<br />
flip chart paper<br />
Back: presentation/ pin<br />
board with blue-grey<br />
felt<br />
1) MEDIUM Varioboard<br />
● Inexpensive multiple tasker: flip chart,<br />
presentation board and whiteboard all in<br />
one since both board sides are usable<br />
● Ideal for short meetings and smaller<br />
conference rooms<br />
● One board side is a whiteboard: to write<br />
on, dry-wipe clean, magnetic surface<br />
● Incl. adjustable paper hangers for all<br />
current flip chart pads up to a size of<br />
approx. 65/100 cm<br />
● <strong>The</strong> other board side is a pin board:<br />
blue-grey felt covering for presentation<br />
cards, notes, pictures etc.<br />
● Mobile thanks to 4 castors of which 2 are<br />
lockable<br />
● Colour of frame: light-grey RAL 7035<br />
Board H/W: approx. 120/78 cm<br />
Total H/W: approx. 194/84 cm<br />
Weight: 11 kg<br />
Code No. 185012077<br />
Accessories for Flip Charts<br />
2) MEDIUM Flip Chart Starter Set<br />
Contents:<br />
● 4 Flip chart markers in red, green, blue,<br />
black<br />
● Magnetic marker holder for 4 markers<br />
● Magnetic board wiper with replaceable felt<br />
strips<br />
● 10 Felt strips for board wiper<br />
● 100 ml Cleaning spray<br />
● 10 Coloured magnets assorted<br />
Code No. 1839-51<br />
4<br />
5<br />
6<br />
3<br />
3) MEDIUM Flip Chart Marker<br />
● Set of 10 flip chart markers<br />
● Black, red, blue, green<br />
Code No. 1839-11<br />
4) Magnetic Board Wiper<br />
● With replaceable felt<br />
Code No. 1839-5<br />
5) Felt Strips, 10 pieces<br />
● For magnetic board wiper<br />
● Self-adhesive, non-permanent<br />
Code No. 1839-6<br />
6) Magnetic Marker Holder<br />
● For 4 markers<br />
Code No. 1838-2<br />
7) MEDIUM Flip Chart Pad, white,<br />
wood-free, chequered and plain<br />
20 Sheets with 6x universal punching<br />
W/H: approx. 65/99 cm<br />
Front: chequered (25 mm squares)<br />
Back: plain<br />
Packing unit: 5 pads<br />
Code No. 1836<br />
8) MEDIUM Flip Chart Pad,<br />
recycling paper, chequered and plain<br />
50 Sheets with 6x universal punching<br />
W/H: approx. 65/99 cm<br />
Front: chequered (25 mm squares)<br />
Back: plain<br />
Packing unit: 4 pads<br />
Code No. 1836-50<br />
2
Highlights<br />
● Manifold arrangement combinations of the<br />
partition boards provide utmost flexibility<br />
● Elegant design<br />
● Double-sided cover = benefit of two<br />
useable surfaces<br />
● Sturdy aluminium frame with black<br />
plastic corners<br />
● Either one board can stand alone or<br />
several boards can be interlinked<br />
● All stands and frames are powder-coated<br />
● Colour: light grey, RAL 7035<br />
Possible<br />
combinations<br />
Linking of partition<br />
boards with an<br />
adapter<br />
Aluminium frame with<br />
black plastic corners<br />
GGrreeaat ffor ......<br />
● BBannkkss<br />
● HHootteells<br />
● Loounnggees<br />
● Shhooww rooomms<br />
● EExxhhibitiioonns<br />
● Offiiceess<br />
..... aass aa<br />
● Paarrttiittiioon bbooaarrdd<br />
● Prreesseennttaattionn booard<br />
● IInfoormaationn bboaarrdd<br />
● PPiinn oorr whhiittebboaarrdd<br />
2 1<br />
MEDIUM Partition Boards –<br />
well-organised and clear presentations<br />
3<br />
5<br />
1) – 4) Board Surfaces<br />
● Incl. adapter for fixing the boards to the<br />
floor stands<br />
● Height/width: approx. 150/120 cm<br />
