<strong>PUSHING</strong> <strong>THE</strong> <strong>ENVELOPE</strong><br />
TWO-DAY MASTERCLASS ON <strong>THE</strong> FUTURE OF<br />
FACADES<br />
TO DAGES MASTERCLASS OM FREMTIDENS<br />
FACADE
© 2010 <strong>Dansk</strong> <strong>Arkitektur</strong> <strong>Center</strong><br />
Udgivet med støtte fra Realdania<br />
Tekst: Christian Bundegaard<br />
Layout: Heidi Pedersen, Christensen & CO arkitekter<br />
Designkoncept: Lene Sørensen Rose<br />
Master class foto’s: Nanna Gyrithe Jardorf, Heidi Pedersen<br />
Cover photo: © James Ward & Arup Associates<br />
Tryk: Grefta Tryk<br />
© 2010 Danish Architecture Centre<br />
Published with support from by Realdania<br />
Text: Christian Bundegaard<br />
Layout: Heidi Pedersen, Christensen & CO architects<br />
Designkoncept: Lene Sørensen Rose<br />
Master class photographs: Nanna Gyrithe Jardorf, Heidi Pedersen<br />
Cover foto: © James Ward & Arup Associates<br />
Print: Grefta Tryk<br />
www.dac.dk
CONTENTS<br />
04 INTRODUCTION<br />
NATALIE MOSSIN<br />
07 MASTERCLASS REPORT<br />
CHRISTIAN BUNDEGAARD<br />
26 FAÇADE REFURBISHMENT<br />
– WHAT IS <strong>THE</strong> POTENTIAL ?<br />
ANNE BAGGER<br />
28 <strong>THE</strong> SOLIDS<br />
JESPER NIELSEN<br />
30 NEW PERSPECTIVES ON FAÇADE REFURBISHMENT<br />
ULRICH KNACK<br />
32 <strong>THE</strong> DECADE OF <strong>THE</strong> FAÇADE ENGINEER<br />
MIKKEL KRAGH<br />
34 NEW MATERIALS<br />
MARCEL BILOW<br />
36 NEXT ACTIVE FAÇADES<br />
TILLMANN KLEIN<br />
38 PREFABRICATION AND <strong>THE</strong> CARE FOR DETAIL IN<br />
REFURBISHING EXISTING FAÇADES<br />
STIG MIKKELSEN<br />
40 INTELLIGENT BEHAVIOUR<br />
ALEXANDRA THYGESEN<br />
42 DANISH SUMMARY<br />
CHRISTIAN BUNDEGAARD<br />
44 PARTICIPANTS<br />
47 ACKNOWLEDGEMENT
INTRODUCTION<br />
Natalie Mossin<br />
Specialist, Innovation in Construction<br />
Danish Architecture Centre<br />
From 2005 through 2008 Realdania<br />
supported the implementation of<br />
a range of development projects<br />
aimed at strengthening innovation<br />
in construction through the initiative<br />
Building Lab DK, a division of the<br />
Danish Architecture Centre. But<br />
while the initiative is completed – the<br />
development projects live on - and the<br />
interest in innovation and the passion<br />
to translate this into practice is<br />
undiminished among the researchers<br />
and practitioners who worked on<br />
Building Lab DK supported projects.<br />
The vibrancy of this informal network<br />
of professionals committed to<br />
innovation is what has lead to the<br />
masterclass “Pushing the Envelope”<br />
and to this publication. The master<br />
class was arranged by DAC in<br />
collaboration with CINARK, DTU Byg<br />
and CCO and its purpose has been<br />
to provide a platform for agents of<br />
change to meet and exchange ideas.<br />
The master class brought together<br />
specialists and professionals with a<br />
specific interest in façade-engineering<br />
from across business and research<br />
institutions..<br />
The purpose was to facilitate a debate<br />
on the future of existing facades and<br />
to develop innovate ideas to the<br />
renewal of underperforming facades.<br />
The debate examined the most<br />
important problems, ideas and<br />
drivers in the development of<br />
sustainable façade systems for<br />
existing buildings, and identified key<br />
components in how we might reap<br />
the potential inherent in renovation<br />
- technically as well as architecturally.<br />
This publication presents the debate<br />
as it took place as well as a range<br />
of specialist viewpoints on the<br />
development of façade solutions<br />
for existing buildings. It is our<br />
hope that it will be of inspiration<br />
to others, who has a stake in, and<br />
the courage to take ownership<br />
of, the future of existing facades.<br />
The Danish Architecture Centre<br />
continues to focus on new<br />
understandings of construction and<br />
the dissemination of experience,<br />
methods and prospects for<br />
construction operators.<br />
5
The master class took place over two days in September, 2010 at the Royal Danish Academy, School<br />
of Architecture in Copenhagen, Denmark.
MASTER CLASS REPORT<br />
CHRISTIAN BUNDEGAARD<br />
"Masterclass" the organizers called<br />
the seminar. "Because all those<br />
participating are the masters in this<br />
field," said Natalie Mossin from the<br />
Danish Architecture <strong>Center</strong> in her<br />
welcome speech. And there were<br />
good reasons behind gathering this<br />
brain trust a few sunny, late summer<br />
days at the School of Architecture in<br />
Copenhagen. The topic was a truly<br />
important one for the future of the<br />
building industry in its global context<br />
of climate change and the need for<br />
energy saving solutions: the façade,<br />
- with a special focus on existing<br />
buildings and refurbishment.<br />
Envelope Innovation Needed.<br />
Façades are much more than just<br />
the faces of buildings. The façade<br />
is the membrane between the living<br />
or working space of the interior and<br />
the forces of nature itself. But with<br />
the looming threat of disruptive<br />
climate changes it is essential that<br />
buildings, as one of the major<br />
energy consumers, are developed<br />
and transformed in a sustainable<br />
direction.<br />
Therefore it is imperative that façade<br />
specialists exchange views on how<br />
to be innovative in developing<br />
tomorrow's façades. The building's<br />
skin contains a high potential for<br />
sustainable solutions. These are<br />
complex matters, however, which<br />
include a diverse range of aspects<br />
such as future technologies, new<br />
materials, indoor climate, human<br />
behavior, architecture and economics.<br />
Further, the solutions that are to be<br />
found must be simple enough to allow<br />
profitably production, and persuasive<br />
enough to convince a conservative<br />
building industry and their final users,<br />
who might rather spend their money<br />
on a new kitchen. Hence, the need<br />
for research, thinking out of the box<br />
and the free exchange of ideas.<br />
Therefore, a master class, trying to<br />
“push” the building envelope.<br />
The development of innovative<br />
solutions might be a challenge<br />
in new constructions, but at least<br />
that situation offers a clean slate.<br />
When dealing with existing buildings<br />
several aspects have to be taken<br />
into account. On one the hand,<br />
there is a substantial need for<br />
renovation and updating of millions<br />
of homes and office buildings with<br />
inadequate insulation and outdated<br />
functionalities, in a sometimes quite<br />
poor design. On the other, however,<br />
many buildings of a poor insulation<br />
standard represent interesting and<br />
robust architectural value. Here, there<br />
is a need for renewing and preserving<br />
at the same time.<br />
My favorite façade.<br />
For a start, all participants were<br />
asked to name af façade they had<br />
worked on or one they simply liked.<br />
Mikkel Kragh from Arup had helped<br />
to create the Danish Pavilion for Expo<br />
in Shanghai and was quite proud of a<br />
façade with no mechanical parts. Stig<br />
Mikkelsen from Dissing + Weitling<br />
recalled his practice’s heritage from<br />
Arne Jacobsen’s studio and what was<br />
possibly the first double-skin façade<br />
on Danish soil, Jacobsen’s building<br />
for Denmark’s National Bank.<br />
Thomas Bo Jensen could not help but<br />
point to another Danish classic, the<br />
building he himself had written his<br />
thesis on, a house made of five million<br />
parts, namely PV Jensen Klint´s brick<br />
cathedral, Grundtvigskirken. Also,<br />
Jean Nouvel’s Arab Institute in Paris<br />
was mentioned, and the Danish neo-<br />
modern icon power-station opposite<br />
of Magasin du Nord in Copenhagen.<br />
Another participant would, rather<br />
than to name a single façade,<br />
choose the optional principle: User<br />
configurated solutions like<br />
in the case of balconies from altan.dk.<br />
And finally, one participant pointed to<br />
his windbreaker made of Goretex as<br />
the perfect envelope - weatherproof,<br />
flexible and attractive to look at.<br />
The two day seminar was structured<br />
around short presentations with<br />
opportunity for discussion, giving way<br />
to group sessions around a series of<br />
specific tasks. The six presentations<br />
are reprinted in this publication, so<br />
below is the primary fracture surfaces<br />
7
8<br />
in the discussions and the recurring<br />
themes and (preliminary) conclusions<br />
that will be discovered.<br />
Potentials in refurbishment.<br />
Postdoctoral Fellow Anne Bagger’s<br />
Introduction to the potentials<br />
for saving energy by renovating<br />
old buildings prompted a lively<br />
discussion. These potentials are<br />
not to be underestimated. Even in<br />
Denmark, which is one of the places<br />
where energy saving in buildings has<br />
been an issue for decades, windows<br />
with high u-value and walls without<br />
insulation abound. As Anne Bagger<br />
herself asked, if at the same time<br />
the indoor climate can be bettered<br />
and energy can be saved, why is not<br />
sustainable refurbishment flowering?<br />
Well, for one thing, private homes<br />
tend to be owned by people! People,<br />
who prioritize differently from the<br />
professionals. Most people find a<br />
new kitchen both more necessary<br />
and more sexy than 300 mm of<br />
insulation. Another challenge is the<br />
“invisibility” energy issues. Many have<br />
their heating bill payed automatically<br />
via internet banking. Finally, there<br />
is the comprehensive question of<br />
everyday habits and behaviour. First<br />
and foremost we live in our houses.<br />
Some people simply might want to<br />
keep their windows open in order to<br />
hear the birds sing. Is this really a<br />
problem? asked Anne Bagger.<br />
In the discussion that followed,<br />
several issues, that should be<br />
recurring during the rest of the<br />
seminar came up. One was the<br />
conservatism of the building industry.<br />
New products like façade elements<br />
with better performance would have<br />
to be produced by manufacturers<br />
that still have to make a profit, and<br />
therefore have to regard what the<br />
craftsmen are used to handle and feel<br />
confident about. Work is carried out<br />
by craftsmen, who are not salesmen,<br />
and have a hard time bringing in new<br />
products. In this way no one, and last<br />
of all the customers, are encouraged<br />
to act differently.<br />
One way out of this vicious circle could<br />
be state support of demonstration<br />
products and projects. This may break<br />
the ice and make new solutions less<br />
adventurous. Often new inventions<br />
are not put into smaller products<br />
but in systems that demand a lot<br />
of resources. Further it is vital to<br />
consider not just the product itself,<br />
but the whole process including<br />
transport issues and maintenance<br />
later on.<br />
Maybe, as Professor Ulrich Knaack<br />
from the Delft University of Technology<br />
(TU Delft) suggested, proponents of<br />
sustainable refurbishment will have<br />
to trigger people to take interest in<br />
solutions put together from kits, or bits<br />
and pieces bought at the bricolage.
