Trunking systems and battens

PHL-H8.QXD 10-03-2004 13:43 Pagina 8.1

Trunking systems

and battens


Selection guide – Trunking systems and battens

Luminaire

family

Trunking

systems

Family picture Page Protection Shock Emergency Mounting Lamps

resistance lighting solution possibilities

N P

IP class IK class TL5 TL-D

Maxos 8.6 IP20, IP40, IK02 • • • • •

IP54, IP64

TTX400 8.50 IP20, IP40 IK02 • • – • •

Tetrix 8.90 IP20 IK02 • – – – •

Battens

F F F

TMX204 LS 8.93 IP20, IP50 IK02 • • • 1)

– •

Pentura 8.96 IP20 IK02 – • – • –

Lineco 8.102 IP20 IK02 – • – – •

TMS028 8.100 IP20 IK02 – • – – •

8.2 TRUNKING SYSTEMS AND BATTENS

1) only version IP50 with electronic gear


Luminaire

family


systems

Design Wiring Reflectors Integrated

lighting

controls

5-wire mm 2 7-wire mm 2 9-wire mm 2 10-wire mm 2 14-wire mm 2 Bus bar White Aluminium

Maxos ++ • • – • • • • • •

TTX400 + • • • – – – • • •

Tetrix – • – – – – – • – –

TRUNKING SYSTEMS AND BATTENS 8.3


Maxos – A touch of style

Excellent design

The Maxos TL5 luminaire’s innovative award-winning design radiates

confidence and professionalism for standard applications, and can be

adapted with Maxos’s optics to add a touch of panache.

The perfect fit – every time

The busbar provides total flexibility since the luminaire can be

clicked in at any point along the lenght of the trunking. Spots can also

be clicked in between luminaires, increasing the scope to create the

ideal lighting system for the application. And as the room’s layout

changes, the luminaires can be easily re-positioned, ensuring the

perfect fit every time.


Light lines

To enable you to create a tailor-made light line system, Maxos comes

with a wide range of electrical solutions: from 5 up to 21 poles to

busbar systems.There is also a choice of ingress protection from

IP20 up to IP64. In addition, a wide choice of reflectors, mirrors and

optics make Maxos the undisputed market leader in trunking

systems.


Maxos TL5

The ultra-modern, award-winning Maxos TL5 provides that extra

special design touch in e.g. high-end retail outlets and offices. It is

based on the MASTER TL5 lamp, which, at 16 mm in diameter, is

40% slimmer than conventional TL-D lamps.Together with the special

optics and electronic gear,TL5 is 22% more energy efficient than

conventional systems, allowing further savings on installation and

running costs.

Maxos TL5 Maxos TL-D

Maxos TL-D

Maxos TL-D is ideal for a wide range of applications from standard

warehousing and heavy industry to super/hypermarkets and other

public areas. In addition, all Maxos luminaires are designed for wide

suspension distances, up to 5 metres apart, which saves on

installation time.



Overview Maxos

Suspension

brackets

in silver and white

Trunkings


Electrical units


Reflectors and

mirror inlays

Louvres and

optics

4MX656

5-wire 1.5 mm 2

7-wire 1.5 mm 2

5-wire 2.5 mm 2

7-wire 2.5 mm 2

Facetted reflector

- slotted

- standard

1-lamp TL5

2-lamp TL5

1-lamp TL5 EL

2-lamp TL5 EL

Semi-high-gloss optics

- wide-beam optic

- narrow-beam optic

White louvre

Prismatic optic


Maxos TL5

4MX656...2x

(double wiring)

2x5-wire 2.5 mm 2

2x7-wire 2.5 mm 2

Aluminium reflector

- narrow beam

- wide beam

- medium beam

- ‘double asymm.’ beam

- asymmetrical beam

- very narrow beam

Aluminium profiled louvre

Bus bar/1-lamp/TL5

Bus bar/2-lamp/TL5

Maxos bus bar system

for TL5 and TL-D

4MX056...BB (bus bar)

Bus bar/5-wire 2.5 mm 2

Bus bar/7-wire 2.5 mm 2

Bus bar/1-lamp/TL-D

Bus bar/2-lamp/TL-D

Ballee on

Maxos

4MX691 4MX691...BB 4MX091...BB (bus bar) 4MX012

4MX692...F 4MX692...D/C

4MX693...D6 4MX693...M2

BALLEE 2-lamp TL5

Ballee can also be fitted

on standard TL-D

trunkings

D6 optics

C6 optics

Decorative optics

(green lamellae)


9MX056

4MX056

5-wire 1.5 mm 2

7-wire 1.5 mm 2

5-wire 2.5 mm 2

7-wire 2.5 mm 2

Trapeze reflector

- without mirror

- with wide-beam mirror

- with narrow-beam mirror

- ‘wall washer’

- perforated without

mirror

- slotted without mirror

White louvre

Silver louvre

SDW-T /

Maxos TL-D / IP20 / IP40 CDM-T units

Maxos TL-D IP54 / IP64

4MX056...2x

(double wiring)

2x5-wire 1.5 mm 2

2x7-wire 1.5 mm 2

2x5-wire 2.5 mm 2

2x7-wire 2.5 mm 2

4MX091

1-lamp TL-D

2-lamp TL-D

1-lamp TL-D EL


with 3C track

2-lamp TL-D FSG32 mm

Facetted reflector

- without mirror

- with wide-beam mirror

- with asymm. beam mirror

- slotted without mirror

White louvre

Prismatic optic

Semi-high-gloss optics

- wide-beam optic

- narrow-beam optic

Extended trunkings

5-wire 1.5 mm 2 /300 mm

600 mm

4MX092...T 4MX092...F 4MX092...D/

C/Wing/L-D

4MX093...L 4MX093...L/PL/C6/D6

4MX056 A.../M...E... 4MX056...IP64

Aluminium reflector

- narrow beam

- wide beam



- wide beam / perforated

and decorated louvre

Wing optic reflector/

indirect decorative tube

with lamellae (1-lamp)

CDM-T lamp

SDW-T lamp

Includes facetted

reflector

1-lamp TL-D

2-lamp TL-D



1-lamp TL-D FF-sign

2-lamp TL-D FF-sign


White only

7-wire 1.5 mm 2

5-wire 2.5 mm 2

7-wire 2.5 mm 2

4MX013 4MX091...IP64 4MX014...IP54

4MX092...IP64

White only

1-lamp TL-D

2-lamp TL-D


with glass cover

- wide beam


L-Louvre



Trunking systems Maxos TL5 standard trunking

4MX656 5x1.5/5x2.5 4MX656 7x1.5/7x2.5

4MX656 2x5x1.5/2x5x2.5 4MX656 2x7x1.5/2x7x2.5

Dimensions in mm


~4MX656~Maxos TL5 standard trunking

4MX656 TL5 standard trunking sections

The trunking fulfils two functions: first it provides a sturdy in-line

mounting rail on which to fix the electrical units, and second, it

provides a housing for the electrical cables that bring power to the

units. All the trunking sections are made of hot-dip galvanised steel,

with a white or silver coating. They are available in dedicated TL5

lengths of 1, 2 and 3 electrical units 49 W (35/80 W) and 54 W

(28 W).

A flat ribbon cable (5 or 7 wires) or two flat ribbon cables

(2 x 5 or 2 x 7 wires) are integrated in the trunking and guarantee

(in combination with an integrated phase selection switch and

contact blocks) safe and correct cabling. The 7-wire cable is used to

integrate light regulation or emergency lighting for those electrical

units equipped with emergency battery packs. Double wiring

(2 x 5 or 2 x 7 wires) is needed to provide a completely separate

mains supply to the electrical units. Double wiring is mostly used for

emergency lighting by central emergency batteries or separate

switching. Hence, no extra contact blocks or wiring needs to be

installed.

For suspended light lines the trunking sections are connected using

the integrated electrical connector and a sturdy external mechanical

coupling piece (accessory). Surface mounted light lines use the same

integrated electrical connector and an internal coupler (accessory).

On the upper part of the trunking section special knockout

openings enable cable entry wherever needed.

The trunking is available with a complete range of interchangeable

components that optimise flexibility. The outstanding stability of the

sections and coupling pieces, allows suspension intervals of 3.4 m to

5 m.

The basic accessories of Maxos TL-D trunkings can also be used for

the TL5 trunkings.

Product ID A

4MX656 491 1479

4MX656 492 2958

4MX656 493 4437

4MX656 541 1179

4MX656 542 2358

4MX656 543 3537


Trunking systems Maxos TL5 standard trunking

Luminaire Specification (standard combination)

Preferred selection

Product ID European Order

4MX656 491 5x2.5 WH

Code (EOC)

58352299

4MX656 492 5x2.5 WH 58353999

4MX656 493 5x2.5 WH 58354699

4MX656 491 5x2.5 SI 58388199

4MX656 492 5x2.5 SI 58389899

4MX656 493 5x2.5 SI 58390499

4MX656 491 7x2.5 WH 58364599

4MX656 492 7x2.5 WH 58365299

4MX656 493 7x2.5 WH 58366999

4MX656 491 7x2.5 SI 58400099

4MX656 492 7x2.5 SI 58401799

4MX656 493 7x2.5 SI 58402499


Code (EOC)

4MX656 491 2x5x2.5 WH 58370699

4MX656 492 2x5x2.5 WH 58371399

4MX656 493 2x5x2.5 WH 58372099

4MX656 491 2x5x2.5 SI 58406299

4MX656 492 2x5x2.5 SI 58407999

4MX656 493 2x5x2.5 SI 58408699

4MX656 491 2x7x2.5 WH 58376899

4MX656 492 2x7x2.5 WH 58377599

4MX656 493 2x7x2.5 WH 58378299

4MX656 491 2x7x2.5 SI 58412399

4MX656 492 2x7x2.5 SI 58413099

4MX656 493 2x7x2.5 SI 58414799



Trunking systems Maxos TL5 electrical units

4MX691 1x TL5



~4MX691~Maxos TL5 electrical units

4MX691 TL5 electrical units

The electrical units for Maxos TL5 are designed for quick and

reliable click-on mounting. They are made of steel, with a white or

silver coating. For electrical connection to the trunking a connector

block is mounted. The electrical units are equipped with HF-P

electronic ballasts or HF-R dimming ballasts, allowing the light

output of the lamps to be regulated from 3 % to 100 %. HF-R units

must be mounted to 7-wire trunking sections. The electrical units

can hold one or two TL5 lamps, 28, 54, 35, 49 or 80 W.

Emergency lighting:

Special electrical units equipped with an emergency battery pack for

1 or 3 hours (EL1/EL3) are available. These units must be used with

7-wire trunking sections. If trunkings with double wiring are used

one flat ribbon cable can be connected to the central battery. This

provides a completely separate emergency lighting circuit. In this

case standard electrical units equipped with electronic ballasts can

be used for emergency lighting.

The electrical units can be combined with a complete range of

reflectors. Moreover, TL5 offers significant efficiency gains compared

to TL-D, and these gains increase when the ambient temperature is

high.

Product ID A

4MX691 28W/54W 1179

4MX691 35W/49W/80W 1479


Trunking systems Maxos TL5 electrical units


4MX691 1x TL5 4MX691 2x TL5



4MX691 1xTL5-49W HFP WH

Code (EOC)

58315799

4MX691 2xTL5-49W HFP WH 58320199

4MX691 1xTL5-49W HFP SI 58441399

4MX691 2xTL5-49W HFP SI 58442099

4MX691 1xTL5-49W HFR WH 58297699

4MX691 2xTL5-49W HFR WH 58324999

4MX691 1xTL5-49W HFR SI 58446899

4MX691 2xTL5-49W HFR SI 58447599



Trunking systems Maxos TL5 bus bar

4MX056 581/582/583 BB 5x2.5/7x2.5



~4MX056-5~Maxos TL5 bus bar

4MX056 TL5 bus bar trunking sections

4MX691 TL5 bus bar electrical units

The bus bar system provides complete flexibility in positioning the

dedicated bus bar electrical units in the bus bar trunking. It is

available with a white or silver coating.

An electrical bus bar (5 or 7 poles) is integrated in the trunking and

guarantees a safe and correct contact to the contact blocks of the

electrical bus bar units. For suspended light lines trunking sections

are connected using the integrated electrical connection unit and a

sturdy external mechanical coupling piece (accessory). For surface

mounting the same integrated electrical connection unit and an

internal coupler (accessory) are used. On the upper part of the

trunking section special knockout openings enable cable entry

wherever needed. Bus bar trunkings and standard flat ribbon

trunkings can be combined by using a special electrical connection

unit (accessory). The trunking sections in the TL-D lengths of 1, 2

and 3 electrical units 58 W are also used for TL5 bus bar units.

The dedicated electrical units for TL5 bus bar are equipped with

HF-P electronic ballasts or HF-R dimming ballasts. They can hold

one or two TL5 lamps 49 W and can be combined with a wide

range of standard Maxos TL5 reflectors and optics. If HF-R dimming

ballasts are used units must be mounted to 7-wire trunking sections.

Please order half of the units with a left adapter (A5L, A7L) and half

with a right adapter (A5R, A7R) to ensure full flexibility.

Product ID A

4MX056 581 1530

4MX056 582 3060

4MX056 583 4590






Product ID A

4MX691 28W/54W 1179

4MX691 35W/49W/80W 1479




4MX056 581/582/583 BB 5x2.5/7x2.5



4MX056 581 BB 5x2.5 WH

Code (EOC)

57451399

4MX056 582 BB 5x2.5 WH 57867299

4MX056 583 BB 5x2.5 WH 57303599

4MX056 581 BB 7x2.5 WH 57359299

4MX056 582 BB 7x2.5 WH 57352399

4MX056 583 BB 7x2.5 WH 57304299

4MX056 581 BB 5x2.5 SI 56398299

4MX056 582 BB 5x2.5 SI 56397599

4MX056 583 BB 5x2.5 SI 56396899

4MX056 581 BB 7x2.5 SI 56395199

4MX056 582 BB 7x2.5 SI 56394499

4MX056 583 BB 7x2.5 SI 56182799


An electrical bus bar (5 or 7 poles) is

integrated in the trunking.