(portrait format)<br />
Surface Code No.<br />
1) Felt, light grey<br />
● heavy duty 1897150<br />
2) Whiteboard<br />
● magnetic<br />
● write-on,<br />
dry-wipe clean 1897154<br />
3) Corkboard<br />
● pierced surface<br />
closes instantly 1897155<br />
4) Whiteboard/Felt Board<br />
● One side magnetic,<br />
write-on,<br />
dry-wipe clean<br />
● Other side<br />
light grey felt 1897156<br />
Available upon request<br />
● Different colour felt covering<br />
● Linen structure surface<br />
5) Floor Stand (without base)<br />
Floor stands always need to be ordered in<br />
addition to the board.<br />
● As lateral support for stand-alone partition<br />
boards<br />
● As central support for interlinked boards<br />
● Oval standpipe, approx. 5 x 2.5 cm<br />
● Height approx. 192 cm<br />
Code No. 1897<br />
5<br />
6) – 8) Floor Stand Bases<br />
Always need to be ordered in addition to the<br />
floor stand.<br />
6) T-Base<br />
● Incl. plastic protection caps, assembly<br />
screws, stoppers<br />
Weight: approx. 1.3 kg<br />
H/W/D: approx. 2.5/5/60 cm<br />
Code No. 18971<br />
7) Plate Base, oval, made of steel<br />
● Incl. assembly screws and stoppers<br />
Oval: W/D: approx. 30/45 cm<br />
Weight: approx. 7 kg<br />
Code No. 18972<br />
8) Middle Base, round<br />
● Black floor adjustment screw incl. plastic<br />
protection cap<br />
● For height adjustment of middle supports<br />
● For optimal stability and floor adherence<br />
of interlinked partition boards<br />
Code No. 18973<br />
6<br />
7 8<br />
3<br />
You need to order:<br />
Partition board<br />
+ Floor stand<br />
(Code No. 1897)<br />
+ Floor stand base<br />
of your choice<br />
Pin/Presentation Boards<br />
101
Display Boards<br />
102<br />
MEDIUM Presentation Accessories –<br />
multi-purpose and colourful<br />
1) MEDIUM Presentation Case<br />
● Elegant, lockable aluminium case with a<br />
clever assortment of presentation aids<br />
● Always ready to hand: clear arrangement<br />
of the various items in preformed<br />
compartments<br />
H/W/D: approx. 16/47/34 cm<br />
Weight: approx. 6.5 kg<br />
Code No. 1896300-M<br />
Contents:<br />
250 Cards, Ø 10 cm, round*<br />
125 Cards, Ø 14 cm, round*<br />
125 Cards, Ø 19 cm, round*<br />
250 Cards, 10x20 cm, rectangular*<br />
250 Cards, 19 cm, oval*<br />
10 Paper markers*, 1 arm pin cushion, 300<br />
pins*, 1 telescopic pointer,<br />
800 marker stickers*, 1 roll of adhesive tape<br />
20 m, 1 pair of scissors, 2 glue sticks,<br />
1 roll of transparent adhesive tape with tape<br />
holder, 1 paper cutter<br />
*in assorted colours<br />
5<br />
1<br />
2) Refill Set for Presentation Case<br />
● In assorted colours:<br />
250 Cards, Ø 10 cm, round<br />
125 Cards, Ø 14 cm, round<br />
125 Cards, Ø 19 cm, round<br />
250 Cards, 10x20 cm, rectangular<br />
250 Cards, 19 cm, oval<br />
Code No. 1896300-S<br />
MEDIUM<br />
Display Boards – ...<br />
Highlights<br />
● Presentation cards and notes can easily be<br />
attached to and removed from the board<br />
with MEDIUM pins<br />
● Large effective area since both board<br />
surfaces are useable (portrait format)<br />
● Mobile with 4 castors (2 lockable)<br />
● Total height incl. floor stand and castors:<br />
approx. 195 cm<br />
● Angled base H/W/D: approx. 1.5/3/60 cm<br />
● Elegant aluminium frame: light grey, RAL<br />