Engaging people might be a core<br />
issue, and the dicussion immediately<br />
showed the different stands and<br />
attitudes. Bagger complained that<br />
no consultant normally is around to<br />
tell you how to operate a window,<br />
for example. But does it make any<br />
sense to say that people are not using<br />
buildings the right way, when after all<br />
they are the ones living there, making<br />
themselves feel at home with all their<br />
habits and ways, it was argued.<br />
Stig Mikkelsen reminded everybody<br />
of the challenge of making new<br />
solutions acceptable to the residents,<br />
as it was the common notion that<br />
refurbishments deterioated indoor<br />
climate; and indeed earlier it had<br />
been the case, as people were not<br />
aware how important it was to<br />
operate windows and systems the<br />
right way.<br />
It was quite amazing, Tom Hay<br />
added, that to his experience even<br />
corporate clients did not understand<br />
how buildings work, and secondly,<br />
to the question of aesthetics,<br />
unfortunately great buildings were<br />
very often energy busters. In both<br />
cases it was down to simple things;<br />
people’s behaviour and preferences.<br />
Perhaps the way to “beat the kitchen,”<br />
as it was put, was to make the<br />
envelope more active, more refined<br />
and attractive. Energy features<br />
should be better integrated in the<br />
overall aesthetic approach, and non-<br />
energy features should be made more<br />
outstanding in the product design.<br />
Another route of attaining stronger<br />
engagement could include, as<br />
Emanuele Naboni suggested,<br />
experiments like the ones where<br />
final users in residential community<br />
housing participated in competitions<br />
to save energy and were monitored<br />
in the everyday routines. In this way,<br />
valuable knowledge of behaviour<br />
could be distilled.<br />
Postdoctoral Fellow Anne Bagger, highlighted the need to<br />
acknowledge the habits of the people expected to invest<br />
private funds in the renovation of their homes.<br />
9
Jesper Nielsen, Head of Centre,<br />
CINEARK, outlined the history of<br />
the curtain wall.<br />
10<br />
Refurbishment of the<br />
preservable.<br />
Head of Centre at CINARK, Jesper<br />
Nielsen, outlined the history of the<br />
curtain wall, going back to the first<br />
curtain wall façades of the 19th<br />
Century through the first industrial<br />
façade with the use of aluminium<br />
in 1954. Since then, most of the<br />
development has taken place around<br />
curatain walling. Renovation is easy<br />
and can be done just by changing<br />
the “curtain”.<br />
But then, what about great<br />
architecture like Danish architect Kay<br />
Fisker’s building for Mødrehjælpen<br />
also from the mid-fifties, Nielsen<br />
asked. A beautiful and austere piece<br />
of brickwork architecture with a lot of<br />
meticulously done detailing. Just to<br />
change the balconies, for example,<br />
would completely alter the balance<br />
of the whole.<br />
Almost anything one does will be<br />
wrong; and the radical solution,<br />
where historic buildings are torn<br />
down only to be completely rebuilt<br />
within todays standards, might not<br />
be what you want either. Buildings<br />
that are not listed, but still highly<br />
preservable are a real challenge to<br />
sustainable refurbishment.<br />
During discussion the participants<br />
in the seminar came to several<br />
interesting conclusions. For one<br />
thing, the industry has to expand<br />
its thinking to include other Façades<br />
than the curtain wall. Alternatives<br />
to highly layered membranes would<br />
have to be found.<br />
Marcel Bilow from Imagine Envelope<br />
at TU Delft made the point that the<br />
curtain wall was about to change<br />
radically. In future, less glass would<br />
be needed to achieve the goals of<br />
most concepts; and Mikkel Kragh<br />
added that first and foremost, he was
in fact “obsessed with windows”, but<br />
second, he was convinced that the<br />
question of transparency of façades<br />
was now solved and that it was time<br />
to move on. Some suggested that<br />
a catalogue of technologies fit for<br />
renovation processes should be made<br />
in order to facilitate the refurbishment<br />
of many types of façades. Again, it<br />
was emphasized by several that<br />
refurbishment starts with the people<br />
living in the buildings, and that is<br />
was paramount to include them in<br />
the process. Anja Bache from the<br />
Technical University of Denmark<br />
finally asked for ways to connect the<br />
proof of concept in development of<br />
new materials and solutions with the<br />
refurbishment process.<br />
After lunch Ulrich Knaack took the<br />
floor to draw a rapid roadmap of<br />
the first 12,000 years of building<br />
development, although with a<br />
focus on the last 15 years of<br />
façade development. At the Delft<br />
University of Technology, Knaack<br />
and his team worked on providing<br />
an “international façades toolbox”<br />
instead of the traditional international<br />
style curtain wall solutions. One of the<br />
key features is the ability to adapt<br />
solutions to different climates, and<br />
thus the toolbox as presented in a<br />
book series published by Knaack’s<br />
Façade Research Group shows a<br />
palette of possibilities of future façade<br />
principles.<br />
The work of the research group is<br />
very much about combining different<br />
disciplines and technologies, in search<br />
of new building “skins”. Some of the<br />
work deliberately try to push the<br />
limits of traditional façade thinking<br />
by using new alternative and even<br />
embryonic technologies. The overall<br />
attitude is that an open mind is<br />
needed to advance the design-related<br />
knowledge and engineering of well-<br />
established researh within this field.<br />
In the discussion the question of<br />
sustainable façade, materials and<br />
recycling came up. As many of the<br />
most promising ideas entails the use<br />
of aluminium, that material was a<br />
natural focal point. Aluminium has got<br />
a bad name due to the current ways<br />
of handling it in terms of recycling,<br />
but according to Ulrich Knaack it still<br />
has the greatest potential.<br />
Finally, some said, all these<br />
discussions about how to develope<br />
sufficient energy saving designs for<br />
old buildings might simply evolve<br />
from the wrong question, even if<br />
the answer did turned out all right.<br />
Sometimes the radical solution in<br />
terms of resources and economics<br />
on the societal level, may be to leave<br />
these preservable brick buildings as<br />
they are, and change the whole<br />
energy production instead.<br />
11
12<br />
The master class participants were divided into three groups, each choosing a focal point<br />
to deal with.