4MX691 HFB/HFR BB A5L/A5R/A7L/A7R



4MX691 1xTL5-49W HFP A5R WH

Code (EOC)

58325699

4MX691 1xTL5-49W HFP A5L WH 58329499

4MX691 2xTL5-49W HFP A5R WH 58326399

4MX691 2xTL5-49W HFP A5L WH 58330099

4MX691 1xTL5-49W HFR A7R WH 58327099

4MX691 1xTL5-49W HFR A7L WH 58331799

4MX691 2xTL5-49W HFR A7R WH 58328799

4MX691 2xTL5-49W HFR A7L WH 58332499

4MX691 1xTL5-49W HFP A5R SI 58448299

4MX691 1xTL5-49W HFP A5L SI 58452999

4MX691 2xTL5-49W HFP A5R SI 58449999

4MX691 2xTL5-49W HFP A5L SI 58453699

4MX691 1xTL5-49W HFR A7R SI 58450599

4MX691 1xTL5-49W HFR A7L SI 58454399

4MX691 2xTL5-49W HFR A7R SI 58451299

4MX691 2xTL5-49W HFR A7L SI 58455099

Spots can be easily fixed on the bus bar,

offering even more flexibility.



4MX692 F + 4MX693 D6


Maxos TL5 facetted reflectors and optics

~4MX692-1~Maxos TL5 facetted reflectors and optics

4MX692 TL5 facetted reflectors

4MX693 TL5 optics

The design-orientated facetted reflectors for TL5 are ideal for

applications focussing on trade (such as supermarkets and shops)

and for offices.They are made of steel, with a white or silver

coating, and are available for electrical units holding one or two TL5

lamps, 28, 54, 35, 49 or 80 W.

Optic (4MX693): the facetted reflector can be integrated with a

semi-high-gloss (D6) OLC optic of high-quality aluminium.This optic

has parabolic side reflectors and parabolic lamellae, and it can

create either a medium beam (with an integrated white top

reflector) or a narrow beam (with an integrated mirror top

reflector). A prismatic screen to cover the facetted reflector and a

white coated steel louvre for basic glare reduction are available on

request.

The reflectors are fixed via a simple click-in on the electrical units.

The facetted TL5 reflectors must be connected to each other in a

light-line with additional coupling pieces. End plates for the beginning

and the end of the light-line are available as accessories.

Product ID A

4MX692 49 F 1479

4MX692 54 F 1179



Trunking systems Maxos TL5 facetted reflectors and optics



4MX692 F + 4MX693 D6



4MX692 1/2 49 F WH

Code (EOC)

58415499

4MX692 1/2 49 F SI 58419299

4MX692 1/2 49 F-S-D/I WH* 59982099

4MX692 1/2 49 F-S-D/I SI*

*D/I: slotted facetted reflector for direct/indirect light distribution

59984499

Accessories

9MX056 EP-F WH/SI

End cap.

Accessory European Order

Code (EOC)

9MX056 EP-F SI 55285600

9MX056 EP-F WH 55284900

9MX056 CP-F SI 55443000

9MX056 CP-F WH 55441600




4MX693 1/2 49 P

Code (EOC)

59977600

4MX693 1/2 49 L-F WH 59980699

4MX693 1/2 49 D6-WB 19900600

4MX693 1/2 49 D6-NB 19901300

9MX056 CP-F WH/SI

Reflector coupling pieces.



4MX692 + 4MX693 M2


Maxos TL5 aluminium reflectors and optics

~4MX692-2~Maxos TL5 aluminium reflectors and optics

4MX692 TL5 aluminium reflectors

4MX693 TL5 optics

The aluminium reflectors for TL5 are optimised for applications in

industry, supermarkets and shops. They are made of high-quality

aluminium in one piece and are available for electrical units holding

one or two TL5 lamps, 28, 54, 35, 49 or 80 W.

For wide-beam, medium-beam, narrow-beam, asymmetrical-beam,

and double-asymmetrical-beam light distributions a semi-high-gloss

(D) aluminium reflector is available. For very narrow beams a highgloss

(C) aluminium reflector is available. All the TL5 aluminium

reflectors can be equipped with aluminium louvres with profiled

lamellae for glare reduction.

The reflector is fixed to the electrical unit via a simple click. The

reflectors can be connected to each other in a light-line with

coupling pieces (9MX056 CP/TL5) (accessories). Decorative

endplates for the beginning and the end of the light-line, are

available as accessories.

Product ID A

4MX692 49 1479

4MX692 54 1179



Trunking systems Maxos TL5 aluminium reflectors and optics


4MX692 D-NB + 4MX693 M2 4MX692 D-WB

4MX692 D-A

Semi-high-gloss (D) aluminium reflector for

an asymmetrical beam.



4MX693 1 49 M2

Code (EOC)

58421599

4MX692 1/2 49 D-WB 58427799

4MX692 1/2 49 D-NB 58428499

4MX692 1/2 49 D-MB 58429199

4MX692 1/2 49 D-DA 58430799

4MX692 1/2 49 C-NB 58431499

4MX692 1/2 49 D-A 58432199


Accessories

9MX056 EP/TL5

End caps.

9MX056 CP/TL5

Reflector coupling pieces (2 pcs.).

~4MX692-2~Maxos TL5 aluminium reflectors and optics


Code (EOC)

9MX056 EP/TL5 SI 55283200

9MX056 CP/TL5 14553900


Trunking systems Maxos TL5 Ballee

4MX012


~4MX012~Maxos TL5 ballee

4MX012 TL5 Ballee

Ballee on Maxos creates a flexible, decorative lighting solution that is

ideal for offices. The system is coloured silver and offers two

separated 180° adjustable reflectors holding two pre-mounted TL5

lamps of 35 W or 49 W to provide direct or indirect light.

Ballee on Maxos is available in versions to be connected to standard

trunkings or to bus bar trunkings in the lengths of TL-D 58 W.

A connector block is mounted for electrical connection to the

trunking. The Ballee units are equipped with electronic ballasts

(possibly HF-R dimming ballasts). HF-R units must be mounted to

7-wire trunking sections.

Optics: high-gloss (C6) or semi-high-gloss (D6) optics of high-quality

aluminium meeting BAP60 glare requirements or decorative optics

with greenish acryl lamellae are integrated in the Ballee reflectors.



Trunking systems Maxos TL5 Ballee




4MX012 581 2xTL5-35W/840 HFP C7 SI

Code (EOC)

17824700

4MX012 581 2xTL5-35W/840 HFP D7 SI 17825400

4MX012 581 2xTL5-35W/840 HFP M-D SI 17826100

4MX012 581 2xTL5-35W/840 HFR C7 SI 17830800

4MX012 581 2xTL5-35W/840 HFR D7 SI 17831500

4MX012 581 2xTL5-35W/840 HFR M-D SI 17832200

4MX012 581 2xTL5-49W/840 HFP C7 SI 17827800

4MX012 581 2xTL5-49W/840 HFP D7 SI 17828500

4MX012 581 2xTL5-49W/840 HFP M-D SI 17829200

4MX012 581 2xTL5-49W/840 HFR C7 SI 17833900

4MX012 581 2xTL5-49W/840 HFR D7 SI 17834600

4MX012 581 2xTL5-49W/840 HFR M-D SI 17835300

8.20 TRUNKING SYSTEMS AND BATTENS


Trunking systems Maxos TL-D standard trunking

4MX056 5x1.5/5x2.5 4MX056 7x1.5/7x2.5

4MX056 2x5x1.5/2x5x2.5 4MX056 2x7x1.5/2x7x2.5


~4MX056-1~Maxos TL-D standard trunking

4MX056 TL-D standard trunking sections

The trunking fulfils two functions: first it provides a sturdy in-line

mounting rail on which to fix the electrical units, and second, it

provides a housing for the electrical cables that bring power to the

units. All the trunking sections are made of hot-dip galvanised steel,

with a white or silver coating. They are available in lengths of

1, 2 and 3 electrical units 36 W and 58 W.

A flat ribbon cable (5 or 7 wires) or two flat ribbon cables

(2 x 5 or 2 x 7 wires) are integrated in the trunking and guarantee

(in combination with an integrated phase selection switch and

contact blocks) safe and correct cabling. The 7-wire cable is used to

integrate light regulation or emergency lighting for those electrical

units equipped with emergency battery packs. Double wiring

(2 x 5 or 2 x 7 wires) is needed to provide a completely separate

mains supply to the electrical units. Double wiring is mostly used for

emergency lighting by central emergency batteries or separate

switching. Hence, no extra contact blocks or wiring needs to be

installed.

For suspended light lines the trunking sections are connected using


coupling piece (accessory). Surface mounted light-lines use the same




The trunking is available with a complete range of interchangeable

components that optimise flexibility. The outstanding stability of the

sections and coupling pieces allows suspension intervals of 3.4 m to

5 m.

Product ID A

4MX056 361 1230

4MX056 362 2460

4MX056 363 3690

4MX056 581 1530

4MX056 582 3060

4MX056 583 4590



Trunking systems Maxos TL-D standard trunking




4MX056 581 5x2.5 WH

Code (EOC)

57314199

4MX056 582 5x2.5 WH 57315899

4MX056 583 5x2.5 WH 57310399

4MX056 581 5x2.5 SI 55187399

4MX056 582 5x2.5 SI 57899399

4MX056 583 5x2.5 SI 57452099

4MX056 581 7x2.5 WH 55341999

4MX056 582 7x2.5 WH 55120099

4MX056 583 7x2.5 WH 55121799

4MX056 581 7x2.5 SI 53685699

4MX056 582 7x2.5 SI 53686399

4MX056 583 7x2.5 SI 53687099




4MX056 581 2x5x2.5 WH

Code (EOC)

56253499

4MX056 582 2x5x2.5 WH 57312799

4MX056 583 2x5x2.5 WH 56373999

4MX056 581 2x5x2.5 SI 57379099

4MX056 582 2x5x2.5 SI 53690099

4MX056 583 2x5x2.5 SI 57380699

4MX056 581 2x7x2.5 WH 53676499

4MX056 582 2x7x2.5 WH 55477599

4MX056 583 2x7x2.5 WH 53677199

4MX056 581 2x7x2.5 SI 57922899

4MX056 582 2x7x2.5 SI 58247199

4MX056 583 2x7x2.5 SI 58248899


Trunking systems Maxos TL-D extended trunking


ME

M

~4MX056-3~Maxos TL-D extended trunking

4MX056 TL-D extended trunking sections

The extended trunking sections are made of hot-dip galvanised

steel, with a white or silver coating. They are available in lengths of

1 and 2 electrical units of 58 W. Extensions of 300 and 600 mm in

the middle only (M), or in the middle and at the end of these

trunking sections (ME), allow interrupted lines. That means gaps

between the electrical units corresponding to the extensions.

The gaps can be filled by blind covers, available as accessories.

A flat ribbon cable (5 wires) is integrated in the trunking and

guarantees (in combination with an integrated phase selection

switch and contact blocks) a safe and correct cabling.

For suspended light-lines the trunking sections are connected using






Product ID X

4MX056 581/582 M300/E300 300

4MX056 581/582 M600/E600 600

4MX056 581/582 M850/E850 850

4MX056 581/582 M950/E950 950

4MX056 581/582 M1110/E1110 1110



Trunking systems Maxos TL-D extended trunking




4MX056 582 M300 5x1.5 WH

Code (EOC)

57365399

4MX056 582 M300/E300 5x1.5 WH 57364699

4MX056 582 M300 5x1.5 SI 57960099

4MX056 582 M300/E300 5x1.5 SI 57386899

4MX056 582 M600 5x1.5 WH 55394599

4MX056 582 M600/E600 5x1.5 WH 55395299

4MX056 582 M600 5x1.5 SI 57457599

4MX056 582 M600/E600 5x1.5 SI 58225999

Accessories



9MX056 BC

Blind cover, used to close the spaces in the

trunking where no electrical units are

mounted.



9MX056 BC-L300 SI

Code (EOC)

53882999

9MX056 BC-L300 WH 53875199

9MX056 BC-L600 SI 53883699

9MX056 BC-L600 WH 53876899


Trunking systems Maxos TL-D electrical units

4MX091 1x TL-D


130

~4MX091-1~Maxos TL-D electrical units

4MX091 TL-D standard electrical units

The electrical units for Maxos TL-D trunking sections are designed

for quick and reliable click-in mounting. They are made of steel, with

a white or silver coating. A connector block is mounted for electrical

connection to the trunking.The electrical units are equipped with

electronic ballasts (possibly dimming ballasts) or low-loss

conventional ballasts. The conventional ballasts are available parallel

compensated (IC) or inductive (I). The units can hold one or two

TL-D lamps, 36 W or 58 W.

Dimmable versions are delivered with the HF-R electronic ballast,

allowing the light output of the TL-D lamps to be regulated from

3% to 100 %. HF-R units must be mounted to trunking sections

with 7-wire cable.

Emergency lighting

Special electrical units equipped with an emergency battery pack of


7-wire trunking sections. If trunkings with double wiring are used,

one flat ribbon cable will be connected to the central battery.

This provides a completely separate emergency lighting circuit.

Only standard electrical units equipped with electronic ballasts can

be used for emergency lighting.

The electrical units can be combined with a complete range of

reflectors. Some 2-lamp-version reflectors need special electrical

units (F32) with a short distance between the lamps. On request,

the electrical units can be upgraded from IP20 to IP40 with special

protection rings that are clicked onto the lampholder.

Product ID A

4MX091 36W 1230

4MX091 58W

* F32 lampholder

1530



Trunking systems Maxos TL-D electrical units


4MX091 1x TL-D 4MX091 2x TL-D

4MX091 2x TL-D F32



4MX091 1xTL-D58W IC LW WH

Code (EOC)

53748899

4MX091 2xTL-D58W IC LW WH 53751899

4MX091 1xTL-D58W IC LW SI 53835599

4MX091 2xTL-D58W IC LW SI 53838699

4MX091 1xTL-D58W HFB WH 49011099

4MX091 2xTL-D58W HFB WH 53709999

4MX091 2xTL-D58W HFB F32 WH 54588999

4MX091 1xTL-D58W HFB SI 53802799

4MX091 2xTL-D58W HFB SI 53806599

4MX091 2xTL-D58W HFB F32 SI 55400399

4MX091 1xTL-D58W HFB EL3 WH 53704499

4MX091 2xTL-D58W HFB EL3 WH 53714399

4MX091 1xTL-D58W HFB EL3 SI 53801099

4MX091 2xTL-D58W HFB EL3 SI 53811999

4MX091 1xTL-D58W HFR WH 53706899

4MX091 2xTL-D58W HFR WH 53710599

4MX091 2xTL-D58W HFR F32 WH 56375399

4MX091 1xTL-D58W HFR SI 53803499

4MX091 2xTL-D58W HFR SI 53807299

4MX091 2xTL-D58W HFR F32 SI 56929899



Trunking systems Maxos TL-D bus bar

4MX056 581/582/583 BB 5x2.5/7x2.5


~4MX056-4~Maxos TL-D bus bar

4MX056 TL-D bus bar trunking sections

4MX091 TL-D bus bar electrical units

The bus bar system provides complete flexibility in positioning the

dedicated bus bar electrical units in the bus bar trunking. It is

available with a white or silver coating. The trunking sections are in

lengths of 1, 2 and 3 electrical units 58 W.