7035, round black plastic corners<br />
Available upon request<br />
● Different colour felt covering<br />
● Linen structure surface<br />
● Straight T-Base<br />
Board surface:<br />
white cardboard<br />
Board surface:<br />
cardboard tinged<br />
with white-grey<br />
Board surface:<br />
blue-grey felt
3) Undivided Display Boards<br />
● For stationary use in seminar rooms<br />
● Stable, continuous presentation surface<br />
● Dimensions of the erected board:<br />
H/W: approx. 150/120 cm<br />
Semicircular<br />
arrangement of<br />
the boards is<br />
possible.<br />
3 4<br />
... encouraging interactive communication<br />
Fields of application:<br />
seminar rooms, exhibitions,<br />
museums, hotels,<br />
congress or training centres<br />
3 4<br />
Undivided Display Boards<br />
Board Surface Weight in Code No.<br />
H/W: approx. 150/120 cm kg approx.<br />
Cardboard, white, two-sided 7.9 18964<br />
Felt, blue-grey, two-sided 8.3 18963<br />
Cardboard, tinged with grey, two-sided 7.9 18965<br />
4) Divided Display Boards<br />
● Well-suited for mobile use: foldable and<br />
easy to transport<br />
● Dimensions of the erected board:<br />
H/B: approx. 150/120 cm<br />
● Dimensions of the folded board:<br />
H/B: approx. 75/120 cm<br />
4<br />
Accessories<br />
5) Shoulder Bag for safe transport<br />
(only for the divided display board)<br />
● Protects against dirt and scratches<br />
● Black nylon fabric<br />
● Sturdy shoulder strap<br />
Code No. 18955<br />
6) Pin Board Paper, light brown<br />
● A useful tool to record the results of your<br />
training sessions<br />
● Simply pin the paper to the board<br />
● H/W: approx. 140/110 cm<br />
● Paper thickness: 60 g/m 2<br />
● 50 Sheets per box<br />
Code No. 18958<br />
7) Set of Pins<br />
● 20 Marker flags<br />
● 20 Pin board needles<br />
● 100 Country map pins<br />
Code No. 1862<br />
Divided Display Boards<br />
Board Surface Weight in Code No.<br />
H/B: approx. 150/120 cm kg approx.<br />
Cardboard, white, two-sided 7.9 18962<br />
Felt, blue-grey, two-sided 8.3 18961<br />
Cardboard, tinged with grey, two-sided 7.9 18960<br />
7<br />
Display Boards<br />
103
Rail System<br />
104<br />
MEDIUM PartnerLine Rail System –<br />
the ideal partner for space-saving solutions<br />
Highlights<br />
● Efficient and eye-catching combination of<br />
individual presentation elements<br />
● Turns even the smallest seminar room into<br />
an auditorium<br />
● Available wall space is used twice thanks<br />
to double rail duct<br />
● Space-saving solution: different<br />
presentation elements can be placed on<br />
top of each other on the two rails<br />
● More freedom of movement - no annoying<br />
floor stands of projection screens<br />
● Walls stay clean thanks to distance rod<br />
with castors<br />
● Easy to mount and use the elements<br />
● Rail material: powder-coated aluminium,<br />
white RAL 9016, white plastic corners, tray<br />
made of white aluminium<br />
All elements are supplied with adapter set<br />
(distance rod/ mounting material).<br />
Decor strip to cover nuts<br />
and joints<br />
Paper clamp roll to hang<br />
up documents<br />
1) Double Rail<br />
● Basic system element: approx. 240 cm<br />
(length can be shortened if required)<br />
● Optimal height of mounting:<br />
approx. 205 cm<br />