Three Parameters.<br />
In the afternoon session the seminar<br />
divided into three groups. All three<br />
groups were assigned to choose<br />
one key issue, through which they<br />
would approach the challenge of<br />
existing façades. For example the<br />
energy issue, special materials, or<br />
preservation. Would it for example<br />
be possible to keep listed buildings by<br />
wrapping them in some way?<br />
One group dived the question into<br />
an issue of massivity vs. flexibility<br />
in façades. Massive is good,<br />
aesthetically satisfying in for example<br />
brick buildings, robust and easy to<br />
maintain. Flexible is also good, even<br />
necessary, when it comes to energy<br />
saving. But massive and flexible<br />
solutions are hard to come up with.<br />
In developing building materials, it<br />
was argued, there is a tendency to<br />
add an increasing number of different<br />
materials to the structure. As one<br />
participant said, “everytime there is<br />
a new need, we put an extra layer<br />
on, and that is a very old-fashioned<br />
approach, to my mind.” Instead, it<br />
might be worthwhile to consider how<br />
innovation is done within product<br />
design, where they try to use as few<br />
materials as possible, thus developing<br />
in a much more integrated way.<br />
Another participant added that in<br />
the traditional curtain wall façade of<br />
commercial buildings, we would put<br />
tinted glass regardless of which corner<br />
of the earth the façade is facing. In<br />
recent years we have tried to optimize<br />
the building, in terms of orientating<br />
it, twisting it so it is self-shading, and<br />
so on. Thus, although we like the<br />
oldfashioned brickbuildings, they are<br />
perhaps not the most flexible design,<br />
when we think flexibility over the year<br />
or over the day?<br />
In fact, introducing façades with the<br />
same face mask all the way around<br />
is a step back, energy saving-wise.<br />
However, massive walls in composite<br />
materials may have a lot of the<br />
flexible qualities wanted. Hence,<br />
what we might be looking for, was a<br />
another kind of massiveness.<br />
It was suggested to turn the<br />
question around and try and make<br />
massive materials like glass or brick<br />
more open. Walls of foam glass,<br />
for example, could deliver all the<br />
insulation needed and still provide<br />
transparancy. Nowadays it is possible<br />
to produce glass with many different<br />
qualities by adding air or adding<br />
thickness. Thinking in this way, the<br />
window, the insulation area and the<br />
load bearing structure could be found<br />
in the same material or component.<br />
Right now, no big glass block is<br />
available, simply because there is<br />
no market for it.<br />
Other options are gradiant materials<br />
that like a toothbrush shaft goes<br />
from soft to hard, or from porous<br />
to solid in order to support different<br />
functionalities. This was an example<br />
of true flexibility.<br />
It was decided to try and move<br />
forward by bringing down the number<br />
of materials in the façade. To think<br />
in homogenous solutions, why not<br />
use the same material on both the<br />
inside and the outside of the building?<br />
With more and more sophisticated<br />
solutions and more and more layers,<br />
the façade would end up entirely<br />
different from the inner structure.<br />
“Different stages of the same material,<br />
providing different funktionalities<br />
that is what triggers me,” as one<br />
remarked.<br />
In another group they took a<br />
completely different approach. “You<br />
know,” one in the group said, “we are<br />
supposed to come up with more or<br />
less technical solutions. What if we<br />
tried to find out how to move people,<br />
instead of moving technology?” The<br />
metaphor of the challenge was<br />
that of “the new kitchen” as the<br />
focal point for investment in many<br />
private homes, thus overshadowing<br />
any interest in energy saving as part<br />
of refurbishment. But what is it with<br />
that kitchen? It was asked. “Well,”<br />
the answer was, “it gives people this<br />
13
dream of the perfect life; and the new<br />
exterieur wall does not.”<br />
Learning from that, participants<br />
wondered how to change the<br />
behaviour of people in line with the<br />
change the new kitchen prompts.<br />
Thus, how can the envelope frame<br />
the activities of the people and people<br />
frame the envelope? Is it for example,<br />
possible to create a “dialouge<br />
envelope” engaging home owners<br />
like the, partly, aesthetic experience<br />
of the kitchen does? How to expand<br />
the feeling from the kitchen to the<br />
entire building, as it was put.<br />
One main obstacle, it was suggested,<br />
was simply a lack of knowledge.<br />
There is a lot of confusion about<br />
what is to be done even with single<br />
family houses. Among professionals<br />
there might, for example, be a<br />
lot of discussion of passive house<br />
standards. But if one asks people in<br />
the street what that means very few<br />
will know. The average home owner<br />
has very little knowledge of what<br />
kind of effect different measures can<br />
have. What is the impact, how big<br />
is the investment, what is the time<br />
frame on turn of investment? Or was<br />
the knowledge at hand, as another<br />
group member suggested; but the<br />
interest lacking?<br />
The third group brainstormed on the<br />
different drivers in the refurbishment<br />
process, trying to make a matrix of<br />
understanding. As the overriding<br />
theme is energy consumption, it<br />
was for example puzzling that we<br />
keep changing the windows and<br />
then the tenants plug in more and<br />
more energy consuming electrical<br />
gear. How to integrate views and<br />
approaches and make them truly<br />
societal and behavioural?<br />
One of the key points identified to go<br />
into the matrix was that of lifefstyle.<br />
“Why do people want balconies?” it<br />
was asked. “because even if they<br />
live in the city, they want to be in<br />
nature.” All these aspirations have<br />
to be taken into account when we<br />
are trying to understand the drivers<br />
of sustainable refurbishment.<br />
Technical solutions sometimes turn<br />
things around and make us think it<br />
is all about technology, when often<br />
cultural aspects play in. Instead,<br />
the way forward should start out on<br />
the realization that there is no one<br />
solution to the façade question, but<br />
a multitude of approaches. Whatever<br />
the solution, “keep it simple” was<br />
a recurring key phrase of this<br />
discussion.<br />
15
The practitioner’s view.<br />
In the late afternoon talks, entailing<br />
four short “Views on façades,” Simon<br />
Smidt Kristensen from HS Hansen<br />
presented the twigs of frames and<br />
their installation on the façade/roof<br />
on Middelfart Sparekasse, a recently<br />
finalized project. An example of the<br />
on-going increase of industrialization<br />
in building, optimizing the building<br />
process, a key ambition of Hansen<br />
and others is the moving of manpower<br />
and materials from site to production<br />
line. The twigs were installed in just<br />
four days.<br />
Currently, transportation is a<br />
challenge, as the profitability of<br />
many prefab element productions<br />
are ruined by high transport costs. In<br />
the future, however, Smidt Kristensen<br />
envisions elements to be folded and<br />
packed in smart ways, much like<br />
folded satellite disks that are easy<br />
to transport and easy to unfold when<br />
mounted.<br />
Would indeed in the future, non-<br />
professional clients themselves be<br />
able to erect façades like this, it was<br />
asked. The answer is yes, perhaps<br />
a substantial business opportunity<br />
within the do-it-your-self range.<br />
Then, this is an example of embedded<br />
knowledge and skills in new<br />
components and products, which is<br />
essential for the development of user<br />
configurated sustainable solutions.<br />
As especially many privately owned<br />
single family houses are in need of<br />
sustainable renovation, the option<br />
of leaving it to private home-owners<br />
could be an important prospect for<br />
the future.<br />
Marcel Bilow from TU Delft<br />
sketched how the many new<br />
materials in different fields open<br />
up new possibilities for alternative<br />
enveloping. Working with students<br />
at the university they have in Delft<br />
a safer and less expensive testing<br />
ground than on the building site.<br />
Lightweight structures used the<br />
right way enhance functionalities.<br />
Concrete, for instance is already<br />
wellknown, and easy to change by<br />
simple means. Using the principle<br />
of biomimicry, learning from the way<br />
plants are “breathing”, a façade panel<br />
can be constructed of fibre reinforced<br />
concrete with built-in thin, capilary<br />
heating/cooling tubes. Or what<br />
about a wall made up of adjustible<br />
air baloons?<br />
Obstacles to this kind of thinking out<br />
of the box lie primarily within the<br />
conservative construction industry.<br />
Therefore, it is paramount for product<br />
development of ideas like these to<br />
have the industry on board from the<br />
start.<br />
17
Mikkel Kragh from Arup showed<br />
examples of a big market for the<br />
company, namely the tired looking<br />
commercial property that needs a<br />
make-over. This may not be driven<br />
by energy efficiency, and owners<br />
may be more interested in making<br />
it look attractive on the real estate<br />
market. He wanted to emphasize<br />
that envelope design is also about<br />
designing space. And that his<br />
personal view was that flexibility<br />
might not be the most important<br />
goal, and that instead one should<br />
design the perfect and most beautiful<br />
building for a specific purpose, and<br />
then that building would be used and<br />
loved as exactly that.<br />
The groups had two sessions to work on their concepts for the façade of the future.<br />
18<br />
Going through the last decades of<br />
development moving towards a more<br />
advanced façade approach, Mikkel<br />
Kragh stated that architecture is<br />
servicing the structure, and that this<br />
also is implied in the value chain, as<br />
the façade represent a substantial<br />
part of the construction costs. This<br />
is a complex issue and there is no<br />
structured approach to it. It is a grey<br />
zone and very few is taking care of<br />
the building envelope and integrating<br />
the different aspects. All of a sudden<br />
you need to know about industry,<br />
about materials, and all sort of things<br />
in order to be able to design the<br />
building, and not many architectural<br />
practices can afford to have that<br />
knowledge in-house. That is where<br />
the specialists came in 25 yars ago.<br />
Inviting everybody to join the Façade<br />
Engineering Society which he chairs,<br />
Mikkel Kragh showed a building in<br />
London, Ropemakers Place, designed<br />
by Arup, featuring angled windows,<br />
leaning and rotating away from<br />
the sun. Arup was able to predict<br />
the energy saving of their façade<br />
design and that convinced the very<br />
traditionally minded developer to go<br />
with the scheme.<br />
Finally, Tillman Klein from TU Delft<br />
went into the issue of active façades,<br />
and the research into the possibility<br />
of developing concepts for the<br />
combination of façade and building<br />
services.
