CABLE WINCHES
WE CAN MAKE IT<br />
<strong>Cable</strong> winches from <strong>Werner</strong> <strong>Forst</strong>- <strong>und</strong> <strong>Industrietechnik</strong><br />
are renown for their long service life and quality. To<br />
maintain this high standard we apply our knowledge and<br />
many years of experience day after day to provide you<br />
with the highest quality and reliable cable winches that<br />
money can buy.<br />
This starts in our design department where our engineers<br />
work on perfecting the design of the winch which<br />
meets your specifi c needs and ends at the workbench<br />
where our staff produce each part of your customised<br />
winch. The exact milling of the worm shaft and the worm<br />
wheel, the main part of the drive in our winches, and the<br />
02<br />
WERNER - THE COMPANY<br />
installation of complex electronic control systems – your<br />
winch is made by one producer only. This is what makes<br />
our winches so very good and why we are so proud of<br />
each and every one of them.<br />
Our many years of experience in designing cable winches,<br />
our enthusiasm for this state-of the-art technology<br />
and our <strong>und</strong>erstanding of the challenges of your daily<br />
work enable us to produce a very special piece of equipment:<br />
a cable winch from <strong>Werner</strong> which does exactly<br />
what it has been designed to do for no less than its whole<br />
lifetime.
Tradition<br />
Ideas<br />
Craft<br />
Ability<br />
CRAFT AND TECHNOLOGY<br />
Experience cannot be replaced by anything else. <strong>Werner</strong> has been making cable winches<br />
for decades for all applications aro<strong>und</strong> the world – every day it draws on a perfect combination<br />
of tradition and innovation.<br />
In our design department our engineers are developing perfect solutions for your cable<br />
winches. For an individual and exacting installation of the winches and in combination<br />
with the other equipment of your vehicle. This is where our well-considered and effi cient<br />
concepts are being developed.<br />
At the workbench our staff make each piece of your cable winches with dedication and<br />
expertise. For each practical challenge they will fi nd a perfect solution.<br />
We assemble your cable winches part for part in our workshops and install them into<br />
your vehicle – either at the front, back or side of the vehicle or retracted to the chassis.<br />
In the well-known <strong>Werner</strong> quality: with an optimal design, customised to satisfy your<br />
requirements and completely reliable.<br />
03
FRONT, SIDE, CHASSIS OR BACK INSTALLATION /<br />
LIFTING, LOWERING, PULLING, TOWING /<br />
AUTOMATIC CABLE TAKE-UP /<br />
RUN-IN OPENING /<br />
ROLLER WINDOW /<br />
CABLE TAKE-UP ACCORDING<br />
TO THE 3° PRINCIPLE /<br />
CABLE SLACK DISCONNECTION /<br />
DRUM NEUTRAL GEAR POSITION /<br />
SLIDING BRAKE /<br />
CABLE GUIDE ROTARY WING,<br />
SLOPE CABLE DRAWING UP TO 90° /<br />
POSITION-DEPENDENT CONTROL /<br />
HYDRAULIC CABLE RELEASE /<br />
TRACTION POWER DISPLAY /<br />
REMAINING CABLE LENGTH DISPLAY /<br />
UNIVERSAL GENIUS
1<br />
3<br />
TAILORED INSTALLATION<br />
Because we do our own design and production work, our<br />
cable winches have no restrictions. We can provide you<br />
with the right winch for each job and for each vehicle.<br />
The options for installing our winches in your vehicle are<br />
almost unlimited since our winch designs have all been<br />
made for as compact a space as possible. This means<br />
that we can install your winch as required either at the<br />
front, the side or the back of your vehicle. We can also install<br />
the winch in a retracted position in the middle of the<br />
chassis. Here we carefully account for the deformation<br />
properties of the chassis and the supporting and tensile<br />
forces and their effects on the frame of your vehicle.<br />
2<br />
As a single source supplier we can also provide you<br />
with a combination of different superstructures for one<br />
vehicle. All our winches are designed using our longstanding<br />
expertise and skills, integrated with each other and<br />
highly effi cient in their use. We also focus on achieving<br />
the lowest possible superstructure weight and complying<br />
with all valid standards.<br />
With all these strengths we are truly second to none.<br />
1 Front installation<br />
2 Side installation<br />
3 Chassis installation<br />
4 Back installation<br />
4<br />
Should you<br />
have any questions<br />
regarding our<br />
winches please<br />
call us.
