<strong>ATTIX</strong> <strong>40</strong> & <strong>ATTIX</strong> <strong>50</strong><br />
Wet and dry vacuum cleaners
<strong>ATTIX</strong> <strong>40</strong> & <strong>ATTIX</strong> <strong>50</strong><br />
Wet and dry vacuum cleaners<br />
Filter Cleaning As Standard<br />
Manual Push&Clean filter cleaning on all <strong>ATTIX</strong> <strong>40</strong><br />
& <strong>50</strong> PC models, and automatic XtremeClean filter<br />
cleaning on all <strong>ATTIX</strong> <strong>50</strong> XC models.<br />
High Performance & Capacity<br />
Container volumes from 37-47 litres mean the<br />
<strong>ATTIX</strong> <strong>40</strong> & <strong>50</strong> range can handle most applications.<br />
NEW improved turbine design provides high<br />
suction performance.<br />
Superior Wet Dirt Collection<br />
All NEW <strong>ATTIX</strong> vacuums include a PET filter which<br />
can be washed and is very hard wearing.<br />
To improve wet dirt collection the NEW range also<br />
features a 'fleece' filter bag. This NEW bag is more<br />
durable to wet dirt which means easier disposal.<br />
TECHNICAL SPECIFICATIONS<br />
*AS - Anti static hose<br />
* - Stainless steel container<br />
Distributed by:<br />
<strong>ATTIX</strong> <strong>40</strong>-01 PC<br />
INOX*<br />
<strong>ATTIX</strong> <strong>50</strong>-21 XC shown<br />
<strong>ATTIX</strong> <strong>50</strong>-01 PC<br />
110v/230v<br />
<strong>ATTIX</strong> <strong>50</strong>-21 PC<br />
110v/230v EC<br />
OPTIONAL ACCESSORIES (see product catalogue for further accessories)<br />
<strong>ATTIX</strong> <strong>50</strong>-21 XC<br />
110/230v<br />
High Mobility<br />
The <strong>ATTIX</strong> range is highly mobile with reinforced front<br />
castors providing excellent movement along all surfaces<br />
Cable & Accessory Storage<br />
Cable grip for easy cable storage, plus on-board storage<br />
for extension tubes and accessories.<br />
Auto On/Off Socket for Power Tools ( -21 versions)<br />
Electric Power Tool dust extraction socket on all '-21'<br />
models mean the vacuum will start and stop when<br />
the tool is operated, reducing noise and power waste.<br />
The speed control also gives you control of the suction<br />
power and noise level.<br />
<strong>ATTIX</strong> <strong>50</strong>-21 PC<br />
CLEAN ROOM<br />
Power (max) W 1<strong>50</strong>0 1100/1<strong>50</strong>0 1100/1<strong>40</strong>0 1100/1<strong>50</strong>0 1<strong>40</strong>0<br />
Power (PIEC) W 1200 1000/1200 1000/1100 1000/1200 1100<br />
Air flow l/min 3700 3200/3700 3200 3200/3700 3200<br />
Vacuum mbar 2<strong>50</strong> 230/2<strong>50</strong> 230 230/2<strong>50</strong> 230<br />
Working noise dB(A) 59 59 59/60 59 60<br />
Container volume l 37 47 47 47 47<br />
L x W x H mm 4<strong>50</strong> x 4<strong>40</strong> x 735 4<strong>50</strong> x 3<strong>50</strong> x 7<strong>50</strong> 4<strong>50</strong> x 3<strong>50</strong> x 7<strong>50</strong> 4<strong>50</strong> x 3<strong>50</strong> x 7<strong>50</strong> 4<strong>50</strong> x 3<strong>50</strong> x 7<strong>50</strong><br />
Weight kg 13 11 11 12 11<br />
Mains Connection (V/~/HZ) 230/1/<strong>50</strong> 110/1/<strong>50</strong>/32 amp 110/1/<strong>50</strong>/32 amp 110/1/<strong>50</strong>/32 amp 230/1/<strong>50</strong><br />
Standard Accessories:<br />
230/1/<strong>50</strong> 230/1/<strong>50</strong> 230/1/<strong>50</strong><br />
Hose (dia x length (m)) 36 x 3 36 x 3 27 x 3.5 AS* 27 x 3.5/5 AS* 36 x 5 AS*<br />
Curved tube <br />
Extension tube <br />
Fleece Filter Bag <br />
Filter Element PET <br />
Flat Filter PET <br />
H Class Filter element <br />
Disposal Bag <br />
Floor Nozzle <br />
Crevice Nozzle <br />
Tool adaptor <br />
Water Vacuuming Set<br />
3 piece set includes 2 x stainless steel <strong>50</strong>0mm<br />
suction tubes, special plastic floor nozzle and<br />
crevice nozzle - 7727<br />
Trade & Industry Set<br />
5 piece set includes 2 x stainless steel <strong>50</strong>0mm<br />
suction tubes, plastic crevice nozzle, large<br />
capacity floor nozzle with brush strips,<br />
replacement wet rubber lips, oil and heat<br />
resistant flat rubber nozzle - 63213<br />
<strong>ATTIX</strong> <strong>40</strong>-01 PC INOX shown<br />
<strong>ATTIX</strong> <strong>50</strong>-21 PC CLEAN ROOM<br />
This model offers H class filtration to suit clean room<br />
applications coupled with a unique brushless single<br />
phase electric motor. This makes it suitable for use in<br />
sensitive pharmaceutical or electronic manufacturing<br />
areas where the presence of carbon dust in the working<br />
atmosphere is not acceptable<br />
Vacuuming Kit for -21 model<br />
Includes crevice nozzle, brush nozzle, universal<br />
nozzle, professional floor tool, extension tubes<br />
and 3 metre hose - 302003703<br />
<strong>Nilfisk</strong>-<strong>ALTO</strong> (A Division of <strong>Nilfisk</strong>-Advance Limited)<br />
Bowerbank Way, Gilwilly Industrial Estate, Penrith, Cumbria CA11 9BQ<br />
Phone 01768 868995 ● Fax 01768 864713 ● www.nilfisk-alto.co.uk ● www.nilfisk-alto.ie<br />
sales.uk@nilfisk-alto.com ● sales.ie@nilfisk-alto.com<br />
No claims can be made on the basis of information or illustrations contained in<br />
literature. Subject to alteration of technical data, design and equipment<br />
FILTER CLEANING SYSTEMS<br />
Filter Cleaning System<br />
For fast and simple filter cleaning<br />
1. Block the inlet fitting or hose<br />
2. Push and release the filter<br />
cleaning button to activate air<br />
pulses which clean the filter<br />
from the inside out.<br />
Automatic Filter Cleaning System<br />
The filter is automatically cleaned<br />
while the machine is working.<br />
Automatic air pulses clean the<br />
filter from the inside out giving<br />
superior results.<br />
Air box (For -21 models)<br />
Allows the machine to be used as an automatic<br />
dust extractor for pneumatic power tools -<br />
107<strong>40</strong>0079/107<strong>40</strong>0394