● Supplied with: end caps, connecting<br />
elements, decor-strips (white), wall fittings<br />
and paper clamp rolls for posters and<br />
other documents<br />
Code No. 18700<br />
2) Corner Element 90° for Double Rail<br />
● For smooth connection in 90° corners<br />
● 1 Piece<br />
Code No. 18703<br />
3) Adapter Set<br />
● Distance rod and mounting material for<br />
both the upper and lower rail<br />
(for replacement)<br />
Code No. 18702<br />
Shapely end caps cover<br />
the stoppers and the<br />
rail ends<br />
Practical wall distance<br />
rod with castors<br />
Complete package incl.<br />
in delivery standard<br />
Stable corner<br />
connection element<br />
Universal adapter set<br />
This Rail System is compatible to the<br />
MEDIUM Design Rail System.<br />
1<br />
2<br />
3
4<br />
4) PartnerLine Projection Screen<br />
● <strong>The</strong> selection of screens ranges from<br />
standard sizes to screens for small rooms<br />
● 45° viewing angle<br />
● Infinitely tiltable projection surface from<br />
0 - 30°, keystone correction<br />
● Coated hard foam plate with matt white<br />
surface for good results even in broad<br />
daylight (type D)<br />
● Incl. adapter set<br />
Projection screen<br />
seen from the side;<br />
infinitely tiltable<br />
projection surface<br />
PartnerLine Projection Screens<br />
Height/width approx. Code No.<br />
180/180 cm 18711<br />
150/150 cm 18710<br />
125/125 cm 18709<br />
(especially for small rooms)<br />
4<br />
5) PartnerLine Racks<br />
Additional storage for books, video recorder,<br />
writing utensils etc.<br />
● Available in two different designs<br />
● <strong>The</strong> lower shelf is fixed whereas the upper<br />
shelf can be flexibly positioned to 8<br />
different levels<br />
● Load capacity: max. of 25 kg per shelf<br />
● Dimensions H/W: approx. 109/89 cm<br />
● Incl. adapter set<br />
PartnerLine Rack<br />
● 2 Shelves approx. 30/80 cm<br />
● Weight: approx. 3.6 kg<br />
Code No. 18704<br />
PartnerLine TV/Video Rack<br />
● 2 Shelves approx. 50/80 cm<br />
● Weight: approx. 4.5 kg<br />
Code No. 18705<br />
6) PartnerLine Country Maps<br />
6<br />
PartnerLine Country Maps<br />
Code No. Product Description<br />
18730 PL map of Germany<br />
H/B:130 x 100 cm<br />
18732 PL map of Europe<br />
H/B: 84 x 124 cm<br />
18733 PL world map<br />
H/B: 100 x 136 cm<br />
5<br />
7) PartnerLine Brochure Rack<br />
Present your brochures or sales pamphlets in<br />
an inviting way.<br />
● 10 Brochure compartments for A4 size<br />
brochures made of transparent acrylic<br />
● Brochure compartments H/W/D:<br />
approx. 30/23.5/2.5 cm<br />
● Incl. adapter set<br />
H/W/D: approx. 109/29/17 cm<br />
Weight: approx. 3.5 kg<br />
Code No. 18707<br />
7<br />
Brochure rack seen from<br />
the side<br />
7<br />
Rail System<br />
105
Rail System<br />
106<br />
MEDIUM PartnerLine Rail System –<br />
well-organized and clearly arranged<br />
1) PartnerLine Flip Chart<br />
● Versatile stylish flip chart for the upper<br />
rail<br />
● Magnetic enamelled surface,<br />
H/W: approx. 100/70 cm (can also be<br />
used as a whiteboard)<br />
● Flip chart clamp rail with movable paper<br />
hangers for all standard punchings<br />
(paper up to approx. 100/65 cm, 70 g/m≈)<br />
● Sheets that have been written on can be<br />
turned over (<strong>The</strong> distance to the wall is<br />