An electrical bus bar (5 or 7 poles) is integrated in the trunking and

guarantees a safe and correct contact to the contact blocks of the

electrical bus bar units. For suspended light lines, trunking sections

are connected using the integrated electrical connection unit and a

sturdy external mechanical coupling piece (accessory). For surface

mounting, the same integrated electrical connection unit and an

internal coupler (accessory) are used. On the upper part of the

trunking section special knockout openings enable cable entry

wherever needed. Bus bar trunkings and standard flat ribbon

trunkings can be combined by using a special electrical connection

unit (accessory).

The dedicated electrical units for the TL-D bus bar are equipped

with electronic ballasts. They can hold one or two TL-D lamps

58 W and can be combined with a wide range of standard Maxos

reflectors and optics. If HF-R dimming ballasts are used, the units

must be mounted to 7-wire trunking sections. Please order half of

the units with a left adapter (A5L, A7L) and half with a right adapter

(A5R, A7R) to ensure full flexibility.

Product ID A

4MX056 581 1530

4MX056 582 3060

4MX056 583 4590



Trunking systems Maxos TL-D bus bar


4MX091

1530





4MX056 581 BB 5x2.5 WH

Code (EOC)

57451399

4MX056 582 BB 5x2.5 WH 57867299

4MX056 583 BB 5x2.5 WH 57303599

4MX056 581 BB 7x2.5 WH 57359299

4MX056 582 BB 7x2.5 WH 57352399

4MX056 583 BB 7x2.5 WH 57304299

4MX056 581 BB 5x2.5 SI 56398299

4MX056 582 BB 5x2.5 SI 56397599

4MX056 583 BB 5x2.5 SI 56396899

4MX056 581 BB 7x2.5 SI 56395199

4MX056 582 BB 7x2.5 SI 56394499

4MX056 583 BB 7x2.5 SI 56182799


An electrical bus bar (5 or 7 poles) is

integrated in the trunking.

4MX056 581/582/583 BB 5x2.5/7x2.5

4MX091 HFB/HFR BB A5L/A5R/A7L/A7R



4MX091 1xTL-D58W HFB A5R WH

Code (EOC)

53719899

4MX091 1xTL-D58W HFB A5L WH 54411099

4MX091 2xTL-D58W HFB A5R WH 53721199

4MX091 2xTL-D58W HFB A5L WH 54418999

4MX091 1xTL-D58W HFR A7R WH 53720499

4MX091 1xTL-D58W HFR A7L WH 54412799

4MX091 2xTL-D58W HFR A7R WH 53722899

4MX091 2xTL-D58W HFR A7L WH 54413499

4MX091 1xTL-D58W HFB A5R SI 53816499

4MX091 1xTL-D58W HFB A5L SI 54416599

4MX091 2xTL-D58W HFB A5R SI 53818899

4MX091 2xTL-D58W HFB A5L SI 54415899

4MX091 1xTL-D58W HFR A7R SI 53817199

4MX091 1xTL-D58W HFR A7L SI 54417299

4MX091 2xTL-D58W HFR A7R SI 53819599

4MX091 2xTL-D58W HFR A7L SI 54414199

Spots can be easily fixed on the bus bar,

offering even more flexibility.


Trunking systems Maxos TL-D trapeze reflectors and optics

4MX092 T + 4MX093 L-T


~4MX092-1~Maxos TL-D trapeze reflectors and optics

4MX092 TL-D trapeze reflectors

4MX093 TL-D optics

The sturdy trapeze reflectors for TL-D are designed for standard

applications in industry, supermarkets, and shops. They are made of

steel, with a white or silver coating. The reflectors are optimised for

electrical units holding one or two TL-D lamps, 36 W or 58 W and

provide an excellent light output ratio.

There are basic trapeze reflectors without a mirror inlay and

trapeze reflectors with different aluminium mirror inlays. These are

suitable for wide-beam, narrow-beam and asymmetrical

wall-washing light distributions. Moreover, perforated and slotted

trapeze reflectors, without mirror inlays, can be ordered as design

elements or to create an indirect uplighting effect.

For glare reduction, the trapeze reflector can be equipped with a

steel louvre (L-T) that has a white or silver coating. For emergency

lighting by separately connected orientation light units (E27-sockets),

special trapeze reflectors with a cut-off must be selected. The

length of this reflector corresponds to that of the 58 W trunking

length. A 36 W-electrical unit plus the orientation light unit will fill

this length.

The reflectors are fixed on the electrical units via a simple click-in.

The reflectors can also be connected to each other in a line

without additional coupling pieces, as they are delivered with an

integrated connection side at one end of the reflector. End plates

for the beginning and the end of the light-line, are available as

accessories.

Product ID A

4MX092 1x36W T 1230

4MX092 1x58W T 1530








Product ID A

4MX092 2x36W T 1230

4MX092 2x58W T 1530

Product ID A

4MX092 1x58W T-A 1530



4MX092 T + 4MX093 L-T

4MX091+

4MX092 T+

4MX093 L-T SI

1xTL-D58W

90°

60°

30°

100

200

300

γ

90°

60°

30°

* UGR R < 19 (acc. EN12464-1)



4MX092 1 58 T SI

Code (EOC)

53961199

4MX092 1 58 T WH * 53898099

4MX092 1 58 T-A SI 55906099

4MX092 1 58 T-A WH 55540699

4MX092 1 58 TI-A SI 53965999

4MX092 1 58 TI-A WH 53903199

4MX092 1 58 T-NB SI 53963599

4MX092 1 58 T-NB WH 53901799

4MX092 1 58 T-P WH 54113399

4MX092 1 58 T-S-D/I SI 53966699

4MX092 1 58 T-S-D/I WH 53904899

4MX092 1 58 T-WB SI 53962899

4MX092 1 58 T-WB WH 53899799

4MX092 2 58 T SI 53994999

4MX092 2 58 T WH 53930799

4MX092 2 58 T IP64 WH * 54091499

4MX092 2 58 T-NB SI 53996399

4MX092 2 58 T-NB WH 53932199

4MX092 2 58 T-S-D/I SI 53998799

4MX092 2 58 T-S-D/I WH 53934599

4MX092 2 58 T-WB SI 53995699

4MX092 2 58 T-WB WH 53931499

* 4MX092 1 58 T WH can be used for IP20 and for IP64

** 4MX092 2 58 T IP64 WH special for IP64

Accessories


Code (EOC)

9MX056 EP1-T SI (2PCS) 10834300

9MX056 EP1-T WH (2PCS) 10833600

9MX056 EP2-T SI (2PCS) 10838100

9MX056 EP2-T WH (2PCS) 10837400

4MX092 2x58T



4MX093 1 58 L-T WH

Code (EOC)

54130099

4MX093 1 58 L-T SI 54131799

4MX093 2 58 L-T WH 54134899

4MX093 2 58 L-T SI 54135599

9MX056 EP1-T WH/SI

9MX056 EP2-T WH/SI

End cap accessories for 1-lamp and 2-lamp

systems are available in white and silver.

4MX091+

4MX092 T

2xTL-D58W

90°

60°

30°

TRUNKING SYSTEMS AND BATTENS 8.31

100

200

300

γ

90°

60°

30°

* UGR R < 24 (acc. EN12464-1)


Trunking systems Maxos TL-D facetted reflectors and optics

4MX092 F + 4MX093 D6


8.32

TRUNKING SYSTEMS AND BATTENS

~4MX092-2~Maxos TL-D facetted reflectors and optics

4MX092 TL-D facetted reflectors

4MX093 TL-D optics

The design-orientated facetted reflectors for TL-D are ideal for

applications focussing on trade (such as supermarkets and shops)

and for offices. They are made of steel, with a white or silver

coating, and are available for electrical units holding one or two

TL-D lamps, 36 W or 58 W. The 2-lamp versions of the facetted

reflectors must be used with special electrical units (lampholder

F32 mm).

There are facetted reflectors without a mirror inlay, and facetted

reflectors with different aluminium mirror inlays. These are suitable

for wide-beam and asymmetrical-beam applications. Moreover,

slotted facetted reflectors without mirror inlay can be ordered to

create an indirect uplighting effect.

Optic: When the facetted reflector comes without a pre-mounted

mirror inlay it can be integrated with a semi-high-gloss (D6) OLC

optic of high-quality aluminium. This optic has parabolic side

reflectors and parabolic lamellae, and it can create either a medium

beam (with an integrated white top reflector) or a narrow beam

(with an integrated mirror top reflector). A prismatic screen to

cover the facetted reflector is also available. For basic glare

reduction, the facetted reflector can be equipped with a whitecoated

steel louvre.

For emergency lighting by separately connected orientation light

units (E27-sockets) a special facetted reflector with a cut-off must

be selected. The length of this reflector corresponds with that of

the 58 W length. A 36 W-electrical unit plus the orientation light

unit will fill this length.

The reflector is fixed on the electrical units via a simple click-in. The

facetted reflectors must be connected to each other with additional

coupling pieces. End plates for the beginning and the end of the

line, are available as accessories.

Product ID A

4MX092 1/2x36W F 1230

4MX092 1/2x58W F 1530

4MX092 1/2x36W F-A

1230

4MX092 1/2x58W F-A

1530





4MX092 F + 4MX093 D6

4MX092 F



4MX092 1/2 58 F WH

Code (EOC)

59962299

4MX092 1/2 58 F SI 59970799

4MX092 1/2 58 F-WB WH 59964699

4MX092 1/2 58 F-WB SI 59971499

4MX092 1/2 58 F-A WH 59953099

4MX092 1/2 58 F-A SI 59954799

4MX092 1/2 58 F-S-D/I WH 59986899

4MX092 1/2 58 F-S-D/I SI 59972199



4MX093 1/2 58 P

Code (EOC)

59974500

4MX093 1/2 58 L-F WH 59988299

4MX093 1/2 58 D6-WB 59991299

4MX093 1/2 58 D6-NB 59992999




Accessories

9MX056 EP-F WH/SI

End cap.


Code (EOC)

9MX056 EP-F SI 55285600

9MX056 EP-F WH 55284900

9MX056 CP-F SI 55443000

9MX056 CP-F WH 55441600


9MX056 CP-F WH/SI

Reflector coupling pieces.


Trunking systems Maxos TL-D aluminium reflectors

4MX092 C-NB


~4MX092-3~Maxos TL-D aluminium reflectors and optics

4MX092 TL-D aluminium reflectors

The aluminium reflectors for TL-D are optimised for applications in

industry, supermarkets and shops. They are made of high-quality

aluminium in one piece and are available for electrical units holding

one or two TL-D lamps, 36 W or 58 W. The 2-lamp versions of the

aluminium reflectors must be used with special electrical units

(lampholder F32 mm).

For wide-beam, narrow-beam, and asymmetrical-beam light

distributions a semi-high-gloss (D) aluminium reflector is available.

For very narrow beams, a high-gloss (C) aluminium reflector is

available. Moreover, a perforated decorative high-gloss aluminium

reflector in wide beam can be ordered. This perforated decorative

reflector can be equipped with a decorative louvre with ring

lamellae in silver.

The reflector is fixed onto the electrical unit via a simple click-in.

The reflectors can be connected to each other in a line without

additional coupling pieces or connection sides. There are no

endplates available for the aluminium TL-D reflectors.

Product ID A

4MX092 1x36W C-NB 1230

4MX092 1x58W C-NB 1530







Product ID A

4MX092 1x36W D-WB 1230

4MX092 1x58W D-WB 1530

Product ID A

4MX092 1x36W D-NB 1230

4MX092 1x58W D-NB 1530

Product ID A

4MX092 1x36W D-A 1230

4MX092 1x58W D-A 1530



4MX092 C-NB

4MX092 CP-WB

4MX091+

4MX092 CP-WB

1xTL-D58W

90°

60°

30°

100

200

300

400

γ

90°

60°

30°

* UGR R < 23 (acc. EN12464-1)

4MX093 RL

Ring louvre can only be used with

decorative reflector (CP-WB).



4MX092 1 58 C-NB

Code (EOC)

54156099

4MX092 1 58 CP-WB 54159199

4MX092 1 58 D-A 54157799

4MX092 1 58 D-NB 54155399

4MX092 1 58 D-WB 54154699

4MX092 2 58 D-NB F32 55556799

4MX092 2 58 D-WB F32 55552999



Trunking systems Maxos TL-D IP64 trunking

4MX056 7x1.5/7x2.5


8.38


~4MX056-2~Maxos TL-D IP64 trunking

4MX056 TL-D IP64 trunking sections

The IP 64 trunking sections are made of hot-dip galvanised steel,

and are coated white. They are available in lengths of 1, 2 and 3

electrical units 36 W and 58 W. Special sealings between the

sections and waterproof trunking end pieces are used (please order

separately).

A flat ribbon cable (5 or 7 wires) is integrated in the trunking and

guarantees (in combination with an integrated phase selection

switch and contact blocks) safe and correct cabling. The 7-wire

cable is used to integrate light regulation or emergency lighting for

those electrical units equipped with emergency battery packs.

Hence, no extra contact blocks or wiring need to be installed.

For suspended light-lines the trunking sections are connected using






The IP 64 trunking can be equipped with special IP 64 electrical

units plus different reflectors or with completely closed reflector

units that include a glass cover (IP 54).

The outstanding stability of the sections and coupling pieces allows

suspension intervals of 3.4 m to 5 m.

Product ID A

4MX056 361 1230

4MX056 362 2460

4MX056 363 3690

4MX056 581 1530

4MX056 582 3060

4MX056 583 4590


Trunking systems Maxos TL-D IP64 trunking




4MX056 581 5x2.5 IP64 WH

Code (EOC)

55150799

4MX056 582 5x2.5 IP64 WH 54367099

4MX056 583 5x2.5 IP64 WH 55151499

4MX056 581 7x2.5 IP64 WH 55133099

4MX056 582 7x2.5 IP64 WH 55134799

4MX056 583 7x2.5 IP64 WH 55135499

Accessories

9MX056 GK IP64

Gasket between trunkings.

9MX056 BC36/BC58 IP64

Blind cover IP64 white.

9MX056 LTR IP64

Gasketted ring for protection tube

(contains 2 pcs).

9MX056 EP IP64 SET

2x end cap for trunking including

1x electrical connection.

9IS125 TL-D 36W RSC-1

PC protection tube for HF gear trays

(1 PC).