The second day of the seminar<br />
started with a reminder of the many<br />
barriers the discussion of the previous<br />
day had laid bare, and thus the need<br />
for proceeding in steps to reach the<br />
goals. Tom Hay from Buro Happold<br />
talked about the refurbishment of<br />
social housing using nanogel. Many of<br />
the challenges in such a process turn<br />
out to be different from what might<br />
be expected. Thus Hay reminded the<br />
seminar, how we as professionals<br />
continue to underestimate people’s<br />
concern for things like how many<br />
weeks do they have to move out<br />
during the renovation and so on.<br />
Karsten Bro from Arkitema talked<br />
about his experience of developing<br />
a window panel made of a composite<br />
material with 70 % glassfiber. A<br />
simple and highly efficient system<br />
compared to many products on the<br />
market.<br />
Stig Mikkelsen from Dissing+Weitling<br />
showed examples of how the<br />
architectural language of the<br />
conventional double skin façade can<br />
be transferred to layered façades.<br />
The building for the National Danish<br />
Broadcast, DR-byen, and the new<br />
National Archives, Rigsarkivet, were<br />
cases in point. Emphasizing that a<br />
lot of testing, and the use of a lot<br />
of mock-ups, is essential Mikkelsen<br />
called for a more unitized thinking<br />
both in constructing anew and in<br />
renovation. Finally in that round of<br />
presentations, architect Alexandra<br />
Thygesen talked about “intelligent<br />
façades and intelligent behaviour as<br />
a disregarded ressource”, and the<br />
need for trusting the intelligence of<br />
daily users. The bottom line is thus<br />
that it is better to make the daily<br />
users open the windows, instead of<br />
applying smart mechanisms that use<br />
electricity.<br />
19
The master class participants contributed with animated<br />
discussions and sketches to emphasize their ideas.<br />
20<br />
Conclusion: Comfort, the human<br />
factor, and the simple but clever<br />
brick.<br />
Presenting the findings of the group<br />
session, the group focusing on user<br />
behaviour told the seminar that the<br />
human factor was important for many<br />
reasons. In single family homes,<br />
owners and users are the sole decision<br />
makers and therefore the ones to<br />
initiate change, and single family<br />
homes with a need for sustainable<br />
refurbishment abounds, especially<br />
in Denmark. Secondly, technical<br />
solutions should be developed in<br />
accordance with trends and needs<br />
in a timely fashion. Trying to make<br />
the envelope a tool for change of<br />
behavior, it could in fact be seen as<br />
an educational component of the<br />
building in terms of making people<br />
aware of the need for measures to<br />
be taken.<br />
Thus, it was suggested to publish<br />
a magazine on sustainable<br />
refurbishment with the same<br />
appeal as the popular and attractive<br />
magazines about interior decoration<br />
and design furniture, the “Refurbo<br />
Magazine. This should stimulate<br />
people to use their brains instead of<br />
being passive comsumers, making<br />
it fashionable to do sustainable<br />
refurbishment.<br />
Rather than dealing with these issues<br />
as challenges to the house, the group
suggested to deal with them on a<br />
room level. Or as they put it: “If<br />
you can’t beat the kitchen, join it!”<br />
Thus an idea could be to initiate a<br />
relation between the kitchen and the<br />
façade, bringing the function of the<br />
kitchen to the envelope. Thinking in<br />
interaction between the temperatures<br />
of inside and outside, using rainwater<br />
for the toilet, using the outside as a<br />
refridgerator in winter etc. In this<br />
proposal the envelope acts as the<br />
interface between interior functions<br />
and outside conditions – instead<br />
of protecting ouselves against the<br />
outside.<br />
Group number two had interpreted<br />
the challenge of pushing the envelope<br />
onto refurbishment as “pushing<br />
materials” – rethinking comfort and<br />
increasing the performance of what<br />
is already there, like bricks, instead of<br />
keep adding something. Thinking in<br />
terms of change a few elements over<br />
time and thus increasing the overall<br />
performance retaining the original<br />
design, this group had come up with<br />
what they called the “Refurbrick”. The<br />
idea is to sell a window with extra<br />
benefits. Using the brick would be<br />
ideal for the Danish market, where a<br />
standard size brick totally dominates<br />
in existing buildings.<br />
Taking out the old window and an area<br />
around the window, and putting in a<br />
new one with better functionalities,<br />
reducing thermal bridging around<br />
the frame. A window that extends<br />
into the existing wall reinforcing the<br />
wall. It is insulating but also has a<br />
humidity transport device built into<br />
it. The operation is quite simple as<br />
it is only a partial refurbrickment. It<br />
would indeed be possible to do it<br />
during the sale of the house, when<br />
the seller is out and before the buyer<br />
is moving in.<br />
Mapping the drivers behind<br />
refurbishment, group number three<br />
had listed several, focusing on the<br />
energy aspect. Reducing energy costs<br />
is a crucial driver both for the private<br />
owner and for society, the group<br />
concluded. Then certain parts of<br />
the building could be considered for<br />
special focus, such as the window, the<br />
roof or the envelope. What is needed<br />
is to balance all the options, provide<br />
decision makers with the matrix and<br />
let them act upon it. In this way,<br />
professionals provide the lay person<br />
with a tool, but leave the decision to<br />
him or her. Again, simplicity would<br />
often be the thing to remember. Any<br />
technological fix thus must take its<br />
place in the matrix. Sometimes it is<br />
indeed a question of forcing people<br />
to put on a jumper instead of turning<br />
up the heat. In the concluding debate<br />
one statement stood out and sent<br />
the participants off into the late<br />
afternoon sun: Follow the seasons<br />
– use the raincoat when it is raining.<br />
That is how we should perceive the<br />
functionality and meaning of the<br />
façade.<br />
21
FINALLY <strong>THE</strong> PARTICIPANTS WERE ASKED<br />
TO GIVE ONE LINE OF ADVICE;<br />
<strong>THE</strong>Y CAME UP WITH <strong>THE</strong> FOLLOWING<br />
To practioners<br />
Take it seriously<br />
Remember the human factor!<br />
Try partnering with producers, architects, engineers etc<br />
Exchange methodologies and green practices<br />
The best medicine knows the body so well it will cure it by itself,<br />
- passive houses create passiv people<br />
Always recpect the end-user’s needs and preferences<br />
Practicioners should listen to users<br />
To governments<br />
Focus on benchmarks instead of hard numbers<br />
Invest in the key variables<br />
Give incitament; the most important is money e.g. cheap loans<br />
Put the environment back on the agenda after COP 15<br />
Increase transparanecy when choosing options<br />
Governement must create incentives<br />
Governments should listen to researchers<br />
To researchers<br />
Use the advantage of not being in a hurry<br />
Architecture and emotional values are important<br />
Keep it simple<br />
Develop communication tools<br />
Care about the relate to users<br />
Reserarchers should use examples<br />
Researchers should listen practitioners<br />
23
ARTICLES<br />
25
26<br />
FAÇADE REFURBISHMENT<br />
– WHAT IS <strong>THE</strong> POTENTIAL?<br />
ANNE BAGGER<br />
New buildings, built according to<br />
today’s strict regulations for energy<br />
consumption, only have little impact<br />
on the total consumption of energy<br />
for heating and hot water due to the<br />
proportionally large existing building<br />
stock. Therefore, if old buildings are<br />
either torn down and replaced or<br />
refurbished and brought up to today’s<br />
standard, significant energy savings<br />
may be achieved. Also, interest in<br />
the reuse of building materials and<br />
the conservation of cultural heritage<br />
makes refurbishment attractive.<br />
Fig. 1: Max energy consumption for the heating of<br />
buildings, according to the Danish building standard.<br />
The blue bar to the left is the average consumption for<br />
existing buildings.<br />
Three different scenarios are reflected<br />
upon here. The data is taken from a<br />
publication from the Danish Building<br />
Research Institute (“Potentielle<br />
energibesparelser i det eksisterende<br />
byggeri”, SBi 2009:05). The scenarios<br />
consider the possible energy savings<br />
for heating and hot water in homes<br />
and offices in Denmark, given a<br />
certain extent of refurbishment.<br />
Fig. 2: Some home owners fear that a refurbishment<br />
of their home will end up messy and expensive<br />
Scenario 1:<br />
Buildings with a larger energy<br />
consumption than required by the<br />
1970’s standards are refurbished<br />
and brought up to today’s standards<br />
in terms of insulation. For either<br />
technical or aesthetic reasons only<br />
about 3 out of 4 of these buildings<br />
are considered for refurbishment.<br />
Energy savings: On average 20-25%<br />
of today’s energy consumption for<br />
heating and hot water.<br />
Cost: About DKK 200 billion (25<br />
billion Euros).<br />
Timeframe return on investment:<br />
Investment is earned back in 15-<br />
25 years. (Some of the investment<br />
will be necessary, anyhow, in order<br />
to extend the service life of the<br />
buildings.)<br />
Scenario 2:<br />
All buildings in Denmark are<br />
brought up to today’s standards,<br />
not considering technical difficulties<br />
or aesthetic issues.
(Variant: All buildings in Denmark<br />
are brought to a super-low energy<br />
consumption level)<br />
Energy savings: 35-40% (45-50%)<br />
Cost: About DKK 400 billion (50 billion<br />
Euros) (DKK 560 billion DKR, or 75<br />
billion Euros)<br />
This cost is probably underestimated,<br />
since it does not consider extra costs<br />
for necessary special solutions.<br />
Scenario 3:<br />
Only the poorest insulated buildings<br />
are considered, such as cavity<br />
walls and roofs with a minimum of<br />
insulation. Of these, less than half<br />
are improved, corresponding to<br />
those where there are no structural,<br />
technical or architectural difficulties<br />
involved.<br />
Energy savings: About 5%<br />
Cost: About DKK 30 billion (4 billion<br />
Euros).<br />
The investment is earned back within<br />
5-10 years.<br />
Based on these three scenarios, it<br />
can be concluded that there is a<br />
great potential for energy savings<br />
in building refurbishment. With<br />
the technical solutions available<br />
today, Scenario 2 is not a realistic<br />
possibility. Scenario 1 is possible, and<br />
ideally ought to become reality, but<br />
a number of factors are hindering<br />
this development, leaving scenario<br />
3 as the most likely. Among the<br />
reasons for this are that building<br />
owner’s often are confused about<br />
Fig. 3: All Danish buildings must be assessed and marked by an energy label when it is sold or let out. The energy<br />
label indicates the building’s energy effectiveness, and points out the most obvious improvements to carry out<br />
the actual cost savings, the return<br />
on investment, and how to raise the<br />
appropriate financing, and that they<br />
may worry that the project will turn<br />
out more expensive than estimated.<br />
Also, most private home owners<br />
lack knowledge about the possible<br />
technical solutions, and many people<br />
fear that a refurbishment project will<br />
turn out messy and full of errors.<br />
Among engineers, architects and<br />
craftsmen, there may be a lack of<br />
will and skill to apply new technical<br />
solutions, and manufactures may be<br />
reluctant to vouch for new technical<br />
solutions.<br />