06 TAILORED INSTALLATION<br />
07
MEETING CHALLENGES<br />
We also design optimal customised solutions when<br />
dealing with the narrow confi nes of the chassis of a<br />
Unimog.<br />
The photograph shows the complex job of combining a<br />
winch with the frame area tog ether with a rear power<br />
take-off shaft. Since the conditions of the structural space<br />
following the introduction of the EURO 4 do not permit a<br />
side installation anymore, the winch had to be integrated<br />
with the frame.<br />
Such a superstructure cannot be integrated into a standard<br />
platform. This is why <strong>Werner</strong> made a winch with an<br />
exact fi t and implemented a solution which allowed for<br />
an installation to the frame according to the customer’s<br />
requirements.<br />
The Unimog U 500 in the photograph has been designed<br />
by <strong>Werner</strong> for a special use in the energy sector.<br />
The customer wished to combine a hydraulic cable winch<br />
with numerous other pieces of equipment on a vehicle<br />
possessing a short wheel base. Along with a front compressor<br />
and a work basket on the platform, this U 500 also<br />
features a crane superstructure and a slope support.<br />
Despite the crane frame recesses the cable course leads<br />
from the winch installed at the side of the vehicle and<br />
through the frame to the back. Combined with the crane<br />
frame this conversion was a special engineering and<br />
design feat by <strong>Werner</strong> not the least because of the short<br />
chassis.
CABLE WINCHES MADE BY WERNER<br />
We make our cable winches completely by ourselves –<br />
from the planning and design stage through to the<br />
production of the smallest gearwheel. We are the only<br />
company that has this manufacturing depth which is why<br />
our cable winches are so exceptionally good.<br />
Already at the design stage of our cable winches we can<br />
take your special needs into account. Whether we are<br />
dealing with a combination together with other equipment,<br />
different drive concepts, winch positions or cable<br />
courses – our engineers will fi nd just the right solution.<br />
10<br />
CABLE WINCHES<br />
<strong>Werner</strong> cable winches are made to precisely fi t the<br />
requirements for which they have been built. Whether<br />
in forestry, the water industry or for any other purpose<br />
anywhere in the world – you can rely on cable winches<br />
from <strong>Werner</strong>.<br />
This is how things have always been and this is also how<br />
things will always be.
TECHNCIAL SPECIFICATIONS<br />
<strong>Cable</strong> wind up: <strong>Werner</strong> cable winches are equipped with<br />
a cable guide housing and a spooler over a cross-wind<br />
threaded spindle. This allows a minimum wear of the<br />
cable and an optimal use of the cable drum volume. A<br />
direct angular traction force can be used with an installation<br />
at the back or the front of the vehicle.<br />
Releasable with a load: Forestry cable winches made by<br />
<strong>Werner</strong> can be released with a load. To avoid damage<br />
to the equipment during its use with downward loads,<br />
the brakes can be opened by pressure and the loads<br />
released. The cable drum can also be completely separated<br />
from the gear unit by using the drum neutral position –<br />
this makes the cable pull out considerably easier.<br />
Hydraulic cable supply: Especially with winches which<br />
have been installed at the front or back of a vehicle, the<br />
hydraulic supply device used to pull out the cable functions<br />
with a minimum of force. The hydraulic cable supply<br />
compensates the friction drag of the defl ection pulleys<br />
and the cable bedding. A fi rmer adjustment of the sliding<br />
brake prevents a trailing of the cable on the drum. The<br />
cable wind up <strong>und</strong>er initial stress prevents loose cable<br />
from gathering on the drum.<br />
Position-dependent control: The use of <strong>Werner</strong> cable<br />
winches with a position-dependent control allows the<br />
respective cable position to be exactly established while<br />
in operation. The electro-hydraulic or elec tronic control<br />
assures a consistent lifting power over the whole length<br />
of the cable.<br />
11
LIFTING<br />