Code (EOC)

9MX056 GK IP64 10830500

9MX056 EP IP64 WH 10826800

9MX056 BC36 IP64 WH 53871399

9MX056 BC58 IP64 WH 53872099

9IS125 TL-D 36W RSC-1 -

9MX056 LTR IP64 (2 PCS) 10851000



Trunking systems Maxos TL-D IP64 electrical units

4MX091 1x TL-D IP64


8.40


~4MX091-2~Maxos TL-D IP64 electrical units

4MX091 IP64 electrical units

The IP 64 electrical units are designed for quick and reliable

mounting in Maxos IP 64 trunking sections. They are made of steel,

with white coating. The high IP classification is possible thanks to

special sealings between the trunkings, and lampholders with screw

rings in the IP 64 electrical units. Maxos IP 64 is not intended for

application in regular humid environment.


trunking. The electrical units are equipped with electronic ballasts

(possibly dimming ballasts) or low-loss conventional ballasts. The

conventional ballasts are available as parallel compensated (IC) or

inductive (I). The units can hold one or two TL-D lamps, 36 W or

58 W.

Dimmable versions are delivered with HF-R electronic ballast,

allowing the light output of the TL-D lamps to be regulated from

3% to 100 %. HF-R units must be mounted to 7-wire trunking

sections.

The electrical units can be combined with special IP 64 trapeze

reflectors and some aluminium reflectors. These can create

narrow-beam, asymmetrical-beam and very-narrow-beam light

distributions for 1 x 58 W. Units which comply with the FF rules

(limited surface temperature) are available on request.

Special electrical units equipped with an emergency battery pack of


7-wire trunking sections.

Product ID A

4MX091 36W IP64 1230

4MX091 58W IP64 1530


Trunking systems Maxos TL-D IP64 electrical units


4MX091 1x TL-D IP64



4MX091 1xTL-D58W IC LW IP64 WH

Code (EOC)

53776199

4MX091 2xTL-D58W IC LW IP64 WH 53779299

4MX091 1xTL-D58W HFB IP64 WH 53729799

4MX091 2xTL-D58W HFB IP64 WH 53731099

4MX091 1xTL-D58W HFR IP64 WH 53730399

4MX091 2xTL-D58W HFR IP64 WH 53732799



Trunking systems Maxos TL-D IP54 reflector units

4MX014 L IP54


8.42

1530


212

90

~4MX014-1~Maxos TL-D IP54 reflector units

4MX014 TL-D IP54 reflector units

The reflector units IP 54 are pre-assembled units combining the

functions of regular electrical units and white reflectors with glass

covers. They are made of steel, with white coating, and are

designed for reliable mounting into Maxos IP 64 trunking sections.


trunking. Maxos is not intended for application in regular humid

environment.Wide-beam and asymmetrical-beam light distribution

are possible. IP 54 reflector units are equipped with electronic

ballasts and can hold one or two TL-D lamps 58 W. Types with an

integrated white louvre (L-WB, L-A) are available.


Trunking systems Maxos TL-D IP54 reflector units


4MX014 L IP54



4MX014 1xTL-D58W HFB L-WB IP54 WH

Code (EOC)

11357600

4MX014 1xTL-D58W HFB L-A IP54 WH 11358300

4MX014 2xTL-D58W HFB L-WB IP54 WH 11359000

4MX014 2xTL-D58W HFB L-A IP54 WH 11360600

4MX014 1xTL-D58W HFB WB IP54 WH 11462700

4MX014 1xTL-D58W HFB A IP54 WH 11463400

4MX014 2xTL-D58W HFB WB IP54 WH 11464100

4MX014 2xTL-D58W HFB A IP54 WH 11465800



Trunking systems Maxos TL-D decorative solutions

4MX092




4MX092 1 36 WG WH

Code (EOC)

11469600

4MX092 1 58 WG WH 11470200

4MX092 2 36 WG F32 WH 17628100

4MX092 2 58 WG F32 WH 17627400

9MX056 EP-WG 02762000


~4MX092-4~Maxos TL-D decorative solutions

4MX092 ... WG Wing optic

The Wing optic is a decorative reflector solution creating soft

indirect light without glare, and is ideal for office applications. It is

made of steel, and is coated white. A perforated sheet hides the

lamps. The reflectors are available for electrical units holding one or

two TL-D lamps, 36 W or 58 W. The 2-lamp version of the Wing

reflector must be used with special electrical units (lampholder

F32 mm) for TL-D lamps. It is possible to fix these reflectors on

electrical units for TL5 lamps as well.

The Wing reflector is fixed to the electrical unit via a simple click-in.

The reflectors can be connected to each other without additional

coupling pieces, as they are delivered with an integrated connection

side at one end of the reflector. Decorative end plates

(9MX056 EP-WG) for the beginning and the end of the light-line,

are available as accessories.

Product ID A

4MX092 36 WG 1230

4MX092 58 WG 1530


Trunking systems Maxos TL-D decorative solutions

4MX093 LD


4MX091+

4MX093 LD Lunar

1xTL-D58W

120°

90°

60°

100

50

50

100

150

γ

120°

90°

60°

* UGR R < 25 (acc. EN12464-1)



4MX093 1 58 LD BL

Code (EOC)

54403500

4MX093 1 58 LD CL 54406600

4MX093 1 58 LD GN 54400400

4MX093 1 58 LD-E BL 54405900

4MX093 1 58 LD-E CL 54408000

4MX093 1 58 LD-E GN 54402800

4MX093 1 58 LD-M BL 54404200

4MX093 1 58 LD-M CL 54407300

4MX093 1 58 LD-M GN 54401100

4MX013 361 IC F + 9MX056 EP-F/TLD



4MX013 361 1xSDW-T100W IC F

Code (EOC)

11996700

4MX013 361 1xSDW-T50W IC F 11997400

4MX013 361 1xCDM-T70W IC F 11998100

4MX013 361 1xSDW-T100W 1xCDM-T70W IC F 11999800

4MX013 361 1xSDW-T50W 1xCDM-T35W IC F 12000000

4MX093 … LD Lunar, decorative louvre solution

Lunar consists of a curved opal foil with pre-mounted transparent

cross louvres made of polycarbonate. It is a design-orientated solution

that creates a friendly atmosphere, and works with electrical units

holding one TL-D lamp 58 W. The transparent cross lamellae are

available in green, blue and colourless. The Lunar is fixed to the

electrical unit via plastic brackets, which are connected to the trunking.

There are three versions of louvers available: one for single mounting,

one for mounting at the end or at the beginning of a track and one

version for mounting in the middle of a track.

Product ID A

4MX092 36 WG 1230

4MX092 58 WG 1530

4MX013 … HID-lamp units

These units are ideal for shop applications and are often used to

illuminate fruit and vegetables in supermarkets. HID-lamp units are

available for 1xSDW-T 50 W or 100 W and for 1xCDM-T 70 W.

In addition, units for 1xSDW-T100 W plus 1xCDM-T 50 W and for

1xSDW-T 50 W plus 1xCDM-T 35 W are available. The electrical

components are integrated in a white-coated housing with the shape

of a facetted reflector. The length of these units corresponds to those

of the 36 W trunking length. End plates for the beginning and the end

of the light-line, are available as accessories.



Trunking systems Maxos mounting accessories


9MX056 MB

Mounting bracket for direct ceiling fixation,

white and silver.

9MX056 CBA

Chain bracket, adjustable, white, silver and

galvanised.

9MX056 CB

Chain bracket, fixed, white, silver and

galvanised.

9MX056 PB

Profile bracket for exposed T-profiles white

and silver.

~9MX056-2~Maxos mounting accessories

9MX056 MB-ST-L1250

Mounting bracket including suspension tube

1 250 mm, white and silver.

9MX056 MB-SW

Mounting bracket for suspension wire,

white and silver.

9MX056 MB-SW-L1250/

MB-SW-L3000

Mounting bracket including suspension wire

1 250 mm/3 000 mm, white and silver.

9MX056 SW2

Suspension wire diameter 2 mm / per

metre.


Trunking systems Maxos mounting accessories

9MX056 CC-SW-L1250-WH/SI

Ceiling cover and suspension wire

1 250 mm, white and silver.


Code (EOC)

9MX056 CB SI 55676299

9MX056 CB WH 55678699

9MX056 CB ZC 55707399

9MX056 CBA SI 10788900

9MX056 CBA WH 10779700

9MX056 MB SI 57196399

9MX056 MB WH 57191899

9MX056 MB-SW SI 57199499

9MX056 MB-SW WH 53866999

9MX056 PB SI 57200799

9MX056 PB WH 57194999

9MX056 SW2 55108899

9MX056 CF-SW-L1250 ZC

Ceiling fixation with steel wire 1 250 mm,

zinc.



Trunking systems Maxos accessories


9MX056 SD

The swivel device enables variable angles

between the lines, and it is suitable for

Maxos TL-D and TL5. The minimum angle

is 45°. Due to its modern design it is often

used in application areas such as shops,

schools and museums. Up to four trunking

sections can be connected with one swivel

device. The housing is made of plastic, with

a white or silver coating, and with inner

supporting elements made of steel.

9MX056 CP-SD

Flexible coupling joint. Coupling piece to

connect flexible coupling joint to the

trunking.

9MX056 EC7

Electrical supply connector 7-pole

(10 pieces).

9MX056 CP

Coupling piece for trunking white and

silver.

9MX056 BC

Blind cover, used to close the spaces in the

trunking where no electrical units are

mounted, available in white and silver.

If needed the swivel device can

accommodate light sensors, cameras,

spotlight adapters, loud speakers, etc., by

dividing it into two chambers. It is premounted

with an infinitely adjustable quick

hanger with a 1.25 m steel suspension wire.

One coupling piece per trunking section is

necessary to connect the trunking to the

swivel device.

~9MX056~Maxos Swivel device

9MX056 EP SET

End-piece set for trunking with mains

supply white and silver.

9MX056 CPI

Internal coupling piece for surface-mounted

trunkings.



9MX056 SD SI

Code (EOC)

54500100

9MX056 SD WH 54497400

9MX056 CP-SD SI 54499800

9MX056 CP-SD WH 54498100

9MX056 EP SI SET 10825100

9MX056 EP WH SET 10824400

9MX056 EC7 13179200

9MX056 CP SI 10808400

9MX056 CP WH 10807700

9MX056 CPI 10809100

9MX056 BC58 SI 53888199

9MX056 BC58 WH 53881299

9MX056 BC49 WH 60157899

9MX056 BC49 SI 60158599




TTX400 – Clicks in seconds, flexible fit

Fast and flexible

TTX400 is the world’s fastest-to-install flexible trunking system

thanks to the 5-click installation principle and the complete range of

interchangeable components that can accommodate most complex

lighting layouts.

Miniaturisation

The new range of TL5 reflectors has been optimised around the

small TL5 lamp.The result: a truly compact design, ensuring that the

TTX400 is easy to integrate into your application.

OLC Optics

While Philips originally developed OLC (Omnidirectional Luminance

Control) optics for recessed and surface-mounted luminaires, we

now use the same optics for TTX400. OLC optics offer superb glare

control and efficiency, making it possible to use the TTX400 in

applications such as libraries and universities.

9 wires

As well as the standard 5 and 7 pre-wired trunkings,TTX400 now

offers 9 wires as a clicks-only solution.This makes it easy to combine

emergency lighting with control functions.


Suspension brackets

Trunkings

Electrical units

Reflectors

Inlay reflectors

Louvres and optics


TTX400 5-wire

TTX400 TL5

TTX400 7-wire TTX400 9-wire

5-wire 2.5 mm 2 7-wire mm 2 9-wire mm 2

TMX400 149

1-lamp TL5

1-lamp TL5 EL

TMX400 249 TMX40. 149

2-lamp TL5

2-lamp TL5 EL

- projectors

- halogen spots

GMX5.. white GMX5.. aluminium

GGX555

GGX555

- wide beam

- medium beam

- bidirectional

- asymmetrical

- white louvre

- flat profiled

aluminium

- high-gloss

parabolic lamella

- matt parabolic lamella

- prismatic panel

- wide beam

- medium beam

- ultra narrow beam

- asymmetric beam

- wall washer

ZTX 400

TTX400 5-wire TTX400 7-wire TTX400 9-wire

5-wire 2.5 mm 2 7-wire 2.5 mm 2 9-wire 2.5 mm 2

TMX400 158 TMX400 258

1-lamp TL-D


2-lamp TL-D


TMX40. 58

- projectors

- halogen spots

GMX4.. white GMX4.. aluminium

GGX45.

GGX450

- standard

- slotted

- perforated

- narrow beam

- asymmetric

- wide beam

- bidirectional

- white louvre

- flat profiled aluminium

- matt parabolic lamella

- perforated louvre

- mesh louvre

- high-gloss parabolic lamella

- semi-high-gloss parabolic lamella

- prismatic panel

TTX400 TL-D

- wide beam

- narrow beam


- ultra narrow beam

- asymmetric beam

- wall washer



Trunking systems TTX400 TL5 trunkings

TTX400 7


8.52


~TTX400T5~TTX400 TL5 Trunking sections

TTX400 TL5 trunking sections

This trunking system for both continuous trunking and individual

mounting consists of prewired (TTX400) sections.

The sections can be easily clicked together using the integrated

electrical/mechanical coupling pieces.The trunking is available with a

complete range of interchangeable components to offer outstanding

flexibility.

All the trunking sections are made of white prelaquered steel.

Round edges reduce the risk of injury. Flat ribbon cable (7 or 9 wires),

integrated phase selection switch, and contact blocks with click

connection, make electrical connection and connection to the mains

quick, simple and safe (if 3 phases are used equalised the maximum

current is 16 A).The great stability of the sections and coupling

pieces, limit the number of mounting brackets needed

(max. 3 metres when using 493 trunking sections).

The electrical unit is clicked simply into the trunking for both

mechanical and electrical connection.

The prewired section TTX400 is equipped standard with a 7- or

9-wire 2.5 mm 2 ribbon cable.The 7-wire flat ribbon cable is used

especially for the integration of the light regulation or emergency

lighting functions. Hence, no extra contact blocks or wiring needs to

be installed.

Both versions are available in length of 1, 2 and 3 electrical units

49 W and 54 W.

Product ID A

TTX400 491 1474

TTX400 492 2949

TTX400 493 4424

TTX400 541 1174

TTX400 542 2348

TTX400 543 3524


Trunking systems TTX400 TL5 trunkings


TTX400 7

TTX400 9

7 wires

9wires

0-10V

NN N L3 L2 L1 LL



TTX400 491 7

Code (EOC)

29027099

TTX400 491 9 68500799

TTX400 492 7 29029499

TTX400 493 7 29031799

TTX400 541 7 30502899

TTX400 542 7 30504299

TTX400 543 7

For associated accessories, see from page 8.83 onwards.

30506699

7 wires

Solution for dimming or DALI or

emergency lighting.