approx. 23 cm.)<br />
● <strong>The</strong> clamp rail is also a tear-off edge for<br />
clean cutting of sheets.<br />
● Includes adapter set and white tray<br />
(approx. 30 cm)<br />
H/W/D: approx. 116/74/33 cm<br />
Weight: approx. 9.9 kg<br />
Code No. 18706<br />
2<br />
1 2<br />
3<br />
Different elements can be positioned on top of each<br />
other.<br />
2) PartnerLine Pin Boards<br />
● Indispensable in the office<br />
● Notes and memos are easily attached and<br />
removed with MEDIUM pins<br />
● High quality fabric, leaving no holes<br />
● Adapter set included<br />
Available upon request<br />
● Max. size H/W: approx. 120/200 cm<br />
Cork surface<br />
PartnerLine Textile Pin Boards<br />
Fabric Cover blue grey<br />
eight/width approx. Code No. Code No.<br />
90/180 cm 18719 18717<br />
90/120 cm 18720 18716<br />
60/ 90 cm 18721 18718<br />
PartnerLine Cork Pin Boards<br />
Cork Cover Code No.<br />
Height/width approx.<br />
90/120 cm 18724<br />
60/ 90 cm 18725<br />
3<br />
3) PartnerLine Whiteboard<br />
● Practical and versatile functionality<br />
● Magnetic enamelled steel panel<br />
(dimensionally stable, durable)<br />
● Write-on and dry-wipe clean<br />
● Includes adapter set and tray<br />
Available upon request<br />
● Max. size H/W: approx. 120/200 cm<br />
Accessories<br />
4) MEDIUM Starter Set for whiteboards<br />
Code No. 1839-62<br />
5) MEDIUM Starter Set for flip charts<br />
Code No. 1839-51<br />
6) Set of pins<br />
20 Marker flags, 20 pin board needles,<br />
100 map pins<br />
Code No. 1862<br />
6<br />
PartnerLine Whiteboards<br />
Height/width approx. Code No.<br />
90/180 cm 18714<br />
90/120 cm 18713<br />
60/ 90 cm 18715
1<br />
Multifunctional Board –<br />
versatility on limited space<br />
1) Multifunctional Board<br />
● Space-saving lockable presentation unit<br />
● Panel whiteboard (enamelled steel):<br />
magnetic, to write on and dry wipe clean<br />
● Integrated wall screen (opened panel):<br />
approx. 145/145 cm, incl. keystone bracket<br />
● Flip chart: flip chart clamp on the left<br />
panel; with movable paper hangers for<br />
paper sizes approx. 100/65 cm (70 g/m 2)<br />
● When closed, 2 whiteboards are usable at<br />
the front<br />
● Incl. wall mounting<br />
● Standard version: white aluminium frame<br />
Wood decor available<br />
on request: pear, light<br />
beech, beech, cherry,<br />
nut and light oak<br />
(black aluminium<br />
frame, black floor<br />
stand)<br />
130<br />
122<br />
73<br />
195<br />
2<br />
82,5<br />
72<br />
330<br />
165 82,5<br />
145<br />
145<br />
Board size: H/W/D: approx. 120/330/10 cm<br />
Folded cabinet:<br />
H/W/D: approx. 120/165/10 cm<br />
Weight: approx. 82.3 kg<br />
Code No. 1850120150-M<br />
Accessories<br />
2) Mobile Floor Stand<br />
● For the Multifunctional Board,<br />
white profile<br />
H/W/D: approx. 195/130/68 cm<br />
Weight: approx. 26 kg<br />
Code No. 1839-U<br />
120<br />
3) MEDIUM Revolving Board<br />
● <strong>The</strong> double-sided board surface is<br />
revolvable through 360° and can be<br />
locked in any position thanks to a turning<br />
knob<br />
● White enamelled steel, to write on, dry<br />
wipe clean, magnetic surface<br />
● Includes mobile floor stand on 4 castors<br />
(2 lockable)<br />
● Tray for markers<br />
● Board frame: white aluminium<br />