The precise operation of a cable winch is especially important for lifting work. This includes the various demands<br />
placed on the equipment during pole positioning work in the power- industry as well as during its use for demanding<br />
rescue operations.<br />
This is why we have solved the problem of an optimal interplay of clutch and brake with our lifting cable winches.<br />
This enables heavy weights to be precisely lifted and lowered as well as the sensitive and exact handling of winches<br />
making precision work with <strong>Werner</strong> cable winches child’s play.<br />
In addition, the balanced interplay of the lifting and lowering functions provides more safety for people and equipment.<br />
The use of our space-saving winches in confi ned areas also opens up a wide range of installation opportunities.<br />
To allow you to make full use of the potential of your cable winch, we will install it in exactly that position of your<br />
vehicle which is the most suitable for your work.<br />
<strong>Werner</strong> is constantly thinking one step ahead. That is why our lifting cable winches with their many well-designed<br />
functions and features can make your work so much easier.<br />
1 2<br />
12<br />
The traction force display shows you the current traction<br />
force values.<br />
For many of the uses of your winch you must know how<br />
much cable you still have available on the drum. The<br />
remaining cable display shows you the exact amount of<br />
cable remaining on the drum. It also provides you with<br />
an acoustic alarm.<br />
The dead man’s operation prevents any accidental operation<br />
of the cable winch.<br />
SECTOR<br />
SECTOR<br />
ENGERY<br />
ENGERY<br />
LIFTING CABLE WINCHES<br />
The cable slack disconnection controls the initial stress<br />
of the cable and prevents loose cable from winding up<br />
on the drum which could damage the cable.<br />
Each centimetre counts during critical rescue operations<br />
and sensitive installation work. The proportional control<br />
unit of our cable winches enables cable speeds which<br />
are close to zero.<br />
PRECISION: The proportional control and perfect balance between the clutch and the brake of our lifting cable winches<br />
allows for highly precise and centimetre-exact operations within precisely prescribed areas – even with heavy loads.
1 2<br />
13
1<br />
2<br />
14<br />
TRACTION CABLE WINCHES<br />
3<br />
4
1<br />
2<br />
PULLING<br />
Traction cable winches are real work animals. They must therefore be robust and effi cient. During a self-rescue<br />
operation on diffi cult gro<strong>und</strong>s, the salvaging of fl oatsam in the water industry, or during logging operations in<br />
the forest you have to be able to rely on your winches.<br />
This is why <strong>Werner</strong> has been manufacturing well-designed and robust winches for many years now. The robust technology<br />
of the gear units and winches assure a safe and effi cient use for years on end. The equipment is also easy to<br />
maintain and repair. This makes the cable winches made by <strong>Werner</strong> such a reliable tool which will not let you down.<br />
This is our promise to you!<br />
Traction cable winches have unlimited applications. <strong>Werner</strong> will make you the right winch for your specifi c use.<br />
For a use in forests your winch must move heavy loads<br />
over great distances. For this purpose, our winches<br />
have an ergonomic ratio between cable diameter and<br />
traction force.<br />
Especially with great cable lengths we especially focus<br />
on the cable spooling of our traction cable winches. To<br />
allow an active winding of the cable we have already<br />
invented the cross thread spindle many years ago. This<br />
assures a tidy drum which goes easy on the cable.<br />
3<br />
4<br />
The neutral gear position of the drum, for example,<br />
makes it easier to pull out cable in diffi cult gro<strong>und</strong>s in<br />
forest opera tions. To avoid dangers from sloping<br />
loads, the cable drum of these winches can still be<br />
disengaged with a load.<br />
Maintenance work in the water industry can be carried<br />
out quickly and safely with slope supports.<br />
TIDY: Great lengths of cable are especially important in the water industry. Our winches with their cross thread<br />