The owners of private homes need<br />
suitable assistance to create an easy<br />
overview of the potential energy<br />
savings, the economy involved and<br />
the technical solutions applicable to<br />
the refurbishment of their home.<br />
Education and certification of<br />
craftsmen, engineers and architects<br />
makes the use of new solutions<br />
easier, and reduces the risk for<br />
the manufacturer. State support<br />
accelerates the use of certain<br />
technical solutions. Public campaigns<br />
may, among other things, focus on<br />
the non-energy benefits of home<br />
refurbishment.<br />
Anne Bagger is a post-doctoral fellow at<br />
the Department of Civil Engineering at the<br />
Technical University of Denmark (DTU).<br />
27
Solid and skeletal construction.<br />
The distinction between solid and<br />
skeletal construction has been one<br />
of the principal ways of categorizing<br />
architecture for centuries.<br />
The construction of a solid material,<br />
whether carved out of existing<br />
structure, like with the cave, or built<br />
from stacked stone or brick, is based on<br />
the structural principle of distributing<br />
loads in a homogeneous structure.<br />
The skeletal construction refers to<br />
the use of timber or steel creating<br />
a structural latticework, to which<br />
membrane components can be<br />
attached. The skeleton takes care of the<br />
structural demands, the membranes<br />
deals with the climatic issues.<br />
After a couple of thousand years<br />
of skeletal wooden construction,<br />
Denmark gradually in the 16th<br />
century, due to lack of wood, turned<br />
its attention to developing solid-<br />
based construction methods based<br />
on masonry. First in the form of<br />
timber framing, but eventually as<br />
full-masonry construction. This<br />
method continued to be refined<br />
by the development of the craft<br />
until it was at such a high level of<br />
perfection, that the material tactility<br />
and the masonry bond itself in the<br />
40ties and 50ties were used as<br />
the primary means of architectural<br />
expression on buildings of otherwise<br />
28<br />
extreme architectural simplicity.<br />
Higher demands, first for speed of<br />
erection, later for higher insulation<br />
values, gradually marginalised the<br />
solid (with insulating cavity) wall. A<br />
version, that still looks like it, but<br />
actually is something completely<br />
different and therefore totally<br />
uninteresting, still exists. In the<br />
meantime the skeletal construction<br />
method, being able to accommodate<br />
for the ever-changing demands of<br />
the energy-related trends, prospered.<br />
By being able to add, remove<br />
or exchange layers of varying<br />
specification, the skeletal frame<br />
structure was the perfect playground<br />
for individual experiments and was<br />
therefore adopted by the architects<br />
as the preferred means of expression.<br />
Refurbishing solids<br />
The result is that solids construction<br />
is seen as a phenomenon of the<br />
past with no actual interest for<br />
modern architecture. An area that<br />
has no future and therefore would<br />
be a dead end to investigate.<br />
The refurbishment of the masonry<br />
architecture, covering almost the<br />
entire city of Copenhagen, except<br />
for a few areas in the western central<br />
parts, suffers gravely under this.<br />
There are no really good solutions<br />
to increasing the energy performance<br />
of this architectural tradition other<br />
<strong>THE</strong> SOLIDS<br />
JESPER NIELSEN<br />
than covering them with a disguising<br />
and disfiguring (skeletal) coat.<br />
The need for a new solids tradition<br />
One of the major reasons for<br />
the absence of solutions is the<br />
general lack of interest for solid or<br />
homogeneous construction methods.<br />
In order to activate knowledge and<br />
experience in a field, a number of<br />
people must work within that field<br />
and evolve it. Having access to a few,<br />
that remembers “how we used to do<br />
it” is not enough. Only a living and<br />
innovative practice within the field<br />
of homogeneous construction, will<br />
create contemporary solutions. The<br />
evolving practice of digital crafting<br />
makes this even more relevant.<br />
The autarki project<br />
CINARK has embarked in a<br />
number of projects attracting focus<br />
to homogeneous construction<br />
methods. “Textile formwork”, by<br />
PhD student Anne-Mette Manelius,<br />
“revitalization of the masonry<br />
wall” by PhD student Mette Jerl<br />
Jensen and the “Autarki” project.<br />
The Autarki project is not dealing<br />
with bricks, but with cross-<br />
laminated timber. It is focusing on<br />
further development of the present<br />
construction techniques of the<br />
material. Through both technical and<br />
process optimization of the material<br />
use we investigate solutions, which will
improve recyclability and reduce the<br />
energy consumption of the building.<br />
One of the main investigations<br />
concern the ability of the material<br />
to work as a homogeneous (double<br />
shell with cavity) wall, that can<br />
be seen as a continuous surface<br />
from exterior to interior space.<br />
The project will result in a small<br />
experimental building, erected in<br />
1:1 on the grounds of the Royal<br />
Academy School of Architecture in<br />
spring 2011. The building will be<br />
intirely self-sufficient in terms of<br />
energy use and will demonstrate the<br />
architectural and technical potential<br />
in a contemporary solids tradition.<br />
Jesper Nielsen is .Head of Centre at CINARK,<br />
at The Danish Royal Academy’s School of<br />
Architecture.<br />
29
The façade technology of the 20th<br />
century was coined by dissolving<br />
the massive wall, which, in the<br />
search for structural and visual<br />
transparency, led to the development<br />
of the curtain wall. More than sixty<br />
years ago the post-beam-façade<br />
thus became firmly established as a<br />
technical solution. Since then, it has<br />
undergone numerous developments<br />
resulting in a multitude of design<br />
options, as well as high efficiency<br />
in terms of technical performance.<br />
At the end of the 20th century the<br />
main task for building planners was to<br />
combine building design and energy<br />
requirements. Thus research and<br />
design developments focused on the<br />
integration of climate aspects into the<br />
façade technology; the result being<br />
various variants of the double façade:<br />
second-skin façade, box façade,<br />
corridor façade, and shaft-box façade.<br />
Current developments of such<br />
integrated façades, still focused on<br />
energetic improvement, show two<br />
tendencies: the so-called hybrid or<br />
mosaic façade, a combination of a<br />
double façade with a single façade,<br />
to further increase efficiency. And<br />
alternatively, the so-called component<br />
30<br />
Figure 1 – Overview double façades<br />
NEW PERSPECTIVES ON<br />
FAÇADE REFURBISHMENT<br />
ULRICH KNACK<br />
façade; some or almost all building<br />
services components are integrated<br />
into the façade itself, to comply with<br />
the trend toward combining functions<br />
and to increase the performance of<br />
the façade as an industrial product.<br />
The same basic principles of façade<br />
constructions are used for all variants,<br />
aluminum post-beam-system or<br />
element façade, we merely add<br />
additional functions to the existing<br />
system. Along with and partially due to<br />
enhanced legal restrictions they have<br />
undergone improvements in terms of<br />
their thermal properties yet, they still<br />
pose a critical problem for the façade<br />
technology, because on the one hand<br />
a physical contact between the inner<br />
and the outer shell is necessary to<br />
enable load transmission, but on<br />
the other a complete separation<br />
is desirable in terms of building<br />
physics criteria. For the time being,<br />
this seems an unresolvable conflict.<br />
We may still cite Mike Davis, who,<br />
while working for Richard Rogers<br />
on the Lloyds Building in London,<br />
suggested the “polyvalent wall” –<br />
the wall as a monolithic building<br />
component combining the function<br />
of the façade, as well as its<br />
Figure 2 – Double façades, integration of building<br />
services components<br />
controllability and the possibility of<br />
energy generation – a task that both<br />
then and now, 30 years later, cannot<br />
be fully fulfilled. However, this idea<br />
can be viewed as a starting point<br />
for the development of “integrative”,<br />
“intelligent” or “smart” façades.<br />
Today’s developments are – besides<br />
various design trends – primarily<br />
driven by material-related or<br />
technological innovations. the<br />
following topics were identified as<br />
technical corner points of a field of<br />
tension that encompasses the new<br />
developments and the conception of<br />
façades in addition to aesthetic trends:<br />
energy, efficiency and individuality.<br />
Energy understood as the motor for<br />
all actions paired with the actuality<br />
of the energy market; operational<br />
energy and embodied energy in<br />
materials. Efficiency in the sense<br />
of performance expected from the<br />
façade as a technically sophisticated<br />
building component. Individuality<br />
as part of the architecture that<br />
reflects the particular urban, spatial<br />
and aesthetic form of the building.<br />
Figure 3 – Façade Research Group of the Faculty of Architecture /<br />
Delft Technical University
With the increasing awareness of the<br />
need for sustainable solutions, the<br />
relation between façade design and<br />
energy-consumption has become key<br />
to the question of reuse of buildings.<br />
In a market with rising demands<br />
on quality, and on environmental<br />
and financial sustainability, this is<br />
especially relevant for the enormous<br />
number of existing buildings.<br />
The research executed by the Façade<br />
Research Group is therefore based<br />
on a wide range of issues including<br />
building construction, architecture,<br />
installations and finance. This<br />
research has led to the development<br />
of a number of strategies dealing<br />
with the many complex aspects of<br />
office building renovation. Thus, a<br />
strategic overview of the possibilities<br />
and systemized solutions of office<br />
building façades, and a tool box<br />
of various façade refurbishment<br />
instruments for dwellings are being<br />
developed in order to provide for a<br />
decision making process for façade<br />
refurbishment on the international<br />
market, taking architecture, costs,<br />
construction and climate into account.<br />
Simulations have shown that an<br />
energy saving of 75% is possible,<br />
and that there will be a return on<br />
investment well within the lifespan of<br />
the technical components used. Taking<br />
other economic aspects such as the<br />
improvement of material reuse and<br />
the potentials for gained rental surface<br />
and higher rental rates into account,<br />
intelligent renovation seems not only<br />
to enhance sustainability, but also<br />
to make an interesting investment.<br />
The building marked is conservative<br />
– and must be, as building is a<br />
long term investment with many<br />
risks. However, with regards to the<br />
environmental footprint, buildings<br />
should be conceived as having<br />
a long life cycle. But building on<br />
existing knowledge and employing<br />
classic scientific research methods<br />
– problem outline, compilation of<br />
material and knowledge, evaluation<br />
and interpretation, structuring and<br />
lastly the development of subsequent<br />
steps – does lead to rather small<br />
steps in development. On this<br />
background, the Façade Research<br />
Group has employed the idea of<br />
heuristic development in order to<br />
faster identify future developments<br />
