<strong>SINTERED</strong><br />
<strong>CARBIDE</strong><br />
FROM THE EXPERTS
Sintered carbide – known for endurance<br />
Expectations for structural components<br />
and tools are becoming more and more<br />
exacting. Optimizing manufacturing processes<br />
while achieving economy and<br />
profitability are always in the foreground.<br />
Sintered carbide is the material which<br />
will meet these expectations. Superior<br />
wear properties and superb precision are<br />
DURIT employs a workforce<br />
of more than 350 around the<br />
world. Its key markets are<br />
Europe and South America.<br />
your options for long service lives in dies,<br />
tools and other components.<br />
The specific application and the technical<br />
requirements are the determining factors<br />
when selecting the grade and<br />
specifying the details of the<br />
production process. DURIT is<br />
your one-stop supplier,<br />
manufacturing a wide range<br />
of sintered carbide tooling<br />
and components. The blanks<br />
are produced using the<br />
newest press technologies and HIP sintering<br />
furnaces. This is followed by machining with<br />
the latest in erosion units and both allpurpose<br />
and CNC grinding machines.
Ongoing investments and<br />
employee training form the basis<br />
for the latest manufacturing techniques<br />
and using the newest<br />
technologies.<br />
Development and engineering pave<br />
the way to excellence<br />
DURIT develops, engineers and<br />
manufactures tools and components<br />
made of sintered carbide for virtually<br />
every branch of industry –<br />
including the chemicals, medical,<br />
automotive, packaging, textiles,<br />
fasteners industries and for shaping<br />
and drawing technologies. Wherever<br />
wear is encountered in machines<br />
and systems, that‘s where our<br />
applications engineers devise<br />
DURIT – modern, with<br />
high performance and close<br />
to the customer<br />
practical and economical solutions<br />
incorporating sintered carbide<br />
components and tools.<br />
Ongoing refinements in materials<br />
and production processes have<br />
made DURIT a standard in sintered<br />
carbide technology.
Sintered carbide blanks<br />
in great shape<br />
Shaped components manufactured to<br />
drawings, with maximum dimensional<br />
accuracy both for immediate use and as<br />
blanks for tool and die making.<br />
Blanks fabricated with the<br />
HIP sintering technology<br />
Engineering components<br />
for the<br />
protection against<br />
wear<br />
They can be delivered in almost any<br />
complex geometry and in all standard<br />
grades, made up to drawings or samples. Abrasive and corrosive media place<br />
severe demands on components.<br />
The correct choice of materials has a<br />
decisive effect on product function<br />
and service life.<br />
Sintered carbide keeps wear within<br />
limits and extends tool lives many<br />
times over.
Due to its high<br />
rated hardness<br />
and excellent<br />
wear resistance<br />
sintered carbide<br />
is a contributing<br />
factor for an<br />
efficient<br />
production.<br />
steel<br />
cast iron<br />
stellite<br />
HARDNESS BY COMPARISON<br />
WC-Co<br />
0 250 500 750 1000 1250 1500 1750 2000 2250<br />
HV 30<br />
Al 2 O 3<br />
Valve and pump components,<br />
bushings and seal-rings, to name<br />
just a few.
High-performance plugs<br />
and drawing dies<br />
Working closely with customers in<br />
the field of tube and bar production,<br />
we engineer dies and plugs geometries<br />
and select a sintered carbide<br />
grade, tailored exactly to the<br />
specific application.<br />
Our line of dies and plugs covers<br />
the complete spectrum for tubing,<br />
bars and profiled sections.<br />
In the limelight here are process<br />
optimization in drawing operations<br />
and a perfect finished product.<br />
Long service lives with optimized<br />
sintered carbide grades
Tooling for metal<br />
packaging<br />
Sintered carbide is the ideal<br />
material for tooling used to manufacture<br />
cans, lids and other sheet<br />
metal containers.<br />
DURIT engineers and implements<br />
professional solutions for<br />
deep drawing, sinking, bending,<br />
beading, rolling and punching.<br />
Sintered carbide tools make a<br />
decisive contribution to optimizing<br />
production and ensure uniform<br />
product output for a long, long<br />
time.<br />
Cold heading tools from<br />
a single source<br />
Sintered carbide, whenever<br />
tool life is critical<br />
Cold heading and forming<br />
with success<br />
Tools used to manufacture fasteners<br />
require an extent know-how and flexibility<br />
in both engineering and manufacture.<br />
DURIT fabricates tools in countless complex<br />
geometries, starting with sintered carbide<br />
blanks and carrying through to precision<br />
tooling ready for use.<br />
Optimized sintered carbide grades,<br />
matched to the particular tool, extend<br />
service life and enable dimensional<br />
accuracy for the pressed components<br />
continously.