3<br />
Optimal use of space<br />
thanks to mobility and a<br />
whiteboard on either side<br />
Board Size Weight<br />
H/W cm A B in kg Code No.<br />
100/200 210 194 50.2 185014142<br />
100/150 160 194 40.6 185014140<br />
3<br />
67<br />
149<br />
A<br />
91<br />
B<br />
Presentation Boards<br />
107
Whiteboards<br />
108<br />
1<br />
2<br />
Whiteboards<br />
● write on with<br />
whiteboard markers<br />
● dry-wipe clean<br />
● magnetic<br />
Whiteboards –<br />
writing classics in two versions<br />
1) MEDIUM Exclusive<br />
● <strong>The</strong> Exclusive series has a steel enamelled<br />
surface providing a long-life cycle; can be<br />
dry-wiped clean<br />
● Board frame: aluminium<br />
● Incl. mounting material and pen tray<br />
● Mounting in portrait or landscape format<br />
MEDIUM Whiteboard Exclusive<br />
Size H/W approx. Code No.<br />
45/ 60 cm 18504560<br />
60/ 90 cm 18506090<br />
90/120 cm 185090120<br />
90/180 cm 185090180<br />
100/150 cm 1850100150<br />
100/200 cm 1850100200<br />
120/180 cm 1850120180<br />
120/240 cm 1850120240<br />
120/300 cm 1850120300<br />
3) Design Flip Chart Quick Clamp<br />
● Turns a magnetic whiteboard into a flip<br />
chart<br />
● With movable paper hangers<br />
● Suited for standard paper sizes up to<br />
approx. 100/65 cm (70 g/m 2)<br />
H/W/D: approx. 6/70/3.5 cm<br />
Weight: approx. 0.57 kg<br />
Code No. 1833<br />
2) MEDIUM Standard<br />
● <strong>The</strong> Standard series with the varnished<br />
writing surface is a whiteboard for the<br />
smaller budget<br />
● Board frame: aluminium<br />
● Incl. mounting material and pen tray<br />
● Mounting in portrait or landscape format<br />
MEDIUM Whiteboard Standard<br />
Size H/W approx. Code No.<br />
45/ 60 cm 18524560<br />
60/ 90 cm 18526090<br />
90/120 cm 185290120<br />
90/180 cm 185290180<br />
100/150 cm 1852100150<br />
100/200 cm 1852100200<br />
120/180 cm 1852120180<br />
120/240 cm 1852120240<br />
120/300 cm 1852120300<br />
3<br />
8<br />
7<br />
Accessories<br />
4) MEDIUM Starter Set for Whiteboards<br />
Contents:<br />
● 4 Whiteboard markers (red, green, blue,<br />
black)<br />
● Magnetic marker holder for 4 markers<br />
● Magnetic board wiper with replaceable felt<br />
● 10 Felt strips for board wiper<br />
● 100 ml Cleaning spray<br />
● 10 Magnets in assorted colours<br />
Code No. 1839-62<br />
5) MEDIUM Whiteboard Marker<br />
Set of 10 whiteboard markers<br />
● To be dry-wiped<br />
● Red, green, blue, black<br />
Code No. 1838-11<br />
6) Magnetic Marker Holder<br />
● For 4 markers<br />
Code No. 1838-2<br />
7) Magnetic Board Wiper<br />
● With replaceable felt<br />
Code No. 1839-5<br />
8) Felt strips, 10 pcs.<br />
● For magnetic board wiper<br />
● Self-adhesive, non-permanent<br />
Code No. 1839-6<br />
9) Magnets, 20 pcs.<br />
● Ø 30 mm<br />
● Red, green, blue, black<br />
Code No. 1839-35<br />
5<br />
6<br />
10) Cleaning Spray, 100 ml<br />
● For periodical cleaning of whiteboards<br />
Code No. 1839-70<br />
9<br />
4<br />
10
1<br />
Five presentation surfaces<br />
on confined space<br />
● for workshops and<br />
meetings<br />
● to write on,<br />
dry-wipe clean<br />
● magnetic<br />
Whiteboard Systems –<br />
make the most out of confined space<br />
1) MEDIUM Side Panel Board, five surfaces<br />
● Whiteboard made of high quality<br />