and their potential and risks. Thus, in<br />
addition to gaining knowledge about<br />
individual technological options, we<br />
learn to quickly assess and evaluate<br />
them. The analysis does not only<br />
consider purely technical parameters<br />
(construction and energy) as deciding<br />
factors for whether or not a certain<br />
technology is worth pursuing but<br />
also social and economic criteria.<br />
Architects do hate to deal with existing<br />
buildings. They are trained to develop<br />
a story around a location, a function<br />
or a client’s request, and to make this<br />
their own idea in order to differentiate<br />
their design from other architect’s<br />
stories and designs. In dealing<br />
with existing buildings, an existing<br />
architecture must be taken on board,<br />
which means that the beginning of<br />
the story is already set, presumably<br />
even linked to negative or positive<br />
individual or common emotions.<br />
Understanding this, we have to<br />
consider two different main strategies<br />
for the refurbishment of existing<br />
buildings: Either, conservation of<br />
valuable buildings and constructions<br />
with the addition of only the<br />
necessary technical, functional<br />
or aesthetic features. Or, keeping<br />
only the main structure, making<br />
a complete change to a new look,<br />
and using new technology. It is<br />
in this field of tension we have to<br />
position ourselves as researchers,<br />
technologists and designers,<br />
accepting that each building requests<br />
for positions and decisions to be taken.<br />
Ulrich Knaack is Profe sor of Design of<br />
Constructions at the Faculty of Architecture<br />
at the Delft University of Technology.<br />
31
The past year has been dominated<br />
by two issues, which will continue<br />
to impact on the way we go about<br />
our business as building designers.<br />
Firstly, the implications of climate<br />
change and the way our buildings<br />
increasingly need to deliver high<br />
performance and low impact.<br />
The effects are felt in the form of<br />
legislation, but also increasingly<br />
as a demand in the marketplace<br />
for sustainability rated buildings.<br />
Secondly, the economic crisis has had<br />
– and continues to have – significant<br />
implications, and both businesses and<br />
professionals are feeling the strain.<br />
During these difficult times, the<br />
Society of Façade Engineering<br />
(SFE) has been steadily expanding<br />
and raising awareness of the<br />
façade engineering as an essential<br />
component of integrated design and<br />
delivery of buildings and building<br />
envelopes. The discipline is potentially<br />
maximising value for clients and<br />
offering the broad technical approach<br />
needed for the realisation of<br />
sustainable buildings to increasingly<br />
challenging programs and budgets<br />
in a global market. This could be<br />
the decade of the façade engineer.<br />
In his influential work De Architectura,<br />
Roman architect Vitruvius talks about<br />
the three elements of Architecture:<br />
Commodity, Firmness, and Delight.<br />
There are interesting parallels to the<br />
32<br />
<strong>THE</strong> DECADE OF <strong>THE</strong><br />
FAÇADE ENGINEER<br />
MIKKEL KRAGH<br />
nature of façade engineering in that<br />
the building envelope needs to fulfil<br />
the functional requirements and meet<br />
the specified performance criteria,<br />
while having a fundamental impact<br />
on architectural aesthetics and the<br />
intangible qualities of the resulting<br />
enclosed space. This, then, is perhaps<br />
one of the aspects that appeal to a<br />
new generation of technically minded<br />
architects and architecturally minded<br />
engineers? There is no doubt that<br />
the nature of façade engineering can<br />
be both complex and stimulating.<br />
Appropriate application of highly<br />
specialised skills is potentially the<br />
difference between a successful<br />
project and a less successful one<br />
The need for specialist input stems<br />
from the gradual transition from<br />
traditional to non-traditional methods<br />
and technologies. Technological<br />
progress and the industrialisation of<br />
the construction industry mean that<br />
the role of the Architect is changing<br />
from that of controlling the design<br />
through a profound knowledge of<br />
materials and techniques to a role<br />
of orchestration of a multitude of<br />
specialist skills, knowledge, and<br />
industry intelligence – possibly<br />
benefiting from façade engineering<br />
input throughout the various stages<br />
of the design process. The increasing<br />
complexity of the technology and<br />
the recognition that not many<br />
architectural practices can sustain<br />
in-house skills in every field resulted<br />
in façade engineering as a relatively<br />
new professional discipline. The<br />
first façade engineering groups<br />
were set up around 20 years ago in<br />
response to the need for specialist<br />
input on technically challenging<br />
projects. Façade engineering<br />
covers the grey area between the<br />
more traditional disciplines but<br />
also overlaps significantly with<br />
all of them, to varying degrees<br />
depending on the circumstances.<br />
One of the key challenges for the<br />
years to come is the existing building<br />
mass, which needs to be upgraded<br />
to perform to today’s standards and<br />
contribute to the mitigation of climate<br />
change. The building envelope<br />
is instrumental to the successful<br />
combination of upgraded performance<br />
and architectonic qualities. Both<br />
aspects will drive up the value of<br />
Photograph © Christian Richters & Arup Associates
assets and lead to the demand<br />
for new retrofitting technologies<br />
and techniques, including thermal<br />
insulation and solar shading systems.<br />
We need to fundamentally alter the<br />
prevailing perception that existing<br />
buildings are somehow less exciting<br />
than new ones. Requalification of<br />
buildings and cities will become an<br />
increasingly important market and<br />
we need the right technologies and<br />
skills to face the challenges ahead.<br />
The development of advanced<br />
technology has often led to what<br />
appears to be complex buildings with<br />
variable and automated façades that<br />
respond to changes in environmental<br />
conditions and user behaviour. Clearly<br />
these systems represent progress in a<br />
technological sense and, when dealt<br />
with appropriately, the technology<br />
can facilitate high performance and<br />
bring about interesting architectural<br />
opportunities. There is, however,<br />
also a risk that certain systems are<br />
incorporated because they are seen as<br />
advanced technology and have come<br />
to symbolise high performance design<br />
(or even sustainable solutions). ‘Green<br />
Wash’ is the term used to describe<br />
design which is over-sold and under-<br />
delivered as sustainable through<br />
high tech gimmicks as opposed to<br />
Photograph © James Ward & Arup Associates<br />
pragmatic, evidence-based (and<br />
perhaps less exciting) solutions.<br />
Every project is unique and needs to<br />
respond to the client’s requirement,<br />
local climate, etc, and there is no<br />
one-size-fits-all solution for building<br />
design. The aim should always be<br />
high performance - low impact. At<br />
times the appropriate solution will<br />
be a highly technological design, at<br />
other times a passive design will be<br />
more appropriate. Passive design<br />
is based on fundamental principles<br />
and seeks to maximise the benefit of<br />
the natural climate and the physics<br />
of the building form, orientation,<br />
materials, etc. To this end, the<br />
building envelope is of fundamental<br />
importance and much can be gained<br />
from early stage studies of the impact<br />
of the building envelope on the<br />
environmental performance of the<br />
building. Advanced design tools and<br />
appropriate use of building physics has<br />
a lot to offer in this field. In a sense,<br />
we are witnessing a return to design<br />
before the era of air-conditioning<br />
and a rediscovery of fundamental<br />
design principles coupled with<br />
cutting edge technological solutions.<br />
Dr Mi kel Kragh is an A sociate at Arup<br />
where he leads the Façade engin ering team<br />
based in Milan (www.arup.com). Besides<br />
his work at Arup, he is the Chairman of<br />
the Society of Façade Engineering (www.<br />
Façadeengineeringsociety.org); Senior<br />
Visiting Research Fellow at University of Bath;<br />
and Visiting Profe sor at Politecnico di Milano.<br />
33
Building materials differ in many<br />
facets, but when it comes to load<br />
bearing elements for façades the<br />
range seems to narrow down to<br />
just a few, like steel, aluminium,<br />
and wood. In the research done<br />
in the last couple of years at the<br />
Delft University of Technology in the<br />
Netherlands and the Detmold School<br />
for Architecture and Interior Design<br />
in Germany, we have looked into<br />
new material approaches in order<br />
to push the envelope. The following<br />
short descriptions introduce a few of<br />
these experimental constructions, in<br />
which we have tried new materials<br />
and building techniques. Often<br />
the idea behind these concepts is<br />
the integration of functions into<br />
one element. This is a challenging<br />
process, and the insight we gain<br />
from the problems we run into,<br />
will surely lead to new solutions<br />
for the integration of functions.<br />
Development of a heating<br />
panel in fibre reinforced<br />
concrete for a façade<br />
The alternation of the glazing with<br />
floor-to-ceiling unglazed units was the<br />
main aspect of the façade concept.<br />
The idea was that the unglazed<br />
surfaces of the façade should be<br />
used as heating surfaces, to avoid<br />
the traditional solution with a heater<br />
placed in front of the glazed areas.<br />
Façade panels are made up of fibre<br />
reinforced concrete embattled with<br />
34<br />
textile fibres. This constitutes a<br />
load carrying system of the panels,<br />
which can be inserted into the<br />
façade system like standard glazing.<br />
The shell oriented towards the<br />
inside of the building is inlaid with<br />
meadows of capillary tubes that heat<br />
up in the summer and cool off in<br />
the winter. Fibre reinforced concrete<br />
provides a good heat conduction<br />
as well as the sufficient stability,<br />
and is therefore ideal for this use.<br />
Fig: 1<br />
Fibre reinforced concrete<br />
heating panel<br />
GRP-sandwich-construction for<br />
a boat hull in a novel folding<br />
technology<br />
A glass-fibre reinforced plastic (GRP)<br />
boat hull was developed during a<br />
seminar in plastics. This hull was<br />
constructed as a blank and was<br />
built as one even layer as opposed<br />
to usual constructions of boat<br />
hulls. The boat was folded to the<br />
final shape only after laminating<br />
the top layer with rigid foam.<br />
After several tests of the construction,<br />
delamination was ensured to take<br />
place only in the area immediately<br />
of the bend, thus eliminating any<br />
danger of loss of stability. This<br />
small sample was handy for testing<br />
NEW MATERIALS<br />
FOR <strong>THE</strong> FAÇADE<br />
MARCEL BILOW<br />
during the seminar, obviously more<br />
elaborate tests of the boat hull will<br />
be needed to confirm the stability of<br />
the construction. For use in buildings<br />
it enables the forming of accurate<br />
edges, which can be manufactured<br />
at low cost using a vacuum<br />
moulding press on a workbench<br />
Fig. 2 Folding a boat hull from a flat sandwich panel<br />
Modular Façade in fibre<br />
reinforced concrete<br />
Until now, materials used for extensive<br />
curtain walls have been aluminium,<br />
steel, wood or glass. The development<br />
of fibre reinforced concrete makes<br />