spindles actively wind up the cable onto the drum thus keeping it tidy and reducing the wear of the cable.<br />
INDUSTRY<br />
INDUSTRY<br />
WATER<br />
WATER<br />
15
RESCUE OPERATIONS<br />
When they are being used by the fi re-brigade, the German technical services THW or for disaster control purposes,<br />
our cable winches help to save lives. To meet all the demanding requirements of these uses, our cable winches have<br />
been optimally designed to meet the special challenges posed by rescue operations.<br />
Especially with regard to the costly superstructures used by fi re-brigade and other special vehicles, <strong>Werner</strong> integrates<br />
the cable winches perfectly with the frame of the vehicle. Here we of course look for a perfect fi t of the installation with<br />
the other equipment of the vehicle and their functions.<br />
The simple and effi cient operation of <strong>Werner</strong> cable winches not only makes the work easier but also safer. In addition,<br />
you can use our cable winches to display and monitor all safety-relevant functions and data from one central position.<br />
This is especially important during fi re-fi ghting operations, and it helps to make your work safer.<br />
High-quality cable winches cannot be replaced by anything else during rescue operations. Here you can always rely on<br />
winches made by <strong>Werner</strong>.<br />
16<br />
A traction force display informs you of the current traction<br />
force values.<br />
A clearly visible display in the operating fi eld of the<br />
cable winches allows you to continuously monitor the<br />
remaining cable length on the drum.<br />
A dead-man operation prevents operations from being<br />
carried out accidentally.<br />
FORESTRY<br />
FORESTRY<br />
SERVICES<br />
SERVICES<br />
SERVICES<br />
SERVICES<br />
RESCUE<br />
RESCUE<br />
RESCUE<br />
RESCUE<br />
RESCUE CABLE WINCHES<br />
1<br />
2<br />
During critical rescue operations – especially those involving<br />
the fi re-brigade – a highly precise control of loads is<br />
often critical. The proportional control unit of our cable<br />
winches allows you to use cable speeds close to zero and<br />
to perform work in the centimetre range.<br />
During self-rescue operations you have to be able to<br />
reply on your cable winches. That is why cable winches<br />
from <strong>Werner</strong> feature a simple and robust design and are<br />
a completely reliable tool for everyday use.<br />
SAFE: For use in fi ghting fi res or controlling disasters: <strong>Werner</strong> cable winches can be optimally<br />
integrated into the total concept of a vehicle while meeting the high safety requirements of<br />
rescue services.
1<br />
2<br />
17
1<br />
WE ARE REAL ALLROUNDERS<br />
We don’t know of any place where cable winches are<br />
used for which we would be unable to fi nd a solution.<br />
Whether on a ski-jump or at a container terminal. Our<br />
winches are able to meet any challenge and they are<br />
It doesn’t always have to be a Unimog. <strong>Werner</strong> has perfected<br />
the customised installation of cable winches –<br />
regardless of where this happens to be.<br />
For example at the Mühlenkopf world cup ski-jump in<br />
Willingen. This is where <strong>Werner</strong> adapted a hydraulic<br />
lifting winch and installed it into the shaft of the ski-jump<br />
tower. The cable leads to the ski-jump table over defl ection<br />
pulleys and lifts or lowers an inspection basket used<br />
to maintain the ski-jump. This is just one of the challenges<br />
which we have successfully met in recent times.<br />
1 2<br />
18<br />
TECHNICAL SPECIFICATIONS<br />
2<br />
designed to meet your specifi c requirements. We only<br />
need to know what your winch is meant to do and we<br />
will design one for you accordingly.<br />
This FESTMA extension was designed and built by<br />
<strong>Werner</strong> according to the special requirements of the<br />
Bremerhaven container terminal.<br />
The vehicle possesses a front lifting device, a 4-tonne<br />
front winch and a 1.5-tonne gypsy winch behind the<br />
driver’s cab. This set up allows the transport and erection<br />
of a gangway. The gypsy winch is used to moor the<br />
container ships in the harbour. With one vehicle two operations<br />
can thus be carried out effi ciently.