enamelled steel<br />
● To write on, dry-wipe clean, magnetic<br />
● <strong>The</strong> side panels are equipped with hinges<br />
and can easily be closed to use the front<br />
board surface<br />
● Board frame: aluminium with plastic<br />
corners<br />
● Supplied with: wall mounting set and a<br />
tray for markers<br />
60<br />
75<br />
100<br />
240<br />
120 60<br />
300<br />
150 75<br />
400<br />
200 100<br />
90<br />
120<br />
100<br />
MEDIUM 5-Surface Whiteboard<br />
Main board size Side Panel Size Code No.<br />
H/W approx. H/W approx.<br />
90/120 cm 90/ 60 cm 185090120-C<br />
120/150 cm 120/ 75 cm 1850120150-C<br />
100/100 cm 100/100 cm 1850100200-C<br />
2<br />
2) MEDIUM Side Panel Board, three surfaces<br />
● <strong>The</strong> side panel is mounted for left-swivel<br />
You can close<br />
one side panel…<br />
60 120<br />
90<br />
90 180<br />
MEDIUM 3-Surface Whiteboard<br />
Side Panel Size Code No.<br />
H/W approx. H/W approx.<br />
90/60 cm 18509060<br />
120/90 cm 185012090<br />
… and be<br />
absolutely certain<br />
that confidential<br />
information is<br />
protected from<br />
prying eyes.<br />
120<br />
Whiteboards<br />
109
Planning Boards<br />
1<br />
110<br />
Optimal planning of projects and deadlines:<br />
● Always up-to-date thanks to magnetic date<br />
stripes for calendar adjustment<br />
● Magnetic whiteboards are made of<br />
enamelled steel, can be written on and<br />
dry-wiped clean<br />
● All boards (8 mm aluminium frame) are<br />
supplied with pen tray and mounting set<br />
3<br />
MEDIUM Planning Boards –<br />
keep track of all your appointments<br />
1) MEDIUM Two-Week Planner<br />
● Practical planning board with 2-week<br />
display<br />
● Horizontal magnetic stripes mark 14 days<br />
● In vertical direction there are 53 available<br />
fields<br />
MEDIUM Two-Week Planner<br />
Size H/W approx. Code No.<br />
60/ 90 cm 18536090-W-GB<br />
90/120 cm 185390120-W-GB<br />
2) MEDIUM Year Planner<br />
● <strong>The</strong> whole year at a glance on one board<br />
● Horizontal magnetic stripes mark each<br />
month<br />
● In the vertical direction magnetic stripes<br />
for each day and date<br />
● Weekends have a lightly shaded<br />
background for a better overview<br />
● 38 lines for entries<br />
3) MEDIUM Day Planner<br />
● Ideal for planning your day<br />
● Horizontal marking of working days<br />
(Mon - Sat) with magnetic stripes<br />
● <strong>The</strong> far left column leaves room for taking<br />
down 37 activities<br />
MEDIUM Year Planner<br />
Size H/W approx. Code No.<br />
60/ 90 cm 18536090-J-GB<br />
90/120 cm 185390120-J-GB<br />
2<br />
Accessories<br />
4) Starter Kit for Planning Boards<br />
1 Board wiper, 4 board markers (1 mm)<br />
(black, red, green, blue)<br />
5 Sets of magnetic symbols<br />
(triangles, squares, arrows …)<br />
Code No. 1853-2-GB<br />
MEDIUM Day Planner<br />
Size H/W approx. Code No.<br />
60/ 90 cm 18536090-T-GB<br />
90/120 cm 185390120-T-GB<br />
4
1<br />
MEDIUM Pin Boards –<br />
the greatest information exchange in the world<br />
1) MEDIUM Pin-Magnetic Board<br />
● Clarity and order are achieved easily<br />
● <strong>The</strong> fabric cover board has a powdercoated<br />
perforated cover which gives it its<br />
designer look<br />
Double Benefit:<br />
Notes can be fixed to this board using<br />