it possible to produce slim profiles<br />
and frames with dimensions close to<br />
those manufactured in aluminium or<br />
steel. The modular façade approach<br />
suggests the possible field of<br />
application of fibre reinforced concrete<br />
and the broadening of existing scopes<br />
for design. The use of fibre reinforced<br />
concrete in façades is commonplace<br />
in panels of curtain walls, whereas its<br />
utilisation for the supporting elements<br />
of the façade is new. The mock-up<br />
model still bears a lot of potential for<br />
development, as it has an elevation
width of only 60mm. The supporting<br />
pillars are filled with rigid foam and<br />
have an average thickness of just 10<br />
mm. The façade unit also includes a<br />
decentral mechanical ventilation unit.<br />
Fig: 3 Façade element of fibre reinforced concrete<br />
Air B Wall<br />
The experimental project Air B Wall<br />
by Jürgen Heinzel, within the scope of<br />
the pneumatic construction seminar<br />
AIR, was developed to be used in<br />
different ways. A huge number of<br />
air filled balloons are embedded in a<br />
clear plastic envelope. Every balloon<br />
can be individually air filled to vary<br />
the sizes of the balloons. If a special<br />
shape is desired, air is outtaken by<br />
the use of vacuum. The deflation<br />
of air from the balloon space will<br />
press the balloons together and<br />
thus establish a stiff load-bearing<br />
element. This principle is well known<br />
from coffee packs, which are solid<br />
hard under vacuum, but soften up<br />
and becomes shapable upon opening.<br />
A possible application is an adjustable<br />
moulding surface enabling low-cost<br />
free-formed surfaces. For indoor<br />
application or for active surfaces<br />
such as media façades, the option<br />
of controlling the shape and pulsation<br />
of each balloon interactively could<br />
be considered. This may also be<br />
applied for temporary use, such as<br />
flexible separation of walls during<br />
façade refurbishment, protecting<br />
office space from the building site.<br />
Fig: 4 Air B Wall<br />
Jackbox – a sandwich wall<br />
approach<br />
The Jackbox Pavilion is an<br />
experimental construction made<br />
to illustrate the use in architecture<br />
of sandwich construction methods<br />
already found in aviation and vehicle<br />
construction. Wall elements are<br />
layered as a sandwich with a GRP<br />
skin, an insulating core, and a fiber<br />
reinforced concrete layer on the<br />
inside. The use of fiber reinforced<br />
concrete allows the addition of<br />
thermal mass, and by additional<br />
insertion of capillary pipes the<br />
wall surface will still be usable as<br />
a wall heating or cooling element.<br />
To enable low-cost manufacturing<br />
of the wall construction modules,<br />
the structure is conceived of as a<br />
planar surface later to be formed<br />
to its final shape. Doors are held<br />
in silicone joints that serve as<br />
connections as well as hinges. The<br />
specially developed tools and aids<br />
for manufacturing this detail, have<br />
been produced with a 3D printer.<br />
Fig: 5 Jackbox Pavillion<br />
Marcel Bilow is research a sociate at<br />
the Façade Research Group at the Delft<br />
University of Technology, and co-founder<br />
of Imagine Envelope.<br />
35
One of the focus points of our research<br />
at the Delft University of Technology<br />
(TU Delft) is façade refurbishment.<br />
The efforts always show one thing:<br />
Successful refurbishment depends<br />
on numerous factors, such as the<br />
financial concept, the architectural<br />
design and others. But it is the<br />
combination of façade and building<br />
services, which is mainly responsible<br />
for the user comfort and the energetic<br />
performance of the building.<br />
This leads directly to the question if<br />
these traditional separated disciplines<br />
should be combined? However<br />
weather the integration of building<br />
services into the façade area is indeed<br />
better than the classical decentralized<br />
concept or not is hard to say. The<br />
comparison is very complex. It has<br />
to deal with indoor climate qualities,<br />
psychological issues such as control<br />
possibilities of the individual user,<br />
space needed for ducting, building<br />
and running costs, maintenance,<br />
warranties and much more.<br />
Figure 1, 2: Schematics of centralized and decentralized building services installations<br />
36<br />
NEXT ACTIVE FAÇADES<br />
- DECENTRALIZED BUILDING SERVICES<br />
FOR FAÇADE REFURBISHMENT<br />
TILLMANN KLEIN<br />
On top of that every building is<br />
different, making a comparison of<br />
executed projects very complicated.<br />
The concept of decentralized<br />
installations is not new, but the<br />
application on modern office<br />
buildings has only recently become<br />
more popular. Not much research<br />
has been carried out in this field.<br />
There is a study carried out by<br />
Institute für Luft- und Kältetechnik<br />
in Dresden, and a recently published<br />
one of the Steinbeiß-Transferzentrum,<br />
based on a two-year monitoring<br />
program of office buildings.<br />
There is indeed an argument that<br />
makes the decentralized approach<br />
interesting for refurbishment: In<br />
order too be independent from the<br />
existing structure, it makes sense<br />
to fit as many installations into<br />
the façade area as possible. The<br />
building envelope can provide all vital<br />
functions and existing installations<br />
can be removed or even left in place.<br />
The goal of the NEXT Active Façades<br />
project we are conducting at TU<br />
Delft is to develop service integrated<br />
façades, based on the product range<br />
of the involved parties. An essential<br />
idea of the concept is to identify<br />
product combinations for the manifold<br />
requirements of a complex market.<br />
The project was initiated as a<br />
joint effort of ALCOA Architectural<br />
Systems, Somfy, TROX/FSL and the<br />
Faculty of Architecture at TU Delft.<br />
Together the parties offer a<br />
broad range of knowledge and all<br />
components necessary for building<br />
services integrated façades. ALCOA<br />
provides unitized curtain walling<br />
façade systems. TROX/FSL offers a<br />
broad range portfolio of decentralized<br />
components, from simple integrated<br />
ventilation units to “all in one”<br />
components for heating, cooling<br />
and heat exchange. Somfy builds<br />
sun-shading systems and control<br />
units and the TU Delft’s role is the
strategic guidance of the project.<br />
The combination of the two<br />
disciplines has different aspects.<br />
First the material interfaces between<br />
components have to be defined. How<br />
will components be attached, where<br />
do pipes and cables run and who is<br />
actually mounting these? How can<br />
the concept be adapted to different<br />
architectural needs? But we also need<br />
to tackle immaterial interfaces: Who<br />
is responsible for the process, the<br />
maintenance and warranty? How<br />
can the product be communicated<br />
to the market and how can decision<br />
makers be approached. The project<br />
shows that the immaterial aspects<br />
are much more difficult to solve than<br />
the more design and engineering<br />
oriented material aspects.<br />
These kinds of integrated products<br />
have to be communicated to<br />
the decision makers at a very<br />
early design stage, because their<br />
introduction has an influence on all<br />
involved disciplines. Therefore we<br />
have developed a calculation tool to<br />
demonstrate the effect on comfort<br />
and energy need of this approach.<br />
At this state of the project, four<br />
different product configurations<br />
have been developed, in order to<br />
be able to react on different market<br />
needs. It starts with simple integrated<br />
ventilation units (for a situation where<br />
the existing exhaust ventilation<br />
system would be used further on)<br />
and ends with a concept where the<br />
new façade provides a functions for<br />
the office space, up to ventilation,<br />
cooling and heating. Basically other<br />
combinations could be realized as well.<br />
A first mock-up has been presented<br />
on the PROVADA 2010 real estate<br />
fair in Amsterdam. The involved<br />
companies are promoting the<br />
concept by using their established<br />
marketing structures (which is<br />
also an advantage of this strategy)<br />
and we can hope to see the first<br />
building with a NEXT façade in 2011.<br />
Tillmann Klein is Head of the Façade Research<br />
Group at the Faculty of Architecture at Delft<br />
University of Technology.<br />
Figure 3:<br />
possible service integration<br />
Figure 4: Mock-up of NEXT faccade on the PROVADA<br />
real estate fair<br />
37
PREFABRICATION AND <strong>THE</strong> CARE FOR DETAIL<br />
IN REFURBISHING EXISTING FAÇADES<br />
STIG MIKKELSEN<br />
Architecture is very much a<br />
question about the façade. The<br />
façade is the face of the building.<br />
Not only does it communicate to<br />
the world what is happening on<br />
the inside, it constitutes a meaning<br />
and an identity in its own right.<br />
As environmental responsibility<br />
and sustainable energy schemes<br />
become still more decisive drivers in<br />
architectural design, naturally façade<br />
construction should reflect this.<br />
Façades of existing buildings comprise<br />
a particular important aspect, and<br />
rather than replacing the entire<br />
building, more sustainable solutions<br />
ought to be found. But façades are<br />
complex filters between the inside<br />
and the surface of the building,<br />
thus changes to the surface must<br />
be balanced against the provision<br />
of satisfactory indoor climate.<br />
Mainly driven by the advantages of<br />
rational production and installation<br />
methods, over the last decades<br />
production of commercial façades<br />
FACADE REALDANIA 23. september 2010<br />
38<br />
has moved towards prefabrication.<br />
Indeed, also increasing air tightness<br />
requirements and demands for better<br />
insulation values, have played a role in<br />
prompting more efficient production<br />
under more controlled conditions.<br />
Recently, Dissing+Weitling has<br />
completed the new Rambøll Head<br />
Office in Ørestad, Copenhagen. This<br />
project included design of a large,<br />
prefabricated envelope package.<br />
Specifications reflect the increasing<br />
demands on many fields towards<br />
making buildings more energy<br />
efficient, and at the same time<br />
demands for the creation of excellent<br />
work space for years to come.<br />
To ensure that these specifications<br />
were met without compromising the<br />
design in the process of developing<br />
the façade system, many mock-ups<br />
and tests were included in the tender.<br />
At Dissing+Weitling we are convinced<br />
that there is great potential to be<br />
more work off site, thus ensuring<br />
both the quality of the design and<br />
the performance of the Façade.<br />
Our experience with the use of modular<br />
principles and prefabrication in product<br />
design, as well as that of a closer<br />
collaboration with manufacturers,<br />
has led us to believe that also the<br />
refurbishment of existing façades in<br />
some cases could benefit from an<br />
approach based on prefabrication.<br />
However, façade refurbishments, or<br />
”reclads”, often suffer from a severe<br />
loss of architectural quality. Valuable<br />
details are handled improperly,<br />
leading to poor results that violates<br />
the initial design without adding new<br />
qualities to the façade. In order to<br />
refurbish existing façades in a<br />
sustainable and energy efficient way,<br />
and ensure architectural design of a<br />
high standard, both sufficient care,<br />
and the development of new tools<br />
found in doing more testing and based on prefabrication, is needed.<br />
1<br />
Architect MAA Stig Mi kelsen is a partner at<br />
Di sing+Weitling Architectute.
