<strong>Adaptivity</strong> <strong>with</strong> <strong>moving</strong> <strong>grids</strong> 55<br />
smooth to avoid possible deterioration of accuracy: see, e.g., Mulholland,<br />
Huang and Sloan (1998), Wang and Shen (2005), Feng, Yu, Hu, Liu, Du<br />
and Chen (2006) and Tee and Trefethen (2006). While preliminary results<br />
are promising, much further investigation is needed to determine the full<br />
potential of these adaptive spectral methods.<br />
3.2. MMPDEs and variational methods in n dimensions<br />
3.2.1. Description of some variational-based methods<br />
In the variational and MMPDE approaches of mesh adaptation in n dimensions,<br />
briefly described in Section 2, adaptive meshes are also generated<br />
as images of a computational mesh under a coordinate transformation from<br />
the computational domain to the physical domain. Such a coordinate transformation<br />
is determined by an adaptation functional, which is commonly<br />
designed to measure the difficulty in the numerical approximation of the<br />
physical solution. The functional often involves mesh properties and employs<br />
a monitor function to control mesh quality and mesh concentration.<br />
The key to the development of variational and MMPDE methods is the formulation<br />
of the adaptation functional. Direct-use standard-error estimates<br />
are often not appropriate since they often lead to non-convex functionals<br />
in two and higher dimensions. Instead, most of the existing methods have<br />
been developed based on physical, geometric, mesh quality control, and/or<br />
other considerations.<br />
The functional can be formulated in terms of either the coordinate transformation<br />
x = F(ξ,t) or its inverse transformation ξ = F −1 (x,t). The latter<br />
has been used more commonly than the former because it is less likely to<br />
produce mesh tangling for non-convex domains (e.g., see Dvinsky (1991)).<br />
In the latter case, the adaptation functional takes the general form<br />
∫<br />
I(ξ) = G(M, ξ, ∇ξ i )dx, i =1,...,n, (3.26)<br />
Ω P<br />
where G is a continuous function of its arguments, M is the (scalar or<br />
matrix-valued) monitor function, and ∇ is the gradient operator <strong>with</strong> respect<br />
to the physical coordinate x. Once a functional has been defined,<br />
an MMPDE can be obtained as described in (2.26) as the gradient flow<br />
equation of the functional (Huang and Russell 1997b, 1999), i.e.,<br />
∂ξ i<br />
∂t = −P ∂I<br />
, i =1,...,n, (3.27)<br />
ɛ ∂ξ i<br />
where P is a positive differential operator and ɛ>0 is a parameter for<br />
adjusting the time scale of mesh movement. For the general form (3.26),<br />
this becomes<br />
∂ξ i<br />
∂t = P (<br />
∇ ·<br />
ɛ<br />
∂G<br />
∂(∇ξ i ) − ∂G<br />
∂ξ i<br />
)<br />
, i =1,...,n. (3.28)