Reduced machine downtimes<br />
by using sintered carbide<br />
Shredding technology and<br />
surface refinement Blasting, grinding and pulverizing –<br />
these operations demand tooling that’s<br />
truly tough. Wearing components made<br />
up to customer specifications, fitted with<br />
sintered carbide inserts or made up of<br />
solid sintered carbide, are engineered for<br />
the specific application. These include<br />
sand-blasting nozzles and blasting lances<br />
for surface finishing, hot channel nozzles<br />
for injection molding technology, rotor bars<br />
and cutting blades to pulverize plastics,<br />
to name just a few.<br />
Tools determine performance
Precision tooling and<br />
machine components<br />
Sintered carbide stops<br />
at nothing<br />
Wear problems? Sintered carbide offers<br />
virtually unlimited capabilities. Forming,<br />
cutting and punching, calibrating, pressing,<br />
rolling – sintered carbide is the ideal<br />
material whenever you are dealing with<br />
Powder pressing and tablet<br />
compacting tools<br />
Powder pressing tools made of<br />
sintered carbide have proven their<br />
superiority when working highly<br />
abrasive media and in mass<br />
production. They multiply tool life<br />
when compared with conventional<br />
steel tools.<br />
Not only excellent wear resistance,<br />
but sintered carbide’s high<br />
compressive strength, too,<br />
makes for excellent results in<br />
many applications. Less<br />
frequent changes of tooling<br />
minimizes machine downtimes.<br />
severe requirements and heavy loading.<br />
Production is optimized, making for enduring,<br />
uniform quality in the final product.
Manufacturing process<br />
WC Co/Ni TiC TaC<br />
MIXING<br />
and<br />
MILLING<br />
LINEAR<br />
PRESSING<br />
PRE-SINTERING<br />
ISOST.<br />
PRESSING<br />
SHAPING<br />
DRYING<br />
HIP SINTERING<br />
DURIT offers maximum<br />
precision and uniform<br />
quality, verified by a quality<br />
assurance system certified<br />
to ISO 9001:2000<br />
PHYSICAL<br />
INSPECTION<br />
SINTERING EROSION<br />
GRINDING<br />
and POLISHING<br />
BLANKS FINAL INSPECTION
The ideal composition for<br />
every application<br />
GD 03F<br />
GD 08F<br />
GD 13F<br />
GD 16F<br />
GD 18F<br />
GD 05<br />
GD 10<br />
GD 15<br />
GD 20<br />
GD 30<br />
GD 40<br />
GD 50<br />
GD 60<br />
GD 10N<br />
GD 20N<br />
GD 08NC<br />
GD 10NC<br />
BD 10<br />
BD 20<br />
BD 30<br />
BD 40<br />
All DURIT products are made from a sintered<br />
material containing mainly tungsten carbide,<br />
which is the basis for its hardness, together with<br />
the cobalt which serves as the cement. The<br />
material‘s properties are largely determined by<br />
the amount of cement and the tungsten carbide<br />
grain size. Toughness rises with the share<br />
of cement while wear resistance declines. Fine<br />
grains will increase hardness and thus wear<br />
resistance. Coarse grain material will increase<br />
toughness and impact resistance.<br />
The table shows the<br />
standard DURIT grades;<br />
special compounds are<br />
available on request.<br />
GD 03F Micro grain GD 30 Medium grain BD 40 Coarse grain<br />
1500:1<br />
1500:1 1500:1<br />
The parameters of the application will<br />
determine which compound is ideal<br />
for any given purpose.<br />
And we also offer:<br />
✓ Regrinding service<br />
✓ 3-D CAD engineering<br />
✓ on-site consulting for sintered<br />
carbide applications<br />
✓ PVD coatings<br />
✓ thermal spraying coatings<br />
Ask for our separate information<br />
package!