FACADE REALDANIA 23. september 2010<br />
LUFTKVALITET<br />
- MEKANISK VENTILATION<br />
- NATURLIG VENTILATION<br />
TEMPERATUR<br />
- OPVARMNING<br />
- NEDKØLING<br />
AKUSTIK<br />
LYS<br />
- DAGSLYS<br />
- KUNSTLYS<br />
BRAND<br />
- REDNINGSÅBNINGER<br />
- KOLLAPS / SIKKERHED<br />
ENERGI<br />
- DRIFT / VEDVLIGEHOLD<br />
- ØKONOMI<br />
FACADE REALDANIA 23. september 2010<br />
INDSIGT<br />
UDSIGT<br />
INDSIGT<br />
UDSIGT<br />
SOL / VARME<br />
TEMPERATUR<br />
4<br />
Klimaaktive FACADER<br />
DAGSLYS / BLÆNDING<br />
VIND<br />
STØJ / AKUSTIK<br />
39<br />
3
INTELLIGENT BEHAVIOUR<br />
ALEXANDRA THYGESEN<br />
When talking about sustainable<br />
solutions in building design the<br />
development of intelligent façades<br />
often pops up. Generally intelligence<br />
is defined as the ability to understand<br />
and profit from experience. In relation<br />
to façades intelligence is usually<br />
understood as a means of combining<br />
the envelope with regulation of the<br />
indoor climate. In this way the<br />
façade becomes part of the building’s<br />
technical systems for regulating<br />
daylight, lighting, heat, ventilation<br />
etc. Often the regulation is computer<br />
controlled rather than influenced by<br />
the users. Put more provocatively,<br />
intelligent façades are developed<br />
without trusting the intelligence of the<br />
daily users. Is this smart or alienating?<br />
In terms of those intelligent systems<br />
the users are often considered<br />
as disturbing elements due to<br />
their unpredictable behaviour.<br />
Preferably everything is to be<br />
calculated from standards and<br />
norms, which is reasonable in terms<br />
of construction engineering but<br />
does it make sense in relation to<br />
human beings and indoor climate?<br />
Individuals are different and have<br />
varying needs. Sometimes is it nice<br />
to feel the heat of the sun, at other<br />
times it is nice to feel the incoming<br />
air from an open window, but in both<br />
cases only if you yourself decide<br />
when and how. If not it is quickly<br />
transformed into user complaints of<br />
overheating and draft. The sense of<br />
comfort and well being is increased if<br />
people have influence on the indoor<br />
climate but it is difficult to handle<br />
in relation to a standardised mind<br />
set and calculations since behaviour<br />
is an incalculable factor. Is it then<br />
wise just to stick to quantified<br />
standards rather than also focusing<br />
on qualititative requirements and<br />
adaptation to individual needs?<br />
In my opinion an intelligent façade<br />
must be designed within a holistic<br />
architectural framework and by<br />
using, not combating, the climatic<br />
conditions. It does not have to be<br />
complicated. Numerous examples of<br />
multi functional façades can be found<br />
in the history of architecture. Façades<br />
that work, are very durable, have low<br />
costs for running and maintenance<br />
and even are intuitively understood<br />
by the users. It would be unintelligent<br />
not to profit from this knowledge.<br />
The biggest potential for developing<br />
sustainable façades is not necessarily<br />
found in extended use of technical<br />
solutions but in simple utilization of<br />
the climatic conditions combined with<br />
intelligent behavior. It is worth trying.<br />
Alexandra Thygesen is owner of AT Architects<br />
41
42<br />
DANISH SUMMARY<br />
CHRISTIAN BUNDEGAARD<br />
Seminaret ”Pushing the Envelope”<br />
samlede en række førende eksperter<br />
inden for forskning i og produktion<br />
af façader. Eftersom façaden ikke<br />
blot er bygningens ”hud” eller en<br />
dekorativ skal, men en afgørende<br />
del af bygningen både økonomisk,<br />
energimæssigt og funktionelt, er<br />
den et væsentligt indsatsområde for<br />
byggeriets udvikling i de kommende<br />
år.<br />
Det blev da også fuldt ud bekræftet<br />
under seminaret, der som særligt<br />
fokusområde havde bæredygtig<br />
renovering af eksisterende bygninger.<br />
Den eksisterende bygningsmasse<br />
byder på helt særlige façade-<br />
udfordringer, fordi man ud over et<br />
stort behov for at opdatere husene<br />
energimæssigt og funktionelt, ofte<br />
har at gøre med bevaringsværdig<br />
arkitektur, der vil lide ubodelig skade<br />
ved det forkerte indgreb.<br />
De to dages seminar var struktureret<br />
omkring korte oplæg med<br />
efterfølgende diskussion, samt<br />
gruppearbejde omkring udvalgte<br />
aspekter eller problemstillinger.<br />
Oplæggene dækkede et bredt felt<br />
af interesseområder og initiativer:<br />
Energibesparelses-potentialet ved<br />
bæredygtige renoveringer af den<br />
eksisterende bygningsmasse i<br />
Danmark; problemerne med energi-<br />
renovering af murstensbyggeri<br />
med arkitektoniske kvaliteter; nye<br />
materialer og utraditionelle idéer i<br />
udviklingen af fremtidens façader;<br />
bruger-synsvinklen; samt en række<br />
konkrete eksempler på byggerier med<br />
nyudviklede, bæredygtige løsninger<br />
såsom orientering af vinduerne<br />
i forhold til solen, anvendelse af<br />
nano-gel, lette elementer i komposit-<br />
materialer mm.<br />
Diskussionerne i grupper og i plenum<br />
samlede sig om især tre spørgsmål:<br />
Hvorfor er det så vanskeligt at<br />
engagere folk i bæredygtig og<br />
energibesparende renovering? Hvad<br />
skal der til for at skabe innovation og<br />
forandring? Hvordan kan man tænke<br />
funktionalitet, fleksibilitet og design<br />
sammen, så de indgår i en helhed,<br />
frem for at modarbejde hinanden?<br />
Spørgsmålet om øget engagement<br />
og brugerinddragelse blev drøftet<br />
i forhold til den gennemsnitlige<br />
boligejers tilbøjelighed til snarere at<br />
investere i ”det nye køkken” frem<br />
for i en intelligent façade. Hvad var<br />
det med alle disse nye køkkener, og<br />
hvilken lære kunne man uddrage<br />
af denne brugeradfærd med<br />
henblik på udviklingen af attraktive<br />
façadeløsninger?<br />
De mange muligheder for teknologiske<br />
”fix” eller lån af teknologier og<br />
materialer fra andre områder førte<br />
blandt deltagerne til et vist behov<br />
for at trænge ind til princippet bag
teknologi-anvendelsen, frem for at<br />
blive hængende i den rent teknisk-<br />
konstruktive proces. ”Gør det enkelt”;<br />
”tænk på brugeren”; ”tænk på<br />
helheden” lød det fra flere.<br />
Disse holdninger blev afspejlet<br />
i de løsningsforslag grupperne<br />
præsenterede. Én gruppe foreslog<br />
at man kunne gøre façader mere<br />
attraktive for menige brugere ved<br />
at udgive et glittet magasin med det<br />
nyeste i teknisk innovative, smukke<br />
og energirigtige façader – modelleret<br />
over boligmagasinernes indretninger,<br />
møbler og design. En anden gruppe<br />
udarbejdede et forslag til et skema,<br />
der kan kortlægge incitamenter og<br />
barrierer for bæredygtig renovering.<br />
Og den tredje gruppe udviklede et<br />
helt nyt produkt, et nyt ”murstens-<br />
system”, der i forbindelse med<br />
udskiftningen af vinduer ikke blot<br />
erstatter vinduet men også en del<br />
af muren, og som på én gang øger<br />
isoleringsgraden af façaden, sænker<br />
vinduets u-værdi og fjerner fugt fra<br />
murværket, og dermed bidrager til at<br />
forbedre husets indeklima og samlede<br />
energiregnskab.<br />
Den afsluttende debat understregede<br />
behovet for fortsat forskning og<br />
nytænkning, men også for at blive ved<br />
med at tænke i simple helheder, som<br />
at orientere husene rigtigt, anvende<br />
få men effektive materialer, samle<br />
funktioner i få materialer, tænke i<br />
indeklima og ikke mindst i bruger-<br />
synsvinklen. For uden brugernes<br />
interesse og accept når man lige så<br />
lidt, som man gør uden industriens<br />
villighed til eksperimenter.<br />
43
PARTICIPANTS<br />
Alexandra Thygesen, owner, AT Architects<br />
Anja Bache, associate professor, department of civil engineering, Technical University of Denmark<br />
Anne Bagger, post.doc., department of civil engineering, Technical University of Denmark<br />
Anne Beim, professor, the Royal Danish Academy of Fine Arts, School of Architecture<br />
Christian Bundegaard, writer and philosopher<br />
Emanuele Naboni, associate professor, the Royal Danish Academy of Fine Arts, School of Architecture<br />
Hans Kolby Hansen, CEO, Hansen Group<br />
Heidi Pedersen, PR, Christensen & CO Architects<br />
Jesper Nielsen, head of center, CINARK, the Royal Danish Academy of Fine Arts, School of Architecture<br />
Karsten Bro, creative leader, prefab, Arkitema Architects<br />
Lotte Bjerregaard, associate professor, department of civil engineering, Technical University of Denmark<br />
Marcel Bilow, co-founder, Imagine Envelope<br />
Martin Vraa Nielsen, ph.d. student, HLT and the Technical University of Denmark<br />
Mikkel Kragh, associate, Arup<br />
Morten Stender Christensen, m.sc. in engineering<br />
Nanna Gyrithe Jardorf, event coordinator, Danish Architecture Centre<br />
Natalie Mossin, specialist, Danish Architecture Centre<br />