either<br />
● Pins:<br />
Prevents smaller notes from being<br />
covered by big magnets.<br />
● Magnets:<br />
Avoids holes in important documents.<br />
Can be hung up vertically or horizontally.<br />
Perforated metal plate RAL 9002 (grey white)<br />
Pin-Magnetic Board<br />
Light grey felt covering<br />
H/W approx. Code No.<br />
60/ 90 cm 18746090<br />
90/120 cm 187490120<br />
3<br />
2) MEDIUM Felt Boards<br />
● Quick and safe attachment of important<br />
information with MEDIUM pins<br />
● <strong>The</strong> textile surface self-seals even after<br />
frequent use<br />
● Board frame: aluminium<br />
● Can be hung up vertically or horizontally<br />
● Supplied in blue or grey<br />
3) MEDIUM Cork Boards<br />
● <strong>The</strong> alternative to coloured felt boards<br />
● <strong>The</strong> pierced cork surface self-seals<br />
instantly which means the cork keeps<br />
its attractive appearance<br />
● Board frame: aluminium<br />
● Can be hung up vertically or horizontally<br />
Felt Board, blue covering<br />
H/W approx. Code No.<br />
60/ 90 cm 18736090-BL<br />
90/120 cm 187390120-BL<br />
Felt Board, grey covering<br />
H/W approx. Code No.<br />
60/ 90 cm 18736090-GR<br />
90/120 cm 187390120-GR<br />
2<br />
Accessories<br />
4) Set of Pins<br />
● 20 Marker flags, 20 pin board needles,<br />
100 country map pins<br />
Code No. 1862<br />
5) Magnets, 20 pcs.<br />
● Ø 30 mm black, red, green, blue<br />
Code No. 1839-35<br />
5<br />
Cork Board<br />
H/W approx. Code No.<br />
60/ 90 cm 1870-K4-A<br />
90/120 cm 1870-K5-A<br />
90/180 cm 1870-K7-A<br />
4<br />
Pin Boards<br />
111
Brochure Stand<br />
112<br />
MEDIUM Brochure Stand Caddy –<br />
display your literature effectively<br />
1) MEDIUM Brochure Stand Caddy<br />
● Chrome-plated appearance<br />
● Great stability and functionality<br />
● Can easily and quickly be mounted to the<br />
wall without base and sustainers<br />
● Functional design:<br />
10 compartments A4 size for up to<br />
40 single leaflets (depending on the<br />
paper thickness)<br />
Dimensions of the compartments:<br />
W/H/D: approx. 23.5/19.0/1.5 cm<br />
Stand: shiny black<br />
Compartments: chrome-plated<br />
● Space-saving<br />
Height: approx. 136.9 cm<br />
Base: approx. 30/24 cm<br />
Weight: approx. 6.5 kg<br />
Code No. 0953<br />
24<br />
30<br />
136,9<br />
2) Carrying Bag for Caddy<br />
● Indispensable for mobile usage<br />
of the brochure stand on fairs<br />
and exhibitions etc.<br />
● Protects the Caddy against dirt<br />
and scratches<br />
● Sturdy, black nylon fabric<br />
● Convenient packing and unpacking of the<br />
folded brochure stand thanks to an<br />
end-to-end zipper<br />
● Adjustable carrying strap and handles are<br />
in red for greater attention thus avoiding<br />
tripping over them<br />
Code No. 0953-T<br />
2<br />
1<br />
Your company logo<br />
can be attached<br />
here<br />
Wall mounting<br />
possible<br />
Ideal for showrooms, trade fairs,<br />
lobbies, conference rooms
<strong>The</strong> Ultimate Presentation Catalogue 2006/07<br />
<strong>The</strong> <strong>Conference</strong> <strong>Company</strong><br />
Düsseldorf • London • Mailand<br />
Willstätterstr. 7 · D-40549 Düsseldorf · Germany · Tel. ++49-211-52 76-0 · Fax ++49-211-52 76-100<br />
Internet: www.medium.de · E-Mail: info@medium.de