9wires

Solution for a combination of emergency

lighting, dimming or DALI.



Trunking systems TTX400 TL5 electrical units

TMX400 2x TL5


8.54


~TMX400T5~TTX400 TL5 Electrical units

TMX400 TL5 electrical units

These electrical units are designed for quick click mounting in

TTX400/410 trunking sections. They are for use with one or two

TL5 lamps, with electronic (dimming) ballast, in emergency lighting

version and in versions for the mounting of projectors. They

contain all the necessary electrical and mechanical functions.

All components are screwed onto the electrical unit.

The units can be combined with any type of reflector, and are made

of white sheet steel.

Electronic ballasts

TMX400 is delivered with electronic ballast HFP. The dimmable

version of the TMX400 is delivered with the electronic ballast HFR,

allowing the light output of the TL5 lamps to be regulated from 3 %

to 100 %. This unit is ideal for (day)light-dependent control, and

must be mounted to the prewired TTX400 section with 7-wire

ribbon cable.

For more control options the TMX400 can be equiped with DALI

ballasts. Especially in combination with the Linesense controls DALI

solutions offer even more control and energy savings.


TMX400 is deliverable in versions with built in 3-hour emergency

lighting equipment. The 49 W versions are mounted in the same

way as all the other TMX400 electrical units and must be used with

the prewired TTX400 trunking section with 7-wire ribbon cable.

54 W and 80 W versions with emergency lighting are available.

Technical description

• Gear/power supply: HF: 220 V - 240 V

• Lamps: 1 and 2x TL5 fluorescent.

Installation

Simple click-in method.

Product ID A

TMX400 28W/54W 1174

TMX400 35W/49W/80W 1474


Trunking systems TTX400 TL5 electrical units


TMX400 2x TL5

2-lamps TL5 electrical unit.



TMX400 1xTL5-35W HFP

Code (EOC)

30512799

TMX400 1xTL5-35W HFP EL3 30508099

TMX400 1xTL5-35W HFR 30498499

TMX400 1xTL5-49W HFD 30331499

TMX400 1xTL5-49W HFP 29109399

TMX400 1xTL5-49W HFP EL3 29117899

TMX400 1xTL5-49W HFR 29113099

TMX400 1xTL5-54W HFP 30472499

TMX400 1xTL5-54W HFR 30480999

TMX400 1xTL5-80W HFP 10545199

TMX400 1xTL5-80W HFR 30564699

TMX400 2xTL5-35W HFP EL3 30510399

TMX400 2xTL5-35W HFR 30500499

TMX400 2xTL5-49W HFD 30333899

TMX400 2xTL5-49W HFP 29111699

TMX400 2xTL5-49W HFP EL3 29119299

TMX400 2xTL5-49W HFR 29115499

TMX400 2xTL5-54W HFP 30474899

TMX400 2xTL5-54W HFR 30482399

TMX400 1x TL5

Accessory

1-lamp TL5 electrical unit.

ZTX400 BC

Blind covers are used to close the trunking

in cases where no electrical unit is

mounted.


Code (EOC)

ZTX400 BC49 29010299

ZTX400 BC54 30573899

ZTX400 BC58 09463299



Trunking systems TTX400 electrical units

8.56


The basic unit is mounted on the trunking

section with a simple click movement.

Electrical/mechanical connection of basic units

with a 5-wire ribbon cable.

Electrical/mechanical connection of the EL3

basic unit in a prewired trunking section with

a 7-wire ribbon cable.

Connectors to connect 0-10 V line of the HFR

gear to the through-wiring in the trunking in

case of 9 wires.

To de-mount the electrical unit, the two

mechanical fixation points are turned in the

direction indicated.


Trunking systems TTX400 TL5 multi-purpose reflectors


~GMX550~TTX400 TL5 Multi-purpose reflectors

GMX555 TL5 multi-purpose reflectors

Multifunctional one-piece reflector designed for applications where

there is a need for high technical lighting quality and design. These

reflectors can be extended by various optics, mirrors and

attachments.The installation is done via a simple click-in on the

electrical units.

Product ID A B C D

GMX555 49 WB 1470 147 60 109

GMX555 54 WB 1170 147 60 109

GMX555 49 MB 1470 147 76 125

GMX555 54 MB 1170 147 76 125



Trunking systems TTX400 TL5 multi-purpose reflectors



Product ID Light Output European Order

Ration (LOR) Code (EOC)

GMX555 49 MB 0.85 68455099

GMX555 49 RP-MB - 68547299

GMX555 49 WB 0.90 68451299

GMX555 54 MB 0.85 68457499

GMX555 54 RP-MB - 68549699

GMX555 54 WB 0.90 68453699

For associated accessories (coupling pieces and end plates), see page 8.88.

8.58


GMX555 MB

White reflector with delta shape light

distribution. All optics can be added to the

GMX555 WB.

The TL5 white reflectors, GMX555, are

suitable for 1 lamp and 2 lamps. Result: lines

with both 1 and 2 lamps form a visually

straight light-line.

GMX555 WB

Very small wide beam white reflector for

general lighting. L or M2 louvre can be

added.



GGX555 C6

TTX400 TL5 louvres and optics

~GGX550~TTX400 TL5 Louvres and optics

GGX555 TL5 louvres and optics

A wide range of different attachments and optics can be mounted

in the multifunctional reflector GMX555.These attachments offer

many possibilities to shield the lamps, and therefore improve

comfort. Each attachment and optic is available in 1-lamp and

2-lamp versions.

Changing the lamp remains simple and quick as the attachments are

hinged to the GMX555.

The attachments, optics and mirror inserts can only be used in

combination with the functional reflector GMX555/GMX555 RS/

GMX555 RP.

Mirror inserts and attachments/optics will not change the outer

dimensions of the installed TTX400 system.

Optics C6 or D6 are available on request, to be used in single

reflector-solutions.

The inlay reflectors GGX555, for TL5

solutions are delivered as a set with the

white reflectors, already mounted.









GMX555 49 MB C-A20 SET 0.95 68466600

GMX555 49 MB C-A40 SET 0.95 68465900

GMX555 49 MB C-BD20 SET 0.95 68463500

GMX555 49 MB C-BD40 SET 0.95 68464200

GMX555 54 MB C-A20 SET 0.95 68469700

GMX555 54 MB C-A40 SET 0.95 68470300

GMX555 54 MB C-BD20 SET 0.95 68467300

GMX555 54 MB C-BD40 SET 0.95 68468000

GGX555 49 C6T 68524300

GGX555 49 C6 68482600

8.60


OLC high-gloss high quality aluminium optic with 3D lamellae and with top reflector

GGX555 C6

High gloss OLC optics for GMX555 MB

top reflectors are available to increase

LOR.

GGX555 L

White lamella louvre. Suitable for MB and

WB reflectors.

TTX400 TL5 louvres and optics

GMX555

Aluminum inlay reflectors improve the LOR

and the distribution.


Code (EOC)

GGX555 49 C-BD/A 68461199

GGX555 49 M6 68481900

GGX555 49 M2 68473499

GGX555 49 L 68471099

GGX555 54 C6-T 68525000

GGX555 54 C6 68480200

GGX555 54 C-BD/A 68459899

GGX555 54 M6 68479600

GGX555 54 M2 68477299

GGX555 54 L 68475899


Trunking systems TTX400 TL5 aluminium reflectors

GGX566 HB-WB

~GMX565~TTX400 TL5 Aluminium reflectors

TTX400 TL5 aluminium reflectors

Compared to the TL-D aluminium reflectors, the TL5 ones are

smaller due to the smaller lamps. This results in easier handling and

less space needed.

Aluminium one-piece reflectors in hammered, matt and glossy

versions. Specially designed for applications where a wide beam,

narrow beam, very narrow beam or ultra narrow beam is

demanded, e.g. distribution centres and warehouses. Installation via a

simple click-in action to the electrical units TMX400.

The high efficiencies of these reflectors ensure a highly cost

effective solution. Mechanical clips are delivered with the reflectors

in order to align them in case of continuous lines.

All aluminium reflectors are available for 49 W or 54 W lengths.





8.62



207

207

102

102

59

59

79

79

TMX400+

GMX565 M-NB

1xTL5-49W

90°

60°

30°

150

300

450

600

750

90°

60°

30°

* UGR R < 21 (acc. EN12464-1)

γ

GMX565 M-NB

One-piece narrow-beam reflector made

from matt aluminium for 1- or 2-lamp

49 W or 54 W. Also available in high-gloss

hammer-bow aluminium (GMX565

HB-NB).

GMX565 HB-NB

One-piece narrow-beam reflector made

from high-gloss hammer-bow aluminium for

1- or 2-lamp 49 W or 54 W. Also available

in matt aluminium (GMX565 M-NB).

GMX566 M-WB

Ultra small one-piece wide beam reflector

made of matt aluminium. Suitable for

2-lamp TL5 49 W or 54 W electrical units.

The reflector is also available in high-gloss

hamerbow aluminium (GMX566 HB-NB).

GMX566 HB-WB

Ultra small one-piece wide beam reflector

made of high-gloss hammerbow aluminium.

Suitable for 2-lamp TL5 49 W or 54 W

electrical units. The reflector is also

available in matt aluminium

(GMX566 M-WB).





Accessory Light Output

European Order

Ration (LOR)

Code (EOC)

GMX565 1 49 HB-NB 0.93

30546299

GMX565 1 54 HB-NB 0.93

30548699

GMX565 1 54 M-NB 0.88

30552399

GMX566 2 49 HB-WB 0.87

10966499

GMX566 2 54 HB-WB 0.87

30554799

GMX566 2 49 M-WB 0.84

10954199

306

258

221

221

107

89

93

93

GMX566 HB-A

One-piece reflector made from matt

aluminium. Suitable for 1- or

2-lamp 58 W TMX400 electrical unit.

GMX567 M-A

One-piece asymmetrical reflector made of

matt aluminium. Suitable for 1- and 2-lamps

49 W or 54 W electrical units.

GMX570 C-NB

One-piece ultra narrow beam reflector

made from high-gloss aluminium. Suitable

for 1-lamp TMX400 electrical unit (same

reflector can be used for 2-lamp electrical

unit). Also available in hammer-bow

aluminium.

GMX570 HB-NB

Very small one-piece narrow beam

reflector made of hammer-bow aluminium.

Suitable for 1- or 2-lamps 49 W or 54 W

electrical units. The reflector is also

available in high-gloss aluminium (GMX570

C-NB).



Ration (LOR)

Code (EOC)

GMX567 49 M-A 0.95

30558599

GMX567 54 M-A 0.95

30556199

GMX570 49 C-NB 1.00

29004199

GMX570 54 C-NB 1.00

30562299

GMX570 49 HB-NB 1.00

30224999

GMX570 54 HB-NB 1.00

30560899



Trunking systems TTX400 TL-D trunkings

TTX400 7



~TTX400~TTX400 TL-D Trunking sections

TTX400/410 TL-D trunking sections

This trunking system for both continuous trunking and individual

mounting includes prewired (TTX400) and unwired (TTX410)

sections. The sections can be easily clicked together using the

integrated electrical/mechanical coupling pieces. The trunking is

available with a complete range of interchangeable components to

offer outstanding flexibility.

All the trunking sections are made of white prelaquered steel.

Round edges reduce the risk of injury. Flat ribbon cable (5 or 7

wires), integrated phase selection switch, and contact blocks with

click connection, make electrical connection and connection to the

mains quick, simple and safe (if 3 phases are used equalised the

maximum current is 16 A). The great stability of the sections and

coupling pieces, limit the number of mounting brackets needed

(max 3 metres when using 58 3 trunking sections).

The electrical unit is clicked simply into the trunking for both

mechanical and electrical connection.

TTX400

The prewired section TTX400 is equipped standard with a 5-, 7- or

9-wire 2.5 mm 2 ribbon cable.

The 7-wire flat ribbon cable is used especially for the integration of

the light regulation or emergency lighting functions. Hence, no extra

contact blocks or wiring needs to be installed.

Both versions are available in length of 1, 2 and 3 electrical units

36 W and 58 W.

TTX410

TTX410 is the unwired trunking section that allows the mounting of

the electrical units at any desired position. On the upper part of the

trunking section special knockout openings enable cable entry. The

mains connection can be achieved with the 7-pole connector

ZTX410 TC. Electrical connection to the electrical unit can be made

with a 5-pole contact block with insert contacts (ZTX400 DC).

These connection blocks can be installed at any place inside the

trunking sections. The required wiring can be fixed inside the

trunking section by using internal cable clips (ZTX410 IC). When

electrical units are used with conventional or low-loss ballasts,

H07GU (110 ºC) cables should be used. When electronic ballasts

are used, H07VU (70 ºC) are sufficient.

The TTX410 unwired trunking sections are delivered with the

mechanical coupling piece.

This unwired system is also well suited for mounting waterproof or

surface mounted luminaires.

Product ID A

TTX400 362 2457

TTX400 363 3686

TTX400 581 1528

TTX400 582 3057

TTX400 583 4586





TTX400 TTX410



TTX400 362 5

Code (EOC)

09341399

TTX400 362 7 09635399

TTX400 363 5 09343799

TTX400 363 7 09637799

TTX400 581 5 09345199

TTX400 581 7 09668199

TTX400 581 9

For associated accessories, see from page 8.83 onwards.

68494999

Product ID A

TTX410 582 3057

TTX410 583 4586


Code (EOC)

TTX400 582 5 09347599

TTX400 582 7 09198399

TTX400 583 5 09349999

TTX400 583 7 09196999

TTX410 582 09351299

TTX410 583 09353699




TTX400 5

TTX400 7

TTX400 9

5 wires

7 wires

9wires


0-10V

NN N L3 L2 L1 LL

Both the electrical and mechanical

connections are secured in one movement, by

clicking the trunking sections together.

5wires

7 wires

Solution for dimming or DALI or

emergency lighting.

9wires

Solution for a combination of emergency

lighting, dimming or DALI.

Extra cables can be taken along inside the

prewired trunking sections by simply clicking

them into the cable clips already installed in

the prewired trunking section.


Trunking systems TTX400 TL-D electrical units

TMX400 2x TL-D


with accessory

~TMX400~TTX400 TL-D Electrical units

TMX400 TL-D electrical units

These electrical units are designed for quick click mounting in

TTX400/410 trunking sections. They are for use with one or two

TL-D lamps, with conventional or electronic (dimming) ballast, in

emergency lighting version and in versions for the mounting of

projectors. They contain all the necessary electrical and mechanical

functions.

All components are screwed onto the electrical unit.

The units can be combined with any type of reflector, and are made

of white sheet steel.