Mechanical<br />
winches<br />
<strong>Winch</strong> type Traction/Lifting<br />
power in daN.<br />
<strong>Cable</strong> speed<br />
m/min. at 540 1/min.<br />
type lifting pulling rescuing lower cable position untere Seillage<br />
<strong>Cable</strong> Ø<br />
in mm<br />
TECHNICAL DATA<br />
<strong>Cable</strong> length<br />
in m<br />
F 56 M1 HW 5.200 19,0 13,0 55 W<br />
<strong>Cable</strong><br />
intake*<br />
F 64.1 M1 5.450 / 6.400 9,1 13,0 45 E / W<br />
62 M2 6.083 / 7.000 29,0 11,0 100 O<br />
70.1 M1 6.083 / 7.000 29,0 11,0 100 W<br />
Hydraulic<br />
winches<br />
<strong>Winch</strong> type Traction/Lifting<br />
power in daN.<br />
<strong>Cable</strong> speed <strong>Cable</strong> Ø<br />
in mm<br />
type lifting pulling rescuing lower cable position lower cable position<br />
1st gear 2nd gear 1st gear 2nd gear<br />
<strong>Cable</strong> length<br />
in m<br />
<strong>Cable</strong><br />
intake*<br />
38.1 H 1 3.800 8,7 12,0 53 E / W<br />
40.1 H 1 4.000 16,6 12,0 80 O / R / W<br />
50.1 H 1 5.000 14,1 13,0 65 O / R / W<br />
50.2 H 1 5.000 1.224 10,2 43,2 13,0 80 O / R / W<br />
50 S H 1 5.500 9,1 13,0 65 W<br />
62.2 H 2 6.738 5.634 15 30 11,0 100 O<br />
64.1 H 1 <br />
70.1 H 1 <br />
5.000<br />
6.000<br />
7.000<br />
6.074<br />
7.000<br />
7,4<br />
6,4<br />
5,6<br />
13,0 45 E / W<br />
11,0 11,0 100 W<br />
70.2 H 1 7.000 1.713 5,7 24,2 14,3 70 O / R / W<br />
79.1 H 1 7.780 13,4 14,3 90 W<br />
80.2 H 1 8.000 5.639 4,5 6,4 16,5 60 O / R / W<br />
100.1 H 1 10.000 7,5 16,0 80 O / W<br />
100.2 H 1 10.000 6.562 4,3 6,9 18,0 80 O / R / W<br />
102.2 H 2 9.828 7.107 15,1 30,3 13,0 130 O<br />
250.1 H 1 24.730 4.578 6,9 37,7 26,5 90 O / W<br />
Functions<br />
Lifting, lowering,<br />
drum neutral position<br />
Pulling, drum neutral<br />
position<br />
Pulling, drum neutral<br />
position also while loaded,<br />
towing permitted<br />
Pulling, drum neutral<br />
position also while loaded,<br />
towing permitted<br />
Functions<br />
Lifting, lowering,<br />
drum neutral position<br />
Lifting, lowering,<br />
drum neutral position<br />
Lifting, lowering,<br />
drum neutral position<br />
Lifting, lowering,<br />
drum neutral position<br />
Lifting, lowering,<br />
drum neutral position,<br />
towing permitted,<br />
fulfi ls DIN 14584<br />
Pulling, drum neutral<br />
position also while loaded,<br />
towing permitted<br />
Pulling, releasing, drum<br />
neutral position<br />
Pulling, drum neutral<br />
position also with load,<br />
towing permitted<br />
Lifting, lowering,<br />
drum neutral position<br />
Pulling, drum neutral<br />
position also while loaded,<br />
towing permitted<br />
Lifting, lowering,<br />
drum neutral position<br />
Pulling, drum neutral<br />
position also while loaded,<br />
towing permitted<br />
Lifting, lowering<br />
drum neutral position<br />
Pulling, drum neutral<br />
position also while loaded,<br />
towing permitted<br />
Lifting, lowering,<br />
drum neutral position<br />
300.1 H 1 30.000 8,0 28,0 68 O Pulling, lowering<br />
* O = open, E = run-in opening, R = roller window, W = winding device<br />
19
Ehranger Straße 101<br />
D-54293 Trier<br />
12/08<br />
www.zuk.deGB AG, Kraemer<br />
Postfach 8051 Tel.: +49 (0) 651 6867-124 vertrieb@werner-trier.com<br />
&<br />
D-54181 Trier Fax: +49 (0) 651 64146 www.werner-trier.com<br />
Zink