Electronic ballasts

TMX400 are delivered standard with electronic ballast HFP, or the

more simple HFB ballast for applications where there is a limited

number of on/off switching.

The dimmable version of the TMX400 is delivered with the

electronic ballast HFR, allowing the light output of the TL-D lamps

to be regulated from 3 % to 100 %. This unit is ideal for (day)lightdependent

control, and must be mounted to the prewired TTX400

section with 7-wire ribbon cable.

The TMX400 units with conventional ballasts, are supplied with an

electrical connector, starters, any necessary capacitor, and

lampholders.


TMX400 are also deliverable in versions with in-built 1- and 3-hour

emergency lighting equipment. These units are mounted in the

same way as all the other TMX400 electrical units and must be used

with the prewired TTX400 trunking section with 7-wire ribbon

cable.


• Gear/power supply:

HF: 220 V - 240 V

Conventional: 230 V or 240 V

• Lamps: 1x and 2x TL-D

Installation

Simple click-in method.

Product ID A

TMX400 36W 1228

TMX400 58W 1528



Trunking systems TTX400 TL-D electrical units


* Master/slave solution.


TTX400 F32


2-lamps TL-D electrical unit

Standard distance between the lampholders

is 114 mm.

2-lamps TL-D electrical unit F32

Distance between the lamp holders is

32 mm. This makes it possible to use it in

1-lamp-reflectors (available in IC, HFB, HFP,

HFR and EL3 versions, e.g. TMX400

2xTL-D58W HFP F32).


Code (EOC)

TMX400 1xTL-D58W HFB 09277599

TMX400 1xTL-D58W HFD 30335299

TMX400 1xTL-D58W HFP 09269099

TMX400 1xTL-D58W HFP EL1 29080599


TMX400 1xTL-D58W HFR 09285099

TMX400 1xTL-D58W IC 09253999

TMX400 2xTL-D58W HFB 09281299

TMX400 2xTL-D58W HFD 30337699

TMX400 2xTL-D58W HFP 09273799



TMX400 2xTL-D58W HFP M/S 09862300

TMX400 2xTL-D58W HFR 09194599


*



Accessory

1-lamp TL-D electrical unit


TTX400 solutions without dimming can be

equipped with emergency lighting

equipment (EL) using standard TTX400

trunking with 7 wires. The poles NN and

LL are used to connect the EL (1 or

3 hours solutions can be chosen).

ZTX400 BC

Blind covers are used to close the trunking

in cases where no electrical unit is

mounted.


Code (EOC)

ZTX400 BC49 29010299

ZTX400 BC54 30573899

ZTX400 BC58 09463299


Trunking systems TTX400 TL-D basic reflector

GMX430


~GMX430~TTX400 TL-D Basic reflector

GMX430 TL-D basic reflector

Basic one-piece white reflector designed for all applications where

optics, mirrors and attachments are not needed. An efficient and

economic solution. Installation is done via a simple click-in on the


Product ID A

GMX430 36 1224

GMX430 58 1524



Trunking systems TTX400 TL-D basic reflector


Accessories



Code (EOC)

ZTX400 CP-430 09419999

ZTX400 EP-430

09413799


ZTX400 CP-430

White plastic coupling piece for white basic

reflector GMX430. Two coupling pieces

needed per junction.

GMX430

Suitable for 1- or 2-lamp TMX400 electrical

unit 36 W or 58 W. End plates and

coupling pieces deliverable as accessories

(ZTX400 EP-430/CP-430). White in

colour, the reflector is made of

prelacquered steel. (GMX430 EL reflector

58 W with slot for mounting on 1- and

2-lamp 36 W in combination with

accessory ZTX400 NE-E27).

Product ID Light Output


Ratio (LOR)

Code (EOC)

GMX430 36 0.76

09317899

GMX430 58 0.75

09319299

GMX430 EL -

09321599

The reflectors are clicked onto the basic units.

ZTX400 EP-430

White plastic end plate for white basic

reflector GMX430.


Trunking systems TTX400 TL-D multi-purpose reflectors

GMX450


1 lamps 2 lamps

~GMX450~TTX400 TL-D Multi-purpose reflector

GMX450 TL-D multi-purpose reflector

Multifunctional one-piece reflector designed for applications where

there is a need for high technical lighting quality and design. These

reflectors can be extended by various optics, mirrors and

attachments.The installation is done via a simple click-in on the






136

236

158

258


Accessory Light Output European Order


GMX450 1 36 0.72 09293599

GMX450 2 36 0.72 09297399

GMX450 1 58 0.72 09295999

GMX450 2 58 0.72 09299799

GMX450 1 36 RS - 09301799

GMX450 2 36 RS - 09305599


GMX450

Suitable for 1- or 2-lamp TMX400 electrical

unit 36 W or 58 W. End plates and

coupling pieces deliverable as accessories

(ZTX400 EP-450/CP-450). White in

colour, the reflector is made of

prelacquered steel.

GMX450

Features slots providing 5 % uplight. The air

flow through the slots (chimney effect)

keeps the reflector and lamps clean for a

longer period which means a reduction in

maintenance costs. End plates and coupling

pieces deliverable as accessories (ZTX400

EP-450/CP-450).

GMX450

Perforated reflector providing 5 % uplight.

It is designed for applications where the

decorative aspect of the lighting plays a

role. This reflector is especially suitable for

applications like mass retail and public areas,

where there is more need for design. In

case of continuous light-lines the

transparent coupling pieces should be used

(GMX450 CPT).

Accessory Light Output European Order


GMX450 1 58 RS - 09303199

GMX450 2 58 RS - 09307999

GMX450 1 36 RP - 09309399

GMX450 2 36 RP - 09313099

GMX450 1 58 RP - 09311699

GMX450 2 58 RP - 09315499



ZTX400 CPI-450

ZTX400 CP2-450

Plastic coupling piece for white reflectors

GMX450.

ZTX400 CPI-TR-450

ZTX400 CP2-TR-450

Transparant plastic coupling piece for

perforated reflector GMX450.


Code (EOC)

ZTX400 CP1-450 09415199

ZTX400 CP2-450 09417599

ZTX400 EP1-450 09411399

ZTX400 EP2-450 09202799

ZTX400 CP1-TR-450 09569199

ZTX400 CP2-TR-450 09571499

To install the white reflectors in a continuous

line, two coupling pieces (CP) are required per

connection. An end piece (EP) can be

mounted at both the start and end of the

light-line.

ZTX400 EPI-450

ZTX400 EP2-450

White plastic end plate for closing off the

trunking section at the end of each line.



Trunking systems TTX400 TL-D mirror inserts

GGX451 NB

8.74


~GGX451~TTX400 TL-D Mirror inserts

GGX451/452/453/454 TL-D mirror inserts

Mirror inserts improve the distribution of light.They are especially

suitable for applications where directed beams are needed. Installing

mirror inserts is as easy as all other components, just click into the

multifunctional reflector (GMX450).

TTX400 offers various types of mirror inserts (narrow, wide and

asymmetrical).


Trunking systems TTX400 TL-D mirror inserts


450

1 36

1 58

A (asymmetric)*

GGX451 M-NB

One-piece narrow beam mirror insert

made of matt aluminium. Suitable for

1-lamp reflectors 36 W/58 W.

GGX452 M-WB

Two-piece wide beam mirror inserts made

of matt aluminium. Suitable for 1-lamp

reflectors 36 W/58 W.

GGX453 M-WB

Two-piece wide beam mirror inserts made

of matt aluminium. Suitable for 2-lamp

reflectors 36 W/58 W.

GGX450 58 A

One piece asymmetric beam mirror inser

made of aluminium suitable 1-lamp or

2-lamp white reflector.



Code (EOC)

GGX450 1 58 A 10164499

GGX451 1 36 M-NB 09361199

GGX451 1 58 M-NB 09363599

GGX452 1 36 M-WB 09365999

GGX452 1 58 M-WB 09367399

GGX453 2 36 M-WB 09407699

GGX453 2 58 M-WB 09409099

GGX454 2 58 C-BD 30200399



Trunking systems TTX400 TL-D louvres and optics

GGX450 C6

8.76


~GGX450~TTX400 TL-D Louvres and optics

GGX450 TL-D louvres and optics

A wide range of different attachments and optics can be mounted

in the multifunctional reflector GMX450.These attachments offer

many possibilities to shield the lamps, and therefore improve

comfort. Each attachment and optic is available in 1-lamp and

2-lamp versions.

Changing the lamp remains simple and quick as the attachments are

hinged to the GMX450.

The attachments, optics and mirror inserts can only be used in

combination with the functional reflector GMX450/GMX450 RS/

GMX450 RP.

Mirror inserts and attachments/optics will not change the outer

dimensions of the installed TTX400 system.




GGX450 C6

High gloss, improved efficiency mirror of

high quality aluminium with parabolic side

reflectors and parabolic lamellae with

Fresnel top-side. Meeting BAP 60 and

CAT 2 glare requirements.

(DIN 5035/7 60°- 200cd/m 2 , EN 12464).

GGX450 D6

Semi-high gloss, improved efficiency mirror

of high quality aluminium with parabolic

side reflectors and parabolic lamellae with

Fresnel top-side. Meeting BAP 60 and

CAT 2 glare requirements.

(DIN 5035/7 60°- 200cd/m 2 , EN 12464).

GGX450 M5

Parabolic cross lamellae louvre in matt,

standard-quality aluminium for good lamp

shielding and high comfort.

GGX450 M2

Profiled cross lamellae louvre of standard

quality aluminium with good lamp shielding.





Accessory Optics European Order

Code (EOC)

GGX450 1 58 C6 C6 06538000

GGX450 2 58 C6 C6 06540300

GGX450 1 58 D6 D6 06534200

GGX450 2 58 D6 D6 06536600

GGX450 1 58 M5 M5 09387199

GGX450 2 58 M5 M5 09405299

GGX450 1 58 M2 M2 09383399

GGX450 2 58 M2 M2 09401499

8.78


GGX450 ML

White metal mesh louvre with good lamp

shielding in both longitudinal and lateral

directions.

GGX450 LP

White perforated lamellae louvre. Especially

attractive in combination with the

perforated reflector GMX450 RP.

GGX450 L

White lamellae louvre with good lamp

shielding in longitudinal direction.

GGX450 P

Prismatic screen for lighting with high

output and low luminance. Outer surface is

flat which makes cleaning fast and easy.

Accessory Optics European Order

Code (EOC)

GGX450 1 58 ML ML 09371099

GGX450 2 58 ML ML 09391899

GGX450 1 58 LP LP 09375899

GGX450 2 58 LP LP 09395699

GGX450 1 58 L L 09379699

GGX450 2 58 L L 09204799

GGX450 1 58 P P 10156999

GGX450 2 58 P P 10160699


Trunking systems TTX400 TL-D aluminium reflectors

GMX465 HB-NB


~GMX460~TTX400 TL-D Aluminium reflectors

GMX460-470 TL-D aluminium reflectors

Aluminium one-piece reflectors in hammered, matt and glossy

versions. Specially designed for applications where a wide beam,

narrow beam, very narrow beam or ultra narrow beam is

demanded, e.g. distribution centres and warehouses. Installation via a

simple click-in action to the electrical units TMX400.

The high efficiencies of these reflectors ensure a highly cost

effective solution. Mechanical clips are delivered with the reflectors

in order to align them in case of continuous lines.

Product ID A

GMX460-470 36 1228

GMX460-470 58 1528





8.80



GMX460 C-NB

One-piece very narrow beam reflector


for 1-lamp 58 W TMX400 electrical unit.

GMX465 HB-NB

One-piece narrow beam reflector made

from high gloss hammer-bow

aluminium.Ensures glare prevention.

Available in a version for 1-lamp 58 W and

2-lamp 58 W.

GMX465 M-NB

One-piece narrow beam reflector made

from matt aluminium. Available in a version

for 1-lamp 58 W and 2-lamp 58 W.

GMX466 HB-A

One-piece wall washer reflector made

from matt aluminium. Suitable for 1- or

2-lamp 58 W TMX400 electrical unit.







Ratio (LOR)

Code (EOC)

GMX460 1 58 C-NB 0.90 09355099

GMX465 1 58 HB-NB 0.88 09728299

GMX465 2 58 HB-NB 0.81 10239999

GMX465 1 58 M-NB 0.84 09695799

GMX465 2 58 M-NB 0.76 10241299


Ratio (LOR)

GMX466 HB-WB

One-piece wide beam reflector made from

high gloss hammer-bow aluminium. Ensures

glare prevention. Suitable for 2-lamp 58 W

TMX400 electrical unit.

GMX466 M-WB

One-piece wide beam reflector made from

matt aluminium. Suitable for 2-lamp 58 W

TMX400 electrical unit.

GMX467 M-A

One-piece asymmetrical beam made from

matt aluminium. Available in a version for

1-lamp 36 W and 1-lamp 58 W.

GMX470 C-NB

One-piece ultra narrow beam reflector


for 1-lamp 58 W TMX400 electrical unit.


Code (EOC)

GMX466 2 58 HB-WB 0.83 09333899

GMX466 2 58 M-WB 0.80 09327799

GMX467 1 58 M-A 0.83 09359899

GMX470 1 58 C-NB 0.89 10104099



Trunking systems TTX400 units for projectors


For associated accessory, see page 8.87.

8.82


~TMX403~TTX400 Units for projectors

TTX403/405/407 units for projectors

Increasingly, accent lighting is integrated in functional and general

lighting systems. Especially in applications like shops, showrooms and

public buildings, such as museums.The TTX400 light-line system can

be equipped with different types of projectors answering to these

lighting needs. Due to its modular concept, the installation of

projectors on TTX400 offers great flexibility. For example a change

in the configuration of the shop floor lay-out, can be easily followed

by changing the positions of the projectors on the light-line.


TMX407 58 3C

Electrical unit with an integrated 3circuit

rail. Standard projectors can be

mounted in the rail. Maximum weight

of the mounted projectors is 9 kg.

TMX405 58-4

Electrical unit with 4 Express

connection points for low-voltage

halogen spots. The unit has 2 built-in

12 V- 105 W transformers.

TMX403 58-2

Electrical unit with 2 connection points

for projectors with e.g. CDM-T or

SDW-T lamps. The projectors are

mounted with the spot bracket on the

trunking.

Product ID Circuit European Order

Code (EOC)

TMX403 58-2 - 10148499

TMX405 58-4 - 10150799

TMX407 58 3C 3C 10152199


Trunking systems TTX400 TL5/TL-D trunking accessories


ZTX400 EP-PHL

White plastic end plate to cover the

trunking. Includes a knock out hole of

20 mm.


Code (EOC)

ZTX400 CM 09435999

ZTX400 CM-620 10852099

ZTX400 CL 09431199

ZTX400 EP-PHL 68442099

ZTX400 CU 09459599

ZTX400 CM

The middle of the line connection unit

enables the mains connection to be made

in the middle of a light-line. The unit

comprises two 7-pole connection blocks

for mains connection. To be used in the

middle of a light-line when very long lines

are used. The same middle of line

connection unit is used for the TTX400

with either the internal 5- or 7-wire flat

ribbon cable. Delivered with coverplate.

ZTX400 CL

The continuous line connection unit is used

at the end of a light-line when a throughconnection

is needed to pass an

interruption of the light-line. It comprises a

7-pole screw connection block. The same

continuous line connector is used for the

TTX400 with either the internal 5- or 7wire

flat ribbon cable. Not to be used for

mains connection.

ZTX400 CU

Connection unit consisting of a 7-pole

contact block with 2.5 mm 2 contacts and

mains connection strain relief for use at the

beginning of a light-line. The same

connection unit is used for the TTX400

with either the internal 5- or 7-wire flat

ribbon cable.



Trunking systems TTX400 TL-D/TL5 trunking accessories


Click 1

Secures the section to the suspension bracket.

Click 2

Connects the section mechanically and

electrically.

Click 3

Mounts the electrical unit.

Click 4

Fits the reflector to the electrical unit.

Click 5

Connects the power supply.


The integrated phase selector is used in both

the 5- and 7-wire ribbon cable, and circuits

can be selected easily.

8th and 9th wire: tool-less through-wiring via

click.

TTX400 CU7 + ZTX400 EP-CU7

TTX400 TL-D/TL5 trunking

Alternative, more aesthetic mains connection,

using a standard electrical connector. Knock

outs in trunking and end caps enable the

mains wires to enter the trunking. Dedicated

trunking e.g. TTX400 491 CU7 with knock

outs. Kit: electrical connector, end plate and 2

cable glands e.g. ZTX400 EP-CU7.

Accessory Order

Code (EOC)

TTX400 581 CU7 68516899

ZTX400 EP-CU7 68521299


Trunking systems TTX400 accessories

ZTX400 CB

Chain bracket for suspending TTX400/410

sections from chains or steel cables.

Includes adjustable suspension hook.

ZTX400 CDB

Universal bracket for suspending TTX400

section including unwired section TTX410

which then serves as cable duct.

ZTX400 MB

Ceiling mounting bracket (8 mm diameter

hole) for mounting TTX400/410 sections

directly to the ceiling.

TTX400/410 suspension/mounting brackets

The TTX400 suspension/mounting brackets have been designed to

allow maximum ease and speed in installation and to provide the

greatest possible flexibility in use. All brackets are simply clicked on

the trunking.They are suitable for direct fixation or with chains,

threaded rods and steel cables for suspension fixation.

Distance between the brackets is up to 3 metres (when using the

583 trunking sections), resulting in faster installation and lower costs.

All mounting and suspension brackets are constructed from

galvanised stainless steel, painted white.

The use of TTX400 on a non-stable surface such as a mezzanine

floor requires a special suspension bracket. All such installations

should be referred to the local Philips Lighting key account manager.

ZTX400 CCD

Chain bracket cable duct for suspending

the TTX400/410 sections with the plastic

cable duct ZTX400 582/583 CD from

chains or steel cables. Includes adjustable

suspension hook.

ZTX400 CH

Adjustable suspension hook with 2 brass

nuts for use with ZTX400 UB,

ZTX400 UCD or ZTX400 CDB.

ZTX400 PB

Profile bracket for mounting TTX400/410

sections onto system ceilings with visible

24 mm T-profiles.





ZTX400 SMS

Cable suspension bracket for suspending

the TTX400/410 sections from steel cable

M 1.5. Integrated adapter allows easy,

toolless adjustment of the mounting height.

Steel cable can be ordered separately with

accessory ZTX400 WIRE (10 m).

ZTX400 UCD

Universal bracket for suspending

TTX400/410 sections, including plastic

cable duct ZTX400 CD 582/583 on

threaded rods, or M13 internally threaded

suspension tubes.

Accessory


Code (EOC)

ZTX400 CB 09423699

ZTX400 CCD 09457199

ZTX400 CDB 10136199

ZTX400 CH 09425099

ZTX400 MB 09427499

ZTX400 PB 10134799

ZTX400 SMS 09429899

ZTX400 UB 09200399

ZTX400 UCD 09455799

Transverse flexibility. If the chains to the

ceiling are not exactly vertical, the brackets

will adjust to create a perfectly continuous

line.

ZTX400 UB

Universal bracket for suspending

TTX400/410 sections on threaded rods, or

M13 internally threaded suspension tubes.

Longitudinal flexibility. The position of the

mounting bracket can still be adapted if it is

clicked onto the trunking section. This ensures

maximum flexibility.




ZTX400 LB ZTX400 WB

ZTX400 BR6

Bracket to mount luminaires on TTX410.

ZTX400 WB-FR

Set of brackets to mount surface mounted

luminaires to TTX410.

ZTX400 EC

Electrical connector for waterproof and

surface mounted luminaires to the

prewired trunking TTX400. This electrical

connector can be clicked on the

connection block as mounted standard in

the TTX400 light-line (also ZTX400 DC).

The electrical connector comprises insert

contacts and a strain reliever.


Code (EOC)

ZTX400 LB (2PCS) 09443499

ZTX400 WB (2PCS) 09445899

ZTX400 BR6 30281299

ZTX400 LB-FR 29565799

ZTX400 LB

Set of 2 suspension brackets to mount

luminaires on TTX400/410 trunking.

ZTX400 WB

Set of 2 suspension brackets to mount

luminaires on TTX400 trunking.

ZTX400 LB-FR

Set of brackets to mount waterproof

luminaires on TTX410.

ZTX400 BR-SPOT

Bracket for projectors with CDM-T/SDW-T

lamps like the 60800.2 series and the

Bolero/Monza. This bracket is delivered

with base plate RCS750 RBA and a cable

for external electrical connection.

Advantage is the fact that this bracket can

be installed on TTX400 with reflector and

louvre, so no interruption of the continuous

light-line.

ZTX400 DC

A 5-pole connection block for connecting

the electrical unit when using the unwired

TTX410 profiles. The same connection

block is used as additional block for the pre

wired TTX400 when connecting to

emergency lighting, light regulation or other

functions (in case more than 7 wires are

needed). The connector is clicked inside

the trunking and allows through-connection.


Code (EOC)

ZTX400 WB-FR 29567199

ZTX400 BR-SPOT 28938099

ZTX400 EC 10166899

ZTX400 DC 09837199





ZTX400 CPX

Structure parts with fixed angles, for use

with prewired TTX400 light-line. This

structure part is delivered with integrated

coupling piece and internal through wiring.

Can be used for X-, T- and L

configurations.

ZTX400 ECC

Cable clips for guiding and easy-click fixing

of wires and/or cables on the top of the

TTX400 or TTX410 trunking section.

ZTX400 NE-E27

Orientation lighting unit for fitting in the

TTX400 and TTX410 light-line. Can be

used in combination with GMX430 EL

reflector and a 36 W unit. The connection

is made by an additional cable. The unit has

an E27 lamp holder and can be clicked into

the light-line.

ZTX400 EP-555-MB/WB

Plastic end plate for closing off the trunking

section at the end of each TL5 light-line.


Code (EOC)

ZTX410 CP 09887699

ZTX400 CPX 28980900

ZTX400 CD492 30571499

ZTX400 CD493 30569199

ZTX400 CD542 30586899

ZTX400 CD543 30588299

ZTX400 CD582 09447299

ZTX400 CD583 09449699

Dedicated IP40 accessories are also

available. Please contact your Philips

Lighting representative for more detailed

information.

ZTX400 CD

Cable duct, for installing on the trunking, in

white plastic, with a length of 2 or 3

electrical units. Can be closed with blind

cover strips. To be used in combination

with the suspension brackets ZTX400

UCD/CCD.

ZTX410 ICC

Internal cable clips for guiding and fixing

wires in the unwired TTX410 trunking

section. Installation by simple click-in.

ZTX400 CP-555-MB/WB

Plastic coupling piece. Two coupling pieces

per TL5 junction.


Code (EOC)

ZTX400 ECC 09441099

ZTX410 ICC 09433599

ZTX400 NE-E27 09437399

ZTX400 CP-555-MB 68446899

ZTX400 CP-555-WB 68444499

ZTX400 EP-555-MB 6843899

ZTX400 EP-555-WB 68440699



ZTX400 MDU-D/MDU-P/MDU-R

ZTX400 MDU-D

ZTX400 MDU-D LINESENSE unit suitable

for, movement detection (dimming or

switching off), daylight linking and manual

control. Works with HFR DALI ballasts.

ZTX400 MDU-R

ZTX400 MDU-R LINESENSE unit for

movement detection. Light dims down to

3% when no movement is detected. No

black areas in the hall for a better visual

comfort. Works with HFR ballasts.

ZTX400 MDU-P

ZTX400 MDU-P LINESENSE unit for

movement detection. Light switches off

when no movement is detected. Works

with HFP ballasts.

Accessory Weight


(kg)

Code (EOC)

ZTX400 MDU-D 1.00 30324699

ZTX400 MDU-R 1.00 30327799

ZTX400 MDU-P 1.00 30329199

TTX400 linesense

TTX400 Linesense

TTX400 with Lighting Controls

Applying Lighting Controls in industry contributes to efficient and

effective lighting solutions. For TTX400 applications, Philips Lighting

offers various standard trunking system based controls solutions,

included in the Linesense range.These solutions offer an intelligent

light-line, which remains easy-to-install.

With Linesense,TTX400 and lighting controls are combined in one.

The speed and ease of installation of TTX400 remains when

Linesense is used. In addition, substantial energy savings up to 75 %

can be achieved. Linesense has been developed for industrial

applications like warehouses.

Linesense consists of a 618 mm piece of trunking, which is fully preequipped

and wired to be added to the trunking.The control

function is integrated into this extra unit, and can easily be clicked

between the light-line and the electrical connection unit. High bay

movement detectors are connected with standard RJ-12 cables and

mounted at the right location with the use of dedicated brackets.

Linesense is equipped as standard with a telejack splitter to easily

connect the detectors to the light-line.

LRM8117/00

High-bay passive infrared movement

detector (mounting heigt up to

15 metre), equipped with an adjustable

delay timer (up to 35 minutes).

Can be used with all three MDU

control units.

A dedicated mounting bracket

(ZTX400 MB-MDU) is available in

which the movement detector can be

clicked.

Accessory Weight


(kg)

Code (EOC)

LRM8117/00 - 51847300

ZTX400 MB-MDU - 30377299

See chapter Lighting Controls in this catalogue for more details.



Trunking systems Tetrix TTX150



~~TTX150

Tetrix

With the introduction of the Tetrix light-line, the emphasis is on

simplicity. Easy ordering, with everything assembled in one box, and

tool-less installation are guaranteed to reduce installation work to a

minimum.Tetrix comes in 1.5 or 3 m lengths with a pre-mounted

mechanical coupling and through-wiring connector, MASTER TL-D

Super 80 lamps, reflector, suspension bracket and snap-on finishing

pieces. A starter kit is required to start the light line.The preassembled

trunking is equipped with 5 x 2.5 mm 2 through-wiring.

Tetrix is delivered with a white in-laid reflector to cover most

standard applications. Conventional and HF versions are available in

58 W.The white pre-lacquered profile forms the carrier of the

system. Its shape has been designed to be compact and ridged.

Dedicated 1.5 m trunkings can be equipped with emergency

lighting. Maintenance is carried out from below, enabling the system

to be used as a surface mounted solution.

Product ID A

TTX150 581

1530

TTX150 582 3060




Tetrix 1.5 m length

TTX 150

* 581 = 1.5 m.

** Lamps are delivered with the trunking.

*** DS = double switching, 2-lamp only.

**** Emergency lighting is optional.

TTX 150


length*

581

Suitable for lamps** Gear

1xTL-D58W/840

2xTL-D58W/ 840

2x1xTL-D58W/840

2x2xTL-D58W/840

IC

IC 240V

IC DS***

HFB

HFB DS***

HFP


Tetrix 3 m length


length*

582

* 582 = 3 m.

** Lamps are delivered with the trunking.

*** S = double switching, 2 x 2 lamps only.

*

Gear

IC

IC 240V

IC DS***

HFB

HFB DS***

HFP


Tetrix empty through-wiring units

TTX 150 5x2.5

TTX150


length

581

582

Through-wiring

Emergency

lighting ****

EL3

TTX 150 582 5x2.5

TTX 150 581 1xTL-D58W/840 IC

TTX 150 2x2xTL-D58W/840 IC




TTX150 + GTX150 L



Code (EOC)

TTX150 581 5x2.5 12479700

TTX150 581 1xTL-D58W/840 IC 12480300

TTX150 581 1xTL-D58W/840 HFB 12481000

TTX150 581 1xTL-D58W/840 HFP 12482700

TTX150 581 2xTL-D58W/840 IC 12504600

TTX150 581 2xTL-D58W/840 HFB 12505300

TTX150 581 2xTL-D58W/840 HFP 12506000

TTX150 581 2xTL-D58W/840 IC DS 12510700

TTX150 581 2xTL-D58W/840 HFB DS 12511400

TTX150 581 1xTL-D58W/840 IC EL3 12522000

TTX150 581 1xTL-D58W/840 HFB EL3 12523700

TTX150 581 1xTL-D58W/840 HFP EL3 12524400

TTX150 581 2xTL-D58W/840 IC EL3 12528200


Mechanical connection of the trunking

sections by pushing them together.



Code (EOC)

TTX150 581 2xTL-D58W/840 HFB EL3 12529900

TTX150 581 2xTL-D58W/840 HFP EL3 12530500

TTX150 582 2xTL-D58W/840 IC 12501500

TTX150 582 2xTL-D58W/840 HFB 12484100

TTX150 582 2xTL-D58W/840 HFP 12485800

TTX150 582 4xTL-D58W/840 IC 12491900

TTX150 582 4xTL-D58W/840 HFB 12492600

TTX150 582 4xTL-D58W/840 HFP 12493300

TTX150 582 4xTL-D58W/840 IC DS 12512100

TTX150 582 4xTL-D58W/840 HFB DS 12513800

TTX150 582 5x2.5 12514500

ZTX150 MB-EC-2xEP (starter kit) 12444599

GTX150 L (louvre) 124773969

Pre-assembled Tetrix delivered with all

components in one box. Starter kit.

Secure mechanical connection with simple

finger-operated locking lever.


Battens TMX204 LS

TMX204 2x 36W/58W


~TMX204~TMX204 LS

TMX204 LS

Basic individual batten for TL-D fluorescent lamp(s) for general

lighting. Possibility of mounting a wide range of reflectors and

attachments of the TTX400-series (except for the mirror inserts).

For suspended or direct ceiling mounting. Due to its slim design the

batten is also well-suited for build-in applications and coves.

Delivered with an individual ceiling mounting rail allowing very easy

mounting and suitable for feed-through wiring. If the mounting rail is

removed, the TMX204 unit can be used to service the existing

TTX200 installations. Certain versions available with emergency kits

for 1 or 3 hours. The batten is available in many protection classes,

including IP50 (FF), for both standard and dusty environments.

Applications

•Discount stores, hyper-

/supermarkets, do-it-yourself

shops

• Normal industries

•Dust protected

•Cleanroom



HF: 220 V - 240 V

conventional: 230 V or 240 V

• Lamps: 1 and 2 TL-D fluorescent

• Housing: galvanised pre-lacquered sheet steel

Installation

Mounting: individual.

Universal fixing with ceiling mounting rail for suspended or direct

ceiling mounting.

Cable entry via knock-out openings in the end-caps or centrally on

the top side.

Method: click-in lampholders, quick mechanical fixing with two push

buttons, mounting rail with connection block and automatic

electrical connection from rail to batten housing.

Accessories

The complete range of reflectors of the TTX400 range can be

mounted on the TMX204 LS.

For fixation of these reflectors a set of fixation screws

(ZMX204 SR) has to be ordered separately. The white reflector

GMX450 can be equipped with the same range of attachments as

the TTX400 system.

With protection rings (ZTX400 IP40), which can be clicked on the

standard lampholders, the TMX204 LS can be upgraded to IP40.


TMX204 1x18W/1x18W IP40/1x18W IP50 370 614 24/32/50 93/99/111










TMX204 2x 36W/58W

TMX204 1x 36W/58W IP50 TMX204 1x 36W/58W IP50 FF



Ratio (LOR) Code (EOC)

TMX204 1xTL-D58W IC LW 0.95 11079099

TMX204 1xTL-D58W IC 0.95 10018099

TMX204 2xTL-D58W IC 0.97 10036499

TMX204 1xTL-D58W HFB 0.95 10076099

TMX204 2xTL-D58W HFB 0;97 10078499

TMX204 1xTL-D58W HFB IP50 FF 0.95 10769100

TMX204 2zTL-D58W HFB IP50 FF 0.97 10850600

TMX204 2xTL-D58W HFB EL3

* Master/slave solution

0.97 10085200



Ratio (LOR) Code (EOC)

TMX204 1xTL-D58W HFP 0.95 10054899

TMX204 2xTL-D58W HFP 0.97 10056299

TMX204 1xTL-D58W HFP IP50 FF 0.95 10044900

TMX204 2xTL-D58W HFP IP50 FF 0.97 10045600

TMX204 1xTL-D58W HFP EL3 0.95 10084500

TMX204 2xTL-D58W HFP M/S* 0.97 10058699

TMX204 1xTL-D58W HFR 0.95 10068599

TMX204 2xTL-D58W HFR 0.97 10070899



Accessories

ZMX204 SR

One set of fixation screws needed for

mounting of one individual reflector.


Code (EOC)

ZMX204 SR (2PCS)

10811799

ZMX204 136 WG

29521300

ZMX204 236 WG

29522000

ZMX204 158 WG

29523700

ZMX204 258 WG

29524400

ZMX204 ... WG

TMX 204 with a two lamps wire guard

(ZMX204 2 36 WG or ZMX204 2 58 WG).

TMX 204 with a single lamp wire guard

(ZMX204 1 36 WG or ZMX204 1 58 WG).

TMX204 LS lampholder with IP40 protection.



Battens Pentura TMS122

TMS122


8.96


~TMS122~Pentura TMS122

Pentura TMS122

Functional and economical general purpose batten for 1 x TL5

fluorescent lamp with choice of three different accessories/optics:

aluminium symmetric or asymmetric reflector and polycarbonate

protection cover.

Applications

•Discount stores, hyper-/

supermarkets, do-it-yourself

shops



• Gear/power supply: HF: 220 V - 240 V

• Lamps: 1 TL5 (16 mm) fluorescent

• Housing: white pre-lacquered steel

Due to the slim dimensions also

suitable for:

• under-shelf lighting

• cornices indirect lighting

Installation

Mounting: electrical connection through cable entry centrally

(except 14 W) or via the end-cap.

Method: base plate (with electrical components) fixed to the ceiling

via holes for (wood) screws. White pre-lacquered cover

(decorative) fixed with 2 clips to the base plate.

Accessories

Matt aluminium, one-piece, symmetrical reflector.

Matt aluminium, one-piece, asymmetrical reflector.

Polycarbonate cover.

Connection block for quick connection facility.

Product ID A B

TMS122 14W/24W 463 571

TMS122 21W/39W 600 871

TMS122 28W/254W 900 1171

TMS122 35W/49W 900 1471





Ratio (LOR)


Code (EOC)

TMS122 1xTL5-14W/830 HFP 0.98 46779599

TMS122 1xTL5-14W/840 HFP TW1* 0.98 64339799

TMS122 1xTL5-21W/830 HFP 0.96 47100699

TMS122 1xTL5-21W/840 HFP 0.96 47140299

TMS122 1xTL5-24W/830 HFP 0.97 47300099

TMS122 1xTL5-24W/840 HFP 0.97 64001399

TMS122 1xTL5-28W/830 HFP 0.97 46781899

TMS122 1xTL5-28W/830 HFP TW1* 0.97 64331199

TMS122 1xTL5-28W/830 HFR 0.97 47134199

TMS122 1xTL5-28W/840 HFP 0.97 46789499

TMS122 1xTL5-28W/840 HFP TW1* 0.97 64341099

TMS122 1xTL5-28W/840 HFR 0.97 47206599

TMS122 1xTL5-35W/830 HFP 0.96 46795599

TMS122 1xTL5-35W/830 HFP TW1* 0.96 64335999

TMS122 1xTL5-35W/830 HFR 0.96 47136599

TMS122 1xTL5-35W/840 HFP 0.96 46797999

TMS122 1xTL5-35W/840 HFP TW1* 0.96 64343499

TMS122 1xTL5-35W/840 HFR 0.96 47208999

TMS122 1xTL5-39W/830 HFP 0.96 47399499

TMS122 1xTL5-39W/840 HFP 0.96 47142699

TMS122 1xTL5-49W/830 HFP 0.96 46783299

TMS122 1xTL5-49W/840 HFP 0.96 46791799

TMS122 1xTL5-54W/830 HFP 0.96 46785699

TMS122 1xTL5-54W/840 HFP 0.96 46793199

TMS122 1xTL5-80W/830 HFP - 04451499

TMS122 1xTL5-80W/840 HFP

* TW = through wiring

- 64571199

Also available with through wiring for

quick/easy installation.




Accessories



ZMS122 EC

Connection block for quick connection

facility (10 pieces per bag).


Code (EOC)

GMS122 1 14 PC 47126699

GMS122 1 21 PC 47132799

GMS122 1 28 PC 47128099

GMS122 1 49 PC 47130399

GMS122 1 14 R 47110599

GMS122 1 21 R 47116799

GMS122 1 28 R 47112999

GMS122 PC

Polycarbonate cover.

Product ID A

GMS122 1 14/1 24 575

GMS122 1 21/1 39 875

GMS122 1 28/1 54 1175

GMS122 1 35/1 49 1475

GMS122 R

Mat aluminium symmetric reflector.

Product ID A

GMS122 R 1 14 R/1 24 R 570

GMS122 R 1 21 R/1 39 R 870

GMS122 R 1 28 R/1 54 R 1170

GMS122 R 1 35 R/1 49 R 1470

GMS122 R-A

Mat aluminium asymmetric reflector.

Product ID A

GMS122 R-A 1 14 R-A/1 24 R-A 570

GMS122 R-A 1 21 R-A/1 39 R-A 870

GMS122 R-A 1 28 R-A/1 54 R-A 1170

GMS122 R-A 1 35 R-A/1 49 R-A 1470


Code (EOC)

GMS122 1 49 R 47114399

GMS122 1 14 R-A 47118199

GMS122 1 21 R-A 47124299

GMS122 1 28 R-A 47120499

GMS122 1 49 R-A 47122899

ZMS122 EC (10PCS) 64395300


Battens Regletta TMS121

TMS121 1x 18W


~TMS121~Regletta TMS121

Regletta TMS121

Functional and economical general-purpose decorative batten for

1x TL Miniature or 1 x TL-D fluorescent lamp with acrylic

protection cover and integrated power switch. For surface

mounting. Due to its slim design the batten is also well suited for

build-in applications and coves. Delivered with a mounting bracket

allowing very easy mounting. Lamp included.

Applications

•Small independent food/nonfood

shops

•Discount stores, hyper-

/supermarkets, do-it-yourself

shops


• Gear/power supply: conventional: 230 V

• Lamps: 1 TL Miniature or 1 TL-D fluorescent

• Housing: white lacquered steel


• Kitchens, corridors, store

rooms

Installation

Mounting: individual; electrical connection through cable entry

centrally or via end-cap.

Method: mounting bracket fixed via holes for (wood)screw fixing.



TMS121 1xTL8W/830 I P

Code (EOC)

82403199

TMS121 1xTL13W/830 I P 82413099

TMS121 1xTL-D18W/830 I P 82423999

TMS121 1xTL-D18W/840 I P 14156599

TMS121 1xTL-D30W/830 I P 82433899

TMS121 1xTL-D36W/830 I P 82443799

TMS121 1xTL-D36W/840 I P 14167199

TMS121 1xTL-D58W/830 I P 82419299

Product ID A B C

TMS121 TL8W 300 38 67

TMS121 TL13W 590 38 67

TMS121 TL-D18W 675 40 78

TMS121 TL-D30W 980 40 78

TMS121 TL-D36W 1280 40 78

TMS121 TL-D58W 1580 40 78



Battens TMS028

TMS028 2x 36W/58W


8.100


~TMS028~TMS028

TMS028

Basic industrial luminaire for TL-D fluorescent lamp(s) for general

lighting. For surface and suspended mounting.

A repositionable contact block makes a flexible connection possible

and keeps the installation costs low.

As option pre-equipped with possibility for mounting on

Telemécanique kle/kla power supply systems.

Reflector supplied with the luminaire.

Attachment (lamallea louvre) available as accessory.

Applications

•Discount stores, hyper-/supermarkets, do-it-yourself shops




HF: 220 V - 240 V (HFB, EI*)

conventional: 230 V or 240 V



* Electronic Included

Installation

Mounting: electrical connection through cable entry centrally or via

end-cap.

Possibility to reposition the contact block (2-lamp versions).

Method: holes for (wood)screw fixing or suspension by

chains/threaded rods.

Accessories

Coupling piece, end-caps and lamellea louvre.


TMS028 36W 1100 960 800 1232

TMS028 58W 1400 1260 1100 1532


Battens TMS028



Ratio (LOR)


Code (EOC)

TMS028 1xTL-D36W EI 0.87 30191400

TMS028 2xTL-D36W EI 0.82 30192100

TMS028 1xTL-D58W EI 0.87 30193800

TMS028 2xTL-D58W EI 0.81 30194500

TMS028 1xTL-D36W IC 0.87 20300300

TMS028 2xTL-D36W IC 0.82 20302700

TMS028 1xTL-D58W IC 0.87 20301000

TMS028 2xTL-D58W IC 0.81 20303400

TMS028 2xTL-D36W HFB 0.82 20304100

TMS028 2xTL-D58W HFB 0.81 20305800

Accessories

GMS028 L

TMS028 with GMS028 L white lamellae

louvre.

ZMS028 EP

End-caps.


Code (EOC)

GMS028 36 L 20825199

GMS028 58 L 20826899

ZMS028 CP (2PCS) 20828299

ZMS028 EP (2PCS) 20827599

ZMS028 CP

Coupling pieces.



Battens Lineco TMS022

TMS022 2xTL-D


8.102


~TMS028~TMS028

Lineco TMS022

Functional and economical general-purpose basic batten for TL-D

fluorescent lamp(s) with choice of two optics for symmetrical or

asymmetrical lighting. For surface mounting.

A repositionable contact block makes a flexible connection possible

and keeps the installation costs low.

Applications

• Discount stores, hyper-/supermarkets, do-it-yourself shops




HF: 220V - 240V (EI* )

conventional: 230V or 240V



* Electronic Included

Installation

Mounting: electrical connection through cable entry centrally or via

end-cap.

Possibility to reposition the contact block (2-lamp version).

Method: holes for (wood)screw fixing.

Accessories

White one-piece symmetrical reflector (for 1- and 2-lamp versions)

and asymmetrical reflector (for 1-lamp version).


TMS022 2x18W 500 615

TMS022 2x36W 900 1225

TMS022 2x58W 1200 1525


Battens Lineco TMS022




TMS022 1xTL-D15W I

Code (EOC)

20737799

TMS022 1xTL-D18W I 20776699

TMS022 1xTL-D18W IC 20778099

TMS022 1xTL-D30W I 20738499

TMS022 1xTL-D36W EI 12133899

TMS022 1xTL-D36W HFB 11851299

TMS022 1xTL-D36W I 20661599

TMS022 1xTL-D36W IC 20783499

TMS022 1xTL-D58W HFB 11855099


TMS022 1x15W 300 462

TMS022 1x18W 500 615

TMS022 1x30W 600 920

TMS022 1x36W 900 1225

TMS022 1x58W 1200 1525

TMS022

1xTL-D36W

GMS022 R


Code (EOC)

TMS022 1xTL-D58W I 20787299

TMS022 1xTL-D58W IC 20789699

TMS022 2xTL-D18W IC 20781099

TMS022 2xTL-D36W EI 12135299

TMS022 2xTL-D36W HFB 11853699

TMS022 2xTL-D36W IC 20786599

TMS022 2xTL-D58W HFB 11857499

TMS022 2xTL-D58W IC 20792699

GMS022 R

TMS022 with GMS022 R white reflector.


GMS022 36 R 900 1223

GMS022 58 R 1200 1523


Code (EOC)

GMS022 36 R 11756099

GMS022 58 R 11760799

GMS022 70 R 11781299

GMS022 R-A

TMS022 with GMS022 R-A white

asymmetric reflector.


GMS022 36 R-A 900 1223

GMS022 58 R-A 1200 1523


Code (EOC)

GMS022 36 R-A 11787499

GMS022 58 R-A 11788199

GMS022 70 R-A 11789899

Trunking systems and battens

Create successful ePaper yourself

Delete template?

Save as template?
